Fleet and operations Performance record

(1)

(2)

2

SBM Offshore | Fleet and operations

Introduction

The objective of SBM Offshore is to provide the offshore

oil and gas industry with high quality production services

through the leasing and operation of Floating Production

Storage and Offloading (FPSO) units, Floating Storage

and Offloading (FSO) units, Mobile Offshore Production

Units (MOPU) and Semi-submersible units. Capitalising

on the resources of all Group companies, SBM Offshore

provides safe, reliable, and cost-effective solutions for

offshore oil and gas field development needs, minimizing

capital and operational expenditure for its clients.

Worldwide Fleet and Operations

SBM Offshore provides tailor-made solutions for both

short term and life-of-field needs based upon:

• cumulative vessel operating experience of more than

200 years, during which in excess of three and a half

billion barrels of oil were exported;

• financial strength enabling attractive financing of large

capital intensive units;

• a vast pool of experienced project managers;

• in-house engineering experts in all disciplines required

for the design of total integrated production and

storage facilities.

Feedback from the day to day operations is integrated

into the design of new units. During the design and

construction phases the marine, maintenance and

production superintendents, who will also operate the

unit, are mobilised early in the project and participate

actively as part of the project execution team. Their

task is to ensure that the design satisfies their ultimate

requirements as operator.

SBM Offshore manages the fleet operations from its

offices in Monaco and through shore bases in the

countries where the units are located. It is a strict policy

of SBM Offshore to manage the fleet operations

in-house and engage all senior staff for the fleet under

direct employment. This specific approach to leasing

and operating fit-for-purpose production and storage

facilities has proven to be most successful in addressing

the needs of the industry throughout the world. This

document provides details of all production and storage

facilities owned and/or operated by SBM in the order of

first oil or gas.

Rio de Janeiro Luanda Dubai Kuala Lumpur Beijing Monaco Marly Schiedam Singapore

Project Execution/Corporate Centres Representative Offices Shore Bases Lease Units Future Lease Units Operate only Laid-up Unit Construction Yard

Houston

(3)

