Instruction Sheet. Turf Groomer WARNING

(1)

Instruction

Sheet

When Performance Matters.™

WARNING

If incorrectly used, this machine can cause severe injury. Those who use and maintain this machine should be trained in its proper use, warned of its dangers and should read the entire manual before attempting to set up, operate, adjust, or service the machine.

19 17 18 13 6 5 9 15 16 7 8 10 4 3 11 1 - INCLUDES ITEMS 3 - 16

2812002

Turf Groomer™

1/4” Spacing

22” R.H. Groomer Product Number 67911

22” L.H. Groomer Product Number 67912

1/2” Spacing

22” R.H. Groomer Product Number 67913

22” L.H. Groomer Product Number 67914

18” R.H. Groomer Product Number 67926

(2)

This product is used on 5.0” diameter reels on GKIV™, GKV™, G-Plex® and Fairway mowers.

1.1 PREPARATION __________________________________________________________________________________

1. Park the mower on a flat and level surface, fully lower the cutting units to the ground, engage the parking brake, turn the ignition switch to the OFF position and remove key.

a. Wait for all movement to stop before making any

adjustments or modifications.

b. Take this opportunity to thoroughly inspect the

equipment and perform other maintenance.

c. For all steps, refer to the Parts List for part

identification.

d. Although the figures show installing a right hand

Groomer, the assembly process is identical for a left hand Groomer.

2. The turf groomer has been pre-assembled into five sub

assemblies and a bag of parts. [See Figure 1]

a. The driven sub assembly (A) is assembled to the

motor end of the reel.

b. The drive sub assembly (B) is assembled to the

counterweight end of the reel.

c. 22” Groomers: The other sub assemblies consist of

a blade assembly (C), roller (D) and clutch knob (E). d. 18” Groomers: The other subassemblies consist of

a blade assembly (C), roller (D) and pulley assembly

(I).

3. To help in the assembly process and prevent confusion

between right hand and left hand units, completely install each Turf Groomer before starting on the next reel.

a. Open each carton to inspect and familiarize yourself

with the contents.

b. Keep all components in original carton until ready for assembly.

4. Remove the reels from the mower, following directions

given in the mower’s manuals.

5. Remove the lift yoke, front roller and height adjust

brackets from each reel. Retain for future use.

6. Determine if a right hand or a left hand Groomer is to be installed for each reel. Move one reel and corresponding groomer assembly to workbench. [See Figure 2]

Figure 1

Figure 2

CAUTION

Read the operator’s manual and become familiar with the controls and proper use of the equipment.

Stay alert for potential hazards and follow all safety precautions. Read all instructions completely and make sure you understand them before proceeding with the assembly.

!

WARNING

Before you clean, adjust, or repair this equipment, disengage all drives, lower cutting units to the ground, engage parking brake, stop engine, remove key from switch and disconnect Negative (BLACK) battery cable to prevent injuries.

!

A B C D E I

Right Hand Groomer Required

Left Hand Groomer Required Motor

End

Motor End Front

(3)

1.2 PRE-ASSEMBLY _________________________________________________________________________________

1. Remove 1/4” hardware (F) and cover / counterweight (G)

from non-motor end of reel.

2. Block the reel with a piece of wood, and remove 3/8”

hardware (H) and spacer (Z) from the end of reel shaft.

Figure 3

Figure 4

3. Check the reel shaft nut (K) to insure it is positioned

properly. [See Figure 4]

a. 22” Groomers: Obtain drive pulley (J) from bag of

parts.

a. 18” Groomers: Obtain pulley spacer (AD) from bag

of parts.

b. Slide pulley (J) or spacer (AD) onto the reel shaft.

c. The pulley or spacer should be up against the

shoulder of the shaft with a 0.01 to 0.02 in. (.25 to .5 mm) gap between the pulley bearing and nut (K). d. If necessary, turn nut (K) until proper gap is obtained. e. Remove pulley or spacer and return to bag of parts.

