FALCO IP: The True Network
Access Control Solution
Building
Our Future
On IP
FALCO Integrated Security
Access Control System
The Falco IP System is a premier integrated security management system for your corporate security needs in small to large enterprises. Its simplicity and intuitive graphical user interface combine together make Falco IP System advance and powerful - yet easiest to use - integrated security management system.
Falco IP System is an Integrated Security Management Solution for medium to large organization offers advanced access control, alarm monitoring, digital video, intrusions detection and visitor management functionality. Individual application modules are available as standalone systems or can be deployed in any combination to deliver a single, seamlessly integrated solution. It delivers important new features that streamline administration and maintenance, facilitate internationalization, enhance integration with other systems and incorporate new technologies to provide a total security solution for the customer. The integrated access control and alarm monitoring systems deliver maximum protection,
simple operation and cost efficiency.
Falco IP System is the most cost effective, up-to-date, reliable, state-of-the-art Integrated Security Control Management System. The Falco IP controller allowed integration with value-added module, such as 8-input module, 8-outputmodule, LCD module and 2nd door controller controls.
TCP/IP ready
Scalability on LAN/WAN architecture. Optional Global Antipassback without PC online Cost effective and simple installation. Advanced video integration
Real time alarm event monitoring integration with video image. Car park control with video comparison option. Pattered card searching algorithm.
Integrated Solution – Incorporate Numerous Module
Door Access Management
Maintain total control and surveillance of all door access in your secure areas directly from any of the connected client workstations. All door access activity is transmitted directly to your computer screen. You can also give specific commands to doors such as opening and closing them directly, sealing them off from further access, etc. Features include the following:
• Anti-Passback Options - In order to prevent a single user card from being re-used to allow more than one person through a door access area, Anti-passback forces users who enter a secure area with a card to leave the area before the card may be used to enter that secure area again.
• Global Anti-Passback Options - In order to prevent a single user card from being re-used to allow more than one person through a door access area in multiple doors in a programmable sequences.
Time Management System
Users coming and going from work have their access times logged at the card reader entrances and exits of their work areas. This enables human resource personnel to notice personnel access behavior such as promptness, tardiness, early out, overtime, absenteeism, lengthy breaks, incomplete entries (ie. an out-entry but no entry, an in-entry but no out-in-entry), abnormal permissible movement (ie. a person from Accounting and Finance in the R&D department, etc.).
Real Time Intrusion & Fire Alarm Monitoring
Receive alert message regarding security breaches on your security system, such as unauthorized intrusions or device tampering, as well as a map of the immediate vicinity of the alert highlighting the location(s) of the occurrences directly on your computer screen in real time as they occur. This helps you response time and assists you in organizing and implementing a response such as contacting the police or deploying security personnel to the scene. In the event of fire alarm, all doors or specified doors will be opened.
Visitor Management System
Manage a large volume of visitor traffic through your premises quickly, easily and accurately.
•
Create and assign visitor cards instantly on demand.
•
Keep track of visitor locations, areas visited, visitor population in a secure area, etc
•
Restrict Access to sensitive areas based on security areas, floors or even particular doors.
•
Temporary cards expire automatically within a specified time so they cannot be reused later.
•
Old temporary cards can be easily recycled and reassigned.
•
Analysis of visitor movement can identify popular routes and visitor destinations.
- Integration with video will provide an extra security checking
•
Track Visitor Vehicles in the Car Park (in conjunction with car park access control).-
Car Park Access Control
Control access to a car park through the use of User ID Cards at the car park gantry areas. Falco Enterprise Network User and Visitor
Cards can be used to gain access to Car Park gantries. Anti-passback applies to vehicles as well - once a card has been used for entry it
can only be used to exit. This is to prevent multiple vehicles from using the same card to enter the car park area. Monitor vehicle
traffic and directly control the gantry from the client workstation.
•
Log vehicle traffic according to Card ID, dates, entry and exit times, etc.
•
Give commands such as opening and closing the gantry for special occasions, such as to facilitate the entry of a convoy of
delivery vehicles quickly.
Lift Access Control
Lift access may be restricted according to the access of a particular lift access cardholder to access particular floors. Unauthorized
floor entry is restricted at the lift car level, as restricted floors buttons will be rendered inoperative. In addition, floor call
overriding can be enabled to give lift usage priority to very important persons (VIP) such as Executive Officers, visiting dignitaries,
etc.
Guard Tour System
Guard touring is an additional security feature involving the close monitoring of guard patrol movement through their assigned
routes in security areas. During a Guard Tour, patrolling guards swipe their Guard Tour cards specific card readers along their tour,
which register on their security interface. Each Guard Tour has a strict schedule, with a list of periods during which the patrolling
guard must swipe his or her Guard Tour card at a particular Tour card reader. If a guard is late swiping his or her card, or misses
swiping a card reader along the tour, it is automatically assumed that the guard may have run into some kind of trouble and an
alert will be activated, informing other security personnel.