3 KUITO • Chevron • Angola _______________________________5

YETAGUN FSO • Petronas • Myanmar _______________________6

FPSO BRASIL • Petrobras • Brazil ___________________________7

FPSO MARLIM SUL • Petrobras • Brazil ______________________8

SANHA LPG FPSO • Chevron • Angola ______________________9

FPSO KIKEH • Murphy Sabah Oil • Malaysia ________________ 10

FPSO MONDO • ExxonMobil • Angola ____________________ 11

FPSO SAXI BATUQUE • ExxonMobil • Angola _____________ 12

THUNDER HAWK • Murphy • USA ________________________ 13

FPSO ESPIRITO SANTO • Shell • Brazil_____________________ 14

FPSO CAPIXABA • Petrobras • Brazil ______________________ 15

FPSO ASENG • Noble Energy • Equatorial Guinea __________ 16

FPSO CIDADE DE ANCHIETA • Petrobras • Brazil __________ 17

FPSO CIDADE DE PARATY • Petrobras • Brazil ______________ 18

FPSO N’GOMA • ExxonMobil • Angola ___________________ 19

FPSO CIDADE DE ILHABELA • Petrobras • Brazil ____________ 20

FPSO FALCON • Stand-by ________________________________ 21

DEEP PANUKE • Encana • Canada _________________________ 22

Operated units

FPSO FRADE • Chevron • Brazil _________________________________ 25

FPSO SERPENTINA • ExxonMobil • Equatorial Guinea ______ 24

FPSO FRADE • Chevron • Brazil ___________________________ 25

P-57 • Petrobras • Brazil __________________________________ 26

Former fleet

FPSO VI • Ashland • Nigeria ______________________________ 27

FSO XV DOMY • Elf • Nigeria _____________________________ 27

NKOSSA I • Elf • Congo __________________________________ 27

TANTAWAN EXPLORER • Chevron • Thailand _______________ 28

FPSO II • Petrobras • Brazil _______________________________ 28

FPSO FIRENZE • Agip • Italy ______________________________ 28

FPSO RANG DONG I • JVPC • Vietnam ___________________ 29

OKHA • Sakhalin Energy Investment • Russia _______________ 29

JAMESTOWN • Agip • Nigeria ___________________________ 29

FPSO MYSTRAS • Agip • Nigeria _________________________ 30

MOPU SAPARMYRAT TÜRKMENBA

ş

Y

Petronas • Turkmenistan _________________________________ 30

FSO OGUZHAN • Petronas • Turkmenistan ________________ 30

FSO UNITY • Total • Nigeria ______________________________ 31

(4)

4

SBM Offshore | Fleet and operations Type FSO LPG Size 50,000 DWT Storage capacity 78,000 m³ Water depth 135 m Field Nkossa

Lease period 10 years + 12 years of extensions

Uptime record 99.9%

Number of risers 1 x 4” Propane

1 x 4” Butane 1 x umbilical

Swivel stack 2 x 4” gas

1 x electric

Date first gas 11 November 1996

Max. throughput 530 tonnes/day Butane

800 tonnes/day Propane

Number of wells Production via a production barge

Note: FSO owned and operated by a joint venture between SBM Offshore and Maersk.

(5)

5

Type FPSO

Size 228,000 DWT

Storage capacity 1,636,000 bbls

Water depth 373 m

Field Kuito

Number of risers 2 x 11” + 2 x 9½” production

2 x 15” export 1 x 4” gas injection 2 x 6” test

4 x gas lift

5 x control umbilicals 1 x 10” water injection line 1 x 10” dead crude import

11 x futures

Swivel stack N/A (Spread mooring)

Date first oil 15 December 1999

Max. throughput 100,000 bbls oil per day

Number of wells 24 production

1 gas injection 8 water injection

Gas production 30 MMscfd

Gas lift 90 MMscfd

Water injection 136,000 bbls water per day

Note: FPSO owned by Sonasing and operated by OPS, both joint ventures between SBM Offshore and Sonangol.

KUITO • Chevron • Angola

(6)

6

SBM Offshore | Fleet and operations Type FSO Size 81,000 DWT Storage capacity 606,000 bbls Water depth 105 m Field Yetagun

Lease period 15 years

Uptime record 100%

Number of risers 1 x 6” Production

Swivel stack 1 x 6” Production ( + 1 x 6” spare)

1 x electrical signal

Date first oil 7 May 2000

Note: Vessel owned and operated by SBM Offshore.

YETAGUN FSO • Petronas • Myanmar

(7)

7

Type FPSO

Size 244,000 DWT

Water depth 1,360 m

Field Roncador

Lease period 5½ years + 5 years & 2 months of

extensions

Number of risers 8 x 6” production

2 x 6” & 1 x 8” gas injection 1 x 12” gas export

3 x 6” water injection 8 x umbilicals

Swivel stack 2 x 14” production

2 x 6” gas lift / export 1 x 10” water injection 1 x 10” fire water 1 x 8” test

2 x utility / hydraulic 1 x LV electric

2 water injection + 1 future

Gas lift + Export 106 MMscfd

Note: FPSO owned by a joint venture between SBM Offshore and MISC.

(8)

8

Type FPSO

Size 278,000 DWT

Field Marlim Sul

Number of risers 3 x 8” + 3 x 6” production

5 x 4” +1 x 2½” gas lift 5 x 6” water injection 1 x 8” gas export 1 x 8” oil import 10 (+ 2 future ) umbilicals

Swivel stack 2 x 16” produced oil

2 x 4” gas lift / export 1 x 10” water injection 1 x 10” test 1 x 10” fire water 1 x 8” oil import 1 x HP utility 1 x HP/LP utility 1 x electrical

Date first oil 7 June 2004

4 water injection

Gas production 80 MMscfd

Gas lift + export 50 MMscfd

(9)

