HARLEY DAVIDSON Make / Model / Year

(1)

BRAKE

APPLICA

TIONS

14

Part numbers, illustrations and format of this catalogue are covered by COPYRIGHT. Imitation or copy without our written consent will result in prosecution.

* 2 Sets Required. All names & numbers are for Reference purposes only. ® Registered Trademarks of Harley-Davidson®_{Motor Corp or Buell.} Recommended Fittings: FA400 for use on polished or chrome show rotors. FA400HH recommended fitting as replacement for O/E.

NOTE :- Some models may have a second rotor fitted as an optional extra. Please double check with your customer exactly which side the front rotor is fitted and if twin rotor or single. PICK UP TRUCK SPECIAL EDITION

F-150 PICK UP TRUCK

Note there is a choice of pad material for 00-04 DP61259 GREEN GD7130 GD7130 DP61633 GREEN GD7154 GD7154 both pads and discs, check website DP41259R YELLOW USR7130 USR7130 DP41633R YELLOW USR7154 USR7154 www.ebcbrakes.com for details of parts

SPORTSTER SERIES

XL, XLH, XLCH, XLS, XLX (Sportster®, 53C Custom®)

54-78 54-78 N/A N/A N/A N/A

54-72 54-72 N/A N/A N/A N/A

(XLH, XLCH) (Rivet Type) 73-77 FA026 N/A FA072 FA072V N/A

(Twin fronts) 79-81 FA071* FA071V* N/A FA072 FA072V N/A

(Twin fronts) (Girling caliper) 82-83 FA071* FA071V* N/A N/A FA078 FA078V N/A 84- Early 87 (Girling caliper) 84-Early 87 FA094 FA094V FA094HH FSD009 FA078 FA078V FA078HH N/A Late 87-99 Late 87-99 FA094 FA094V FA094HH FSD009 FA200 FA200V FA200HH RSD019 XL 50 50th Anniversary Sportster 07 FA381 FA381V FA381HH FSD010 FA387 FA387V FA387HH RSD020 XLH Sportster 883 00-03 FA400 FA400V FA400HH FSD010 Use FA400V FA400V FA400HH RSD020 XLH Sportster 883 R Flat Track 00-03 FA400 FA400V FA400HH FSD010 Use FA400V FA400V FA400HH RSD020 XL Sportster 883 Hugger 00-03 FA400 FA400V FA400HH FSD010 Use FA400V FA400V FA400HH RSD020 XL Sportster 53c Custom (883cc) 00-03 FA400 FA400V FA400HH FSD010 Use FA400V FA400V FA400HH RSD020 XL 883 Sportster Standard 00-03 FA400 FA400V FA400HH FSD010 Use FA400V FA400V FA400HH RSD020 XL 883 R 100th Anniversary Edition 03 FA400* FA400V* FA400HH* FSD010 FSD010 Use FA400V FA400V FA400HH RSD020 XL 883 C Sportster Custom 04-08 FA381 FA381V FA381HH FSD010 FA387 FA387V FA387HH RSD020 XL 883 L 883 Low 04-10 FA381 FA381V FA381HH FSD010 FA387 FA387V FA387HH RSD020 XL 883 L Superlow 11-12 FA381 FA381V FA381HH FSD010 FA387 FA387V FA387HH RSD020 XL 883 R Sportster R 05-09 FA381* FA381V* FA381HH* FSD010 FSD010 FA387 FA387V FA387HH RSD020 XL 883 R Roadster 10 FA381* FA381V* FA381HH* FSD010 FSD010 FA387 FA387V FA387HH RSD020 XL 883 N Iron 09-12 FA381 FA381V FA381HH FSD010 FA387 FA387V FA387HH RSD020 XL Sportster 1200c Custom 00-03 FA400 FA400V FA400HH FSD010 Use FA400V FA400V FA400HH RSD020 XL Sportster 1200s Sport 00-03 FA400* FA400V* FA400HH* FSD010 FSD010 Use FA400V FA400V FA400HH RSD020 XL 1200 C Sportster Custom 04-12 FA381 FA381V FA381HH FSD004 FA387 FA387V FA387HH RSD020 XL 1200 L Sportster Low 07-11 FA381 FA381V FA381HH FSD010 FA387 FA387V FA387HH RSD020 XL 1200 N Nightster (Spoke wheel) 08-12 FA381 FA381V FA381HH FSD010 FA387 FA387V FA387HH RSD020 XL 1200 R Sportster Roadster 04-08 FA381* FA381V* FA381HH* FSD004 FSD004 FA387 FA387V FA387HH RSD020 XL 1200 V - Seventy Two 12 FA381 FA381V FA381HH FSD010 FA387 FA387V FA387HH RSD020 XL 1200 X - Forty Eight 10-12 FA381 FA381V FA381HH FSD010 FA387 FA387V FA387HH RSD020

XR 1200 08-10 FA296HH* MD523X MD523X FA387 FA387V FA387HH MD524

XR 1200 X 10-12 FA296HH* MD523X MD523X FA387 FA387V FA387HH MD524

DYNA SERIES

FX, FXE, FXEF, FXWG, FXS

(FX, FXE) (Rivet Type) 73-77 FA026 N/A FA024/2 FA024/2V N/A

(Twin Fronts) Late 78-83 FA071 FA071V N/A FA024/2 FA024/2V N/A

84-86 FA094* FA094V* FA094HH* FSD009 FSD009 FA078 FA078V FA078HH N/A

(FXWG, FXSB) 83 FA071 FA071V N/A FA078 FA078V FA078HH N/A

FL, FLH

49-71 N/A N/A

58-62 N/A N/A

(Banana Caliper) 72-84 FA024/2 FA024/2V N/A FA024/2 FA024/2V N/A

(Banana Caliper) 72-80 FA024/2 FA024/2V N/A FA024/2 FA024/2V N/A

81-84 FA024/2 FA024/2V N/A FA079 FA079V N/A

PAD/SHOE/ROTOR Applications for AMERICAN PRODUCED MOTORCYCLES

R

Suffix = High Durability Sintered Pad.

HH

Suffix = High Performance Sintered Pad.

G

Suffix = Grooved Shoe.

D

Suffix = Drilled Disc.

C

Suffix = Contoured Disc.

LS

Suffix = Left/Steel Disc.

RS

= Right/Steel Disc.

FRONT

Organic Pads Semi-Sintered V-Pads Sintered Pads FSD (Left) FSD (Right) Organic Pads Semi-Sintered V-Pads Sintered Pads FSD (Left) FSD (Right)

REAR

HARLEY DAVIDSON

®

Make / Model / Year

(2)

BRAKE

APPLICA

TIONS

15

NOTE :- Some models may have a second rotor fitted as an optional extra. Please double check with your customer exactly which side the front rotor is fitted and if twin rotor or single. FXD, FXDL, FXDWG, FXR, FXRS, FXRT, FXRD, FXLR

(Convertible®, Dyna®, Superglide®, Sportglide®, Lowrider®, Wide Glide®)

(Twin Fronts) 82-83 FA071 FA071V N/A

84-99 FA094* FA094V* FA094HH* FSD009 FSD009

(Girling Caliper) 82-Early 87 FA078 FA078V FA078HH N/A

Late 87-99 FA200 FA200V FA200HH RSD019

FLD Switchback 12 FA457V FA457HH MD516 ◆ FA458V FA458HH RSD020

FXD Super Glide 00-03 FA400 FA400V FA400H FSD010 Use FA400V FA400V FA400HH RSD020

FXD Super Glide (Cast wheel) 08-10 FA457V FA457H MD516 ◆ FA458V FA458HH RSD020

NOTE ◆MD516X Floating conversion in place of solid MD516 disc. 08-10

FXDF Fat Bob (Cast wheel) 08-12 FA457V* FA457HH* MD518 MD518 FA458V FA458HH RSD020 FXDX Super Glide Sport 00-03 FA400* FA400V* FA400HH* FSD010 FSD010 Use FA400V FA400V FA400HH RSD020 FXDL Low Rider 00-03 FA400* FA400V* FA400HH* FSD010 FSD010 Use FA400V FA400V FA400HH RSD020 FXDWG Wide Glide 00-03 FA400* FA400V* FA400HH* FSD010 Use FA400V FA400V FA400HH RSD020

FXDWG Wide Glide (Spoke wheel) 08-12 FA457V FA457HH MD518 FA458V FA458HH RSD020

FXDS-CON Dyna Convertible 00-02 FA400* FA400V* FA400HH* FSD010 FSD010 Use FA400V FA400V FA400HH RSD020 FXDXT Superglide T-Sport 01-03 FA400* FA400V* FA400HH* FSD010 FSD010 Use FA400V FA400V FA400HH RSD020 FXDi Super Glide 1450 04-05 FA400 FA400V FA400HH FSD010 Use FA400V FA400V FA400HH RSD020 FXDi 35 35th Anniversary Super Glide

(Spoke wheels) 06 FA400 FA400V FA400HH MD518 Use FA400V FA400V FA400HH RSD020

FXDXi Super Glide Sport 04-05 FA400* FA400V* FA400HH* FSD010 FSD010 Use FA400V FA400V FA400HH RSD020 FXDLi Low Rider 1450 04-05 FA400 FA400V FA400HH FSD010 Use FA400V FA400V FA400HH RSD020 FXDLi Dyna Low Rider (Spoke wheels) 06 FA400 FA400V FA400HH MD518 Use FA400V FA400V FA400HH RSD020 FXDWGi Wide Glide 1450 04-05 FA400 FA400V FA400HH FSD010 Use FA400V FA400V FA400HH RSD020 FXDWGi Dyna Wide Glide (Spoke wheels) 06-07 FA400 FA400V FA400HH MD518 Use FA400V FA400V FA400HH RSD020 FXDC/FXDCi Super Glide Custom 05 FA400 FA400V FA400HH FSD010 Use FA400V FA400V FA400HH RSD020 FXDCi Dyna Superglide Custom (Spoke wheels)06-07 FA400 FA400V FA400HH MD518 Use FA400V FA400V FA400HH RSD020 FXDC Super Glide Custom (Spoke wheel) 08-12 FA457V FA457HH MD518 FA458V FA458HH RSD020 FXDBi Street Bob (Spoke wheels) 06-07 FA400 FA400V FA400HH MD518 Use FA400V FA400V FA400HH RSD020

FXDB Street Bob (Spoke wheel) 08-12 FA457V FA457HH MD518 FA458V FA458HH RSD020

FXDi Super Glide (Cast wheel) 06-07 FA400 FA400V FA400HH MD516 _◆ Use FA400V FA400V FA400HH RSD020 NOTE _◆MD516X Floating conversion in place

of solid MD516 disc.

FXDLi (Cast wheel) 06-07 FA400 FA400V FA400HH MD516 _◆ Use FA400V FA400V FA400HH RSD020 NOTE _◆MD516X Floating conversion in place

FXDL Low Rider (Cast wheel) 08-09 FA457V FA457HH MD516 _◆ FA458V FA458HH RSD020

NOTE _◆MD516X Floating conversion in place of solid MD516 disc.

