MOTORS

2.1 Common types of industrial motors

Induction motors

An induction motor performs two primary functions:

 start - convert electrical energy into mechanical energy in order to overcome the inertia of the load and accelerate to full operating speed.

 run - convert electrical energy into productive work output to a driven load.

Full voltage starting (also referred to as direct on-line or across-the-line starting) results in a high starting current, equal to locked rotor current. The locked rotor current (LRC) of a motor depends on the motor design, and is typically between five and ten times motor full load current (FLC). A value of six times FLC is common. Shaft loading only affects start time, not LRC.

High motor starting currents can cause voltage fluctuations on the electrical supply system, and electrical supply authorities often require reduction in motor starting current. Reduced voltage starting of an induction motor reduces the available starting torque, and loads with demanding start torque requirements may not be compatible with reduced voltage starting.

When selecting a motor for a specific application, both the start and run characteristics are very important. Motors consist of two major components:

 The stator consists of magnetic poles created from stator windings located in slots within the frame of the motor. The full load running characteristics of the motor are determined by the winding configuration and the contour of the stator slots and laminations. Motor speed is determined by the number of pole pairs and the supply frequency applied to the stator windings.

 The rotor consists of a cylindrical short circuited winding, embedded within iron laminations. The rotor winding is often referred to as a squirrel cage. This cage is constructed from a number of bars running parallel to the motor shaft near the surface of the rotor. The rotor bars are short circuited at each end of the rotor using shorting rings. The material, position and shape of the rotor bars determines the starting characteristics of the motor.

The rotor design determines the starting characteristics of the motor. The stator design determines the running characteristics of the motor.

AC induction motor

When 3-phase supply voltage is applied to the stator winding of an induction motor, a rotating magnetic field is produced which cuts through the rotor bars. The rotating speed of this magnetic field is referred to as "synchronous speed".

Interaction between the rotating magnetic field and the rotor bars induces a voltage which causes current to flow in

magnetic field and the rotor, otherwise known as slip. Slip is commonly expressed as a percentage of the motor's synchronous speed.

Motor start performance characteristics can vary greatly depending on rotor design and construction, but in general, a motor with high locked rotor current will produce low locked rotor torque and vice versa. A high resistance rotor produces relatively high starting torque but runs at high slip which causes inefficiency. To produce superior starting and running characteristics, specially shaped rotor bars or double cage rotors are used.

Typical start performance characteristics of an induction motor.

Full voltage motor current Full voltage motor torque Load torque (quadratic load, eg pump) Cur ren t T or qu e Speed

Useful formulae

Motor synchronous speed

Where:

Ns = synchronous speed (rpm)

f = mains supply frequency (Hz) p = number of stator pole pairs Motor slip speed (%)

Where:

Nslip = percentage slip speed (%)

Ns = synchronous speed (rpm)

Nr = rotor speed (rpm)

Motor shaft output power

Where:

Po = output power (kW)

Nr = rotor shaft speed (rpm)

Tr = rotor torque (Nm)

Motor electrical input power

Where:

Pi = input power (kW)

V = motor line voltage (kV) I = motor line current (A) cosØ = motor power factor Motor efficiency

Where:

eff = motor efficiency (%)

7 x FLC 6 x FLC 5 x FLC 3 x FLC 1 x FLC 4 x FLC 2 x FLC 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 2 x FLT 1 x FLT 0 3 3 4 0 .B N p s= × f 60 N (N N ) N slip s r s = ×100 Po N T r r = × 9550 Pi= 3× × ×V I cos = × eff Po 100

MOTORS

Slip-ring motors

A slip-ring induction motor is also referred to as a wound rotor motor. In principle, the stator construction is the same as that of a squirrel cage induction motor. The rotor is made up of a set of windings embedded in rotor slots and brought out to a set of slip-rings. External rotor resistance is then connected to the slip-rings via a brush gear arrangement. The external rotor resistance is variable and is used for starting the motor.

Slip-ring rotor arrangement

Slip-ring motor installation

Three-phase supply Bridging contactors

KM1 Main contactor KR1 First stage contactor

Slip-ring motor KR2 Second stage contactor

A Stator External rotor resistance

B Rotor R1 First stage resistor bank

R2 Second stage resistor bank

A high level of starting torque is produced by matching the rotor resistance with the rotor leakage reactance as the motor speed increases. At standstill, all the available external rotor resistance is in the circuit. As the motor speed increases, the external rotor resistance is reduced by using shorting contactors, until all the external resistance is

13227.A KM1 KR2 R2 KR1 R1 1 2 3 4 A B

Typical start performance characteristics of a slip-ring motor. To rque C urren t Speed Speed

Slip-ring speed control

In some cases, the variable resistance is used for speed control of the load. This method of speed control can cause erratic fluctuations in speed (if the load demand changes), and heat loss from the resistors causes major inefficiencies. Compared with using a slip-ring motor for speed control, a better result can be achieved by using a variable frequency drive (VFD) to operate a standard squirrel cage motor. A VFD typically provides more precise speed control, as well as being more efficient, less expensive, and easier to install and maintain.

Provided sufficient start torque is developed with a single stage of rotor resistance, soft starters can be successfully applied to slip-ring motors.

Refer to Slip ring motor control on page 66 for further details.

MOTORS

Synchronous motors

The construction of a synchronous motor stator is the same as a standard induction motor, although the stator configuration is such that relatively low operating speeds are common (eg 300-600 rpm).

When 3-phase voltage is applied to the stator windings, a magnetic field is generated which rotates at a synchronous speed around the stator and rotor. The synchronous speed is determined by the stator construction and frequency of the supply voltage.

Motor synchronous speed

Where:

Ns = synchronous speed (rpm)

f = mains supply frequency (Hz) p = number of stator pole pairs

The rotor design incorporates a squirrel cage winding combined with a DC excitation winding. This allows the motor to start as a standard squirrel cage induction motor, reaching a running speed of approximately 95% synchronous speed. At this point, a DC voltage is applied to the excitation winding via a slip-ring and brush arrangement. A fixed magnetic field is created in the rotor which locks in with the rotating magnetic field of the stator. The motor shaft now runs at synchronous speed.

Synchronous motor

Fan inside

Excitation rings (x2) Three phase stator windings

Rotor with poles and excitation windings Excitation brushes (x2)

As motor shaft load is increased, the operating power factor of the motor is reduced. This power factor can be improved by increasing the DC excitation level of the rotor. This behaviour allows the AC synchronous motor to operate very efficiently at a fixed speed, independent of loading.

Soft starters are suitable for this type of application, but an external DC excitation package is required for synchronous speed control and operation.

N p

s=

× f 60

2.2 Motor starting methods