9

Type LPG FPSO with depropanizer plant

Size 94,000 DWT

Storage capacity 135,000 m³

Field Sanha

Number of risers 2 x 6” production LPG

1 x 4” Fuel Gas 1 x umbilical

Swivel stack 2 x 6” (Toroidal) LPG

1 x 4” (Pipe swivel) Fuel Gas 1 x electrical swivel

Date first gas 21 April 2005

Max. throughput 37,370 bbls LPG per day

Number of wells Production via wellhead platform

SANHA LPG FPSO • Chevron • Angola

(10)

10

SBM Offshore | Fleet and operations Type FPSO Size 273,000 DWT Storage capacity 2,179,000 bbls Water depth 1,350 m Field Kikeh

Uptime record 99.5% Number of risers: 3 x 10" production 2 x 7" production 1 x 8" export 3 x 10" water injection 1 x 8.5" water injection 3 x umbilicals

Swivel stack 2 x 14” HP production

1 x 10” IP production 1 x 10” oil import 1 x 8” test / pigging 1 x 16” water injection 1 x 8” gas export / injection 1 x utility

1 x electrical 1 x electro-optical

1 x 12” future subsea production

Date first oil 17 August 2007

Number of wells Numerous wells directly to FPSO

or from DTU.

Gas injection 141 MMscfd

Note: FPSO owned by MDFT and operated by MDPC, both joint ventures between MISC and SBM Offshore.

FPSO KIKEH • Murphy Sabah Oil • Malaysia

(11)

11

Type FPSO

Size 273,000 DWT

Field Mondo

Number of risers 2 x 6” + 2 x 7” + 2 x 8” production

1 x 4” gas lift 1 x 7” gas injection 1 x 9” water injection 3 x umbilicals

Swivel stack 1 x double 12” production

1 x double 12” Production test 1 x 10” water injection 1 x 6” gas lift 1 x 6” pigging 1 x 6” gas injection 1 x utility hydraulic 1 x electro - optical

Date first oil 1 January 2008

Number of wells 17

Gas injection / Export 95 MMscfd

FPSO MONDO • ExxonMobil • Angola

(12)

12

Type FPSO

Size 311,000 DWT

Fields Saxi & Batuque

Number of risers 2 x 9” production (Saxi)

2 x 7” production (Batuque) 2 x 4” gas lift

1 x 6” gas injection (Saxi) 1 x 9” water injection (Saxi) 1 x 7” water injection (Batuque) 4 x umbilicals

1 x double 10” test 1 x 12” water injection 1 x 6” gas lift 1 x 8” pigging 1 x 8” gas injection 1 x utility / hydraulic 1 x electro-optical

Date first oil 1 July 2008

Max. throughput 105,000 barrels of oil per day

Number of wells Saxi 11

Batuque 9

Gas injection / Export 150 MMscfd

FPSO SAXI BATUQUE • ExxonMobil • Angola

(13)

13

Type Semi-submersible

Size 23,000 DWT

Field Mississippi Canyon, Gulf of Mexico

Lease period 5 years + options

Number of risers 2 x 8” production initial

1 x 12” oil SCR export 1 x 12” gas SCR export 6 x future SCRs

Max. throughput 45,000 barrels oil per day

Number of wells 8 + future

Note: Facility owned by SBM Offshore and operated by MURPHY.

(14)

14

SBM Offshore | Fleet and operations Type FPSO Size 392,000 DWT Storage capacity 2,067,000 bbls Water depth 1,780 m Field BC-10

Uptime record 99%

Number of risers 2 x 10" production oil

3 x 14" production oil 1 x 10" production gas (2 x 14" future production oil) 1 x 8" gas export

1 x 6" test

1 x 12" water injection 1 x 8" gas injection 6 + (3 future) x umbilicals

Swivel stack 1 x double 14” production A

1 x 16” production B 1 x 12” production C 1 x 8” firewater 1 x 8” gas production 1 x 12” water injection 1 x 6” gas export / injection 1 x utility

1 x 8” service / hot oil 1 x electro-optical 1 x HV ESP 1 x HV MPP

Max. throughput 100,000 barrels of oil per day

Gas compression 45 MMscfd

Gas export 45 MMscfd

Note: Vessel owned and operated by a joint venture between SBM Offshore and MISC.

