Oracle Approvals Management (AME) had rst published over ten years ago, and also big question is “Why isn’t it so popular”. I think this is

all about supporting unnecessary extra extensibility which is not required for traditional approval processes. AME includes many

advantages for more exibility/extensibility/functionality on approval processes. If we would like to check some of these advantages; you

can create custom transaction types ,approval groups , approval types. These are de nitions called rules, attributes, conditions, approval

groups, action types.

Most featured functionality that AME provides us is action types like paralel or serial voting. You can use approval types like consensus

(all approvers have to approve to end approval process) , rst responder wins ( rst approver nishes all process). And you can de ne these

approvers dynamically , It supports;

HR Organization Hierarchy

Roles

Users

Most important one: your custom approval processes with your custom rules

For further information about AME you can check these document for AME implementation : Metalink Note 336901.1 and Note

282529.1

In this case, We created a simple custom WF and PL/SQL package for AME rules and noti cation process. Custom WF contains two

processes a main and a subprocess;

ORACLE

CREATING CUSTOM ORACLE WORKFLOW USING AME

JANUARY 27, 2015 | EFE AVŞAR | LEAVE A COMMENT

(2)

(3)

In main Work ow process we call AME process with only a return type approved or rejected. So! We are focussing only AME sub-process

in this practice . Now check two notifcations and what function look like ;

(4)

These three functions use following package ;

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18

CREATE OR REPLACE package apps.xx_ame_approval_pkg is

procedure getAmeTransactionDetail (x_transaction_type in out varchar2 , x_application_id out number ); procedure getNextApprover(itemtype in varchar2,

itemkey in varchar2, actid in number, funcmode in varchar2,

resultout out NOCOPY varchar2) ;

procedure updateAmeWithResponse(itemtype in varchar2, itemkey in varchar2,

actid in number, funcmode in varchar2,

resultout out nocopy varchar2) ; END; / 1 2 3 4

CREATE OR REPLACE package body apps.xx_ame_approval_pkg is

procedure getAmeTransactionDetail (x_transaction_type in out varchar2 , x_application_id out number ) is

(5)

5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 cursor c1 is

select fnd_application_id as application_id, transaction_type_id as transaction_type from ame_transaction_types_v

where transaction_type_id = x_transaction_type;

begin

for crec in c1 loop x_transaction_type:=crec.transaction_type; x_application_id := crec.application_id ; end loop ; end ;

procedure getNextApprover( itemtype in varchar2, itemkey in varchar2, actid in number, funcmode in varchar2,

resultout out NOCOPY varchar2) IS E_FAILURE EXCEPTION; l_transaction_id number; l_next_approver ame_util.approverRecord2; l_next_approvers ame_util.approversTable2; l_next_approvers_count number; l_approver_index number; l_is_approval_complete VARCHAR2(1); l_transaction_type VARCHAR2(200); l_application_id number; l_role_users WF_DIRECTORY.UserTable; l_role_name VARCHAR2(320) ; l_role_display_name VARCHAR2(360) ; l_all_approvers ame_util.approversTable;

cursor c1(p_user_name varchar2) is

select papf.full_name from fnd_user fu , per_all_people_f papf

where fu.employee_id = papf.person_id and fu.user_name = p_user_name

and sysdate between papf.EFFECTIVE_START_DATE and nvl(papf.EFFECTIVE_end_DATE,sysdate+1) and sysdate between fu.start_date and nvl(fu.end_date,sysdate+1) ;

begin

if (funcmode = 'RUN') THEN

-- l_transaction_id := TO_NUMBER(itemkey);

(6)

59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 itemkey => itemkey, aname => 'AME_TRANSACTION_ID' );

l_transaction_type := wf_engine.getItemAttrText( itemtype => itemtype, itemkey => itemkey, aname => 'AME_TRANSACTION_TYPE' ); getAmeTransactionDetail ( l_transaction_type,l_application_id ); ame_api2.getNextApprovers4(applicationIdIn=>l_application_id, transactionTypeIn=>l_transaction_type, transactionIdIn=>l_transaction_id, flagApproversAsNotifiedIn => ame_util.booleanTrue, approvalProcessCompleteYNOut => l_is_approval_complete, nextApproversOut=>l_next_approvers); l_next_approvers_count:=l_next_approvers.count ;

if (l_is_approval_complete = ame_util.booleanTrue) then resultout:='COMPLETE:'||'APPROVAL_COMPLETE';

return;

