(1)

w w w . p y t h o n b i k e s . c o m

(2)

Table Of Contents

Race

Single speed

Dual suspension

MTB

Junior

Urban

Hybrid

Comfort

Heritage

Freestyle

Folding

Electric

01

04

06

09

17

22

28

25

32

34

36

37

www.pythonbikes.com

Table Of Contents

Race

Single speed

Dual suspension

MTB

Junior

Urban

Hybrid

Comfort

Heritage

Freestyle

Folding

Electric

01

04

06

09

17

22

28

25

32

34

36

37

www.pythonbikes.com

(3)
(4)

RACE

2

RACE

3

FRAME Python, alloy racing frame. FORK Python, alloy fork.

WHEELS Shimano, WH-R500A.

GEARS Shimano 105 / Microshift , 20 speed.

CHAINSET Alloy/ Steel 39/53T double with an alloy crank. BRAKES Promax alloy with release mechanism. SADDLE Python road design with Cr-mo rails. TYRES Kenda Koncept (60 TPI) 700C x 23mm. SIZES 48cm, 51cm, 54cm, 57cm, 60cm. PART NO GRX148 , GRX151 , GRX154 , GRX157 , GRX160.

RX1

FRAME Python, alloy racing frame.

FORK Python, alloy fork.

WHEELS Shimano, WH-R500A.

GEARS: Shimano, Sora 18 speed.

CHAINSET Alloy/ Steel 39/53T double with an alloy crank.

BRAKES Promax alloy with release mechanism.

SADDLE Python road design with Cr-mo rails.

TYRES Kenda Koncept (60 TPI) 700C x 23mm.

SIZES 48cm, 51cm, 54cm, 57cm, 60cm.

PART NO GRX248 , GRX251 , GRX254 , GRX257 , GRX260.

RX2

FRAME Python, alloy racing frame.

FORK Python, alloy fork.

WHEELS ALEX, R-450.

GEARS Shimano 2200, 16 speed.

CHAINSET Steel 39/53T double with an alloy crank.

BRAKES Promax alloy with release mechanism.

SADDLE Python road design with Cr-mo rails.

TYRES Kenda Koncept (60 TPI) 700C x 23mm.

SIZES 48cm, 51cm, 54cm, 57cm, 60cm.

PART NO GRX348 , GRX351 , GRX354 , GRX357 , GRX360.

RX3

RX4

FRAME Python, alloy racing frame. FORK Python, Hi-Tensile steel.

WHEELS Alloy double wall rims with alloy quick release hubs. GEARS Shimano A050, 14 speed.

CHAINSET Steel 42/52T double with an alloy crank. BRAKES Alloy brake.

SADDLE Python road design. TYRES Kenda 700C x 25C

SIZES 48cm, 51cm, 54cm, 57cm, 60cm PART NO IRX448 , IRX451 , IRX454 , IRX457 , IRX460.

(5)

5

SINGLE SPEED

REAL GROOVE!!

SINGLE SPEED BIKE HAS BEEN A FASHION ICON ON STREET FOR A COUPLE OF YEARS.

IT IS NOT JUST ANOTHER ORDINARY SPORTING GEAR FOR THE CYCLISTS, BUT ANOTHER

FASHION TOOLS FOR RECREATION.

IT DOES NOT MATTER WHAT KIND OF GEAR SHIFTER OR SUSPENSION THAT IS

BEING USED ON THE BIKE. WHAT REALLY MATTER IS WHETHER THE BIKE WILL REPRESENT

THE SOUL OF THE BIKER OR NOT !

SINGLE SPEED BIKE IS NOT A FREESTYLE BIKE, BUT THE EXTENSION OF THE CREATION

IS EVEN MORE VOLATILE, ONLY THE SKY IS THE LIMIT!!

SINGLE SPEED

ATLAS

FRAME Python, Hi-Tensile steel.

FORK Python, Hi-Tensile steel.

WHEELS Alloy double wall rims.

FRONT HUB Alloy 32H high flange hub.

REAR HUB Alloy 32H high flange fixed hub.

GEARS Single speed.

CHAINSET Steel 46T single ring with an alloy crank.

BRAKES Alloy brake.

SADDLE Python road design.

TYRES Kenda 700C x 25C

SIZES 51cm, 54cm, 57cm

PART NO IDUK51 , IDUK54 , IDUK57

FRAME Python, Hi-Tensile steel.

FORK Python, Hi-Tensile steel.

WHEELS Alloy double wall rims.

