Preventing the spread of smoke and fire in a building often presents

major challenges to owners, facility managers and installers of services

and technical systems. Often these facilities are required to prove

that the passive fire prevention system in their building is capable of

passing acceptance inspections after the completion of the building

work or maintenance. It is also necessary to provide confirmation

of correct installation and verification of compliance with firestop

requirements for each penetration. Hilti now offers a convienant way

to compile these installation locations and create an comprehensive

documentation using the latest mobile technology.

FOR PEACE OF MIND.

CFS-DM Firestop documentation manager

Hilti Firestop Documentation

Compliant, simple and efficient.

CFS-DM Firestop documentation manager is the straightforward solution that equally fulfills the needs of

planners, specifiers, installers, building owners and authorities. This new innovative software allows you to plan

and document every stage of an entire firestop project in a single, comprehensive software application. With an

easy to use online back office interface, progress reports and work permits can be produced instantaneously

with a click of the mouse. This not only streamlines the documentation process, it also greatly simplifies building

acceptance inspections and subsequently makes maintenance more efficient.

(3)

Clear and efficient installation planning

Coordinating firestop between architects and planners does not have to be overwhelming. Take advantage of the CFS-DM multi-user capability and prepare the entire project and installation in advance from your office. Assign each penetration to the appropriate firestop product, tested system, location in the building and subcontractor or installer responsible for completion.

Marking with added value

The identification process is revolutionized by electronically connecting the physical penetration with the virtual penetration via a QR code located on each label. The information about each penetration can be easily recorded directly into the CFS-DM Firestop documentation manager system by scanning the QR code with the hand-held mobile device (smartphone or tablet).

Immediate, on-site documentation

(4)

Reporting for automatic compliance

With the CFS-DM Firestop documentation manager, customized and standardized reports can be produced at a moment's notice. The web-based back office platform allows you to create a comprehensive report to show compliance with applicable regulations, up-to-date project status and all locally recorded information, photos and corresponding firestop design verification.

Coordination and acceptance

Accessibility is always an option. The status of each penetration can be viewed online either in the field or office. At any time, each party involved in the project, from installers to site coordinators and architects, can be kept up-to-date about their project’s current status.

Servicing and building maintenance

(5)

Free 30 day trial

Step 1

Prepare the project

Create a project with the easy-to-use web-based back office application. Customize the required penetration information that will be documented according to the project or building needs. Additional project information such as assigning users, adding technical documents and 2D plans can also be included as necessary.

Step 3

Firestop reports

Create a report

Whether at the completion of the project or at any intermediate step, a customized or standard report can be produced to show the status of the recorded penetrations. Three types of reports can be created: standard, Excel list or 2D plan format. All reports are automatically saved and can accessed for future reference.

Step 2

Record the penetration

All of the relevant information about each penetration is recorded in the field with the use of Hilti’s intuitive CFS-DM app. This data is transmitted from the smartphone or tablet straight to the cloud-based database. The labels are equipped with a distinct QR code for quick reference to the penetration details.

Firestop Documentation

Start documenting in less than 10 minutes

• Download the free app from iTunes or Google Play

• Try a free 30 day trial period or call 1-800-879-8000 for full enrollment • Receive a welcome email with your username and password

• Login and build company profile • Create a project and start documenting

System Requirements

• Hilti CFS-DM is a web-based application that can be accessed through the internet using a standard browser utilizing Microsoft Internet ExplorerTM_{, Google Chrome}TM_and

Mozilla FirefoxTM

• The mobile application is available for devices running Apple iOS 6 or higher (Apple iPhoneTM_{and iPad}TM_{), Android}TM_{2.3 or higher and the new Samsung Galaxy Camera}TM

(6)

Software

Order Description Item No. Single

CFS-DM Basic

Hilti CFS-DM Firestop documentation manager software basic package. 1 year subscription. Maximum 5,000 penetrations. 2093086

CFS-DM Premium

Hilti CFS-DM Firestop documentation manager software premium package. 1 year subscription. Maximum 20,000 penetrations. 2093330

Extensions

CFS-DM Small Extension - 10000

Hilti CFS-DM Firestop documentation manager average extension package. Additional 10,000 penetrations. 2093332

CFS-DM Medium Extension - 20000

Hilti CFS-DM Firestop documentation manager large extension package. Additional 20,000 penetrations. 2093333

CFS-DM Large Extension - 50000

Hilti CFS-DM Firestop documentation manager mega extension package. Additional 50,000 penetrations. 2093334

Hilti, Inc. (U.S.) I 1-800-879-8000 I en español 1-800-879-5000 I www.us.hilti.com

Hilti. Outperform. Outlast.

Learn how a HAFSC can help implement

CFS-DM on your next project.

A Hilti Accredited Firestop Specialty Contractor (HAFSC) is an independent professional firestop installer who received specialized training by Hilti and who has committed to provide building owners, general contractors, and subcontractors with a full service solution for all their firestopping needs. When you use a HAFSC, you are selecting a trained firestop installation specialist committed to proven Hilti firestopping technology and innovation to minimize the risk of loss due to fire, smoke and toxic gases.

Learn more by visiting www.hiltifsc.com.

Ordering information

Identification labels

CFS-DM Identification label - 2000

Includes a roll of 2000 firestop identification labels. Each label consists of (3) adhesive paper stickers with matching QR codes. One large sticker with fields to handwrite penetration details (4-3/4" W x 3-1/8" H) and (2) small stickers (1-1/2" W x 1" H).

2096830

Includes a roll of 100 firestop identification labels. Each label consists of (3) adhesive paper stickers with matching QR codes. One large sticker with fields to handwrite penetration details (4-3/4" W x 3-1/8" H) and (2) small stickers (1-1/2" W x 1" H).

3517802

Includes a roll of 2000 firestop identification labels. Each label consists of (1) small adhesive paper sticker (1-3/4" W x 1-1/4" H) with one QR code.

2096832

Includes a roll of 500 firestop identification labels. Each label consists of (1) small adhesive paper sticker (1-3/4" W x 1-1/4" H) with one QR code.

2096831
