CAT FILTER AND FILTER APPLICATION GUIDE

(1)

Cat

®

Filter & Fluid

Application Guide

2005

(2)

Cat UHE Air Filters:

Improve filtration efficiency for

better, longer engine protection

• Reduced engine wear.

Particles collect on the

filter’s very fine fiber

surface layer; quickly

building a cake that

allows less dust to

reach the engine.

• Higher efficiency. This surface particle cake is more

porous than dust-coated media fibers, causing less

restriction throughout filter life.

• Better engine performance and fuel economy.

Low filter restriction allows the engine to “breathe”

easier, so it takes less power to pull in air.

• Longer filter life. The unique surface lasts twice as

long as standard media, limiting filter changes and

the chance of contamination control.

For more information, contact your local Cat Dealer

or visit the Caterpillar website at www.cat.com

(3)

Total Support. One Source. Your Cat Dealer.

As your Cat dealer, we define world-class product support. We offer you the right

parts and service solutions, when and where you need them.

We are proud to offer you over 1,500 Caterpillar parts listed in this first edition

of the Caterpillar Filter and Fluid Application Guide. You can count on genuine

Cat parts to deliver performance and long life, because they are built to high-quality,

original equipment specifications.

We carry most parts listed in the guide in stock for your immediate, off-the-shelf

convenience. And thanks to Caterpillar’s worldwide distribution system, we can

deliver most other parts within 24 hours.

Our highly trained experts offer you comprehensive service options to keep

your equipment up and running, maximizing your investment. Whether you

are maintaining one machine or many, the support you get from us makes the

difference that counts every day.

This guide is organized into eight major categories, focusing on Cat equipment:

● Filters – application guide for all Cat equipment, product information,

filtration upgrade options, and data sheets.

● Lubricants – general application guide for all Cat equipment, product

information, part numbers, and data sheets.

● Coolants – general application guide for all Cat equipment, part

numbers, product information, and data sheets.

● Greases – general application guide for all Cat equipment, grease

selection guide, part numbers, and data sheets.

● S·O·S Oil Analysis – general application guide and data sheets.

● Media – comprehensive collection of Caterpillar filter and fluid

brochures, data sheets, sales aides, catalogs, training materials,

and videos.

● Index – quick reference page for key information.

Very truly yours,

Ken Hoefling

Parts Products Manager

Caterpillar Product Support Division

(4)

Filters. . . 1

Application Guide:

Agricultural Equipment. . . 1

Articulated Trucks . . . 3

Backhoe Loaders . . . 5

Compactors. . . 9

Excavators . . . 12

Forest Machines . . . 33

Integrated Toolcarriers . . . 37

Material Handlers . . . 40

Motor Graders . . . 42

Multi Terrain Loaders . . . 46

Off-Highway Tractors . . . 47

Off-Highway Trucks . . . 48

Paving Equipment . . . 54

Pipelayers . . . 62

Skid Steer Loaders . . . 63

Telehandlers . . . 65

Track Loaders . . . 67

Track-Type Tractors . . . 70

Underground Mining Equipment. . . 84

Wheel Dozers . . . 86

Wheel Loaders . . . 88

Wheel Tractor-Scrapers . . . 99

Product Information:

Micron Ratings . . . 103

Filter Upgrade Quick Reference . . . 106

Upgrade Options . . . 108

Cat Turbine PreCleaner Application Guide . . . 122

Data Sheets:

Air Filters:

Cat Cabin Air Filters – PEHJ0092 . . . 126

Cat UHE Air Filters – PEHP6028-02 . . . 128

Cat Turbine PreCleaners – PEHP7077-02 . . . 130

Cat Air Filter Service Indicator – PEHP9013-02 . . . 132

Engine Oil Filters:

Cat Advanced Efficiency Engine Oil Filters – PEHJ0068 . . . 134

Fuel Filters:

Cat Fuel Water Separators and

PrimeTime Priming Pumps – PEHJ0082 . . . 136

Fuel Contamination Control for

3500 Series Cat Engines – PEHP7045-01 . . . 138

Fuel Contamination Control – PEHP7046-01 . . . 140

Hydraulic & Power Train Filters:

Cat Hydraulic & Power Train Filters – PEHJ0069 . . . 142

Lubricants . . . 147

Application Guide . . . 147

Part Numbers . . . 152

Product Information:

Cat Backhoe Loader Brake Oil Additive . . . 154

Data Sheets:

Cat DEO 15W-40, 10W-30 (North America) – PEHJ0059-01 . . . 156

Cat DEO 15W-40, 10W-30 (Worldwide) – PEHJ0021-02 . . . 158

(5)

Lubricants

(continued)

Data Sheets (continued):

Cat DEO 15W-40 (Egypt and Saudi Arabia) – PEHJ0091. . . 162

Cat DEO SYN 5W-40 (Worldwide) – PEHP7062-02 . . . 164

Cat DEO Monograde 30, 40 (Worldwide) – PEHJ0093 . . . 166

Cat TDTO 10W, 30, 50 – PEHP7506-10 . . . 168

Cat TDTO-TMS Synthetic Blend – PEHP8035-01. . . 170

Cat FDAO 60 – PEHP9530-03. . . 172

Cat FDAO SYN Multigrade – PEHP9570-01 . . . 174

Cat HYDO 10W (North America) – PEHJ0009-01. . . 176

Cat HYDO 30 (Outside North America) – PEHP9544-02 . . . 178

Cat MTO Multigrade – PEHP3050-03. . . 180

Cat GO 80W-90, 85W-140 – PEHP7508-06 . . . 182

Cat Synthetic GO 75W-140 – PEHJ0030-01 . . . 184

Cat NGEO 30, 40 – PEHP0004-04 . . . 186

Cat NGEO EL350 40– PEHJ0006-01. . . 188

Coolants . . . 191

Application Guide . . . 191

Part Numbers . . . 197

Product Information:

Cat SCA . . . 198

Cooling System Cleaner – Standard . . . 198

Cooling System Cleaner – Quick Flush . . . 199

Coolant Conditioner Test Kit. . . 199

223-9116 ELC Dilution Test Kit. . . 199

Data Sheets:

Cat ELC 50/50 Premix – PEHJ0067-01 . . . 200

Cat DEAC Concentrate – PEHP9554-02 . . . 202

Cat NGEC Premix 50/50 – PEHJ0040-01 . . . 204

Greases . . . 207

Application Guide . . . 207

Selection Guide . . . 213

Part Numbers . . . 214

Data Sheets:

Cat Advanced 3Moly Grease NLGI Grade 2 – PEHP0002-01 . . . 218

Cat Ultra 5Moly Grease NLGI Grade 1, 2 – NEHP6010-01. . . 220

Cat Arctic Platinum Grease NLGI Grade 0 – NEHP6011-01 . . . 222

Cat Desert Gold Grease NLGI Grade 2 – NEHP6012-01 . . . 224

Cat High Speed Ball Bearing Grease NLGI Grade 2 – NEHP6015-01 . . . 226

Cat Multipurpose Grease NLGI Grade 2 – PEHJ0088 . . . 228

S·O·S Oil Analysis . . . 231

Application Guide . . . 231

Data Sheets:

Making the Most of S·O·S Services – PEHP7052-01 . . . 234

Media . . . 243

(6)

Cat

Filter & Fluid

(7)

