Chapter 1. Scope, requirements, and support

This blueprint applies to System x®running Linux. You can learn more about this blueprint, including the intended audience, the scope and purpose, the hardware and software requirements for the tasks detailed in this blueprint, and the types of support available to you.

Systems to which this information applies

System x running Linux

New in the second edition (March 2013)

v _{Support for 802.1 Qbg over bonding devices in Red Hat Enterprise Linux 6.4}

Intended audience

This blueprint is intended for advanced Linux®system administrators and programmers who need to configure virtual and physical switches in a Red Hat Enterprise Linux 6.1 KVM hypervisor environment.

Scope and purpose

To complete the instructions in this blueprint, the virtual machines must already be defined. Only the differences to a normal libvirt network setup are described. The process of defining virtual machines and all the details of a libvirt network setup is outside the scope of this blueprint.

This blueprint provides information about configuring libvirt to use macvtap devices for virtual network interfaces, and how to use the 802.1Qbg Virtual Station Interface (VSI) types with physical switches. This document also provides information about configuring the network filter for virtual switches in a libvirt-controlled environment, and the necessary changes to the appropriate XML files with the help of the virsh tool.

Test environment

The instructions in this blueprint were tested on System x® HS22 blade systems running Red Hat Enterprise Linux 6.1 KVM Hypervisor with already defined virtual machines. The HS22 blade systems were connected to a VEPA and 802.1 Qbg enabled switch.

Hardware, software, and other prerequisites

Host machines must be running either Intel VT chipsets or AMD-V chipsets that support

hardware-assisted virtualization. For more information about hardware requirements, see the′′Enabling KVM support on your hardware′′section of the Quick Start Guide for installing and running KVM.

Author names

Gerhard Stenzel Jens Osterkamp Thomas Richter

Other contributors

Santwana Samantray Heather Crognale

(8)

IBM

®

Services

Linux offers flexibility, options, and competitive total cost of ownership with a world class enterprise operating system. Community innovation integrates leading-edge technologies and best practices into Linux.

IBM is a leader in the Linux community with over 600 developers in the IBM Linux Technology Center working on over 100 open source projects in the community. IBM supports Linux on all IBM servers, storage, and middleware, offering the broadest flexibility to match your business needs.

For more information about IBM and Linux, go to ibm.com/linux (https://www.ibm.com/linux)

IBM Support

Questions and comments regarding this documentation can be posted on the developerWorks® Systems Management Blueprint Community Forum: developerWorks Linux Virtualization Blueprint Community Forum

The IBM developerWorks discussion forums let you ask questions, share knowledge, ideas, and opinions about technologies and programming techniques with other developerWorks users. Use the forum content at your own risk. While IBM attempts to provide a timely response to all postings, the use of this developerWorks forum does not guarantee a response to every question that is posted, nor do we

(9)

Chapter 2. Network setup

The use of virtual machines in physical host machines leads to a situation where there is no longer a strict separation between host and network administration because some form of virtual network setup is needed to connect the virtual machines to the physical network.

Depending on the type of workload on the virtual machines and the type of communication between them, the spectrum of the network setup for the guest within the hosts can range from a dedicated network card for a guest to a fully administratable virtual switch with advanced routing and filtering capabilities. In this blueprint, two complementary scenarios are considered:

v _{the VEPA scenario, or network centric scenario, where the administration of the network happens in} one or more physical switches, and where the virtual machines are connected to the physical network as closely as possible.

v _{the VEB scenario, or host centric scenario, where all administration including the administration of the} virtual network and switches happens in the hypervisor host machines.

Related concepts:

Chapter 1, “Scope, requirements, and support,” on page 1

This blueprint applies to System x running Linux. You can learn more about this blueprint, including the intended audience, the scope and purpose, the hardware and software requirements for the tasks detailed in this blueprint, and the types of support available to you.

Managing virtual machines with libvirt

Both scenarios described in this blueprint assume that you will use libvirt.

Many libvirt tasks, like defining, starting, or migrating a virtual machine can be accomplished using virsh, the command-line utility. The graphical interface to libvirt, virt-manager, does not currently support all of the features discussed in this blueprint. If you decide to use virt-manager, though, you can do so with some manual editing of the virtual machine definition (the details of which are outside of the scope of this blueprint).

For more information about using libvirt, see http://libvirt.org/docs.html. Related concepts:

Considerations for live migration

Live migration of virtual machines requires that the virtual disk of a virtual machine is stored on a shared resource accessible to both source and target host. For example an NFS-based or iSCSI-based storage pool.

For more information about live migration of virtual machines, see http://www.redhat.com/docs/en-US/Red_Hat_Enterprise_Linux/6-Beta/html/Virtualization/

(10)

(11)

Chapter 3. The VEPA scenario

In the VEPA scenario, the virtual machines are connected to the physical network as closely as possible, so that the virtual network interface is directly connected to the physical network interface of the host without going through the virtual bridge of the Linux host.

All network traffic from a virtual machine goes to the switch first, effectively bypassing the internal bridge even if the network traffic is intended for the host or another virtual machine on the same host. Communication between virtual machines on the same host therefore requires that the respective switch port is put in 'reflective relay' mode. This kind of communication will also impact the overall bandwidth of the respective physical interface and the latency of the network traffic.

Adding a VEPA interface to a virtual machine

A VEPA interface is added to a virtual machine by specifying the "direct" interface type in the domain XML.

(12)

Change the interface definition using thevirsh edit <virtual machine>command as follows to add a VEPA interface to a virtual machine (using eth2 with VLAN ID 20 in this example).

Note: If you are using BNT switches, the VLAN ID should be in the range of 2 to 4094. <devices>

...

... </devices>

This change causes libvirt to create a macvtap device, tie it to the specified physical network interface, and then pass the macvtap file descriptor to QEMU upon virtual machine start. This sequence works similarly for virtual machine shutdown and migration.

While using the VEPA mode provides the base for the network-centric management of the virtual

machines network activities, an additional step is necessary to actually do this: enforcing port policies. In this case, 802.1Qbg VSI types.