FXDCi Superglide Custom (Cast wheel) 06 FA400 FA400V FA400HH MD516 _◆ Use FA400V FA400V FA400HH RSD020 NOTE _◆MD516X Floating conversion in place

of solid MD516 disc. SOFTAIL SERIES

FXST, FXSTB, FXSTC, FXSTS, FLST, FLSTC, FLSTF, FLSTS, FLSTN

(Fat boy®, Softail®, Softail Custom®, Heritage Softail®, Heritage Softail Custom ®, Heritage Springer®, Springer®, Night train®)

(Girling Caliper) 84-99 FA094 FA094V FA094HH FSD009

84- Early 87 FA078 FA078V FA078HH N/A

Late 87-99 FA200 FA200V FA200HH RSD019

FXST/FXSTi Softail Standard 00-05 FA400 FA400V FA400HH FSD010 Use FA400V FA400V FA400HH RSD020 FXSTB/FXSTBi Night Train 00-05 FA400 FA400V FA400HH FSD010 Use FA400V FA400V FA400HH RSD020 FXSTDI/FXSTD Softail Deuce/i 00-07 FA400 FA400V FA400HH FSD010 Use FA400V FA400V FA400HH RSD020 FXSTS/FXSTSi Softail Springer 00-05 FA094 FA094V FA094HH FSD009 Use FA400V FA400V FA400HH RSD020 FLSTF/FLSTFi Fat Boy 00-06 FA400 FA400V FA400HH FSD010 Use FA400V FA400V FA400HH RSD020

FLSTF/FLSTFi Fat Boy 07 FA400 FA400V FA400HH FSD010 FA434 FA434V FA434HH RSD020

PAD/SHOE/ROTOR Applications for AMERICAN PRODUCED MOTORCYCLES

R

HH

G

D

C

LS

RS

= Right/Steel Disc.

FRONT

REAR

HARLEY DAVIDSON

®

Make / Model / Year

(3)

BRAKE

APPLICA

TIONS

16

NOTE :- Some models may have a second rotor fitted as an optional extra. Please double check with your customer exactly which side the front rotor is fitted and if twin rotor or single.

FLSTFB Fat Boy Special/LO 10-11 FA457V FA457HH FSD010 FA458V FA458HH RSD020

FLSTFi Fat Boy 15th Anniversary Edition 05 FA400 FA400V FA400HH FSD010 Use FA400V FA400V FA400HH RSD020 FLSTCI/FLSTC Heritage Classic/i 00-07 FA400 FA400V FA400HH FSD010 Use FA400V FA400V FA400HH RSD020 FLSTS Heritage Springer 00-03 FA094 FA094V FA094HH FSD010 Use FA400V FA400V FA400HH RSD020 FLSTN/FLSTNi Softail Deluxe 05-07 FA400 FA400V FA400HH FSD010 Use FA400V FA400V FA400HH RSD020 FLSTSC/FLSTSCi Springer Classic 05-07 FA094 FA094V FA094HH FSD010 Use FA400V FA400V FA400HH RSD020 FLST/FLSTI Heritage Softail 06 FA400 FA400V FA400HH FSD010 Use FA400V FA400V FA400HH RSD020 FLSTSB Softail Cross Bones 08-11 FA094 FA094V FA094HH FSD010 FA458V FA458HH RSD020 FXST/FXSTI Softail Standard 06-07 FA400 FA400V FA400HH FSD010 FA434 FA434V FA434HH RSD020 FXSTB/FXSTBi Night Train Softail 06-07 FA400 FA400V FA400HH FSD010 FA434 FA434V FA434HH RSD020 FXSTB Night Train (Spoke wheel) 08-09 FA457V FA457HH FSD010 FA458V FA458HH RSD020 FXSTC Softail Custom 07 FA400 FA400V FA400HH FSD010 Use FA400V FA400V FA400HH RSD020 FXSTC Softail Custom (Spoke wheel) 08-10 FA457V FA457HH FSD010 FA458V FA458HH RSD020 FLSTSC/FLSTSCi Springer Softail Classic 06-07 FA094 FA094V FA094HH FSD010 FA434 FA434V FA434HH RSD020 FLSTC Heritage Softail Classic 07 FA400 FA400V FA400HH FSD010 FA434 FA434V FA434HH RSD020 FLSTC Heritage Softail Classic 08-12 FA457V FA457HH FSD010 FA458V FA458HH RSD020

FLSTF Fat Boy (Solid wheel) 08-12 FA457V FA457HH FSD010 FA458V FA458HH RSD020

FLSTN Softail Deluxe (Spoke wheel) 08-12 FA457V FA457HH FSD010 FA458V FA458HH RSD020

FLS Softail Slim 12 FA457V FA457HH FSD010 FA458V FA458HH RSD020

FXCW Rocker (Cast wheel) 08-09 FA457V FA457HH FSD010 FA458V FA458HH RSD020

FXCWC Rocker C (Cast wheel) 08-11 FA457V FA457HH FSD010 FA458V FA458HH RSD020

TOURING SERIES FLT, FLHT, FLHTCI (Ultraglide®, Electraglide®, Electraglide Classic®/Ultra Classic®)

80-83 FA072* FA072V* N/A N/A FA079 FA079V N/A

84-85 FA094* FA094V* FA094HH* N/A N/A FA079 FA079V N/A

86-99 FA094* FA094V* FA094HH* FSD009 FSD009 FA201 FA201V FA201HH MD509SR FLHR, FLHRCI (Road King®, Road King Classic®)

94-99 FA094* FA094V* FA094HH* FSD009 FSD009 FA201 FA201V FA201HH MD509SR FLHRi/FLHR Road King 00-07 FA400* FA400V* FA400HH* FSD010 FSD010 Use FA400V FA400V FA400HH RSD020 FLHRCi Road King Classic 00-07 FA400* FA400V* FA400HH* FSD010 FSD010 Use FA400V FA400V FA400HH RSD020 FLHR Road King 08-12 FA409* FA409V* FA409HH* MD520 MD520 FA409 FA409V FA409HH MD521 FLHRC Road King Classic 08-12 FA409* FA409V* FA409HH* MD520 MD520 FA409 FA409V FA409HH MD521 FLHT/FLHTi Electra Glide Standard 00-07 FA400* FA400V* FA400HH* FSD010 FSD010 Use FA400V FA400V FA400HH RSD020 FLHTK Electra Glide Ultra LTD 10-12 FA409* FA409V* FA409HH* MD520 MD520 FA409 FA409V FA409HH MD521 FLTR/FLTR-i Road Glide 00-07 FA400* FA400V* FA400HH* FSD010 FSD010 Use FA400V FA400V FA400HH RSD020 FLTR Road Glide 08-09 FA409* FA409V* FA409HH* MD520 MD520 FA409 FA409V FA409HH MD521 FLTRX Road Glide Custom 10-12 FA409* FA409V* FA409HH* MD520 MD520 FA409 FA409V FA409HH MD521 FLTRU Road Glide Ultra 11-12 FA409* FA409V* FA409HH* MD520 MD520 FA409 FA409V FA409HH MD521 FLHTCU-I Electra Glide Ultra Classic 00-07 FA400* FA400V* FA400HH* FSD010 FSD010 Use FA400V FA400V FA400HH RSD020 FLHRS/FLHRSi Road King Custom 04-07 FA400* FA400V* FA400HH* FSD010 FSD010 Use FA400V FA400V FA400HH RSD020 FLHTC/FLHTCi Electra Glide Classic 04-07 FA400* FA400V* FA400HH* FSD010 FSD010 Use FA400V FA400V FA400HH RSD020 FLHTC Electra Glide Classic 08-12 FA409* FA409V* FA409HH* MD520 MD520 FA409 FA409V FA409HH MD521 FLHTCU Ultra Classic Electra Glide 08-12 FA409* FA409V* FA409HH* MD520 MD520 FA409 FA409V FA409HH MD521 FLHT Electra Glide Standard 08-10 FA409* FA409V* FA409HH* MD520 MD520 FA409 FA409V FA409HH MD521 FLHX/FLHXi Street Glide 06-07 FA400* FA400V* FA400HH* FSD010 FSD010 Use FA400V FA400V FA400HH RSD020 FLHX Street Glide 08-12 FA409* FA409V* FA409HH* MD520 MD520 FA409 FA409V FA409HH MD521 FLHTCUTG Tri Glide Ultra Classic Trike 09-12 FA409* FA409V* FA409HH* MD520 MD520 N/A* FA605/4V FA605/4HH N/A N/A FLHXXX Street Glide Trike 10-11 FA409* FA409V* FA409HH* MD520 MD520 N/A* FA605/4V FA605/4HH N/A N/A

VRSCA/VRSCB

V-Rod 02-04 FA400* FA400V* FA400HH* MD514LS MD514RS Use FA400V FA400HH FA400HH MD515 V-Rod 05-06 FA409* FA409V* FA409HH* MD516 _◆ MD516 _◆ FA409 FA409V FA409HH MD517 NOTE _◆MD516X Floating conversion in place

VRSCAW V-Rod 07 FA409* FA409V* FA409HH* MD516 _◆ MD516 _◆ FA409 FA409V FA409HH MD517 NOTE _◆MD516X Floating conversion in place

PAD/SHOE/ROTOR Applications for AMERICAN PRODUCED MOTORCYCLES

R

HH

G

D

C

LS

RS

= Right/Steel Disc.

FRONT

REAR

HARLEY DAVIDSON

®

Make / Model / Year

(4)

BRAKE

APPLICA

TIONS

17

NOTE :- Some models may have a second rotor fitted as an optional extra. Please double check with your customer exactly which side the front rotor is fitted and if twin rotor or single.

VRSCAW V-Rod (Spoke wheel) 08-09 FA409* FA409V* FA409HH* MD519 MD519 FA409 FA409V FA409HH MD517 VRSCR Street Rod 05-07 FA409* FA409V* FA409HH* MD516 ◆ MD516 ◆ FA409 FA409V FA409HH MD517 NOTE ◆MD516X Floating conversion in place

VRSCD Night Rod (Cast Wheel) 05-08 FA409* FA409V* FA409HH* MD516 ◆ MD516 ◆ FA409 FA409V FA409HH MD517 NOTE ◆MD516X Floating conversion in place

VRSCDX Night Rod Special (Cast Wheel) 07-11 FA409* FA409V* FA409HH* MD516 ◆ MD516 ◆ FA409 FA409V FA409HH MD517 NOTE ◆MD516X Floating conversion in place

VRSCX V-Rod 07 FA409* FA409V* FA409HH* MD519 MD519 FA409 FA409V FA409HH MD517

VRSCF V-Rod Muscle 08-12 FA409* FA409V* FA409HH* MD516 ◆ MD516 ◆ FA409 FA409V FA409HH MD517 NOTE ◆MD516X Floating conversion in place

BUELL

(M2 Cyclone®, S1 Lightning®,

S2 Thunderbolt®, S3 Thunderbolt®) 94-97 FA210 FA210V MD719RS FA251 MD511

(M2 Cyclone®, S1 Lightning®, S1 Whitelightning®, S3 Thunderbolt®, S3T Thunderbolt®, X1 Lightning)

(Countersunk screws fixing disc) 98-00 FA424 FA424HH MD719RS FA140 FA140V FA140HH MD511 M2 Cyclone, X1 Lightning

(Counterbored screws fixing disc) 00-05 FA424 FA424HH MD734RS FA140 FA140V FA140HH MD511

