Mobile DVR
Vehicle Use 4 Chs Video Record GPS Support GSM onlineMonitoring
Mobile, 4-CH H.264 Digital Video Recorder with
Removable Host
KG-132M
Overview
The Mobile DVR system's removable design provides for instant playback of recorded footage, maximum reliability at minimal cost.
The Mobile DVR system records and provides Security center online GPS position and live video & audio through IE & GPRS/3G Mobile Phone & Online Video monitoring continuously when the vehicles ignition is on.With KGUARD Mobile DVR system, no driver interaction is required at any time! No video can be unintentionally missed or erased!
With optional GPS receiver, the location and speed of the vehicle is recorded along with the video feed, ensuring essential data is immediately and easily available should it be needed; excellent for court admissible evidence.
Features
- Removable DVR host, 1 Din Size (The host could be player in Office directly) - Anti-shock and anti-vibration mechanical structure
- GPS Support: The SH132M can locate the vehicles positions on Google™ Earth and record car speeds and routes.
- GSM Router(GSM350WH: 3.5G/GPRS-Edge/WiFi) Support: 3G network built up to transmit the live image and audio to central control center; support DDNS
- Two way Audio communication capabilities - Event trigger by car speed
- Audio Broadcasting facilitates administrator easy to manage multiple SH132M through one IE - Simple USB Backup & SD Card
- Supported Multi-language
- Smart search: provides smart search of “Mark specific Area” for quicker search
- Highly efficient compression technology –H.264 (for better video quality & smaller file size) - Digital watermark to Prevent film to be altered.
- Playback search by time or event (alarm, motion, video loss, acceleration, & speed) - 1 internal 2.5” SATA hard drive
- Multi-Operation: Remote controller, keypad, and mouse operation (optional) - RS-232 and RS-485 for PTZ, keyboard control,
- Automatic DDNS configuration
- Delay-on/off function can prevent SH132M from voltage surge damage when the vehicles ignition is on & off. - Immediately remote trigger I/O devices via IE remote software & Mobile Phone
- Remote view via Mobile Phone/IE/CMS2000
- Free Bundle powerful CMS IE remote management software, control up to 64chs on one screen & no limitation for number of DVR. - Optional KGuard Hybrid CMS2000 Server: powerful managing control for all the cars and integrate other KGuard security devices all together. - OCX SDK available for the integration with different applications
Application
Airplane
Mass Rapid Transit
Truck
School Bus
Removable Host
Car Speed Pulse
Mobile DVR
Power HDD LAN Video loss Failure 1 2 3 4 LAN SDPanel Layout
Back Panel
(Removable DVR Host)
Front Panel
Bracket
Hold Dock
Back Panel
(Hold Dock)
1 2
PS/2 Mouse Connector
Main Monitor Output VGA Connector (VGA, optional)
3 Outer Chamber Signal Connector
4 Main Monitor Output Connectors (VIDEO OUT)
5 Audio Output Connectors (AUDIO OUT 1-2)
6 NTSC/PAL Selector Switch
7 Power Inlet (5V IN)
1 2
In PTZ & Playback Mode Control Button Split Windows Buttons (+/-)
3 MENU / ESC Button
4 Stop / PTZ Button
5 MODE Button
6 Play / Pause Button
7 Copy / CALL Button
8 Key Lock
9 Alpha-numeric Buttons
10Ethernet Connector
11USB connector (USB)
12SD slot
8 9