Filters – Agricultural Equipment

35 powered by 3116 Engine

ADK1-UP

Air – Cab Recirculation 1 117-6843 Air – Cab Vent 1 116-5796 * Air Primary – Radial Seal 1 6I-2501 * Air Secondary – Radial Seal 1 6I-2502 Breather – Engine 1 2W-9162 Breather – Hydraulic 1 9G-9981 Breather – Power Train 1 9G-9981

Engine Oil 1 1R-0739 *

Fuel Secondary – Advanced 2 1R-0751 Fuel/Water Separator 1 151-2409

Hydraulic 1 152-6902 *

Hydraulic 1 1G-8878 *

35 NA powered by 3116 Engine

1DR1-UP

Air – Cab Vent 1 116-5796 * Air Primary – Radial Seal 1 6I-2501 * Air Secondary – Radial Seal 1 6I-2502 Breather – Engine 1 2W-9162 Breather – Power Train 1 9G-9981

Fuel Primary 1 9M-2341

Fuel Secondary – Advanced 1 1R-0751

45 powered by 3116 Engine

3BK1-UP

Air – Cab Recirculation 1 117-6843 Air – Cab Vent 1 116-5796 * Air Primary – Radial Seal 1 6I-2501 * Air Secondary – Radial Seal 1 6I-2502 Breather – Engine 1 2W-9162 Breather – Power Train 1 9G-9981 Fuel Secondary – Advanced 2 1R-0751 Fuel/Water Separator 1 151-2409

45 NA powered by 3116 Engine

8DN1-UP

55 powered by 3126 Engine

6NN1-UP, AEN1-UP

Air – Cab Recirculation 1 117-6843 Air – Cab Vent 1 116-5796 * Air Primary – Radial Seal 1 6I-2501 * Air Secondary – Radial Seal 1 6I-2502 Breather – Engine 1 2W-9162 Breather – Power Train 1 9G-9981

55 NA powered by 3126 Engine

7DM1-UP

65C powered by 3306 Engine

2ZJ1-UP

Air – Cab Recirculation 1 105-4968 * Air Primary – Radial Seal 1 6I-0273 * Air Secondary – Radial Seal 1 6I-0274 Breather – Engine 1 8S-0248 Breather – Power Train 1 9G-5127

Hydraulic 1 9T-0973 * Power Train 1 8S-9129 Screen 1 8S-9130 Screen – Hydraulic 1 3S-3875

65D US powered by 3306 Engine

2ZJ1-UP

Hydraulic 1 6E-5215

Hydraulic 1 6E-6407

Hydraulic 1 6E-6409

Power Train 1 6E-5596

Strainer 1 9J-3047

65E US powered by 3176 Engine

6GS1-UP

Air – Cab Recirculation 1 105-4968 * Air Primary – Radial Seal 1 6I-0273 * Air Secondary – Radial Seal 1 6I-0274 Breather – Engine 1 9Y-4357 Breather – Power Train 1 9G-5127

Hydraulic 1 9T-0973 *

Hydraulic – Fire Resistant 1 134-3014

Power Train 1 8S-9129

Screen 1 8S-9130

Screen – Hydraulic 1 3S-3875

70C US powered by 3306 Engine

2YL1-UP

Air – Cab Recirculation 1 105-4968 * Air Primary – Radial Seal 1 6I-0273 * Air Secondary – Radial Seal 1 6I-0274 Breather – Engine 1 8S-0248

Fuel Secondary – Advanced 1 1R-0749 Fuel Secondary – Advanced 1 1R-0750

Hydraulic 1 6E-5215 Hydraulic 1 6E-6409 Hydraulic 1 9T-0973 * Power Train 1 8S-9129 Screen 1 8S-9130 Strainer 1 9J-3047

75C powered by 3176 Engine

4KK1-UP

Screen 1 8S-9130

Screen – Hydraulic 1 3S-3875

Air Filters

●

Radial Seal Design – No tools are required, so service times and maintenance

costs are minimized.

●

One-Piece Molded Urethane End Caps – Forms a tough, reliable

corrosion-proof bond to paper media. Up to 30% more seal contact area for a seal that is

more reliable than conventional elements.

●

Densely Pleated Filter Paper – Large media area provides superior capacity

without impeding airflow.

●

Built-in Pleat Support and Positive Pleat Spacing – Prevents pleat bunching

and ensures optimum filter media surface area.

●

Heavy-duty Metal Inner and Outer Wrap – Increases structural strength

and durability.

●

Baked-on Enamel Outer Filter Wrap – Resists corrosion.

AGRICULTURAL EQUIPMENT

(8)

*Refer to higher performance filter options on pages 108-109 for efficiency upgrade information and fire resistant options available.

75D US powered by 3176 Engine

5AR1-UP

Screen 1 8S-9130

Strainer 1 9J-3047

75E US powered by 3176 Engine

6HS1-UP

Power Train 1 8S-9129 Screen 1 8S-9130 Screen – Hydraulic 1 3S-3875

75 US powered by 3176 Engine

4CJ1-UP

Air – Cab 1 7X-6023

Air Primary – Axial Seal 1 7W-5495 Air Secondary – Axial Seal 1 1P-7360 Breather – Engine 1 9Y-4357 Breather – Power Train 1 9G-5127

Hydraulic 1 1G-8878 * Hydraulic 1 9T-0973 * Screen 1 8S-9130 Screen – Hydraulic 1 3S-3875

85C US powered by 3176 Engine

9TK1-UP

Air – Cab Recirculation 1 105-4968 * Air Primary – Radial Seal 1 6I-2505 * Air Secondary – Radial Seal 1 6I-2506 Breather – Engine 1 9Y-4357

Screen 1 8S-9130

Strainer 1 9J-3047

85E US powered by 3196 Engine

6JS1-UP

Power Train 1 8S-9129 Screen 1 8S-9130 Screen – Hydraulic 1 3S-3875

CH65 powered by 3306 Engine

7YC1 – UP

Air – Cab 1 7T-8944 Air – Cab 1 7T-8945 Air – Cab 1 7T-8946

Air Primary – Axial Seal 1 7W-5316

CH35 powered by 3116 Engine

8RD1-UP

Air – Cab Recirculation 1 117-6843 Air – Cab Vent 1 116-5796 * Air Primary – Radial Seal 1 6I-2501 * Air Secondary – Radial Seal 1 6I-2502 Breather – Engine 1 2W-9162 Breather – Power Train 1 9G-9981 Fuel Secondary – Advanced 2 1R-0751 Fuel/Water Separator 1 151-2409

CH95E powered by 3196 Engine

6KS1-UP

Air – Cab Advanced 1 139-3204 Air – Cab Recirculation 1 105-4968 * Air Primary – Radial Seal 1 6I-2505 * Air Secondary – Radial Seal 1 6I-2506

LEXION 460 powered

by 3126B Engine

9FW 1-UP

Air Primary 1 151-3453 Air Secondary 1 151-3455 Breather – Engine 1 2W-9162 Fuel Primary 1 133-5671 Fuel Secondary – Advanced 1 1R-0751 Fuel/Water Separator 1 133-5673 Hydraulic 1 149-3298 Strainer 1 149-3334

9FW1-UP

Air – Cab 1 147-9728 Air Primary 1 151-3453 Air Secondary 1 151-3455 Breather – Engine 1 2W-9162 Engine Oil 1 1R-0739 * Fuel Primary 1 133-5671 Fuel Secondary – Advanced 1 1R-0751 Fuel/Water Separator 1 133-5673 Hydraulic 1 149-3298 Strainer 1 149-3334

