1.1.P Precision farming – consideration of reduced exposure in the pollinator risk assessment
Johannes Lückmann, Sibylle Kaiser, Felix von Blankenhagen
RIFCON GmbH, Goldbeckstraße 13, 69493 Hirschberg, Germany, E-Mail: [email protected]
DOI 10.5073/jka.2020.465.039
Abstract
Observed declines in the distribution and abundance of various insect species have moved the topic of biodiversity and the protection of honey bees, an insect species of particular economic interest, into the focus of public attention. This also resulted in an increasing public pressure to reform the European agricultural policy and as part of this to minimise the amount of synthetic plant protection products used.
In this context, so-called ‘precision farming’ offers a considerable potential for a reduced application of plant protection products by using precision application techniques that allow to adjust applications to the actual scale of target distribution within a field. Is however currently not possible to exactly quantify the subsequent decrease of exposure of non-target organisms. Focusing on honey bees, the authors are therefore in a first step proposing a field study design to quantify the direct and indirect exposure of honey bees and their colonies in relation to the ratio of treated to untreated field area and the application pattern used. Furthermore, parameters of the bee risk assessment scheme are discussed that could be suitable to describe exposure reduction by precision application.
Keywords: precision farming, precision application, plant protection product, honey bees, exposure Introduction
Recent publications on severe declines in the distribution and abundance of various insect species and the potential reasons for this trend (see e.g. DNR 2018, NABU 2018, Sánchez-Bayo & Wyckhuys 2019, Seibold et al. 2019) as well as citizens' initiatives on the protection of bees (two European Citizens Initiatives in 2019) have moved the topic of biodiversity into the focus of public attention. Consequently, European agricultural policy is under increasing public pressure to reorient the current agricultural practice in the European Union in general and in particular to minimise the amount of synthetic plant protection products applied and to reform the criteria for their authorisation and use (EU 2009a, FMFA 2013).
In this context, modern technological developments in the field of precision farming offer a considerable potential for a reduced use of plant protection products (e.g. Heege 2013) and thus for a decreased exposure of non-target organisms to plant protection products by adjusting applications to the actual scale of target (i.e. in-crop arthropods and weeds or fungi on crop plants) distribution within a field.
In the following, we exemplarily discuss the potential of precision application of plant protection products for the exposure reduction of adult honey bees, an economically and ecologically important insect group of particular public interest, and their colonies. In addition, a study design is proposed to further examine the relationship between the ratio of treated to untreated field area, application pattern and bee exposure.
Moreover, suggestions are made, how to include the resulting reduced exposure of honey bees into the honey bee risk assessment according to the ‘EFSA Guidance Document on the risk assessment of plant production products on bees’ (EFSA 2013) (hereafter called EFSA Bee GD). Parameters of the bee risk assessment scheme are discussed that could be suitable to describe risk mitigation by the precision application of plant protection products.
Abstracts: Poster
Examples for precision application equipment to reduce the area where plant protection products are applied
For the purpose of precision control of fungal diseases, insect pests and weeds, a wide range of application techniques for site/target-specific and small scale application are available or in the development stage. These application techniques may have further components to determine the spatial distribution of the target in real time. Such techniques are for example:
Pulse-width modulation sprayers, allowing variable application rates across fields by quick flow rate changes and individual spray nozzle control (see Fig. 1a; see e.g. Butts et al. 2018) Direct injection spraying, allowing application of different plant protection products on sub-areas
(e.g., Clarke 2018)
Field sprayers or robots equipped with sensing devices and sprayer systems allowing real time, targeted spot applications on weeds (see Fig. 1b & c, 2; e.g., Scholz et al. 20014).
Fig. 1 Exemplary precision spraying systems – pulse width modulation (a), patch spraying of the SmartSprayer
joint project (b), Bonirob (c)
Exposure routes of honey bees to plant protection products and the potential benefits of ‘precision farming’
Within any agricultural landscape, there are several potential exposure routes for honey bee to plant protection products (Gradish et al. 2018). When considering the worst-case exposure situation of bees foraging in a flowering, bee attractive crop, the following main exposure routes to sprayed plant protection products or their residues, respectively, are relevant:
Adult bees: contact exposure via spray deposits (i.e. overspray or spray drift) during foraging activity;
Adult bees: oral exposure via pollen & nectar collected as food within the treated field (from crop and weed plants);
Bee larvae: oral exposure via consumption of pollen and nectar collected by forager bees in the treated field and supplied as food to larvae
In contrast to overall spraying, the use of precision application techniques creates the possibility to reduce the share of treated area within a field. This reduction of treated in-field area will result in a declining number of (A) over-sprayed bees and (B) forage plants (crop plants and weeds growing in the field and close by) and subsequently in a decrease of the overall residue level in pollen and nectar collected in the field by the entire colony.