Main Monitor Output VGA Connector RS-232 for POS / GPS Connector
10 Alarm Input Connectors (ALARM IN 1-4)
11Video In/Out & I/R Remote Connector
12 Audio In/Out & Y/C Out Connector
13 Alarm In/Out & RS-485 Connectors
14 Power Inlet (POWER 12-24V)
MOUSE VGA (OPTIONAL) VIDEO OUT
NTSC PAL AUDIO OUT5V IN #1 #2 1 2 3 4 5 6 7 VIDEO IN / OUT & IR REMOTE VGA (OPTIONAL AUIDO IN / OUT & Y/C OUT
RS-232 #2 (OPTIONAL)
RS-232 #1 DELAY ON 30A
ALARM OUT
ALARM IN CAR SPEED C 1 2 C V + - G C 1 2 3 4 G SPD G NC NO12VRS-485 POWER 12-24V ACC VIN GND ACC VIN GND 8 9 10 11 12 13 14 1 2 4 5 6 7 8 3 9 10 11 12 Microphone
1.Alarm System (I/O) 2.Speeddome (RS-485) 3.Dashboard(Car speeding pulse)
VIDEO IN / OUT & IR REMOTE
VGA (OPTIONAL
AUIDO IN / OUT & Y/C OUT
RS-232 #2 (OPTIONAL)
RS-232 #1 DELAY ON 30A
ALARM OUT
ALARM IN CAR SPEED
C 1 2 C V + - G C 1 2 3 4 G SPD G NC NO12VRS-485 POWER 12-24V ACC VIN GND ACC VIN GND Ignition Battery Site A.-Driver CSN(P)-3210 Site B.-Passenger CSN(P)-3242 Site C.-Front CSN(P)-5710 Site D.-Rear CSN(P)-3320 composite video POS loudspeaker CRT Monitor In Vehicle Camera GPS Receiver GR-213
Mobile DVR
Touch Board Controller
IR Remote Controller
(Standard 1din size design)
CCTV Camera Microphone
Host DVR Player
MonitoringApplication Diagram
Power HDD LAN Video loss Failure 1 2 3 4 LAN SD SD Card DVD/RW Flash Disk Battery Video/Audio In Control Device RS-2321.Install on the roof of bus
2.Install into the Car Stereo Console
Installation
Video OutMobile Phone Live View & I/O Control GSM Router
(DDSN)
Ethernet
Connection Diagram(
Front Panel
)
GSM Router GSM-350WH GPS Receiver
Mobile DVR
SH-132M
Removable Host
Remote Site Monitoring
Google Earth Online
video & Position Data
Playback Monitoring
Backup
Mobile DVR
System DVR Host Video Audio Hold Dock Video Audio Record Display Playback Storage Alarm Network O.S. Multiplex Certification Format Input Main monitor Loss detection Motion detection Input Output Main monitor Output CompressionFrame rate (IPS) & Resolution Watermark Mode Pre-record time Post-record time Resolution Split windows Frame rate Freeze Sequential switch Digital Zoom
Frame rate (IPS) & Resolution Search Operation HDD Partitions Backup Input Output Buzzer Triggered by Event log Ethernet Web E-mail FTP Video Audio Protocol Remote users Bandwidth Remote stations Embedded Linux 2.6
Six fold operation - simultaneous record, live, playback, backup, control & remote access FCC, CE, LVDS, PSE, etc.
NTSC/EIA or PAL/CCIR
4-CH, BNC connector, 1Vp-p/75ohm CVBS x 1, S-video x 1, 1Vp-p/75ohm Optional VGA D-SUB 15-pin connector Yes
Yes, with configurable detection area & sensitivity 2 RCA-jack connector, line-in level (100mV-2Vrms) 2 RCA-jack connector, line-out level (up to 2Vrms) VGA Out
CVBS (RCAx1) 2 RCA
Video: H.264 Baseline Profile Audio: ADPCM NTSC – 30 / 720*480, 60 / 720*240, 120/360*240 PAL – 25 / 720*576, 50 / 720*288, 100 / 360*288 Yes Manual/Schedule/Alarm/Motion/Acceleration/Speed 0 - 10 seconds 0 - 60 minutes NTSC – 720*480, PAL – 720*576 1/4
Up to 30 (NTSC) / 25 (PAL) IPS per camera Yes
User adjustable X2, X4
NTSC – 30 / 720*480, 60 / 720*240, 120/360*240 PAL – 25 / 720*576, 50 / 720*288, 100 / 360*288
Smart search, Date/time, Camera, Alarm, Motion, Video Loss, & Acceleration Play, Fast Forward, Backward, Pause, Stop, etc.