-- Incase of consensus voting method, next approver count might be zero but there will be pending approvers elsif (l_next_approvers.Count = 0) then

ame_api2.getPendingApprovers(applicationIdIn=>l_application_id, transactionTypeIn=>l_transaction_type, transactionIdIn=>l_transaction_id, approvalProcessCompleteYNOut => l_is_approval_complete, approversOut =>l_next_approvers); end if; l_next_approvers_count := l_next_approvers.Count;

if (l_next_approvers_count = 0) then

resultout:='COMPLETE:'||'NO_NEXT_APPROVER'; return;

end if;

if (l_next_approvers_count > 0) then

resultout:='COMPLETE:'||'VALID_APPROVER'; --return;

end if;

if (l_next_approvers_count = 1) then

l_next_approver:=l_next_approvers(l_next_approvers.first()); wf_engine.SetItemAttrText( itemtype => itemType,

itemkey => itemkey,

aname => 'APPROVER_USER_NAME' , avalue => l_next_approver.name);

(7)

113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166

wf_engine.SetItemAttrText( itemtype => itemType, itemkey => itemkey,

aname => 'APPROVER_DISPLAY_NAME' , avalue => l_next_approver.display_name);

/*role name is user name here */

for crec in c1(l_next_approver.name) loop l_role_display_name:=crec.full_name ; end loop ; -- l_role_name:= resultout:='COMPLETE:'||'VALID_APPROVER'; --return; end if; l_approver_index := l_next_approvers.first();

while ( l_approver_index is not null ) loop l_role_users(l_approver_index):= l_next_approvers(l_approver_index).name ; l_approver_index := l_next_approvers.next(l_approver_index); end loop;

wf_directory.CreateAdHocRole2( role_name => l_role_name

,role_display_name => l_role_display_name ,language => null

,territory => null

,role_description => 'AME ROLE DESC' ,notification_preference => null ,role_users => l_role_users ,email_address => null ,fax => null ,status => 'ACTIVE' ,expiration_date => null ,parent_orig_system => null ,parent_orig_system_id => null ,owner_tag => null ); wf_engine.setitemattrtext(itemtype => itemtype, itemkey => itemkey, aname => 'RECIPIENT_ROLE', avalue => l_role_name ); return;

(8)

167 168 169 170 171 172 173 174 175 176 177 178 179 180 181 182 183 184 185 186 187 188 189 190 191 192 193 194 195 196 197 198 199 200 201 202 203 204 205 206 207 208 209 210 211 212 213 214 215 216 217 218 219 220 exception

when others then

-- The line below records this function call in the error -- system in the case of an exception.

wf_core.context('xx_ame_approval_pkg', 'getNextApprover', itemtype, itemkey, to_char(actid), funcmode); raise; end getNextApprover;

procedure updateAmeWithResponse(itemtype in varchar2, itemkey in varchar2, actid in number, funcmode in varchar2,

resultout out nocopy varchar2) is e_failure exception; l_transaction_id number; l_nid number; l_gid number; l_approver_name varchar2(240); l_result varchar2(100); l_ame_status varchar2(20); l_original_approver_name varchar2(240); l_forwardeein ame_util.approverrecord2;

l_transaction_type varchar2 (200 byte); l_application_id number ;

begin

l_transaction_type := wf_engine.getItemAttrText( itemtype => itemtype, itemkey => itemkey, aname => 'AME_TRANSACTION_TYPE'); getAmeTransactionDetail (l_transaction_type, l_application_id);

l_transaction_id:= wf_engine.getItemAttrNumber( itemtype => itemtype, itemkey => itemkey,

aname => 'AME_TRANSACTION_ID');

if (funcmode = 'RUN') then -- l_transaction_id := itemkey; l_gid := wf_engine.context_nid; select responder,notification_id into l_approver_name,l_nid from wf_notifications

(9)

