MAXSYS. High-End Integrated Security from DSC

High-End Integrated Security from DSC

M A X S Y S

C O M P R E H E N S I V E S E C U R I T Y

T H A T ’ S N O T C O M P L I C A T E D

Managing a business takes a lot of work, passion and commitment.

That’s why it’s important that the same effort be made when choosing

a security system. After all, properly protecting the people and other

valuable assets that comprise a successful business are not something

you want to jeopardize.

There was a time when building security consisted of little more than burglar

alarms, motion detectors and a few smoke detectors. Clearly times have

changed and the need for a premium security system is real.

In keeping with new times and new technologies, DSC has defined the meaning

of security, as is evident with MAXSYS. The security system allows a host of

value-added and life-safety features to be integrated to provide peace of mind

for years to come. Security concerns, whether they are intrusion, fire, alarm

communications, access control, automation, wireless/addressable expansion or

structured cabling, can be tailored to meet specific needs. MAXSYS is truly a

single-system solution that is ideal for commercial, industrial and institutional

facilities, as well as large or multi-level residential units.

Fully integrated security solutions

High-end, premium quality security

s

M A X S Y S

I N T R U S I O N C O N T R O L P A N E L S

Every business is unique. With MAXSYS you

can choose the best combination of

technologies to expand security needs

as necessary.

COMBUS expansion

Addressable loop expansion

Wireless expansion

16-128 Zone Control Panel

PC4020

• 16 zones on main control panel • Supports up to 16 hardwired keypads • Expandable to 128 zones using hardwire,

wireless modules and addressable zones • COMBUS hardwired expansion

• 8 partitions

• 1,500 user codes (4 or 6 digit) • 3,000-event buffer

• 9 account and 3 phone numbers • 1 supervised bell zone

• Built-in telephone line and siren supervision

• Auto SIA and Contact ID formats • Supports GS3050-A/GS3050-I GSM

universal wireless alarm communicators and T-Link™_{/T-Link TL250 network/Internet} alarm communicators

• Full upload/download support with DLS download software

K E Y P A D S

The MAXSYS LCD keypad puts security and

convenience at your fingertips. The keypad offers

end-users simple one-button activation of five

programmable function keys. For urgent situations,

keypad-activated emergency keys send an alarm

signal to the central monitoring station, which in

turn, notifies the proper authority (police, fire or

emergency services).

Programmable-Message LCD Keypad

LCD4501

• Connect up to 16 keypads

• Large, backlit, 2-line, 32-character display • Plain-language display of zone status, system

status, trouble conditions, event buffer, system instructions, date and time • Ready, Armed and Trouble LEDs • 5 programmable function keys • 4 keypad-activated alarms:

- Panic, Auxiliary, Fire and Duress

• Backlight boost

s

s

Internet Alarm Communicator

T-LINK TL250

T-Link TL250 Internet alarm communicators provide an always-on, two-way line of IP communication between DSC control panels and central monitoring station receivers. It works over the Internet or local LAN/WAN networks and installs easily, even behind firewalls.

Network Alarm Communicator

T-LINK

Low-cost T-Link network alarm communicators transmit alarm signals securely over an existing LAN/WAN network and then through the Internet to a central monitoring station. This is an ideal application for banks or large retail chains where significant networks have already been established and are being used for various purposes.

GSM Universal Wireless Alarm

Communicators

GS3050-A:

• Compatible with any control panel

• 4 inputs for the activation of voice messages and SMS dialer (optional NC2/VOX voice board module required for voice dialer)

• 2 SMS messages available on each input • Programmable voice/SMS dialer-channel activation • 8 telephone numbers available for the voice/SMS

dialer function

• 5 outputs (open collector) • Output control via SMS messaging • Dual-band (900 MHz and 1,800 MHz

GSM networks)

• SIM card (not included) programmable via any GSM cellphone or PC with the Windows™

compatible GS3050-A Software Application • Compatible with standard central monitoring

station receivers, like Sur-Gard™

• 7-segment status display

• Supports Contact ID, 10 bps and 20 bps protocols, and in areas with optimum signal strength, SIA and CESA protocols

GS3050-I:

The GS3050-I includes all of the same features as the GS3050-A, with the following exceptions. • Dual-band:

- I version (850 MHz/1,900 MHz networks) - IW version (900 MHz/1,800 MHz networks) • 4 outputs (open collector)

• Optional NC2/VOX voice board module is not available

• Not equipped with 7-segment status display • Includes GS3050-I Software Application

• Multiple receivers for larger coverage area or overlap

• New technology for greater signal range and accuracy

• Long-life lithium batteries • Attractive, compact designs • Easy to install, program and use

W I R E L E S S E X P A N S I O N

Use the PC4164-433 wireless receiver to support

up to 64 wireless zones and 16 wireless keys.