Abstracts: Poster
Fig. 2 Exposure of honey bees foraging within a field treated with precision application techniques
The authors would like to put forward the hypothesis that the decrease of exposure of an entire bee colony is proportional to the share of treated area within the field and that at a given ratio of treated to untreated field area, the reduction in exposure is independent from the application pattern. Verification of the hypothesis on the correlation of application scheme and honey bee exposure
The following field study design is envisaged to verify the above given hypothesis. The scheme is based on EPPO (2010), EFSA Bee Guidance (2013) and current recommendations of the ICPPR WG on honey bee field testing:
Use of several fields of a flowering and bee attractive crop (e.g., rape, mustard, buckwheat, phacelia);
Fields of appropriate and uniform size (e.g., 2-3 ha with sparse alternative forage nearby); Honey bee hives located at the field border;
Spray application of a non-toxic, hydrophilic (not bounding to wax) tracer;
Use of a tracer to determine the proportion of bees topically contaminated via over-spray or spray drift (e.g., via tracer colour by recording bees with digital monitoring devices);
Determination of the amount of tracer as residue surrogate in pollen and nectar entering the hive by ‘residue’ analysis in these matrices obtained from returning honey bees (i.e., honey sac dissection, pollen loads);
The study set-up needs to include overall and partially sprayed fields; the latter with different application patterns, in sufficient replication (Fig. 3). For partially sprayed fields, ratios of 1 (treated): 1 (untreated) (Fig. 3b & c & d), 3 : 1 (Fig. 3e), etc. should be considered to investigate potential correlations of application scheme and exposure.
Fig. 3 Illustration of different application patterns to investigate contact exposure proportions of foraging bees
and residue levels of pollen and nectar entering the hives ((a) total area treated, b) to d) ratio of treated vs. untreated area 1:1, in different application patterns, e) ratio treated vs. untreated area 3:1; honey bee hives located at the field border
Abstracts: Poster
Consideration of precision application in the honey bee risk assessment for plant protection products
The benefits of reduced exposure of honey bee colonies by precision application could be used in the honey bee risk assessment conducted for the placing of plant protection products on the market according to Regulation (EC) No 1107/2009 (EU 2009b).
The current risk assessment procedure described in the EFSA Bee Guidance Document (GD) assumes uniform exposure of foraging honey bees and uniform residues in pollen and nectar of crops and weeds growing within a treated field. In contrast, the use of precision application techniques would lead to non-uniform contact and oral exposure of forager bees in the treated field and reduced exposure of their colonies to residues in food matrices. Although, the EFSA Bee GD already envisages the consideration of spatial variation of exposure, details and guidance how to handle this aspect are not provided.
Thus, it would be necessary to adapt the current risk assessment approach to consider the exposure aspects of precision application. The following parameters could be suitable to describe reduced exposure in partially treated fields:
The exposure factor, which is currently set to ’1’ (i.e., 100% exposure) for adults and larvae; The mean default initial residue concentrations in pollen/nectar of the crop in the treated field
(expressed as Residue Unit Dose (RUD)); and,
The shortcut values for crops being attractive due to their pollen and/or nectar supply, depending among other parameters on the RUD.
However, results of field studies following the above outlined design need to be conducted first to get a realistic picture of the exposure of honey bees colonies in partly treated fieldsand to support the identification of suitable risk assessment parameters.
Acknowledgements
Many thanks to AMAZONE (Hasbergen-Gaste, Germany) providing figures on spraying systems and Jan-Dieter Ludwigs (Rifcon GmbH) for his comments on the manuscript.