Adding 802.1Qbg VSI types to a VEPA interface

The VSI types are defined and stored in a database with an associated unique ID. The switch advertises its support for 802.1Qbg capabilities, including reflective relay.

On the KVM host, the link layer discovery protocol agent daemon (lldpad) is used to configure the port in VEPA mode (hairpin mode), effectively offloading packet-switching functions from the KVM host to the adjacent switch. The lldpad daemon is notified by libvirt if VSI types are to be applied to a specific MAC/physical port pair. The unique ID of the VSI type and the virtual NIC MAC/VLAN information is registered with the adjacent switch port through lldpad and the switch retrieves the VSI type that is based on the unique ID and associates the rules against the registered MAC/VLAN.

802.1Qbg requires support from the physical switch that is connected to the server. See your switch user guide to determine whether the switch supports 802.1Qbg, and how to configure it. Both IBM blade switches and rack switches support 802.1Qbg. If necessary, upgrade to a newer switch firmware version. Configuration typically involves enabling EVB on the switch port, and configuring connection details for the VSIDB server.

(13)

For more information about how to configure a switch for VEPA, see chapter 6 of the Implementing a VM-Aware Network Using VMready® (http://www.redbooks.ibm.com/abstracts/sg247985.html) IBM Redbooks® publication.

Note: The switch IBMNOS allows a port to be configured with "tag-pvid". With this configuration, all packets that are leaving the port are tagged, including the LLDP and ECP packets. This configuration is not recommended for ports on which 802.1Qbg is used because it is not supported by the current lldpad implementation

Installing and starting the lldpad daemon

To configure the port in VEPA mode, install and start the link layer discover protocol agent daemon (lldpad).

Procedure

1. Install the lldpad daemon with the following command: yum install lldpad

2. Start the lldpad daemon with the following commands: service lldpad start

3. Enable the admin status for the interface that is connected to the switch (in this example eth2) with the following commands:

Note: These two commands address the nearest bridge and the nearest customer bridge. lldptool -L -i eth2 adminstatus=rxtx

lldptool -i eth2 -g ncb -L adminstatus=rxtx

4. Enable transmission of the EVB TLV (edge virtual bridging type length value message) and then configure reflective relay mode and capabilities with the following sets of commands for both the nearest bridge and for the nearest customer bridge. For Red Hat Enterprise Linux 6.4 and later, lldpad uses only the nearest customer bridge.

a. For the nearest bridge (unnecessary for Red Hat Enterprise Linux 6.4 and later): lldptool -T -i eth2 -V evbCfg -c enableTx=yes

lldptool -T -i eth2 -V evbCfg -c fmode=reflectiverelay lldptool -T -i eth2 -V evbCfg -c capabilities=rte,ecp,vdp b. For the nearest customer bridge:

lldptool -i eth2 -T -g ncb -V evbCfg -c enableTx=yes

lldptool -i eth2 -T -g ncb -V evbCfg -c fmode=reflectiverelay lldptool -i eth2 -T -g ncb -V evbCfg -c capabilities=rte,vdp,ecp c. Display the EVB parameters:

lldptool -t -i eth2 -g ncb -V ecbCfg -c enableTx lldptool -t -i eth2 -g ncb -V ecbCfg -c fmode lldptool -t -i eth2 -g ncb -V ecbCfg -c capabilities 5. Enable VDP with the following commands:

Note: These commands address the nearest bridge and the nearest customer bridge. Red Hat Enterprise Linux 6.3 and before

lldptool -T -i eth2 -V vdp -c enableTx=yes lldptool -i eth2 -T -g ncb -V vdp -c enableTx=yes

(14)

Red Hat Enterprise Linux 6.4 and later

lldptool -i eth2 -T -g ncb -V vdp -c enableTx=yes 6. Restart the lldpad daemon with the following command:

service lldpad restart

Results

All the changes made with lldptool as above have to be made only once and will be saved to the lldpad configuration file. They will available to lldpad automatically on the next start. The changes can be verified by examining the/var/lib/lldpad/lldpad.conffile. The changes due to step 4a arehighlighted: dcbx : { version = "1.0"; dcbx_version = 2; }; nearest_customer_bridge : { eth2 : { tlvid00000001 : { info = "04001B2163BEE8"; }; tlvid00000002 : { info = "03001B2163BEE8"; }; adminStatus = 3; tlvid001b3f00 : { capabilities = "rte,vdp,ecp"; fmode = "reflectiverelay"; enableTx = true; }; vdp : { enableTx = true; }; }; ... }; lldp : { eth2 : { tlvid00000001 : { info = "04001B2163BEE8"; }; tlvid00000002 : { info = "03001B2163BEE8"; }; adminStatus = 3; vdp : { enableTx = true; }; tlvid001b3f00 : { enableTx = true; info = "001B3F0080070000DF0C00000F"; capabilities = "rte,ecp,vdp"; fmode = "reflectiverelay";

(15)

};

}; ... };

v _{The status of the negotiation of EVB capabilities can be queried with lldptool with the following} command for the nearest bridge:

lldptool -t -i eth2 -V evbcfg

The result of this command should look similar to the following: EVB Configuration TLV

supported forwarding mode: (0x40) reflective relay supported capabilities: (0x07) RTE ECP VDP

configured forwarding mode: (0x40) reflective relay configured capabilities: (0x07) RTE ECP VDP

no. of supported VSIs: 0001 no. of configured VSIs: 0000 RTE: 16

v _{The status of the negotiation of EVB capabilities can be queried with the}_{-g ncb}_{option for the nearest} customer bridge:

lldptool -i eth2 -t -g ncb -V evbcfg

Note: The displayed values of configured forwarding mode and configured capabilities, shown as 0, are incorrect on some Red Hat Enterprise Linux 6.x versions.

Specifying a VSI type

Specify the VSI type for a VEPA interface by adding a <virtualport/> element to the domain XML using virsh edit.

The parameters of the virtualport element are documented in more detail in the IEEE 802.1Qbg standard. The values are network specific and should be provided by the network administrator. In 802.1Qbg terms, the Virtual Station Interface (VSI) represents the virtual interface of a virtual machine.

Important: Be sure to adapt the attribute values for the <parameter/> element to your specific network environment.