LEXION 465 powered

by 3126B Engine

3HZ 1-UP

Air – Cab 1 147-9728 Air Primary 1 151-3453 Air Secondary 1 151-3455 Breather – Engine 1 2W-9162 Engine Oil 1 1R-0739 * Fuel Primary 1 133-5671 Fuel Secondary – Advanced 1 1R-0751 Fuel/Water Separator 1 133-5673 Hydraulic 1 149-3298 Strainer 1 149-3334

LEXION 470 powered

by 3126, 3126B Engine

9TW 1-UP

Air – Cab 1 147-9728 Air Primary 2 151-3453 Air Secondary 1 151-3455 Engine Oil 1 1R-0739 *

Fuel Secondary – Advanced 2 1R-0751 Fuel/Water Separator 1 133-5673 Hydraulic 1 149-3298

LEXION 480 powered

by 3176 Engine

8ZW1-UP

Fuel Primary 1 133-5671

9BZ 1-UP

Air – Cab 1 147-9728 Air Primary 1 151-3453 Air Secondary 1 151-3455 Breather – Engine 1 9Y-4357

Fuel Secondary – Advanced 1 1R-0762 Fuel/Water Separator 1 133-5673 Hydraulic 1 149-3298

LEXION 485 powered

by 3176 Engine

8ZW 1-UP

Air – Cab 1 147-9728 Air Primary 1 151-3453 Air Secondary 1 151-3455 Breather – Engine 1 2W-9162 Breather – Engine 1 9Y-4357

Coolant 1 148-0503

Fuel Primary 1 133-5671 Fuel/Water Separator 1 133-5673

Hydraulic 1 149-3298

Qty. P/N Qty. P/N Qty. P/N

(9)

Filters – Articulated Trucks

Filters – Articulated T

rucks

615C powered by 3306 Engine

2XG1-U, 5TF1-UP

Air – Cab A/C 1 7G-6599 Air – Cab Recirculation 1 8P-5142 Air Primary – Axial Seal 1 7W-5316 Breather – Power Train 1 9G-5127

Hydraulic 2 1R-0732 *

Power Train 1 1R-0719 *

725 powered by 3176C Engine

AFX1-UP

Air – Cab 1 174-8145

Air – Cab A/C 1 119-3355 *

Air – Dryer 1 175-7162

Air – Dryer A/C 1 175-7162 Air Primary 1 142-1339 * Air Secondary 1 142-1403 Air Secondary 1 142-1404 Breather – Engine 1 9Y-4357 Breather – Power Train 1 9G-5127

Power Train – UHE 1 139-1537 *

730 powered by 3196 Engine

AGF1-UP

Air – Cab 1 174-8145

Air – Cab A/C 1 119-3355 *

Air – Dryer 1 175-7162

Air Primary 1 142-1339 * Air Secondary 1 142-1403 Air Secondary 1 142-1404 Breather – Engine 1 9Y-4357

735 powered by 3406E Engine

AWR1-UP

Air – Cab 1 174-8145

Air – Dryer 1 175-7162

Air Primary 1 142-1340 * Air Secondary 1 142-1403 Breather – Engine 1 9Y-2988 Breather – Hydraulic 1 157-7911 Breather – Hydraulic 1 8X-4575

Engine Oil 1 196-5540

Fuel Secondary – Advanced 1 1R-0749 Fuel/Water Separator 1 133-5673 Power Train – UHE 1 139-1537 * Power Train – UHE 3 132-8876 *

740 powered by 3406E Engine

AXM1-UP

Air – Cab 1 174-8145

Air – Dryer 1 175-7162

Air Primary 1 142-1340 * Air Secondary 1 142-1403 Breather – Engine 1 9Y-2988 Breather – Hydraulic 1 157-7911 Breather – Hydraulic 1 8X-4575

Power Train – Fire Resistant 1 4T-3131 Power Train – UHE 2 132-8876 *

740 Ejector powered

by 3406E Engine

AZZ1-UP

Air Primary 1 142-1340 * Air Secondary 1 142-1403 Engine Oil 1 1R-0716 *

D20D EN powered by 3116 Engine

9MG1-UP

Air Primary – Axial Seal 1 7W-5316 Air Secondary – Axial Seal 1 2S-1287 Breather – Engine 1 2W-9162 Breather – Power Train 1 6U-1989

Hydraulic 1 1R-0720 Hydraulic 1 2U-7441 Power Train 1 1R-0719 * Strainer 1 4D-1998 Strainer 1 9J-3047

D250D EN powered

by 3116 Engine

6NG1-UP

Air Primary – Axial Seal 1 7W-5316 Air Secondary – Axial Seal 1 2S-1287 Breather – Engine 1 2W-9162 Breather – Power Train 4 6U-1989

Hydraulic 1 1R-0720 Hydraulic 1 2U-7441 Power Train 1 1R-0719 * Strainer 1 4D-1998 Strainer 1 9J-3047

D250E EN powered

by 3306 Engine

5TN1-UP

Air – Cab 1 8C-9657

Air Primary – Radial Seal 1 6I-0273 * Air Secondary – Radial Seal 1 6I-0274 Breather – Engine 1 2W-9162 Breather – Hydraulic 1 160-5615 Breather – Power Train 1 9G-5127 Breather – Power Train 3 6U-1989

Power Train 1 1R-0719 * Power Train 2 1R-0741 * Screen 1 6J-3795 Screen 4 8M-7160 Screen – Hydraulic 1 119-4885 Screen – Hydraulic 1 3S-3875 Strainer 1 5D-7927

Liquid Filters

●

One-Piece Aluminum Base Plate has added reinforcing to prevent ruptures due

to cold starts.

●

One-Piece Canister provides structural strength and anti-rupture protection.

●

Self-Lubricating, Free-Rotating Seal prevents bunching, eliminates leaks.

●

One-Piece Urethane End Caps have a tighter bond with filter media that

provides greater strength.

●

Spiral Roving and Acrylic Beads maintain pleat stability and spacing for

maximum efficiency, no bunching and maximum capacity.

●

Non-Metallic Center Tube is stronger than metal to prevent collapsing, prevents

metal contamination.

ARTICULATED TRUCKS

(10)

D250E II powered by 3306 Engine

4PS1-UP

Air – Cab 1 8C-9657

Air – Cab A/C 1 119-3355 * Air – Dryer A/C 1 175-7162 Air Primary – Radial Seal 1 6I-0273 * Air Secondary – Radial Seal 1 6I-0274 Breather – Engine 1 2W-9162 Breather – Power Train 1 9G-5127 Breather – Power Train 4 6U-1989

D25C powered by 3306 Engine

9YC1-1011

Air Primary – Axial Seal 1 7W-5495 Air Secondary – Axial Seal 1 1P-7360

Coolant 1 2U-2148 Engine Oil 1 1R-0739 * Power Train 1 1R-0719 * Power Train 1 1R-0741 *

D300B powered by 3306 Engine

4SD1-573

Fuel Secondary – Advanced 1 1R-0750 Power Train – Fire Resistant 1 4T-3131

Screen 1 6U-5728

D300E EN powered

by 3306 Engine

7FN1-UP

Air – Cab 1 8C-9657

Air Primary – Radial Seal 1 6I-0273 * Air Secondary – Radial Seal 1 6I-0274 Breather – Engine 1 2W-9162 Breather – Hydraulic 1 160-5615 Breather – Power Train 1 9G-5127 Breather – Power Train 2 6U-1989

