SolidStore benefits: SolidStore file system

(1)

(2)

Next level of

performance

SolidStore beneﬁ ts:

• Fast data access

• Unsurpassed reliability for video storage

• No fragmentation of data

• Greater hard disk service life

● EXPERIENCE THE NEX T WATCH VIDEO

SolidStore ﬁ le system

Oftentimes, the main bottleneck on VMS performance is the fi le system. Data fragmentation builds with time. Slow hard disk access negates the performance of even the fastest CPUs. That’s why SolidStore, a special fi le system, has been developed exclusively for Axxon Next. SolidStore resolves the issue of fragmentation altogether, ensuring read and write times close to bare-metal speeds. Another benefi t is that our fi le system reduces wear and tear on hard disks, thus increasing their service life.

One of the key development requirements for SolidStore was maximum preservation of data in the event of random disk sector damage. Thus, SolidStore does not allocate separate blocks for critically important fi le system information whose loss could render all accumulated data in-accessible. It is precisely because of this that SolidStore did not rely on the OS fi le system, but instead was developed as a full-fl edged fi le system that communicates directly with the data storage device.

Eff ectively, in SolidStore, damage to any data block on the disk causes only that particular block to be inaccessible, not the entire video archive. This helps maximize video storage reliability, which is absolutely crucial to video surveillance systems.

is absolutely crucial to video surveillance systems.

(3)

Micromodule architecture

beneﬁ ts:

• Greater reliability – each VMS function is performed by a separate

micromodule

• If an error occurs in a certain micromodule, only that one is

relaunched, without aﬀ ecting the functioning of the system overall

• Ease of micromodule testing enables quicker delivery of stable new

versions

Next level of

reliability

● EXPERIENCE THE NEX T

Micromodule architecture

The micromodule architecture of Axxon Next allows implementing diff erent video manage-ment system functions as diff erent operating system processes. Each function is the responsibility of a diff erent micromodule; a dispatcher module monitors the functioning of the micromodules. If a function encounters an error and a process is quit unexpectedly, the dispatcher module au-tomatically relaunches the corresponding micromodule. This does not aff ect the performance of other processes or the functioning of the VMS overall. After a micromodule is initially written, its code undergoes automated functional testing, substantially reducing the likelihood of errors in the code. This micromodule architecture allows for a VMS that is more stable than anything else on the market.

Standard

architecture Micromodule _architecture

Module crashes and is restarted A module crash

causes the system to crash

(4)

MomentQuest2 beneﬁ ts:

• Quickly search archive video using speciﬁ ed criteria

• Search instantly – no pre-conﬁ guration of video detection tools

required before recording

Next level of

MomentQuest 2 VIDEO

MomentQuest2

MomentQuest2 allows for quick retrieval of video footage thanks to metadata stored with each image. These are all the data on objects moving in the scene which are calculated as the video is streaming and stored alongside with the footage. Within seconds, the MomentQuest2 system will fi nd the records that match the user’s query.

You can specify the following search criteria:

• motion in the zone, user-defi ned with any polyline

• detection of crossing a virtual line in a user-defi ned direction • loitering (prolonged presence of an object in an area) • simultaneous presence of a few objects in an area • motion from one area to another.

You can apply these fi lters to your search results: • object size

• object color

• direction of object motion • speed of the moving object

(5)

Time Compressor beneﬁ ts:

• Quickly review all events over a selected timeframe

• Speed up search for an event of interest – by dozens of times

• Click to view a relevant video fragment in normal mode

Next level of

Time Compressor VIDEO

Time Compressor

Time Compressor allows the user to set a time range for video footage and get a short video clip of all moving objects in the scene. Objects and events captured at diff erent times are dis-played simultaneously in a condensed “video synopsis”. When you spot an object of interest, click to jump to playback of the corresponding video fragment.

Time Compressor works by writing “tracks” of object movement to the archive in parallel with video. This lets us separate moving objects from a static background, and then display multiple objects on screen at the same time in synopsis mode. When there is a small number of objects in the frame at any one time – when we’re not dealing with a crowd – this view substantially reduces the time needed to review the scene over the timeframe in question.