FRONT HUB Alloy 32H high flange hub.

REAR HUB Alloy 32H high flange fixed hub.

GEARS Single speed.

CHAINSET Steel 46T single ring with an alloy crank.

BRAKES Alloy brake.

SADDLE Python road design.

TYRES Kenda 700C x 25C

SIZES 51cm, 54cm, 57cm

PART NO IATL51 , IATL54 , IATL57

(6)

7

DUAL SUSP.

DUAL

SUSPENSION

Challenge

The

Trail

DUAL

VENOM 240 DD

VENOM 240

FRAME Python Full suspension with semi-integrated headset design.

FORK SR Suntour XCT V2 MLO alloy suspension fork 100m/m travel with preload adjuster and lockout.

WHEELS Alloy double wall rims with alloy quick release hubs.

GEARS Shimano Acera 24 speed EZ FIRE Plus shifter and brake levers.

STEERING Oversize ahead set with alloy stem and handlebar.

CHAINSET SR Suntour 22/32/42 triple with alloy crank.

BRAKES Alloy V type brakes.

TYRES Duro, 26 x 2.10 all black.

SIZES 18” only.

PART NO GVEN24.

FRAME Python Full suspension with semi-integrated headset design.

FORK SR Suntour XCT V2 MLO alloy suspension fork 100m/m travel with preload adjuster and lockout.

WHEELS Alloy double wall rims with alloy quick release hubs.

GEARS Shimano Acera 24 speed EZ FIRE Plus shifter and brake levers.

STEERING Oversize ahead set with alloy stem and handlebar.

CHAINSET SR Suntour 22/32/42 triple with alloy crank.

BRAKES Promax front and rear mechanical disc.

TYRES Duro, 26 x 2.10 all black.

SIZES 18” only.

(7)

8

DUAL SUSP.

VENOM 180 DD

VENOM 180

FRAME Alloy oversized box taper section main frame, Alloy multi link rear including disc brake mounts.

FORK SR Suntour XCT V2 alloy suspension fork 100m/m travel with preload adjuster.

WHEELS Alloy rims with front alloy quick release hubs.

GEARS Shimano Tourney TX-31 21 speed with EZ FIRE Plus shifter and derailleur.

STEERING Oversize ahead set with alloy stem and handlebar.

BRAKES Promax front and rear mechanical disc.

CHAINSET Python triple 24/34/42T with alloy crank.

TYRES Duro, 26 x 2.10 all black.

SIZES 18” only.

PART NO GVEN18DD.

FRAME Alloy oversized box taper section main frame, Alloy multi link rear including disc brake mounts.

FORK SR Suntour XCT V2 alloy suspension fork 100m/m travel with preload adjuster.

WHEELS Alloy rims with front alloy quick release hubs.

GEARS Shimano Tourney TX-31 21 speed with EZ FIRE Plus shifter and derailleur.

STEERING Oversize ahead set with alloy stem and handlebar.

CHAINSET Python triple 24/34/42T with alloy crank.

BRAKES Alloy V type brakes.

TYRES Duro, 26 x 2.10 all black.

SIZES 18” only PART NO GVEN18.

mountain bike

REACH

To The

PEAK

MOUNTAIN

(8)

10

MTB

11

MTB

IMPACT 9000 DD

IMPACT 9000

FRAME Python, Alloy MTB with semi-integrated headset design. FORK SR Suntour XCT V2 MLO alloy suspension fork 100m/m travel with preload adjuster and lockout.

WHEELS Alloy double wall rims with alloy quick release hubs. GEARS Shimano Deore Dual control 27 speed.

STEERING Oversize ahead set with alloy stem and handlebar. CHAINSET SR Suntour XCT V2 22/32/42 triple with alloy crank. BRAKES Promax front and rear mechanical disc.

SADDLE Python MTB saddle. TYRES Duro, 26 x 2.125 all black. SIZES 16”, 18”, 20”, 22”. PART NO GIMP(+SIZE)DD.

FRAME Python, Alloy MTB with semi-integrated headset design. FORK SR Suntour XCT V2 MLO alloy suspension fork 100m/m travel with preload adjuster and lockout.

WHEELS Alloy double wall rims with alloy quick release hubs. GEARS Shimano Deore Dual control 27 speed.

STEERING Oversize ahead set with alloy stem and handlebar. CHAINSET SR Suntour XCT V2 22/32/42 triple with alloy crank. BRAKES Alloy V type brakes.