Blast 00-07 FA196 FA196V FA196HH MD735RS FA140 FA140V FA140HH N/A

Firebolt XB9R 02-07 FA345HH MD735RS FA140 FA140V FA140HH MD522

XB 9 S Lightning 03-04 FA345HH MD735RS FA140 FA140V FA140HH MD522

XB 12 S Lightning 04-08 FA345HH MD735RS FA140 FA140V FA140HH MD522

XB 9 SX Lightning CityX 05-09 FA345HH MD735RS FA140 FA140V FA140HH MD522

XB 9 SX Lightning 08-10 FA345HH MD735RS FA140 FA140V FA140HH MD522

XB 12 X Ulysses 06-10 FA345HH MD735RS FA140 FA140V FA140HH MD522

XB 12 XT Ulysses 08-10 FA345HH MD735RS FA140 FA140V FA140HH MD522

XB 12 SCG Lightning 06-08 FA345HH MD735RS FA140 FA140V FA140HH MD522

XB 12 Ss Lightning Long 06-08 FA345HH MD735RS FA140 FA140V FA140HH MD522

XB 12 Ss Lightning Long 09-10 FA454/4HH MD735RS FA140 FA140V FA140HH MD522

XB 12 STT Lightning 08 FA345HH MD735RS FA140 FA140V FA140HH MD522

XB 12 SCG Lightning 09-10 FA454/4HH MD735RS FA140 FA140V FA140HH MD522

XB 12 R Firebolt 04-08 FA345HH MD735RS FA140 FA140V FA140HH MD522

XB 12 R Firebolt 09-10 FA454/4HH MD735RS FA140 FA140V FA140HH MD522

1125 R 08-10 FA454/4HH MD735RS FA460HH N/A

1125 CR 09-10 FA454/4HH MD735RS FA460HH N/A

VICTORY

Victory “V92C” (All models single front rotor) 98-03 FA244 FA244V FA244HH MD727 FA209/2 FA209/2V FA209/2HH MD727 Victory V92SC 00-03 FA244* FA244V* FA244HH* MD727 MD727 FA209/2 FA209/2V FA209/2HH MD727 Arlen Ness Victory Vision 10-12 FA261HH* MD678 MD678 FA196 FA196V FA196HH MD678

Cross Country 10-12 FA347HH* MD678 MD678 FA196 FA196V FA196HH MD678

Cross Country Tour 12 FA347HH* MD678 MD678 FA196 FA196V FA196HH MD678

Cory Ness Cross Country 11-12 FA347HH* MD678 MD678 FA196 FA196V FA196HH MD678

Cross Roads 10-12 FA347HH* MD678 MD678 FA196 FA196V FA196HH MD678

Cory Ness Jackpot 08-10 FA347HH MD678 FA196 FA196V FA196HH MD678

Ness Signature Series 05-07 FA244 FA244V FA244HH MD678 FA209/2 FA209/2V FA209/2HH MD678 Hammer 05-07 FA244* FA244V* FA244HH* MD678 MD678 FA209/2 FA209/2V FA209/2HH MD678

Hammer 08-11 FA347HH* MD678 MD678 FA196 FA196V FA196HH MD678

Hammer 8 Ball 10-11 FA347HH* MD678 MD678 FA196 FA196V FA196HH MD678

Hammer S 07 FA244* FA244V* FA244HH* MD678 MD678 FA209/2 FA209/2V FA209/2HH MD678

Hammer S 08-12 FA347HH* MD678 MD678 FA196 FA196V FA196HH MD678

Hardball 12-13 FA347HH* MD678 MD678 FA196 FA196V FA196HH MD678

Highball 12 FA347HH* MD678 MD678 FA196 FA196V FA196HH MD678

Jackpot 10-11 FA347HH* MD678 MD678 FA196 FA196V FA196HH MD678

Judge 12-13 FA244 FA244V FA244HH N/A FA196 FA196V FA196HH N/A

PAD/SHOE/ROTOR Applications for AMERICAN PRODUCED MOTORCYCLES

R

HH

G

D

C

LS

RS

= Right/Steel Disc.

FRONT

REAR

VRSCA/VRSCB Contd

Make / Model / Year

(5)

BRAKE

APPLICA

TIONS

18

NOTE :- Some models may have a second rotor fitted as an optional extra. Please double check with your customer exactly which side the front rotor is fitted and if twin rotor or single.

King Pin 04-07 FA244 FA244V FA244HH MD678 FA209/2 FA209/2V FA209/2HH MD678

King Pin 08-12 FA347HH MD678 FA196 FA196V FA196HH MD678

King Pin Tour 04-07 FA244 FA244V FA244HH MD678 FA209/2 FA209/2V FA209/2HH MD727

Kingpin Tour 08-09 FA347HH MD678 FA196 FA196V FA196HH MD678

Kingpin 8-Ball 08-11 FA347HH MD678 FA196 FA196V FA196HH MD678

Kingpin-Low 09 FA347HH MD678 FA196 FA196V FA196HH MD678

Vegas 03-07 FA244 FA244V FA244HH MD678 FA209/2 FA209/2V FA209/2HH MD678

Vegas - 8 Ball 05-07 FA244 FA244V FA244HH MD678 FA209/2 FA209/2V FA209/2HH MD678

Vegas - 8 Ball 08-12 FA347HH MD678 FA196 FA196V FA196HH MD678

Vegas Jackpot 06-07 FA244 FA244V FA244HH MD678 FA209/2 FA209/2V FA209/2HH MD678

Vegas 08-12 FA347HH MD678 FA196 FA196V FA196HH MD678

Zach Ness Vegas 08-12 FA347HH MD678 FA196 FA196V FA196HH MD678

Vegas Low 08-09 FA347HH MD678 FA196 FA196V FA196HH MD678

Vegas Jackpot 08-09 FA347HH MD678 FA196 FA196V FA196HH MD678

Vision 8 Ball 10-11 FA261HH* MD678 MD678 FA196 FA196V FA196HH MD678

Vision Street 08-09 FA261HH* MD678 MD678 FA196 FA196V FA196HH MD678

Vision Tour (All models) 08-12 FA261HH* MD678 MD678 FA196 FA196V FA196HH MD678

INDIAN

Chief All models Chief/Deluxe/Springfield/Spirit

All models Deluxe/Springfield/Roadblaster 02-08 FA216/3 FA216/3V FA216/3HH N/A FA216/3 FA216/3V FA216/3HH N/A Scout All models Scout/Deluxe/Springfield 02-08 FA216/3 FA216/3V FA216/3HH N/A FA216/3 FA216/3V FA216/3HH N/A Road Master/Vintage 02-08 FA216/3 FA216/3V FA216/3HH N/A FA216/3 FA216/3V FA216/3HH N/A Chief Blackhawk (Brembo calipers) 11 FA095* FA095V* FA095HH* N/A N/A FA018 FA018V FA018HH N/A Chief Blackhawk Dark (Brembo calipers) 11 FA095* FA095V* FA095HH* N/A N/A FA018 FA018V FA018HH N/A Chief Classic (Brembo calipers) 11-12 FA095* FA095V* FA095HH* N/A N/A FA018 FA018V FA018HH N/A Chief Standard (Brembo calipers) 09-11 FA095* FA095V* FA095HH* N/A N/A FA018 FA018V FA018HH N/A Chief Deluxe (Brembo calipers) 09 FA095* FA095V* FA095HH* N/A N/A FA018 FA018V FA018HH N/A Chief Roadmaster (Brembo calipers) 09-11 FA095* FA095V* FA095HH* N/A N/A FA018 FA018V FA018HH N/A Chief Vintage (Brembo calipers) 09-12 FA095* FA095V* FA095HH* N/A N/A FA018 FA018V FA018HH N/A Bomber (Brembo Calipers) 10-11 FA095* FA095V* FA095HH* N/A N/A FA018 FA018V FA018HH N/A Dark Horse (Brembo calipers) 10-12 FA095* FA095V* FA095HH* N/A N/A FA018 FA018V FA018HH N/A

CAN-AM

Spyder RS SE5 08-09 FA474* FA474V* MD801 MD801 FA473 FA473V MD802

Spyder RS SM5 08-09 FA474* FA474V* MD801 MD801 FA473 FA473V MD802

Spyder RS Phantom Black 09 FA474* FA474V* MD801 MD801 FA473 FA473V MD802

Spyder RT 10-12 FA474* FA474V* MD801 MD801 FA473 FA473V MD802

Spyder RT LTD 10-12 FA474* FA474V* MD801 MD801 FA473 FA473V MD802

Spyder RT-S 10-12 FA474* FA474V* MD801 MD801 FA473 FA473V MD802

Spyder RS 10-12 FA474* FA474V* MD801 MD801 FA473 FA473V MD802

Spyder RS-S 10-12 FA474* FA474V* MD801 MD801 FA473 FA473V MD802

PAD/SHOE/ROTOR Applications for AMERICAN PRODUCED MOTORCYCLES

R

HH

G

D

C

LS

RS

= Right/Steel Disc.

FRONT

REAR

VICTORY

Make / Model / Year

(6)

JAPANESE Built Motorcycles

*-2 Sets Required. ■ - Also available in MX-S race compound, see page 4. ✘- Oversize and Supermoto disc available - see page 468. Please use the part number listed here for OS/SM discs as it may vary from the standard listing due to use of different relocation brackets.

SAFETY WARNING:- DO NOT USE HH PADS ON REAR UNLESS ALSO USED ON FRONT TO AVOID BRAKE IMBALANCE

19

BRAKE

APPLICA

TIONS

R

Suf

fix = High Durability Sintered Pad.

HH

Suf

fix = High Performance Sintered Pad.

G

Suf

fix = Grooved Shoe.

D

Suf

fix = Drilled Disc.

C

Suf

fix = Contoured Disc.

LS

Suf

fix = Left/Steel Disc.

RS

= Right/Steel Disc.

C 50 All Models 75-93 H303 H303

C 50 N (Single seat model) 95 H303 H304

C 50 P/S/V/X/Y/1/2 (Single seat model) 96-02 H303 H304

CB 50 J 81 FA040 N/A H304

CB 50 V/W Dream 50 97-98 FA197 FA197HH N/A FA131TT N/A

CD 50 ST/SV/SW/SX Benley 50 S 96-99 H304 H304

CF 50 Chaly 79 H303 H303

CHF 50-1/Scoopy 50 (Drum brake model) 01-05 H333 H333

CL 50 V/X Benley CL50 97-99 H304 H304

CR 50 RE/RF 84-85 H333 H333G H333 H333G

CRF 50 F4/F5/F6/F7/F8/F9/FA/FB/FC 04-12 H301 H301

CRM 50 RN/RP/RR/RT 93-96 FA125TT FA125R■ MD6001D H304

MB 5 S 80-82 SFA054 FA054HH N/A H304

MBX 50 SD/SF 83-85 FA086 FA086HH N/A H304

MG 50 S/X/1/3 Magna 50 (AC13-) 95-03 SFA054 FA054HH■ N/A H304

MP 50 3/DX3 (AC17) Solo 03 H304 H304 MRX 50 88- FA054TT N/A H304 MT 50 SA/SE/SG/SJ/SL 80-93 H304 H304G H304 H304G MTX 50 SC 83-84 H304 H304G H304 H304G NB 50 ME Aero 84 H301 H302 NB 50 MF/MG/TH Vision 86-88 H301 H302 NC 50 K1/Z Express 79-82 H301 H301 NC 50 C Express 2 82 H301 H302 NC 50 A/BExpress 3 Delux 82 H301 H302 NE 50 MF/MG Vision 86-87 H301 H302

NH 50 Lead 50 SS 84 SFA176 N/A H302

NH 50 Lead AF01/D716 84-85 SFA176 N/A H302

NJ 50 MDY/M2/MD2 (TD01) Gyro-X 00-02 H333 H333* NP 50 D Melody Mini 83 H301 H302 NPC 50 2/3 (AF59) Bite 02-03 H333 H333 NPS 50 1/2/3/5/6/7/8/9 (AF58) Zoomer 01-12 H333 H333 NS 50 Melody 82 H301 H302 NS 50 MSB Melody Delux 82 H301 H302