4. Determine how many shims will be required for driven

sub assembly (A).[See Figure 5]

a. Obtain driven assembly (A) and four 0.02 in. thick

shims (L) from bag of parts.

b. Slide driven assembly (A) onto the motor end bearing

housing and hold it squarely and tightly against the housing.

c. Determine how many shims (L), if any, fit between

the height adjuster mounting block (M) and driven assembly. Write number of shims down for assembly purposes.

d. Remove driven assembly (A) and return shims to bag

of parts.

5. If you are installing the Turf Groomer on an LF series

mower, move the height adjust pivot (N) from the bottom hole to the top hole of both driven assembly (A) and drive assembly (B). [See Figure 6]

Figure 5

Figure 6 NOTE: The bottom hole is for GKIV, GKV and G-Plex units, and the upper hole is for Fairway units. Groomer is shipped with pivot

(N) installed in bottom hole.

6. If you are installing the Turf Groomer on a

non-FlashAttach™ reel with a two bolt reel motor attachment, reposition pivot block and clamp on driven assembly as shown in Figure 7. Item numbers used in the following instructions refer to the driven assembly Illustration on Page 14.

a. Remove set screw from micro adjust knob (Item 19)

and remove knob.

b. Remove hardware (Items 24 & 10) holding pivot

block (Item 11) to driven side of groomer.

c. Remove bolt (Item 13) securing rod end (Item 12) to

cam (Item 23) and remove pivot block and adjuster assembly.

d. Remove nut (Item 20) from adjusting bolt (Item 14)

and slide bolt from pivot pin (Item 21).

F G H Z AD K J J 0.01 0.02 in. AD K

CAUTION

Pivot pin has a spring loaded detent. Be careful when removing adjusting bolt.

A L M A B N Fairway Units

!

(4)

-e. Slide pivot pin (Item 21) from pivot block (Item 11).

f. Reposition pivot block and loosely reassemble

hardware (Items 24 & 10). The screw mounts through the inside flange of pivot block only.

g. Slide pivot pin (Item 21) through pivot block (Item

11). Remove plug (Item 17) from pivot pin. Compress

spring and ball (Items 15 & 16) and slide adjuster assembly through pin.

h. Reassemble rod end to cam with bolt (Item 13) and

reassembly plug to pivot pin.

i. Replace nut (Item 20) on adjusting bolt (Item 14).

Tighten just enough to remove play and allow free rotation of bolt.

j. Reassemble knob (Item 19) and set screw (Item 18).

Set screw must line up with indent in adjusting bolt. k. Tighten pivot block mounting bolt (Item 24).

l. Remove bracket retaining clamp (Item 8) and

reassemble to its new position shown in Figure 7.

Figure 7 1.3 DRIVE/BLADE ASSEMBLY ________________________________________________________________________

1. Obtain drive assembly (B) and remove belt housing cover

(O) and belt (P). Set cover and belt aside.

2. Obtain blade assembly (C) and identify the drive end

(End with 16 tooth pulley). Slide the pulley through the large slot in back of belt housing.

3. Align bearing housing with belt housing and secure with

one 3/8-16 x 7/8” socket head screw (Q) and lockwasher

(R). Do not tighten screw.

Figure 8 1.4 DRIVE ASSEMBLY TO REEL _______________________________________________________________________

1. Turn quick height adjuster knob (S) 90° to unlock the

height adjustment for ease of assembly.

2. Apply Lubriplate Multi-Lube (Part No. 5001581)

compound to the outside diameter of the bearing housing.

3. Assemble cover plate (T) and drive/blade assembly to

counterweight end bearing housing. Align holes in cover plate with holes in bearing housing and slots in belt housing and secure with two 1/4-20 x 3/4” socket head screws (U) and special washers (V).

Tighten the screws, then back off 1/8 to 1/4 turn. Belt housing must be free to pivot.

4. Obtain roller assembly and remove nut (W) from both

ends. Thread nut (AJ) as far as possible onto shaft. 5. Slide one end of roller shaft into the “D” shaped hole of

drive assembly.

a. Center the blades between the roller grooves.

b. Loosely assembly one nut (W) to drive end of roller.

