HIGH-RES
TOUCH SCREEN
DATA STORED ON
CLOUD PLATFORM
EASY SETUP
CertoLog
& CertoPID
Programmable data loggers
and PID controllers with
cloud access
CertoLog
CertoLog Touch
CertoLog Touch Industrial
SET CertoLog Touch + PT 100 sensor SET CertoLog Touch Industrial + PT 100 sensor
Printer
PT 100 port female plug (emtpy) PT 100 Sensor
USB cable PC Software
Temperature (PT100) data logger. High precision measurement electronics. Cloud connected for easy data handling and storage. Ports: PT 100, USB, RS 232 for printer. Includes power cable.
Same, but with Industrial grade rugged tablet controller (waterproof). Capacitative touch screen.
With PT 100 sensor (Cable length 100cm. Silicone cable. Submersible probe).
Receipt printer. Thermotransfer.
Plug for soldering a PT 100 sensor. 3 or 4 wire.
PT 100 sensor with cable and plug. Submersion head. Other heads on request. 200cm silicone cable.
USB A to USB B cable. Connects CertoLog to a PC. For data display and storage on a windows PC.
8510313 8510315 8510314 8510316 1300154 1300224 8510317 1300196 8510318
CertoCloud
The easy to use cloud platform
• Data storage
• Data visualisation
• User management
• Alarm messages
• API for LIMS
integration
MODELS
ACCESSOIRES
ART. NR.
ART. NR.
DESCRIPTION
DESCRIPTION
3 month use
included with
purchase
DATA LOGGER WITH
REVOLUTIONARY INTERFACE
AND CLOUD CONNECTION
CertoPID LCD
CertoPID Touch
CertoPID Touch Industrial
SET CertoPID LCD + PT 100 sensor SET CertoPID Touch + PT 100 sensor
SET CertoPID Touch Industrial + PT 100 sensor
Printer
PT 100 port female plug (emtpy) PT 100 Sensor
USB cable
PC Software Basic Version PC Software
Professional Version
Programmable PID Controller with solid state relay (SSR), max 2000 W. High precision measurement electronics. Basic version of PC Software (data display and storage) included. Simple programms (1 temperature, 1 time) and endless programs can entered via the controller. Professional Version of PC Software necessary for programms with multiple temperature and time steps, ports: PT 100, USB, RS 232 for printer, power out max 2000 W. Includes power cable and power connection cable with high heat plug C15A acc. to IEC 60320-1. Same as above with tablet PC Controller. Cloud connected for easy data handling and storage. Complex programs can be entered via tablet controller (no addtional software required).
Same as above, but with Industrial grade rugged tablet controller (waterproof). Capacitative touch screen.
As above, but with PT 100 sensor (cable length 100 cm, silicone cable, submersible probe).
Receipt printer. Thermotransfer.
Plug for soldering a PT 100 sensor. 3 or 4 wire. PT 100 sensor with cable and plug. Submersion head. Other heads on request. 200cm silicone cable. USB A to USB B cable. Connects CertoLog to a PC. For data display and storage on a windows PC.
For data display and storage on a windows PC. Addtionally complex programs (multiple time and temperature steps) can be entered. Only needed for CertoPID LCD. 8510319 8510320 8510321 8510322 8510323 8510324 1300154 1300224 8510317 1300196 8510318 8510318
MODELS
ACCESSOIRES
ART. NR.
ART. NR.
DESCRIPTION
DESCRIPTION
CertoPID
CertoCloud
The easy to use cloud platform
3 month use
included with
purchase
PROGRAMMABLE POWER
CONTROLLER (PID/SSR) AND
CLOUD ACCESS
• Data storage
• Data visualisation
• User management
• Alarm messages
• API for LIMS
EASY DATA ACCESS AND STORAGE.
ONLINE DEVICE MANAGEMENT.
Secure Connection
• SSL encryption • Secure server • 100 % data privacyCustomization
• Custom reports • Direct printing• Freely definable data formats
Email Notifications
• Alarms • Cycle complete• Process data
User Management
• Individual accounts • Accounts linked to devices
Multi Device Management
• Combine all devices in one account • Create programs
• Disseminate programs to all devices
Long Term
Data Storage
• All data stored for 10 years tofulfil documentation requirements • Secure backup
CertoCloud
THE USER INTERFACE WITH
ON-SCREEN TRAINING.
CertoTouch
Define custom programs
• With a simple interface you can program multi-step processes of temperature and time. E.g. 20 minutes at 110° C, then 3 hours at 120° C and then 1 hours at 80° C. • Long term cycles possible. Programming can be done in minutes, hours and days. • Program is graphically displayed.
• Programs can be named.
• One-click solution to program a fractioned venting process.
Choose program
• All programs are displayed as icons with name and key data. • Programs can be added an deleted.
• Full list of steps of each programm can be displayed.
Watch step-by-step video instructions
• All usage steps are explained in videos, e.g. when used as an autoclave the steps to load the unit are explained.
• No more need to train staff – the unit explains everything itself. • Videos can be skipped once staff is proficient in using the equipment.
Show status of running programs
• Current step of program is displayed. • Current data displayed.
• Time passed and remaining is displayed.
Scroll through protocol history
• Protocols are stored on the device.
• Target temperature and actual temperature are graphically displayed and accessible in numerical format.