SADDLE Python MTB saddle. TYRES Duro, 26 x 2.125 all black. SIZES 18”, 20”, 22”.

PART NO GIMP(+SIZE).

ULTRA 9000 DD

ULTRA 9000

FRAME Python, Alloy MTB with semi-integrated headset design. FORK SR Suntour XCT V2 MLO alloy suspension fork 100m/m travel with preload adjuster and lockout.

WHEELS Alloy double wall rims with alloy quick release hubs. GEARS Shimano Deore 27 speed with Microshifter and brake levers. STEERING Oversize ahead set with alloy stem and handlebar. CHAINSET SR Suntour XCT V2 22/32/42 triple with alloy crank. BRAKES Promax front and rear mechanical disc.

SADDLE Python MTB saddle. TYRES Duro, 26 x 2.125 all black. SIZES 16”, 18”, 20”, 22”. PART NO GUL(+SIZE)DD.

FRAME Python, Alloy MTB with semi-integrated headset design. FORK SR Suntour XCT V2 MLO alloy suspension fork 100m/m travel with preload adjuster and lockout.

WHEELS Alloy double wall rims with alloy quick release hubs. GEARS Shimano Deore 27 speed with Microshifter and brake levers. STEERING Oversize ahead set with alloy stem and handlebar. CHAINSET SR Suntour XCT V2 22/32/42 triple with alloy crank. BRAKES Alloy V type brakes.

SADDLE Python MTB saddle. TYRES Duro, 26 x 2.125 all black. SIZES 18”, 20”, 22”.

(9)

12

MTB

13

MTB

ATTAK 9000 DD

ATTAK 9000

FRAME Python, Alloy MTB with semi-integrated headset design.

FORK SR Suntour XCT V3 MLO alloy suspension fork with disc mount and preload adjuster.

WHEELS Alloy double wall rims with alloy quick release hubs.

GEARS Shimano Acera 24 speed with EZ FIRE Plus shifter and brake levers.

STEERING Oversize ahead set with alloy stem.

CHAINSET SR Suntour XCT V2 22/32/42 triple with alloy crank.

BRAKES Clark front and rear mechanical disc.

SADDLE Python MTB saddle.

TYRES 26 x 2.10 all black.

SIZES 16”, 18”, 20”, 22”.

PART NO IAT(+SIZE)DD.

FRAME Python, Alloy MTB with semi-integrated headset design

FORK SR Suntour XCT V2 MLO alloy suspension fork 100m/m travel with preload adjuster and lockout

WHEELS Alloy double wall rims with alloy quick release hubs.

GEARS Shimano Acera 24 speed with EZ FIRE Plus shifter and brake levers.

STEERING Oversize ahead set with alloy stem.

CHAINSET SR Suntour XCT V2 22/32/42 triple with alloy crank.

BRAKES Alloy V type brakes

SADDLES Python MTB saddle.

TYRES Duro, 26 x 2.125 all black.

SIZES 18”, 20”, 22”.

PART NO GAT(+SIZE).

BITE 9000 FD

FRAME Python, Alloy MTB with semi-integrated headset design.

FORK SR Suntour XCT V2 alloy suspension fork with 100m/m travel with preload adjuster.

WHEELS Alloy double wall rims with alloy quick release hubs.

GEARS Shimano Altus 24 speed with EZ FIRE Plus shifter and brake levers.

STEERING Oversize ahead set with alloy stem.

CHAINSET SR Suntour 22/32/42 triple with alloy crank.

BRAKES Alloy V type brakes.

SIZES 14”, 16”, 18”, 20”, 22”.

PART NO GBT(+SIZE).

BITE 9000

FRAME Python, Alloy MTB with semi-integrated headset design.

FORK SR Suntour XCT V2 alloy suspension fork with 100m/m travel with preload adjuster.

WHEELS Alloy double wall rims with alloy quick release hubs.

GEARS Shimano Altus 24 speed with EZ FIRE Plus shifter and brake levers.

STEERING Oversize ahead set with alloy stem.

CHAINSET SR Suntour 22/32/42 triple with alloy crank.

BRAKES Promax front mechanical disc and rear alloy v type.

SIZES 14”, 16”, 18”, 20”, 22”.

(10)

14

MTB

15

MTB

BITE 9000 LADIES

FRAME 7005 Aluminium gents oversized tubing.

FORK Python suspension fork with disc mount.

WHEELS Alloy rims with front alloy quick release hubs.

GEARS Shimano Tourney TX-35 21 speed with EZ FIRE Plus shifter and brake levers.