Up to eight backup receivers can be installed on

one system. Choose wireless devices from the

innovative line-up of DSC wireless solutions.

I N T E R N E T & N E T W O R K

A L A R M C O M M U N I C A T O R S

The award-winning DSC T-Link family of Internet

and network alarm communicators saves customers

money by taking advantage of their existing

Internet/Intranet networks to create fully supervised

security solutions between protected premises and

the central monitoring station.

G S M A L A R M C O M M U N I C A T I O N S

GSM universal wireless alarm communicators are an

effective backup or alternative to traditional

telephone lines and work by connecting the alarm

control panel to the GSM network to provide

protection against accidental line cuts.

M A X S Y S

A D D R E S S A B L E L O O P E X P A N S I O N

The Addressable Multiplexed Loop (AML) provides the ultimate in simple, flexible and affordable zone

expansion. Save time and money by connecting any addressable detector anywhere on the two-wire AML loop

to create up to 128 addressable zones.

Addressable Passive Infrared Detector

AMB-300

• Based on the Bravo®_{3 hardwire motion detector}

• Patented MLSP (Multi-Level Signal Processing) • Interchangeable lenses:

- Wall-to-wall lens (standard), curtain lens, pet-immune lens and corridor lens

• Built-in tamper switch

Addressable Pet-Immune Passive

Infrared Detector

AMB-600

• Based on the Bravo®_{6 hardwire motion detector}

• Patented MLSP (Multi-Level Signal Processing) • Provides pet immunity up to 85 lbs (38 kg) • Built-in tamper switch

Addressable Ceiling-Mount Passive

Infrared Detector

AMB-500

• Based on the Bravo®_{5 hardwire motion detector}

• Patented MLSP (Multi-Level Signal Processing) • Coverage diameter based on mounting height • Built-in tamper switch

Addressable Glassbreak Detector

AMA-100

• Based on the AcuityTM

hardwire glassbreak detector

• Detects all types of breaking glass

- Plate, laminated, safety and tempered

• Can be tested using the glassbreak simulator (AFT-100)

• Built-in tamper switch

Addressable Photoelectric Smoke Detectors

FSB-210 SERIES

• Automatic drift compensation

• Easy-maintenance removable smoke chamber • Non-contact sensitivity reading with

handheld test meter (FSD-100) • Self diagnostics

• UL listed

Addressable Point / Contact Modules

AMP-700 / AMP-701 / AMP-701NP / AMP-702 / AMP-704 / AMP-704F

• AMP-700 door/window contact with built-in reed switch

• AMP-701 door/window contact with normally closed input

• AMP-701NP universal addressable point module • AMP-702 fire point module with normally

open, EOL resistor supervised input

• AMP-704 4-zone door/window contact with normally closed, single or double EOL inputs

• AMP-704F 4-zone normally open fire input module

Loop Repeater / Isolator Module

AMX-400

• Can be used to repeat and re-power the AML loop to allow for longer wire runs:

- Requires 12 VDCpower source

• Will isolate the wire run in the event of a problem • Adds additional 170 mA

Loop Isolator Module

AML-770

• Can be used to isolate burglary detectors from fire detectors on the same wire run

M A X S Y S

D A T A I N T E R F A C E M O D U L E S

With the installation of data interface modules (PC4401), MAXSYS control panels are able to interface with

leading manufacturers of home and building automation products and audio distribution systems to create

seamless, fully integrated control solutions.

Data Interface Module

PC4401

• Connect up to 4 modules

• Capable of performing as either a bi-directional RS-232 interface, PC-Link isolator, printer module or DVACS®

* communicator (Canada only)

M O D U L E S

MAXSYS zone expanders can add eight zones or 16 zones where needed. Simply connect them to the COMBUS

for flexible, efficient and distributed zone expansion.