NSC 50 C - Vision 50 14” Wheels 12 SFA603 SFA603HH MD9140D H352 NSC 50 AC - Vision 50 16” Wheels 12 SFA603 SFA603HH MD9140D H352

NSR 50 FP/FR/FS 93-95 FA086 FA086HH N/A H304

NSR 50 RV/RW/RX/RY 97-00 FA197 FA197HH MD1142RS SFA131/3 SFA131/3HH MD1143

NSR 50 SK/SP/SR/SS 89-95 FA086 N/A H304

NSR 50 V (AC10-180) 97 FA197 FA197HH MD1169C/CF SFA131/3 SFA131/3HH MD1170C

NSR 50 X (AC10-190) 99 FA197 FA197HH MD1169C/CF SFA131/2 SFA131/2HH MD1170C

NT 50 F/G/H Melody Mini 85-87 H301 H301 NU 50 MC Runaway 82 H333 H302 NV 50 MSD Stream 84 H302 H302 NVS 501SH2/Today 50 01-05 H333 TBA NX 50 A/B/MB Caren 80-82 H301 H302 PA 50 Camino 80 H322 H322 PC 50 K1 79 H301 H301 PF 50 M Novio 75 H322 H322

PK 50 Wallaro All models 90-01 H333 H303

PX 50 82-83 H322 H302

PX 50 84 H322 H337

PXR 50 84 H335 H334

SA 50 J/M/P/R/S Vision Metin 88-95 H333 H333

SFX 50 S/T/V/W/X/Y/1 95-04 SFA193 SFA193HH MD906D H303

SGX 50 V/W/X/Y/1 Sky/Sky Deluxe 97-03 SFA193 SFA193HH MD931D H303

SH 50 E/H/K/M/P/DP City Express 85-96 H303 H336

SH 50 T Fifty/Scoopy W/X/Y/1 97-03 SFA193 SFA193HH MD918D H303 SJ 50 P/R/S/T/V/W/X Bali 93-99 SFA256 SFA256HH MD923D MD923C H303 SK 50 MM/MM-YA/MM-YC/MN/MN-YA/MN-YB/MP

/MP-YA/MMR/MMT (AF27) DIO Drum Front & Rear H333 H333

HONDA

Front/Avant/Vorn Frente/Anteriore Rear/Arrière/Hinten Posterior/Posteriore Sintered/ HH Pads/ Grooved shoes Semi-Sintered V-Pads™ Sintered/ HH Pads/ Grooved shoes Contour Rotor Universal left and right fitment

Contour Rotor

Rear fitment

Left/Gauche/Links Right/Droite/Rechts

Semi-Sintered V-Pads™

1 2 3 4 5 6 7 8 9 10 11

(7)

BRAKE

APPLICA

TIONS

20

SAFETY WARNING:- DO NOT USE HH PADS ON REAR UNLESS ALSO USED ON FRONT TO AVOID BRAKE IMBALANCE

Front/Avant/Vorn Frente/Anteriore Rear/Arrière/Hinten Posterior/Posteriore Sintered/ HH Pads/ Grooved shoes Semi-Sintered V-Pads™ Sintered/ HH Pads/ Grooved shoes Contour Rotor Universal left and right fitment

Contour Rotor Rear fitment Left/Gauche/Links Right/Droite/Rechts

R

Suf

HH

Suf

G

Suf

fix = Grooved Shoe.

D

Suf

fix = Drilled Disc.

C

Suf

LS

Suf

RS

= Right/Steel Disc.

SK 50 MM-II/MM-YD/MN-II/MP-II (AF28) DIO SR SFA257 MD919D H333

SK 50 MNIII/MPIII/MP-IV (AF28) DIO-ZX SFA257 MD919D H333

SK 50 MR-II/MMT-II DIO XR (AF28) SFA257 MD919D H333

SN 50 N/R/S Giorno 94 H333 H333

SS 50 ZK2 75-77 H303 H303

SS 50 ZB2 77-80 FA040 N/A H303

SRX 50 T/W/X Joker/Shadow 97-99 SFA131/3 SFA131/3HH MD931D H303

ST 50 J/K Dax 78-93 H303 H303

SXR 50 W/SW/X/SX 98-99 SFA193 SFA193HH MD906D H303

X8R-S Super Sport Scooter (SZX 50 SW/SX/SY/S1) 98-04 SFA193 SFA193HH MD920D SFA234 MD921D X8R-X Cross Sport Scooter (SZX 50 XW/XX/XY/X1) 98-04 SFA193 SFA193HH MD920D SFA234 MD921D

Tact 50 SFA257 N/A H333 H333G

TC 50 M/P/V Gyro Canopy (TA02) 96-00 H303 H333

TC 50 Y/2 (TA02) Gyro Canopy 00-02 H304 H333

TLM 50 F 85 H333 H333G H333 H333G

QR 50 D/E/F 83-87 H301 H302

QR 50 M/R/V/W/Y 93-03 H301 H333

XR 50 R1/R2/R3 01-03 H301 H301

XR 50 M5 (AD14) Motard 05 FA197 FA197HH TBA FA131TT TBA

XZ 50 1/2 APE-AC16 01-02 H304 H304

Z 50 R All Models 79-86 H301 H301

CR 60 RF/RG 85-86 H333 H333G H333 H333G

ATC 70 All Models 78-85 None H310

C 70 All Models 75-85 H303 H303 CF 70 C 77-78 H303 H303 CRF 70 F4/F5/F6/F7/F8/F9/FA/FB/FC 04-12 H333 H333G H333 H333G TRX 70 Fourtrax 86-87 H346* H346G* H306 H306G XR 70 RV/RW/RX/RY/R1/R2/R3 97-03 H333 H333G H333 H333G CRM 75 RK/RL/RM/RP/RR 89-94 FA125TT FA125R■ MD6001D MD6001C H304 H304G NF 75 79 H303 H303

NSR 75 N/P/R/X/Y (NS-1) 92-00 FA197 FA197HH MD1142RS SFA131/2 SFA131/2HH MD1143

SA 75 Vision 89- H303 H333 SH 75 Scoopy H/K/M/P/DP/S/DS 87-95 H303 H336 XR 75 K4 75-78 H304 H304G H303 H303G XR 75 K5 79 H303 H303G H303 H303G CR 80 RA/RB 80-81 H304 H304G H304 H304G CR 80 RC 82 H304 H304G H333 H333G CR 80 RD/RE 83-84 H333 H333G H333 H333G CR 80 RF 85 H333 H333G H338 H338G CR 80 R2F/R2G 85-86 H304 H304G H304 H304G CR 80 RG/RH/RJ/RK/RL/RM 86-91 FA084TT FA084R■ MD6004D H338 H338G

CR 80 RN/RP/RR/RS 92-95 FA084TT FA084R■ MD6004D FA131TT FA131R■ MD6005D MD6005C CR 80 RT/RBT/RV/RBV/RW/RBW/RX/RBX/RY/RBY

/R1/RB1/R2/RB2 96-02 FA084TT FA084R■ MD6058D✘ MD6058C✘ FA131TT FA131R■ MD6005D MD6005C CRE 80 98- FA084TT FA084R■ MD6058D✘ MD6058C✘ FA131TT FA131R■ MD6005D MD6005C

CRF 80 F4/F5/F6/F7/F8/F9/FB/FC 04-12 H333 H333G H333 H333G

MB 80 (MB8) 80- FA083/2TT N/A H304

MBX 80 FWDD/FWDF 83-86 SFA054* FA054HH* N/A N/A H304

MCX 80 82- FA083/2TT N/A H304

MTX 80 RFD/RFF 83-84 H304 H304G H304 H304G

NH 80 MD-D/MD-G 83-86 H303 H302

NH 80 Lead 80 85 SFA176 N/A H302

NH 80 Lead 80 SS 85 SFA176 N/A H333

NH 80 MDR 94- H303 H333

NSR 80 J-2/K/L/N (HC06) 88-92 FA086 FA086HH MD1169C/CF SFA131/3 SFA131/3HH MD1170C

NSR 80 P/R/S (HC06) 93-95 FA197 FA197HH MD1169C/CF SFA131/3 SFA131/3HH MD1170C

NSR 80 V (HC06-170) 97 FA197 FA197HH MD1169C/CF SFA131/3 SFA131/3HH MD1170C

NSR 80 X (HC06-180) 99 FA197 FA197HH MD1169C/CF SFA131/3 SFA131/3HH MD1170C

XR 80 Z/A/B 80-81 H304 H304G H304 H304G XR 80 R 87-88 H333 H333G H333 H333G Semi-Sintered V-Pads™ 1 2 3 4 5 6 7 8 9 10 11

HONDA Contd.

(8)

SAFETY WARNING:- DO NOT USE HH PADS ON REAR UNLESS ALSO USED ON FRONT TO AVOID BRAKE IMBALANCE

21

BRAKE

APPLICA

TIONS

R

Suf

HH

Suf

G

Suf

fix = Grooved Shoe.

D

Suf

fix = Drilled Disc.

C

Suf

LS

Suf

RS

= Right/Steel Disc.

Front/Avant/Vorn Frente/Anteriore Rear/Arrière/Hinten Posterior/Posteriore Sintered/ HH Pads/ Grooved shoes Semi-Sintered V-Pads™ Sintered/ HH Pads/ Grooved shoes Contour Rotor Universal left and right fitment

Rear fitment

1 2 3 4 5 6 7 8 9 10 11

CR 85 R3/RB3/R4/RB4/R5/RB5/R6/RB6/R7/RB7 03-07 FA084TT FA084R■ MD6058D✘ MD6058C✘ FA131TT FA131R■ MD6005D MD6005C

C 90 All Models 75-92 H303 H303

C 90 All Models 93-03 H304 H304

EZ 90 Cub 91-95 H303 H303

Lead 90 88- SFA131/3 SFA131/3HH N/A H336

NH 90 M/P/R Yuppy 91-94 SFA131/3 SFA131/3HH TBA H303

SRX 90 Shadow T/W/X 97-99 SFA131/3 SFA131/3HH MD931D H303

TRX 90 Fourtrax/Sportrax P/R/S/T/V/W/X/Y/1-6 93-06 H303* H303G* H306 H306G

TRX 90 EX 07-08 H303* H303G* H306 H306G

TRX 90 X9/XB 09-11 H303* H303G* H306 H306G

Astrea Supra NF 100 99 SFA197 FA197HH N/A H303

Astrea Grand/Supra (Drum Model) 97-98 H303 H303

CB 100 N 78-80 FA52 N/A H304

CRF 100 F4/F5/F6/F7/F8/F9/FA/FB/FC 04-12 H333 H333G H333 H333G

H 100 A/SD/SG/SJ 82-92 H303 H303

SCV 100-3/F5 Lead 03-08 H352 H352

SH 100 T/W/X/Y/1 Scoopy 96-01 SFA193 SFA193HH MD918D H303 SJ 100 T/V/W/X Bali Ex 96-99 SFA256 SFA256HH MD923D MD923C H303

