FlexCloud: A Flexible and Extendible

Simulator for Performance Evaluation of

Virtual Machine Allocation

Minxian Xu, Wenhong Tian, Xinyang Wang, Qin Xiong

F

Abstract—Cloud Data centers aim to provide reliable, sustainable and scalable services for all kinds of applications. Resource schedul-ing is one of keys to cloud services. To model and evaluate different scheduling policies and algorithms, we propose FlexCloud, a flexible and scalable simulator that enables users to simulate the process of initializing cloud data centers, allocating virtual machine requests and providing performance evaluation for various scheduling algo-rithms. FlexCloud can be run on a single computer with JVM to simulate large scale cloud environments with focus on infrastructure as a service; adopts agile design patterns to assure the flexibility and extensibility; models virtual machine migrations which is lack in the existing tools; provides user-friendly interfaces for customized config-urations and replaying. Comparing to existing simulators, FlexCloud has combining features for supporting public cloud providers, load-balance and energy-efficiency scheduling. FlexCloud has advantage in computing time and memory consumption to support large-scale simulations. The detailed design of FlexCloud is introduced and performance evaluation is provided.

Index Terms—Cloud Data Centers; Resource Scheduling Algo-rithms; Virtual Machine Allocation; Performance Evaluation; Flexibil-ity and ExtensibilFlexibil-ity

1

I

With various recent advancements in virtualization, like Grid computing, Web computing, utility com-puting and related technologies, Cloud comcom-puting obtains great development. Cloud computing aims to provide both infrastructure and services on de-mand through the Internet or intranet [20], and its benefits can be concluded as hiding and abstraction of complexity, virtualized resources and efficient use of distributed resources. Cloud computing allows the sharing, allocation and aggregation of software, com-putational and storage network resources on demand. Currently, quite a few IT enterprises products, like Amazon EC2 [4], Google App Engine [14], IBM blue Cloud [17] and Microsoft Azure [22] have shown their practice of emerging Cloud computing plat-forms. Whereas there are many challenging issues to be resolved [20] [1] [25], Cloud computing is still

Dr. Tian, Mr. Wang and Miss Xiong are in the school of Computer Sci-ence, University of Electronic Science and Technology of China (UESTC), 610054; Mr. Xu is in the school of software engineering of UESTC.

considered in its infancy. Youseff et al. [19] introduce a detailed ontology of dissecting Cloud into five main layers from top to down: Cloud application (SaaS), Cloud software environment (PaaS), Cloud software infrastructure (IaaS), software kernel and hardware (HaaS), and illustrates their interrelations as well as their inter-dependency on preceding technologies. From structure perspective, Cloud data center can be regarded as a distributed network, containing many computing nodes, storage nodes, or network devices. Each node is composite of a series of resources such as CPU, memory, network bandwidth and so on. In this paper, we focus on Infrastructure as a service (IaaS) in Cloud data centers, and proposing general and flexible definition as well as model that could be used by various cloud providers.

An essential technology in Cloud datacenter is re-source scheduling. One challenge problem related to scheduling in Cloud data center is to consider alloca-tion and migraalloca-tion of reconfigurable virtual machines and integrated features of hosting physical machines. Different from existing load-balancing scheduling al-gorithms that consider only physical servers with one factor such as CPU, the new algorithms treat CPU, memory and network bandwidth integrated for both physical machines (PMs) and virtual machines (VMs). Besides that, real-time virtual machine allocation for multiple parallel jobs and physical machines is taken into consideration. With the development of cloud computing, the size and density of the cloud data center become huge, and problems which need to be solved therewith. For instance, how to manage physical resources and virtual resources intensively and use them dynamically, to improve elasticity and flexibility which can improve service and reduce cost and risk management; and how to help customers build flexible, dynamic, and business growth adapt-ing infrastructure as well as ensure the sustainable development in the future.

Because of the uncertainty of network environ-ments, it is extremely hard to research widely for all these problems in real Internet platform. In

dition, the network conditions cannot be predicted or controlled accurately, but affect the validation of strategies. A considerate way in research is develop-ing a simulation system, which supports visualized modeling and simulation in large-scale applications in cloud infrastructure. Data center simulation sys-tem can describe the application workload stasys-tement, which includes user information, data center position, the amount of users and data centers, and the amount of resources in each data center. Using this informa-tion, data center simulation system generates response requests and allocates these requests to virtual ma-chines. By using data center scheduling simulation system, researchers can evaluate suitable strategies such as distributing reasonable data center resources, selecting data center to match special requirements, reducing costs, finding efficient scheduling algorithms and so on.

The major contributions of this paper are as follow-ing:

• the proposal of a new cloud simulator, FlexCloud, with light weight design to simulate cloud envi-ronment;

• the design and implementation of a flexible and extendible architecture model that resource, re-quest specification and scheduling algorithms can be easily added;

• the validation of the simulator, which has been carried out by comparing realistic data with ac-tual results collected from Lawrence Livermore National Lab [16] trace;

• the performance comparison with CloudSim, which shows FlexCloud has strength in time cost and memory consumption.

The remainder parts of this paper are organized as follows: section 2 describes the related work on virtual machine allocation algorithms and compares existing cloud computing simulators from several categories. At the end of this section, the major contributions of this paper are given. Section 3 demonstrates the archi-tectural model of the newly proposed simulator from several aspects, including its layered architecture, sce-nario, datacenter modeling, VM requests modeling, scheduling algorithms modeling, implemented per-formance metrics, VM migration modeling, schedul-ing process modelschedul-ing and etc. Section 4 presents implementation details and design patterns adopted in FlexCloud. Section 5 and section 6 demonstrate the validation and evaluation of FlexCloud respectively. Finally, this paper ends with the brief conclusions and a discussion on future work.

2

R

A mount of research has been conducted in resource scheduling algorithms, which are significant for cloud data centers. Mastroaianni [8] et al. present a self-organizing and adaptive approach for the consolida-tion of VMs on CPU and RAM resources. Wood et al.