8 / 16 Hardwire Zone Expanders

PC4108A / PC4116

• PC4108A adds 8 hardwire zones • PC4116 adds 16 hardwire zones • AUX power rated at 250 mA

(PTC protected)

Power Supply / Relay

Output / COMBUS Repeater Module

PC4204CX

• Connect up to 16 modules • Fully supervised for AC failure,

low battery and AUX failure • 4 programmable form ‘C’ relays:

- Rated at 3 Amps @ 12 VDC

P O I N T & G R A P H I C A N N U N C I A T O R S

When emergencies occur, make certain operating and emergency personnel are able to understand the nature

of an alarm and are able to communicate the information needed for swift and effective action. With MAXSYS

point or graphic annunciators important, context-sensitive information is never more than a glance away. The

annunciators can display up to 144 zone, partition and system events.

32 / 64 Point & Graphic Annunciators

PC4632 / PC4664

• Egg-crate backplate for flexible LED locations • Pre-printed point display transparency • Clear transparencies (2) for custom graphics

• Real-time zone status • Fully programmable • 4-wire hook-up to COMBUS • FCC and IC listed

* DVACS is a registered trademark of Electro Arts Ltd. Scarborough, Ontario, Canada.

16-Output Module

PC4216

• Provides 16 programmable outputs:

- Rated at 50 mA @ 12 VDC

• Connect up to 9 PC4216 modules per system

M A X S Y S

M A X S Y S F I R E P R O D U C T S

MAXSYS fire products provide all the equipment

needed to integrate full commercial fire into any

security application. MAXSYS fire products are only

approved for North American regulations.

PC4020CF LCD4521 PC4701 PS4350R PC4204CXCF PC4702BP

Commercial Fire Panel

PC4020CF

• Includes all the features of the PC4020 plus:

- PC4050CR cabinet - PC4701 module

- Built-in 16 VAC, 40 VA transformer

Programmable Fire-Message LCD Keypad

LCD4521

• Includes all the features of the LCD4501 keypad • Red bezel

• Fire function keys:

-Silence Trouble, Silence Bells, Fire Reset, Fire Drill and Lamp Test

Dual-Line Dialer Module

PC4701

• Dual, supervised phone line connections • 1 2-wire Class B/Style B supervised

smoke alarm zone

• 1 Class B/Style B waterflow zone • Fire alarm and fire trouble form ‘C’ relays

External Battery Charger

PS4350R

• Includes PS4085 multi-rate charger module • Includes PT1012 transformer, 12 VDC, 160 VA

• Space for 60 Ah of rechargeable batteries

Commercial Fire Power Supply

PC4204CXCF

• Includes all the features of the PC4204CX • Includes PC4052CR cabinet

• Built-in 16 VAC, 40 VA transformer

Dual-Zone Bell Panel

PC4702BP

• Connect up to 4 modules

• Provides 2 alarm notification circuits: -Rated at 1.8 Amps @ 24 VDCeach

• Fully supervised outputs for open, short and ground fault

• PTC protected • Includes:

- PC4052CR red cabinet - 28 VAC, 180 VA transformer

M A X S Y S

2-Reader Access Control Module

PC4820

• Connect up to 16 modules • Multiple reader technologies • 2 supervised lock outputs:

- 250 mA per output

• 64 user access levels • 99 date schedules • 4 holiday groups

• Arm/Disarm partitions via access control • PC4053 beige cabinet included

A C C E S S C O N T R O L

Monitoring and restricting the individual entry of tens or

perhaps a thousand people within a building is not easy. To

protect it from theft or damage, MAXSYS allows simple and

affordable access control integration with its alarm systems.

Readers

• MAXSYS supports a wide range of 26-bit Weigand readers:

- Polaris™, ioProx™, Shadowprox™, HID and Kantech XSF Technologies

M A X S Y S A C C E S S C O N T R O L K I T

This affordable package is the perfect access control

starter kit. It has all the essentials you need: control

panel, access control module, reader and keys in one

low-cost package. And, if needed, the system can be

easily expanded.

