products includes the innovative and patented SMP

Data Communications’ copper cabling solution. An

industry pioneer in copper cabling technology, and now

part of Optical Cable Corporation (OCC), SMP products

are the optimum choice to complement an AFC fibre

network. AFC’s total communications cabling solution

encompasses a full portfolio of fibre optic products,

copper closet, workstation and copper cabling.

cc

Copper Closet

Ws

Workstation

(3)

(4)

SMP Data Communications’ Copper Closet connectivity

solutions offer customers engineering excellence and design

innovation. From patented circuit board technology to 100%

component erformance-tested patch cords, SMP continuously

strives to produce quality connectivity components that offer

reliability and value. This dedication to manufacturing

produces components that exceedingly surpass industry

standards and customer expectations.

contents:

cc-2

Limited Axcess

Solution

cc-5

Category 6a

Solutions

cc-8

Patch Panels

cc-14

Zone Distribution

Solutions

cc-17

Cable Assemblies

& Patch Cords

(5)

limited axcess™

Keyed Copper Network Solutions

In part because of the research and development associated with developing a guaranteed 10 Gig system, SMP was able to generate a whole new product line for securing and segmenting network access while continuing to offer superior performance. The patented Limited Axcess™ RJ45 product line offers enhanced network security by providing physically restrictive access to the network using a unique plug and jack interconnect system.

Additionally, SMP’s signature Bezel system and Patch Cord boot combination create multiple levels of keyed access to the network. This break through technology provides enhanced system performance exceeding TIA Category 6a component requirements. Whether your concern is HIPAA, Sarbanes Oxley, Security Clearance or just controlled access to your network, SMP Data Communication’s Limited Axcess™ product line will provide physical control of user access for the network administrator and bandwidth above any copper system available.

• Limited Axcess™ jacks exceed Category 6a

component performance requirements

• Two layers of enhanced security may be deployed

independently, as either the proprietary plugs and jacks or keyed bezels.

• Prohibits unauthorized access.

• Available in 8 different colored keyed bezel and

boot combinations.

• Conversion patch cords are available to connect

standard Ethernet hardware to the Limited Axcess™ network.

• UL listed communications circuit accessory. • Compliant with Power over Ethernet

(PoE) requirements

• Contact material - high strength beryllium copper

alloy Contact plating - 50 µin gold over nickel

AppliCAtioNS

• 10GBASE-T Ethernet

• 1000BASE-T Gigabit Ethernet • 100BASE-TX Fast Ethernet • 10BASE-T Ethernet • Voice

• Broadband Video

• All other applications developed for operation over class E cabling

(6)

limited axcess™ patch cords

catalog number

LAPC6A - m - - xx YY

cable type plug one plug two plug two Boot length in Feet denotes Boot color

s

Shielded Keyed BootK Keyed Plugm Keyed BootK Code ChartSee Color

u

Unshielded Non-keyed BootB 568A Wireda Non-keyed BootB

B

568B Wired Slimline Boots

n

No Boot

limited Axcess™ Jacks

SMP’s patented Limited Axcess™ jacks are the initial component when creating a Limited Axcess secure network. These unique jacks offer an innovative security layer for establishing a physically restrictive network system through keyed configurations and locking keyed bezels. Deployed with the keyed strain relief and plugs found on the Limited Axcess patch cords, the entire system can easily segregate any network segment for physical security. In addition to the security aspect of the Limited Axcess jacks, these RJ45 components exceed TIA Category 6a component performance requirements with a dramatic increase in primary parameter performance.

• Bezels may be applied after installation to lock

jacks in place

• Compliant with Power over Ethernet

(PoE) requirements

• Contact material high strength beryllium copper

alloy; Contact plating – 50 µm gold over nickel

• Available in 8 different colored

keyed bezel combinations

• Shielded keystone version available as well –

call factory for details

limited Axcess™ patch Cords

The Limited Axcess™ patch cord, with its patented plug technology, is a key component to creating a secure Limited Axcess system. This one-of-a-kind patch cord uses a keyed plug and a unique locking boot to provide two layers of physically restrictive network security. Both these layers of enhanced security may be deployed independently as either the proprietary plugs with corresponding jacks or the keyed bezels with matching locking boots. In addition, performance exceeds TIA Category 6a component requirements.

• Locking boot applied during

manufacturing

• Conversion patch cords

available to connect standard Ethernet hardware to the Limited Axcess system

• Available in 8 different colored

keyed boot combinations

• Cable color is gray

Ex: lapc6as-mK-as0309 = Limited Axcess™_{Shielded Patch Cord, Keyed plug}

and boot on one side and A wired with Slimline boot on other side, 3 feet, yellow

limited axcess™ Jacks

catalog number description

LA6Axx Limited Axcess™ Cat 6a RJ45 jack with keyed bezel * Replace “xx” with color code – see color code chart

limited axcess™_{color code chart} code color code color

02 Black 06 Gray

03 Red 07 White

04 Green 08 Orange

(7)

limited axcess™

limited Axcess

™

Secure Faceplates

To create truly limiting admission to secure networks, SMP went one step further in developing the Limited Axcess™ product line and created faceplates that offer an added layer of defense for segregating specific networks. The SMP Secure faceplate is double layered with the outer stainless steel faceplate acting as a locking mechanism, securing the bezels onto the jack and preventing access for removal.

• Stainless steel construction for

corrosion resistance

• Tamper proof screws included

• Minimum ordering quantities may apply

limited Axcess

™

patch panels

From the outlet to the equipment room, SMP’s new keyed copper solution offers physically restrictive access to assist in network segregation. For the communications closet, the Limited Axcess™ system allows network administrators to easily control user connectivity to specific network segments. By using SMP’s 24 port snap-in patch panel and Limited Axcess™ RJ45 jacks, network permissions can be effortlessly managed. Furthermore, Limited Axcess’™ patented technology provides enhanced system performance exceeding Category 6a requirements. This one-of-a-kind system is ideal for applications where restrictive network security is required or for end users looking for superior bandwidth performance.

• 24 port snap in panel

• Limited Axcess™ and color options on page CC-3

limited axcess™ secure Faceplates

LAFP01SS Limited Axcess™ Stainless Steel Secure Faceplate Kit, 1 port

LAFP02SS Limited Axcess™ Stainless Steel Secure Faceplate Kit, 2 port

limited axcess™ patch panels

A24 Limited Axcess™ Snap-In Patch Panel, 24 Port, 2 RU (Jacks not included)

(8)

category 6a solution

For 10 GBASE-t Applications

AppliCAtioNS

• 10GBASE-T Ethernet

• 1000BASE-T Gigabit Ethernet • 100BASE-TX Fast Ethernet • 10BASE-T Ethernet • Broadband Video • 155/622 Mbps ATM • 100 Mbps TP-PMD • 4/16 Mbps Token Ring • Voice

With the number of new 10 Gigabit structured cabling solutions flooding the market, SMP has developed a system that sets the standard for this next generation of technology. SMP created components that are not only guaranteed to surpass the IEEE throughput standards but exceed the elevated frequency response requirements of TIA. This deliberate and methodical approach to component design has led SMP to create superior 10 Gigabit shielded and un-shielded systems. Within these system solutions, SMP has kept one thing constant and that is our commitment to quality. Whether choosing a UTP or FTP 6a solution, customers can be assured that they are getting a connection to count on. SMP's 10 Gig solution reaches beyond the current Category 6 specifications and creates a system that offers enhanced performance and guaranteed 6a connectivity. As a system, the SMP UTP or FTP 6a solution offers superior alien cross-talk performance that exceeds ISO Class E, Augmented Cat 6 and IEEE 10 GBASE-T requirements for a full 100 meters.

• Guaranteed 10 GBASE-T link segment

performance compliant

• 10 GBASE-T 100m Solution

• Backward compatibility (Cat 6, Cat 5e,

and Cat 3 compliant)

• Fully inter-operable with other standards

based components and systems

• Power over Ethernet (PoE) compliant • Twice the bandwidth of Category 6 cabling

(9)

categorY 6a solution

Category 6a patch Cords

To complete the link, SMP created Category 6a station cords that guarantee 6a compliance and offer superior PSANEXT performance suitable for mitigation of alien cross-talk. These station cords also improve the external noise immunity of structured communications cabling systems and EMI suppression through shielded cabling and plug design. Overall, SMP’s Cat 6a patch cords assist in creating a complete 10 Gigabit throughput system that is reliable for years to come.