Hydraulic 2 1R-0720 Power Train 1 1R-0719 * Screen 4 8M-7160 Screen – Hydraulic 1 119-4885 Screen – Hydraulic 1 3S-3875 Strainer 1 4D-1998

D300E II powered by 3306 Engine

5KS1-UP

Air – Cab 1 8C-9657

Air – Cab A/C 1 119-3355 * Air – Dryer A/C 1 175-7162 Air Primary – Radial Seal 1 6I-0273 * Air Secondary – Radial Seal 1 6I-0274 Breather – Engine 1 2W-9162 Breather – Power Train 1 9G-5127 Breather – Power Train 4 6U-1989

D30C powered by 3306 Engine

7ZC1-257

Coolant 1 2U-2148 Engine Oil 1 1R-0739 * Power Train 1 1R-0719 * Power Train 1 1R-0741 *

D350C powered by 3306 Engine

8XC1-404

Coolant 1 2U-2148

D350E powered by 3406 Engine

9LR1-UP

Air – Cab 1 7X-6012 *

Air Primary – Radial Seal 1 6I-0273 * Air Secondary – Radial Seal 1 6I-0274

Coolant 1 2U-6391

D35C powered by 3306 Engine

2GD1-124

Coolant 1 2U-2148

D35 HP powered by 3406 Engine

3FD1-79

Engine Oil 1 2P-4005

D400 powered by 3406B Engine

1MD1-246

Engine Oil 1 2P-4005

D400E powered by 3406 Engine

2YR1-UP

Air – Cab 1 7X-6012 *

Coolant 1 2U-6391

Power Train 1 1R-0719 * Power Train 3 1R-0741 *

D400E II powered

by 3406E Engine

8PS1-UP

Air – Cab 1 7X-6012 *

Air – Dryer A/C 1 106-5532 Air Primary – Radial Seal 1 6I-0273 * Air Secondary – Radial Seal 1 6I-0274

Breather 1 136-1602

Breather – Hydraulic 1 157-7911 Breather – Power Train 1 6U-1989

Engine Oil 1 1R-0716 * Fuel/Water Separator 1 133-5673 Power Train 1 1R-0719 * Power Train 1 1R-0741 * Screen – Hydraulic 1 119-4885 Strainer 1 5D-7927 Strainer – Fuel 1 9P-7121

APF1-UP

Air – Cab 1 7X-6012 *

Air – Cab Heater 1 9X-4717 Air Primary – Radial Seal 1 123-6855 * Air Secondary – Radial Seal 1 123-6856

Breather 1 136-1602

Breather – Hydraulic 1 8X-4575

D44B powered by 3408 Engine

8SD1-UP

Air Primary – Axial Seal 1 1P-8483 Air Secondary – Axial Seal 1 1P-8482

D550B powered by 3408 Engine

5ND1-UP

Air Primary – Axial Seal 1 1P-8483 Air Secondary – Axial Seal 1 1P-8482

(11)

Filters – Backhoe Loaders

416 powered by T4.236 Engine

5PC 1-UP

Air – Cab Recirculation 1 7T-3549

Air Primary 1 8N-5504 Air Secondary 1 4W-6691 Engine Oil 1 7W-2327 Fuel Primary 1 7W-6268 Fuel Secondary 1 067-6987 Hydraulic 1 1R-0722 * Hydraulic 1 1R-0735 * Power Train 1 119-4740

416B powered by 3054 Engine

8SG1-11999

Air Primary 1 8N-5504 Air Secondary 1 4W-6691 Engine Oil 1 7W-2326 Engine Oil 1 7W-2327 Fuel Secondary 1 159-6102 Hydraulic 1 9T-0973 * Power Train 1 119-4740

8SG12000-UP

Air Primary 1 8N-5504 Air Secondary 1 4W-6691 Engine Oil 1 7W-2326 Engine Oil 1 7W-2327 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic 1 9T-0973 * Power Train 1 119-4740

8ZK1-5999

Air Primary 1 8N-5504 Air Secondary 1 4W-6691 Engine Oil 1 7W-2326 Engine Oil 1 7W-2327 Fuel Secondary 1 159-6102 Hydraulic 1 108-1153 * Power Train 1 119-4740

8ZK6000-UP

Air Primary 1 8N-5504 Air Secondary 1 4W-6691 Engine Oil 1 7W-2326 Engine Oil 1 7W-2327 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic 1 108-1153 * Power Train 1 119-4740

416C powered by 3054 Engine

1AR1-UP, 1KR1-UP, 1XR2250-UP,

4ZN1-16043

Air 1 104-9481 Air – Cab 1 133-7488 Air Secondary 1 110-6331 Engine Oil 1 7W-2326 Engine Oil 1 7W-2327 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic 1 108-1153 * Power Train 1 119-4740

1WR1-8115

Air Secondary 1 110-6331 Engine Oil 1 7W-2326 Engine Oil 1 7W-2327 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic 1 108-1153 *

Power Train 1 119-4740

1WR8116-UP, 1XR2184-2249,

4ZN16044-UP, 5YN15148-UP

Air 1 104-9481 Air – Cab 1 133-7488 Air Secondary 1 110-6331 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic 1 108-1153 * Hydraulic – Advanced 1 126-1817 * Power Train 1 119-4740

1XR1-2183, 5YN1-15147

Air 1 104-9481 Air – Cab 1 133-7488 Air Secondary 1 110-6331 Engine Oil 1 7W-2326 Engine Oil 1 7W-2327 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic 1 108-1153 * Hydraulic 1 9T-0973 * Power Train 1 119-4740

1ZR1-UP

Air 1 104-9481 Air – Cab 1 133-7488 Air Secondary 1 110-6331 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic 1 108-1153 * Power Train 1 119-4740

416D powered by 3054 Engine

BFP05178-UP, CXP1-UP

Air – Cab 1 170-7272

Air – Cab Recirculation 1 206-7514 Air Secondary 1 110-6331 Breather – Hydraulic 1 9R-9925 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 121-4480 Fuel/Water Separator 1 131-1812 Hydraulic – Fire Resistant 1 134-3014

BFP12900-UP, BGJ01050-UP

Air – Cab 1 170-7272

Air – Cab Recirculation 1 206-7514

Air Primary 1 227-7448 Air Secondary 1 227-7449 Breather – Hydraulic 1 9R-9925 Engine Oil 1 7W-2326 Fuel/Water Separator 1 228-9130 Hydraulic – Advanced 1 126-1817 * Power Train 1 119-4740

BFP1-UP

Air – Cab 1 170-7272

Air – Cab Recirculation 1 206-7514 Air Secondary 1 110-6331 Breather – Hydraulic 1 9R-9925 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 121-4480 Fuel/Water Separator 1 131-1812 Hydraulic – Advanced 1 126-1817 * Hydraulic – Fire Resistant 1 134-3014

BGJ1-UP, BKG1-UP

Air – Cab 1 170-7272 Air Secondary 1 110-6331 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic – Advanced 1 126-1817 * Power Train 1 119-4740

BKG01300-UP

Air – Cab 1 170-7272 Air Secondary 1 110-6331 Breather – Hydraulic 1 9R-9925 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 121-4480 Fuel/Water Separator 1 131-1812 Hydraulic – Fire Resistant 1 134-3014

Air Filters

●

Radial Seal Design – No tools are required, so service times and maintenance

costs are minimized.