STEERING Alloy Aheadset stem and riser bar.

CHAINSET Python alloy triple 24/34/42T.

BRAKES Clark front mechanical disc & rear alloy V-type.

TYRES KENDA MTB off road design.

SIZES 14”, 16”, 18”, 20”, 22”.

PART NO HRK26 (+SIZE) FD.

26” ROCK FD

FRAME Python, Alloy MTB with semi-integrated headset design.

FORK SR Suntour XCT V2 alloy suspension fork with 100m/m travel with preload adjuster.

WHEELS Alloy double wall rims with alloy quick release hubs.

GEARS Shimano Altus 24 speed with EZ FIRE Plus shifter and brake levers.

STEERING Oversize ahead set with alloy stem.

CHAINSET SR Suntour 22/32/42 triple with alloy crank.

BRAKES Alloy V type brakes.

SIZES 14”, 16”, 18”, 20”.

PART NO GBTL(+SIZE).

26” ROCK FS GENTS

FRAME 7005 Aluminium gents oversized tubing.

FORK Python suspension fork.

WHEELS Alloy rims with CNC side wall and alloy Q/R front hub.

GEARS Shimano Tourney TX-35 21 speed with EZ FIRE Plus shifter and brake levers.

STEERING Alloy Aheadset stem and riser bar.

CHAINSET Python alloy triple 24/34/42T.

BRAKES Alloy V brake and alloy levers.

TYRES KENDA MTB off road design.

SIZES 14”, 16”, 18”.

PART NO HRL26 (+SIZE) FS.

FRAME 7005 Aluminium gents oversized tubing.

FORK Python suspension fork.

WHEELS Alloy rims with CNC side wall and alloy Q/R front hub.

GEARS Shimano Tourney TX-35 21 speed with EZ FIRE Plus shifter and brake levers.

STEERING Alloy Aheadset stem and riser bar.

CHAINSET Python alloy triple 24/34/42T.

BRAKES Alloy V brake and alloy levers.

TYRES Kenda MTB off road design.

SIZES 14”, 16”, 18”, 20”, 22”.

PART NO HRK26 (+SIZE) FS.

(11)

16

MTB

26” ROCK GENTS

FRAME 7005 Aluminium ladies oversized tubing.

FORK Hi-tensile steel MTB fork.

WHEELS Alloy rims with nutted alloy hubs.

GEARS 18 speed with Shimano derailleurs & SHIMANO REVO shifters.

STEERING Oversized quill stem and riser bar.

CHAINSET Python alloy triple 24/34/42T.

BRAKES Alloy V brakes and alloy levers.

TYRES KENDA MTB off road design.

SIZES 14”, 16”, 18”.

PART NO HRL26 (+SIZE).

FRAME 7005 Aluminium gents oversized tubing.

FORK Hi-tensile steel MTB fork.

WHEELS Alloy rims with nutted alloy hubs.

GEARS 18 speed with Shimano derailleurs & SHIMANO REVO shifters.

STEERING Oversized quill stem and riser bar.

CHAINSET Python alloy triple 24/34/42T.

BRAKES Alloy V brakes and alloy levers.

TYRES KENDA MTB off road design.

SIZES 14”, 16”, 18”, 20”, 22”. PART NO HRK26 (+SIZE).

26” ROCK LADIES

REACH

To The

PEAK

MOUNTAIN

junior range

2011

(12)

18

JUNIOR

19

JUNIOR

24” ROCK FS BOYS

24” ROCK FS GIRLS

FRAME 7005 Aluminium boys oversized tubing.

FORK Python suspension fork.

WHEELS Alloy rims with nutted alloy hubs.

GEARS 18 speed with Shimano derailleurs & SHIMANO REVO shifters.

STEERING Oversized quill stem and riser bar.

CHAINSET Python alloy triple 28/38/48T.

BRAKES Alloy V brakes and alloy levers.

TYRES KENDA MTB off road design.

SIZE 13” Only.

PART NO HRK24FS.

FRAME 7005 Aluminium girls oversized tubing.

FORK Python suspension fork.

WHEELS Alloy rims with nutted alloy hubs.

GEARS 18 speed with Shimano derailleurs & SHIMANO REVO shifters.

STEERING Oversized quill stem and riser bar.

CHAINSET Python alloy triple 28/38/48T.

BRAKES Alloy V brakes and alloy levers.

TYRES KENDA MTB off road design.

SIZE 13” Only.

PART NO HRL24FS.