<devices> ...

<virtualport type=’802.1Qbg’> <parameters

managerid=’12’ typeid=’0x123456’

(16)

typeidversion=’1’ instanceid=’09b00c53-8b5c-4eeb-8f00-d847aa05191b’ /> </virtualport> <model type=’virtio’/> </interface> ... </devices> Related concepts:

VM startup

When the virtual machine is started, libvirt parses the virtualport type, determines the physical device (nth parent) and VLAN ID, and sends a netlink message with an 'ASSOCIATE' request to the lldpad daemon.

The lldpad daemon then sends an ASSOCIATE VDP message on the physical interface to the switch. Depending on the success or failure of registering the VSI type, you will see one of the following messages.

Table 1. System status messages

Output message shown Status

virsh start testvm3

error: Failed to start domain testvm3 error: internal error sending of

PortProfileRequest failed

The lldpad daemon is not running.

virsh start testvm3

error: Failed to start domain testvm3 error: internal error port-profile

setlink timed out

The environment does not have an 802.1Qbg enabled switch.

virsh start testvm3 Domain testvm3 started

The virtual machine is successfully created.

You can verify the status of the association of the profile with the following command: lldptool -t -i eth2 -V vdp mode

The output will look similar to the following output: mode = mode: 2 (VDP_MODE_ASSOCIATED) response: 0 (success) state: 2 (VSI_ASSOCIATED) mgrid: 12 id: 1193046 (0x123456) version: 3 instance: 09b00c53-8b5c-4eeb-8f00-d847aa05191b mac: d0:0f:d0:0f:02:01 vlan: 20

(17)

VM migration

Live migration allows you to migrate a virtual machine from one host to another host while the virtual machine continues to run seamlessly.

The virtual disk of the virtual machine is located in a shared storage pool and should be mounted on both the source and destination. Configuring SSH to authenticate without requiring passwords will simplify the migration process.

For more information about shared storage pools, see Chapter 6, “Shared storage pools,” on page 25. Related concepts:

Migrating your VM

Use this procedure to migrate your virtual machines.

Before you begin

This procedure assumes that SSH keys are already set for password-less authentication. If you do not have SSH keys set for password authentication, do so before continuing with this procedure.

Procedure

1. Verify that password-less authentication is working: virsh -c qemu+ssh://c7b5/system list --all

Id Name State

--- testvm3 shut off

2. Verify that the virtual machine is running locally: virsh list --all

Id Name State

---23 testvm3 running

3. Migrate the virtual machine to the destination host: virsh migrate testvm3 qemu+ssh://c7b5/system

4. Verify that the virtual machine is running on the destination: virsh -c qemu+ssh://c7b5/system list --all

Id Name State

5. Migrate the virtual machine back with one of the following command strings: v [root@c7b4 ~]# virsh --connect qemu+ssh://c7b5/system \

(18)

v virsh --connect qemu+ssh://c7b5/system migrate testvm3 \ qemu+ssh://c7b4/system

Shutting down a virtual machine

You can shut down a virtual machine from either directly within the virtual machine or by using the virshcommand from the host.

To shut down the virtual machine from the host, use the following command: virsh shutdown testvm3

If the command is successful, the following output is displayed: Domain testvm3 is being shutdown

Configuring a bonding device

Use this procedure to configure a bonding device for lldpad.

Before you begin

Beginning with Red Hat Enterprise Linux 6.4, lldpad supports bonding devices. Only active-backup mode is supported. In this example, a bond device named bond0 has an IP address of 192.168.0.5, and two slaves named eth2 and eth3.

Note: Switch configuration to support a bond device on an HS22 blade has the following characteristics and limitations:

v _{Slave devices must be connected to a different switch device. The switch firmware does not support} EVB protocol on external ports.

v _{Switches must be interconnected. Use an external port between both switches.}

v _{Enable the external ports on both switches to transfer traffic for the VLAN id that is defined in the} lldpad configuration section.

To configure a bonding device for lldpad, complete the following procedure:

Procedure

1. Install the bonding device driver:

modprobe bonding mode=active-backup miimon=100 A device named bond0 is available.

2. Assign an IP address to the bond0 device:

ifconfig bond0 192.168.0.5 netmask 255.255.255.0 up 3. Create slaves and assign them to the bond0 device:

(19)

4. Assign a VLAN device that is named bond0.4 on top of the bond0 device: vconfig add bond0 4

A new device that is called bond0.4 is associated with VLAN id 4. 5. Assign an IP address the the bond0.4 VLAN device:

ifconfig bond0.4 192.168.4.5 netmask 255.255.255.0 up lldpad uses the device bond0 for switch communication. 6. Enable transmission of the EVB TLV for the bond0 device:

a. For the nearest customer bridge:

lldptool -i bond0 -T -g ncb -V evbCfg -c enableTx=yes

lldptool -i bond0 -T -g ncb -V evbCfg -c fmode=reflectiverelay lldptool -i bond0 -T -g ncb -V evbCfg -c capabilities=rte,vdp,ecp lldptool -i bond0 -T -g ncb -V vdp -c enableTx=yes

lldptool -i bond0 -L -g ncb adminstatus=rxtx b. Display the EVB parameters:

lldptool -t -i bond0 -g ncb -V ecbCfg -c enableTx lldptool -t -i bond0 -g ncb -V ecbCfg -c fmode lldptool -t -i bond0 -g ncb -V ecbCfg -c capabilities lldptool -i bond0 -t -g ncb -V vdp -c enableTx lldptool -i bond0 -l -g ncb adminstatus

lldpad uses the bond device to communicate with the switch. If the active slave fails, the backup slave becomes the new active slave and communication between virtual machines, lldpad, and the switch resumes after a short wait period.

(20)

(21)

Chapter 4. The VEB scenario

In the VEB scenario, all of the virtual machines in a host are connected to a virtual switch, or possibly several virtual switches.

The host connects the virtual switch to the physical switch. This scenario has advantages where the inter-guest communication is performance-critical and also where no 802.1Qbg enabled switches are available.