Do not tighten nut.

6. Assemble spacer block (X) with one 5/16-18 x 2-1/2”

carriage bolt, spacer, lockwasher and nut (Y). Do not tighten hardware. From This: To This: B C O P Q R Rotate 90° Apply Lubriplate D S T U V W AJ X Y Y Multi-Lube Compound

(5)

1.5 DRIVEN ASSEMBLY TO REEL______________________________________________________________________

1. Turn quick height adjusters knob (S) 90° to unlock the

height adjustment for ease of assembly.

2. Apply Lubriplate Multi-Lube compound to the outside

diameter of the bearing housing.

3. Align the blade assembly (C) and the roller assembly (D)

with their corresponding mounting locations on the driven assembly (A). Slide driven assembly onto bearing housing, blade assembly and roller.

a. Secure blade assembly with one 3/8-16 x 7/8” socket

head screw (Q) and lockwasher (R).

b. Loosely assemble nut (W) to driven end of roller. Do

not tighten.Thread nut (AJ) as far as possible onto shaft.

4. Assemble spacer block (X) with one 5/16-18 x 2-1/2”

carriage bolt, spacer, lockwasher and nut (Y). Do not tighten hardware. Be sure to install correct number of shim washers (N) (Determined in Section 1.2).

Figure 10 1.6 CLUTCH ASSEMBLY _____________________________________________________________________________

1. Loosen eccentric retaining screw (AA) and turn eccentric

nut (AB) to move blade assembly pulley (AC) towards reel shaft as much as possible.

2. 22” Groomer: Obtain drive pulley (J) from bag of parts

and place belt (P) on the pulley.

2. 18” Groomer: Obtain spacer (AD) from bag of parts and slide onto reel shaft. Place belt (P) on pulley assembly (I).

NOTE: To prevent permanent damage to the belt, do not overtighten, twist, fold or bend the belt.

3. 22” Groomer: Position drive pulley (J) with bearing

towards center of reel and slide the pulley onto the reel shaft. As you slide the pulley down the shaft, work belt over blade assembly pulley (AC).

3. 18” Groomer: Install key (AE) onto reel shaft. Align

pulley assembly (I) with key and slide onto the reel shaft. As you slide the pulley down the shaft, work belt over blade assembly pulley (AC).

4. 22” Groomer: Install spacer (AD) and key (AE) onto reel

shaft.

5. 22” Groomer: Hold clutch (E) together and remove

shipping nut (AF).

NOTE: The clutch assembly (E) is spring loaded and must be held together before you remove shipping nut (AF) to prevent the clutch from coming apart.

6. 22” Groomer: Align clutch (E) with key (AE) on reel shaft

and install clutch on the shaft. Secure by tightening bolt

(AG). Block the reel with a piece of wood and torque bolt (AG) to 20 ft lb (27 Nm).

7. 18” Groomer: Secure pulley assembly to reel shaft with

3/8” hardware (H). Block the reel with a piece of wood and torque bolt to 20 ft lb (27 Nm).

Figure 11 Figure 12 Rotate 90° S Q R W AJ X Y Y N C D A AA AB AC J / I P Q AC J P AD AE AF AG E AE AD H I

(6)

1.7 ADJUSTING BELT _______________________________________________________________________________

1. Place a deep well socket on eccentric nut (AB) and turn

to tighten belt. [See Figure 11]

NOTE: Use a deep well socket without the ratchet. The belt must be adjusted with hand pressure only.

2. Hold socket securely and torque screw (Q) to 20 ft lb (27 Nm).

3. Remove socket and torque retaining screw (AA) to 8 - 10

ft lb (11 - 13 Nm).

4. Assemble belt housing cover (O) and torque hardware

(AH) to 6 - 8 ft lb (8 - 11 Nm).

Figure 13 1.8 BLADE ASSEMBLY DRIVEN BEARING ADJUSTMENT__________________________________________________

1. Before the adjustment can be performed, set both quick

height adjusters (S) to the same detent position.