Camera Management
View real-time video on multiple cameras. Cameras can be programmed to react to alarm via additional hardware. In the event of
alarm, door tagged with camera will be displayed at another monitor, Thus security guard will react accordingly. Integration
to Car Park can be used to provide extra security check for guard on car thefts.
Web Enable
These features provide online through web (internet) to apply leaves, view simple report much as overtime and annual leave taken.
It also allowed admin to approve their staff leaves through web (internet).
Product Features
Features
Benefits
Going Digital Evolution from conventional or obsolete RS-485 or RS-232 based technology to future proof Falco IP system.
Cost-efficient Infrastructure Most facilities are already wired with twisted-pair infrastructures, so with IP access control no additional wiring is required.
Scalability LAN / WAN architecture IP access control scales from one to hundreds of IP door access control in the increments of single controller.
Global Antipassback Global Antipassback without the need of PC online 24 hours. Eliminates chances of failure when PC down.
Reduces Bandwidth High speed communication up to 100MB/s will reduce the Network Bandwidth usage. High Speed Polling Data are transmitted in bulk therefore increase the speed of data transmission from
controller to PC. These provide a real-time transactions event to the user. Peer to Peer Controller Communication Between controllers, they can communicate with each other. Therefore alarm signals
can be sent in betweens controller without PC to be online.
Wireless Networking Wireless can be use to save cable cost and also enable IP controller to be connected to those area where hardwire wiring is not permissible such as museum. Patented Card Searching Algorithm For 100k user system with our patented card searching algorithm, user can open the
door in less than a second upon proxing on the card reader
Integrated Power Supply Module Monitor AC power failure and low battery and battery cut-off. This eliminates the possibility of controller hang or become unstable when the AC power fails. When the AC power returns the EM-lock or door will not release or stuck if there is no low battery cut-off.
Star Topology A controller will not affect the other controller communication as compare with Daisy Chain or looping between the controllers. Therefore it is easy to service and troubleshoot.
Remote Site Access With the available network infrastructure, we can remote access and monitor branches from HQ via the internet/broadband. Also process data in HQ. By concentrating the monitoring of a number of buildings into a single location, client costs are reduced.
3rd Parties Software Information or data collected in the server can be export to 3rd party’s software such as HR and payroll.
Graphic User Interface (GUI) Powerful yet Easy-To-Use GUI. Uses windows based GUI which is just point and click. Auto Detects No need to set the jumper on controller to address it. It will auto detect the respective
IP on the board. Which means you do not have to set the IP number, if use our default IP and it will automatically save this in the database. The conventional 485 way you have to set the jumper and also remember the jumper address before you can install it. More Secure Our relay or door controller is inside the premises. Some low end product, the controller
and relay are together. If you tamper with the relay using the magnet, you can easily open the door or damage the system.
Ethernet Physical Transiver (EPHY) Integrated 10/100 Mbps Ethernet physical transceiver (EPHY) to our processor. If a signal converter is use to convert theRS/232 or 485 signal to TCP/IP the maximum speed is 115 K/B compare with 100 M/B for the integrated EPHY. Software driver will be required to intercept theRS/232 or 485 protocols to be converted to IP protocol. This not only slows down the system but reduce the reliability of the system. Auto Setup Our Falco IP software is intelligent enough to set the PC IP to our default IP address
system. No network IT specialist is required.
Client/Server Environment Falco IP controller uses the client/server environment to communicate with the server PC. Communication between the Falco IP controller and the computer will only happen when there is data in the controller. This reduces the network traffic compare with other system where data from the controller is poll from the computer. So the computer will try to check with each controller in the system to see if there is any data to be poll. This cause the network to be congested.