[28] introduce techniques for virtual machine migra-tion and propose some migramigra-tion algorithms. Zhang et al. [29] compare major load balancing scheduling algorithms for traditional web servers. Singh et al. [5] propose a novel load balancing algorithm called VectorDot for handling the hierarchical and multi-dimensional resource constraints by considering both servers and storage in Cloud computing. Doyle et al. [18] propose a system named Stratus to determine the routine decisions for data center requests.

Buyya et al. introduce GridSim [23] toolkit for mod-eling and simulation of distributed resource manage-ment for grid computing. Dumitrescu and Foster [7] introduce GangSim tool for grid scheduling. Buyya et al. [24] introduce modeling and simulations of Cloud computing environments at application level, a few simple scheduling algorithms such as time-shared and space-time-shared are discussed and compared. CloudSim [24] is one of Cloud computing simulators, which provides: modeling large-scale cloud comput-ing infrastructure; models for the data center, service agency, scheduling and distributing strategies; virtual engines, which is helpful to create and manage several independent and collaborative virtual services in a data center node; switching flexibly between process-ing cores with space-sharprocess-ing and time-sharprocess-ing. Cloud-Analyst [6] aims to achieve the optimal scheduling among user groups and data centers based on the current configuration. Both CloudSim and CloudAna-lyst are based on SimJava [12] and GridSim [23]. Also CloudSim and CloudAnalyst treat a Cloud data center as a large resource pool and consider only application-level workloads, may not suitable for Infrastructure as a service (IaaS) simulation where each virtual machine as resource is considered to be requested and allo-cated. A CloudSim-based simulation tool considering DVFS energy model is proposed in [27]. Kliazovich et al. propose an energy-aware simulation environment named GreenCloud for Cloud datacenters [11]. Nunez et al. [3] introduce a new simulator of cloud infras-tructure named iCanCloud using C++ and compare the performance with CloudSim.

Table 1 shows the comparison of some state-of-art cloud simulators as well as FlexCloud proposed in this paper. We compare these cloud simulators from several categories.

Platform: CloudSim and FlexCloud are both imple-mented with Java, so they can be executed on any machine installed JVM. Built in GridSim and SimJava, CloudSim is heavy to execute. MDCSim is written in CSIM, as for GreenCloud and iCanCloud, they are based on NS2 and OMNET respectively.

Language: The languages implemented with the simulators are related to the platforms. CloudSim and FlexCloud are implemented with Java, MDCSim can be implemented with C++ and Java, and GreenCloud needs combining C++ and OTcl, which is difficult for developers.

TABLE 1

Summary of Cloud Simulators

Items CloudSim MDCSim GreenCloud iCanCloud FlexCloud

Platform any CSIM NS2 OMNET, MPI any

Programming Language Java C++/Java C++/OTcl C++ Java

Availability Open Source Commercial Open Source Open Source Open Source Graphical Support Limited (Via CloudAnalyst) None Limited (Via Nam) Full Full

Physical Models None None Limited (Via Plug-in) Full Full

Models for public cloud None None None Amazon Amazon

Support for Parallel experiments No No No Yes No

Support for Energy Consumption Model Yes Yes Yes No Yes

Support for Migration algorithms Yes No No No Yes

Availability: Only MDCSim is commercial, and other four simulators are free or open-source. Flex-Cloud can be fetched from [13].

Graphical support: MDCSim doesnt support inter-face operations. The original CloudSim support no graphical interface, but with CloudAnalyst, the graph-ical interface are supported. However, full support is not provided in CloudAnalyst, in a whole scheduling process, only the configurations and results can be presented. So we label it limited, the same reason for GreenCloud. FlexCloud and iCanCloud support whole scheduling process to be showed on the inter-faces.

Physical models: iCanCloud and FlexCloud pro-vide detailed simulation for physical analogs for the scheduling. GreenCloud needs to use a plug-in to simulate that.

Models for public cloud providers: Both iCanCloud and FlexCloud use the model suggested by Amazon, in which physical machine and virtual machine spec-ifications are pre-defined.

Parallel experiments: Supporting for multiple ma-chines running the experiments together is a main feature of iCanCloud and that feature is under de-velopment. As for FlexCloud, we are working to implement that function as well.

Power consumption model: Except for iCanCloud, other four simulators can support power consumption modeling.

Migration algorithm: CloudSim and FlexCloud sup-port migration algorithms, while other 3 simulators haven’t supported that.

In our teaching practice in our university, we have adopted CloudSim, a mature simulator, as a teaching tool assisted, but according to the students feedback, CloudSim is a bit complex to use and heavy to exe-cute. That complexity is also a feature of iCanCloud. As for MDCSim, a commercial tool, is not appropriate for researching. Apart from that, its not easy to use several languages together in GreenCloud, since it is implemented with C++ and OTcl.

The main contribution of FlexCloud lies in that it is implemented with light weight design, flexible to extend as well as easy to start. Besides the benefits for teaching, we also cooperate with a company research-ing in resource schedulresearch-ing to boost the functions of

FlexCloud under multi-datacenter environment. They would use FlexCloud to explore suitable algorithms for their company applications.

3

T

A

M

F

-C

Fig.1 shows the overview architecture of FlexCloud with layered components. The top layer is Client Layer that provides the interface for user to config-ure requests properties and have results feedbacks from lower layers. At this layer, a GUI implemented with Java Swing supports user to configure algo-rithm types, set PM and VM specifications and select scheduling algorithms. After all settings are com-pleted, the defined configurations would be submitted to lower layer and a sequence of scheduling steps would be processed. Comparison diagrams as well as result outputs would be sent as feedback to Client Layer. At lower layer, a Requests Broker is imple-mented at Broker Layer acting as a mediator between Client Layer and Scheduler Layer. This Layer is re-sponsible for verifying the inputs from Client Layer and transforming the settings into recognized com-mands at Scheduler Layer. For instance, the number of VM requests submitted from Client Layer would be written into a configuration file, which could be read in the process of scheduling at Scheduler Layer. Scheduler Layer implements the core functions for FlexCloud system. At this layer, the scheduling pro-cess is defined: VM Requests Generation component generates the VM requests with configured properties on user interface; Datacenter Scheduler component schedules the particular algorithms to allocate VMs to corresponding PM according to algorithms; VM Requests Allocation component manages the allocated VMs, including checking the allocation conditions and removing VMs at the end of their lifecycles. At bottom layer, Resource Layer contains a Resource Management component providing resource that VM requests require and supporting services for higher levels. Besides the component, the physical resource, such as servers, network and storage are resources of the whole system.