2. Restrain the blade assembly from turning, and loosen nut

(AK) one full turn towards nut (AL).

3. Remove 3/8-16 x 1” screw (AM), lockwasher (AN) and

flat washer (AO) from driven end of blade assembly. 4. Tighten hardware (Y) on both ends of reel.

a. After tightening hardware (Y), make certain driven

assembly (A) is shouldered squarely on the bearing housing.

b. Add or remove shims as necessary until driven

assembly is shouldered squarely on the bearing housing.

NOTE: The squareness of driven assembly to the bearing housing will affect how difficult or easy the turf groomer is to adjust.

5. Assemble screw (AM) and flat washer (AO) to end of

blade assembly. Hand tighten only.

6. Tighten nut (AK) against spacer (AP) until spacer (AQ)

begins to rotate.

NOTE: Nut (AK) is a nylock nut and is designed to resist turning.

7. Remove screw (AM) and flat washer (AO), and

re-assemble using lockwasher (AN). Torque screw (AM) to 20 ft lb (27 Nm).

8. Check to see if driven assembly (A) remains shouldered

against the bearing housing.

Figure 14

Figure 15 O

AH

CAUTION

Be careful to prevent entrapment of hands and fingers between moving and fixed components of the machine.

!

S Q R W AJ X Y Y N C D A AK AL AM AN AO AP AQ

(7)

1.9 FINAL ASSEMBLY _______________________________________________________________________________

1. Set height of cut to same height at both ends of reel.

2. Adjust nuts (AJ) as required to center blades between

roller grooves. Tighten nuts (N).

If any threads remain exposed after tightening nuts (N), add spacers (AR) as required to cover threads.

3. Assemble guide wheels (AS) to roller shaft with 5/16-18 x 3/4” screws, spacers and lockwashers (AT). Wheels (AS) must turn freely after assembly.

4. Tighten all remaining hardware securely.

5. Assemble lift yoke to reel and secure with shoulder bolts

(AU).

6. Raise quick height adjuster (S) to top notch and install

reel on mower.

7. Follow all steps for each remaining Turf Groomer to be

installed.

Figure 16 2.1 ADJUSTING PROCEDURE _________________________________________________________________________

1. Adjustments and maintenance should always be

per-formed by an qualified technician. If proper adjustment cannot be made, contact an authorized Jacobsen® Dealer.

2. Do not wear jewelry or loose fitting clothing when

adjusting or repairing any equipment.

3. Inspect the equipment on a regular basis; establish a

maintenance schedule and keep detailed records.

a. Keep the mower clean and moving parts properly

adjusted and lubricated.

b. Replace worn or damaged parts before operating the

machine.

c. Keep shields in place and all hardware securely

fastened.

4. Wash the equipment after each use. Do not wash any

portion of the equipment while it is hot. Do not spray water directly at bearing housings and seals. Do not use high pressure spray or steam.

5. Repair damaged metal surfaces and use touch up paint.

6. Use the illustrations in the Parts Catalog as reference for the disassembly and reassembly of components.

2.2 GENERAL RECOMMENDATIONS ___________________________________________________________________

1. Initially, expect an increased amount of grass removal

when using the Turf Groomer. Also expect an increased amount of wear on the reel and bedknife; therefore, sharpening will be required more frequently. With contin-ued usage, however, the frequency of sharpening will decline.

2. Do not use the Turf Groomer immediately following top

dressing as the blades will pick up the top dressing and pass it through the reel. The groomer should be raised to its highest position and disengaged with the clutch knob.

3. Use the Turf Groomer on a regular basis, however, if you

wish to skip a day, the Turf Groomer should be disengaged. The groomer blades will simply roll on the ground without leaving any marks.

4. The Turf Groomer may also be raised to its highest level

but leave clutch knob engaged so that the blades will rotate though the grooves in the roller and keep the roller grooves clean.