●

One-Piece Molded Urethane End Caps – Forms a tough, reliable

corrosion-proof bond to paper media. Up to 30% more seal contact area for a seal that is

more reliable than conventional elements.

●

Densely Pleated Filter Paper – Large media area provides superior capacity

without impeding airflow.

●

Built-in Pleat Support and Positive Pleat Spacing – Prevents pleat bunching

and ensures optimum filter media surface area.

●

Heavy-duty Metal Inner and Outer Wrap – Increases structural strength

and durability.

●

Baked-on Enamel Outer Filter Wrap – Resists corrosion.

BACKHOE LOADERS

(12)

416 II powered by 3054B Engine

5PC 1-UP

Breather – Power Train 1 7T-3251

420D powered by 3054 Engine

BGP00648-UP

Air – Cab 1 170-7272 Air Secondary 1 110-6331 Breather – Hydraulic 1 9R-9925 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 121-4480 Fuel/Water Separator 1 131-1812 Hydraulic – Fire Resistant 1 134-3014

BKC00920-UP, BLN10300-UP,

BMC01060-UP, FDP18400-UP

Air – Cab 1 170-7272

BKC1-UP, BMC1-UP, FDP1-UP

BLN04544-10299, FDP07199-UP

Air – Cab 1 170-7272

BLN1-UP

424D powered by 3054 Engine

BGP1-UP, BKR1-UP

CJZ1-UP, RXA1-UP

Air – Cab 1 170-7272

426 powered by D4.236 Engine

7BC1-UP

Air Secondary 1 4W-6691

426B powered by 3054 Engine

5J1-UP

Air Primary 1 8N-5504

Air Secondary 1 4W-6691 Bowl – Fuel Filter 1 7W-4481 Breather – Hydraulic 1 9R-9925 Breather – Power Train 1 7T-3251

Engine Oil 1 7W-2327

Fuel Secondary 1 6I-0589

Screen – Hydraulic 1 6E-4192

5YJ1-2299, 6KL1-1199

Air Primary 1 8N-5504 Air Secondary 1 4W-6691 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Hydraulic 1 9T-0973 * Power Train 1 119-4740

5YJ2300-UP

Air Primary 1 8N-5504 Air Secondary 1 4W-6691 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Hydraulic 1 108-1153 * Hydraulic 1 9T-0973 * Power Train 1 119-4740

6KL1200-UP

Air Primary 1 8N-5504 Air Secondary 1 4W-6691 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic 1 108-1153 * Hydraulic 1 9T-0973 * Power Train 1 119-4740

426C powered by 3054 Engine

1CR1-863, 1ER900-UP, 1MR1-955,

1NR1050-UP, 1YR1-1516, 1ZR1000-UP,

6XN1-3615, 7WN1100-UP

Air Primary 1 104-6040 Air Secondary 1 110-6331 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic 1 108-1153 * Hydraulic 1 9T-0973 * Power Train 1 119-4740

1CR864-UP, 1ER864-899, 1MR956-UP,

1NR954-1049, 1YR1517-UP, 1ZR926-999,

6XN3616-UP, 7WN939-1099

Air Primary 1 104-6040 Air Secondary 1 110-6331 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic 1 9T-0973 * Hydraulic – Advanced 1 126-1817 * Power Train 1 119-4740

1ER1-863, 1NR1-953, 1ZR1-925, 7WN1-938

Air Primary 1 104-6040 Air Secondary 1 110-6331 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic 1 108-1153 * Hydraulic 1 9T-0973 * Power Train 1 119-4740

426 II powered by 3054 Engine

7BC1-UP

Air – Cab 1 7T-3519

Air Primary 1 8N-5504 Engine Oil 1 7W-2327 Fuel Primary 1 7W-6268 Fuel Secondary 1 067-6987 Hydraulic 1 119-4740 Hydraulic 1 1R-0722 * Hydraulic 1 1R-0735 *

428 powered by T4.236 Engine

6TC1-6563

Air Primary 1 8N-5504 Air Secondary 1 4W-6691 Engine Oil 1 7W-2327 Fuel Primary 1 7W-6268 Hydraulic 1 1R-0722 * Hydraulic 1 1R-0735 * Power Train 1 119-4740

428B powered by 3054 Engine

3KK1-2999

3KK3000-UP

7EJ1-5999

Engine Oil 1 7W-2326 Fuel/Water Separator 1 131-1812 Hydraulic 1 108-1153 *

7EJ1-UP

Engine Oil 1 6I-0510

Fuel Secondary 1 159-6102

7EJ6000-UP

428C powered by 3054 Engine

1HR1-300, 8RN1-4088

Air Secondary 1 110-6331 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic 1 9T-0973 * Power Train 1 119-4740

1SR1-UP, 8RN4089-UP

Air Secondary 1 110-6331 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic – Advanced 1 126-1817 * Power Train 1 119-4740

2CR1-UP

Air Primary 1 104-6040 Air Secondary 1 110-6331 Engine Oil 1 7W-2326 Engine Oil 1 7W-2327 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic 1 4T-4520 Hydraulic – Advanced 1 126-1817 * Power Train 1 119-4740

(13)

Filters – Backhoe Loaders

_{Filters – Backhoe Loaders}

428C powered by 3054 Engine

(cont’d)

8RN1-UP

Air Primary 1 104-6040 Air Secondary 1 110-6331 Engine Oil 1 7W-2326 Engine Oil 1 7W-2327 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic 1 4T-4520 Power Train 1 119-4740

428D powered by 3054 Engine

BLL1-UP, BNB1-UP

Air – Cab 1 170-7272 Engine Oil 1 7W-2326 Engine Oil 1 7W-2327 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic – Advanced 1 126-1817 * Power Train 1 119-4740

BMT1-UP

Air – Cab 1 170-7272 Air Secondary 1 110-6331 Breather – Hydraulic 1 9R-9925 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 121-4480 Fuel/Water Separator 1 131-1812 Hydraulic – Advanced 1 126-1817 * Hydraulic – Fire Resistant 1 134-3014

BNS1-UP

BXC1-UP, DSX1-UP, MBM1-UP

Air – Cab 1 170-7272

428 II powered by 3054 Engine

6TC8000 – UP

Air – Cab 1 7T-3519

Air Primary 1 8N-5504 Air Secondary 1 4W-6691 Engine Oil 1 7W-2327 Fuel Secondary 1 067-6987 Hydraulic 1 119-4740 Hydraulic 1 1R-0722 * Hydraulic 1 1R-0735 *

428 II powered by 3054 Engine

6TC6564-7999

430D powered by 3054 Engine

BML02281-04799, BML02281-UP

Air – Cab 1 170-7272

BML04800-UP, BNK05900-UP

Air – Cab 1 170-7272

BML1-UP, BNK1-UP

BNK02502-UP

Air – Cab 1 170-7272

432D powered by 3054 Engine

BLD1-UP

TDR1-UP, WEP1-UP

Air – Cab 1 170-7272

436 powered by 4.236 Engine

5KF1-UP

Air – Cab 1 7T-3519

Air Secondary 1 4W-6691 Bowl – Fuel Filter 1 7W-4481 Breather – Power Train 1 7T-3251