24” ROCK BOYS

FRAME 7005 Aluminium girls oversized tubing.

FORK Hi-tensile steel MTB fork.

WHEELS Alloy rims with nutted alloy hubs.

GEARS 18 speed with Shimano derailleurs & SHIMANO REVO shifters.

STEERING Oversized quill stem and riser bar.

CHAINSET Python alloy triple 28/38/48T.

BRAKES Alloy V brakes and alloy levers.

TYRES KENDA MTB off road design.

SIZE 13” Only.

PART NO HRL24.

24” ROCK GIRLS

FRAME 7005 Aluminium boys oversized tubing.

FORK Hi-tensile steel MTB fork.

WHEELS Alloy rims with nutted alloy hubs.

GEARS 18 speed with Shimano derailleurs & SHIMANO REVO shifters.

STEERING Oversized quill stem and riser bar.

CHAINSET Python alloy triple 28/38/48T.

BRAKES Alloy V brakes and alloy levers.

TYRES KENDA MTB off road design.

SIZE 13” Only.

(13)

20

JUNIOR

21

JUNIOR

20” ROCK FS BOYS

FRAME 7005 Aluminium girls oversized tubing.

FORK Python suspension fork.

WHEELS Alloy rims with nutted alloy hubs.

GEARS 6 speed with Shimano derailleurs & SHIMANO REVO shifters. STEERING Oversized quill stem and riser bar.

CHAINSET 3 piece 42t double chain guard with 140mm cranks. BRAKES Alloy V brakes and alloy levers.

TYRES KENDA MTB off road design. SIZE 11” Only.

PART NO HRL20FS.

FRAME 7005 Aluminium girls oversized tubing.

FORK Python suspension fork.

WHEELS Alloy rims with nutted alloy hubs.

GEARS 6 speed with Shimano derailleurs & SHIMANO REVO shifters. STEERING Oversized quill stem and riser bar.

CHAINSET 3 piece 42t double chain guard with 140mm cranks. BRAKES Alloy V brakes and alloy levers.

TYRES KENDA MTB off road design. SIZE 11” Only.

PART NO HRK20FS.

20” ROCK FS GIRLS

20” ROCK BOYS

FRAME 7005 Aluminium girls oversized tubing.

FORK Hi-tensile steel MTB fork.

WHEELS Alloy rims with nutted alloy hubs.

GEARS 6 speed with Shimano derailleurs & SHIMANO REVO shifters. STEERING Oversized quill stem and riser bar.

CHAINSET 3 piece 42t double chain guard with 140mm cranks. BRAKES Alloy V brakes and alloy levers.

TYRES KENDA MTB off road design. SIZE 11” Only.

PART NO HRL20.

FRAME 7005 Aluminium boys oversized tubing.

FORK Hi-tensile steel MTB fork.

WHEELS Alloy rims with nutted alloy hubs.

GEARS 6 speed with Shimano derailleurs & SHIMANO REVO shifters. STEERING Oversized quill stem and riser bar.

CHAINSET 3 piece 42t double chain guard with 140mm cranks. BRAKES Alloy V brakes and alloy levers.

TYRES KENDA MTB off road design. SIZE 11” Only.

PART NO HRK20.

(14)

23

URBAN

URBAN

2011

CITY COMMUTER

In recent years, energy saving

and waste reduction have

been the most concerned

issues for the globe.

Bicycle use has grown to the

highest level in decades , due

to the awareness of the

enviro-mental factors.

Commuting with bicycle seems

like the easiest way to save

our world from energy shortage.

QUANTUM 8000

FRAME Alloy oversized tubing with oversized stays.

FORK 700C Suspension fork with alloy crown and disc mount.

WHEELS Alloy double wall rims with front alloy quick release hubs.

GEARS Shimano Tourney TX-30 21 speed with EZ FIRE Plus shifter and derailleur.

CHAINSET SR Suntour triple 28/38/48T with alloy crank.

BRAKES Shimano Levers, Alloy V-brakes.

SIZES 18”, 20”, 22”.

PART NO GQ8118B , GQ8120B , GQ8122B.

FRAME Alloy oversized tubing with oversized stays.

FORK Hi-tensile steel 700C with tapered blade.

WHEELS Alloy Double wall rims with front alloy quick release hubs.

GEARS Shimano Tourney TX-30 21 speed with EZ FIRE Plus shifter and derailleur.

CHAINSET SR Suntour triple 28/38/48T with alloy crank.

BRAKES Shimano Levers, Alloy V-brakes.