• Guaranteed Augmented Category 6 compliant • Backward compatible with Category 3, 5, 5e and 6 • Superior PSANEXT performance suitable for

mitigation of alien cross-talk in existing installs

• Superior PSAACR-F performance • Superior EMI suppression

• Improves the external noise immunity of structured

cabling systems

• LS0H or PVC

cable construction

• PVC patch cord

is UL Listed

Category 6a outlet Jacks

SMP’s Augmented Category 6 jack offers a high performance interconnect hardware component in a compact form factor. This RJ45 Slim-line Category 6a jack provides a comprehensive solution for high

performance structured cabling systems. Using patented crosstalk reduction technology and multiple printed circuit boards, SMP engineering has developed its highest performing component product yet. In addition to the performance levels, the small sized form factor of the Slim-line design supports high density applications allowing for 24 ports in a 1U panel for shielded applications.

• Guaranteed Augmented Category 6 compliant • Slim-line profile allows 24 ports in a 1U panel. • IEEE - 10GBASE-T 802.3an clause 55.7 (compliant

to link definition)

• TIA - TSB-155 (Channel compliant) & 568b.2-10

(Component compliant)

• ISO - TR-24750 (Channel compliant)

• Versatile form factor allows implementation in

most vendor faceplates.

• New high performance contacts provide low

crosstalk with improved mechanical robustness.

• Single stuffer cap.

• Terma-grip technology for easy field installation. • Minimized shielding aperture size for reduced

EMI emissions.

• 2 PCB Mezzanine assemblies for low crosstalk

performance in a small form factor.

• Improved strain relief system designed for

Category 6a cable.

• UL listed communications circuit accessory. • Large easy-to-read color code labels.

• Compliant with Power over Ethernet (PoE) requirements. • Contact material - high strength beryllium copper alloy • Contact plating - 50 µin gold over nickel

smp category 6a patch cords

PC6AS-B-xxyy* Category 6a patch cord with boot * Replace “xx” with length in feet; replace “yy” with color choice -06=Data Gray (Standard)

** UL Listed CCA File E137579

Ex: PC6AS-B-0306 = Category 6a patch cord with boot, 3 feet, Gray (Standard)

smp category 6a outlet Jacks

U6Axx Category 6a UMJ outlet jack, UTP - Unshielded

K6Axx Category 6a KMJ outlet jack, UTP - Unshielded, Slim-line K6A02S Category 6a KMJ outlet jack,

FTP - Shielded, Slim-line

* Replace “xx” with color code – see color code chart in Workstation section – KMJ Jacks & Adapters

(10)

Category 6a patch panels

SMP Data Communications’ Category 6a Patch Panels offer a high density solution for guaranteed 10GBASE-T Ethernet applications. Both SMP’s UTP and FTP Cat 6a patch panels present a product solution that exceeds proposed 10Gbit standards by TIA/EIA and promises superior performance compliance. As a 10 Gig compo-nent, the Category 6a patch panel is ideal for end users who are looking for superior network performance to keep their infrastructure lasting well into the future.

• Guaranteed Augmented Category 6 compliant • Backward compatible to Category 3, 5, 5e, and 6 • Offers mounting flexibility and removable cable

strain-relief bar that attaches directly to panel

• All steel construction ensures panel rigidity and

reliable terminations

• Can be easily mounted to any 19” rack or cabinet • High density configuration allows for 24 ports in a

1U rack space

• Write on window plates for port identification • TIA-TSB 155 & 568B.2-10 component compliant • ISO 24750 compliant

• IEEE 802.3an 10GBASE-T link segment

(Clause 55.7) compliant – when installed with approved cable and patch cords

• CSA certified

• Insulation resistance – 500 MΩ minimum

• Dielectric withstand – 1000 VAC RMS, AC 60 Hz

or 1414 VDC P-P

• DC current rating – 1.5 A per conductor at 20° C

ambient de-rated to 0.75 A at 60° C ambient

smp category 6a patch panels

AAXG6A16-UTP Category 6a 10 Gig UTP Patch Panel, UMJ style, 1 RU, 16 port

AKXG6A16-UTP Category 6a 10 Gig UTP Patch Panel, KMJ style, 1 RU, 16 port

AKXG6A16-FTP Category 6a 10 Gig FTP Patch Panel, Shielded KMJ style, 1 RU, 16 port AKXG6A24-FTP Category 6a 10 Gig FTP High Density Patch

Panel, Shielded KMJ style, 1 RU, 24 Port AKXG6A32-FTP Category 6a 10 Gig FTP Patch Panel,

Shielded KMJ style, 2 RU, 32 Port AKXG6A48-FTP Category 6a 10 Gig FTP Patch Panel,

(11)

patch panels

Category 6

When Category 6 was introduced to the market, SMP brought a product offering that was designed to exceed industry expectations and surpass the governing standards. SMP created Category 6 connectivity components that offered patented technology and guaranteed bandwidth performance. SMP’s Category 6 patch panels were no exception. Developed to offer true performance, SMP’s Category 6 patch panels are assured to meet the standard when verified.

• Category 6 component compliant • 610 punch down block

• ETL Verified to TIA/EIA 568-B.2-1 Cat 6 • Power-Safe modular jack contacts • SMP patented PCB technology • Backward compatible, Cat 3, 5, & 5e • Mounting flexibility

• Removable cable strain-relief bar attaches

directly to Panel

• All steel panel (no plastic frames) ensures panel

rigidity and reliable terminations

• IKON compatible - 12 colors

• Universal T568A/B wiring for easy installation • 6 Port component modules

• Write-on label fields

• Rigid Box-Section panel construction • Long term application confidence

• Compliant with power over Ethernet requirement • All components made in the U.S.

applications

• TIA/EIA 854 Gigabit

Ethernet over Cat 6 Cabling

• 1000BASE-T Gigabit Ethernet • 100BASE-TX Fast Ethernet • 10BASE-T Ethernet • Broadband Video • 270 Mbps digital video • 155/622 Mbps ATM • 100 Mbps TP-PMD • 100 VG-AnyLan • 4 / 16 Mbps Token Ring • Voice

axcess 6™ patch panels

PP12SIX Wall Mount Patch Panel, 568A/B wired, 12 port, 89D Bracket

PP1288/110A6 Wall Mount Patch Panel, 568A/B wired, 12 port PP2488/110A6 Wall Mount Patch Panel, 568A/B wired, 24 port DCC1288/110SIX Rack Mount Patch Panel, 568A/B wired, 12 port, 1 RU DCC1688/110SIX Rack Mount Patch Panel, 568A/B wired, 16 port, 1 RU DCC2488/110SIX Rack Mount Patch Panel, 568A/B wired, 24 port, 1 RU DCC3288/110SIX Rack Mount Patch Panel, 568A/B wired, 32 port, 2 RU DCC4888/110SIX Rack Mount Patch Panel, 568A/B wired, 48 port, 2 RU DCC6488/110SIX Rack Mount Patch Panel, 568A/B wired, 64 port, 4 RU DCC9688/110SIX Rack Mount Patch Panel, 568A/B wired, 96 port, 4 RU DCC12088/110SIX Rack Mount Patch Panel, 568A/B wired, 120 port, 5 RU DCC1688/110SIX-S Rack Mount Patch Panel, 16 Port, KMJ Shielded

Jacks, 1 RU

DCC2488/110SIX-S Rack Mount Patch Panel, 24 Port, KMJ Shielded Jacks, 2 RU

ACC2488/110SIX Rack Mount Patch Panel, Angled, 568A/B wired, 24 port, 1 RU

ACC4888/110SIX Rack Mount Patch Panel, Angled, 568A/B wired, 48 port, 2 RU

(12)

Category 5e -110 Style

SMP’s Category 5e patch panels incorporate SMP’s best design and application performance specifications ever. The A5E™ product line provides unmatched performance in premise connectivity. Designed for the most demanding network applications, SMP created Category 5e patch panels that offer customers the highest level of headroom to any Category 5e link or channel.