Fig.2 shows an application scenario with FlexCloud. This figure shows the three main components: user,

Fig. 1. Layered FlexCloud architecture

FlexCloud scheduler center and other computing cen-ters. The FlexCloud scheduler center is responsible for the following main tasks: (1) accepting the VM re-quests sent by users; (2) managing computing centers that in service; (3) finding available computing unit to allocate requests; (4) sending feedback information to users. Computing centers represent a pool of Physical Machines (PMs) or Virtual Machines (VMs), each one configured with a pre-defined specification such as CPU, memory and storage. Users are represented as component that submits a set of jobs to be allocated to specific PM in computing center. These submissions submitted directly to the FlexCloud scheduler center. Then, the requests are managed by this module to be allocated to specific PM in the corresponding data center. After all requests have been processed, a feed-back report would be sent feed-back to the user.

3.1 Modeling the datacenter in FlexCloud

From computing resource point of view, a data center consists of a number of physical servers (PMs), net-work devices, storages and other related equipment. A PM contains several kinds of resource, like CPU, memory, storage and bandwidth, etc. Before VM re-quests are coming, the PMs are at the state of turned-on, which means the class of Physical Machine is instantiated in FlexCloud. The number of instances depends on the number of PMs would provide ser-vices.

In TABLE 2, the 3 suggested types of heterogeneous PMs in FlexCloud are listed, and the configuration can

TABLE 2

3 types of physical machines (PMs) suggested

PM Pool Type Compute Units Memory Storage

Type 1 16 units 30GB 3380GB

Type 2 52 units 136GB 3380GB

Type 3 40 units 14GB 3380GB

be dynamically set. The type and property values, like CPU, memory, storage and power, are recorded in a configuration XML file (in Fig. 3), which would be loaded into system. Because these property values are in XML file, modification can be easily done either for exactly value or new added property elements. For instance, if more types of PMs are needed, the

pair < pminf o > type−id < pminf o > could be

created and other values of this type PM could so also be added. Besides the load balance algorithms, we also implement energy-saving algorithms that contain a new property named power consumption. This property is added in the configuration XML file and corresponding methods are added in class PhysicalMachine. The corresponding methods in class PhysicalMachine are responsible for accessing these property values.

More detailed information related to comparison indices can be found in Section 3.3. In datacenter model, the left resource capacity decides whether a VM request can be allocated to that PM. At initializa-tion stage, PM has a full capacity resource to offer

ser-Fig. 2. A scenario architecture with FlexCloud

Fig. 3. PM specification in XML file

vices. Either the allocation or remove operation would update the available capacity value and influence the later requests allocation.

3.2 Modeling VM requests in FlexCloud

We use a simple example to show how VM re-quests are modeled in FlexCloud in Fig. 4. Slots

#1,#2, . . . ,#6 represent the time slots in discrete

time, which can be treated as a second or a minute that a request is in. For instance, VM2 occupies time slot 3 to 5, so lifecycle of VM2 is 3 slots. The value 0.0625 is proportion of resource occupation, meaning that VM2 would occupy 6.25% resource of the PM it is allocated to, during time slot 3 to 5. In our model, several VM requests can share the capacity of the same PM at the same time slot only if the capacity is enough.

0.0625 0.0625 0.0625

Fig. 4. an example of VM requests

TABLE 3 shows the corresponding CPU, memory, storage values for different VMs. Also for extensi-ble reason, these property values are also recorded into a configuration XML file. Once a VM request is allocated to a PM, the left resource capacity would be decreased by the value of that request, and the capacity is increased back when request is released.

In FlexCloud, several VM requests generation ap-proaches have been implemented, in which requests can be generated in Poisson, Normal and Random distributions. When the specific distribution is se-lected, the start time or duration of the generated requests would follow the distribution. In section 5,

TABLE 3

8 types of virtual machines (VMs) in Amazon EC2

Compute Units Memory Storage VM Type 1 units 1.7GB 160GB 1-1(1) 4 units 7.5GB 850GB 1-2(2) 8 units 15GB 1690GB 1-3(3) 6.5 units 17.1GB 420GB 2-1(4) 13 units 34.2GB 850GB 2-2(5) 26 units 68.4GB 1690GB 2-3(6) 5 units 1.7GB 350GB 3-1(7) 20 units 7GB 1690GB 3-2(8)

we would show the data collected from different distributions. Moreover, its available for FlexCloud to import requests data from file in the Generate VMs step (see section 3.6), which means it can be tested under realistic data.

3.3 Modeling Scheduling Algorithms in FlexCloud Four kinds of scheduling algorithms are provided in FlexCloud based on scheduling goals and request types. For request types, scheduling algorithms can be divided into online algorithms and offline algorithms, the difference lies in whether the requests information is all known before scheduling. Requests would come and be operated one by one in online algorithm, while requests sequence can be adjusted by processing time or end time because all requests information have been collected before scheduling in offline algorithms. Another division principle is via goal: we consider load balancing and energy saving in FlexCloud.

When comparing the effects of different algo-rithms, the scheduling process would be same ex-cept that the scheduling algorithms are different. For online load balancing comparison, Random, Round-Robin (Round), List Scheduling (LS) algorithms have been implemented. Under the layered architectural model and related design pattern (introduced in later section), new created algorithms can be added to scheduling algorithm library, without influencing other existed algorithms.