SIZES 18”, 20”, 22”.

PART NO GQ8018A , GQ8020A , GQ8022A.

(15)

24

URBAN

QUANTUM 8200

FRAME Alloy oversized tubing with oversized stays. FORK 700C Suspension fork with alloy crown and disc mount.

WHEELS Alloy double wall rims with front and rear alloy quick release hubs. GEARS Shimano Acera 24 speed with EZ FIRE Plus shifter and brake levers.

CHAINSET SR Suntour triple 28/38/48T with alloy crank. BRAKES Shimano Levers, Alloy V-brakes.

SIZES 18”, 20”, 22”.

(16)

26

HYBRID

27

HYBRID

PARAGON GENTS

PARAGON LADIES

FRAME Alloy oversized tubing with oversized stays.

FORK Hi-tensile steel 700C with tapered blade.

WHEELS Alloy rims with CNC side wall and alloy hubs.

GEARS Shimano Tourney 18 speed REVO shifter and derailleur.

CHAINSET Python triple 28/38/48T with alloy crank.

BRAKES Alloy V-brakes and levers.

SIZES 16”, 18”.

PART NO IPAL16 , IPAL18.

FRAME Alloy oversized tubing with oversized stays.

FORK Hi-tensile steel 700C with tapered blade.

WHEELS Alloy rims with CNC side wall and alloy hubs.

GEARS Shimano Tourney 18 speed REVO shifter and derailleur.

CHAINSET Python triple 28/38/48T with alloy crank.

BRAKES Alloy V-brakes and levers.

SIZES 20”, 22”.

PART NO IPAG20 , IPAG22.

PARAGON FS GENTS

FRAME Alloy oversized tubing with oversized stays.

FORK 700C Suspension fork with alloy crown and disc mount.

WHEELS 700C alloy double wall rims with CNC side wall and alloy hubs.

GEARS Shimano 21 speed with EZ FIRE Plus shifter and brake levers.

CHAINSET SR Suntour triple 28/38/48T with alloy crank.

BRAKES Alloy V-brakes and levers.

SIZES 16”, 18”.

PART NO IPAL16FS , IPAL18FS.

FRAME Alloy oversized tubing with oversized stays

FORK 700C Suspension fork with alloy crown and disc mount.

WHEELS 700C alloy double wall rims with CNC side wall and alloy hubs.

GEARS Shimano 21 speed with EZ FIRE Plus shifter and brake levers.

CHAINSET SR Suntour triple 28/38/48T with alloy crank.

BRAKES Alloy V-brakes and levers.

SIZES 20”, 22”.

PART NO IPAG20FS , IPAG22FS .

(17)

29

COMFORT

Relax

Explore

Outdoor

EXPLORE RELAX OUTDOOR

DAYTONA GENTS

DAYTONA LADIES

FRAME Alloy low step over frame design.

FORK Suspension fork with alloy crown and disc mount.

WHEELS 26” alloy rims with CNC side wall and alloy hubs.

GEARS Shimano 21 speed with EZ FIRE Plus shifter and brake levers.

CHAINSET Python triple 28/38/48T with alloy crank.

BRAKES Alloy V-brakes and levers.

SIZES 16”, 18”.

PART NO IDTL16 , IDTL18.

FRAME Alloy oversized tubing with oversized stays.

FORK Suspension fork with alloy crown and disc mount.

WHEELS 26” alloy rims with CNC side wall and alloy hubs.

GEARS Shimano 21 speed with EZ FIRE Plus shifter and brake levers.

CHAINSET Python triple 28/38/48T with alloy crank.

BRAKES Alloy V-brakes and levers.

SIZES 16”, 18”, 20”.

(18)

30

COMFORT

31

COMFORT

LEAN GENTS

LEAN LADIES

FRAME Python, Alloy comfort with semi-integrated headset design.

FORK 700C Suspension fork with alloy crown and disc mount.

WHEELS 700C alloy double wall rims and alloy front QR hub.

GEARS Shimano Tourney 21 speed with EZ FIRE Plus shifter and brake levers.

CHAINSET SR Suntour triple 28/38/48T with alloy crank.

BRAKES Alloy V type brakes.

SIZES 16”, 18”, 20”, 22”.

PART NO GLNG16 , GLNG18 , GLNG20 , GLNG22.

FRAME Python, Alloy comfort with semi-integrated headset design.

FORK 700C Suspension fork with alloy crown and disc mount.

WHEELS 700C alloy double wall rims and alloy front QR hub.

