Highlights
DIGITAL SOLUTION CENTER
Toolbox Release Information
Release Date
October 12
th, 2021
Web
v20211012
Touch - iOS
1.74.6
T ouch - Android
1.74.6
www.bstoolbox.com
01 02 03 04
New User Identity Framework
Tire Position Numbering Options
Inspections of Spare Tires in TOUCH
Improvement and Bug Fixes
WEB
https://www.bstoolbox.com
NA LA
EMIA
CAP
JP
New User Identity Framework
We are implementing a new user identity framework in Toolbox to improve security and to allow for more seamless sign-in experience across our global mobility solutions.
This change will require you to reset your Toolbox password that will need to comply with a stricter validation rule. For details, please refer to the guide.
Once completed, you will be fully migrated into the new environment.
Fig.1: Change your password with a new stricter validation rule
For users, who want to sign up into Toolbox, it now requires you to verify your email address. We will have checks in place if the email address or username is already in use across our global mobility solutions.
Fig.2: Requires verifying your email address Note
Please reach out to [email protected] if you have any further enquiries.
Please clear your web browsing cache before login, to experience the new features mentioned in this release.
!
NA LA
EMIA
CAP
JP
Tire Position Numbering Options
Previously, two position numbering types were available and derived from the country you belong to. With this release a new numbering method is added (specially geared towards ultra large OTR customers) and you can now choose your preferred numbering method under your user profile.
The three options are as follows:
Fig.3: Wheel Position Numbering Options selectable in the user profile
.
Fig.4-6: Wheel Position Numbering Options – 3 choices available in WEB (only)
A B C
4
Option A: Axle + Wheel Number (1-1, 1-2…)
The first number is the axle number, and the second number is the wheel number counted from left to right of the vehicle (arial view).
The wheel number count is starting again by each axle, for instance 1-1, 1-2, 2-1, 2-2, 2-3, 2-4.
You can immediately tell that there are 2 tires on the first axle and 4 on the second axle.
Fig.7: intelliTire/Tracker: Vehicle Details using Option A Option B: Axle + Direction + Wheel Number (1-L1, 1-R1...)
The first number is the axle number. A letter will follow to define the direction if it is Left or Right of the vehicle (arial view). After the letter comes the wheel number.
The numbering starts from the outer to inner by each direction per axle, for instance, 2-L1, 2-L2, 2-R1, 2-R2. There are 2 tires on the left and 2 on the right for the second axle.
Fig.8: intelliTire/Tracker: Vehicle Details using Option B
Option C: Wheel Number (1, 2, 3...)
We only take the wheel number for this option. Wheel Number 1 is always on the top left of the first axle (arial view).
It continuously counts the wheels from left to right on each axle, down to the last right wheel of the last axle, for instance, 1, 2, 3, 4, 5, 6 for a semi-trailer, see fig. 6.
Fig.9: intelliTire/Tracker: Vehicle Details using Option A
By default, your tire position numbering will be set to your main assigned country.
You can experience the changes immediately across all modules in Toolbox WEB incl. reports.
INSTA
Yard Check incl. Performance Tracking
intelliTire/TRACKER
Reports
Note
For both TOUCH application, this option selection will be developed later this year (TBC).
NA LA
EMIA
CAP
JP
Improvement: Immediate Action Reports (TPMS)
We are continuously improving the layout of the immediate action report (IAR) to help you consume the information more efficiently.
Changes are:
Clearer indication for the installed sensor:
Wi-Fi icon shows blue when sensor returns latest TPMS reading Wi-Fi icon shows grey when sensor does not receive any readings No icon means that the pressure value has been entered manually
Showing Critical and Warning icons linked to tasks generated from the data engine
Location filtering at the top navigation are now taken into account.
Fig.10: Improved IAR with TPMS data
.
NA LA
EMIA
CAP
JP x
Improvement: intelliTire/Tracker – Registering new tires
It will no longer automatically select a tire when you register more than one tire for a position.
This will reduce the chances of accidentally entering the data during an inspection.
Fig.11: intelliTire/Tracker: Registering new tires during inspection
NA LA
EMIA
CAP
JP
Improvement: Terms and Conditions / Privacy Policy
We have expanded the languages available for the privacy policy and terms and conditions and included clauses for specific markets.