• 1 PC4020 control panel • 1 PC4820 access control module • 1 P225W26 ioProx reader • 10 P40KEY ioProx dual-encoded

proximity keys

Request-to-Exit Detector

T-REX™

• Passive infrared request-to-exit detector with patented X-Y Targeting™_{and DSP}

M A X S Y S

Telephone Interface & Automation

Control Module

ESCORT™ 4580

• Turns any touchtone telephone into a talking keypad

• Programmable labels:

- 6 words per label - 240+ word library

• Built-in X-10 interface:

- Supports up to 32 X-10 devices - 16 schedules, 8 modes

• Available in English, Spanish and French

C O N C O U R S E E

E X

X P

P

™

_{S T R U C T U R E D C A B L I N G}

ConcourseEXP is the best value in residential structured

cabling. It provides new home builders and home-system

integrators with the convenience of a single, comprehensive

family of cable management products that are easy to use in

applications of all sizes and complexity. ConcourseEXP

enclosures and low-voltage modules have been designed to

provide seamless integration with MAXSYS control panels

and modules.

H O M E A U T O M A T I O N

Imagine a security system that controls home lighting automatically. With MAXSYS control panels lights can

be programmed to automatically turn on and off according to a daily, weekend or monthly schedule. These

tasks can be controlled by turning any touchtone phone into a fully functional keypad that can be used to

monitor and control a security system from home or from anywhere in the world.

D L S 2 0 0 2 S A S Y S T E M A D M I N I S T R A T O R

™

_{S O F T W A R E}

DLS2002SA System Administrator software is the perfect solution for large or multi-location business

applications using the MAXSYS control panel. The software is simple to use and gives users the ability to view

and change codes, access cards and schedules, as well as view system status, arm/disarm partitions, and view,

sort and print the event buffer. The software can be found in the Products area of the DSC website under the

password-protected software section.

M A X S Y S

®

I N T E G R A T E D S Y S T E M S T E C H N O L O G Y

G S 3 0 5 0 - A G S M U N I V E R S A L W I R E L E S S A L A R M C O M M U N I C A T O R G S 3 0 5 0 - I G S M U N I V E R S A L W I R E L E S S A L A R M C O M M U N I C A T O R

A D D R E S S A B L E E X P A N S I O N

S E R I A L I N T E R F A C E

I N T R U S I O N

A M B - 3 0 0 A D D R E S S A B L E P A S S I V E I N F R A R E D D E T E C T O R A M A - 1 0 0 A D D R E S S A B L E G L A S S B R E A K D E T E C T O R A M B - 5 0 0 A D D R E S S A B L E C E I L I N G - M O U N T P A S S I V E I N F R A R E D D E T E C T O R A M B - 6 0 0 A D D R E S S A B L E P E T - I M M U N E P A S S I V E I N F R A R E D D E T E C T O R F S B - 2 1 0 S E R I E S A D D R E S S A B L E P H O T O E L E C T R I C S M O K E D E T E C T O R S A M P - 7 0 0 / A M P - 7 0 1 A M P - 7 0 1 N P / A M P - 7 0 2 A M P - 7 0 4 / A M P - 7 0 4 F A D D R E S S A B L E C O N T A C T M O D U L E S A M X - 4 0 0 L O O P R E P E A T E R / I S O L A T O R M O D U L E A M L - 7 7 0 L O O P I S O L A T O R M O D U L E