In order to manage and potentially limit the network activities of the guest machines, network filters can be added to the virtual machine definition. The implementation of these network filters is a combination of iptables (layer 3) and ebtables (layer 2) rules, but the network filter rules are specified in an

(22)

The state of the virtual switch can be queried through SNMP. The setup of the net-snmp daemon to serve the bridge MIB is described in “The SNMP bridge management information base” on page 18.

Filtering

Filtering allows the hypervisor to control which network packets are sent to, or received from, a virtual machine.

For more information about network filters, including information about writing custom filters, see "Network Filters" at libvirt.org.

Adding a filter reference to the domain XML

You can add a filter reference to a guest XML definition by adding a <filterref/> element to the network interface definition using the virsh edit <virtual machine> command.

In the following example, the no-spoofing filter is added: ... <interface type=’network’> <mac address=’52:54:0:11:11:11’/> <source network=’mynet’/> <model type=’virtio’/> <filterref filter=’no-spoofing’/> </interface> ... Related concepts:

The no-spoofing filter

The no-spoofing filter in this example references the respective filter for preventing MAC, IP, and ARP spoofing.

The xml file for the no-spoofing filter can be created by creating a file calledno-spoofing.xmlwith the following content:

Then, define the file to libvirt with the following command: virsh nwfilter-define no-spoofing.xml

(23)

Tip: A filter can be examined using the following command: virsh nwfilter-dumpxml no-spoofing

You can see the effect of specifying the no-spoofing filter when you view the ebtables output, as shown in the following examples:

1. With no virtual machine running, the output looks similar to the following: # ebtables -t nat -L

Bridge table: nat

Bridge chain: PREROUTING, entries: 0, policy: ACCEPT Bridge chain: OUTPUT, entries: 0, policy: ACCEPT Bridge chain: POSTROUTING, entries: 0, policy: ACCEPT

2. After starting the virtual machine with the no-spoofing filter, the output looks similar to the following:

# ebtables -t nat -L Bridge table: nat

Bridge chain: PREROUTING, entries: 1, policy: ACCEPT -i vnet0 -j libvirt-I-vnet0

Bridge chain: OUTPUT, entries: 0, policy: ACCEPT Bridge chain: POSTROUTING, entries: 0, policy: ACCEPT Bridge chain: libvirt-I-vnet0, entries: 4, policy: ACCEPT -s ! 52:54:0:6e:4c:17 -j DROP

-p IPv4 -j ACCEPT -p ARP -j ACCEPT -j DROP

3. When the virtual machine requests an IP address through DHCP, the output looks similar to the following:

ebtables -t nat -L Bridge table: nat

Bridge chain: PREROUTING, entries: 1, policy: ACCEPT -i vnet0 -j libvirt-I-vnet0

Bridge chain: OUTPUT, entries: 0, policy: ACCEPT Bridge chain: POSTROUTING, entries: 1, policy: ACCEPT -o vnet0 -j libvirt-O-vnet0

Bridge chain: libvirt-I-vnet0, entries: 2, policy: ACCEPT -p IPv4 -j I-vnet0-ipv4

-p ARP -j I-vnet0-arp

Bridge chain: libvirt-O-vnet0, entries: 1, policy: ACCEPT -p ARP -j O-vnet0-arp

Bridge chain: I-vnet0-ipv4, entries: 2, policy: ACCEPT -s ! 52:54:0:11:11:11 -j DROP

-p IPv4 --ip-src ! 192.168.122.40 -j DROP

Bridge chain: I-vnet0-arp, entries: 6, policy: ACCEPT -s ! 52:54:0:11:11:11 -j DROP

-p ARP --arp-mac-src ! 52:54:0:11:11:11 -j DROP -p ARP --arp-ip-src ! 192.168.122.40 -j DROP -p ARP --arp-op Request -j ACCEPT

(24)

-j DROP

Bridge chain: O-vnet0-arp, entries: 5, policy: ACCEPT

-p ARP --arp-op Reply --arp-mac-dst ! 52:54:0:11:11:11 -j DROP -p ARP --arp-ip-dst ! 192.168.122.40 -j DROP

-p ARP --arp-op Request -j ACCEPT -p ARP --arp-op Reply -j ACCEPT -j DROP

These ebtables rules only allow packets to and from the virtual machine with the specified MAC and IP values. All other packets are dropped, therefore effectively preventing spoofing attacks of the virtual machine.

The SNMP bridge management information base

With the bridge, you can query information about the virtual switch in the KVM hypervisor through SNMP.

This ability can be exploited by IBM Director, IBM Tivoli Network Manager, and other SNMP-capable tools. The SNMP bridge Management Information Bases (MIBs) define the representation of the bridge data:

v _{802.1d Bridge MIB RFC 2674, for switches with no VLANs (located in the}

/usr/share/mibs/ietf/Q-BRIDGE-MIBdirectory oflibsmi-0.4.8in Red Hat Enterprise Linux 6.x)

v _{802.1q Bridge MIB RFC 4363, for switches with VLANs (located in the}

/usr/share/mibs/ietf/P-BRIDGE-MIBdirectory oflibsmi-0.4.8in Red Hat Enterprise Linux 6.x). For more information about this bridge, see Definitions of Managed Objects for Bridges with Traffic Classes, Multicast Filtering, and Virtual LAN Extensions.

v _{The Bridge MIB module for managing devices that support IEEE 802.1D (RFC 4188):} – RFC 1286 (1st rev)

– RFC 1493 (2nd rev)

For more information about this bridge module, see Definitions of Managed Objects for Bridges. In Red Hat Enterprise Linux 6.0, only RFC 4188 was supported. Support for RFC 4363 (VLAN support) was added in Red Hat Enterprise Linux 6.1.The following sections gives a short outline about how to install, configure and verify the support of the bridge MIB. The bridge MIB is implemented as a Perl extension for the net-snmp daemon.

If those files are missing useyum install libsmi-0.4.8-4.el6.x86_64 to install them. Related concepts:

Installing net-snmp

Before using the SNMP MIB, you must install the net-snmp package. To install the net-snmp package, run the following command: yum install net-snmp

(25)

This command also installs all prerequisite packages. Related concepts:

Installing net-snmp-perl

Before using the SNMP MIB, you must install the net-snmp-perl package.