(15)

15

Type FPSO

Size 273,000 DWT

Field Cachalote

Number of risers 5 x 10” ( + 2 x 10” future ) production

6 x 6” ( + 2 x 6” future ) gas lift

2 x 8” ( + 1 x 12” future ) water injection 1 x 10” LP gas import

1 x 10” gas export 9 ( + 3 spare ) umbilicals

1 x 12” test 1 x 10” fire water 2 x 6” gas lift 1 x electric 1 x HP/LP utility 1 x 10” water injection

Date first oil 29 May 2010

2 water injection

Note: Vessel owned by a joint venture between Queiroz Galvão and SBM Offshore, operated by SBM Offshore. Since May 2006, the FPSO was on the Capixaba field under a lease contract to Petrobras and was upgraded for the Cachalote field.

(16)

16

SBM Offshore | Fleet and operations Type FPSO Size 255,502 DWT Storage Capacity 1,695,000 bbls Water depth 960 m Field Aseng

Lease Period 15 years

Uptime Record 98.8%

Number of Risers 4 x 8" production oil

1 x 8" gas injection 1 x 8" water injection 1 x 6" diluent

Swivel Stack 10 units (5 production)

Date first oil 7 November 2011

Max. throughput 80,000 bbls of oil per day

Number of wells 10 (5 production, 3WI, 2GI)

Gas lift + Export 174 MMscfd

Note: The Aseng FPSO is owned and operated through joint venture companies between SBM Offshore and GEPetrol.

FPSO ASENG • Noble Energy • Equatorial Guinea

(17)

17

Type FPSO

Size 269,643 DWT

Field Baleia Azul

Number of risers 39

2 x 6” gas lift / export 1 x 10” water injection 1 x 10” fire water 1 x 8” test 1 x HP utility 1 x LP utility 1 x HV electric 1 x LV optical

Date first oil Q3 2012

Number of wells 9 production (8 present + 1 future)

4 water injection (3 present + 1 future)

Gas lift 70 MMscfd

Note: The FPSO was originally on location on Antan field, Nigeria and was refurbished and reconverted for the

Espadarte field, Brazil, and renamed the FPSO Espadarte. The FPSO was on the Espadarte field for 11 years under a lease contract with Petrobras. The FPSO is currently undergoing refurbishment for its future lease contract with Petrobras on the Baleia Azul Field.

(18)

18

Type FPSO

Size 265,243 DWT

Storage Capacity 1,600,000 bbls

Field Lula Nordeste

Number of Risers 10 x production

5 x production / water injection 10 x gas lift

5 x gas lift / injection 1 x gas export

1 x fiber optic communication 16 x umbilicals

Swivel Stack N/A (spread moored)

Max. throughput 150,000 bbls per day of liquids

Number of wells 15

Gas treatment 174 MMscfd

Note: The FPSO will be owned by a shareholding consortium comprised of SBM Offshore, Queiroz Galvão Óleo e Gás (QGOG), Nippon Yusen Kabushiki Kaisha (NYK) and Itochu.

FPSO CIDADE DE PARATY • Petrobras • Brazil

(19)

19

Type FPSO

Size 255,900 DWT

Storage capacity 1,507,395 bbls.