XL 100 All models 78-82 H304 H304G H304 H304G

XR 100 RP/RR/RS/RT/RV/RW/RX/RY/R1-R3 93-03 H333 H333G H333 H333G

XR 100 M5 (HD13) Motard 05 FA197 FA197HH TBA FA131TT TBA

XZ 100 2 APE-HC07 02 H304 H304

ATC 110 All models 79-84 None H306 H306G

CT 110 A/B/C/D/K/M 80 - 88 H303 H304

CT 110 P 89-04 H304 H304

CT 110 X 05-09 H304 H352

NSC 110 C - Vision 50 14” Wheels 12 SFA603 SFA603HH MD9140D H352 NSC 110 AC - Vision 50 16” Wheels 12 SFA603 SFA603HH MD9140D H352 SCV 110 Lead (NHX 110-WH8

- 3 Bolt Front Disc Fixing) 08-09 SFA323 SFA323HH MD923D MD923C H352 SCV 110 Lead (NHX 110-WHA

- 4 Bolt Front Disc Fixing) 10-11 SFA323 SFA323HH MD9140D H352

ANF 125-3/5/T5/6/7/A Innova 03-11 SFA375 N/A H353

ATC 125 ME/MG 84-85 H303 H303G H306 H306G

CA 125 S/T Rebel 95-97 FA228 FA228HH MD1030 H318

CA 125 V/W/X Rebel 98-00 FA256 FA256HH MD1030 H318

CB 125 K1-K5 72-76 H308 H310 CB 125 K6/S2 76 N/A N/A H310 CB 125 S 75-79 H303 H303 CB 125 J 79 FA040 N/A H304 CB 125 T 78 FA040 N/A H310 CB 125 T2 79 FA052 N/A H310

CB 125 TDC/TDE/TDJ 83-89 FA069 FA069HH N/A H310

CB 125 RS 83 SFA054 FA054HH N/A H310

CBF 125 M9/MA/MB 09-12 FA375 MD1030 H352

CBR 125 R4/R5/RS5/RS6 (6 Bolt Front Disc Fixing) 04-06 FA375 MD644RS FA343 MD1151 CBR 125 RW7/RW8/RW9/RWA

(6 Bolt Front Disc Fixing) 07-10 FA375 MD644RS FA343 MD1151

CBR 125 RWB (5 Bolt Front Disc Fitting) 11-12 FA375 MD1166RS FA343 MD1151

CBX 125 TS Custom 82- SFA054 FA054HH N/A H310

CBX 125 F 84- FA069 FA069HH N/A H318

CBX 125 Custom 88- FA086 FA086HH N/A H304

CD 125 TC 78 H312 H310

CG125 Cargo 09-10 H352 H352

CG 125 K1/B/C/E 77-84 H303 H303

CG 125 BR-K/BR-T/95 85-97 H330 H303

CG 125 T/W/M1/1 98-03 H330 H304

CG 125-ES4-ES8 04-08 SFA054 FA054HH N/A H352

CG 125 Job 05 H352 H353

CH 125 D/E/G Spacy 84-86 H303 H303

HONDA Contd.

(9)

BRAKE

APPLICA

TIONS

22

SAFETY WARNING:- DO NOT USE HH PADS ON REAR UNLESS ALSO USED ON FRONT TO AVOID BRAKE IMBALANCE

R

Suf

HH

Suf

G

Suf

fix = Grooved Shoe.

D

Suf

fix = Drilled Disc.

C

Suf

LS

Suf

RS

= Right/Steel Disc.

CH 125 J/K/L/M/P/R/T Spacy 88-96 H303 H303

CLR 125 W City Fly 99-03 FA256 FA256HH MD1147LS H304

CM 125 CC/CF 82-85 H312 H310

CR 125 M2-M4 76-78 H304 H304G H304 H304G

CR 125 RZ/RA/RB 79-81 H324 H324G H330 H330G

CR 125 RC 82 H319 H319G H330 H330G

CR 125 RD 83 H331 H331G H331 H331G

CR 125 RE/RF 84-85 FA092TT FA092R MD6087D H331 H331G

CR 125 RG 86 FA092TT FA092R MD6087D H344 H344G

CR 125 RH/RJ 87-88 FA125TT FA125R■ MD6087D FA131TT FA131R■ MD6009D

CR 125 RK 89 FA125TT FA125R■ MD6008D FA131TT FA131R■ MD6002D

CR 125 RL/RM 90-91 FA125TT FA125R■ MD6003D FA131TT FA131R■ MD6002D

CR 125 RN/RP/RR 92-94 FA125TT FA125R■ MD6001D✘ MD6001C✘ FA131TT FA131R■ MD6002D CR 125 RS/RT/RV 95-97 FA185TT FA185R■ MD6037D✘ MD6037C✘ FA131TT FA131R■ MD6002D CR 125 RW/RX/RY/R1 98-01 FA185TT FA185R■ MD6037D✘ MD6037C✘ FA131TT FA131R■ MD6124D MD6124C CR 125 R2/R3 02-03 FA185TT FA185R■ MD6037D✘ MD6037C✘ FA346TT FA346R■ MD6191D MD6191C❹ CR 125 R4/R5/R6/R7 04-07 FA185TT FA185R■ MD6037D✘ MD6037C✘ FA346TT FA346R■ MD6191D MD6191C❹

CRM 125 RL/RM/R/RP/RR/RV/RX 90-99 FA256TT FA256HH MD1147LS FA047/3 N/A

CT 125 C 85 H304 H304

FES 125 W/Y/1/2 Pantheon 98-02 SFA281 SFA281HH MD922D MD922C H351

FES 125 3/4/5 Pantheon 03-06 SFA281 SFA281HH MD922D MD922C SFA140 SFA140HH MD1004 MD1004C FES 125 7/9/A S-Wing (Non ABS Model) 07-11 SFA388 SFA388HH MD922D MD922C SFA415 SFA415HH TBA

FES 125 A7/A9/AA S-Wing (ABS Model) 07-11 SFA388 SFA388HH MD922D MD922C SFA415 SFA415HH TBA

FS 125 Sonic 03-04 SFA086 SFA086HH N/A SFA375 N/A

LS 125 RY 00- FA086 FA086HH N/A FA197 FA197HH N/A

MBX 125 FE 84-86 FA086 FA086HH N/A H304

MTX 125 RWD 83-84 H304 H304

MTX 125 RWE/RWF/RWH/RWL 85-95 FA092TT FA092R MD6087D H304 H304G

NES 125 Y/1/2/3/4/5/6 (@ 125 Scooter) 00-06 SFA323 SFA323HH MD970D MD970C H352

NH 125 MD-D Lead 83 H303 H303

NH 125 Lead 125 86-87 SFA176 N/A H303

NS 125 FG/FH/RH 86-87 FA256 FA256HH MD1084LS H303

NSR 125 FJ/FK/FL/FM/FN 88-92 FA256 FA256HH MD1088LS FA047/3 N/A

NSR 125 RK/RL/RM/RN 89-92 FA256 FA256HH MD1088LS FA047/3 N/A

NSR 125 RR/RS/RV/RW/RX/RY/R1 93-01 FA256 FA256HH MD1109LS FA047/3 N/A

NX 125 K/S/F Transcity 89-97 FA256TT FA256HH MD1147LS H303

NXR 125 Bros ES/KS 05 H352 H353

PCX125 (WW125 EX2A- 10) 10 - 12 SFA603 SFA603HH MD9134D H352 PES 125 6/7/8/9/A(PS125) 06-09 SFA323 SFA323HH MD970D MD970C H352 PES 125 R8/R9/RA (PS125) 08-09 SFA323 SFA323HH MD970D MD970C H352 SES 125 2/3/4 Dylan 02-07 SFA323 SFA323HH MD970D MD970C H352 SH 125 1/3 (Carb/Rear drum model) 01-03 SFA323 SFA323HH MD970D MD970C H352 SH 125i 4/5/6/7/8 (Fuel Injection/Rear Drum Model) 04-08 SFA323 SFA323HH MD970D MD970C H352

SH 125i 9/A/B (Fuel Injection/Rear Disc Model) 09-12 SFA388 SFA388HH MD922D MD922C SFA415 SFA415HH MD9139D SH 125 i-D9 (Fuel Injection/Rear Drum Model) 09 SFA323 SFA323HH MD922D MD922C H352

SH125i R8 (Fuel Injection/Rear Drum Model) 08 SFA323 SFA323HH MD970D MD970C H352

SH 125i RA/RB (Fuel Injection/Rear Disc Model) 10-12 SFA388 SFA388HH MD922D MD922C SFA415 SFA415HH MD9139D SH125i S7/S8 (Fuel Injection/Rear Drum Model) 07-08 SFA323 SFA323HH MD970D MD970C H352

SL 125 KIA 76 H303 H303

SL 125 KID/E/F/G/K2A 76-80 H304 H304

TL 125 76 H304 H304G H304 H304G

TRX 125 J 88 H303* H303G* H306 H306G

VT 125 CX/CY/C2Y/C21/C1-C8 Shadow 99-08 FA197 FA197HH MD1030 H318

XL 125 K2 78 H304 H304G H304 H304G

XL 125 K3/K4 79 H303 H303G H304 H304G

XL 125 SZ/SA/SB/SC/RC 79-82 H304 H304G H304 H304G

XL 125 Paris-Dakar 85 FA256TT FA256HH N/A H303

XL 125 RF/RH 85-86 FA092TT FA092R MD6087D H304 H304G

XL 125 V1/V2/V3/V4/V5V6/V7/V8/V9/VA Varadero 01-11 FA197 FA197HH MD1150RS FA343 MD1151

XLR 125 RW 98-01 FA185TT FA185R■ MD6001D MD6001C H304 H304G Semi-Sintered V-Pads™ 1 2 3 4 5 6 7 8 9 10 11

HONDA Contd.

(10)

SAFETY WARNING:- DO NOT USE HH PADS ON REAR UNLESS ALSO USED ON FRONT TO AVOID BRAKE IMBALANCE

23

BRAKE

APPLICA

TIONS

R

Suf

HH

Suf

G

Suf

fix = Grooved Shoe.

D

Suf

fix = Drilled Disc.

C

Suf

LS

Suf

RS

= Right/Steel Disc.