• Comfortably exceeds EIA/TIA 568-B.2

Category 5e standards

• ISO/IEC11801 compliant • Patented PC Board Technology

• Constructed of cold rolled steel for durability • Rigid design provides solid frame for hi-impact

punching tools

• Universal TIA 568A/B wiring configuration • IDC’s withstand 200 wire insertions • Write on label fields

• IKON compatible – 12 colors • Cable strain relief bar provided • All components made in U.S.

applications

• 1000BASE-T Gigabit Ethernet • 100BASE-TX Fast Ethernet • 10BASE-T Ethernet • Broadband video • 270 Mbps digital video • 155 / 622 Mbps ATM • 100 Mbps TP-PMD • 100 VG AnyLan • 4 / 16 Mbps Token Ring • Voice

a5e™ patch panels

PP12A5E Wall Mount Patch Panel, 568A/B wired, 12 port, with 89D bracket

PP1288/110A5E Wall Mount Patch Panel, 568A/B wired, 12 port PP2488/110A5E Wall Mount Patch Panel, 568A/B wired, 24 port DCC1288/110A5E Rack Mount Patch Panel, 568A/B wired,

12 port, 1 RU

DCC1688/110A5E Rack Mount Patch Panel, 568A/B wired, 16 port, 1 RU

ACC2488/110A5E Rack Mount Patch Panel, Angled, 568A/B wired, 24 port, 1 RU ACC4888/110A5E Rack Mount Patch Panel, Angled,

(13)

patch panels

Category 5e - Shielded 110 Style

SMP’s shielded Category 5e patch panels provide superior performance with an extra sense of security. A removable cover protects against external noise and wireless technologies while also offering easy access for termination. Just like all A5E™ patch panels by SMP, performance is designed to exceed EIA/TIA 568-B.2 Category 5e standards.

• Comfortably exceeds EIA/TIA 568-B.2

Category 5e standards

• ISO/IEC11801 compliant • Fully shielded RJ45 jacks • Patented PC Board Technology • Rigid design provides solid frame for

hi-impact punching tools

• 110 Style punch down for easy terminations • IDC’s withstand 200 wire insertions • Write on label fields

• IKON compatible – 12 colors

• Removable cable strain-relief bar attaches

directly to Panel

• Removable cover for protection from EMI

and RFI emissions

• All components made in U.S.

Voice Grade telco

The same cross-connect solutions available for Ethernet applications are also available for PBX equipment. For these applications, SMP offers Voice Grade Telco Patch Panels which break out to 24-RJ45 jacks. Customers can easily patch their phone system into the permanent link by simply using patch cords and open ended cable assemblies punched down to a 110 block, 66-block, or 110 patch panel.

• Patented PC Board Technology

• Constructed of extruded aircraft grade aluminum • 25 Pair Telco connectors allow for quick connects

and easy installations

• Write on label fields • IKON compatible – 12 colors • All components made in U.S.

applications

• 1000BASE-T Gigabit Ethernet • 100BASE-TX Fast Ethernet • 10BASE-T Ethernet • Broadband video • 270 Mbps digital video • 155 / 622 Mbps ATM • 100 Mbps TP-PMD • 100 VG AnyLan • 4 / 16 Mbps Token Ring • Voice

a5e™ shielded patch panels catalog number description

DCC1688/110S01 Rack Mount Patch Panel, Shielded 110-style, 568B wired, 8 port modules, 16 port, 1 RU DCC1688/110S03 Rack Mount Patch Panel, Shielded 110-style,

568A wired, 8 port modules, 16 port, 1 RU DCC2488/110SAB Rack Mount Patch Panel, Shielded, 110 style,

568A/B wired, 8 port modules, 24 Port, 1 RU DCC2488/110S6-01 Rack Mount Patch Panel, Shielded 110-style,

568B wired, 6 port modules, 24 port, 1 RU

Voice grade telco patch panels

DCC2462/2502 Rack Mount Patch Panel, Telco Interface panel, 6x2, USOC, 24 Port

(14)

Gigabit Ethernet telco

High speed data connections are essential for keeping pace with today’s business climate. SMP took this into consideration when developing patch panels that offered 1000BASE-T Gigabit Ethernet performance. Not only does the performance exceed industry standards, SMP’s Gigabit Ethernet Patch Panels are 100% component tested in the factory guaranteeing the customer worry-free installations.

• Exceeds EIA/TIA 568-B.2 specifications • ISO/IEC11801 compliant

• Patented PC Board Technology • All steel construction for durability • All plastic components are high impact

self-extinguishing, rated 94V-0

• Each female Telco connector is split out to 6 RJ45 ports wired for 1000BASE-T applications • Fast and easy installations

• Write on label fields • IKON compatible – 12 colors

• Fully adjustable cable management support bar and bend radius requirements

• All components made in U.S.

applications

• 1000BASE-T Gigabit Ethernet • 100BASE-TX Fast Ethernet • 10BASE-T Ethernet • Broadband video • 155 / 622 Mbps ATM • 100 Mbps TP-PMD • 100 VG Any LAN • 4 / 16 Mbps Token Ring • Voice

gigabit ethernet patch panels

PP1288/25V03 Wall Mount Patch Panel, Gigabit Telco, 568A wired, 12 Port

PP1288/25V01 Wall Mount Patch Panel, Gigabit Telco, 568B wired, 12 Port

PP2488/25V03 Wall Mount Patch Panel, Gigabit Telco, 568A wired, 24 Port

PP2488/25V01 Wall Mount Patch Panel, Gigabit Telco, 568B wired, 24 Port

DCC24A/GBASET21 Rack Mount Patch Panel, Gigabit Telco, 568A wired, 24 Port with cover

DCC24B/GBASET21 Rack Mount Patch Panel, Gigabit Telco, 568B wired, 24 Port with cover

DCC48A/GBASET21 Rack Mount Patch Panel, Gigabit Telco, 568A wired, 48 Port with cover

DCC48B/GBASET21 Rack Mount Patch Panel, Gigabit Telco, 568B wired, 48 Port with cover

DCC2488/25S-01 Rack Mount Patch Panel, Shielded Gigabit Telco, 568B wired, 24 Port with cover ACC2488/25V01 Rack Mount Patch Panel, Angled,

Gigabit Telco, 568B wired, 24 port, 1 RU ACC4888/25V01 Rack Mount Patch Panel, Angled,

(15)

patch panels

Fast Ethernet telco

SMP was one of the first developers of Category 5e compliant 100BASE-T Patch Panels that support advanced high-density Telco ports. Each female 25-pair Telco connector is split out to 12-RJ45 ports wired for 100BASE-T applications for fast and easy installations. Developed initially for use with Cisco switches, SMP’s Fast Ethernet Telco patch panels offer customers a single source solution that guarantees unrivaled 100BASE-T performance.

• Patented PC Board Technology • All steel construction for durability • All plastic components are high impact

self-extinguishing, rated 94V-0

• Each female Telco connector is split out to 12 RJ45 ports wired for 100BASE-TX applications • Fast and easy installations

• Write on label fields • IKON compatible – 12 colors

• Removable cable strain-relief bar attaches directly to Panel

• Also available in shielded version • All components made in U.S.

applications

• 100BASE-TX Fast Ethernet • 10BASE-T Ethernet • Broadband video • 270 Mbps digital video • 155 / 622 Mbps ATM • 100 Mbps TP-PMD • 100 VG Any LAN • 4 / 16 Mbps Token Ring • Voice

Fast ethernet patch panels

PP2484/25VEFS100 Wall Mount Patch Panel, Telco, 24 Port DCC2484/25V100 Rack Mount Patch Panel, Telco, 24 Port, 2 RU DCC3684/25V100 Rack Mount Patch Panel, Telco, 36 Port, 2 RU DCC4884/25V100 Rack Mount Patch Panel, Telco, 48 Port, 2 RU DCC9684/25V100 Rack Mount Patch Panel, Telco, 96 Port, 4 RU DCC4884/25S-100 Rack Mount Patch Panel, Shielded Telco,

48 Port, 2 RU

(16)

patch panel Accessories

SMP’s IKON kits color code patch panels for easy labeling and to meet EIA/TIA 606 port identification requirements. IKON kits may be used to dress up any A5E™ or Axcess 6™ patch panel. Snap-In Multi-media panels and all kits include enough IKONS to color every port with any 9 colors.