Remote I.E.
1 set of 2.5” SATA type HDD, Max. 500GB HDD storage size Configurable alarm partition size / Configurable auto-overwrite or not 1 SD slot
1 USB 2.0 ports for USB 2.0 disk drives, DVD+RW, DVD+R, DVD-R, card readers, HDD, etc. 4 contact or TTL/CMOS signal, polarity selectable
1 Normally Open, 1 Normally Closed relay output Yes
Sensor input, Video loss, Motion, & Acceleration Yes
1 RJ-45 10/100BaseT Ethernet connector
Remote setup, monitoring, backup, alarm notification, & remote software upgrade 1 I.E. for multiple DVRs
Configurable HTTP/Control/Data port
Alarm notification to stationary or mobile devices Alarm video/audio file storage
1/4 split-window & SEQ mode for I.E. Bidirectional
TCP/IP, HTTP, PPPoE, DHCP, DDNS, FTP, TSP Up to 6 users simultaneously
TCP/IP type dynamic sliding window control PC, mobile phone, or PDA
Mobile DVR
Control / GPS / Car Speed
Setup
Reliability
Weights & Measures Power
Operating Temperature
- HSDPA speed up to 3.6Mbits/s (7.2 Mbits/s) - One WAN port for ADSL
- One LAN port - Wireless LAN
- Wide range of DC power supply (Optional 8~27VDC input ) Suitable for battery operation - Hardware reset when system hangs Suitable for environment without attendance
I/R RS-232 RS-485 Car speed Local Remote Multi-lingual System recovery Watch Dog Timer Timer Security Operating shock Operating vibration Dimension Weight(Net) Source Consumption - Removable DVR Host - Hold Dock Delay ON/OFF Delay out
1 I/R remote controller through built-in sensor or wired remote sensor 2 D-type female connector for PTZ or GPS
2-pin for PTZ control or GPS
2-pin for car speeding pulse input with configurable parameters or from GPS (Car Maker will offer this target spec. for specific design.)
On screen setup via keypad and/or I/R remote controller Setup & upload via Windows application software Yes
Auto power on after power loss recovery Yes
Built-in real time clock
Time synchronization with TSP server or GPS Key lock for DVR host
Multi-level password (3 levels, up to 18 accounts) protection for remote access 8G, 11ms (20 per five seconds max)
5~500Hz, 0.75G (0 to peak) 178(W) x 193 (D) x 50(H)mm 1.8 KG (without HDD) 12~24VDC DC5V@2A DC12V-24V@2A
Yes, with configurable timer 20A delay output
0o C ~ +50o C
Specification
(Model No. GSM-350WH) Dimension:22.4cmx14cmx6.4cmAccessory
GSM Router
(Model No. GR-213)GPS Reciver
Bracket
Top View
Side View
22.4cm 6.4cm 14cm- Builds on SiRFstarIII chipset with embedded ARM7TDMI CPU available for customized applications in firmware.
- Built-in hardware Tracking Loop Processor WAAS/EGNOS Demodulator support.
- Built-in repeatable and rechargeable Lithium-ion battery for Time- to- First-Fix(TTFF).
- 20 parallel satellite-tracking channels for fast acquisition and reacquisition.
- 200,000 effective correlators for fast TTFF, and Extremely fast TTFF’s at low signal level.
- Support NMEA 0183 v2.2 data protocol.
- Enhanced algorithms provide superior navigation performance in urban, canyon and foliage environments.
- For Car Navigation, Marine Navigation ,Fleet Management ,AVL and Location-Based Services , Auto Pilot ,Personal Navigation or touring devices ,Tracking devices/systems and Mapping devices application.