Front/Avant/Vorn Frente/Anteriore Rear/Arrière/Hinten Posterior/Posteriore Sintered/ HH Pads/ Grooved shoes Semi-Sintered V-Pads™ Sintered/ HH Pads/ Grooved shoes Contour Rotor Universal left and right fitment

Rear fitment

1 2 3 4 5 6 7 8 9 10 11

XR 125 L3/L4/L5/L6/L7/L8 03-08 FA185TT FA185R■ N/A H304 H304G

CBR 150 R 00-03 FA375 MD644RS FA343 MD1151

CG 150 ESD Titan 04-05 FA054TT FA054R■ N/A H352

CG 150 KS/ES Titan 04-05 FA054TT FA054R■ N/A H352

CRF 150 F3/F4/F5/F6/F7 03-07 FA185TT FA185R■ MD6317D✘ H304 H304G

CRF 150 RB7/R7/RB8/R8/RB9/R9/RC/RBC 07-12 FA084TT FA084R■ MD6314D✘ MD6314C✘ FA346TT FA346R■ MD6316D MD6316C FES 150 W/Y/1/2 Pantheon 98-02 SFA281 SFA281HH MD922D MD922C H351

FES 150 3/4/5 Pantheon 03-06 SFA281 SFA281HH MD922D MD922C SFA140 SFA140HH MD1004 MD1004C FES 150 7/9 S-Wing (Non ABS Model) 07-09 SFA388 SFA388HH TBA SFA415 SFA415HH TBA

FES 150 A7/A9 S-Wing (ABS Model) 07-09 SFA388 SFA388HH TBA SFA415 SFA415HH TBA NES 150 Y/1/2/3/4/5/6 @ 150 Scooter 01-06 SFA323 SFA323HH MD970D MD970C H352

NSR 150 RR (Malaysian Market) FA197 FA197HH N/A FA197 FA197HH N/A

PES 150 6/7/8/9/A (PS150) 06-10 SFA323 SFA323HH MD970D MD970C H352 PES 150 R8/R9/RA (PS150) 08-11 SFA323 SFA323HH MD970D MD970C H352 SES 150 2/3/4 Dylan 02-06 SFA323 SFA323HH MD970D MD970C H352 SH 150 1/3 (CARB/Rear Drum Model) 01-03 SFA323 SFA323HH MD970D MD970C H352 SH 150i 4/5/6/7/8 (Fuel Injection/Rear Drum Model) 04-08 SFA323 SFA323HH MD970D MD970C H352

SH 150i 9/A/B(Fuel Injection/Rear Disc Model) 09-12 SFA388 SFA388HH MD922D MD922C SFA415 SFA415HH MD9139D SH 150 i-D9 (Fuel Injection/Rear Drum Model) 09 SFA323 SFA323HH MD922D MD922C H352

SH150i R8 (Fuel Injection/Rear Drum Model) 08 SFA323 SFA323HH MD970D MD970C H352

SH 150i RA/RB (Fuel Injection/Rear Disc Model) 10-12 SFA388 SFA388HH MD922D MD922C SFA415 SFA415HH MD9139D SH150i S7/S8 (Fuel Injection/Rear Drum Model) 07-08 SFA323 SFA323HH MD970D MD970C H352

CB 175 All models 74-76 H308 H309 CD 175 All models 71-78 H306 H307 ATC 185 A/SB 80-81 H303 H303G H306 H306G CD 185 T 78 H312 H310 XL 185 SZ/SA/SB 80-82 H304 H304G H304 H304G ATC 200 B/ESE/ESF/SE 81-84 H303 H303G H306 H306G

ATC 200 XD 83 FA084/2R MD6059D FA084/2R MD6059D

TRX 200 L/M/DM/DN 90-93 H345* H345G* H306 H306G

CB 200 B 76-79 N/A N/A H309

CBX 200 Strada 97-01 SFA054 FA054HH N/A H352

CD 200 TA/TB 79-80 H312 H310

CM 200 TA/TB 79-80 H312 H310

CTX 200/CTX 200 A Bushlander 04-05 FA185TT FA185R■ MD6001D MD6001C H304 H304G

MTX 200 RWD 83-84 H304 H304G H304 H304G

MTX 200 RWF 85 FA092TT FA092R MD6087D H304 H304G

TA 200 (TA Shadow) 02-05 FA197 FA197HH TBA TBA FA197 FA197HH N/A

TL 200 J/Y Colin Seeley 76-78 H304 H304G H304 H304G

TLR 200 D/E 83-85 H333 H333G H333 H333G

TLR 200 G/H 86-87 H304 H304G H333 H333G

TRX 200 L/M 90-91 H345* H345G* H306 H306G

TRX 200 D 91-97 H345* H345G* H306 H306G

TRX 200 SX 86-87 H345* H345G* H306 H306G

XL 200 L 85 FA256TT FA256HH N/A H303

XL 200 R 85 FA092TT FA092R N/A H303

XR 200 80-84 H304 H304G H304 H304G

XR 200 R 81-83 H304 H304G H304 H304G

XR 200 R 84-85 H304 H304G H304 H304G

XR 200 R 86-02 H304 H304G H304 H304G

FTR 223 Y/2/A2 (MC34) 00-02 FA092TT FA092R TBA H352

CRF 230 F4/F5/F6/F7/F8/F9 04-09 FA185TT FA185R■ MD6001D✘ MD6001C✘ H304 H304G

CRF 230 L 08-10 FA185TT FA185R■ MD6001D✘ MD6001C✘ FA131TT FA131R■ MD6013D MD6013C CRF 230 M (Supermoto) 09-10 FA185TT FA185R■ MD6001D✘ MD6001C✘ FA131TT FA131R■ MD6013D MD6013C SL 230 Free Landsports (MD33) V/W/X/1 97-01 FA185TT FA185R■ MD6001D MD6001C FA131TT FA131R■ MD6013D MD6013C

XL 230 2 (MC36) 02 H352 H352

ATC 250 RB 81 FA054TT FA054R■ MD6060D H306 H306G

ATC 250 RC 82 FA084TT FA084R■ MD6060D H306 H306G

ATC 250 RD 83-84 FA084TT FA084R■ MD6059D FA084TT FA084R■ MD6059D

ATC 250 RF/RG 85-86 FA092TT FA092R MD6059D FA092TT FA092R MD6007D

HONDA Contd.

(11)

BRAKE

APPLICA

TIONS

24

SAFETY WARNING:- DO NOT USE HH PADS ON REAR UNLESS ALSO USED ON FRONT TO AVOID BRAKE IMBALANCE

R

Suf

HH

Suf

G

Suf

fix = Grooved Shoe.

D

Suf

fix = Drilled Disc.

C

Suf

LS

Suf

RS

= Right/Steel Disc.

ATC 250 ESF/ESG/ESH/ESJ 85-88 H306 H306G H315 H315G

AX-1 (NX 250 J/K/R/R3) 89-94 FA125TT FA125R■ MD6001D MD6001C FA153 MD6198D

CB 250 K3-K5 73-75 H314 H315

CB 250 G5 75 FA013 N/A H315

CB 250 T 78 FA045 N/A H313

CB 250 N/NA/NB/NDB/NDC 78-82 FA045 MD1036LS H313

CB 250 RSA/RSD 81-84 FA045 N/A H309

CB 250 FT/FV/FX/FY/F1 Hornet 96-01 FA187 FA187HH MD1144RS FA140 FA140V FA140HH MD1004 MD1004C CB 250 N/T/W/X/Y/1/4 Two Fifty 92-05 FA196 FA196HH MD1089LS H310

CBF 250 4/6 04-06 FA197 FA197HH MD1166RS H352

CBR 250 FG/FGYA (MC14) 86 FA121* FA121HH* MD1006 MD1006 MD1006C* H309

CBR 250 RH (MC17) 87 FA121* FA121HH* MD1006 MD1006 MD1006C* FA140 FA140V FA140HH MD1002 CBR 250 RJ/RK/RK2 (MC19) 88-89 FA142 FA142HH MD1140RS FA140 FA140V FA140HH MD1002 CBR 250 RRL/RRN/RRR (MC22) 90-94 FA142* FA142HH* MD1145LS MD1145RS FA140 FA140V FA140HH MD1004 MD1004C CBR 250 RB (Non ABS Model) 11-12 FA142 FA142HH MD1180X FA496 FA496HH MD1004

CBR 250 RAB (ABS Model) 11-12 FA388 FA388HH MD1180X FA496 FA496HH MD1181

CBX 250 RSE 84 FA069 FA069HH MD1090LS H318

CBX 250 Twister TBA H352

CBX 250 84-98 FA086 FA086HH MD1030 H304

CD 250 UJ 88-92 FA124/2 FA124/2HH MD1090LS H310

CH 250 F/G Spacy 85-86 SFA323/2 SFA323/2HH MD913D H341

CJ 250 T 77 FA013 N/A H315

C 250 SC 81 H312 H309

CM 250 TB 81 FA045 MD1036LS H313

CMX 250 CT Rebel (Nissin Caliper) 96 FA228 FA228HH MD1030 H318 CMX 250 CV/CW/CX Rebel (Grimeca Caliper) 97-00 FA256 FA256HH MD1030 H318 CN 250 H/J/K/L/M/P/R/S/T/V/X Spazio/Helix 87-98 FA069/2 MD908D H350 CN 250 3 (MF02) Fusion/Fusion X/Fusion X Special 03 SFA196 SFA196HH MD908D H350

CR 250 RZ/RA 79-80 H324 H324G H325 H325G

CR 250 RB 81 H327 H327G H330 H330G

CR 250 RC/RD 82-83 H328 H328G H331 H331G

CR 250 RN/RP/RR 92-94 FA125TT FA125R■ MD6001D✘ MD6001C✘ FA131TT FA131R■ MD6002D CR 250 RS/RT 95-96 FA185TT FA185R■ MD6037D✘ MD6037C✘ FA131TT FA131R■ MD6002D CR 250 RV/RW/RX/RY/R1 97-01 FA185TT FA185R■ MD6037D✘ MD6037C✘ FA131TT FA131R■ MD6124D MD6124C CR 250 R2/R3 02-03 FA185TT FA185R■ MD6037D✘ MD6037C✘ FA346TT FA346R■ MD6191D MD6191C◆ CR 250 R4/R5/R6/R7 04-07 FA185TT FA185R■ MD6037D✘ MD6037C✘ FA346TT FA346R■ MD6191D MD6191C◆

CRF 250 LC 12 FA465TT TBA FA346TT FA346R■ TBA

CRF 250 R4/R5/R6/R7 04-07 FA185TT FA185R■ MD6037D✘ MD6037C✘ FA346TT FA346R■ MD6191D MD6191C◆ CRF 250 R8/R9/RA/RB/RC 08-12 FA185TT FA185R■ MD6037C✘ FA346TT FA346R■ MD6191C◆ CRF 250 X4/X5/X6/X7 04-07 FA185TT FA185R■ MD6037D✘ MD6037C✘ FA346TT FA346R■ MD6191D MD6191C◆

CRF 250 X8/X9/XB/XC 08-12 FA185TT FA185R■ MD6037C✘ FA346TT FA346R■ MD6191C◆

CRM 250 R (RK) MK1 MD24 (100001-1008385) 89-90 FA125TT FA125R■ MD6087D FA153 MD6165D CRM 250 R (RM) MK2 MD24 (1200001-1211634) 91-92 FA125TT FA125R■ MD6001D✘ MD6001C✘ FA131TT FA131R■ MD6013D MD6013C CRM 250 R (RP/RP-II) MK2/2 MD24 (1300001-) 93 FA125TT FA125R■ MD6001D✘ MD6001C✘ FA131TT FA131R■ MD6013D MD6013C CRM 250 (MD24) 140 (MK3) RR-RR-II 94-96 FA185TT FA185R■ MD6001D✘ MD6001C✘ FA131TT FA131R■ MD6013D MD6013C CRM 250 ARV/ARW Active Radical (MD32) 97-98 FA185TT FA185R■ MD6001D✘ MD6001C✘ FA131TT FA131R■ MD6013D MD6013C FES 250 W/X Foresight 98-99 SFA281 SFA281HH MD922D MD922C H351

FES 250 Y/1/2/5 Foresight 00-05 SFA281 SFA281HH MD922D MD922C SFA140 SFA140HH MD1004 MD1004C FES 250 Y/1/2/5 Foresight Note

- Brake shoes (Parking) 00-05 H351

FL 250 Odyssey 77-84 FA040 N/A H306 H306G

GB 250 E/H Clubman (MC10 101-110) 84-87 FA069/2 TBA H318

GB 250 J/L/P/S/V Clubman (MC 10-120-150) 89-97 FA124/2 FA124/2HH TBA H318

MXV 250 F (MC92) 83-88 FA080/2 N/A H315

NS 250 FE/RE (MCII-100) 84 FA069/2* MD1006 MD1006 MD1006C* FA069/3 FA069/3V MD1002

1 2 3 4 5 6 7 8 9 10 11

HONDA Contd.

