CertainTeed. Soffit and Vertical Siding

(1)

Soffit and Vertical Siding

CertainTeed

(2)

PERIMETER

™

TRIPLE 3

-1/3

"

Triple 3

-1/3

" InvisiVent

®

has the highest ventilation

performance of any vinyl soffit available today.

Soffit: Triple 3-1/3" InvisiVent Soffit in colonial white.

Siding: CedarBoards Double 6" Clapboard in timber blend.

Perimeter Triple 3-1/3" offers a smooth,

flat surface and provides the perfect

balance of aesthetics and performance.

Front Cover

Soffit: Triple 3-1/3" Soffit in colonial white. Siding: Cedar Impressions Double 7" Straight Edge

Perfection Shingles in natural clay. Trim: Vinyl Carpentry®_{& Restoration Millwork}®_. Shown Here

Soffit: Perimeter Triple 3-1/3" Soffit in colonial white. Siding: Cedar Impressions Double 7" Perfection

Shingles in charcoal gray.

Trim: Vinyl Carpentry®_{& Restoration Millwork}®_.

TRIPLE 3

-1/3

"

(3)

The classic appearance of wainscoting

offers the look of fine detailing

and craftsmanship.

The authentic look of beveled-edge wood

plus the durability of vinyl siding.

Combines the attractive appeal of

wood with the rigidity and durability of

premium extra-thick vinyl.

CHAMFER BOARD

™

DOUBLE 5"

IRONMAX

™

DOUBLE 5"

BEADED TRIPLE 2"

Beautifies the overhangs of any home

and delivers outstanding performance,

quality and durability.

(4)

PERIMETER

™

TRIPLE 3

-1/3

"

Soffit Vents (intake) Ridge Vents (exhaust)

The Air Balance System

Experts agree that the most effective system is a balance of air intake and exhaust that creates a uniform flow of air through the attic.

This system creates a condition in which the roof temperature is equalized from top to bottom, supplying a uniform air flow along the entire underside of the roof deck.

Triple 3-1/3" InvisiVent and Hidden Vent offers at least 50% more ventilation than most standard vinyl soffit, providing more than 10" of net-free intake area.

This means that not only will InvisiVent provide a balanced ventilation system, but will do so with an overhang as short as 10".

Protection against damage

to the roofing materials and

structure increase comfort inside

the home and energy savings.

TRIPLE 3

-1/3

" SOLID

Perfect for Vertical

Siding Applications, Too.

Solid Triple 3-1/3" vertical siding panels are the ideal solution for accent areas where a vented panel is not necessary. The flat face design creates a straighter panel with the look of smooth, painted wood. Deep dovetails between panel faces contribute extra rigidity, while forming a clear, sharp edge that is pleasing to the eye. Ideal as an accent or coordinating panel, Solid Triple 3-1/3" is available in the same color palette as Triple 3-1/3" InvisiVent.

Hidden vents provide a smooth, flat non-perforated surface versus most vented soffits with unsightly perforations.

Standard vented soffit

Triple 3-1/3" InvisiVent

PROPER VENTILATION

IS VITAL

TRIPLE 3

-1/3

"

(5)

Value Triple 4" & Double 5" Soffit

9 colors in Triple 4": colonial white, snow, heritage cream, herringbone, desert tan, light maple, sterling gray, savannah wicker and natural clay 5 colors in Double 5": colonial white, desert tan, savannah wicker, sterling gray and natural clay

All CertainTeed Soffits Feature:

u Virtually maintenance free, never needs painting.

u Class 1(A) fire rating.

u Lifetime limited warranty.

Triple 3

-1/3

"

u InvisiVent®₌_{and solid styles.}

u InvisiVent® _{is the only vinyl soffit to}

provide more than 10 inches of

net-free intake area.

u Concealed intake vents provide

a smooth appearance.

u Matte finish looks like freshly

painted wood.

u Deep 3/4" panel projection creates sharp definition.

u 13 low-gloss colors.

u Heavy-duty .044" thickness for rigidity.

Perimeter Triple 3

-1/3

"

u Solid and hidden vent styles.=

u .040" thickness.

u Hidden vent style provides up to

9.65"of net-free intake area.

