PRODUCT DESCRIPTION

Firestop tape INTU FR WRAP L is made of graphite-based material. The material swells under the influence of high temperature (about 140°C), and fills the entire space created after burned flammable systems.

➔

APPLICATION

INTU FR WRAP L is used for fire protection of penetrations with plastic pipes (PVC, PP, PE,

HDPE, PEX/Al/PEX, PE-RT/Al/PE-RT, PP-R/Al/PP-R, PP-R GLASS) running through fire partitions. It is also possible to protect non-flammable pipes with insulation made of synthetic Armaflex /K-flex or PE foam, penetrating floors or walls.

• protection of flammable and non-flammable pipes insulated with synthetic rubber Armaflex / K-Flex or PE foam

• fire resistance up to 240 minutes

• availability: roll length: 10, 25 or 50 meters; width: 60mm and 100mm • installation on pipes with large diameters is possible

• easy to cut • high swelling ratio

• ideal for installation in very tight spaces

Rigid walls:

The wall must be at least 150mm thick and have concrete, cellular concrete structure or masonry structure, with a minimum density of 600kg/m3

Rigid floors:

The floor must be at least 150mm thick and have concrete, cellular concrete structure or masonry structure, with a minimum density of 1700kg/m3

Flexible walls:

The wall must be at least 125mm thick and have a steel profile structure covered on both sides with a minimum of 2 layers of boards with a thickness of 12.5mm.

➔

AVAILABILITY

Type Art. No.

10mb x 60mm INWRL60X10 10mb x 60mm (AT) INWRL60X10AT 25mb x 60mm INWRL60X25 25mb x 60mm (AT) INWRL60X25AT 10mb x 100mm INWRL100X10 10mb x 100mm (AT) INWRL100X10AT 25mb x 100mm INWRL100X25 25mb x 100mm (AT) INWRL100X25AT AT – Adhesive Tape .

➔

COMPLIANCE:

• Reference standard: EN 1366-3 / ETAG 026-2 / EAD 350454-00-1104 • DoP 1/2019 • ETA-18/0593 • CoC 1488-CPR-0722/W • TDS • SDS

➔

TRANSPORT

AND STORAGE

It is recommended to store in dry internal conditions at temperatures between + 5°C and + 35°C.

(3)

➔

FIRE RESISTANCE CLASSIFICATION for flammable pipes

IN WALLS

DIAMETER 32mm 40mm 50mm 55mm 63mm 75mm 90mm 110mm 125mm 160mm 200mm

PVC EI240 EI240 EI240 EI120 EI120 EI120 EI120 EI120 EI120 EI120 EI120

PP EI240 EI240 EI240 EI120 EI120 EI120 EI120 EI120 EI60 EI60 EI60

HDPE EI240 EI120 EI120 EI120 EI120 EI120 EI120 EI120 EI120 EI120 EI90

PEX/AL./PEX EI120 EI120 EI120 EI120 EI120 EI120 X X X X X

PE-RT/AL./PE-RT EI240 EI240 EI240 EI240 EI240 EI240 X X X X X

PP-R/AL./PP-R EI240 EI240 EI240 EI240 EI240 EI240 EI240 EI240 X X X

PP-R GLASS EI120 EI120 EI120 EI120 EI120 EI120 EI120 EI120 X X X

IN FLOORS

DIAMETER 32mm 40mm 50mm 55mm 63mm 75mm 90mm 110mm 125mm 160mm 200mm

PVC EI240 EI240 EI240 EI240 EI240 EI240 EI120 EI120 EI120 EI120 EI120

PP EI240 EI240 EI240 EI240 EI240 EI240 EI240 EI240 _EI120*EI90 _EI120*EI90 X

HDPE EI240 EI240 EI240 EI240 EI240 EI240 EI120 EI120 EI120 EI120 _EI120*EI90

PEX/AL./PEX EI240 EI240 EI240 EI240 EI240 EI240 X X X X X

PE-RT/AL./PE-RT EI120 EI120 EI120 EI120 EI120 EI120 X X X X X

PP-R/AL./PP-R EI240 EI240 EI240 EI240 EI240 EI240 EI240 EI240 X X X

PP-R GLASS EI240 EI240 EI240 EI240 EI240 EI240 EI240 EI240 X X X

FLEXIBLE WALL

DIAMETER 32mm 40mm 50mm 55mm 63mm 75mm 90mm 110mm PVC EI120 EI120 EI120 EI120 EI120 EI120 EI120 EI120

