Revit MEP. Autodesk Navisworks

What is BIM ?

Autodesk BIM is an intelligent model-based process that helps owners and service providers achieve business results by enabling more accurate, accessible, and actionable insight throughout project execution and lifecycle.

BIM changes the way companies work—both internally and externally. Projects have become more and more complex, requiring firms to manage and share immense amounts of data across diverse and distributed teams. By enabling greater insight into the project at any point in its lifecycle, BIM helps AEC service providers to improve accuracy, efficiency, and productivity, resulting in time and cost savings. The significant value-added benefits that BIM-ready firms can provide include: faster project approvals, more predictable outcomes, sustainable design and analysis services, and improved collaboration and information sharing for integrated project delivery strategies.

BIM Diploma content ( included courses) :

Training course Course Levels Duration Outputs

Revit Mep 2 level 50hrs Electromechanical design and modeling Autodesk navisworks 1 level 24 hrs Clash detection

 Our customers use Autodesk BIM solutions to achieve better business results.

BIM helps improve the way work gets done by providing more insight and greater predictability

Revit MEP

Autodesk building information modeling (BIM) software helps mechanical, electrical, and plumbing (MEP) engineers keep design data coordinated, minimize errors, and experience enhanced collaboration with engineering and architecture teams.

Autodesk Navisworks

Navisworks® helps architecture, MEP , structure engineers, and construction professionals holistically review integrated models and data with stakeholders to gain better control over project outcomes. Integration, analysis, and communication tools help teams coordinate disciplines, resolve conflicts, and planprojects before construction .

Autodesk building design suite

ARCHITECTURAL , MEP AND STRUCTURAL ENGINEERING

Autodesk®Revit

Autodesk® Revit® software* is specifically built for Building Information Modeling (BIM), empowering design and construction professionals to bring ideas from concept to construction with a coordinated and consistent model-based approach. Autodesk Revit is a single application that includes features for architectural design, MEP and structural engineering and construction.

ARCHITECTURAL , MEP AND STRUCTURAL ENGINEERING

Autodesk® Revit® software provides mechanical, electrical, and plumbing (MEP) engineers with tools to design even the most complex building systems. Revit supports Building Information Modeling (BIM), to help drive accurate design, analysis, and documentation of efficient building systems from concept through construction.

mechanical & electrical engineer ( HVAC , PLUMING , ELECTRICAL

RevitMEP:

Revit MEP ® Training course

1.

2.

course

hrs / days

Revit MEP basic course 25

Revit MEP Advanced course 25

Training materials : Autodesk official training materials

Prerequisites : There are no required prerequisites for the Essential course .

Attendance : mechanical & electrical engineers & drafters .

1.

Course Objectives :

The primary objective of this course is to teach students the concept of building information modeling and introduce the tools for parametric engineering design and documentation using Revit MEP. After completing this course, students will be able to:

 Understand Autodesk® Revit® MEP, its interface, including viewing, drawing, and editing commands

 Work with linked architectural files

 Create and modify views

 Understand Revit MEP systems in general

 Create spaces and zones.

 Analyze heating and cooling loads

 Work with HVAC module to add air terminals, mechanical equipment, and create HVAC systems

 Work with the Piping module to add mechanical equipment as well as creating hydronic piping systems

 Work with fire protection systems

 Work with fixtures, piping systems and analysis tools in the Plumbing module

 Work with components, circuits, cable tray, and conduits in the Electrical module

 Create and annotate construction documents

 Add tags and create schedules

 Detail in Revit MEP

Course outline :

 Day 1

Building Information Modeling (BIM).

Exploring the User Interface Starting a Project

Viewing commands

Overview and Basic Drawing Tools Linking Revit Models

Copying and Monitoring Linked Files Setting up Levels

 Day 2

Duplicating Views Adding Callout Views Setting the View Display Creating Elevations Creating Sections

Revit MEP Systems settings Working with Components Visiblity and graphics Spaces and Zones Creating Color Schemes

 Day 3

Analyzing the Heating and Cooling Loads Working With Ceilings

V iew Range Library

HVAC Systems Duct Systems

Hydronic Piping Systems Fire Protection Systems

 Day 4

About Electrical Systems Placing Electrical Components Creating Electrical Circuits Cable Trays and Conduit Electrical Panel Schedules

 Day 5

About lighting Systems Placing lighting fixtures Rendering

about low current systems Plumbing Systems

Piping for Plumbing Systems

 Day 6

Construction Documents

Adding Detail Lines and Symbols Creating Legends

Tags and Schedules Detailing in Revit MEP Importing and Exporting

2.Revit MEP advanced course : - Course Objectives :

 The primary objective of this course is to teach students the powerful tools and advanced techniques for creating complex designs , creating advanced systems, creating and customizing objects.