The bridge MIB implementation is in the/usr/bin/snmp-bridge-mibdirectory, part of the net-snmp-perl RPM, which is installed with following command:

yum install net-snmp-perl Related concepts:

Installing net-snmp-utils

Before using the SNMP MIB, you must install the net-snmp-utils package.

The successful configuration of the bridge MIB can be verified with the snmpwalk utility, part of the net-snmp-utils RPM, which is installed with the following command:

yum install net-snmp-utils.x86_64 Related concepts:

Configuring and verifying net-snmp

Before using SNMP MIB, configure and verify bridge support.

Before you begin

For testing purposes only, you can grant access to snmpd for all users by adding the following line to the

/etc/snmp/snmpd.conffile: rocommunity public

Note: This access should be granted only for testing purposes. In a production environment, be sure to replace this line with the correct access controls for your environment.

Procedure

1. Start the snmp daemon: service snmpd restart

Stopping snmpd: [FAILED]

Starting snmpd: [ OK ]

(26)

snmpwalk -Os -c public -v 2c localhost .1.3.6.1.2.1.17.4 mib-2.17.4 = No Such Object available on this agent at this OID

3. Configure support for the bridge MIB module by adding the following line to the

/etc/snmp/snmpd.conffile: master agentx

The changes to the/etc/snmp/snmpd.conffile look similar to the following: --- /etc/snmp/snmpd.conf 2010-07-28 10:14:00.000000000 +0200 +++ snmpd.conf 2010-08-10 22:40:37.000000000 +0200 @@ -16,6 +16,7 @@ # Access Control ########################################################################### +rocommunity public

# As shipped, the snmpd demon will only respond to queries on the # system mib group until this file is replaced or modified for

# security purposes. Examples are shown below about how to increase the @@ -460,3 +461,4 @@

# Further Information #

# See the snmpd.conf manual page, and the output of "snmpd -H". +master agentx

4. Restart snmpd: service snmpd restart

Stopping snmpd: [ OK ]

Starting snmpd: [ OK ]

5. Run the following perl script: perl /usr/bin/snmp-bridge-mib virbr0

6. Verify that the bridge is configured. In this example, there is no virtual machine connected to the bridge. The followingsnmpwalkcommand typically generates a long return.

snmpwalk -c public -v2c -m +BRIDGE-MIB -M +/usr/share/mibs/ietf/ \ localhost .1.3.6.1.2.1.17

The MAC address of the virtual machine is used to verify correct operation. Assuming the MAC address contains the string “4C:17,” then when you grep for the MAC address, no output is returned if the virtual machine is not running:

snmpwalk -c public -v2c -m +BRIDGE-MIB -M +/usr/share/mibs/ietf/ \ localhost .1.3.6.1.2.1.17 | grep "4c:17"

7. Start a virtual machine that connects to the bridge using thevirsh start <virtual-machine> command, and then run the same command from Step 6 again:

BRIDGE-MIB::dot1dTpFdbAddress.’RT.nL.’ = STRING: 52:54:0:6e:4c:17 BRIDGE-MIB::dot1dTpFdbAddress.’.T.nL.’ = STRING: fe:54:0:6e:4c:17

8. Shutdown the virtual machine and wait at least 30 seconds to run the command again and verify that the output is empty:

Results

(27)

(28)

(29)

Chapter 5. Relevant standards and protocols

The relevant 802.1Qbg protocols are listed for your convenience.

v _{External Virtual Bridging protocol (EVB) uses LLDP as transport} – Defines locus of VM to VM switching

– Set VEPA or VEB mode

v _{Channel Discovery and Configuration Protocol (CDCP) [Not Implemented]}

– Virtualize the physical link to simultaneously support multiple VEPA/VEB components v _{Edge Control Protocol (ECP)}

– ECP provides a reliable, acknowledged protocol for VDP rather than using LLDP v _{Virtual Station Interface (VSI) Discovery Protocol(VDP)}

– Associate and De-associate interface MAC/VLAN to port profile Related concepts:

(30)

(31)

Chapter 6. Shared storage pools

For live migration, the source and the target host of the to-be-migrated guest must both have access to the virtual disk of the guest. You can ensure this access by using a shared storage pool.

In the following example, an NFS server is used, which exports a directory to all the host machines: showmount -e dcnserver

Export list for dcnserver: /server/sas/nfs *

The definition of an NFS-based stored pool looks similar to the following: <pool type=’netfs’> <name>dcnserver</name> <uuid>178a678a-ab47-b26b-cdcc-5bc3a33ffd79</uuid> <capacity>1082195443712</capacity> <allocation>24719130624</allocation> <available>1057476313088</available> <source> <host name=’dcnserver’/> <dir path=’/server/sas/nfs/images’/> <format type=’auto’/> </source> <target> <path>/var/lib/libvirt/images</path> <permissions> <mode>0700</mode> <owner>-1</owner> <group>-1</group> </permissions> </target> </pool>

The disk from the storage pool is referenced in the domain xml: <devices>

...

... </devices>

Note also that the <shareable/> element is added to the disk definition. Related concepts:

(32)

(33)

Chapter 7. Configuring the network for virtual machines in a

data center

Learn how to configure virtual machines to connect more directly to the physical network adapter (Virtual Ethernet Port Aggregator/VEPA mode) and the necessary steps to use 802.1Qbg to configure the physical switches. You can also learn how to configure virtual machines connected to a virtual switch to use network filters (Virtual Ethernet Bridge/VEB mode). Key tools and technologies discussed in this demonstration include libvirt, net-snmp, and the lldpad daemon.

Scope, requirements, and support

Systems to which this information applies

System x running Linux

New in the second edition (March 2013)

v _{Support for 802.1 Qbg over bonding devices in Red Hat Enterprise Linux 6.4}

Intended audience

This blueprint is intended for advanced Linux®system administrators and programmers who need to configure virtual and physical switches in a Red Hat Enterprise Linux 6.1 KVM hypervisor environment.

Scope and purpose

To complete the instructions in this blueprint, the virtual machines must already be defined. Only the differences to a normal libvirt network setup are described. The process of defining virtual machines and all the details of a libvirt network setup is outside the scope of this blueprint.