We take the Random algorithm, one of the simplest algorithms, as an example to show scheduling algo-rithm could be modeled, mapped and extended in FlexCloud. Fig.5 shows the pseudo-code of Random algorithm. After a data center scheduler has initialized the PMs and VM requests, Random algorithm would randomly generate an index in the range of 0 andM-1 (line 3) for PMs. Then VM request will be allocated to the PM with generated index (line 5), if allocation is successful by checking whether the PM has available resource, then allocated PM needs updating its left capacity (line 7), another index would be generated if allocation is failed and the VM request should be allocated again with a new index (line 8-9). As VM requests have lifecycles, the VM requests should be released from hosting PM to prepare for other VM

requests’ allocation (line 11 to 12) after their end-time expired. This example is based on singe data center, while under multiple data centers, the index genera-tion process would be involved with data center id generation, rack id generation and PM id generation rather than only PM id generation.

Fig. 5. The pseudocode of Random algorithm

The algorithm process of R-R and LS is quite similar to Random except the way the index is generated for PMs or VMs. In R-R algorithm, index generation is in a round robin way while the index refers to the PM with the least average utilization in LS algorithm. The more complex algorithms, Post Migration algo-rithms and Prepartition Algorithm, that considering migrations operations introduced in section 3.5 could also be modeled based on these principles. As for offline load balancing algorithms, a procedure of re-quest processing should be added before line 4. The processing procedure may change the requests order by processing time or end time or other features. Also, the process of online/offline energy-saving algorithms taken is similar to online/offline load balancing algo-rithms.

3.4 Performance Metrics in FlexCloud

In this section, we introduce the major performance metrics we used in FlexCloud:

For load balancing algorithms:

Average utilization: Each PM would have the utilization value in scheduling process, and average utilization is the arithmetic average value of all PMs in the data center;

PM resource:P Mi(i, P CP Ui, P M emi, P Storagei),iis

the index number of PM,P CP Ui, P M emi, P Storagei

are the CPU, memory, storage capacity of that a PM can provide.

VM resource:

is the VM type ID, V CP Uj, V M emj, V Storagej are

the CPU, memory, storage requirements of V Mj,

Tstart

j , Tjend are the start time and end time, which

are used to represent the life cycle of a VM.

Time slot: we consider a time span from 0 to T be divided into parts with same length. Then n parts can be defined as [(t1−t0),(t2−t1), . . . ,(tn−tn−1)],

each time slotTk means the time span (tk−tk−1).

Average CPU utilization of P Mi during slot 0 and

Tn: P CP U_iU = Pn k=0(P CP U Tk i ×Tk) Pn k=0Tk (1) And memory P M emU

i and storage P StorageUi

uti-lization of both PMs and VMs can be computed in the same way. Similarly, average CPU utilization of a VM can be computed.

Integrated load imbalance value ILBi of P Mi. The

variance is widely used as a measure of how far a set of values is spread out from each other in statistics. Using variance, an integrated load imbalancing value

ILBi of server iis defined

ILBi= (Avgi−CP UuA)2 3 + (Avgi−M emAu)2 3 +(Avgi−Storage A u)2 3 (2) where Avgi = P CP UU i +P M emUi +P StoargeUi 3 (3)

andCP UuA, M emAu, StorageAu are respectively the

av-erage utilization of CPU, memory and storage in a Cloud data center.

ILBi is applied to indicate load imbalance level

comparing utilization of CPU, memory and network bandwidth of a single server itself.

Makespan: is as same as traditional definition, and therefore the capacity makespan of all PMs can be formulated as below:

capacity makespan= max

i (Li) (4)

Load efficiency (skew of makespan): is defined as the (minimal average load divided by maximal average load) on all machines:

skew(makespan) = mini(Li)

maxi(Li)

(5) where Li is the load of PM i. Skew shows the load

balancing efficiency to some degree.

Capacity makespan: In any allocation of VM requests to PMs, we can letA(i)denote the set of VM requests allocated to machine P Mi, under this allocation,

ma-chineP Mi will have total loads,

Li =

X

j∈A(i)

cjtj (6)

Based on the above definitions and equations, we have developed another metric, capacity skew on

load balancing algorithm for the new situation as follow:

Skew of capacity makespan is defined as the minimal capacity makespan over maximal capacity makespan on all machines (referring to equation (6)):

skew(capacity makespan) = min

P

j∈A(i)cjtj

maxP

j∈A(i)cjtj

(7) where cj is the capacity (for example CPU) requests

ofV Mjandtjis the span of requestj (i.e., the length

of processing time of requestj).

For energy saving algorithms, following indices are provided:

1) The total number of PMs turned-on during the scheduling;

2) Rejected number of VM requests: VM requests which cannot be served by the data center resources; 3) Total energy consumption: the energy consumption of all PMs (including VMs allocated on them); a less total energy consumption value reflects a better energy saving effect for a given set of requests.

In [1], authors found that CPU utilization is typ-ically proportional to the overall system load, and proposed a power model defined in equation (8):

P(u) =kPmax+ (1−k)Pmaxu (8)

wherePmax is the maximum power consumed when

the server is fully utilized; kis the fraction of power consumed by the idle server (studies show that on average it is about 70%); and u is the CPU utiliza-tion. This paper focuses on CPU power consumption, which accounts for main part of energy comparing to the other resources such as memory, disk storage and network devices. In FlexCloud, we use the power model defined in (8). Equation (8) is further reduced to (9):

P =Pmin+ (Pmax−Pmin)u (9)

wherePmin is the power of given PM when its CPU

utilization is zero (the PM is idle without any VM running). In real environment, the utilization of the CPU may change over time due to the workload variability. Thus, the CPU utilization is a function of time and is represented as u(t). Therefore, the total energy consumption by a PM (Ei) can be defined as

an integral value of the power consumption function over a period of time as in (10):

Ei=

Z t1

t0

P(u(t))dt (10)

Ifu(t)is constant over time, for example average uti-lization is adopted,u(t) =u, thenEi=P(u)×(t1−t0).

The total energy consumption of a cloud data center is computed as (11): EDC = n X i=1 Ei (11)

It is the sum of energy consumed by all PMs. Notes that energy consumption of all VMs on PMs is in-cluded.