(12)

SAFETY WARNING:- DO NOT USE HH PADS ON REAR UNLESS ALSO USED ON FRONT TO AVOID BRAKE IMBALANCE

25

BRAKE

APPLICA

TIONS

R

Suf

HH

Suf

G

Suf

fix = Grooved Shoe.

D

Suf

fix = Drilled Disc.

C

Suf

LS

Suf

RS

= Right/Steel Disc.

Front/Avant/Vorn Frente/Anteriore Rear/Arrière/Hinten Posterior/Posteriore Sintered/ HH Pads/ Grooved shoes Semi-Sintered V-Pads™ Sintered/ HH Pads/ Grooved shoes Contour Rotor Universal left and right fitment

Rear fitment

1 2 3 4 5 6 7 8 9 10 11

NS 250 RG (MCII-102) 86 FA069/2* MD1006 MD1006 MD1006C* FA069/3 FA069/3V MD1002 NSR 250 RG (MC16-100) 86 FA121* FA121HH* MD1129LS MD1129RS FA069/3 FA069/3V FA069/3HH MD1002 NSR 250 R2J0MC18-100) R4J (MC18-100) 88 FA187* FA187HH* MD1117LS MD1117RS FA140 FA140V FA140HH MD1002 NSR 250 R5K/R5K-2 (MC18-110) 89 FA187* FA187HH* MD1117LS MD1117RS FA140 FA140V FA140HH MD1002 NSR 250 R6K/R6K-2 (MC18-110) 89 FA187* FA187HH* MD1117LS MD1117RS FA140 FA140V FA140HH MD1002 NSR 250 R7L/R7N (MC21-106) 90 FA187* FA187HH* MD1117LS MD1117RS FA140 FA140V FA140HH MD1002 NSR 250 R8L-3 (MC21-101) R9L (MC21-102)

R8N/R8N-3 (MC21-106) 90-92 FA187* FA187HH* MD1117LS MD1117RS FA140 FA140V FA140HH MD1002 NSR 250 R9N (MC21-106) 92 FA187* FA187HH* MD1117LS MD1117RS FA140 FA140V FA140HH MD1002

NSR 250 RR (MC28-100) 94 FA187* FA187HH* MD1117LS MD1117RS FA143 MD1111

NSR 250 R2R/R3R (MC28-110) R2T/R3T (MC28-120) 94 FA187* FA187HH* MD1117LS MD1117RS FA143 MD1111 NSS 250 Y/AY/1/A1/A3/3 Forza/Forza-ST/S/T/Jazz

/Reflex (MF04/MF06) 00-04 SFA281 SFA281HH MD922D MD922C SFA358 SFA358HH MD1004 MD1004C NSS 250 EX5/EX6 Forza EX (ABS) 05-06 SFA388 SFA388HH MD922D MD922C SFA415 SFA415HH MD1020 MD1020C NSS 250 EX5/EX6 Forza EX (ABS) Parking brake 05-06 H333

NSS 250 AX5/AX6 Forza Z (ABS) 05-06 SFA388 SFA388HH MD922D MD922C SFA415 SFA415HH MD1020 MD1020C NSS 250 AX5/AX6 Forza Z (ABS) Parking brake 05-06 H333

NSS 250 8/9 Forza X 08-09 SFA388 SFA388HH TBA SFA415 SFA415HH TBA

NSS 250 A8/A9 Forza EX ABS 08-09 SFA388 SFA388HH TBA SFA415 SFA415HH TBA

NX 250 J/K (MD21) 87-90 FA125TT FA125R■ MD6008D H323 H323G

NX 250 2L/M/P/2P (MD25) 90-93 FA125TT FA125R■ MD6001D MD6001C H323 H323G PS 250 5/6 Big Ruckus 05-06 SFA388 SFA388HH MD922D MD922C H351

RTL 250 SG 86 H304 H304G H304 H304G

TL 250 K1 79 H304 H304G H304 H304G

TLR 250 F 85 H304 H304G H304 H304G

TLM 250 RJ 89 H304 H304G H304 H304G

TRX 250 F/G/H 85-87 H339* H339G* H315 H315G

TRX 250 RG/RH 86-87 FA125TT* FA125R*■ MD6046D MD6046D FA092TT FA092R MD6007D TRX 250 RJ/RK 88-89 FA125TT* FA125R*■ MD6006D MD6006D FA092TT FA092R MD6007D TRX 250 V/W/X/Y/1/TE2-9/TEA/TEB/TEC//TM2-9

/TMA/TMB/TMC Re Con/ES 97-12 H345* H345G* H340 H340G

TRX 250 EX1/2/3/4/5/6/7/8 01-08 FA084TT* FA084R*■ MD6006D MD6006D H340 H340G

TRX 250 X9/XA/XB 09-11 FA084TT* FA084R*■ MD6006D MD6006D H340 H340G

VT 250 FL Spada/Castel 88-90 FA142 FA142HH TBA FA140 FA140V FA140HH MD1002

XL 250 K3/K4 78-79 H311 H311G H312 H312G

XL 250 S/SZ/SA 78-81 H312 H312G H323 H323G

XL 250 SB 82 H312 H312G H318 H318G

XL 250 RE/RF 84-85 H330 H330G H323 H323G

XL 250 RC 82 H330 H330G H323 H323G

XL 250 RL 90 FA125TT FA125R■ MD6001D MD6001C FA131TT FA131R■ MD6013D MD6013C

XL 250 Degree (MD26) FA185TT FA185R■ MD6001D MD6001C H323 H323G

XR 250 SZ/SA 79-80 H312 H312G H323 H323G

XR 250 RB/RC/RD 81-83 H327 H327G H323 H323G

XR 250 RE/RF 84-85 FA092TT FA092R MD6001D MD6001C H304 H304G

XR 250 RG/RH 86-87 FA092TT FA092R MD6087D H304 H304G

XR 250 RJ/RK 88-89 FA125TT FA125R■ MD6087D H304 H304G

XR 250 RL 90 FA125TT FA125R■ MD6087D FA131TT FA131R■ MD6013D MD6013C

XR 250 RM/RN/RP/RR/RS 91-95 FA125TT FA125R■ MD6001D✘ MD6001C✘ FA131TT FA131R■ MD6013D MD6013C XR 250 RT/RV/RW/RX/RY/R1/R2/R3/R4 96-04 FA185TT FA185R■ MD6001D✘ MD6001C✘ FA131TT FA131R■ MD6013D MD6013C XR 250 Y/3 (MD30) 00-03 FA185TT FA185R■ MD6001D MD6001C FA131TT FA131R■ MD6013D MD6013C XR 250 3/5 (MD30) Motard 03-05 FA185TT FA185R■ MD6001D MD6001C FA131TT FA131R■ MD6013D MD6013C

XR 250 Tornado 05 TBA TBA H352

XR 250 III Y/3 Baja 00-03 FA185TT FA185R■ MD6001D MD6001C FA131TT FA131R■ MD6013D MD6013C XLR 250 Baja MK1 RF/R2F/RH (MD22) FA092TT FA092R MD6001D MD6001C H323 H323G

XLR 250 Baja MK2 R3 (MD22) FA185TT FA185R■ MD6001D MD6001C FA153 MD6013D MD6013C XLR 250 R/R3J/RK/RL/R3L/R3M/RN (MD22) 88-90 FA092TT FA092R MD6087D FA153 MD6013D MD6013C XLR 250 RM/R3N/RP/RR/R3R (MD22) 91- FA185TT FA185R■ MD6001D MD6001C FA131TT FA131R■ MD6013D MD6013C

VT 250 FD 83 FA080/2 N/A H309

VT 250 CR/CT/CV Magna 95-97 FA196 FA196HH MD1021LS H321

VTR 250 W/Y/1-7 (MC33) 98-07 FA196 FA196HH MD1144RS FA140 FA140V FA140HH MD1004 MD1004C

HONDA Contd.

(13)

BRAKE

APPLICA

TIONS

26

SAFETY WARNING:- DO NOT USE HH PADS ON REAR UNLESS ALSO USED ON FRONT TO AVOID BRAKE IMBALANCE

R

Suf

HH

Suf

G

Suf

fix = Grooved Shoe.

D

Suf

fix = Drilled Disc.

C

Suf

LS

Suf

RS

= Right/Steel Disc.

VTR 250 9 09-10 FA196 FA196HH TBA FA140 FA140V FA140HH TBA

VTZ 250 H/J/K 86-88 FA124/2 FA124/2HH TBA H309

CB 300 R10 10 FA197 FA197HH MD1166RS H352

SH 300i 7/8/9/A/B (Non ABS Model) 07-12 SFA388 SFA388HH MD9118D SFA415 SFA415HH MD9119D SH 300i A7/A8/A9/AA/AB (ABS Model) 07-12 SFA388 SFA388HH MD9118D SFA415 SFA415HH MD9119D SH 300i R8/R9/RA (Non ABS Model) 08-10 SFA388 SFA388HH MD9118D SFA415 SFA415HH MD9119D SH 300i AR8/AR9/ARA (ABS Model) 08-10 SFA388 SFA388HH MD9118D SFA415 SFA415HH MD9119D

TRX 300 J/K/L/T/V/W/X/Y (2WD) 88-00 H345* H345G* H315 H315G

TRX 300 FWJ/K/L/T/V/W/X/Y (4WD) 88-00 H347* H347G* H315 H315G

TRX 300 EX P/R/S/T/V/W/X/Y/1-8 93-08 FA084TT* FA084R*■ MD6006D MD6006D FA084TT FA084R■ MD6064D

TRX 300 X9 09 FA084TT* FA084R*■ MD6006D MD6006D FA084TT FA084R■ MD6064D

XR 300 R10 10 FA185TT FA185R■ MD6010D FA131TT FA131R■ MD6013D

CB 350 K4 74 H314 H315

CB 350 SG/SJ 86-90 FA121* FA121HH* MD1005LS MD1005RS H313

FL 350 R Odyssey 85-87 H339* H339G* FA111 FA111R N/A

TRX 350 G/H/J/K/L/M/N 86-93 H342* H342G* H343 H343G

TRX 350 Rancher ES 4x4/2x4 (FMY/1/2/3)

/Rancher 4x4 & 2x4 (FEY/1/2/3) 00-03 H347S* H347SG* H351 H351G

XR 350 RD 83 H331 H331G H304 H304G

XR 350 RE 84 FA092TT FA092R MD6087D H304 H304G

CB 360 G5 75 FA013 N/A H315

CJ 360 T 78 FA013 N/A H315

CB-1 (CB 400 F) 89-90 FA142 FA142HH MD1038RS FA140 FA140V FA140HH MD1020

CB 400 SF (F2N/F2R/F2S/F2T/F3S)

Superfour (NC31) 92-95 FA142* FA142HH* MD1132 MD1132 MD1132C* FA140 FA140V FA140HH MD1020 MD1020C CB 400 SF (F2V/F3T) Superfour (NC31) 96-97 FA187* FA187HH* MD1132 MD1132 MD1132C* FA140 FA140V FA140HH MD1020 MD1020C CB 400 SF (F3V) Superfour (NC31) 97 FA244* FA244HH* MD1132 MD1132 MD1132C* FA140 FA140V FA140HH MD1020 MD1020C

CB 400 F/F1/F2 75-79 FA013 N/A H315

CB 400 A Honda-Matic 79 FA045 N/A H313

CB 400 T 78 FA045 N/A H313

CB 400 N/NA/NB 78-81 FA030* N/A N/A H313

CB 400 NC 82 FA069/2* N/A N/A H313

CB 400 Four V/V-II/W/W-II (NC36) 97-98 FA142* FA142HH* TBA TBA FA140 FA140V FA140HH MD1020 CB 400 SFX/SFY/SF1/SF2/SF3 Superfour