Additions:
Indonesian
Malaysian
Thai
Fig.12: Privacy Policy in Malaysian
List of resolved issues and improvements (WEB)
Module Description 🔃 Improvement or Update Bug Fix
General Fixes for the Admin section [80678] [75966] [76339]
🔃 Improvements for the Admin section [77865] [78647]
Fleet Profile Vehicle Config.: When deleting the structure with the keyboard, it did not show the list of available options [75933]
Maintenance Policy: Decimal point for dual pressure mismatch shown for countries that uses comma [78946]
INSTA When MVC button had been unselected, the Replaced stayed on [80462]
OOSTA Inspection with RFID are not getting deleted [81480]
🔃 Navigation Icons were shown even when uploading one image [80248]
TRACKER Register new tires: Decimal point was allowed for countries that uses comma [77170]
Register secondary tire Ids – Error message stayed on after rectification [81269]
Message was not shown for unsupported file formats under Rim Crack History [80755]
Tire Rotation: Lowest Tread Depth still showed the previous tire [80276]
Inspection photos were not shown in the Photo Library module [80638]
Inventory-Sensors: Exporting to Excel for installed sensors was not possible [73239]
Register new tires: List of Retreads were not shown after deleting the previous selection using the keyboard [80500]
🔃 Vehicle Details Page: Both RTD values are now shown as RTD1/RTD2 when a second value as been recorded [66164]
🔃 Tire Movement: Immediate Action Report for all vehicles can be generated. This can be found by selecting the three dots icon [61153]
🔃 Improved performance for the Inventory Page [80501]
Connectivity Sensors could not be added to a managed location [77426]
Alert Email – Labels were missing [81170]
Photo Library When user selected intelliTire/Tracker first, photos were not loaded [80172]
Inspection photos from intelliTire/Tracker were not displayed [80638]
Yard Check: Filter for selecting tire sizes were not working [75909]
Report INSTA Combined Report: Number for Retreads not matching [79052] [Hotfix]
Performance Combined Report: It was not working for a fleet [78361] [Hotfix]
Yard Check Roll-up Report not available in the Report History [77861]
Yard Check Combined: blank page shown if only Mgt Summary was selected [77861]
Yard Check Performance Tracking: Generate button was always enabled [76938]
Yard Check Performance Tracking: When selecting one vehicle ID, the same ones in the list were also automatically selected [72200]
OOSTA Combined Report: Blank page was included if downloading to WORD [80505]
🔃 Analytics: Workbooks are sorting alphabetically [80260]
🔃 INSTA Combined Report: Sorting is now by vehicle number, then by Inspection Date.
Target pressure is now hidden when there is no pressure recorded for a tire [78373]
🔃 OOSTA: Tire Condition Codes are searchable and shown in the filters [73305]
MOBILE APP - TOUCH
iOS / Android
NA x LA
EMIA
CAP
JP
INSTA: Ability to inspect Spare Tires
Previously, you could only inspect spare tires in WEB.
With this release, you can record the details of spare tires directly in TOUCH during your audit.
First, make sure the spare tire option is enabled for your vehicle in WEB. You will then see a new tire position called ‘SP’, when creating a new inspection using INSTA in TOUCH, see fig 8-9 [A].
Fig. 13-14: New download icon for TPMS and warning message to sync your sensor data (left, iOS, right, Android) iOS
ANDROID
Please update the new version on App Store.Previous version is obsolete. Any un-synced data will be uploaded prior to the update.
!
A A
Once selected, you can then enter the details with all the familiar fields.
Fig. 15-16: Sensor Tab (left, iOS, right, Android)
After completing the inspection, you can review your information in the vehicle details page [A].
.