EIA/TIA color coding – SMP color code: • Key Telephone Systems Red – 03 • Network Communications Green – 04 • Station Blue – 05

• Second Level Backbone Gray – 06 • First Level Backbone White – 07 • Demarcation Point Orange – 08 • Miscellaneous Yellow – 09 • Common Equipment Purple – 10 • Inter-building Backbone Brown – 11

Snap in Multi – Media panels

The ability to be flexible and adaptable to each customer’s unique needs has been SMP’s speciality for years. With SMP’s Snap-In Multi-media patch panels, any combination of UMJ or KMJ style jacks and adapters can be chosen to configure a custom patch panel. All Multi-media patch panels are mountable in any 19” rack.

• Ports will accommodate any UMJ or KMJ jack or adapter

• Constructed of extruded aircraft grade aluminum for durability • Write on label fields

• IKON compatible – 12 colors

axcess™ snap-in multi-media patch panels

A16 Rack Mount Empty Patch Panel, UMJ style, 16 Port, 1 RU A24 Rack Mount Empty Patch Panel, UMJ style, 24 Port, 2 RU A32 Rack Mount Empty Patch Panel, UMJ style, 32 Port, 2 RU A48H Rack Mount Empty Patch Panel, UMJ style, 48 Port, High Density 2

RU

A48 Rack Mount Empty Patch Panel, UMJ style, 48 Port, 4 RU ACC24U Rack Mount Empty Patch Panel, Angled, UMJ style, 24 port, 1 RU ACC48U Rack Mount Empty Patch Panel, Angled, UMJ style, 48 port, 2 RU AK16 Rack Mount Empty Patch Panel, KMJ style, 16 Port, 1 RU AK24 Rack Mount Empty Patch Panel, KMJ style, 24 Port, 1 RU

AK48H Rack Mount Empty Patch Panel, KMJ style, 48 Port, High Density 2 RU AK481U Rack Mount Empty Patch Panel, KMJ Style, 48 port, 1RU

AK16STP Rack Mount Empty Patch Panel, KMJ style, Shielded, 16 Port, 1 RU AK24STP Rack Mount Empty Patch Panel, KMJ style, Shielded, 24 Port, 1 RU AK48STP Rack Mount Empty Patch Panel, KMJ style, Shielded, 48 Port, 3 RU ACC24K Rack Mount Empty Patch Panel, Angled, KMJ style, 24 port, 1 RU ACC24KS Rack Mount Empty Patch Panel, Angled, KMJ style, Shielded, 24

port, 1 RU

ACC48K Rack Mount Empty Patch Panel, Angled, KMJ style, 48 port, 2 RU ACC48KS Rack Mount Empty Patch Panel, Angled, KMJ style, Shielded, 48

port, 2 RU

iKon Kits

IKON1U IKON Kit for 10-24 Ports, 9 color assortment IKON2U IKON Kit for 32-48 Ports, 9 color assortment IKON3U IKON Kit for 64-96 Ports, 9 color assortment IKON5U IKON Kit for up to 120 Ports, 9 color assortment IKONxx IKON Kit, Pack of 100 6-port strips

(17)

Zone distriBution solutions

Zone

distribution

solutions

Zone Cross Connect

SMP’s zone distribution solutions optimize any horizontal cabling infrastructure. Through innovative designs, SMP continues to provide zone cross connect solutions that meet every need. Whether using SMP’s 6-Port

Interconnect Module or the new “Spider” Zone Module, the convenience and reliability of SMP technology guarantees performance for high speed applications.

25-pair Zone distribution cable assemblies

25Zd/ - 25-pair Zone distribution cable assembly

cable type & category Wiring type end type length in Feet

5e

Cat 5e Riser 568A wired6a

tr

Telco Right

ep

Cat 5e Plenum 568B wired6B

tl

Telco Left

ts

Telco Straight

x

Blunt End – No Connector

hr Hydra Right hl Hydra Left hsxx* Hydra Straight *Replace “xx” with length

of legs (12 or 24)

Zone interconnect modules (Field terminable)

ZDIMA5E Zone Interconnect Module, Category 5e, 568A/B wired, 6 port (pictured above) ZDIMSIX6A/B Zone Interconnect Module, Category 6,

568A/B wired, 6 port (not pictured, mounts to an 89D bracket)

Ex: 25ZD/5E6BTS-100 = 25 Pair Cable Assembly, Zone Distribution module to Telco Straight, Cat 5e Riser, 568B wired, 100 Feet

applications

• 1000BASE-T Gigabit Ethernet • 100BASE-TX Fast Ethernet • 10BASE-T Ethernet • Broadband Video • 155 / 622 Mbps ATM • 100 Mbps TP-PMD • 4 / 16 Mbps Token Ring • Voice

SMP’s Interconnect Module offers the ease and compact design to give customers an alternative to multiple outlets in an office environment. The 6 port module allows for termination between 25-Pair cables to modular RJ45 ports at the workstation, minimizing the need for multiple horizontal cable runs.

• Universal 568A/B wiring

• Compact design allows for easy installation • Ideal in multiple situations, i.e. under floor,

power pole, and multi-port workstations • May be factory assembled with cable or

field terminated.

• All components made in the U.S.

(18)

Zone Distribution Box

Perfect for serving multiple remote outlets, SMP’s Zone Distribution Box provides an easy connection between a 25-pair cable and six modular ports. Each box is constructed with one female Telco connector and 6-RJ45 jacks, 3 on each side. With its compact design, the Zone Distribution Box can easily be used as a wall mountable mini patch panel for increased cost effectiveness.

• Available in 568A or 568B wired applications • Patented PC Board technology

• Ideal for multiple situations, i.e. under floor, ceiling, and multi-port workstations • Mounts anywhere

Zone Distribution Jack packs

Created for completely modular connections, the SMP Jack Pack is ideal for any zone distribution application and can easily be mounted anywhere. With performance that exceeds all standards requirements, the Jack Pack offers a multitude of application solutions. Whether mounting to cable tray for a quick cross connect point or using as a distribution site within an equipment room, the SMP Jack Pack offers guaranteed performance in a compact package.

• Available for 10/100 or Gigabit Ethernet applications

• Exceeds EIA/TIA 568A specifications • Patented PC Board Technology • Compact design

• Mounts anywhere • Also available in shielded • All components made in the U.S.

applications

Zone distribution Box

ZDB6VA01 Zone Distribution Box, 568A wired, 6 Port ZDB6VB01 Zone Distribution Box, 568B wired, 6 Port

Zone distribution Jack packs

ZDIM81225TX Zone Distribution Jack Pack, 10/100 RJ45 to Female Telco, 568B wired, 12 Port

ZDIM8625A Zone Distribution Jack Pack, Gigabit RJ45 to Female Telco, 568A wired, 6 port

ZDIM8625B Zone Distribution Jack Pack, Gigabit RJ45 to Female Telco, 568B wired, 6 Port

ZDIM8625BS Zone Distribution Jack Pack, Gigabit Shielded RJ45 to Female Telco, 568B wired, 6 Port

(19)

Zone distriBution solutions

Zone “Spider” Distribution Solutions (for cable tray)

SMP’s new Zone “Spider” Distribution Solutions for

cable tray mounting provide a convenient means to access copper network cross connect points. The copper modules are manufactured with Telco PCB assemblies factory installed for fast and easy installations. Simply insert the Telco cable assembly and patch cords and the job is finished. These modules allow customers to take the distribution point out of the equipment room to where it’s needed, while giving installers less installation time and a reduction in cabling costs.

• Available for 10/100 or Gigabit Ethernet applications

• Patented PC Board Technology • Expandable design will fit tray widths

from 12" to 18"

• Easy installations and additions without disturbing previously installed cable

• Reduces the number of cables and congestion in a cable tray

applications

• 1000BASE-T Gigabit Ethernet (only on Gigabit Ethernet module) • 100BASE-TX Fast Ethernet • 10BASE-T Ethernet • Broadband Video • 155 / 622 Mbps ATM • 100 Mbps TP-PMD • 4 / 16 Mbps Token Ring • Voice

Zone “spider” distribution solution (for cable tray)

ZDMB12/25V100 Zone Distribution Module, 10/100 Telco, 12 Port

ZDMB12A/GBASET21 Zone Distribution Module, Gigabit Telco, 568A wired, 12 Port

ZDMB12B/GBASET21 Zone Distribution Module, Gigabit Telco, 568B wired, 12 Port

(20)

cable assemblies

As the industry demands systems with faster installation times and less network interruption, SMP developed a modular solution to meet those specific communications cabling needs. Using 25-pair Telco cable assemblies coupled with SMP Telco patch panels, SMP created a solution that is as simple as Plug-and-Play. SMP’s 25-pair

Telco cable assemblies make moves/adds/ changes more flexible, air passages less restricted and data throughput rates uninterrupted. Each 25-pair assembly is designed to support new interface

technology of leading switch manufacturers. Constructed to exceed EIA/TIA Category 5e specifications, SMP’s Telco assemblies offer guaranteed Gigabit throughput with 100% component testing to their specified protocols. From rack mount to zone distribution, SMP’s PowerSum-Rated 5e assemblies offer a wide variety of options to meet 10/100 and Gigabit Ethernet solutions.