To start viewing video in Time Compressor, the user selects the timeframe of interest and sets a maximum number of objects to see in a frame simultaneously – say, no more than 10 objects at the same time. Then the user can start viewing practically right away: our system does the calculations in real time.

g p

a maximum number of objects to see in a frame simultaneously – say, no more than 10 objects at the same time. Then the user can start viewing practically right away: our system does the calculations in real time.

(6)

Interactive 3D Map

Interactive 3D Map beneﬁ ts:

Interactive 3D Map

Axxon Next is a user-friendly, intuitive system that lets security personnel get started quickly and easily, without needing to learn complicated workfl ows and procedures. The ergonomic in-terface ensures excellent usability and makes it easy to access the system’s full functionality right away. Axxon Next includes the Interactive 3D Map, which superimposes camera locations on a site map and displays camera views in the same window. This handy viewing mode allows op-erators to monitor situations without spending time to switch between windows. Opop-erators can instantly pinpoint where a selected camera is located on the map and identify the correspond-ing location of interest.

The way we’ve made our 3D map is simple but has to be seen to be believed. We take an ordinary 2D blueprint of a facility in raster format: BMP, say. We twist it around into a pseudo-3D projection (2.5D) and map onto it the cameras with their fi elds of view. That way the screen

still has enough space for showing the video, even as the blueprint is easy to see. This is also great for quickly showing, visually, where a selected camera is located at the site. Just click the video and

you’ll see which camera the video is coming from.

Next level of

usability

WATCH VIDEO

• Logically arranged, intuitive interface

• Clear view of all cameras at a site

• Simultaneously view the status, ﬁ eld of view, and video feeds

from cameras

(7)

Beneﬁ ts:

• Powerful video analytics are included in the license

• Convenient, interactive conﬁ guration of video detection tools

• Flexible

conﬁ guration of system responses to triggers

Video Analytics

AxxonSoft believes that video analytics are a must-have for any modern VMS. That’s why Axxon Next features a range of powerful video detection tools absolutely free:

• motion detection

• background change detection • loss of video quality detection • abandoned objects detection

• detection of crossing a line in a given direction • motion in the zone detection

• stopping in the zone detection • loitering detection

• zone entry/appearance detection • zone exit/disappearance detection.

We tried to make video analytics available to all users and to make their use as convenient and easy as possible. So we created an interactive confi guration mode for the detection tools. In the frame, the user sets areas, lines, and other parameters for the detection tool. Then the user clicks “Apply” and sees right away how the detection tool is going to work. All the events which trigger the tool will be shown immediately on a special part of the screen. This lets you see at a glance whether the detection tool is working correctly. Then you can simply adjust the settings so every-thing works in precisely the way it needs to.

After the tool is confi gured, there is a convenient graphical interface for selecting the system reaction when the tool is triggered. These responses, for example, could be writing video from the camera, sending an SMS or email, playing a sound, or applying presets to rotate a PTZ unit.

With this combination of powerful video analytics and automated reactions, the operator expe-riences less fatigue and does not risk missing even a single important event.

Next level of

functionality

(8)

Beneﬁ ts:

• Flat price list

• No hidden costs

• Zero maintenance fee

• Zero support costs

• Free

updates

• Free version for 1 server, 16 cameras and 1 Tb storage

Availability

State-of-the-art video management systems are critical for guaranteeing the security of sites big or small. That’s why we don’t release “crippled” versions of Axxon Next with limited features. We practice fl at pricing: we off er the same price for a video channel, no matter how many there are. All functions are just as accessible and just as eff ec-tive whether installed on a system of one camera or infi nite cameras. Axxon Next means no hidden expenses and no maintenance fees. We provide free software updates and free technical support for all of our users and partners. This means you can create modern, eff ective video surveillance systems that are easy to budget.

AxxonSoft’s flexible, client-oriented pricing policy allows creating systems with

greater functionality and more advanced cameras than any other VMS software.