Also confidence intervals can be calculated for dif-ferent metrics as follows: Let x1, x2, x3, ..., xn be the

calculated metrics (such as IBLtot and Ecdc values

etc.) from n times of repeated simulations. Then the mean is xmean= 1 n n X i=1 xi (12)

and the standard deviations is

s=

s Pn

i=1(xmean−xi)2

n−1 (13)

and the confidence interval at 95%confidence is given by (xmean−1.96 s √ n, xmean+ 1.96 s √ n) (14)

Above are basic the metrics that already implemented in FlexCloud. Other metrics could also be included for further research.

3.5 Modeling Virtual Machine Migrations in Flex-Cloud

There is lack of virtual machine migration modeling in existing simulation tools. In [32], the detailed algo-rithms about migration are introduced and compared. In this section, we provide brief introduction to vir-tual machine migration modeling in FlexCloud. The key difference from allocation is that the migration objectives and the choose of resource and destination PMs. Two typical migration algorithms are introduced in FlexCloud:

Post Migration algorithm: Firstly, it processes the requests in the same way as LPT (Longest Processing Time first) does. Then the average capacity makespan of all jobs is calculated. The up-threshold and low-threshold of the capacity makespan for the post migration are calculated through the average capacity makespan multiplied by a factor (in this paper we set the factor as 0.1, so the up-threshold is average capacity makespan multiplied by 1.1 and the low-threshold is multiplied by 0.9). Off course the fac-tor can be set dynamically to meet different require-ments; however, the larger the factor is, the higher imbalance is. A migration list is formed by collecting the VMs taken from PMs with capacity makespan higher than the low-threshold. The VMs would be taken from a PM only if the operation would not lead the capacity makespan of the PM to be less than the low threshold. After that, the VMs in the migration list would be re-allocated to a PM with capacity makespan less than the up-threshold. The VMs would be allocated to a new PM only if the operation would not lead the capacity makespan of

the PM to be higher than the up-threshold. There may be still some VMs left in the list, finally the algorithm allocates the left VMs to the PMs with the lowest capacity makespan until the list is empty.

Capacity makespan Prepartition Algorithm: novel work proposed by ourselves. For a given set of VM reservations, let us consider there aremPMs in a data center and denote OPT as the optimal solution for a given set ofJ VM reservations. Firstly define

P0=max{maxJj=1CMj, 1 m J X j=1 CMj} ≤OP T (15)

P0is a lower bound on OPT. The Capacity makespan

Prepartition algorithm is introduced in detailed in [32]. It firstly computes balance value by equation (15), defines partition value (k) and finds the length of each partition (i.e. dP0/ke, which is the max time

length a VM can continuously run on a PM). For each request, Prepartition equally partitions it into multiple dP0/ke subintervals if its CM is larger than dP0/ke, and then finds a PM with the lowest average

capacity makespan and available capacity, and up-dates the load on each PM. After all requests are allo-cated, the algorithm computes the capacity makespan of each PM and finds total partition (migration) num-bers. For practice, the scheduler has to record all possible subintervals and their hosting PMs of each request so that migrations of VMs can be conducted in advance to reduce overheads.

FlexCloud therefore can evaluate the performance of different migration algorithms; the evaluation process is similar to allocation algorithms.

3.6 The Scheduling Process in FlexCloud

The major steps of the scheduling process in Flex-Cloud are as followings:

1). Booting PMs: it loads the configuration XML file containing PM specifications set by user from user interface. After needed information is collected, in-stances of PMs are created to prepare for VM allo-cation.

2). Generating traces (VM requests): it loads the con-figuration XML file containing VM specifications and VM traces from user interfaces.

3). Comparing scheduling algorithms: two or more iterators would collect the compared algorithms and compared indices. All selected algorithms will be compared and corresponding indices are collected. 4) Output results: the comparison results are outputed in both text or diagrams format.

For building a more flexible system, the scheduling process only defines the basic framework process and customization may be improved based on this pro-cess. Before booting PMs, the PM specifications can be modified in configuration file. As for generating VM requests traces, besides the configuration file, more VM requests creation methods can be implemented.

Fig. 6. Scheduling process in FlexCloud

Various algorithms can be developed in algorithm scheduling process and other results format may be adopted for better visual effects. Fig. 6 shows a scheduling process combing user interface configura-tions and basic scheduling process.

4

I

F

C

In this section, we will introduce the detailed imple-mentation of FlexCloud from design patterns’ point of view. The design principles are mainly aiming at satisfying agile system goals with flexibility and extendibility.

4.1 Main Features in FlexCloud

Considering design principles, FlexCloud mainly has following novel features:

(1) FlexCloud is built on Java platform and can be run on a single computer installed JVM to simulate large scale cloud infrastructure as a service (IaaS). A computer with 4 GB memory can simulate larger scale applications. We test the condition when the Java environment would throw an OutOfMemory exception by increasing requests gradually. With a 4 GB memory computer, experiments can simulate scheduling process of more than 100,000 requests. We have extended our tests with computers with 2GB memory, that configuration can simulate requests ranging from 25,000 to 50,000.

(2) A user-friendly GUI is provided and lots of customized configurations can be set to satisfy various simulation assumptions. The basic operation includes: select algorithm type, set VM numbers, set average duration, set start time, set total number of PMs, select comparison algorithms and indices. Of course, without GUI, user can also simulate a cloud datacenter and scheduling process in .java class file as well.

(3) A scheduling process framework is defined, each step of process can be extended easily in agile style. (4) New scheduling algorithms and performance

metrics are flexible and extendable to add in; currently load-balancing and energy-efficiency scheduling algorithms are considered.

(5) Virtual machine migration is modeled, this is still lack in current simulation tools.

4.2 Design Patterns in FlexCloud

Fig. 7. Decorator pattern in FlexCloud

FlexCloud has adopted some design patterns to meet the extendible goal. Fig.7 shows decorator pat-tern to meet the requirement that requests gener-ation approaches may differ. Class CreateVMDec-oratorA and CreateVMDecorateB extend the creat-eVM() method of CreateVM and add a new behavior method. With this pattern, when new requests gen-eration approaches are needed, we can rewrite the method addedBehavior(). Under this method, func-tion of class CreateVM can be dynamically added or deleted. For instance, new resource is needed, resource collection codes can be put in the addedBe-havior() method rather than change the existing codes or add new classes.