PP EI120 EI120 EI120 EI120 EI120 EI120 EI120 EI120

HDPE EI120 EI120 EI120 EI120 EI120 EI120 EI120 EI120

➔

FIRE RESISTANCE CLASSIFICATION for non-flammable pipes with flammable insulation

Steel pipes in synthetic rubber

insulation

Partition _{synthetic rubber}INSULATION Material 42,4mm 88,9mm 159,0mm 219,0mm

Wall 9mm steel EI120 EI240 EI60 EI60

Wall 50mm steel EI120 EI120 EI120 EI90

Floor 9mm steel EI240 EI120 EI120 EI60*

Floor 50mm steel EI240 EI120 EI120 EI90*

Flexible wall 9mm steel EI120 EI90 EI60* X

Flexible wall 50mm steel EI120 EI120 X X

Copper pipes in synthetic rubber

insulation

Partition INSULATION

synthetic rubber Material 15mm 54,0mm 108,0mm

Wall 9mm copper EI120 EI240 EI60

Wall 50mm copper EI120 EI120 EI60

Floor 9mm copper EI240 EI120 X

Floor 50mm copper EI240 EI120 X

Flexible wall 9mm copper EI120* X X

(4)

➔

FIRE RESISTANCE CLASSIFICATION for a bundle of copper pipes

Copper pipes in PE foam insulation Partition INSULATION PE foam Material 1/4" 5/8" bundle (separate wrapping) 1/4" 1/4" 5/8" bundle (collective wrapping) 1/4" 1/4" 5/8" Numbers of wrap

Wall 9mm copper EI240 EI120 EI120 EI120 2

Floor 9mm copper EI120 EI120 EI120 EI120 2

➔

FIRE RESISTANCE CLASSIFICATION for a bundle of pipes copper, flammable and cables

Copper pipes in PE +flammable pipes + cabel

Partition Type EI Numbers

of wrap

Wall Copper in PE (1/4” i 5/8”) + cable Ø 21mm + PP pipe Ø 25mm EI120* 4

Floor Copper in PE (1/4” i 5/8”) + cable Ø 21mm + PP pipe Ø 32mm EI240* 4

*outside of ETA, result based on the test report

➔

FIRE RESISTANCE CLASSIFICATION – outside ETA

Combustible insulated pipes (rubber) * Combustible insulated pipes (Tubolit)*

TYPE DN THICKNESS RUBBER [mm] PARTITION EI Numbers of wrap HDPE 110 2x9 wall EI 120 4 PP-R GLASS 110 2x9 wall EI 120 4 PP-R 110 2x9 wall EI 120 4 HDPE 110 2x9 floor EI 120 4 PP 110 2x9 floor EI 120 4 HDPE 110 2x13 floor EI 120 4 PP-R 110 2x9 floor EI 120 4 PP-R GLASS 110 2x9 floor EI 120 4 HDPE 160 2x23 floor EI 120 8

TYPE DN Tubolit DG Plus _[mm] PARTITION EI Numbers _{of wrap}

PP 75 2x9 wall EI 60 2 PP 110 2x13 wall EI 60 4 PP 75 2x9 floor EI 240 2

Other combustible pipes *

Other combustible pipes next to each other*

TYPE DN PARTITION EI Numbers _{of wrap}

PP Basalt 110 wall EI 240 2 PP Basalt 110 floor EI 90 2

TYPE DN PARTITION EI Numbers _{of wrap}

PP + PP 110 wall EI 120 2 PP + HDPE 110 floor EI 120 2 3x HDPE 3x32 floor EI 240 1 3x HDPE 3x32 wall EI 120 1 * outside of ETA, result based on the test report

(5)