References
BUTTS,T.R.,G.R.KRUGER,2018: Pulse-Width Modulation (PWM) Sprayers. What, Why, and How? – Nebraska Extension Publications. NebGuide. G2302. http://extensionpubs.unl.edu/publication/9000019910805/pulse-width-modulation-pwm-sprayers-g2302/ (date of last query: 15.01.2020)
CLARKE, A., 2018: Is direct injection spraying technology about to take off? https://www.futurefarming.com/Machinery/Articles/2018/2/Analysis-Is-direct-injection-spraying-technology-about-to-take-off-3709WP/ (date of last query: 15.01.2020)
DEUTSCHER NATURSCHUTZRING (DNR) 2018: Forderungen an ein Aktionsprogramm Insektenschutz. https://www.nabu.de/imperia/md/content/ nabude/insekten/180426-dnr-aktionsprogramm-insektenschutz.pdf (date of last query: 15.01.2020)
EPPO,2010:PP 1/170 (4) - Side-effects on honeybees. – EPPO Bulletin 40, 313-319.
EFSA,2013:EFSA Guidance Document on the risk assessment of plant production products on bees (Apis mellifera, Bombus spp. and solitary bees) (published on July 04, 2013, updated on 04 July 2014). – EFSA Journal 11(7): 3295, 268 p.
EFSA,2014:User Manual: A small application developed in R for the estimation of the residue intake rate for certain bee species under given conditions: the SHVAL tool. – EFSA supporting publication, EN-623, 10 p.
EUROPEAN CITIZENS INITIATIVES (ECI) of 27.05.2019: “Save the bees! Protection of biodiversity and improvement of habitats for insects in Europe” (discontinued in favour of ECI 04.09.2019). https://ec.europa.eu/commission/presscorner/detail/en/IP_19_2472 and www.savebeesandfarmers.eu (date of last query: 15.01.2020)
EUROPEAN CITIZENS INITIATIVES (ECI) of 30.09.2019: “Save bees and farmers! Towards a bee-friendly agriculture for a healthy environment“. https://europa.eu/citizens-initiative/initiatives/details/2019/000016_en (date of last query: 15.01.2020) EU2009a:Directive 2009/128/EC of the European Parliament and of the Council of 21 October 2009 establishing a framework
for community action to achieve the sustainable use of pesticides.– Official Journal of the European Union, L 309/71, 16 p. EU2009b:REGULATION (EC)NO 1107/2009 of the European Parliament and of the Council of 21 October 2009 concerning the placing of plant protection products on the market and repealing Council Directives 79/117/EEC and 91/414/EEC. – Official Journal of the European Union L 309/1. 24.11.2009.
FMFA (Federal Ministry of Food and Agriculture 2013: National Action Plan on Sustainable Use of Plant Protection Products. 100 p.
Abstracts: Poster
GRADISH,A.E.,J. VAN DER STEEN,C.-D.SCOTT-DUPREE,A.R.CABRERA,C.CUTLER,D.GOULSON,O.KLEIN,D.M.LEHMANN,J.LÜCKMANN,B.O’NEILL, N.E.RAINE,B.SHARMA,H.THOMPSON, 2018: Comparison of Pesticide Exposure in Honey Bees (Hymenoptera: Apidae) and Bumble Bees (Hymenoptera: Apidae): Implications for Risk Assessments. – Environmental Entomology 48 (1): 12-21. HEEGE,H.J.(ed.),2013: Precision in Crop Farming: Site Specific Concepts and Sensing Methods. Springer Science+ Business Media
Dordrecht. 356 p.
NATURSCHUTZBUND DEUTSCHLAND (NABU),2018,: Aktionsprogramm Insektenschutz. Erforderliche Inhalte eines Aktionsprogramms für den Schutz und die Verbesserung der Lebensbedingungen von Insekten. https://www.nabu.de/imperia/md/content/nabude/insekten/180302-aktionsprogramm_insekten_nabu-hintergrund.pdf (date of last query: 15.01.2020)
SÁNCHEZ-BAYO,F.,K.A.GWYCKHUYS, 2019: Worldwide decline of the entomofauna: A review of its drivers. – Biological Conservation 232: 8-27.
SCHOLZ,C.,M.KOHLBRECHER,A.RUCKELSHAUSEN,D.KINSKI,D.MENTRUP, 2014: Camera-based selective weed control application module (“Precision Spraying App”) for the autonomous field robot platform BoniRob. – Proceedings International Conference of Agricultural Engineering, Zurich, 06-10.07.2014. Ref C0598.
SEIBOLD,S.,M.M.GOSSNER,N.K.SIMONS,et al. 2019: Arthropod decline in grasslands and forests is associated with landscape-level drivers. – Nature 574: 671–674.