2.3 HEIGHT OF CUT _________________________________________________________________________________

Before this attachment can be put into regular use, several passes should be made over a test area, each pass at a different setting to obtain the best possible results for your turf

conditioning needs.

1. Record the settings and conditions during the first test. Examine the test area a few days after the first grooming

AJ N AR AS AT AU S

WARNING

Before you clean, adjust, or repair this equipment, disengage all drives, lower cutting units to the ground, engage parking brake, stop engine, remove key from switch and disconnect Negative (BLACK) battery cable to prevent injuries.

CAUTION

Be careful to prevent entrapment of hands and fingers between moving and fixed components of the machine.

!

(8)

and record the results.

2. Your requirements will determine the final settings and

they will be governed by the type and condition of the grass, temperature and season of the year, the frequency of cut and many other variables.

3. Keep in mind that the conditions and settings will vary

from green to green and from one season to the next.

NOTE: Over grooming can cause severe damage to turf.

2.4 REEL HEIGHT OF CUT ____________________________________________________________________________

1. To set the cutting height for the reel, loosen the wing nut

(D) and thread screw (A) in or out to obtain the desired

height of cut (B) on gauge bar (C).

Use a small metal scale to measure dimension (B) as the height of cut. Once dimension (B) is obtained, tighten wing nut (D).

2. Loosen nuts (E) on both ends of the reel just enough to

allow knob (F) to raise or lower the roller brackets.

3. Place gauge bar across the front and rear rollers at one

end of the reel.

4. Slide the head of screw (A) over the bedknife and adjust

knob (F) to close the gap between the screw head and the bedknife.

5. Repeat adjustment on opposite end of reel.

6. Recheck both ends of reel for proper adjustment and

tighten nuts (E).

Figure 17 2.5 TURF GROOMER HEIGHT OF CUT ADJUSTMENT _____________________________________________________

1. The height of cut adjustment on the Turf Groomer is

made with the “Quick” and “Micro” adjusters and the gauge bar (C).

a. The “Quick” height adjusters (J) allows changes in

increments of 1/8 in. (3 mm) per detent position.

b. The “Micro” height adjusters (K) permits infinite

variations between the 1/8 in. increments. Each “click” of the micro adjuster moves the groomer shaft 0.007 in (0.18 mm) up or down.

2. The height of cut for the reel must be adjusted before the Turf Groomer height of cut can be set. If reel height of cut is changed, the groomer will need to be re-adjusted.

3. To set grooming height, loosen wing nut (G) and adjust

screw (H) from 0 to 1/16 in (2 mm) below reel height of cut (B).

4. Place the gauge bar across the front and rear rollers on

one end of the reel with head of screw (A) over the bedknife.

5. Unlock the “Quick” height adjuster (J) on one end of reel by turning knob 90° and bring the groomer blades down as close to screw (H) as the lowest detent allows. Lock adjuster.

6. Move “Quick” height adjuster on opposite end of reel to

same detent position.

7. Finish adjustment using “Micro” adjusters (K) on both

ends of reel.

8. Do not set the blades at ground level or below. To

mow at this level may damage the machine as well as the turf. The Turf Groomer was designed to be a conditioner, not a vertical mower.

9. Jacobsen does not recommend setting the groomer blades over 1/16 inch below the reel cutting height.

This height will also help eliminate natural graining and smooth out uneven grass

10. Make absolutely certain that each Turf Groomer is adjusted evenly on both ends and that all the cutting units on the mower are adjusted to the same height.

Figure 18 A B C D E F A B C G H J K 0-1/16 in.

(9)

2.6 CLUTCH KNOB (22” GROOMER ONLY) ______________________________________________________________ Note: The 18” groomer is not equipped with a clutch knob

and is designed to be always ON.

1. The Turf Groomer is equipped with a clutch to disengage

the groomer blades and allow you to cut grass with the reel only.

2. The groomer blades should be raised to their highest

position and the clutch knob disengaged when groomer is not in use.