Fig. 17-18: Associating Sensors with clearer cut (left, iOS, right, Android)
A A
List of resolved issues and improvements (TOUCH)
Module iOS Android
Description 🔃 Improvement or Update Bug Fix
General Screen hangs when uploading data after setting a default fleet [37550] [51138]
Settings: App crashed when user taps on the default fleet field [80819]
Fleet Near Me (Map): Internet connection message appeared [79921]
Upload Message is no longer displayed if interrupting Internet Access [26837]
When using the Fleet Near me (Map) multiple times, app crashed [76793]
When user refreshed a fleet, not set as a favorite, it never completed [78220]
Month was incorrectly displayed in Date Field for OOSTA & Yard check [80316]
Fleet Name was no longer shown at header if refreshing the fleet data [76933]
🔃 Security improvement [77022]
🔃 Update to API level 30 required for Android [79677]
Fleet Profile User was not able to add depots/locations [78553]
Vehicle Layout 2SD-2SD image was bigger than the others [75911]
It was possible to exceed 100 % for Bridgestone & Bandag demand [76305]
INSTA When registering a new vehicle, it could not be found immediately [76542]
Reconnect to Probe message displayed twice while disconnecting [49129]
Landscape mode was not supported if selecting the probe (Bluetooth) [76133]
Sensor Pages was not working in landscape mode [76422]
Inspection page is distorted after pressing confirm in landscape mode [75994]
Inspection: Search bar was expanded for no reason in landscape mode [76132]
App crashed on Sensor Mapping screen when changing orientation [76421]
Odometer reading became blank when changing orientation of tablet [75982]
Walk-Around for TPMS: Last Seen was not updated [37546]
Yard Check Uploaded photos not displaying in the report (Report History in WEB) [78270]
For certain languages, decimal comma was not recognized [76981] [Known]
App crashed for certain languages when using Performance Tracking [79543]
TRACKER Inspection: RTD field is changing decimal comma value to a whole number after saving it for countries that use decimal comma [76982] [Known]
Register new tire: Tire OTD not converting to 32nd from mm [79880]
TPMS: When replacing sensors, the ID is not changed to most recent [71275]
TPMS: Removed sensor was still set as Installed [71574]
TPMS: Tire color from data engine did not appear immediately [73422]
Walk-Around for TPMS: Last Seen was not updated [37546]
🔃 For TPMS enabled vehicles, it automatically shows the sensor tab [77778]
🔃 TPMS-Sensor tab: show all positions regardless of sensor fitment [77778]
🔃 Inspection: Target Pressure & Pull-Point are now displayed [72828]
🔃 Correct Number pad is now displayed derived from user profile UoM [78463]
Known Issues (TOUCH)
Module iOS Android
Description
General We are continuously working hard that Toolbox works on iOS & iPadOS 15 Yard Check Deleted Performance history in WEB still shown in TOUCH [77380]
Supported Versions
The table below summarizes the range of operating systems (OS) supported by Toolbox TOUCH.
The application may very well run fine on older versions of each OS.
[Last Modified: Oct 08th, 2021]However, we do not support nor guarantee it. This restriction allows us to reduce our code debt and always keep our development agile so that we constantly bring new features at a high pace.
Platform Supported OS Devices/Specs
iOS Version 14 or higher* iPhone 7 or higher iPad 2015 or newer iPad Pro Versions iPad Mini Versions
Android Version 8.0 or higher Minimum: 2.2GHz, 4GB RAM with available storage of 350MB (depending on assigned fleets)
These devices have been confirmed to work during UAT:
Google Pixel 4 incl. 4a (Android 11) Sony Xperia 5 (Android 9)
Samsung Galaxy A40 (Samsung One UI 1.1, Android 9) Samsung Galaxy Tab Active Pro (Android 10)
Samsung Galaxy Note 9 (Samsung Experience 9.5, Android 10) Samsung Galaxy S7 Prime (Samsung Experience 9.5, Android 8.1)
*iOS 15 and iPadOS 15 may work well in our preliminary software quality checks.
Platform Supported Web Browsers for Toolbox WEB PC / MAC RECOMMENDED:
Google Chrome (version 80 or greater)
Microsoft Edge Chromium (version 80 or greater) OPTIONAL (which may work well)
Opera Chromium (version 74 or greater) Apple Safari (version 14 or greater) Mozilla Firefox (version 80 or greater)
Glossary
Abbreviation Explanation Abbreviation Explanation
NA North America UoM Unit of Measurement
LA Latin America IV Inaccessible Valve Cap
EMIA Europe, Middle East, India, Africa and C.I.S. MVC Missing Valve Cap
CAP China and Asia Pacific MVE Missing Extension Valve
JP Japan VC Valve Cap
FMS Fleet Management System IAR Immediate Action Reports
TCU Telematics Controller Unit INSTA In Service Tire Analysis TRACKER Asset Tracking OOSTA Out of Service Tire Analysis