Engine Oil 1 7W-2327 Fuel Primary 1 7W-6268 Fuel Secondary 1 067-6987 Hydraulic 1 1R-0722 * Hydraulic 1 1R-0735 * Power Train 1 119-4740

436B powered by 3054 Engine

6JM1-UP

Fuel Secondary 1 6I-0589

6MJ1-UP

Air Primary 1 8N-5504 Air Secondary 1 4W-6691 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Hydraulic 1 9T-0973 * Power Train 1 119-4740

7FL1-UP

Air Primary 1 8N-5504 Air Secondary 1 4W-6691 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic 1 9T-0973 * Power Train 1 119-4740

436C powered by 3054 Engine

1Fire Resistant1-1415, 1GR950-UP,

1PR1-1598, 1RR998-UP, 2BR911-UP, 8TN1-924,

9JN884-UP

Air Secondary 1 110-6331 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic 1 108-1153 * Power Train 1 119-4740

1Fire Resistant1416-UP, 1GR916-949,

1PR1599-UP, 2AR1604-UP, 8TN925-UP

Air Secondary 1 110-6331 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic – Advanced 1 126-1817 * Power Train 1 119-4740

1GR1-915, 1RR1-997, 2BR1-910,

7WN1-UP, 9JN1-883

Air – Cab 1 133-7488 Air Secondary 1 110-6331 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic 1 108-1153 * Hydraulic 1 9T-0973 * Power Train 1 119-4740

2AR1-1603

Air Secondary 1 110-6331 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic 1 108-1153 *

438 powered by 4.236 Engine

3DJ1-827

Air – Cab 1 7T-3519

Air Secondary 1 4W-6691 Breather – Power Train 1 7T-3251

Fuel Primary 1 7W-6268

(14)

438 powered by 4.236 Engine

(cont’d)

3DJ828-UP

Air – Cab 1 7T-3519

Breather – Power Train 1 7T-3251

Engine Oil 1 7W-2327 Fuel Secondary 1 067-6987 Hydraulic 1 1R-0722 * Hydraulic 1 1R-0735 * Power Train 1 119-4740

438B powered by 3054 Engine

3KK1-2999

3KK3000-UP

Engine Oil 1 7W-2327 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic 1 108-1153 * Hydraulic 1 119-4740 Hydraulic 1 9T-0973 *

438C powered by 3054 Engine

1JR1107-UP, 1TR1284-1549,

2DR2717-3249, 9KN1061-1199,

9KN1400-UP

Air Primary 1 104-6040 Air Secondary 1 110-6331 Engine Oil 1 7W-2326 Engine Oil 1 7W-2327 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic 1 4T-4520 Hydraulic – Advanced 1 126-1817 * Power Train 1 119-4740

1JR1-1106, 1TR1-1283, 1TR1550-UP,

2DR3250-UP, 9KN1-1060

Air Primary 1 104-6040 Air Secondary 1 110-6331 Engine Oil 1 7W-2326 Engine Oil 1 7W-2327 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic 1 108-1153 * Hydraulic 1 4T-4520 Power Train 1 119-4740

2DR1-2716

Air Secondary 1 110-6331 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 131-1812 Hydraulic 1 108-1153 * Hydraulic – Advanced 1 126-1817 * Power Train 1 119-4740

438D powered by 3054 Engine

BPE1-UP

BPN1-UP

438 II powered by 3054 Engine

3DJ828-UP

Air – Cab 1 7T-3519

Air Secondary 1 4W-6691 Bowl – Fuel Filter 1 7W-4481 Breather – Power Train 1 7T-3251

Engine Oil 1 7W-2327 Fuel Secondary 1 067-6987 Hydraulic 1 119-4740 Hydraulic 1 1R-0722 * Hydraulic 1 1R-0735 *

438 II powered by 3054 Engine

3DJ828-UP

442D powered by 3054 Engine

BRG1-UP

BRY1-UP

SMJ1-UP, TBD1-UP

Air – Cab 1 170-7272

446 powered by 3114 Engine

6XF1-UP

Air Primary – Axial Seal 1 7W-3920 Air Secondary – Axial Seal 1 7C-1062

Engine Oil 1 1R-0714

Hydraulic 1 1G-8878 * Hydraulic 1 1R-0722 * Hydraulic 1 1R-0735 * Power Train 1 9T-9054 *

446B powered by 3114 Engine

5BL1-2499

Air – Cab 1 7T-3519

Air Primary 1 108-0671

Air Primary – Axial Seal 1 7W-3920 Air Secondary 1 108-0672 Air Secondary – Axial Seal 1 7C-1062 Breather – Engine 1 2W-9162 Breather – Hydraulic 1 9R-9925 Breather – Power Train 1 9G-9981

Fuel Primary 1 9R-5895

Fuel Secondary – Advanced 1 1R-0750 Fuel Secondary – Advanced 1 1R-0753 Fuel/Water Separator 1 117-4089 Fuel/Water Separator 1 121-4480 Hydraulic 1 108-1153 * Hydraulic 1 1G-8878 * Hydraulic – Advanced 1 126-1817 * Power Train 1 119-4740 Power Train 1 9T-9054 *

5BL2500-UP

Air – Cab 1 7T-3519

Air Secondary 1 108-0672 Air Secondary – Axial Seal 1 7C-1062 Breather – Engine 1 2W-9162 Breather – Hydraulic 1 9R-9925 Breather – Power Train 1 9G-9981

Fuel Primary 1 9R-5895

Fuel Secondary – Advanced 1 1R-0750 Fuel Secondary – Advanced 1 1R-0753 Fuel/Water Separator 1 117-4089 Fuel/Water Separator 1 121-4480 Hydraulic – Advanced 1 126-1817 * Power Train 1 119-4740 Power Train 1 9T-9054 *

446D powered by 3114 Engine

DBL1-UP

Air Primary – Axial Seal 1 7W-3920 Air Secondary – Axial Seal 1 7C-1062 Breather – Hydraulic 1 9R-9925

Filters – Backhoe Loaders

(15)

Filters – Compactors

814B powered by 3306 Engine

16Z1-UP

Air – Cab Recirculation 2 2V-0036 * Air Primary – Axial Seal 1 7W-5317 Breather – Power Train 1 4H-6112

815B powered by 3306 Engine

17Z1-UP

816B powered by 3306 Engine

15Z1-UP

Air – Cab Recirculation 1 2V-0036 * Air Primary – Radial Seal 1 6I-2501 * Air Primary – Axial Seal 1 7W-5317 Air Secondary – Axial Seal 1 9S-9972 Air Secondary – Radial Seal 1 6I-2502 Breather – Power Train 1 4H-6112

824C powered by 3406 Engine

85X1-UP

Fuel Secondary – Advanced 1 1R-0749 Breather – Power Train 1 4H-6112 Air Primary – Axial Seal 1 7W-5495

Air – Cab Recirculation 1 2V-0036 *

825C powered by 3406 Engine

86X1-UP

826C powered by 3406 Engine

87X1-UP

Hydraulic 2 1R-0722 * Power Train 1 1R-0719 *

826G powered by 3406 Engine

7LN1-UP

Air – Cab 1 107-0266 * Air – Cab 1 112-7448 *

Air Primary – Radial Seal 1 6I-0273 * Air Primary – Radial Seal 1 6I-2505 * Air Secondary – Radial Seal 1 6I-0274 Air Secondary – Radial Seal 1 6I-2506