➔

TAPE YIELD

FLAMMABLE PIPES

Wrap type [width] Diameters [mm] Pipe type Number of wraps

Amount from a roll 10m [pcs.] 60mm ≤32 PVC, PP, PE, HDPE 1 88,5 ≤40 1 72,4 ≤50 1 59,0 ≤55 1 54,0 ≤63 1 47,5 ≤75 1 40,3 ≤82 2 18,1 ≤90 2 16,6 ≤110 2 13,7 100mm ≤125 ≤160 4 5 5,9 3,7 ≤200 8 1,8

LAYERED FLAMMABLE PIPES

Wrap type

[width] Diameters [mm] Pipe type Number of wraps

Amount from a roll 10m [pcs.] 60mm ≤20 PP STABI (Aluminium/Glass) 1 132,7 ≤25 1 109,8 ≤32 1 88,5 ≤40 1 72,4 ≤50 1 59,0 ≤63 1 47,5 ≤75 1 40,3 ≤90 2 16,6 ≤110 2 13,7 60mm ≤20 PEX/AL/PEX 1 132,7 ≤25 1 109,8 ≤32 1 88,5 ≤40 1 72,4 ≤50 1 59,0 ≤63 1 47,5 ≤75 1 40,3 60mm ≤20 PE-RT/AL/PE-RT 1 132,7 ≤25 1 109,8 ≤32 1 88,5 ≤40 1 72,4 ≤50 1 59,0 ≤63 1 47,5 ≤75 1 40,3

NON-FLAMMABLE PIPES IN SYNTHETIC RUBBER INSULATION **

Wrap type [width] Diameters [mm] Thickness of the pipe wall [mm] Armaflex thickness Number of wraps 60mm ≤159,0 mm 2,0 - 14,2 9 1 10 2 13 2 16 2 19 2 25 3 32 3 40 4 50 4

(6)

➔

INSTALLATION METHOD

Prepare the appropriate length of the tape (cut off from the roll). Wrape the pipe. Slide inside the fire partition. Fill the gap with cement mortar.

INSTALLATION IN FLOORS

INSTALLATION IN WALLS

Fig. 1. A single pipe in a floor

1 – floor

2 – cement mortar filling

3 – INTU FR WRAP L firestop tape max 1 cm above floor 4 – flammable pipe

Fig. 2. A single pipe in a wall

1 – wall

2 – cement mortar filling 3 – INTU FR WRAP L firestop tape 4 – flammable pipe

Fig. 3. A single pipe with rubber in a floor

1 – floor

2 – cement mortar filling

3 – INTU FR WRAP L firestop tape max 1 cm above floor 4 – rubber

5 – non-flammable pipe

Fig. 4. A single pipe with rubber in a wall

1 – wall

2 – cement mortar filling 3 – INTU FR WRAP L firestop tape 4 – rubber

5 – non-flammable pipe

Fig. 5. A bundle of pipes in a floor

1 – a bundle of flammable pipes 2 – cement mortar filling 3 – floor

4 – INTU FR WRAP L firestop tape max 1 cm above floor

Fig. 6. A bundle of pipes in a wall

1 – a bundle of flammable pipes 2 – cement mortar filling 3 – wall

(7)

Fig. 7. A bundle of copper pipes insulated with PE foam in a floor

1 – a bundle of copper pipes ≤ ø 5/8" in PE foam insulation

2 – cement mortar filling 3 – floor

4 – INTU FR WRAP L firestop tape max 1 cm above floor 5 - PE foam insulation

Fig.8. A bundle of copper pipes insulated with PE foam in a wall

1 – a bundle of copper pipes ≤ ø 5/8" in PE foam insulation

2 – cement mortar filling 3 – wall

4 – INTU FR WRAP L firestop tape 5 - PE foam insulation

INSTALLATION IN FLEXIBLE WALLS

Fig. 9. A single pipe in a drywall

1 – flammable pipe 2 – cement mortar filling 3 – drywall

4 – 2 x INTU FR WRAP L firestop tape

Fig. 10. A single pipe with rubber in a drywall

1 – non-flammable pipe 2 – cement mortar filling 3 – drywall