This blueprint provides information about configuring libvirt to use macvtap devices for virtual network interfaces, and how to use the 802.1Qbg Virtual Station Interface (VSI) types with physical switches. This document also provides information about configuring the network filter for virtual switches in a libvirt-controlled environment, and the necessary changes to the appropriate XML files with the help of the virsh tool.

Test environment

The instructions in this blueprint were tested on System x® _{HS22 blade systems running Red Hat}

Enterprise Linux 6.1 KVM Hypervisor with already defined virtual machines. The HS22 blade systems were connected to a VEPA and 802.1 Qbg enabled switch.

Hardware, software, and other prerequisites

Host machines must be running either Intel VT chipsets or AMD-V chipsets that support

hardware-assisted virtualization. For more information about hardware requirements, see the′′Enabling KVM support on your hardware′′section of the Quick Start Guide for installing and running KVM.

(34)

Author names

Gerhard Stenzel Jens Osterkamp Thomas Richter

Other contributors

Santwana Samantray Heather Crognale

IBM Services

Linux offers flexibility, options, and competitive total cost of ownership with a world class enterprise operating system. Community innovation integrates leading-edge technologies and best practices into Linux.

IBM is a leader in the Linux community with over 600 developers in the IBM Linux Technology Center working on over 100 open source projects in the community. IBM supports Linux on all IBM servers, storage, and middleware, offering the broadest flexibility to match your business needs.

For more information about IBM and Linux, go to ibm.com/linux (https://www.ibm.com/linux)

IBM Support

Questions and comments regarding this documentation can be posted on the developerWorks Systems Management Blueprint Community Forum: developerWorks Linux Virtualization Blueprint Community Forum

The IBM developerWorks discussion forums let you ask questions, share knowledge, ideas, and opinions about technologies and programming techniques with other developerWorks users. Use the forum content at your own risk. While IBM attempts to provide a timely response to all postings, the use of this developerWorks forum does not guarantee a response to every question that is posted, nor do we

validate the answers or the code that are offered.

Network setup

The use of virtual machines in physical host machines leads to a situation where there is no longer a strict separation between host and network administration because some form of virtual network setup is needed to connect the virtual machines to the physical network.

Depending on the type of workload on the virtual machines and the type of communication between them, the spectrum of the network setup for the guest within the hosts can range from a dedicated network card for a guest to a fully administratable virtual switch with advanced routing and filtering capabilities. In this blueprint, two complementary scenarios are considered:

v _{the VEPA scenario, or network centric scenario, where the administration of the network happens in} one or more physical switches, and where the virtual machines are connected to the physical network as closely as possible.

v _{the VEB scenario, or host centric scenario, where all administration including the administration of the} virtual network and switches happens in the hypervisor host machines.

(35)

Managing virtual machines with libvirt

Both scenarios described in this blueprint assume that you will use libvirt.

Many libvirt tasks, like defining, starting, or migrating a virtual machine can be accomplished using virsh, the command-line utility. The graphical interface to libvirt, virt-manager, does not currently support all of the features discussed in this blueprint. If you decide to use virt-manager, though, you can do so with some manual editing of the virtual machine definition (the details of which are outside of the scope of this blueprint).

For more information about using libvirt, see http://libvirt.org/docs.html. Related concepts:

Considerations for live migration

Live migration of virtual machines requires that the virtual disk of a virtual machine is stored on a shared resource accessible to both source and target host. For example an NFS-based or iSCSI-based storage pool.

For more information about live migration of virtual machines, see http://www.redhat.com/docs/en-US/Red_Hat_Enterprise_Linux/6-Beta/html/Virtualization/

The VEPA scenario

In the VEPA scenario, the virtual machines are connected to the physical network as closely as possible, so that the virtual network interface is directly connected to the physical network interface of the host without going through the virtual bridge of the Linux host.

All network traffic from a virtual machine goes to the switch first, effectively bypassing the internal bridge even if the network traffic is intended for the host or another virtual machine on the same host. Communication between virtual machines on the same host therefore requires that the respective switch port is put in 'reflective relay' mode. This kind of communication will also impact the overall bandwidth of the respective physical interface and the latency of the network traffic.

(36)

Adding a VEPA interface to a virtual machine

A VEPA interface is added to a virtual machine by specifying the "direct" interface type in the domain XML.

A typical network interface definition looks similar to the following: <devices> ... <interface type=’network’> <mac address=’d0:0f:d0:0f:02:01’/> <source network=’default’/> <model type=’virtio’/> </interface> ... </devices>

Change the interface definition using thevirsh edit <virtual machine>command as follows to add a VEPA interface to a virtual machine (using eth2 with VLAN ID 20 in this example).

Note: If you are using BNT switches, the VLAN ID should be in the range of 2 to 4094. <devices>

...

(37)

... </devices>

This change causes libvirt to create a macvtap device, tie it to the specified physical network interface, and then pass the macvtap file descriptor to QEMU upon virtual machine start. This sequence works similarly for virtual machine shutdown and migration.

While using the VEPA mode provides the base for the network-centric management of the virtual

machines network activities, an additional step is necessary to actually do this: enforcing port policies. In this case, 802.1Qbg VSI types.

Adding 802.1Qbg VSI types to a VEPA interface

The VSI types are defined and stored in a database with an associated unique ID. The switch advertises its support for 802.1Qbg capabilities, including reflective relay.

On the KVM host, the link layer discovery protocol agent daemon (lldpad) is used to configure the port in VEPA mode (hairpin mode), effectively offloading packet-switching functions from the KVM host to the adjacent switch. The lldpad daemon is notified by libvirt if VSI types are to be applied to a specific MAC/physical port pair. The unique ID of the VSI type and the virtual NIC MAC/VLAN information is registered with the adjacent switch port through lldpad and the switch retrieves the VSI type that is based on the unique ID and associates the rules against the registered MAC/VLAN.

802.1Qbg requires support from the physical switch that is connected to the server. See your switch user guide to determine whether the switch supports 802.1Qbg, and how to configure it. Both IBM blade switches and rack switches support 802.1Qbg. If necessary, upgrade to a newer switch firmware version. Configuration typically involves enabling EVB on the switch port, and configuring connection details for the VSIDB server.