3. To disengage the clutch, hold pulley (L) and turn clutch

knob (M) 110° counter-clockwise. Make sure the groomer is disengaged by manually turning pulley (L) and check if groomer blades turn.

Figure 19

2.7 BELT __________________________________________________________________________________________

1. The drive belt used on the Turf Groomer is a patented

design, Kevlar® cord, syncronus belt.

NOTE: To prevent permanent damage to the belt, do not overtighten, twist, fold or bend the belt.

Overtightening the belt will cause premature belt failure and abraisive wear of the pulley and bearings. Twisting or bending the belt will permanently damage the cord fibers of the belt.

2. Once the belt has been adjusted as described in the

assembly process, no further adjustment is required.

[See Section 1.7]

3. Periodic inspections of the belt will be required to check for wear.

4. Spare belts should be stored individually and not

compressed or bent into any form other than eliptical.

2.8 LUBRICATION ___________________________________________________________________________________ Lubrication intervals are based on operating from 8 to 10

hours per day, 5 days per week under normal operating conditions.

All maintenance intervals must be performed more frequently when operating in extremely dusty conditions.

1. Always clean the grease fitting before and after lubricat-ing.

2. Lubricate with grease that meets or exceeds NLGI Grade

2 specifications.

3. Apply grease with a manual grease gun and fill slowly

until pressure is felt. Do not use compressed air guns to prevent damage to seals.

Grease each of the following points not more than once a month.

a. Clutch (22” Groomer Only) (1 Fitting) (N)

b. Groomer bearing housings (2 Fittings) (O)

c. Roller bearings (2 Fittings) (P)

d. Micro Adjust Pivot (2 Fittings - See Note) (Q)

NOTE: To grease motor side micro-adjust pivot, remove grease fitting (Q) from micro-adjust pivot on opposite end of reel and plug (R). Install fitting and grease motor side pivot. Reinstall all parts to their original position. This is applicable to all units except for G-Plex.

4. For smooth operation of pivot points and other friction

points, apply several drops of SAE 30 wt. oil every 40 hours, or as required.

Clean and lubricate individual parts and components as required. Apply Lubriplate Multi-Lube compound between bearing housings and drive / driven assemblies.

Figure 20

WARNING

Never hold onto the reel blades during the engaging or disengaging operation. If it is necessary to stop the rotation of the reel, place a wood block between a reel blade and the frame.

!

L M N O P P Q R

(10)

A A A 2 3 3 5 6 6 7 7 8 9 10 12 12 11 13 13 14 16 19 20 21 22 23 24 27 28 29 30 31 33 4 17 15 25 26 34 38 37 18" Groomer 22" Groomer 35 36 36 32 1

TURF GROOMER

Turf Groomer Assembly

Right Hand Groomer Shown (Left Opposite)

(11)

> Change from previous revision

TURF GROOMER

Item Part No. Qty. Description Serial Numbers/Notes

1 365226 1 Cover Plate

> 2500229 1 Pulley Assembly 22” Groomers Only

2 365228 1 • Pulley, 28 Groove 22” Groomers Only

3 365229 2 • Bearing, Ball 22” Groomers Only

4 458461 1 • Snap Ring 22” Groomers Only

5 365232 1 • Spacer 22” Groomers Only

6 365256 1 Spacer, Pulley

7 365239 1 Key, 1/8 x 1/8 x 7/16”

8 446142 2 Lockwasher, 3/8 Heavy

9 434030 2 Screw, 3/8-16 x 7/8” Socket Head

10 365237 2 Spacer, Grass Catcher

11 441672 2 Carriage Bolt, 5/16-18 x 2-1/2”

12 364441 4 Spacer, 5/16

14 443106 2 Nut, 5/16-18 Hex

15 365246 2 Bolt, 3/8-16 Nyloc Shoulder

16 365341 2 Washer, Special

> 18

19 365343 2 Wheel, Guide

20 400184 2 Screw, 5/16-18 x 3/4” Hex Head

21 365409 AR Spacer, Roller

22 3005515 AR Spacer, Driven Assembly 0.02”