• Exceeds EIA/TIA Category 5e specifications • Utilizes UL certified Cat 5e 25-pair cable

• 100% component testing for guaranteed Gigabit Ethernet performance

• All Telco to Telco assemblies are male-to-male • All Hydra assemblies are manufactured with

precise leg measurements to span 19” racks or a stand alone switch

• Works with high-density 48 port blades • 50-pin Telco connectors available in 120° or

180° angles

• Available with right, left, or straight connectors – plenum or non-plenum

• Shielded 25-pair cable assemblies also available

applications

• 1000BASE-T Gigabit Ethernet • 100BASE-TX Fast Ethernet • 10BASE-T Ethernet • Broadband Video • 155 Mbps ATM • 100 Mbps TP-PMD • 100 VG AnyLAN • 4/16 Mbps Token Ring • Voice

telco to telco Cable Assemblies

25-pair telco to telco cable assemblies

25PA/ - - - 25-Pair Telco to Telco Cable Assembly

end type end type cable type & _category length in Feet

TR Telco Right TR Telco Right 5E Cat 5e Riser TL Telco Left TL Telco Left EP Cat 5e Plenum TS Telco Straight TS Telco Straight X Blunt End – No Connector

Ex: 25PA/TR-TR-5E-100 = 25 Pair Cable Assembly with Telco Right to Telco Right, Cat 5e Riser, 100 Feet

(21)

caBle assemBlies

Hydra Cable Assemblies:

Ex: 25PA/TRHS1265E-025 = 25 Pair Cable Assembly with Telco Right to Gigabit Hydra Straight, 6 Legs at 12", Cat 5e Riser, 25 Feet

* Must use B-wired Telco panel with 6 Leg Gigabit Hydra Assemblies

Ex: 25PA/TRHS24-5E-050 = 25 Pair Cable Assembly with Telco Right to 10/100 Hydra Straight, 12 Legs at 24", Cat 5e Riser, 50 Feet

25-pair telco to gigabit hydra cable assemblies (6 legs)

25PA/ 6 - 25-Pair Telco to Hydra Cable Assembly

end type end type cable type & _category length in _Feet

tr Telco Right hr Hydra Right 5e Cat 5e Riser tl Telco Left hl Hydra Left ep Cat 5e Plenum ts Telco Straight hsxx* Hydra Straight x Blunt End - No Connector *Replace “xx” with length of legs (12 or 24)

25-pair telco to 10/100 hydra cable assemblies (12 legs)

25PA/ - - 25-Pair Telco to Hydra Cable Assembly

end type end type cable type & _category length in _Feet

tr Telco Right hr Hydra Right 5e Cat 5e Riser tl Telco Left hl Hydra Left ep Cat 5e Plenum ts Telco Straight hsxx* Hydra Straight x Blunt End - No Connector *Replace “xx” with length of legs (12 or 24) copper closet cc-18

(22)

Category 5e patch Cords

SMP’s Category 5e patch cords are manufactured to strict standards, ensuring adherence to TIA/EIA 568-B.2 component performance

requirements. After all, SMP’s test methods for patch cord component testing methods have helped form the basis for the Category 5e standards. This commitment to guaranteed performance is what makes SMP’s A5E patch cords an excellent addition to any SMP Category 5e structured cabling system

• 100% component performance tested

• Exceeds TIA/EIA 568-B.2 Category 5e requirements • Customizable lengths and colors available

Category 6 patch Cords

SMP’s Category 6 patch and workstation cords are the perfect compliment to any SMP Axcess 6™ copper system. SMP’s Axcess 6 cords offer Onyx Grip, a strain relief solution that ensures mechanical and electrical stability during and after adds, moves or changes. In addition, Axcess 6 patch cords utilize straight-thru pair orientation and are 100% component performance tested. SMP’s test methods have formed the basis for standard patch cord component testing methods in TIA/EIA 568-B.2 -1 Category 6 standards ensuring that the Axcess 6 patch cord will guarantee performance.

• 100% component performance tested • Exceeds TIA/EIA 568B.2-1 specifications • Customizable lengths and colors available • Shielded version available

applications

• 1000BASE-T Gigabit Ethernet • 100BASE-TX Fast Ethernet • 10BASE-T Ethernet • Broadband Video • 155/622 Mbps ATM • 100 Mbps TP-PMD • 4/16 Mbps Token Ring • Voice

• All applications developed for operation over Category 6 or class E cabling

applications

• 1000BASE-T Gigabit Ethernet • 100BASE-TX Fast Ethernet • 10BASE-T Ethernet • Broadband Video • 155/622 Mbps ATM • 100 Mbps TP-PMD • 4/16 Mbps Token Ring • Voice • All applications developed for operation over Category 5e or class D cabling

axcess 6™ patch cords catalog number description

PCSIXxxyy Category 6 patch cord without boot PCSIXxxByy Category 6 patch cord with boot PCSIXSxxByy Category 6 shielded patch cord with boot *Replace xx with length in feet; replace yy with color code – (06) gray, (09) yellow

** Ex: = PCSIX03B09 – Category 6 patch cord, 3 feet, with boot, yellow

a5e™ patch cords

PC5EBxxyy Category 5e patch cord without boot PC5EBxxByy Category 5e patch cord with boot *Replace xx with length in feet; replace yy with color code – (06) gray, (09) yellow

** Ex: = PC5EB03B09 – Category 5e patch cord, 3 feet, with boot, yellow

(23)

110 Wiring products

Whether installing a Category 5e or Category 6 system, SMP offers a complete solution with 110 Block

connectivity. SMP’s 110 product line offers easy network cabling consolidation and quick transitions with

maximum performance. From wall mount to rack mount 110 blocks and cable organizers, SMP’s selection of products offer customers a solid backbone for an exceptional structured wiring solution.

• Exceeds industry standards for Category 5e and Category 6 specifications, respectively • 110 Blocks may be field terminated with

22-26 AWG solid wire

• Color coded pairs for easy identification • Designation labels included

• Order with legs when back case routing • Order without legs when depth is limited or

when frame mounting

• 110 Block may be kitted for easy installations

applications

• 1000BASE-T Gigabit Ethernet • 100BASE-TX Fast Ethernet • 10BASE-T Ethernet • Broadband Video • 155/622/1000 Mbps ATM • 100 Mbps TP-PMD • 100 VG AnyLAN • 4/16 Mbps Token Ring • Voice copper closet cc-20

(24)

Category 5e 110 Wiring products

Category 6 110 Wiring products

Cable organizers

category 5e 110 Wiring products

C410 Category 5e 110 C-4 Connector Blocks C510 Category 5e 110 C-5 Connector Blocks DCC50/110EFS* Category 5e Wall Mount 110 Block, 50 Pair,

Without Legs

DCC50/110EFSL* Category 5e Wall Mount 110 Block, 50 Pair, With Legs

DCC100/110EFS* Category 5e Wall Mount 110 Block, 100 Pair, Without Legs

DCC300/110EFS* Category 5e Wall Mount 110 Block, 300 Pair, Without Legs

DCC300/110EFSTWB Category 5e Wall Mount 110 Tower, 300 Pair, Mounting Frame

DCC300/110EFSTEXP Category 5e Wall Mount 110 Tower, 300 Pair, Extension Mounting Frame

DCC100/110EFSRK Category 5e Rack Mount 110 Block, Kitted 100 Pair

*Place a “K” at the end of the part number for a complete kit. Ex: DCC48/110EFSLK = Category 5e Wall Mount 110 Block with Legs and Connectors

category 6 110 Wiring products

C64-10 Category 6 110 C-4 Connector Blocks DCC48/110SIX* Category 6 Wall Mount 110 Block, 48 Pair,