GEARS Shimano Tourney 21 speed with EZ FIRE Plus shifter and brake levers.

CHAINSET SR Suntour triple 28/38/48T with alloy crank.

BRAKES Alloy V type brakes.

SIZES 16” ,18”, 20”.

PART NO GLNL16 , GLNL18 , GLNL20.

KIRO GENTS

KIRO LADIES

FRAME Python, Alloy comfort with semi-integrated headset design.

FORK 700C Suspension fork with alloy crown and disc mount.

WHEELS 700C alloy double wall rims and alloy front and rear QR hubs.

GEARS Shimano Acera 24 speed with EZ FIRE Plus shifter and brake levers.

CHAINSET SR Suntour triple 28/38/48T with alloy crank.

BRAKES Alloy V type brakes.

SIZES 16” , 18”, 20”, 22”.

PART NO GKRG16 , GKRG18 , GKRG20 , GKRG22.

FRAME Python, Alloy comfort with semi-integrated headset design.

FORK 700C Suspension fork with alloy crown and disc mount.

WHEELS 700C alloy double wall rims and alloy front and rear QR hubs.

GEARS Shimano Acera 24 speed with EZ FIRE Plus shifter and brake levers.

CHAINSET SR Suntour triple 28/38/48T with alloy crank.

BRAKES Alloy V type brakes.

SIZES 16” , 18”, 20”.

(19)

33

HERITAGE

Heritage Range

CLASSIC GENTS

CLASSIC LADIES

FRAME Traditional Hi-ten steel frame design.

FORK Hi-tensile steel 700C with tapered blade.

WHEELS 700C alloy double wall rims with CNC side wall.

GEARS Sturmey Archer internal 3 speed.

BRAKES Alloy V-brakes and levers.

EXTRAS Rear carrier, full mudguards & alloy kickstand.

SIZES 17”, 19”.

PART NO ICLSL17 , ICLSL19.

FRAME Traditional Hi-ten steel frame design.

FORK Hi-tensile steel 700C with tapered blade.

WHEELS 700C alloy double wall rims with CNC side wall.

GEARS Sturmey Archer internal 3 speed.

BRAKES Alloy V-brakes and levers.

EXTRAS Rear carrier, full mudguards & alloy kickstand.

SIZES 20”, 22”.

(20)

35

FREESTYLE

FRAME

Oversized Hi-Tensile tubing.

FORK

Oversized Hi-Tensile fork.

CHAINSET

3 piece crank.

BRAKES

Alloy U-brakes front and rear.

EXTRAS

1 pair of threadless axle pegs.

PART NO

ILABK.

FRAME

Oversized Hi-Tensile tubing.

FORK

Oversized Hi-Tensile fork.

CHAINSET

3 piece crank.

BRAKES

Alloy U-brakes front and rear.

EXTRAS

1 pair of threadless axle pegs.

PART NO

ILAWHT.

35

FRAME

Oversized Hi-Tensile tubing.

FORK

Oversized Hi-Tensile fork.

CHAINSET

3 piece crank.

BRAKES

Alloy U-brakes front and rear.

EXTRAS

1 pair of threadless axle pegs.

PART NO

ILABK.

FRAME

Oversized Hi-Tensile tubing.

FORK

Oversized Hi-Tensile fork.

CHAINSET

3 piece crank.

(21)

36

FOLDING

SPEED 2.0

Flexibility & Portability

FOLDING

FRAME Python Cr-mo folding bike frame. FORK Python Cr-mo unicrown fork.

WHEELS 20” alloy double wall rims and hubs with quick release. GEARS Microshift 18 speed with Microshifter and brake levers.

CHAINSET Python double 42/52T, with Power Drive BB mount.

BRAKES Alloy V type brakes.

SIZE 16” only.

PART NO GSPD2.

(22)

38

ELECTRIC

39

ELECTRIC

Frame 26” x 18” Alloy 6061 Low Step Over Unisex Design

Fork ZOOM Alloy Suspension

Gears 6 spd Shimano TX-50 Shifter/TY-18 Deraillieur

Wheels Alloy Anodized 26” Double Wall Rims

Tyres KENDA KHAN K-935

Brakes Alloy V-Type Front & Rear

Mudguards Thermo Plastic with Splash Guards

Rear Carrier Alloy With Sprung Top

Propstand Alloy Dual Leg For Extra Stability

Handlebar Height 105cm - 115cm

Saddle Height 83cm - 89cm

Bike weight 25Kgs (including battery)