– 1 Clutch Assembly 22” Groomers Only

23 163776 1 • Pulley Assembly 22” Groomers Only

24 338768 1 • • Seal, Grease 22” Groomers Only

25 365272 2 • Spring 22” Groomers Only

26 365258 2 • Pin 22” Groomers Only

27 365254 1 • Shaft, Stub 22” Groomers Only

28 241817 1 • Knob, Clutch 22” Groomers Only

29 363841 1 • Washer 22” Groomers Only

30 446142 1 • Lockwasher, 3/8 Heavy 22” Groomers Only

31 365257 1 • Bolt 22” Groomers Only

32 471214 1 • Grease Fitting, 1/4-28 22” Groomers Only

33 – 1 Drive Assembly See Breakdown

34 – 1 Driven Assembly See Breakdown

35 – 1 Blade Assembly See Breakdown

36 – 1 Roller Assembly See Breakdown

37 365235 1 Belt, Drive

38 4118617 1 Pulley Assembly 18” Groomers Only

365228 1 • Pulley, 28 Groove Groomer 18” Groomers Only

(12)

TURF GROOMER

Drive Assembly

Serial No. All

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 9 30 29 31 26

(13)

TURF GROOMER

> 1 4103100 1 Bracket, Groomer Roller

2 220302 1 Housing, Belt

3 365260 1 Link, Belt Adjusting

4 367162 1 Eccentric, Belt Adjusting

7 2500231 1 Cover, Belt Housing

8 338752 1 • Seal, Oil

10 434029 2 Screw, 1/4-20 x 1” Socket Head

12 365247 1 Rod End

14 434032 1 Screw, 5/16-18 x 1-3/4” Socket Head

15 365270 1 Bolt, Micro Adjusting

16 3003969 1 Pin, Pivot

17 465006 1 Ball, 5/16 Diameter Steel

18 365291 1 Spring

19 471219 1 Grease Fitting, 1/8 NPT

20 445667 1 Nut, 1/2-20 Hex Nyloc

21 422502 1 Set Screw, 1/4-20 x 1/4”

22 3005108 1 Knob, Micro Adjuster

23 367166 1 Cam

24 453009 1 Flat Washer, 5/16

26 400186 2 Screw, 5/16-18 x 7/8” Hex Head

27 364061 1 Bracket, Adjusting Pivot

28 365344 1 Clamp, Housing Retaining

29 444718 2 Nut, 5/16-18 x 7/8” Hex Head

30 365233 1 Link, Roller Adjusting

(14)

TURF GROOMER

Driven Assembly

Serial No. All

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 ₁₉ 20 21 22 23 3 24 25

(15)

TURF GROOMER

> 1 4103100 1 Bracket, Groomer Roller

2 338748 1 Bracket, Groomer Mounting

3 400186 2 Screw, 5/16-18 x 7/8” Hex Head

4 365233 1 Link, Roller Adjusting

5 444718 2 Locknut, 5/16-18 Center

6 453009 2 Flat Washer, 5/16

7 364061 1 Bracket, Adjusting Pivot

8 365342 1 Clamp, Backet Retaining

10 2811566 1 Screw, 1/4-20 x 1/2” Locking

11 2810479 1 Block, Pivot

12 365247 1 Rod End

13 434032 1 Bolt, 5/16-18 x 1-3/4” Socket Head

14 365270 1 Bolt, Micro Adjusting

15 465006 1 Ball, 5/16 Diameter Steel

16 365291 1 Spring

17 472006 1 Pipe Plug, 1/8 NPT Socket Head

18 422502 1 Set Screw, 1/4-20 x 1/4”

19 3005108 1 Knob, Micro Adjuster

20 445667 1 Nut, 1/2-20 Hex Nyloc

21 3010709 1 Pin, Pivot

23 367166 1 Cam

24 1 Quick Height Adjuster See Breakdown

(16)

TURF GROOMER

Blade Assembly

1/4 Inch Spacing, Right Hand Groomer Shown (Left Opposite)