Without Legs

DCC48/110SIXL* Category 6 Wall Mount 110 Block, 48 Pair, With Legs

DCC96/110SIX* Category 6 Wall Mount 110 Block, 96 Pair, Without Legs

DCC288/110SIX* Category 6 Wall Mount 110 Block, 288 Pair, Without Legs

DCC288/110SIXTWB Category 6 Wall Mount 110 Tower, 288 Pair, Mounting Frame

DCC288/110SIXTEXP Category 6 Wall Mount 110 Tower, 288 Pair, Extension Mounting Frame

DCC96/110SIXRK Category 6 Rack Mount 110 Block, Kitted 96 Pair

*Place a “K” at the end of the part number for a complete kit. Ex: DCC48/110SIXLK = Category 6 Wall Mount 110 Block with Legs and Connectors

110 Block cable organizers

COH110 Wall Mount Horizontal Cable Organizer without Legs

COH110L Wall Mount Horizontal Cable Organizer with Legs

DCC300/110EFSTHVCM Wall Mount Vertical Cable Organizer, For 110 Tower

DCC300/110EFSTVCM Wall Mount Vertical Cable Organizer Extension, For 110 Tower

COH110R Rack Mount Horizontal Cable Organizer, 19" Width

(25)

(26)

created a complete line of connectivity components to take

guaranteed SMP performance from the equipment room to

the desktop. As with all SMP products, performance is always

the priority. Every SMP jack, whether our proprietary Bezel

design or the standard Keystone version, are 100% tested to

stringent performance standards and all are completely

backward compatible to lower category performance levels.

This attention to detail makes SMP’s jacks and outlet solutions

a clear answer to constructing the perfect structured cabling

system, from telecom room to the desk.

SMP’s workstation product line features a broad range of

quality modular products to meet any structured cabling

application. In addition to delivering unsurpassed performance

and patented SMP technology, SMP’s workstation solutions

provide customers a durable aesthetic appeal to fit any

desktop scenario. And in order to fit any setting, our

workstation products offer the widest ranges of jacks,

adapters, faceplates, surface-mount boxes, and station cords

in a variety of colors and styles. Whether using SMP’s unique

Universal Modular (Bezel) components or the industry standard

Keystone Modular design, SMP has the workstation solution

that will give customers exceptional performance and flexibility

to meet any desktop configuration.

Ws-2

UMJ Jacks and

Adapters

Ws-6

UMJ Faceplates

Ws-10

KMJ Jacks and

Adapters

Ws-14

KMJ Faceplates

Ws-17

Wall plates and

Connectors

Ws-18

Surface Mount

Boxes

(27)

umJ JacKs and adapters

umJ Jacks

and adapters

SMP’s Universal Modular Jack offers a unique locking bezel system that allows for easy port identification and labeling at the work center. This jack and bezel combination create a superior hold on the faceplate or box, making it virtually impossible to accidentally remove the jack. More than the aesthetic appeal and convenience the UMJ jack offers, it is designed to support emerging high performance platforms that exceed category specifications.

Category 6a outlet Jacks

(See Copper Closet, page CC-6)

Category 6 Jacks

SMP’s Axcess 6™_{jacks are world-class performers with}

patented printed circuit board technology to provide true Category 6 component performance on all pair combinations. With a standard 110 style punch down termination, SMP’s Category 6 UMJ style jacks are manufactured to comply with TIA component performance requirements and are ETL Verified to TIA/EIA 568-B.2-1 Cat 6 standards. Each UMJ Cat 6 jack utilizes universal T568A/B wiring and is backward compatible with Category 3, 5, and 5e.

• Meets IEC 60603-7 requirements • 110 style IDC contacts meet

TIA/EIA 568-B.2 requirements

• ETL Verified to TIA/EIA 568-B.2-1 Cat 6

• Backward compatible, Cat 3, 5, and 5e compliant • Full 6-position, modular plug compatible with bezel • Universal T568A/B wiring for easy installation • TERMA Grip conductor & jacket retention for

easy wiring

• Available with 20 labeling and color options • Secure mounting locks jack into faceplate • Fits all SMP Axcess™ faceplates and surface

mount boxes

applications

• TIA/EIA 854 Gigabit Ethernet over Cat 6 Cabling

• 1000BASE-T Gigabit Ethernet • 100BASE-TX Fast Ethernet • 10BASE-T Ethernet • Broadband Video • 270 Mbps digital video • 155/622 Mbps ATM • 100 Mbps TP-PMD • 100 VG-AnyLan • 4/16 Mbps Token Ring • Voice

axcess 6™ umJ Jacks catalog number description

UMJA6 Axcess 6™_{UMJ Category 6 Jack,}

Universal 568A/B wiring, no bezel UMJA6xx Axcess 6™_{UMJ Category 6 Jack,}

Universal 568A/B wiring, colored bezel UMJA650xx Axcess 6™_{UMJ Category 6 Jack,}

Universal 568A/B wiring, 50 pack

* Replace “xx” with color code – see color code chart on page WS-5

(28)

Category 5e Jacks

SMP’s Axcess™ Category 5e Bezel jacks utilize SMP’s patented PC Board technology to exceed the ANSI/TIA/ EIA 568-B.2 category 5e requirements with headroom to spare. For a more cost effective solution, SMP also offers a Leadframe Bezel jack that utilizes SMP’s

patented Leadframe technology. 110 style punch downs accommo-date 22 AWG solid through 26 AWG solid and 24 AWG stranded conductors and each SMP jack offers universal T568A/B wiring and performance enhancements to exceed industry standards. • 110 style IDC contacts meet

TIA/EIA 568-B.2 requirements

• Backward compatible, Cat 3, and Cat 5 compliant • Full 6-position, modular plug compatible with bezel • Universal T568A/B wiring for easy installation • TERMA Grip conductor & jacket retention

for easy wiring

• Available with 20 labeling and color options • Secure mounting locks jack into faceplate • Fits all SMP Axcess™ faceplates and surface

mount boxes

Category 3 Voice Grade Jacks

SMP’s Category 3 Jacks offer customers SMP’s patented Leadframe technology for a cost effective solution to voice grade systems. 110 style IDC connectors on back for 26, 24, and 22 AWG solid conductors, make SMP’s Category 3 jacks easy to install and offer unmatched

performance. Add the locking color/ icon bezel to provide distinctive jack identification. • 110 style IDC contacts

• TERMA Grip conductor & jacket retention for easy wiring

• Available with 20 labeling and color options

• Secure mounting locks jack into faceplate • Fits all SMP Axcess™ faceplates and surface

mount boxes

applications

a5e™ umJ Jacks

UMJA5E A5E™ UMJ Category 5e Jack, Universal 568A/B wiring, no bezel

UMJA5Exx A5E™ UMJ Category 5e Jack, Universal 568A/B wiring, colored bezel

UMJA5E50xx A5E™ UMJ Category 5e Jack, Universal 568A/B wiring, 50 pack

UMJVL8A/B A5E™ UMJ Category 5e Leadframe Jack, Universal 568A/B wiring, no bezel UMJVL8A/Bxx A5E™ UMJ Category 5e Leadframe Jack,

Universal 568A/B wiring, colored bezel UMJVL8A/B50xx A5E™ UMJ Category 5e Leadframe Jack,

Universal 568A/B wiring, 50 pack

axcess™ umJ category 3 Jacks

UMJL06U Axcess™ Jack USOC 6x6 Leadframe, 110 style, no bezel

UMJL06Uxx Axcess™ Jack USOC 6x6 Leadframe, 110 style, colored bezel

UMJL08U Axcess™ Jack USOC 8x8 Leadframe, 110 style, no bezel

UMJL08Uxx Axcess™ Jack USOC 8x8 Leadframe, 110 style, colored bezel

UMJL08A/B Axcess™ Jack 568A/B, 8x8 Leadframe, 110 style, no bezel

UMJL08A/Bxx Axcess™ Jack 568A/B, 8x8 Leadframe, 110 style, colored bezel

(29)

umJ JacKs and adapters

UMJ Adapters

For multi-media options, SMP created a complete line of data, video, and audio ports for fiber, copper, coaxial and speaker cables. Combined with the multi-color, low-profile recessed Bezels, SMP’s UMJ style adapters are a flexible alternative for port identification, no matter what the application.