POWER SYSTEM

Motor Rear Driven 250w High Torque Brushless Motor

Battery Li-ion 36V / 8Ah

Battery Capacity 288 Watt hours

Power delivery Pedal Assist Mode

Range 20miles +/- Depending on Terrain

Charge time 4 - 6 hours

Battery life Rechargeable up to 500 Cycles

Battery weight 3.7 kgs FRAME 2 Years BATTERY 1 Year GUARANTEE BICYCLE SPECIFICATION

METRO 3

Frame 700C x 19” Alloy 6061 Low Step Over Unisex Design

Fork ZOOM Alloy Suspension

Gears 7 spd Shimano REVOSHIFT SL-RS43 /TX-31 Derailleur

Wheels Alloy anodized 700C double wall rims

Tyres KENDA KHAN K-935

Brakes Alloy V-Type Front & Rear

Mudguards Thermo plastic with splash guards

Rear Carrier Alloy double layer with intergrated battery carrier.

Propstand Alloy Dual Leg For Extra Stability

Handlebar Height 102cm - 112cm

Saddle Height 88cm - 100cm

Bike weight 26.4Kgs (including battery)

POWER SYSTEM

Motor Front Drive Max Power 250W High Torque Brushless Motor

Battery Li-ion 36V / 10Ah

Battery Capacity 360 Watt hours

Power delivery Pedal Assist Mode

Range 20miles +/- Depending on Terrain

Charge time 5 - 7 hours

Battery life Rechargeable up to 500 Cycles

Battery weight 4.8 kgs FRAME 2 Years BATTERY 1Year GUARANTEE BICYCLE SPECIFICATION

E-PASS

(23)

5/JM/02/11 Reece Cycles PLC 100 Alcester street Birmingham B12 0QB TEL : 0121 622 0180 FAX : 0121 666 7225 E-mail : [email protected] www.pythonbikes.com

Python branded bicycles are guaranteed against manufacturing or material defects from the date of original purchase for a period of :

Steel hardtail frames with rigid forks Alloy hardtail frames

Suspension frames

1 year 1 year 1 year

Provided the bicycle has been properly cared for, maintained and used and has not been fitted with parts other than a Python approved spare part. This guarantee does not cover normal wear and tear, alteration, accident, misuse, neglect, improper maintenance, racing, stunt riding or

commercial use (e.g. Hiring).

All original parts including suspension forks and rear shocks are guaranteed for a period of one year or as specified by the component manufacturers. All suspension parts used in your Python bicycle are guaranteed by the specialist manufactures. Details of the UK and EIRE distributor can be obtained from your Python dealer. Regular service is recommended to ensure roadworthiness and to prolong the life of your Python bicycle.

Python bicycles are guaranteed for normal off road use. Activities such as “Wheelies”, stunt riding or jumping constitutes misuse and will invalidate this guarantee.

Under these terms, Python will bear the cost of replacement parts. Additionally labour charges incurred within one year of the date of the original sale will also be borne by Python, provided proof of purchase is available and the claim has been processed by an approved Python dealer. PROOF OF PURCHASE IS THE OWNERS RESPONSIBILITY. This guarantee does not affect your statutory rights. In the event of a guarantee claim, consult the original selling dealer or your local Python agent. Taking the complete bicycle with you.

Python are continually developing their product range and therefore reserve the right to alter components and specifications without notice.

References

Related documents

panel Handlebar and controls Front forks Frame Stand Clutch control Front brake Rear brake Front and rear wheels Rear wheel axle Rear subframe Number plate holder Rear

Ending with Margaret’s spiritual and legal inheritance of Howards End, Forster’s novel conclusion provides an optimistic vision of married women’s property rights compared to

Bag Coalition v. This Article summarizes the current state of the movement to reduce plastic bag consumption and provides a framework for further efforts. Part II of

I’ve created a very useful CATIA macro to help clean up my CATIA files before I send them to my customers by automatically deleting all deactivated features. This helps keep the

Based on this discussion, and considering the importance of studies that have examined the value relevance of accounting information (Kothari, 2001) and the propensity that

Nevertheless, the number of firms involved in these studies is rather small (28), hampering a more generalised study of Portuguese TIF. Moreover, albeit acknowledging the

• International Journal for Advanced Review and Research in Pharmacy (IJARRP) • International Journal for Development of Computer Science and Technology (IJDCST) •

Mirroring the limited body of research, studies focusing on micro and small firm innovation in historic/traditional European industries have been scant, including in the