A L T E R N A T E

C O M M U N I C A T I O N S

T - L I N KTM N E T W O R K A L A R M C O M M U N I C A T O R T - L I N KTM _{T L 2 5 0} I N T E R N E T A L A R M C O M M U N I C A T O R 2 - W I R E A D D R E S S A B L E L O O P ( S ) W L S 9 2 5 L - 4 3 3 W I R E L E S S D O O R / W I N D O W C O N T A C T W L S 9 0 4 P L - 4 3 3 W I R E L E S S P A S S I V E I N F R A R E D D E T E C T O R W L S 9 1 2 L - 4 3 3 W I R E L E S S G L A S S B R E A K D E T E C T O R W S 4 9 1 6 W I R E L E S S P H O T O E L E C T R I C S M O K E D E T E C T O R W S 4 9 3 9 4 - B U T T O N W I R E L E S S K E Y P C 4 1 6 4 - 4 3 3 W I R E L E S S R E C E I V E R 4 - W I R E C O M B U S P C 4 2 0 4 C X P O W E R S U P P L Y / R E L A Y O U T P U T / C O M B U S R E P E A T E R M O D U L E P C 4 1 0 8 A / P C 4 1 1 6 8 / 1 6 H A R D W I R E Z O N E E X P A N D E R S L C D 4 5 0 1 P R O G R A M M A B L E -M E S S A G E L C D K E Y P A D P C 4 2 1 6 1 6 P R O G R A M M A B L E O U T P U T M O D U L E W I R E L E S S E X P A N S I O N L C D 4 5 2 1 P R O G R A M M A B L E F I R E - M E S S A G E L C D K E Y P A D P C 4 7 0 1 D U A L - L I N E D I A L E R M O D U L E P C 4 7 0 2 B P D U A L - Z O N E B E L L P A N E L P C 4 2 0 4 C X C F C O M M E R C I A L F I R E P O W E R S U P P L Y E S C O R TTM_{4 5 8 0} T E L E P H O N E I N T E R F A C E & A U T O M A T I O N C O N T R O L M O D U L E D L S 2 0 0 2 S A S Y S T E M A D M I N I S T R A T O RTM S O F T W A R E

W I N D O W S S O F T W A R E

L O C A L / R E M O T E C O N T R O L W I T H V O I C E P R O M P T T - R E XTM R E Q U E S T T O -E X I T D -E T -E C T O R M U L T I P L E R E A D E R T E C H N O L O G I E S

A C C E S S C O N T R O L

F I R E A L A R M

P C 4 6 3 2 / 4 6 6 4 3 2 / 6 4 P O I N T & G R A P H I C A N N U N C I A T O R S

A U T O M A T I O N

P C 4 8 2 0 2 - R E A D E R A C C E S S C O N T R O L M O D U L E F S A - 2 1 0 / 4 1 0 S E R I E S 2 / 4 - W I R E P H O T O E L E C T R I C S M O K E D E T E C T O R S D L S 2 0 0 2 D O W N L O A D I N G S O F T W A R E P C 4 4 0 1 D A T A I N T E R F A C E M O D U L E W L S 9 1 4 - 4 3 3 W I R E L E S S P E T - I M M U N E P A S S I V E I N F R A R E D D E T E C T O R P S 4 3 5 0 R E X T E R N A L B A T T E R Y C H A R G E R

Distributed by:

For product information www.dsc.com

Product specifications and availability subject to change without notice. Certain product names mentioned herein may be trade names and/or registered trademarks of other companies. ©2006 2006•05 P / N 3 0 0 0 0 3 5 0 R 0 0 1 P ri n te d in C a n a d a

M A X S Y S

A M E R I C A N L I S T I N G S

Category Description Applicable Standard

APAW Police station alarm units (commercial burglary) UL365, UL1635 AMCX Central station alarm units (commercial burglary) UL1610, UL1635 AOTX Local alarm units (commercial burglary) UL609, UL1635 NBSX Household burglar alarm units UL1023 UTOU Control units and accessories UL985 UOJZ Control units system (commercial fire) UL864 ALVY Access control system units UL294

E U R O P E A N L I S T I N G S

This product is in conformity with EMC directive 89/336EEC, R&TTE directive 1999/5/EC and low voltage directive 73/23/ECC based on results using the harmonized standards: CISPR Class B, EN50130-4, TBR21, EN60950-1.

A U S T R A L I A N L I S T I N G S

The product carries the A-Tick, Australian compliance mark, indicating that it meets the minimum safety and network integrity standards set by the ACA and can legally be connected to the telecommunications network in Australia.

C H I N E S E L I S T I N G S

Certification under MII (Network Access License) and CCC (Burglar Alarm Systems) CCC Standard: General Specifications for Burglar-Alarm Control Units GB 12663-2001

MII standards: GB/T 15279-2002,YD/T 868-1996, YD/T 968-2002, YD/T 965-1998, YD/T 993-1998

C A N A D I A N L I S T I N G S

Description Applicable Standard

Central station fire alarm system units CAN/ULC-S527 Central monitoring station burglar alarm system units CAN/ULC-S302 Local alarm units (commercial burglary) CAN/ULC-S303 Household burglar alarm system units CAN/ULC-S310 Household fire warning system units CAN/ULC-S545 Access control system units UL294