• Available with 12 color options

• Secure mounting locks adapters into faceplate • Fits all SMP Axcess™ faceplates and surface

mount boxes APBLK01 AASTM01 AASCM01 AARCA01 AABNC01 AAF01

axcess™ umJ adapters catalog number description

AASCMxx Axcess™ UMJ snap-in SC Multi-mode adapter AASCSxx Axcess™ UMJ snap-in SC Single-mode adapter AASTMxx Axcess™ UMJ snap-in ST Multi-mode adapter AASTSxx Axcess™ UMJ snap-in ST Single-mode adapter AADLCMxx Axcess™ UMJ snap-in Dual LC Multi-mode

adapter

AAFxx Axcess™ UMJ snap-in F coupler AABNCxx Axcess™ UMJ snap-in BNC coupler AASVHSxx Axcess™ UMJ snap-in Super VHS coupler AARCAxx Axcess™ UMJ snap-in RCA adapter with

solder tab

APBLKxx Axcess™ UMJ snap-in Blank Bezel (20 pack) * Replace “xx” with color code – see color code chart on page WS-5

(30)

Bezels

Whether ordering kitted or separate for field installations, SMP’s unique bezel system offers an easy and affordable alternative for desktop port identification. Bezels may be ordered blank or labeled and with a multitude of colors to choose from. The flexibility and variety of combinations for workstation labeling are endless.

• 12 different color and 4 labeling options • Standard package of bezel is 20 per bag • Can be easily customized or kitted with jacks/

adapters for special orders • Available for 6 or 8 position plugs

• Locks the jack or adapter into the faceplate • Shuttered bezels available for dust protection

axcess™ umJ Bezels

B E - - Optional Optional

position color text options

06 = 6 Position * See color chart below

V = Voice K = Keyed 08 = 8 Position D = Data S = Shuttered

F = Fax Blank = None M = Modem

Blank = None

axcess™_{umJ color code chart} code color code color

00 Electrical Ivory 07 White 01 Office White 08 Orange

02 Black 09 Yellow

03 Red 10 Purple

04 Green 11 Brown

05 Blue 12 Bright White

(31)

umJ Faceplates

SMP’s Workstation solution isn’t complete without our Axcess™_{faceplates. Available}

in a multitude of configurations and designed to meet any application, the Axcess™

faceplates for UMJ style jacks and adapters offer a convenient and aesthetically appealing solution for any desktop purpose.

Commercial Faceplates

• Commercial grade faceplates accept any UMJ Bezel jack or adapter

• ID windows include write-on labels and plastic protective covers

• Slotted mounting holes simplify installation • Available in most popular colors

• Commercial grade faceplates accept any UMJ Bezel jack or adapter

• Vertical ID windows provide easier identification changes and removal of plate for jack access • ID windows include write-on labels and plastic

protective cover

• Available in most popular colors

• Angled faceplates reduce strain on existing station cables

• ID windows include write-on labels and plastic protective cover • Available in most popular colors

axcess™ umJ commercial Faceplates

catalog

number description

FPSR01xx Single gang commercial faceplate, recessed UMJ, 1 port

DP01xx Double gang commercial faceplate, UMJ, 1 port DP02xx Double gang commercial faceplate, UMJ, 2 port DP03xx Double gang commercial faceplate, UMJ, 3 port DP04xx Double gang commercial faceplate, UMJ, 4 port DP06xx Double gang commercial faceplate, UMJ, 6 port * Replace “xx” with color choice: 00 = Electrical Ivory, 01 = Office White, 07 = White, or 12 = Bright White

axcess™ umJ Vertical Window commercial Faceplates catalog number description

FPRSV03xx Single gang commercial faceplate, vertical window UMJ, 3 port

* Replace “xx” with color choice: 00 = Electrical Ivory, 01 = Office White, 07 = White, or 12 = Bright White

axcess™_{umJ commercial angled Faceplates} catalog number description

FP04Axx Single gang commercial faceplate, angled UMJ, 4 port

DP08Axx Double gang commercial faceplate, angled UMJ, 8 port

(32)

Residential Faceplates

• Smooth surface faceplates accept any UMJ Bezel jack or adapter

• Bezel openings are recessed for neater appearance • Available in most popular colors

Stainless Steel Faceplates

• Stainless Steel faceplates accept any UMJ Bezel jack or adapter

• Corrosion resistant

• May be ordered with tamper proof screws

axcess™ umJ residential Faceplates catalog number description

FPR01xx Single gang smooth faceplate, UMJ, 1 port FPR02xx Single gang smooth faceplate, UMJ, 2 port FPR03xx Single gang smooth faceplate, UMJ, 3 port FPR04xx Single gang smooth faceplate, UMJ, 4 port FPR06xx Single gang smooth faceplate, UMJ, 6 port SDP01xx Double gang smooth faceplate, UMJ, 1 port SDP02xx Double gang smooth faceplate, UMJ, 2 port SDP03xx Double gang smooth faceplate, UMJ, 3 port SDP04xx Double gang smooth faceplate, UMJ, 4 port SDP06xx Double gang smooth faceplate, UMJ, 6 port * Replace “xx” with color choice: 00 = Electrical Ivory, 01 = Office White, 07 = White, or 12 = Bright White

axcess™_{umJ stainless steel Faceplates} catalog

number description

FP01SS Single gang stainless steel faceplate, UMJ, 1 port FP02SS Single gang stainless steel faceplate, UMJ, 2 port FP03SS Single gang stainless steel faceplate, UMJ, 3 port FP04SS Single gang stainless steel faceplate, UMJ, 4 port FP06SS Single gang stainless steel faceplate, UMJ, 6 port DP01SS Double gang stainless steel faceplate, UMJ, 1 port DP02SS Double gang stainless steel faceplate, UMJ, 2 port DP03SS Double gang stainless steel faceplate, UMJ, 3 port DP04SS Double gang stainless steel faceplate, UMJ, 4 port DP06SS Double gang stainless steel faceplate, UMJ, 6 port

(33)

umJ Faceplates

office Furniture Faceplates

• Fits most popular office furniture including Herman Miller and Steelcase

• Available in gray or black • Attractive and functional

Front Axcess™ Faceplates

• Custom configurable to accommodate UMJ and KMJ style jacks and adapters

• Accommodates three individual modules for ultimate flexibility

• Additional cable storage depth • Slim design

axcess™ umJ office Furniture Faceplates

catalog number description _dimensionscut out office Furniture compatible

herman miller steel case haworth hon other

FAP3xx Furniture faceplate, 3 port 2.65”W x 1.35”H X X X FAP302-HM Furniture faceplate, 3 port 2.98”W x 1.88”H X

FAP4xx Furniture faceplate, 4 port 5.25”W x 1.37”H X X * Replace “xx” with color choice: 02 = Black or 06 = Data Gray

Front axcess™_{umJ & KmJ Front axcess Faceplates} catalog number description

FP-FAOR-xx Front Axcess™_{faceplate, single gang ring}

FAOC-1A-xx Front Axcess™_{UMJ faceplate, 1 port insert}

FAOC-2A-xx Front Axcess™_{UMJ faceplate, 2 port insert}

FAOC-B-xx Front Axcess™_{faceplate, blank insert}

FAOC-VGA1-xx Front Axcess™_{faceplate, 1 VGA insert}

FAOC-1K-xxS Front Axcess™_{KMJ faceplate, 1 port insert}

FAOC-2K-xxS Front Axcess™_{KMJ faceplate, 2 port insert}

FP-FAU222-xx Front Axcess™_{faceplate kit,}

(3) 2 port UMJ inserts

FP-FAU221-xx Front Axcess™_{faceplate kit, (2) 2 port UMJ}

inserts, (1) 1 port UMJ insert

inserts, (1) blank insert

insert, (2) 1 port UMJ inserts

insert, (1) 1 port UMJ insert, (1) blank insert FP-FAU200-xx Front Axcess™_{faceplate kit, (1) 2 port UMJ}

insert, (2) blank inserts

FP-FAU111-xx Front Axcess™_{faceplate kit, (3) 1 port inserts}

FP-FAU110-xx Front Axcess™_{faceplate kit, (2) 1 port inserts, (1)}

blank insert

FP-FAU100-xx Front Axcess™_{faceplate kit, (1) 1 port insert, (2)}

blank inserts

(34)