Coolant 1 9N-3368

Coolant 1 9N-6123

Power Train – Fire Resistant 1 4T-3131

834B powered by

3408E, 3408 Engine

92Z1-UP

Coolant 1 1W-5518

Breather – Power Train 1 4H-6112 Air Primary – Axial Seal 1 7W-5313

Power Train 1 1R-0719 * Engine Oil 2 1R-0716 * Hydraulic 2 1R-0732 * Air – Cab 2 8P-5343 *

836 powered by 3408 Engine

3RL1-UP

7 Fire Resistant 1-263

7 Fire Resistant 264-UP

Fuel Secondary – Advanced 1 1R-0749 Fuel/Water Separator 1 133-5673 Hydraulic 1 1R-0732 * Power Train 1 1R-0719 *

836G powered by 3456 Engine

7MZ1-UP

Air – Cab 1 107-0266 * Air – Cab 1 112-7448 *

Air – Dryer A/C 1 175-7162 Air Primary – Radial Seal 1 6I-2509 * Air Secondary – Radial Seal 1 6I-2510

Fuel Primary 1 129-0372 Fuel Secondary – Advanced 1 1R-0749 Fuel/Water Separator 1 133-5673 Hydraulic 1 1G-8878 * Hydraulic 1 9T-0973 * Hydraulic 2 1G-8878 * Hydraulic – Advanced 1 126-1817 * Hydraulic – UHE 1 167-2009 *

CB-214E powered

by 3013C Engine

2141-UP

Air Primary 1 146-7472 Air Secondary 1 146-7473 Breather – Engine 1 153-5939 Breather – Hydraulic 1 081-2614 Engine Oil 1 220-1523 Fuel Primary 1 156-1200 Fuel/Water Separator 1 121-4480 Hydraulic 1 144-6691 *

Liquid Filters

●

One-Piece Aluminum Base Plate has added reinforcing to prevent ruptures due

to cold starts.

●

One-Piece Canister provides structural strength and anti-rupture protection.

●

Self-Lubricating, Free-Rotating Seal prevents bunching, eliminates leaks.

●

One-Piece Urethane End Caps have a tighter bond with filter media that

provides greater strength.

●

Spiral Roving and Acrylic Beads maintain pleat stability and spacing for

maximum efficiency, no bunching and maximum capacity.

●

Non-Metallic Center Tube is stronger than metal to prevent collapsing, prevents

metal contamination.

COMPACTORS

(16)

CB-224D powered by 3013 Engine

8RZ1-UP

Air Primary 1 146-7472 Air Secondary 1 146-7473 Engine Oil 1 220-1523 Hydraulic 1 144-6691 *

CB-224E powered

by 3013C Engine

2241-UP

Air Primary 1 146-7472 Air Secondary 1 146-7473 Breather – Engine 1 153-5939 Breather – Hydraulic 1 081-2614 Engine Oil 1 220-1523 Fuel Primary 1 156-1200 Fuel/Water Separator 1 121-4480 Hydraulic 1 144-6691 * Hydraulic 1 7X-8381

CB-225E powered

by 3013C Engine

2251-UP

Air Primary 1 146-7472 Air Secondary 1 146-7473 Breather – Engine 1 153-5939 Breather – Hydraulic 1 081-2614 Engine Oil 1 220-1523 Fuel Primary 1 156-1200 Fuel/Water Separator 1 121-4480 Hydraulic 1 144-6691 * Hydraulic 1 7X-8381

CB-534D powered

by 3054C Engine

EAA1-UP, FGH1-UP

Air Primary 1 206-5234 Air Secondary 1 206-5235 Breather – Fuel 1 190-9775 Breather – Hydraulic 1 171-5286 Engine Oil 1 7W-2326 Fuel/Water Separator 1 1R-1804 Hydraulic 1 1G-8878 *

CB-634D powered

by 3116T Engine

CDF1-UP

Air Primary – Radial Seal 1 6I-2499 * Air Secondary – Radial Seal 1 6I-2500 Breather – Fuel 1 190-9775 Breather – Hydraulic 1 5E-8934

Fuel Secondary – Advanced 1 1R-0751 Fuel Secondary – Advanced 1 1R-0753 Fuel/Water Separator 1 117-4089

CP-323C powered by 3054 Engine

EAS1-UP

Air Primary – Radial Seal 1 6I-1450 Air Secondary – Radial Seal 1 6I-1451

Fuel/Water Separator 1 1R-1804

CP-433E powered by 3054 Engine

CYE1-UP

Air – Cab 1 180-7487 Air Secondary 1 110-6331 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 138-3100 Hydraulic 1 1G-7663 Hydraulic 1 1G-8878 *

CP-563E powered

by 3056E Engine

BWE1-UP

Air – Cab 1 180-7487

Air Primary – Radial Seal 1 131-8822 * Air Secondary – Radial Seal 1 131-8821 Breather – Hydraulic 1 191-5439 Engine Oil 2 7W-2327 Fuel Secondary 1 145-4501 Fuel/Water Separator 1 138-3100 Hydraulic 2 1G-8878 *

CNT1-UP

Air – Cab 2 180-7487

Air Primary – Radial Seal 1 131-8822 * Air Secondary – Radial Seal 1 131-8821 Breather – Hydraulic 1 183-3873

Fuel Secondary 1 145-4501 Fuel/Water Separator 1 138-3100

CP-663E powered by 3056 Engine

ASF1-UP

Air – Cab 2 180-7487

Air Primary – Radial Seal 1 131-8822 * Breather – Fuel 1 190-9775 Breather – Hydraulic 1 183-3873 Engine Oil 2 7W-2327 Fuel Secondary 1 145-4501 Fuel/Water Separator 1 138-3100 Hydraulic 2 1G-8878 *

DAF1-UP

Air – Cab 2 180-7487

Air Primary – Radial Seal 1 131-8822 * Breather – Fuel 1 190-9775 Engine Oil 2 7W-2327 Fuel Secondary 1 145-4501 Fuel/Water Separator 1 138-3100 Hydraulic 2 1G-8878 *

CS-323C powered by 3054 Engine

DAR1-UP

Air Primary – Radial Seal 1 6I-1450 Air Secondary – Radial Seal 1 6I-1451

Engine Oil 1 7W-2326 Fuel/Water Separator 1 1R-1804 Hydraulic 1 1G-8878 *

CS-423E powered

by 3054B Engine

ASH1-UP

Air – Cab 2 180-7487 Air Secondary 1 110-6331 Breather – Fuel 1 190-9775 Breather – Hydraulic 1 171-5286 Engine Oil 1 7W-2326 Fuel Secondary 1 159-6102 Fuel/Water Separator 1 138-3100 Hydraulic 1 1G-7663 Hydraulic 1 1G-8878 *

DCL1-UP

CS-433E powered by 3054 Engine

DAC1-UP

CS-533E powered by 3116 Engine

ASL1-UP, DAK1-UP

Air – Cab 1 180-7487 Air Primary 1 206-5234 Air Secondary 1 206-5235 Breather – Fuel 1 190-9775 Breather – Hydraulic 1 171-5286 Engine Oil 1 7W-2326 Fuel/Water Separator 1 1R-1804 Hydraulic 1 1G-8878 *