Chamfer Board

™

_{Double 5"}

u Solid and fully vented soffit.=

u Extra thick .044" construction.

u Designed for vertical siding, porch ceiling and soffit application.

u 6.4" of net-free air per sq. ft. – fully vented.

Ironmax

™

_{Double 5"}

u Solid and fully vented styles.=

u Extra-thick .046" construction for optimum strength and flat face appearance.

u Designed for vertical siding, porch ceiling and soffit applications.

u Unique post-formed lock design

helps ensure secure installation.

u 32 low-gloss woodgrain colors (sable brown, pacific blue, ivy green,

autumn red, charcoal gray and forest for soffit applications only).

u 6.4" of net-free air per sq. ft. – fully vented.

Beaded Triple 2"

u Wainscot style in solid and invisibly vented.=

u Smooth finish appearance of professionally applied paint. u Extra-long slip-lock design helps provide secure installation. u 8 low-gloss colors.

u .039" thickness.

u 1.6"of net-free air per sq. ft. – invisibly vented.

Universal Triple 4"

u Solid, fully vented and center vented styles.=

u Matte finish.

u Post-formed lock design helps

provide secure installation.

u 36 low-gloss colors. u .040" thickness.

u 5.9" of net-free air per sq.ft. – fully vented. u 2" of net-free air per sq. ft. – center vented.

2" 2" 2" 3/8"

4" 4" 4" 7/16"

NOTE: Colors throughout this brochure are simulated. Consult product samples before making final selection.

** PREMIUM COLORS * DELUXE COLORS = SOFFIT USE ONLY

V

alue T

riple 4" & Double 5"

(Sof

fit Use Only)

Universal T riple 4" Beaded T riple 2" Ir onmax ™ Double 5" Chamfer Boar d ™ Double 5" Perimeter T riple 3-1/3" Triple 3-1/3"

Color performance, impact resistance and durability are assured through our exclusive PermaColor™_System, a blend of our own Certavin™_resin, superior micro-ingredients and state-of-the-art pigment chemistry.

TM

LIFETIME

_{F A D E P R O T E C T I O N} TM Arbor Blend l Arctic Blend l Weathered Blend l Frontier Blend l Timber Blend l Canyon Blend l Meadow Blend l Glacier Blend l

Musket Brown (soffit only) l

Autumn Red l= l Terra Cotta l Mountain Cedar l Sable Brown l= l Hearthstone l Suede l Spruce l Forest l= l Ivy Green l= l Pacific Blue l= l Flagstone l Charcoal Gray l l= l Castle Stone l Granite Gray l l l l l Sterling Gray l l l l l l l Bermuda Blue l Oxford Blue l l Seagrass l l l l Cypress l l l l l Green Tea l Linen l l Silver Ash l l Warm Sand l l Herringbone l l l l l Sandstone Beige l l l l l Desert Tan l l l l l l Natural Clay l l l l l l l Savannah Wicker l l l l l l l Light Maple l l l l l l Buckskin l l Sandpiper l Heritage Cream l l l l l l l Autumn Yellow l Snow l l l l l l Colonial White l l l l l l l ** ** ** ** ** * * * **

3-1/3"3-1/3" 3-1/3"

3/4"

_{3-1/3"3-1/3" 3-1/3"}

3-1/3" 3-1/3" 3-1/3"

3/4"

3/4" 5" 5" 9/16" 9/16" 5" 5" 9/16" 5" 5" 5" 5" 9/16" 5" 5" 9/16" 3-1/3" 3-1/3" 3-1/3"3-1/3" 3-1/3" 3-1/3"

3-1/3"3-1/3" 3-1/3"

3/4"

_5/8"

= Vented soffits are for soffit use only.

(6)

CertainTeed

Polymer Shakes & Shingles

Insulated Siding

Roofing and Ventilation

Decking and Railing PVC Exterior Trim & Beadboard

Vinyl Siding Vinyl Carpentry®_Trim _Housewrap

CertainTeed products are designed to work together and complement

each other in color and style to give your home a beautiful finished look.

Fence