221 222 223 224 225 226 227 228 229 230 231 232 233 234 235 236 237 238 239 240 241 242 243 244 245 246 247 248 249 250 251 252 253 254 255 256 257 258 259 260 261 262 263 264 265 266 267 268 269 270 271 272 273 274 ---where group_id=l_gid where group_id=l_gid and status = 'CLOSED';

l_result := wf_notification.getattrtext(l_nid, 'RESULT');

if (l_result = 'APPROVED') then -- this may vary based on lookup type used for approval l_ame_status := ame_util.approvedstatus;

elsif (l_result = 'REJECTED') then l_ame_status := ame_util.rejectstatus;

else -- reject for lack of information, conservative approach l_ame_status := ame_util.rejectstatus;

end if;

--set approver as approved or rejected based on approver response ame_api2.updateapprovalstatus2( applicationidin=>l_application_id, transactiontypein=>l_transaction_type, transactionidin=>l_transaction_id, approvalstatusin => l_ame_status, approvernamein => l_approver_name);

elsif ( funcmode = 'TIMEOUT' ) then l_gid := wf_engine.context_nid; select responder,notification_id into l_approver_name,l_nid from wf_notifications where group_id=l_gid; --and status = 'CLOSED';

l_result := wf_notification.getattrtext(l_nid, 'RESULT');

if (l_result = 'APPROVED') then -- this may vary based on lookup type used for approval l_ame_status := ame_util.approvedstatus;

elsif (l_result = 'REJECTED') then l_ame_status := ame_util.rejectstatus;

else -- reject for lack of information, conservative approach l_ame_status := ame_util.rejectstatus;

end if;

--set approver as approved or rejected based on approver response ame_api2.updateapprovalstatus2( applicationidin=>l_application_id, transactiontypein=>l_transaction_type, transactionidin=>l_transaction_id, approvalstatusin => l_ame_status, approvernamein => l_approver_name);

elsif ( funcmode = 'TRANSFER' ) then

--l_transaction_id := itemkey;

l_forwardeein.name :=wf_engine.context_new_role;

(10)

What we had done in package above is simple ;

in getNextApprover : we used AME engine to nd existing situation of our noti cation and approvers. Then we created a role for the

current approver then set it as noti cation performer .

in updateAmeWithResponse : we updated current noti cation status using AME engine(ame_api2 package) and control if it is in timeout

period or not , also if it is nal approver of AME approver group.

Now we begin to start this WF process from this following package below for Orders which have holds (startApprovalWF procedure) . We

can log this process (insertLog procedure) . We set document type attribute to set a custom OAF page for noti cation content. We also

have custom business rules like timeout for noti cation process just in case our approver doesn’t give a response to it . (getTimeoutDay

function). In this case our AME transaction type has the same name as Work ow item type . Package ;

275 276 277 278 279 280 281 282 283 284 285 286 287 288 289 290 291 292 293 294 295 296 297 298 299 300 301 302 ame_api2.updateapprovalstatus2(applicationidin=>l_application_id , transactiontypein=>l_transaction_type, transactionidin=>l_transaction_id, approvalstatusin => 'FORWARD', approvernamein => l_original_approver_name, forwardeein => l_forwardeein );

end if; -- run

resultout:= wf_engine.eng_completed || ':' || l_result;

exception

when others then

wf_core.context('xx_ame_approval_pkg', 'updateAmeWithResponse', itemtype, itemkey, to_char(actid), funcmode); raise; end updateAmeWithResponse; END; / 1 2 3 4

CREATE OR REPLACE package xx_ame_start_appr_pkg is

procedure startApprovalWF(errbuff out varchar2, retcode out number,

(11)

5 6 7 8 9 10 11 12 13 14 15 16 p_order_number in number, p_hold_type in varchar2 , p_comment in varchar2 ) ;

function getTimeoutDay (p_header_id in number) return number ; procedure insertLog (itemtype IN VARCHAR2,

itemkey IN VARCHAR2, p_log in varchar2 ) ; end ; / 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38

CREATE OR REPLACE package apps.xx_ame_start_appr_pkg is

/*This procedure starts our Approval WF via setting AME transaction types and required information (this can be also called as Concurrent Program)*/

procedure startApprovalWF(errbuff out varchar2, retcode out number,

p_order_number in number, p_hold_type in varchar2, p_comment in varchar2 ) is

cursor c1 is

select oh.header_id ,

oh.order_number

from oe_order_holds_all ha , oe_order_headers_all oh where ha.header_id = oh.header_id and oh.ORDER_NUMBER= p_order_number and ha.released_flag = 'N'; itemkey varchar2(240); itemtype varchar2(8); created_by_user_name varchar2(250); l_seq number ;

is_entered boolean := false ;

begin

select xxxl.xxxl_wf_item_key.nextval into l_seq from dual ;

itemkey := l_seq||'-'||p_hold_type;

itemtype :='YOUR CUSTOM WF NAME'; for crec in c1 loop

insertLog (itemtype , itemkey ,

'startApprovalWF procedure has been called');