Field Angolan Block 15/06

Number of risers (16 risers)

4 x 10” Production 1 x 8” Production 2 x 8” Water Injection 1 x 8” Gas Injection 1 x 8” Service Line 2 x 4” Gas Lift 3 x Umbilicals 1 x Power Umbilical 1 x Future Power Umbilical

Swivel stack 1 x Optical Swivel

1 x 6” Gas Injection / Lift Swivel 1 x LV Electrical Swivel

1 x HP/LP Multi-path Utility Swivel 1 x HV Electrical Swivel

1 x 10” Pigging / Hot Oil Swivel 1 x 10” Water Injection Swivel 1 x double 14” HP Production Swivel 1 x double 14” HP Test/Production Swivel

Date first oil 2014

Max. Throughput 100,000 bbls. Oil Per Day

Number of Wells (Sangos, Cinguvu & Ngoma):

10 Production Wells 3 Water Injection Wells

3 Water Alternating Gas (WAG) Injection Wells

Gas Injection 100 MMscfd

Gas Lift + Export 70 MMscfd

Water Injection 110,000 bbls water per day

Note: The vessel is currently under refurbishment and will be renamed the FPSO N’Goma.

(20)

20

SBM Offshore | Fleet and operations Type FPSO Size 265,243 DWT Storage Capacity 1,600,000 bbls Water depth 2,140 m Field Sapinhoás

Uptime record N/A

Number of risers 55 (up to 16 spare risers)

Max. throughput 150,000 bbls of oil per day

Number of wells N/A

Note: The FPSO will be owned by a shareholding consortium comprised of SBM Offshore, Queiroz Galvão Óleo e Gás (QGOG) and affiliates.

(21)

21

Type FPSO

Size 297,000 DWT

Field Yoho, Nigeria (until March 2006)

Lease period 6 years to ExxonMobil

1 x 8” gas injection

1 x double 12” test 1 x 10” water injection 1 x 6” pigging 1 x 6” gas injection 1 x LP utility 1 x HP utility 1 x electric

Date first oil 6 December 2002 Date last oil 20 February 2006 Max. throughput 165,800 bbls per day Number of wells Production and gas

injection via wellhead platform

Gas injection 95 MMscfd

Water injection 90,000 bbls water per day Note: FPSO currently laid-up in Malaysia.

Vessel owned and operated by SBM Offshore and is currently on stand-by ready for a new location.

(22)

22

Type MOPU (Gas)

Size 62 x 52 x 7 m (4-legged)

Field Deep Panuke, Nova Scotia, Canada

Number of risers 4 production

1 disposal 4 future

Max. throughput 313 MMscfd

1 acid gas disposal 4 future

Umbilical connections 8

Gas Export 300 MMscfd by sub-sea pipeline

Note: Reservoir fluids contain H2S and CO2 which are separated and disposed of in a disposall well. Facility owned and operated by SBM Offshore.

(23)

(24)

24

SBM Offshore | Fleet and operations Type FPSO Size 297,355 DWT Storage capacity 2,140,000 bbls Water depth 475 m Field Zafiro Uptime record 99.1%

1 x 6” gas lift

1 x 12” water injection 1 x 14” oil import 3 x 6” umbilicals 1 x 6” future / spare

Swivel stack 1 x 12” production (double)

1 x 12” import product 1 x 12” test (double) 1 x 10” water injection 1 x 6” gas lift 1 x 6” pigging 1 x LP utility 1 x HP utility 1 x electrical

Max. throughput 110,000 bbls oil production

185,000 bbls oil import

5 water injection

Gas lift (no export) 50 MMscfd

Water injection 150,000 BWPD

Note: FPSO Serpentina was under a 7 year lease contract until ExxonMobil exercised their purchase option on 1 November 2005. The vessel is still operated by SBM Offshore.

(25)

25

Type FPSO Size 273,500 DWT Storage capacity 1,861,000 bbls Water depth 1,080 m Field Frade Uptime record 99.3%

2 x 8” water injection 1x 8” gas import / export 3 x 6” gas lift

4 x umbilicals

1 x double 18” production / test 1 x 8” gas lift / export

1 x 12” water injection 1 x 6” firewater 1 x 6” pigging 1 x HP/LP utility 1 x power / signal

Date first oil 20 June 2009 .

Max. throughput 100,000 bbls oil per day .

Number of wells 12 production.

7 water injection.

Gas compression 106 MMscfd .

Gas export 40 MMscfd.