Fig. 8. Abstract Factory pattern in FlexCloud

Fig.8 shows the Abstract Factory pattern to meet the requirement of different compositions of requests generation approaches and scheduling algorithms. An instance of LoadBalanceFactory would combine a request generation approach from CreateVM and scheduling algorithms from generalization of Allo-cateAlgorihm. These different combinations can pro-duce diverse scheduling process, like set requests

order by processing time and scheduled by a subtype of class OnlineAlgorithm. Adopting this design pat-tern can avoid fixed composition and gain a better extendable effect.

Fig. 9. Strategy pattern in FlexCloud

Strategy pattern in Fig.9 defines a series encapsu-late scheduling algorithm classes: Random, Round-Robin, and OLRSA [18] for OnlineAlgorithm and LPT (Longest Process Time) etc. for OfflineAlgorithm, which can be substituted with each other, enabling scheduling algorithms be independent on the changes from users. With strategy design pattern, when a new algorithm is joined, only allocate() method in new joined algorithm should be implemented. After that, the new joined algorithm can work as same as existing algorithms.

Fig. 10. Iterator pattern in FlexCloud

Fig.10 shows the Iterator pattern to meet the re-quirement of algorithm and indices results compar-ison in data centers. After user have selected the comparison indices and algorithms on user interface, the selected algorithms and indices would be added to separate list, at the same time, Iterator for algorithm and index, Index Iterator and Algorithm Iterator, would be generated. When outputting results, the Iterator would schedule algorithms in Iterator one by one and output indices results with showIndex() method in order. To satisfy the Iterator, both

algo-TABLE 4

Theoretical and simulation results comparison of LS algorithm

LS Indices Theoretical Simulation Average Utilization 0.5 0.5 Imbalance Degree 0.0 0.0 Makespan 0.5 0.5 Skew(makespan) 1 1 Capacity makespan 50 50 Skew(capacity makespan) 1 1

rithms and indices should extend from their base class. The strength for this design pattern is also a favorable extendibility. It’s intelligent when new algorithms and indices are implemented, the Iterator would compare results only if they are appended to it.

4.3 Communications Between Entities

Fig. 11. Sequence diagram of basic process

Fig.11 depicts the flow of communication among important FlexCloud entities. At the beginning of the simulation, a DataCenter entity sends necessary messages that BootPM entity needs to start PMs pro-viding services in datacenter. CreateVM entity would also accept messages it needs to create VM requests. AlgorithmIterator and IndexIterator entities act to run scheduling algorithms and send calculated indices values back to DataCenter entity.

The communication flow described above is a basic flow in a simulated experiment. Some variations in this flow are possible depending on the scheduling process. For example, before bootPM() and creat-eVM(), the message sent by a datacenter should be verified.

5

V

F

C

To validate the accuracy of FlexCloud, we have de-signed some test cases to compare the theoretical results and simulation results. In this section, we use LS (List Scheduling), LPT(Longest Processing Time First), EDF(End-time Decreasing First) algorithms to compare theoretical and simulation results.

TABLE 5

theoreticcal and simulation results comparison of LPT algorithm

LPT Indices Theoretical Simulation Average Utilization 0.505 0.505 Imbalance Degree 0.0 0.0 Makespan 1 1 Skew(makespan) 1 1 Capacity makespan 50.5 50.5 Skew(capacity makespan) 1 1 TABLE 6

theoretical and simulation results comparison of EDF algorithm

EDF Indices Theoretical Simulation Power Consumption 250000 250000

Rejected Number 10 10

Turned on PMs 20 20

The test cases we designed are easily theoretically calculated and can reflect some general situations. For LS algorithm that always allocate a VM to the PM with the lowest load, we set that there are 100 PMs and 100 VMs requests both in the same types, the start-time of requests are ordered in increasing sequence, 1,2,3, . . . ,100, and all requests duration are 100 and require capacity is 0.5 of a PM. Since PMs number and VMs number are same in this case, LS algorithm works as Round-Robin algorithm, that means each PM would undertake a VM task. Then we calculate the values in theoretical way and simu-lation, same results have been observed and shown in TABLE 4.

We also design a test case for LPT algorithm, an offline algorithm that VM requests can be reordered by processing time before they are allocated. In this case, there are 50 PMs and 100 VMs both in the same types, each request requires 0.5 capacity of a PM and starts at 1,2,3, . . . ,100, and the durations of VMs are ordered in decrease order from 100 to 1

as100,99,98, . . . ,1. Same results have been observed

and collected in TABLE 5.

For energy saving algorithm EDF, it should be noticed that comparison indices are different and requests are ordered by end-time. In this case, we set that there are 20 PMs and 50 VMs both in the same types, the start-times of VM requests are ordered in in-creasing as1,2,3, . . . ,50and end-times are decreasing

as100,99,98, . . . ,51. Each VM requires 0.5 capacity of

a PM. We adopt the energy saving model referred to section 3.4 and assumePmin= 300,Pmax= 500. Same

theoretical and simulation values have been collected in TABLE 6. Referring to the collected data in TABLE 5 and 6, the results show the correctness of FlexCloud.

6

E

In this section, we provide more performance evalu-ations for FlexCloud, including evaluevalu-ations for differ-ent algorithms with basic and advanced settings. 6.1 Basic Algorithm Performance Evaluations To begin with, we compare scheduling algorithms performance with basic settings, and show the comparison diagrams generated by FlexCloud. The related settings are as followings:

1) Algorithm type: is online load balancing;

2) PM specifications: using suggested specifications in Amazon EC2 shown in Table 2. PM type1 number is 50, type2 and type3 number are set as 0 to simplify simulation;

3) VM requests: using suggested specifications in Amazon EC2 as shown in Table 3 and 3, and requests are generated under Normal Distribution.

4) Algorithms for comparison: Random, RoundRobin (R-R) and List Scheduling algorithm (LS, referring to section 3.3);

5) Indices for comparison: average utilization, imbalance degree, capacity makespan, skew of makespan, skew of capacity makespan.