For more information about how to configure a switch for VEPA, see chapter 6 of the Implementing a VM-Aware Network Using VMready (http://www.redbooks.ibm.com/abstracts/sg247985.html) IBM Redbooks publication.

Note: The switch IBMNOS allows a port to be configured with "tag-pvid". With this configuration, all packets that are leaving the port are tagged, including the LLDP and ECP packets. This configuration is not recommended for ports on which 802.1Qbg is used because it is not supported by the current lldpad implementation

Installing and starting the lldpad daemon

To configure the port in VEPA mode, install and start the link layer discover protocol agent daemon (lldpad).

(38)

Procedure

1. Install the lldpad daemon with the following command: yum install lldpad

2. Start the lldpad daemon with the following commands: service lldpad start

3. Enable the admin status for the interface that is connected to the switch (in this example eth2) with the following commands:

Note: These two commands address the nearest bridge and the nearest customer bridge. lldptool -L -i eth2 adminstatus=rxtx

lldptool -i eth2 -g ncb -L adminstatus=rxtx

4. Enable transmission of the EVB TLV (edge virtual bridging type length value message) and then configure reflective relay mode and capabilities with the following sets of commands for both the nearest bridge and for the nearest customer bridge. For Red Hat Enterprise Linux 6.4 and later, lldpad uses only the nearest customer bridge.

a. For the nearest bridge (unnecessary for Red Hat Enterprise Linux 6.4 and later): lldptool -T -i eth2 -V evbCfg -c enableTx=yes

lldptool -T -i eth2 -V evbCfg -c fmode=reflectiverelay lldptool -T -i eth2 -V evbCfg -c capabilities=rte,ecp,vdp b. For the nearest customer bridge:

lldptool -i eth2 -T -g ncb -V evbCfg -c enableTx=yes

lldptool -i eth2 -T -g ncb -V evbCfg -c fmode=reflectiverelay lldptool -i eth2 -T -g ncb -V evbCfg -c capabilities=rte,vdp,ecp c. Display the EVB parameters:

lldptool -t -i eth2 -g ncb -V ecbCfg -c enableTx lldptool -t -i eth2 -g ncb -V ecbCfg -c fmode lldptool -t -i eth2 -g ncb -V ecbCfg -c capabilities 5. Enable VDP with the following commands:

Note: These commands address the nearest bridge and the nearest customer bridge. Red Hat Enterprise Linux 6.3 and before

lldptool -T -i eth2 -V vdp -c enableTx=yes lldptool -i eth2 -T -g ncb -V vdp -c enableTx=yes Red Hat Enterprise Linux 6.4 and later

lldptool -i eth2 -T -g ncb -V vdp -c enableTx=yes 6. Restart the lldpad daemon with the following command:

service lldpad restart

Results

All the changes made with lldptool as above have to be made only once and will be saved to the lldpad configuration file. They will available to lldpad automatically on the next start. The changes can be verified by examining the/var/lib/lldpad/lldpad.conffile. The changes due to step 4a arehighlighted: dcbx : { version = "1.0"; dcbx_version = 2; }; nearest_customer_bridge : { eth2 : { tlvid00000001 : { info = "04001B2163BEE8";

(39)

}; tlvid00000002 : { info = "03001B2163BEE8"; }; adminStatus = 3; tlvid001b3f00 : { capabilities = "rte,vdp,ecp"; fmode = "reflectiverelay"; enableTx = true; }; vdp : { enableTx = true; }; }; ... }; lldp : { eth2 : { tlvid00000001 : { info = "04001B2163BEE8"; }; tlvid00000002 : { info = "03001B2163BEE8"; }; adminStatus = 3; vdp : { enableTx = true; }; tlvid001b3f00 : { enableTx = true; info = "001B3F0080070000DF0C00000F"; capabilities = "rte,ecp,vdp"; fmode = "reflectiverelay"; }; }; ... };

v _{The status of the negotiation of EVB capabilities can be queried with lldptool with the following} command for the nearest bridge:

lldptool -t -i eth2 -V evbcfg

v _{The status of the negotiation of EVB capabilities can be queried with the}_{-g ncb}_{option for the nearest} customer bridge:

lldptool -i eth2 -t -g ncb -V evbcfg

(40)

EVB Configuration TLV

Note: The displayed values of configured forwarding mode and configured capabilities, shown as 0, are incorrect on some Red Hat Enterprise Linux 6.x versions.

Specifying a VSI type

Specify the VSI type for a VEPA interface by adding a <virtualport/> element to the domain XML using virsh edit.

The parameters of the virtualport element are documented in more detail in the IEEE 802.1Qbg standard. The values are network specific and should be provided by the network administrator. In 802.1Qbg terms, the Virtual Station Interface (VSI) represents the virtual interface of a virtual machine.

Important: Be sure to adapt the attribute values for the <parameter/> element to your specific network environment.

<devices> ...

<mac address=’d0:0f:d0:0f:02:01’/> <source dev=’eth2.20’ mode=’vepa’/> <source network=’default’/> <virtualport type=’802.1Qbg’> <parameters managerid=’12’ typeid=’0x123456’ typeidversion=’1’ instanceid=’09b00c53-8b5c-4eeb-8f00-d847aa05191b’ /> </virtualport> <model type=’virtio’/> </interface> ... </devices> Related concepts:

VM startup

When the virtual machine is started, libvirt parses the virtualport type, determines the physical device (nth parent) and VLAN ID, and sends a netlink message with an 'ASSOCIATE' request to the lldpad daemon.

(41)

The lldpad daemon then sends an ASSOCIATE VDP message on the physical interface to the switch. Depending on the success or failure of registering the VSI type, you will see one of the following messages.

Table 2. System status messages

Output message shown Status

virsh start testvm3

error: Failed to start domain testvm3 error: internal error sending of

PortProfileRequest failed

The lldpad daemon is not running.

virsh start testvm3

error: Failed to start domain testvm3 error: internal error port-profile

setlink timed out

The environment does not have an 802.1Qbg enabled switch.

virsh start testvm3 Domain testvm3 started

The virtual machine is successfully created.

