Sawdust
from the editor
WS229_002.indd 2
No. 229 February/March 2017
contents
Woodsmith.com • 324
42
36
30
Projects
weekend project
Unique Routed Bowl Jig . . . .18
Want to make a bowl but don’t have a lathe? No problem. By
building a simple router jig and templates, you can accurately
shape the inside and outside curves of a solid-wood bowl.
shop project
Ultimate Outfeed Table . . . .24
Breaking down sheet goods is a challenge. This mobile table saw
lift minimizes the hassle by making it a snap to do it quickly and
safely. Plus, it provides storage and an extra worksurface.
designer project
Knock-Down Shelving System . . . .30
Contrasting materials and a stylish design give this shelving
system a great look. But the hardware-free, knock-down design
means you can easily move it and set it up in minutes.
shop project
Heavy-Duty Shop Workstation . . . .36
No matter what the task at hand is, this workstation can be
set up or taken down in minutes. Optional accessories provide
expanded capability to make it even more versatile.
heirloom project
Classic Card Catalog Cabinet . . . .42
The classic appearance of a card catalog is unmistakable.
While this one looks traditional, there’s a secret — extra-wide
drawers that provide more useful storage to meet your needs.
WS229_002.indd 3
4 • Woodsmith / No. 229
14
12
Departments
from our readers
Tips & Techniques . . . 5
all about
Latches & Catches . . . 10
router workshop
Custom Carved Panels . . . 12
great gear
Powermatic Tenoning Jig . . . 14
woodworking technique
Flattening a Board . . . 16
woodworking technique
Pocket Hole Joinery Basics . . . 52
working with tools
5 Drill Press Mistakes to Avoid . . 56
in the shop
Our Favorite Cordless Tools . . . 58
woodworking essentials
Brushing on a Finish . . . 60
mastering the table saw
Cutting Sheet Goods. . . 62
tips from our shop
Shop Notes . . . 64
questions & answers
Choosing the Right Bit . . . 66
52
60
WS229_004.indd 4
Woodsmith.com • 5
from our
readers
Tips &
Techniques
Double-Duty Drawers
Large, deep drawers in cabinets seem to waste a lot of space. In the past, I would just dump loosely associated tools into one of these drawers, only to spend time rooting around in the drawer looking for the item I needed later. That item, of course, was underneath everything else.
It occurred to me that I could reclaim some of this dead space by adding a pair of slide-out trays to the top of the exist-ing drawer box. As the photo shows, this is done by flipping the direction of these additional trays and slides.
I started by cutting a pair of notches in the sides of the drawer and sanding the opening smooth. Then, as the draw-ings show, I built a pair of trays that open to the sides. This gives you maximum control over the space you have avail-able. When sizing the parts of each tray, remember to account for the thickness of the drawer slides.
Fred Adams Henderson, New York
Simply send us your favorite shop tips. If your tip or technique is selected as the featured reader’s tip, you’ll win a Forrest Woodworker II blade. To submit your tip or technique, go to Woodsmith.com/magazine and click on the link, “SUBMIT A TIP” at the bottom of the page. There you can upload your tips and photos for consideration.
Win This Forrest Blade
The Winner!
Congratulations to Fred Adams, the winner of this Forrest Woodworker II. To fi nd out how you can win
this blade, check out the information at left. TRAY BOTTOM TRAY BACK TRAY FRONT TRAY SIDE TRAY SIDE Base drawer Notch in drawer side
provides clearance for tray and slides Drawer slide
NOTE: Tray width and depth will vary depending upon your needs and space available NOTE: Tray
bottom is !/4" hardboard. Other parts are #/4" plywood
SIDE VIEW Size the tray to allow for drawer slide