(NC39 - Superfour/Superfour Bol Dor) 99-03 FA296HH* TBA TBA FA254 FA254HH TBA

CB 400 SS (SS2-NC41) 02 FA196 FA196HH TBA H351

CB 400 SF4/5/S5 (NC39 - Superfour/Superfour Bol Dor) 04-05 FA296HH* TBA TBA FA174 FA174V FA174HH TBA CBR 400 RG (NC23) 100 86 FA121* FA121HH* MD1001 MD1001 FA069/3 FA069/3V FA069/3HH MD1002 CBR 400 RH-YA (NC23) 101 86 FA121* FA121HH* MD1001 MD1001 FA069/3 FA069/3V FA069/3HH MD1002 CBR 400 RRJ/RRK (NC23) Tri -Arm (102/109) 87-89 FA142* FA142HH* MD1003X MD1003X MD1003XC* FA140 FA140V FA140HH MD1002

CBR 400 RRL/RRN/RRR (NC29) Gull Arm 90-94 FA142* FA142HH* MD1003X MD1003X MD1003XC* FA140 FA140V FA140HH MD1004 MD1004C FJS 400 Silverwing D6/D7/D8

Non ABS 256mm front disc 06-08 SFA281 SFA281HH MD1006 SFA196 FA196HH MD1149 FJS 400 Silverwing D6/D7/D8 Non ABS 256mm

front disc Parking brake: 06-08 SFA257/2

FL 400 R RK/RL Pilot 89-93 H339* H339G* FA111 FA111R MD6144D

NS 400 RF/RG 85-87 FA069* FA069HH* MD1006 MD1006 MD1006C* FA069 FA069V FA069HH MD1002

NT 400 Bros (NC25) FA187 FA187HH MD1124LS FA140 FA140V FA140HH MD1022

NV 400 CJ/CK Steed 92-93 FA124/2 FA124/2HH TBA H321

NV 400 CS/CV Steed 95-97 FA142 FA142HH TBA H321

NV 400 DCY/DC1/DC2 (NC40) Shadow Slasher 00-02 FA196 FA196HH MD1159 H343

NX 4 Falcon 02-05 FA185TT FA185R■ TBA FA131TT FA131R■ MD1004

RVF 400 RR/RR-II/RT/RT-II (NC35) 94-96 FA187* FA187HH* MD1003X MD1003X MD1003XC* FA143 MD1111

SW-T 400 (FJS400D9) 09 SFA388 SFA388HH MD1172LS SFA196 SFA196HH MD1149

SW-T 400 (FJS400D9) Parking Brake 09 SFA257/2

SW-T 400 (FJS400A9/AB) 09-12 SFA388 SFA388HH MD1172LS SFA196 SFA196HH MD1149 SW-T 400 (FJS400A9/AB) Parking Brake 09-12 SFA257/2

TRX 400 FWS/T/V/W/X/Y 95-00 H347* H347G* H351 H351G

TRX 400 EXX/EXY/EX1-EX8 99-08 FA084TT* FA084R*■ MD6006D MD6006D FA084TT FA084R MD6164D

TRX 400 FA4/5/6/7 Fourtrax AT 04-07 H347* H347G* H351 H351G Semi-Sintered V-Pads™ 1 2 3 4 5 6 7 8 9 10 11

HONDA Contd.

(14)

SAFETY WARNING:- DO NOT USE HH PADS ON REAR UNLESS ALSO USED ON FRONT TO AVOID BRAKE IMBALANCE

27

BRAKE

APPLICA

TIONS

R

Suf

HH

Suf

G

Suf

fix = Grooved Shoe.

D

Suf

fix = Drilled Disc.

C

Suf

LS

Suf

RS

= Right/Steel Disc.

Front/Avant/Vorn Frente/Anteriore Rear/Arrière/Hinten Posterior/Posteriore Sintered/ HH Pads/ Grooved shoes Semi-Sintered V-Pads™ Sintered/ HH Pads/ Grooved shoes Contour Rotor Universal left and right fitment

Rear fitment

1 2 3 4 5 6 7 8 9 10 11

HONDA Contd.

TRX 400 FGA4/5/6/7 Fourtrax Rancher at Gscape 04-07 H347* H347G* H351 H351G

TRX 400 X9 09 FA084TT* FA084R*■ MD6006D MD6006D FA084TT FA084R MD6164D

VF 400 FD 83-85 FA080/2 N/A FA080/2 N/A

VFR 400 ZG/ZH/RG/RG-YA (NC21) 85-87 FA121* FA121HH* MD1006 MD1006 MD1006C* FA069/3 FA069/3V FA069/3HH MD1002 VFR 400 RH2/RJ (NC24) 87-88 FA121* FA121HH* MD1001 MD1001 FA140 FA140V FA140HH MD1022 VFR 400 R3K/R3N (NC30) 89-92 FA187* FA187HH* MD1003X MD1003X MD1003XC* FA143 MD1111 VFR 400 R3L/R3M (NC30) 90-91 FA187* FA187HH* MD1003X MD1003X MD1003XC* FA143 MD1111

VRX 400 T (NC33) 96 FA196 FA196HH TBA FA174 FA174V FA174HH TBA

XL 400 R 82 H332 H332G H318 H318G

XR 400 RT/RV/RW/RX/RY/R1/R2/R3/R4 96-04 FA185TT FA185R■ MD6001D✘ MD6001C✘ FA131TT FA131R■ MD6013D MD6013C XR 400 M Supermotard (ND08/NC38E) 06-08 FA142 FA142HH TBA FA131TT FA131R■ TBA

TRX 420 FE7/FE8/FE9/FEA/FEB 4WD - Fourtrax ES 07-11 FA084TT* FA084R*■ MD6302D MD6302D H351 H351G TRX 420 FM7/FM8/FM9/FMA/FMB 4WD Fourtrax Auto 07-11 FA084TT* FA084R*■ MD6302D MD6302D H351 H351G TRX 420 FPA9/FPAA/FPAB Fourtrax

- Auto - Power Steering 09-11 FA084TT* FA084R*■ MD6302D MD6302D FA373TT FA373R MD6217D TRX 420 FA9/FAA/FAB Fourtrax Auto 4WD 09-11 FA084TT* FA084R*■ MD6302D MD6302D FA373TT FA373R MD6217D TRX 420 FPM9/FPMA/FPMB Fourtrax - 4WD

- Power Steering 09-11 FA084TT* FA084R*■ MD6302D MD6302D H351 H351G TRX 420 TE7/TE8/TE9 Fourtrax ES - 2WD 07-09 FA084TT* FA084R*■ MD6302D MD6302D H351 H351G TRX 420 TM7/TM8/TM9/TMA/TMB 07-11 FA084TT* FA084R*■ MD6302D MD6302D H351 H351G CB 450 SG/SJ 86-88 FA121* FA121HH* MD1005LS MD1005RS H313

CB 450 DX-K 89-92 FA122* N/A N/A FA122 N/A

CMX 450 CH/CJ Rebel 87-88 FA069 FA069HH MD1041LS H313

CR 450 RB 81 H327 H327G H319 H319G

CRF 450 R2/R3 02-03 FA185TT FA185R■ MD6037D✘ MD6037C✘ FA346TT FA346R■ MD6191D MD6191C◆ CRF 450 R4/R5/R6/R7 04-07 FA185TT FA185R■ MD6037D✘ MD6037C✘ FA346TT FA346R■ MD6191D MD6191C◆ CRF 450 R8/R9/RA/RB/RC 08-12 FA185TT FA185R■ MD6037C✘ FA346TT FA346R■ MD6191C◆ CRF 450 X5/X6/X7 05-07 FA185TT FA185R■ MD6037D✘ MD6037C✘ FA346TT FA346R■ MD6191D MD6191C◆

CRF 450 X8/X9/XB/XC 08-12 FA185TT FA185R■ MD6037C✘ FA346TT FA346R■ MD6191C◆

TRX 450 ESW/ESX/ESY/ES1 98-01 H347S* H347SG* H351 H351G

TRX 450 R4/R5/R6/ER6/R7/ER7/R8/ER8/R9/ER9 04-09 FA185TT* FA185R*■ MD6006D MD6006D FA373TT FA373R MD6233D

CR 480 RC 82 H327 H327G H330 H330G

CR 480 RD 83 H328 H328G H331 H331G

CB 500 T 75-77 FA013 N/A H316

CB 500 K1/K2/F 75-77 FA013 N/A H316

CB 500 R/T 94-96 FA196 FA196HH MD1008 H321

CB 500 V/W/SW/X/SX/Y/SY/2/S2 97-03 FA209/2 FA209/2HH MD1008 FA213 FA213HH MD1020 CBF 500 A4/A5/A6/A7 (ABS Model) 04-07 FA388 FA388HH MD1155RS FA174 FA174V FA174HH MD1156 CBF 500 4 (Non ABS Model) 04 FA196 FA196HH MD1155RS FA174 FA174V FA174HH MD1156 CBR 500 FH/FJ/FK/FL 87-90 FA121* FA121HH* MD1001 MD1001 FA069/3 FA069/3V FA069/3HH MD1002

CR 500 RN/RP/RR 92-94 FA125TT FA125R■ MD6001D✘ MD6001C✘ FA131TT FA131R■ MD6002D CR 500 RS/RT/RV/RW/RX/RY/R1 95-01 FA185TT FA185R■ MD6037D✘ MD6037C✘ FA131TT FA131R■ MD6002D

CX 500 CA/CB/Z/A/B 79-81 FA029* N/A N/A H321

CX 500 CC 82 FA069* FA069HH* N/A N/A H321

CX 500 EC 82 FA069* FA069HH* MD1036LS MD1036RS FA069 FA069V FA069HH N/A

FT 500 C 82 FA069 FA069HH MD1131LS FA069 FA069V FA069HH MD1048

GL 500 DC 82 FA069 FA069HH N/A N/A H321

CX 500 TCC Turbo 83 FA069* FA069HH* N/A N/A FA069 FA069V FA069HH N/A

NX 500 J/K/L/M Dominator 88-91 FA124/2 FA124/2HH MD6010D FA140 FA140HH MD6013D

NX 500 N/P/R/S/T 92-96 FA124/2 FA124/2HH MD6010D FA140 FA140HH MD6099D

NX 500 V/W/X Dominator 97-99 FA209/2 FA209/2HH MD6010D FA213 FA213HH MD6099D TRX 500 FA1/FA2/FA3/FA4/FA5/FA6/FA7/FA8/FA9

/FAA/FAB Fourtrax Foreman - Auto 01-04 H347* H347G* H343 H343G

TRX 500 FA5/FA6/FA7/FA8/FA9/FAA/FAB

Fourtrax Foreman - Auto 05-11 FA410TT* FA410R* MD6251D MD6251D H343 H343G 019-064 Jap Built Apps 2012 Intl MC_UK 15/03/2012 16:30 Page 27

(15)

BRAKE

APPLICA

TIONS

28

SAFETY WARNING:- DO NOT USE HH PADS ON REAR UNLESS ALSO USED ON FRONT TO AVOID BRAKE IMBALANCE

Front/Avant/Vorn Frente/Anteriore Rear/Arrière/Hinten Posterior/Posteriore Sintered/ HH Pads/ Grooved shoes Semi-Sintered V-Pads™ Sintered/ HH Pads/ Grooved shoes Conto