Serial No. All

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 2 3 6 9 10 11 14 20 21 24 26

(17)

TURF GROOMER

1 367029 1 Locknut, 3/4-16 Hex Nyloc

2 367165 2 Spacer, 7/8 x 17/32”

> 3 471221 2 Grease Fitting, 1/4-28

2500228 1 Driven Bearing Housing

4 241808 1 • Housing, Bearing 5 365229 1 • Bearing, Ball 6 458461 2 • Snap Ring 7 336962 1 • Grease Seal 8 367164 1 Spacer, 7/8 x 1-13/16” 9 453011 2 Flat Washer, 3/8 10 446142 2 Lockwasher, 3/8 Heavy

11 400298 2 Screw, 3/8-24 x 1” Hex Head

2500227 1 Drive Bearing Housing

12 241807 1 • Housing, Bearing 13 365229 1 • Bearing, Ball 14 458461 2 • Snap Ring 15 336962 1 • Grease Seal 16 367163 1 Spacer, 7/8 x 7/8” 17 365227 1 Pulley, 16 Groove 18 345556 1 Key, 1/8 x 1/8 x 31/32”

2500232 1 1/4” Spacing Groomer Shaft Assy 67911 and 67912

2500230 1 1/2” Spacing Groomer Shaft Assy 67913 and 67914 (Not Shown)

4116926 1 1/2” Spacing Groomer Shaft Assy 67926 (Not Shown)

19 390857 1 • Shaft, 22” Groomer 67911, 67912, 67913 and 67914

19 3000782 1 • Shaft, 18” Groomer 67926

20 365234 2 • Spacer, 1-1/16 x 15/32”

● 21 365230 71 • Blade (1/4” Spacing) 67911and 67912

● 21 365230 40 • Blade (1/2” Spacing) 67913 and 67914

● 21 365230 32 • Blade (1/2” Spacing) 67926

22 367029 1 • Locknut, 3/4-16 Hex Nyloc

23 364040 AR • Shim, Groomer Shaft

24 367161 2 • Spacer, 1 x 3/4”

25 443832 1 • Nut, 3/4-16 Hex Jam

26 365236 70 • Spacer, 1/4” Blade Spacing 67911 and 67912

26 365234 39 • Spacer, 1/2” Blade Spacing 67913 and 67914

26 365234 31 • Spacer, 1/2” Blade Spacing 67926

(18)

TURF GROOMER

Roller Assembly

Serial No. All

1 390899 1 22” Roller Tube, 1/4” Spacing 67911 and 67912

1 390900 1 22” Roller Tube, 1/2” Spacing 67913 and 67914

1 4116739 1 18” Roller Tube, 1/2” Spacing 67926

2 365330 2 Bearing, Ball

3 4169260 2 Shaft, Roller

4 338773 2 Grease Seal

5 458113 2 Snap Ring

7 443816 2 Nut, 7/16-20 Hex Jam

8 452008 2 Flat Washer, 7/16

9 443836 4 Nut, 7/8-14 Hex Jam

10 365345 2 Nylos Ring 11 471214 2 Grease Fitting, 1/4-28 1 2 3 4 5 6 7 8 9 10 11

(19)

TURF GROOMER

1 422502 1 Set Screw, 1/4-20 x 1/4” 2 365265 1 Link, Adjusting 163761 1 Knob Assembly 3 365271 1 • Bolt 4 365268 1 • Spring 5 365267 1 • Plunger 6 365266 1 • Bolt, Adjusting 7 365269 1 • Spring

8 444708 1 • Locknut, 1/4-20 Hex Center

9 271919 1 Knob, Quick Adjuster

Quick Height Adjuster

Serial No.

1 2 3 4 5 6 7 8 9

(20)

Jacobsen, A Textron Company

Equipment from Jacobsen is built to exacting standards ensured by ISO 9001 and ISO 14001 registration at all of our manufacturing locations. A worldwide dealer network and factory trained technicians backed by Jacobsen Parts Xpress provide reliable, high-quality product support.