Gas lift 86,5 MMscfd .

Water injection 150,000 bbls water per day .

Note: Vessel owned by Chevron Frade LLC, operated by SBM Offshore

(26)

26

SBM Offshore | Fleet and operations Type FPSO Size 255,000 DWT Storage capacity 2,536,900 bbls Water depth 1,300 m Field Jubarte Uptime Record 99.7%

Number of risers 19 x 6” production oil

19 x 4” gas-lift 7 x 8” water injection 2 x 8” spare water injection 1 x 9.13” gas export 1 x spare import oil 29 + (2 spare) x umbilicals

Liquid 300,000 bpd

Number of wells 15 + 4 Oil, 7+2 Water

ESP gas lift 15 + 2 Wells – up to 7 Wells

Total water injection 360,000 bpd

Prod. water reinjection 134,000 bpd

Gas treatment 2 million m3/d

Compression 2 x 100% - 71MMscfd

Removal sulphate unit 224,000 bpd

Mooring Spread mooring - 21 Mooring Lines

(Stern 2x6 + Aft 1x5 + 1x4 lines) Note: Vessel owned by Petrobras; 3-year operating contract with SBM Offshore including 6 months of transition to owner for training.

(27)

27 Type

FPSO

Size

285,000 DWT

Storage capacity

1,750,000 bbls

Water depth

42 M

Field

Antan

Uptime record

99.9%

Date first oil

5 February 1986

Date last oil

21 July 1998

Max. throughput

80,000 bbls oil per day

Note: Vessel was refurbished and upgraded for relocation to Espadarte, Brazil.

FSO XV DOMY • Elf • Nigeria

Type FSO

Size 270,000 DWT

Field OML 100 + OML 102

Date first oil 1 March 1993

Date last oil 3 June 2003

Note: Vessel refurbished and converted into an FPSO, for relocation to BC-10, Brazil.

NKOSSA I • Elf • Congo

Type

FSO

Size

270,000 DWT

Storage capacity

2,020,000 bbls

Water depth

126 m

Field

Nkossa

Uptime record

100%

Date first oil

9 June 1996

Date last oil

28 February 2003

Max. throughput

Note: Vessel sold for redeployment on the Yoho Field, Nigeria after refurbishment and modification.

(28)

28

Type FPSO

Size 127,000 DWT

Storage capacity 828,300 bbls

Field Marlim South

Date last oil 31 December 2001

Note: Relocated from West Linapacan / Cadlao fields, Philippines, where it was on location 4½ and 10 years, respectively. The unit has since been scrapped.

FPSO II • Petrobras • Brazil

Type FPSO Size 139,000 DWT Storage capacity 550,000 bbls Water depth 850 m Field Aquila Uptime record 91.3%

Date first oil 3 March 1998

Date last oil 30 April 2006

Note: FPSO owned by a joint venture between SBM Offshore and Saipem. Decommissioned end of 2006.

FPSO FIRENZE • Agip • Italy

Type FPSO Size 137,000 DWT Storage capacity 1,000,000 bbls Water depth 74 m Field Tantawan Uptime record 99.4%

Date first oil 1 February 1997

Date last oil 21 July 2008

Note: Vessel owned and operated by SBM Offshore. At contract end, Chevron excercised their purchase option of the FPSO.

(29)

29 FPSO II • Petrobras • Brazil

Type FPSO

Size 40,000 DWT

Field Okono and Okpoho

Date last oil 5 December 2003

Note: FPSO was owned by a joint venture between SBM Offshore and Saipem. Upon completion of the lease contract, the vessel was sold.

JAMESTOWN • Agip • Nigeria

OKHA • Sakhalin Energy Investment • Russia

Type FSO

Size 158,000 DWT

Field Piltun-Astokhskoye, Sakhalin

Date last oil 30 October 2008

Note: SALM mooring system designed to be laid down on seabed through winter season. Vessel owned and operated by SBM Offshore. Vessel under refurbishment for conversion into

an FPSO, for relocation to the North West Shelf, Australia.