Proprietary Protocol Falco IP system uses our own proprietary protocol. This is more secure unlike most of the TCP/IP converter (485 to IP) protocol which can be obtained from the respective manufacturer
Project Reference
Air Asia, KLIA AirPort (KL, Malaysia)
Petronas, West Port (Klang, Malaysia) MidValley (KL, Malaysia) Eurocopter Subang AirportPort SMC Hospital (Kota Kinabalu, Sabah)
Berjaya, KL Plaza (KL, Malaysia)
World Distribution
Network
Controller Specifications
1DRSMT-TCP Controller Specification
Manufacturer Falco IP
CPU Motorola Enhanced microprocessor 16-bit MCU 25 MHz Memory EEPROM
Battery Charger 7AH Operating Temperature 0C to 60C Humidity Range 0-95% non-condensing Card Holder 1,000 upgradeable to 100,000 Event 2,000 upgradeable to 50,000
Reader 1 in, 1 out for 1 door (Expandable: 2 in, 2 out for 2 doors) Card format support Wiegand 26, MIFARE
Controlled Doors single door controller (Expandable: two door controller) Alarm Points 2 (Expandable: 32 Alarm input Points)
Output Relays 1 (Expandable: 64 1A Output Relays) Communication 10/100 Mbits/s
Holidays 50
Time Zones 50 Time Sets 50 Time Sets Interval 3 Access Level 72 Tamper Detection Yes Software User Level 3 Elevator Floors 64 floors Elevator Access Level 50 controls of 64 floor Card Holder Photo yes Floor Plan yes Network Protocols TCP/IP, ARP, DHCP Board Dimension (w/o casing) 128 mm x 104 mm Power source requirement 16VAC, 12VDC
Optional Configuration Able be car park controller for 2 barrier (Expandable 4 barrier) Expandable lift module
Expandable alarm module
8-Input Module Specification
Max Expansion 32 input Usage Alarm Input zones expansion Power Input 12V DC
Input Type Active Low and Active High Board Dimension (w/o casing) 90 mm x 53 mm
8-Output Module Specification
Max Expansion 64 output (dry contact) Usage Lift Floor Expansion, Automation Control Power Input 12V DC
Relay Output 10 A Contact Rating Current Consumption 0.25 A
Output Type Dry Contact (Normally Open / Normally Close) Board Dimension (w/o casing) 138 mm x 53 mm
Expansion 2nd Door Module
Power 12 VDC (Able Internal / External) Usage Connect to 2nd
Door Output 2 Relay Output Current Consumption 0.1 A Reader 2 (1 IN and 1 OUT) Tamper Detection Yes
Communication 4 LCD reader (PCC2003) PCC2003 Com Protocol RS485 PCC2003 Max Distance 1 Km Dimension 25 mm X 77 mm X 105 mm PCC 2003 LCD module Microprocessor Renesa5 R5F51256 Bus speed 18.432 MHz Communication RS485 to Interface card Baud rates 38400
Mode of operation Card only, PIN only, Card + PIN
Usage Display current date, time, card number and events Display 16 x 4 characters
Keypad 3*4
Back Light yes (Blue colour) Power Input 12V DC Built-in reader yes
Format Weigand or MIFARE Compatible Read Range 60mm – 120mm (depends on environment) Dimension (with casing) 120 mm x 90 mm
Operating Temperature 0C to 60C Humidity Range 0-95% non-condensing Power requirements 12VDC 100mA Casing material PVC type
System Capacities
Window XP, 2000 Card Readers/keypads 2048 Door controller 1024 Transactions (on line) Unlimited Transaction per controller 2,000(expandable 50,000) Card Holder per controller 1,000(expandable 100,000) Remote Communication 50 capability workstation Holidays 50
Time Zones 50 Time Sets 50 Time Sets Interval 3 Access Level 99 Numbers of controller 1000 Numbers of reader 2000 Numbers of Alarm Points 500 Numbers of auxiliary Output 250 Numbers of Elevator Lifts 250 Tamper Detection Yes Software User Level 3 Elevator Floors 64 floors Elevator Access Level 50 controls of 64 floor Card Holder Photo yes Floor Plan yes Global Antipasspack
Continuos Reading of card Even When Door is open
Card lockout is disable cards with 3 successive incorrect card (card lockout can be manually reset based on time) User Definable working hour
Door release from PC Export data to third party Simple time attendance report 3 modes of operation : card, card & pin, pin Concurrent operator languages 2 System Operator password Unlimited
Security levels 4 ( Enterprise System Admin, System Admin , Operator, Time Attendant) Number of printer 1 per workstation
Databases MSDE/SQL Others features :
- Elevator Control
- Virtual Alarm System
- Web Based Visitor Management System
- On Line Guard Tour
- Video Integration
- Car Parking Control - Remote Site Management
PC Specification
Processor Intel Pentium 4, 2.4GHz RAM Memory 256MB RAM Hard Disk Space 1000MB for software installation
Network Card (100BASE-TX / 10BASE-T) (RJ-45) or Wireless LAN IEEE802.11b/g Operating System Windows XP, Windows 2000 and above
Database Type Microsoft SQL, MSDE, Microsoft Access
System Specification
Numbers of controller 1000 Numbers of reader 2000 Numbers of Alarm Points 500 Numbers of Output Relays 250 Numbers of Elevator Lifts 250
Ethernet Specification
Ethernet 10/100 Mbps transceiver (EPHY) — IEEE 802.3 compliant — Digital adaptive equalization — Half-duplex and full-duplex — Auto-negotiation next page ability — Baseline wanders (BLW) correction — 125-MHz clock generator and timing recovery — Integrated wave-shaping circuitry — Loop back modes
FALCO IP REMOTE SITE THROUGH DDNS AND VIDEO
INTERGRATE SYSTEM ARCHITECTURE
VPN Configuration:
Requirement: router has built in VPN feature.
Both site need to apply DDNS account.
