Technical Application
Guide for UP-SHINE
LED Ceiling light
www.upshine.com [email protected]
Ø270
Ø300
17.5 48
Detection Pattern
Wall Mounting pattern (Unit: m)
wall mounting height(m)
Ceiling Mounting pattern (Unit: m)
ceiling mounting height
(
m
)
High detection area Low detection area
1 2 3 4 5 6 7 8 9 10 10 9 8 7 6 5 4 3 2 1 10 11 12 13 14 15 16 9 8 7 6 5 4 3 2 1
Up-shine surface mounted led ceiling light adopts high
lumen SMD led, fire rated PC diffuser with even light
output. Super slim design with elegant and modern
outline makes it more popular nowadays. Humanized
sensor design, by selecting the combination on the
switch, sensor data can be precisely set for each specific
application. Detection area, hold time and daylight
sensor lux setting can be adjustable according to
customer’s different request, giving them a new and
comfortable experience they never had before.
• Up to 70% energy saving compared to
standard CFL
• Long lifetime of 40,000 hours
• 120° wide beam angle
• CCT: 3000K 4000K 5000K 5700K
• No UV/IR light
• Environment friendly, without Mercury or any other
hazardous substances
Application Areas
Applicable for corridor, basement, garage, warehouse,
monitoring, and other places of energy-saving indoor
and outdoor lighting.
Certificate
Daylight & Microwave Sensor
Detection area:
◆
140 degree wide detective beam angle with 5~7 meters distance.
Working pattern:
◆
With sufficient natural light, when illuminance is more than the setting lux, the light does not switch on when
presence detected.
◆
With insufficient natural light:
• When illuminance is less than the setting lux, the light switches on automatically when presence detected.
• With presence detected, light will never switch off, even the nature light is sufficient.
• After presence left, any movement detected within time-delay, the light will continuously work for another hold
time, then switch off automatically until next movement detected.
Sensor Setting:
Detection area:
Detection area can be reduced by selecting the combination on the DIPswitches to fit
precisely each application.
Hold time:
Refers to the time period the lamp remains at 100% illumination after nomotion detected.
Daylight sensor:
The sensor can be set to only allow the lamp to illuminate below a defined ambient
brightness threshold.When set to Disable mode, the daylight sensor will switch on the lamp
when motion is detected regardless of ambient light level.50lux: twilight operation, 10lux,
5lux: darkness operation only.
Emergency
Smart IC control.
◆
Emergency function switches automatically between power cut and power restoration.
◆
Li battery, high efficiency
◆
Battery duration: 3 hours@4W
◆
Charge period: 24 hours
Emergency keeping (25%-30% power)
Charge Indicate Sensor Indicate Sensor keeping(Full power)
www.upshine.com [email protected]
Technical Specifications
Model Voltage Power PowerFactor Lumen(±5%) Beamangle CCT Lifespan CRI Dimmable Dimension
UP-AL08-12-18W-MS AC230V 18W ≥0.9 1710 120o 3000K 40000h ≥80 No Ø300*48mm UP-AL08-12-18W-MS AC230V 18W ≥0.9 1890 120o 4000K 40000h ≥80 No Ø300*48mm UP-AL08-12-18W-MS AC230V 18W ≥0.9 1910 120o 5000K 40000h ≥80 No Ø300*48mm UP-AL08-12-18W-MS AC230V 18W ≥0.9 1910 120o 5700K 40000h ≥80 No Ø300*48mm
Fixture Compatibility
RatedWattage ClassificationElectrical Protection Ingress OperatingTemp OperatingHumidity Storage Temp
18W Ⅱ IP40 -20oC~45oC 0~90% -20oC~65oC
Driver data Sheet
Driver data Sensor Emergency Main Power
Input rated Voltage AC230V AC230V AC230V
Frequency 50Hz 50Hz 50Hz
Input Voltage AC200-240V AC200-240V AC200-240V
Efficiency — ≥70% ≥88%
No load wattage — — ≤0.4W
Total load Wattage 2W±0.5W 4W±0.5W 18W±1W
Power Factor — — ≥0.9
Rated input current ≤0.02A ≤0.04A ≤0.1A
Full load output Voltage — DC24-38V 60-75V
Rated output current — 100-170mA 230mA
Output current range — — 230mA±5%
Power tolerance — — ±5%
Current output tolerance — — ±5%
Hold time 20S, 60S, 3Min, 10Min — —
Detection distance 5-7m(25%, 50%, 75%, 100%) — —
Daylight Sensor 5Lux, 10Lux, 50Lux, Disable — —
Battery duration — 3h@4W —
Charge Period — 24h —
Short circuit protection — — PASS
Over voltage protection — — PASS
Over temperature protection — — PASS
Withstand voltage — — AC3750V
Photometric Diagram
Spectral Distribution
Polar intensity diagram
Polar intensity diagram Polar intensity diagram
Polar intensity diagram Beam diagram
Beam diagram Beam diagram
Beam diagram Cartesian intensity diagram
Cartesian intensity diagram Cartesian intensity diagram
Cartesian intensity diagram
UNIT: cd AVERAGE BEAM ANGLE(50%): 115.4 DEG
-/+180 -120 -90 -30 120 90 30 0 140 280 420 560 700 0 UNIT: cd AVERAGE BEAM ANGLE(50%): 115.3 DEG
-/+180 -120 -90 -30 120 90 30 0 150 300 450 600 750 0 UNIT: cd AVERAGE BEAM ANGLE(50%): 115.2 DEG
-/+180 -120 -90 -30 120 90 30 0 140 280 420 560 700 0 UNIT: cd AVERAGE BEAM ANGLE(50%): 113.9 DEG
-/+180 -120 -90 -30 120 90 30 0 150 300 450 600 750 0 Planar Illuminance Curve
Distance(m) MH=10m E(LX) 7.0 6.3 5.6 4.9 4.2 3.5 2.8 2.1 1.4 0.7 0 C0/180 C90/270 -25-20-15-10-5 0 5 10 15 20 25
Planar Illuminance Curve
Distance(m) MH=10m E(LX) 7.50 6.75 6.00 5.25 4.50 3.75 3.00 2.25 1.50 0.75 0 C0/180 C90/270 -25-20-15-10-5 0 5 10 15 20 25
Planar Illuminance Curve
Distance(m) MH=10m E(LX) 7.0 6.3 5.6 4.9 4.2 3.5 2.8 2.1 1.4 0.7 0 C0/180 C90/270 -25-20-15-10-5 0 5 10 15 20 25
Planar Illuminance Curve
Distance(m) MH=10m E(LX) 7.50 6.75 6.00 5.25 4.50 3.75 3.00 2.25 1.50 0.75 0 C0/180 C90/270 -25-20-15-10-5 0 5 10 15 20 25
Height Eavg, Emax Angle: 115.15deg Diameter
Note: The Curves indicate the illuminated area and the average illumination when the Luminaire is at different distance.