You can verify the status of the association of the profile with the following command: lldptool -t -i eth2 -V vdp mode

The output will look similar to the following output: mode = mode: 2 (VDP_MODE_ASSOCIATED) response: 0 (success) state: 2 (VSI_ASSOCIATED) mgrid: 12 id: 1193046 (0x123456) version: 3 instance: 09b00c53-8b5c-4eeb-8f00-d847aa05191b mac: d0:0f:d0:0f:02:01 vlan: 20 Related concepts:

VM migration

Live migration allows you to migrate a virtual machine from one host to another host while the virtual machine continues to run seamlessly.

The virtual disk of the virtual machine is located in a shared storage pool and should be mounted on both the source and destination. Configuring SSH to authenticate without requiring passwords will simplify the migration process.

(42)

Migrating your VM

Use this procedure to migrate your virtual machines.

Before you begin

This procedure assumes that SSH keys are already set for password-less authentication. If you do not have SSH keys set for password authentication, do so before continuing with this procedure.

Procedure

1. Verify that password-less authentication is working: virsh -c qemu+ssh://c7b5/system list --all

Id Name State

--- testvm3 shut off

2. Verify that the virtual machine is running locally: virsh list --all

Id Name State

3. Migrate the virtual machine to the destination host: virsh migrate testvm3 qemu+ssh://c7b5/system

4. Verify that the virtual machine is running on the destination: virsh -c qemu+ssh://c7b5/system list --all

Id Name State

5. Migrate the virtual machine back with one of the following command strings: v [root@c7b4 ~]# virsh --connect qemu+ssh://c7b5/system \

migrate testvm3 qemu+ssh:///system

v virsh --connect qemu+ssh://c7b5/system migrate testvm3 \ qemu+ssh://c7b4/system

Shutting down a virtual machine

You can shut down a virtual machine from either directly within the virtual machine or by using the virshcommand from the host.

To shut down the virtual machine from the host, use the following command: virsh shutdown testvm3

If the command is successful, the following output is displayed: Domain testvm3 is being shutdown

(43)

Configuring a bonding device

Use this procedure to configure a bonding device for lldpad.

Before you begin

Beginning with Red Hat Enterprise Linux 6.4, lldpad supports bonding devices. Only active-backup mode is supported. In this example, a bond device named bond0 has an IP address of 192.168.0.5, and two slaves named eth2 and eth3.

Note: Switch configuration to support a bond device on an HS22 blade has the following characteristics and limitations:

v _{Slave devices must be connected to a different switch device. The switch firmware does not support} EVB protocol on external ports.

v _{Switches must be interconnected. Use an external port between both switches.}

v _{Enable the external ports on both switches to transfer traffic for the VLAN id that is defined in the} lldpad configuration section.

To configure a bonding device for lldpad, complete the following procedure:

Procedure

1. Install the bonding device driver:

modprobe bonding mode=active-backup miimon=100 A device named bond0 is available.

2. Assign an IP address to the bond0 device:

ifconfig bond0 192.168.0.5 netmask 255.255.255.0 up 3. Create slaves and assign them to the bond0 device:

ifenslave bond0 eth2 eth3

4. Assign a VLAN device that is named bond0.4 on top of the bond0 device: vconfig add bond0 4

A new device that is called bond0.4 is associated with VLAN id 4. 5. Assign an IP address the the bond0.4 VLAN device:

ifconfig bond0.4 192.168.4.5 netmask 255.255.255.0 up lldpad uses the device bond0 for switch communication. 6. Enable transmission of the EVB TLV for the bond0 device:

a. For the nearest customer bridge:

lldptool -i bond0 -T -g ncb -V evbCfg -c enableTx=yes

lldptool -i bond0 -T -g ncb -V evbCfg -c fmode=reflectiverelay lldptool -i bond0 -T -g ncb -V evbCfg -c capabilities=rte,vdp,ecp lldptool -i bond0 -T -g ncb -V vdp -c enableTx=yes

lldptool -i bond0 -L -g ncb adminstatus=rxtx b. Display the EVB parameters:

Blueprints. Configuring the network for virtual machines in a data center

Blueprints

Configuring the network for virtual machines in a data

center

Blueprints

Configuring the network for virtual machines in a data

center

Contents

Chapter 1. Scope, requirements, and

support . . . 1

Chapter 2. Network setup . . . 3

Chapter 3. The VEPA scenario . . . 5

Chapter 4. The VEB scenario . . . 15

Chapter 5. Relevant standards and

protocols. . . 23

Chapter 6. Shared storage pools

. . . 25

Chapter 7. Configuring the network for

virtual machines in a data center . . . 27

Notices

. . . 47

Chapter 1. Scope, requirements, and support

Systems to which this information applies

New in the second edition (March 2013)

Intended audience

Scope and purpose

Test environment

Hardware, software, and other prerequisites

Author names

Other contributors

IBM

Services

IBM Support

Chapter 2. Network setup

Managing virtual machines with libvirt

Considerations for live migration

Chapter 3. The VEPA scenario

Adding a VEPA interface to a virtual machine

Adding 802.1Qbg VSI types to a VEPA interface

Installing and starting the lldpad daemon

Procedure

Results

Specifying a VSI type

VM startup

VM migration

Migrating your VM

Before you begin

Procedure

Shutting down a virtual machine

Configuring a bonding device

Before you begin

Procedure

Chapter 4. The VEB scenario

Filtering

Adding a filter reference to the domain XML

The no-spoofing filter

The SNMP bridge management information base

Installing net-snmp

Installing net-snmp-perl

Installing net-snmp-utils

Configuring and verifying net-snmp

Before you begin

Procedure

Results

Chapter 5. Relevant standards and protocols

Chapter 6. Shared storage pools

Chapter 7. Configuring the network for virtual machines in a

data center

Scope, requirements, and support

Systems to which this information applies

New in the second edition (March 2013)

Intended audience

Scope and purpose

Test environment

Hardware, software, and other prerequisites

Author names

Other contributors

IBM Services

IBM Support

Network setup