Divax Faceplates

• Designed to blend in with any home or office décor • Completely compatible with DIVAX single-gang

rectangular electrical plates

• Mounts in any standard electrical box • Can be used with all DIVAX type switches • Smooth, clean surface

• Ultimate flexibility

office Furniture Faceplates

• Fits inside any standard electrical faceplate • Accommodates two UMJ ports

axcess™ umJ divax style Faceplates catalog number description

FDRxx Divax faceplate, UMJ, single gang ring FDBxx Divax faceplate, UMJ, blank insert FDUxx Divax faceplate, UMJ, 1 port Axcess™_insert

FD2Uxx Divax faceplate, UMJ, 2 port Axcess™_insert

FD3Uxx Divax faceplate, UMJ, 3 port Axcess™_insert

FDFxx Divax faceplate, UMJ, 1 port Co-ax insert FD2Fxx Divax faceplate, UMJ, 2 port Co-ax insert * Replace “xx” with color choice: 00 = Electrical Ivory, 01=White, 07 = White or 12=Bright White

axcess™ umJ receptacle insert catalog number description

A106xx UMJ Receptacle Insert, 2 port * Replace “xx” with color choice: 00 = Electrical Ivory, 01 = Office White, or 07 = White

(35)

KmJ JacKs and adapters

As an alternative to SMP’s unique UMJ jacks and adapters, SMP has created a Keystone product line to meet the demands of industry standard installa-tions. SMP’s Keystone jacks may have been designed to keep pace with standard installations, but in keeping with the SMP guarantee of excellence, every KMJ jack was created with SMP’s superior perfor-mance in mind. Each Keystone Modular Jack is component compliant to Category 3, Category 5e, and Category 6 standards and exceeds their respective category specifications. All KMJ jacks offer universal T568A/B wiring and 110 style punch downs for easy installations, making SMP’s KMJ product line a guaranteed connection.

KmJ Jacks and adapters

Category 6 Jacks

SMP’s KMJ jacks offer the same great printed circuit board technol-ogy that the UMJ jacks do to provide best-in-class Category 6 component performance. With standard 110 style terminations, SMP’s Category 6 KMJ jacks are ETL verified to TIA/EIA 568-B.2-1 Category 6 specifications and are backward compatible to Category 3.

• ETL Verified to TIA/EIA 568-B.2-1 Cat 6 • Category 6 component compliant • Mounting flexibility

• Large, easy to read color code labels • Universal T568A/B wiring for easy installation • Long term application confidence

• Compliant with power over Ethernet requirements • Backward compatible, Cat 3, 5, & 5e compliant • TERMA Grip conductor and jacket retention for

easy wiring

• Fits all SMP Keystone faceplates and surface mount boxes

Category 6a outlet Jacks

(See in Copper Closet section 2-6)

applications

• TIA/EIA 854 Gigabit Ethernet over Cat 6 Cabling • 1000BASE-T Gigabit Ethernet • 100BASE-TX Fast Ethernet • 10BASE-T Ethernet • Broadband Video • 270 Mbps digital video • 155/622 Mbps ATM • 100 Mbps TP-PMD • 100 VG-AnyLan • 4 / 16 Mbps Token Ring • Voice KmJ category 6 Jacks

catalog number description

KMJA6xx KMJ Category 6 jack, Universal 568A/B wiring KMJA650xx KMJ Category 6 jack, Universal 568A/B wiring,

50 pack

KMJA602S KMJ Category 6 shielded jack, slimline, Universal 568A/B wiring

(36)

Category 5e Jacks

The SMP Category 5e Keystone Modular Jack is a great alternative for high-density applications. Featuring a

lower profile and a snap-in design, the KMJ Category 5e jacks by SMP offer exceptional performance that exceeds industry standards. Offering Universal T568A/B wiring and component compliance to Cat 5e specifications, these Keystone jacks may be ordered with SMP’s patented PC board technology or in a leadframe configuration for cost effective solutions.

• 110 style IDC contacts meet TIA/EIA 568-B.2 requirements

• Backward compatible, Cat 3, and Cat 5 compliant • Universal T568A/B wiring for easy installation • TERMA Grip conductor & jacket retention for

easy wiring

• Available in 12 color options

applications

• 1000BASE-T Gigabit Ethernet • 100BASE-TX Fast Ethernet • 10BASE-T Ethernet • Broadband Video • 270 Mbps digital video • 155 / 622 Mbps ATM • 100 Mbps TP-PMD • 4 / 16 Mbps Token Ring • Voice KmJ category 5e Jacks

catalog number description

KMJA5Exx KMJ Category 5e Jack, Universal 568A/B wiring KMJA5E50xx KMJ Category 5e Jack, Universal 568A/B

wiring, 50 pack

KMJVL8A/Bxx KMJ Category 5e Leadframe Jack, Universal 568A/B wiring

KMJVL8A/B50xx KMJ Category 5e Leadframe Jack, Universal 568A/B wiring, 50 pack

KMJVL8A/B02S KMJ Category 5e Leadframe Shielded Jack, Universal 568A/B wiring

* Replace “xx” with color code – see color code chart below

KmJ color code chart

code color code color

00 Electrical Ivory 07 White 01 Office White 08 Orange

02 Black 09 Yellow

03 Red 10 Purple

04 Green 11 Brown

05 Blue 12 Bright White 06 Data Gray

(37)

KmJ JacKs and adapters

KMJ Feed-through Cat 5e Jack

SMP’s Category 5e Feed-through Jack offers exceptional connectivity and workstation versatility.

Category 3 Voice Grade Jacks

For voice grade applications, SMP offers a Keystone Modular Jack that exceeds performance specifications to any Category 3 requirement. SMP’s KMJ Category 3 jacks offer easy installations with 110 style terminations on back for 26, 24, and 22 AWG solid conductors and delivers unsurpassed performance, keeping with SMP’s guarantee for consistent performance.

• 110 style IDC contacts

• TERMA Grip conductor & jacket retention for easy wiring

• Available in 12 color options

KmJ category 5e Feed-through Jacks

KMJ5EFT02 KMJ Category 5e Jack, Feed-through, Black

KmJ category 3 Jacks

KMJL8A/Bxx KMJ Jack 568A/B, 8x8 Leadframe, 110 style KMJL06Uxx KMJ Jack USOC, 6x6 Leadframe, 110 style * Replace “xx” with color code – see color code chart on page WS-11

(38)

KMJ Adapters

SMP’s Keystone adapters complete the product line by offering a full array of data, video, and audio ports for fiber, copper, coaxial and speaker cables. Featuring snap-in accessibility and a wide arrange of multi-media options, the SMP KMJ adapter line gives customers a flexible solution to meet any connectivity demand.

• Fits all SMP Keystone faceplates and surface mount boxes AKSVHS12 AKF12 AKRCA110B12 AKSCM01 AKRCAP12 AKBLK12 AKRCA110Y12 AKBP212 AKDLCM00 AKSTM12 KmJ adapters

catalog number description

AKSCMxx KMJ snap-in SC Multi-mode adapter AKSTMxx KMJ snap-in ST Multi-mode adapter AKDLCMxx KMJ snap-in Dual LC Multi-mode adapter AKBNCxx KMJ snap-in BNC coupler

AKFxx KMJ snap-in F coupler AKSVHSxx KMJ snap-in Super VHS adapter AKRCAPxx KMJ snap-in Gold-plated RCA

Bulkhead adapter

AKRCA110yxx KMJ snap-in RCA to 110 adapter

AKBP2xx KMJ snap-in Gold-plated Binding Posts (pair) AKBC2xx KMJ snap-in Gold-plated Banana

adapters (pair)

AKBLKxx KMJ snap-in Blank adapters

* Replace “xx” with color choice: 00 = Electrical Ivory, 01 = Office White, or 12 = Bright White

* Replace “y” with color inset choice: R = Red, Y = Yellow, B = Black, or W = White

(39)

KmJ Faceplates

SMP’s Keystone line of faceplates offers customers a versatile and flexible approach to any workstation demand. Available to meet a variety of configurations, SMP’s KMJ faceplates offer convenience in a visually appealing solution for any desktop purpose.

• Keystone commercial grade faceplates accept any KMJ style jack or adapter

• ID windows include write-on labels and plastic protective covers • Slotted mounting holes

simplify installation

• Available in most popular colors

• Angled faceplate reduces strain on existing