FlexCloud provides several output formats for fur-ther analysis, like diagram outputs, text outputs or outputs in Excel file. The diagram output results are showed as bar chart presented in Fig. 12, which is composite of three small diagrams. As seen from these diagrams, it can be concluded that LS over-whelms the other two algorithms on imbalance de-gree, makespan, skew of makespan, and the skew of capacity makespan with the settings. Its easy to understand as LS algorithm dynamically allocates VM requests based on the PM loads while Random and RoundRobin algorithms do not collect real-time load information from PMs.

6.2 Advanced Algorithm Performance

Evalua-tions

To extend performance evaluations, we also compare scheduling algorithms performance with advanced settings and collect the comparison data. The related settings are as following:

1) Algorithm type is offline load balancing;

2) PM specifications: using suggested specifications in Amazon EC2 shown in Table I. PMs with different numbers are considered. PMs numbers are varying from 15, 30, 60 to 240 and each type of PMs occupies about 1/3 of total PMs numbers;

3) VM requests: using suggested specifications in Amazon EC2 shown in Table II. We adopt the log data at Lawrence Livermore National Lab (LLNL) to reflect realistic data generation. The log contains months of records collected by a large Linux cluster

Fig. 12. Output comparison Diagram

and has characteristics consistent with our problem model. Each line of data in that log file includes 18 elements, while we only need the request-ID, start-time, duration and number of processors (capacity demands) in our simulation. We convert the units from seconds in LLNL log file into minutes, as we design 5 minutes to be a time slot length;

4) Algorithms for comparison: RoundRobin (R-R), Longest Processing Time first (LPT, referring to section 5), Post Migration Algorithm (MIG, referring to section 3.5), Capacity makespan Prepartition Algorithm (CMP, referring to section 3.5);

5) Indices for comparison: average utilization, imbalance degree, longest process time and capacity makespan.

Fig.13 to Fig.14 show the average utilization, im-balance degree, makespan and capacity makespan comparison for different algorithms with LLNL data trace. From these figures, we can notice that CMP algorithm has better performance than other al-gorithms in average utilization, imbalance degree, makespan, capacity makespan. CMP algorithm has 10%-20% higher average utilization than MIG and LPT, and 40%-50% higher average utilization than Random-Robin (R-R). Prepartition algorithm has 10% -20%lower average makespan and capacity makespan than MIG and LPT, and 40%-50% lower average makespan and capacity makespan than R-R.

Besides the above evaluations, we also vary the partition number k from 4, 8 to 10 to compare the load balance affects. Fig.15 presents imbalance degree of Capacity makespan Prepartition algorithm with differentkvalues. It’s easy to understand that a larger

k value would produce a better load balance, which would lead to more partitions, and more partitions could achieve better load balance effects. It can be ob-served that whatever numbers of migrations to taken, Post Migration algorithm (MIG) just cannot achieve the same level of average utilization, makespan and capacity makespan as Capacity makespan Preparti-tion does.

Fig. 15. The comparison of Time Cost by varying k

values

7

C

F

In this paper, we introduce the FlexCloud, a novel simulator for performance evaluation of virtual ma-chine allocation in Cloud data centers. It is flexible, scalable to simulate resource scheduling in cloud data centers. A complete simulation framework has been built and introduced.

There are a few research directions for extending the simulator:

• Considering more scheduling algorithms. In Flex-Cloud, we already implemented load-balancing and energy-efficiency, other scheduling algo-rithms such as cost-oriented or reliability-oriented algorithms can be added in easily. • Evaluate performance by datasets from real

traces. Currently we are collecting data from real cloud applications, more evaluating results can be provided by real traces and benchmarks. • Providing more visual outputs such as

dash-boards and logical view of different data centers and their resource usages. This information is very important for managers and operators to have.

• Considering more infrastructures, such as net-working devices. Currently FlexCloud considers bandwidth requests and allocations. The network devices such as three-tire switches and routers distributed in different data centers are under modeling consideration.

(a) (b)

Fig. 13. The offline algorithm comparison of average utilization (a) and imbalance degree (b) with LLNL trace

(a) (b)

Fig. 14. The offline algorithm comparison of makespan (a) and capacity makespan (b) with LLNL trace

A

This research is partly sponsored by the National Natural Science Foundation of China (NSFC) (Grant Number:61150110486), and by Scientific Funding of Central University (2012-2014).

R

[1] A. Beloglazov, J.Abawajy, R. Buyya, Energy-Aware Resource Allocation Heuristics for Efficient Management of Data Cen-ters for Cloud Computing Future Generation Computer Sys-tems, Volume 28, Issue 5, May, pp.755-768, 2012.

[2] A. Legrand, L. Marchal, and H. Casanova. Scheduling dis-tributed applications: the SimGrid simulation framework. Pro-ceedings of the 3rd IEEE/ACM International Symposium on Cluster Computing and the Grid, 2003.

[3] A. Nunez, J. Vazquez-Poletti, A. Caminero et al., iCanCloud: A Flexible and Scalable Cloud Infrastructure Simulator, J. Grid Computing 10:185, C209, 2012

[4] Amazon EC2, http://aws.amazon.com/ec2/

[5] A. Singh, M. Korupolu, D. Mohapatra, Server-Storage Virtu-alization: Integration and Load Balancing in Data Centers, in the proceedings of the 2008 ACM/IEEE conference on Supercomputing, pp.1-12, 2008.

[6] B. Wickremasinghe et al., CloudAnalyst: A CloudSim-based Tool for Modelling and Analysis of Large Scale Cloud Com-puting Environments, Proceedings of the 24th IEEE Interna-tional Conference on Advanced Information Networking and Applications (AINA 2010), Perth, Australia, April 20-23, 2010. [7] C. L. Dumitrescu and I. Foster. GangSim: a simulator for grid scheduling studies. Proceedings of the IEEE International Symposium on Cluster Computing and the Grid (CCGrid 2005), Cardiff, UK, 2005.