Flux out: 1504 lm 17.37,63.32fc 186.9,681.5lx 314.84cm10.33ft 20.66ft 629.68cm 30.99ft 944.52cm 41.32ft 1259.36cm 51.65ft 1574.19cm 4.342,15.83fc 46.74,170.4lx 1.930,7.035fc 20.77,75.73lx 1.085,3.957fc 11.68,42.60lx 0.6947,2.533fc 7.478,27.26lx 16.4ft 5m 13.12ft 4m 9.843ft 3m 6.562ft 2m 3.281ft 1m
Height Eavg, Emax Angle: 115.08deg Diameter
Note: The Curves indicate the illuminated area and the average illumination when the Luminaire is at different distance.
Flux out: 1624 lm 18.75,68.39fc 201.8,736.2lx 314.41cm10.32ft 20.63ft 628.83cm 30.95ft 943.24cm 41.26ft 1257.66cm 51.58ft 1572.07cm 4.688,17.10fc 50.46,184.0lx 2.083,7.599fc 22.43,81.80lx 1.172,4.275fc 12.61,46.01lx 0.7501,2.736fc 8.073,29.45lx 16.4ft 5m 13.12ft 4m 9.843ft 3m 6.562ft 2m 3.281ft 1m
Height Eavg, Emax Angle: 115.20deg Diameter
Note: The Curves indicate the illuminated area and the average illumination when the Luminaire is at different distance.
Flux out: 1522 lm 17.57,64.15fc 189.2,690.5lx 315.14cm10.34ft 20.68ft 630.29cm 31.02ft 945.43cm 41.36ft 1260.57cm 51.7ft 1575.71cm 4.393,16.04fc 47.29,172.6lx 1.953,7.128fc 21.02,76.72lx 1.098,4.009lx 11.82,43.16lx 0.7029,2.566fc 7.566,2762lx 16.4ft 5m 13.12ft 4m 9.843ft 3m 6.562ft 2m 3.281ft 1m
Height Eavg, Emax Angle: 111.32deg Diameter
Note: The Curves indicate the illuminated area and the average illumination when the Luminaire is at different distance.
www.upshine.com [email protected] 140 280 420 560 700 0O 180O 150O -150O 120O -120O 90O -90O 60O -60O 30O -30O 0
Polar Diagram Comparison
AVERAGE BEAM ANGLE (50%): 115.2 DEG
UNIT: cd C0/180, 115.2 deg C30/210, 115.2 deg C60/240, 115.2 deg C90/270, 115.1 deg Temperature ( oC)
The driver lifespan is based on capacitor working temperature. IC Capacitor MOS PCB LED Fitting Environmental temperature 90 80 70 60 50 40 30 20 10 0 11:13:13 11:31:10 11:49:10 12:07:10 12:25:10 12:43:10 13:01:10 13:19:10 13:37:10 13:55:10 14:13:10 14:31:10 14:49:10 15:07:10 15:43:10 16:01:10 16:19:10 16:37:10 Time
Driver lifetime & LED light decay rate
90000 80000 70000 60000 50000 40000 30000 20000 10000 0 65oC 75oC 85oC 95oC 105oC Lifetime (hours) Capacitor Tc (oC)
Driver Lifetime LED Light Decay Rate
% Luminous Flux FLUX △U'V' 110% 105% 100% 95% 90% 85% 80% 75% 70% 0.0040 0.0035 0.0030 0.0025 0.0020 0.0015 0.0010 0.0005 0.0000 0 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000 LifeTime (hours)
Temperature
● The testing is operated at 25°C
● The lifetime of capacitor, minimum of 5,000 hours if operated at 105°C, will be doubled whenever the temperature drops 10°C ● The highest withstand temperature of IC, MOS could be 120°C
Installation
Packaging Information
SIZE(CM) N.W/pc(KGS) G.W.(KGS) Q'TY(PCS) Carton 61*32.5*33.5 1.2 14.2 10 CTNS Q'TY(PCS) VOLUME(CBM) 20'' standard container 410 4100 28 40'' standard container 820 8200 561.Take out ceiling light and accessory pack
from box. 2. Knock-in the plastic anchor into ceiling, remove screw, take out bracket. 3. Fix bracket with screw into the ceiling.
4. Selecting the combination on switch, sensor data can be precisely set for each specific application.
6. Switch on.
ON OFF
5. Open junction box, wire "A" "L" "N" to terminal block and mount ceiling light into the right place.