Type FPSO

Size 150,000 DWT

Field Rang Dong

Date last oil 21 October 2008

Note: Vessel was owned and operated by SBM Offshore and under lease for a 10 year period. It has since been sold and scrapped.

(30)

30

Type MOPU

Dimension 105 x 60 m

Max. throughput 15,000 bbls oil per day Number of wells 2 production wells

MOPU SAPARMYRAT TÜRKMENBA

ş

Y

Petronas • Turkmenistan

Type FSO

Size 9,500 DWT

Storage capacity 60,000 bbls Water depth 59 m

Field Barinov, Livanov & Gubkin Lease period 3 years

Uptime record 99.5%

Number of risers 1 x 4” + 1 x 2” Date first oil 8 March 2006 Date last oil 31 July 2009

Note: The FSO & MOPU formed the Extended Well Test (EWT) system for the Caspian Sea. At contract end, Petronas excercised its purchase option.

FSO OGUZHAN • Petronas • Turkmenistan

Type

FPSO

Size

139,000 DWT

Storage capacity

1,040,000 bbls

Water depth

72 m

Field

Okono and Okpoho

Uptime record

99.1%

Date first oil

14 January 2004

Date last oil

16 May 2008

Max. throughput

Note: FPSO owned and operated by a joint venture between SBM Offshore and Saipem. During the 2Q 2008, responsibilities of the owner for the management, operation, and maintenance of the vessel were transferred to Agip Energy and Natural Resources with full delivery pursuant upon the sale of the unit.

(31)

31 MOPU SAPARMYRAT TÜRKMENBA

ş

Y

Petronas • Turkmenistan

FSO OGUZHAN • Petronas • Turkmenistan

Type FSO Size 340,000 DWT Storage capacity 2,400,000 bbls Water depth 65 m Field Amenam Uptime record 99.9%

Operation Period 7 years + 4 months

Date first oil 2 June 2003

Note: Vessel owned by TOTAL and was partially operated by SBM Offshore, until 30 september 2011.

(32)

Technology

Creating

Value

Monaco Schiedam Kuala Lumpur Houston Monaco 24, avenue de Fontvieille P.O. Box 199 MC 98007 Monaco CEDEX Principality of Monaco Telephone +377 92 05 15 00 Telefax +377 92 05 32 22 USA

1255 Enclave Parkway, suite 400 Houston, TX 77077, USA Telephone +1 281 848 6000 Telefax +1 281 848 6100

The Netherlands

P.O. Box 11, 3100 AA Schiedam Karel Doormanweg 66 3115 JD Schiedam The Netherlands Telephone +31 (0) 10 2320 000 Telefax +31 (0) 10 2320 101 Malaysia Block 2B – Level 9 Plaza Sentral Jalan Stesen Sentral 5 Kuala Lumpur Sentral

50470 Kuala Lumpur – Malaysia Telephone +60 (3) 2773 53 00 Telefax +60 (3) 2773 5399

www.sbmoffshore.com

The sole intention of this brochure is to share general information.

This document was printed in accordance with the Forest Stewardship Council and the

European Programme of Forestation

www.pefc.org P E F C / 1 6 - 3 3 - 1 8 6 P E F C / 1 0 - 3 1 - 1 7 9

This document was printed in accordance with the Forest Stewardship Council and the European Programme of Forestation

USA

1255 Enclave Parkway, suite 400 Houston, TX 77077, USA Telephone +1 281 848 6000 Telefax +1 281 848 6100 The Netherlands Karel Doormanweg 66 3115 JD Schiedam The Netherlands Telephone +31 (0) 10 2320 000 Telefax +31 (0) 10 2320 101 Malaysia Block E, Lot E Jalan Stesen Sentral 2 Kuala Lumpur Sentral 50470 KL

Telephone +60 (3) 2773 53 00 Telefax +60 (3) 2773 5399

July 2013

The sole intention of this brochure is to share general information.