(12)

39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 itemkey ,

'YOUR MAIN PROCESS NAME');

select user_name into created_by_user_name from fnd_user

where user_id = fnd_profile.value('USER_ID');

wf_engine.setItemAttrText(itemtype =>itemtype,

itemkey =>itemkey,

aname =>'CREATED_BY_USER_NAME',

avalue=>created_by_user_name) ;

itemkey =>itemkey,

aname =>'HOLD_TYPE',

avalue=>p_hold_type) ;

itemkey =>itemkey,

aname =>'AME_TRANSACTION_TYPE',

avalue=>'YOUR CUSTOM WF NAME') ;

wf_engine.setItemAttrNumber(itemtype =>itemtype,

itemkey =>itemkey,

aname =>'AME_TRANSACTION_ID',

avalue=>crec.header_id) ;

itemkey =>itemkey,

aname =>'ORDER_HEADER_ID',

avalue=>crec.header_id ) ;

itemkey =>itemkey,

aname =>'ORDER_NUMBER',

avalue=>crec.order_number ) ;

itemkey =>itemkey,

aname =>'START_COMMENT',

avalue=>p_comment) ;

itemkey =>itemkey,

aname =>'NUMBER_OF_WAIT_DAYS',

avalue=>getTimeoutDay(crec.header_id )) ;

wf_engine.setitemattrtext (itemtype,

itemkey,

'NTF_HOLD_CONTENT_DOC',

'JSP:/OA_HTML/OA.jsp?page=/xxxl/oracle/apps/xxxl/ame/webui/XxxlAmeNtfRN&xx_order_header_id='||crec.header_id

(13)

93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145 146 ||'&xx_item_type='||itemtype ||'&xx_item_key='||itemkey);

wf_engine.startprocess (itemtype,

itemkey); is_entered := true ; exit; end loop;

if (not is_entered) then

insertLog (itemtype , itemkey ,

'startApprovalWF no record has been found' );

fnd_file.put_line (fnd_file.LOG,'startApprovalWF no record has been found');

retcode := 2; --error RETURN; end if ; end ;

/*This function defines our custom rules for timeout function in our AME WF*/ function getTimeoutDay (p_header_id in number) return number is

l_control number; begin

begin

select 1 into l_control from oe_transaction_types_tl ott, oe_order_headers_all ooh where language='US'

and ott.name like 'Your Custom Transaction Type' and ooh.header_id=p_header_id

and ott.transaction_type_id= ooh.order_type_id;

/*Your Custom Transaction Type Order if they wouldn't order until next day at 5:00pm approval process cancel*/ return round( ((24-to_char(sysdate,'HH24') ))+ 17 )*60; --dakika

--round( ((24-to_char(sysdate,'HH24') )/24)+ 17/24 , 2) ;

exception when others then

/*If it is not approved in 5 days it will be cancelled */ return 5*24*60 ; --dakika end ; end ;

procedure insertLog (itemtype IN VARCHAR2, itemkey IN VARCHAR2,

(14)

I hope this will help to increase in demand for this productive Oracle Engine . We nished Creating Custom Oracle Work ow using AME

process ! Thanks.

Please like & share:

AME E-BUSINESS SUITE OAF ORACLE APPLICATION FRAMEWORK ORACLE APPROVALS MANAGEMENT ORDER MANAGEMENT PL/SQL R12 WORKFLOW 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 p_log in varchar2 ) is PRAGMA AUTONOMOUS_TRANSACTION; l_rec xxxl.xxxl_wf_log%rowtype ; begin

l_rec.item_type:=itemtype ; l_rec.item_key:=itemkey ; l_rec.xlog:=p_log ;

l_rec.object_name:='xx_ame_start_appr_pkg' ; l_rec.trnx_Date :=sysdate ;

insert into xxxl.xxxl_wf_log VALUES l_rec ; commit;

end ;