Course outline :

 Day 1

Work sharing

Collaboration and coordination Worksets

Managing Revision.

Walkthroughs 3d view annotation

 Day 2

Shared parameters Parameters

Create project templates Energy Analysis

Transfer project standards

 Day 3

Creating MEP Families

Editing and advanced families creation Autodesk seek

 Day 5

Sketching solid extrusions and voids Aligning and locking geometry

Constraints object styles

Material quantity take off Sheet list

 Day 6

Duct Pressure Loss Reports Pipe Pressure Loss Reports Creating legends

Fabrication parts Materials

Addins and plugins

Autodesk NavisWorks Course :- Course Description

 The Autodesk® Navisworks® training course instructs students in best approaches to combine 3D geometry from cross disciplines into one scene to enable effective model reviews. Through a hands-on, practice- intensive curriculum, students acquire the knowledge needed to review and markup the model, use TimeLiner, Animator, Scripter, and Presenter, as well as the Clash Detective tools within Autodesk Navisworks. Using the functionality of the Autodesk® Navisworks®

Review, Simulate, and Manage features, students learn how to open, review, and run object-interference checks on 3D models. Students also learn how to link to task-scheduling files and create 4D construction simulations. Using the Animator and Scripter tools, students create interactive animations. In addition, students learn how the Presenter tools can help them create photorealistic images and animations.

Training Objectives

After completing this course, students will be able to:

 Describe the main features and functionality of Autodesk Navisworks.

 Open and append 3D files of different formats and save in the Autodesk Navisworks format.

 Create links to object properties files and scheduling files in external databases.

 Perform visual project model reviews using the built-in review and reporting tools.

 Create construction simulations of a project model to check the validity of construction schedules.

 Use Animator and Scripter to create interactive animations for presentations and demonstrations.

 Add true-to-life materials, and lighting and backgrounds to project models, to create photorealistic output.

 Perform interference detection tests between 3D files of different disciplines to check integrity of the design.

1. Autodesk®Navisworks®Training course

course

hrs Days

Autodesk Navisworks training course 24 6

Training materials : Autodesk official training materials

Prerequisites : Completion of Any Revit course or knowledge of 3D design and task-scheduling software

Attendance :(mechanical , electrical , structural , architecture ) engineers & Drafters .

Certification : autodesk course completion certification.

Training Objectives

After completing this course, students will be able to:

 Describe the main features and functionality of Autodesk Navisworks.

 Open and append 3D files of different formats and save in the Autodesk Navisworks format.

 Create links to object properties files and scheduling files in external databases.

 Perform visual project model reviews using the built-in review and reporting tools.

 Create construction simulations of a project model to check the validity of construction schedules.

 Use Animator and Scripter to create interactive animations for presentations and demonstrations.

 Add true-to-life materials, and lighting and backgrounds to project models, to create photorealistic output.

 Perform interference detection tests between 3D files of different disciplines to check integrity of the design

 Course outline:



Getting Started

NavisWorks Interface 3D Model Review

Selection Tree & Selecting Objects Hiding Objects & Overriding Materials Object Properties

Measuring & Moving Objects Selection & Search Sets Viewpoints

Comments & Redlining



Comparing Models Switchback

Navisworks Real-Time Rendering Core Concepts

Navigating The Model



Appending/Merging Files Animation

Configuring & Defining a Simulation Timeliner Simulation

Core Concepts Clash Detective Creating Tasks Gantt View

Import Tasks from External Project File Simulation Export



Creating & Managing Scripts Events

Creating & Configuring Actions Presenter Basics

Materials Lighting Backgrounds Rendering Ground Planes Exporting Images Exporting Animations



Presenter Advanced Features Editing & Managing Materials Advanced Material Editing Individual Light Effects Light Scattering

Image-Based Lighting Backgrounds & Reflections Custom Rendering Effects Custom Environments RPC



Clash Detective Setting Clash Rules Clash Results

Clash Test Reporting Audit Checks

Create & Save Batches of Clash Tests Export & Import Clash Tests

Custom Clash Tests Laser Scan Data Clashing Holding & Releasing Objects Switchback

Time-Based Clashing Quantification

Integrating 2D Takeoffs Using the 2D Markup Tools Modifying Formulas