[8] C. Mastroianni, M. Meo, G. Papuzzo, Probabilistic Consol-idation of Virtual Machines in Self-Organizing Cloud Data Centers. IEEE Transactions on Cloud Computing, vol.1, no.2, pp.215-228, Dec, 2013.

[9] D. Economou, S. Rivoire, C. Kozyrakis, P. Ranganathan, Full-System Power Analysis and Modeling for Server Environ-ments, 2006. Stanford University / HP Labs Workshop on Modeling,Benchmarking, and Simu- lation (MoBS) June 18, 2006.

[10] DMTF Cloud Management, http://www.dmtf.org/standards /cloud

[11] D. Kliazovich, P. Bouvry, S.U. Khan, GreenCloud: a packet-level simulator of energy-aware, J SuperComput, 2010 [12] F. Howell and R. Mcnab. SimJava: A discrete event simulation

library for java. Proceedings of the first International Confer-ence on Web-Based Modeling and Simulation, 1998.

[13] FlexCloud Project, http://sourceforge.net/projects/flexcloud/, 2014

[14] Google App Engine, http://code.google.com/intl/zh-CN/appengine/

[15] H. Zheng, L. Zhou, J. Wu, Design and Implementation of Load Balancing in Web Server Cluster System, Journal of Nanjing University of Aeronautics & Astronautics, Vol. 38 No. 3 Jun. 2006.

[16] Hebrew University, Experimental Systems Lab, www.cs.huji.ac.il/labs/parallel/workload, 2013.

[17] IBM (2007) blue cloud, http://www.ibm.com/grid/

[18] J. Doyle, R. Shorten, D. O’Mahony, Stratus: Load Balancing the Cloud for Carbon Emissions Control. IEEE Transactions on Cloud Computing, vol.1, no.1, pp.116-128, Aug, 2013. [19] L. Youseff, et al., 2008. Toward A Unified Ontology Of Cloud

Computing, In the proceedings of Grid Computing Environ-ments Workshop, GCE08, 2008.

[20] M. Armbrust, A. Fox, R. Griffith, A. Joseph, R. Katz, A. Konwinski, G. Lee, D. Patterson, A. Rabkin, I. Stoica, M. Zaharia. Above the Clouds: A Berkeley View of Cloud com-puting. Technical Report No. UCB/EECS- 2009-28, University of California at Berkley, USA, Feb. 10, 2009.

[21] M. Xu, W. Tian, An Online Load Balancing Schduling Algorithm for Cloud Data Centers Considering Real-time Multi-dimensional Resource, IEEE International Conference on Cloud Computing and Intelligence Systems, 2012.

[22] Microsoft (2008) Windows Azure,

http://www.microsoft.com/windowsazure.

[23] R. Buyya and M. Murshed. GridSim: A Toolkit for the Model-ing and Simulation of Distributed Resource Management and Scheduling for Grid Computing. Concurrency and

Compu-tation: Practice and Experience, 14(13-15), Wiley Press, Nov-Dec., 2002.

[24] R.Buyya, R. Ranjan and R. N. Calheiros, Modeling and Sim-ulation of Scalable Cloud Computing Environments and the CloudSim Toolkit: Challenges and Opportunities, Proceedings of the 7th High Performance Computing and Simulation Con-ference (HPCS 2009, ISBN: 978-1-4244-4907-1, IEEE Press, New York, USA), Leipzig, Germany, June 21 - 24, 2009.

[25] R.Buyya, C. S. Yeo, S. Venugopal, J. Broberg, and I. Brandic. Cloud Computing and Emerging IT Platforms: Vision, Hype, and Reality for Delivering Computing as the 5th utility. Fu-ture Generation Computer Systems, 25(6): 599-616, Elsevier Science, Amsterdam, The Netherlands, June 2009.

[26] R. Prodan and M. Wieczorek, Bi-criteria scheduling of scien-tific grid workflows, IEEE Trans. Autom. Sci. Eng., vol. 7, no. 2, pp. 364376, Apr 2010.

[27] T. Guerout, T. Monteil, G. D. Costa et al., Energy-aware simu-lation with DVFS, Simusimu-lation Modelling Practice and Theory, 39. pp 76-91, Dec 2013.

[28] T. Wood, et. al., Black-box and Gray-box Strategies for Virtual Machine Migration in the proceedings of Symp. on Networked Systems Design and Implementation (NSDI), 2007.

[29] W. Zhang, Research and Implementation of Elastic Network Service, PhD dissertation, National University of Defense Technology, China (in Chinese) 2000.

[30] W. Tian. Adaptive Dimensioning of Cloud Datacenters, in the proccedings of IEEE the 8th International Conference on Dependable, Autonomic and Secure Computing (DASC-09), Chengdu, China, December 12-14, 2009.

[31] W. Tian, Y. Zhao, Y. Zhong, M. Xu, C. Jing, A dynamic and integrated load-balancing scheduling algorithm for Cloud data centers, In the proceedings of CCIS 2011, Beijing, China. Sept. 2011.

[32] W. Tian, M. Xu, Y. Chen, Y. Zhao, Prepartition: A New Paradigm for the Load Balance of Virtual Machine Reserva-tions in Data Centers, To appear in the proceedings of the IEEE International Conference on Communications (ICC), 2014.

Minxian Xuis a graduate student at the School of Software, Univer-sity of Electronic Science and Technology of China, Chengdu, under the supervision of Dr. Tian.

Wenhong Tianfinished his PhD degree in Computer Science, from North Carolina State University in 2007. Currently, he is an associate professor at University of Electronic Science and Technology of China. His research interests include dynamic design and resource management in random changing networks, Cloud computing, RFID middleware design, biocomputing. As the first author, he has pub-lished about 30 journal and conference papers in related research areas during recent years.

Xinyang Wang is a graduate student at the School of Computer Science, University of Electronic Science and Technology of China, Chengdu, under the supervision of Dr. Tian.

Qin Xiongis a graduate student at the School of Computer Science, University of Electronic Science and Technology of China, Chengdu, under the supervision of Dr. Tian.