CS-563E powered

by 3056E Engine

ASA1-UP

Air – Cab 1 180-7487

CNG1-UP

Air – Cab 2 180-7487

CS-573E powered

by 3056E Engine

CEB1-UP

Air – Cab 1 180-7487

CNN1-UP

Air – Cab 2 180-7487

CS-583E powered

by 3056E Engine

CNX1-UP

Air – Cab 2 180-7487

DAJ1-UP

Air – Cab 1 180-7487

Air Primary – Radial Seal 1 131-8822 * Air Secondary – Radial Seal 1 131-8821 Breather – Hydraulic 1 191-5439

(17)

Filters – Compactors

CS-663E powered by 3056 Engine

ASB1-UP

Air – Cab 2 180-7487

DAG1-UP

Air – Cab 2 180-7487

Air Primary – Radial Seal 1 131-8822 * Breather – Fuel 1 190-9775

CS-683E powered by 3056 Engine

ASG1-UP

Air – Cab 2 180-7487

DAD1-UP

Air – Cab 2 180-7487

Air Primary – Radial Seal 1 131-8822 * Breather – Fuel 1 190-9775 Engine Oil 2 7W-2327 Fuel Secondary 1 145-4501 Fuel/Water Separator 1 138-3100 Hydraulic 2 1G-8878 *

D6R powered by C-9 Engine

9PN1-UP

Fuel Secondary 1 1R-1712 * Power Train – UHE 1 132-8876 * Strainer – Fuel 1 9P-7121

RM-367 powered by 3406 Engine

87X00752-01455

Air Secondary – Axial Seal 1 1P-7360

(18)

Air Filters

●

Radial Seal Design – No tools are required, so service times and maintenance

costs are minimized.

●

One-Piece Molded Urethane End Caps – Forms a tough, reliable

corrosion-proof bond to paper media. Up to 30% more seal contact area for a seal that is

more reliable than conventional elements.

●

Densely Pleated Filter Paper – Large media area provides superior capacity

without impeding airflow.

●

Built-in Pleat Support and Positive Pleat Spacing – Prevents pleat bunching

and ensures optimum filter media surface area.

●

Heavy-duty Metal Inner and Outer Wrap – Increases structural strength

and durability.

●

Baked-on Enamel Outer Filter Wrap – Resists corrosion.

205 powered by 4.236 Engine

4DC1-UP

Fuel 1 081-4662 Hydraulic 2 8U-2805

205B powered by 3114 Engine

5ZF1-UP

Engine Oil 1 1R-0714 Fuel Primary 1 9M-2341

Hydraulic 2 8U-2805

206 powered by 4.236 Engine

3GC1-UP

Fuel 1 081-4662 Hydraulic 2 8U-2805

206B powered by 4.236 Engine

9BF1-UP

Air Primary 1 8T-7462 Air Secondary 1 8T-7463 Engine Oil 1 1R-0714 Fuel Primary 1 9M-2341

Hydraulic 2 8U-2805

211B powered by 3114 Engine

6XG1-UP

Hydraulic 3 8U-2805

212 powered by 4.236 Engine

5DC1-UP

Engine Oil 1 081-4661 Fuel 1 081-4662 Hydraulic 3 8U-2805

212B powered by 4.236 Engine

3PJ1-UP

Hydraulic 3 8U-2805

213B powered by 3116 Engine

1EF1-UP

Air – Cab 1 5W-9610

Air Primary 1 8U-2601

Air Secondary 1 8T-7463 Engine Oil 1 1R-0739 * Fuel – Advanced 1 1R-0750 Hydraulic 4 8U-2805 Screen – Fuel 1 7C-5867

1EJ1-UP

Air Secondary 1 8T-7463

Hydraulic 2 8U-2805

214B powered by 3116 Engine

4CF1-UP

Air – Cab 1 5W-9610

Air Primary 1 5W-3402

Air Primary 1 7E-0974

Hydraulic 1 5W-5804

Hydraulic 2 8U-2805

Screen – Fuel 1 7C-5867

9MF1-UP

Air Primary 1 8T-7462

Hydraulic 2 8U-2805

214B FT powered by 3116 Engine

4CF1-UP

Hydraulic 2 8U-2805

9MF1-UP

Air – Cab 1 5W-9610

Air Primary 1 8T-7462

Hydraulic 1 5W-5804

Screen – Fuel 1 7C-5867

215 powered by 3402 Engine

14Z1-UP, 57Y1-UP, 61Z1-UP

Air Primary – Axial Seal 1 7W-5389 Air Secondary – Axial Seal 1 2S-1285

Hydraulic 1 4T-6788

95Z1-UP

Hydraulic 1 4T-6788

215B powered by 3204 Engine

2XC1-UP

Hydraulic 1 4T-6788

9YB1-UP

Hydraulic 1 4T-6788

CAT FILTER AND FILTER APPLICATION GUIDE

Cat

®

Filter & Fluid

Application Guide

2005

Cat UHE Air Filters:

Improve filtration efficiency for

better, longer engine protection

• Reduced engine wear.

Particles collect on the

filter’s very fine fiber

surface layer; quickly

building a cake that

allows less dust to

reach the engine.

• Higher efficiency. This surface particle cake is more

porous than dust-coated media fibers, causing less

restriction throughout filter life.

• Better engine performance and fuel economy.

Low filter restriction allows the engine to “breathe”

easier, so it takes less power to pull in air.

• Longer filter life. The unique surface lasts twice as

long as standard media, limiting filter changes and

the chance of contamination control.

For more information, contact your local Cat Dealer

or visit the Caterpillar website at www.cat.com

Total Support. One Source. Your Cat Dealer.

As your Cat dealer, we define world-class product support. We offer you the right

parts and service solutions, when and where you need them.

We are proud to offer you over 1,500 Caterpillar parts listed in this first edition

of the Caterpillar Filter and Fluid Application Guide. You can count on genuine

Cat parts to deliver performance and long life, because they are built to high-quality,

original equipment specifications.

We carry most parts listed in the guide in stock for your immediate, off-the-shelf

convenience. And thanks to Caterpillar’s worldwide distribution system, we can

deliver most other parts within 24 hours.

Our highly trained experts offer you comprehensive service options to keep

your equipment up and running, maximizing your investment. Whether you

are maintaining one machine or many, the support you get from us makes the

difference that counts every day.

This guide is organized into eight major categories, focusing on Cat equipment:

●

Filters – application guide for all Cat equipment, product information,

filtration upgrade options, and data sheets.

●

Lubricants – general application guide for all Cat equipment, product

information, part numbers, and data sheets.

●

Coolants – general application guide for all Cat equipment, part

numbers, product information, and data sheets.

●

Greases – general application guide for all Cat equipment, grease

selection guide, part numbers, and data sheets.

●

S·O·S Oil Analysis – general application guide and data sheets.

●

Media – comprehensive collection of Caterpillar filter and fluid

brochures, data sheets, sales aides, catalogs, training materials,

and videos.

●

Index – quick reference page for key information.

Very truly yours,

Ken Hoefling

Parts Products Manager

Caterpillar Product Support Division

Table of Contents

Filters. . . 1

Application Guide:

Agricultural Equipment. . . 1

Articulated Trucks . . . 3

Backhoe Loaders . . . 5

Compactors. . . 9

Excavators . . . 12

Forest Machines . . . 33

Integrated Toolcarriers . . . 37

Material Handlers . . . 40

Motor Graders . . . 42

Multi Terrain Loaders . . . 46

Off-Highway Tractors . . . 47
