HMIs for the Process Industry

(1)

NEW

for hazardous & industrial areas

(2)

15" DISPLAY

19" DISPLAY

10" DISPLAY

7" DISPLAY

R. STAHL HMI Systems

the right operator interface terminal for each application

Wide Product Portfolio

Interfaces to distributed control systems (DCS),

such as PCS 7, DeltaV, 800xA, Experion, Centum, Freelance, Proficy, Citect, etc.

(3)

22" DISPLAY

24" DISPLAY

24"WU DISPLAY

In Use all over the World

Communicates with PLC brands, such as Siemens, Rockwell, Schneider, Omron,

ABB, Beckhoff, B&R, Mitsubishi, Yokogawa, etc.

(4)

(5)

Why R. STAHL HMI Systems?

4 reasons why R. STAHL HMI systems make the difference:

�

widest range of HMIs (5" – 24"WU displays)

�

all current communications technologies

�

special, in-house developed Remote HMI Firmware for enhanced

data security and user comfort

(6)

Technologies Overview

KVM Systems

�

Ideal for point-to-point connections

�

Fully digital transmission

Thin Client Systems

�

Latest remote access technologies

�

Flexible access from HMI to PCs or virtual PCs

�

Centralized data management

and security management

�

Remote HMI Firmware for enhanced

data security

(7)

Panel PC Systems

�

Intel

®

Atom™

�

Multi-lingual Windows operating systems

�

Backup/recovery system

Operator Interface EAGLE

�

Security-enhanced with own operating system

�

Multi-lingual machine terminal

�

Cost-effective, pre-installed SPSPlusWIN software

Operator Interface SERIES 200

�

Brilliant 7", 800 x 480 widescreen display

�

Extreme temperature range -40 °C … +65 °C

�

Windows

®

Embedded Compact 7 and SPSPlus Runtime

�

Windows

®

Embedded Compact 7 and Movicon Runtime

�

Windows

®

Embedded Compact 7 for third-party software

(8)

SAFE AREA

ZONE 1 / 2 / 21 / 22 / Non-Ex

CAT7 < 150 m (< 500 m on requrest) Fiber optic < 10 km

DVI VGA

KEYBOARD / MOUSE / USB

KVM-DVI-Box

19" / 22" / 24" / 24" WU

�

High-quality KVM system with digital transmission

�

Display sizes: 19" (1:1), or 22" diagonal

�

LED technology delivers best picture quality

�

19", 22", 24", 24"WU

�

1280x1024 / 1650x1080 / 1920x1080 / 1920 x1200

SERIES 600

KVM Systems

The classic KVM system consists of an operator terminal

and a KVM box. The KVM box extends the transmission

distance of VGA interfaces / DVIs, or keyboard and mouse

interfaces of up to 500 m (copper), or 10,000 m (LWL) to

the operator terminal on site – in the hazardous area or

industrial production environment.

The new KVM box DVI3 has been developed in-house

by R. STAHL HMI and specifically designed for use in

the process industries. It allows for transmission of all

current resolutions to the on-site area – 19", 22", 24", and

24"WU. The fully digital data transmission delivers the

best picture quality at the operator terminal, and allows

for "plug & play" operation without any additional driver to

be installed.

(9)

Technical Data

Ex certificates ATEX, IECEx, GOST-R

Design Front panel mounting

Display TFT color display: 19", 22", 24", 24"WU 16.7 m colors

Resolution: 1280x1024 / 1650x1080 / 1920x1080 / 1920x1200 Aspect ratio: 5:4, 16:10, 16:9

Brightness: 250 – 1000 cd/m2_{; contrast ratio: 1000:1} 5-wire resistive touch screen optional

Backlight LED technology

Service life 50,000 at +20 °C

Function keys at display

-External keyboard Yes (optional); 107 keys with trackball / joystick / mouse / touchpad (Ex ia)

Data transmission / cable lengths

KVM box: DVI3 (in resolutions up to 1920 x 1200 pixels) Copper: up to 150 m (500 m optional)

LWL: Multi-mode up to 500 m / single-mode up to 10 km

Interfaces 1 x data (Ex e), or LWL (Ex op is) 2 x USB (Ex ia) 1 x USB (Ex e)

2 x USB (Ex ia) (keyboard, pointing device) 1 x RS-232 (Ex e)

Optional interfaces:

1 x ReaderBox for card reader / barcode scanner WLAN via USB (Ex e)

Power supply 24 VDC (max. = 3A) 100 – 240 VAC (max. = 1A)

Permissible temperature range

Operation -20 °C up to +60 °C

Permanent operation -20 °C up to +50 °C

Operation with optional heater up to -30 °C: -30 °C up to +50 °C (Option only available for AC devices!)

Storage -30 °C up to +70 °C

Heat dissipation approx. 40 % through front plate, approx. 60 % through back plate

Rel. air humidity 10 up to 90 % at +40 °C, non-condensing

Material (front) Aluminum front plate, glass, glass or polyester laminated touch screen optional

Material (back) Galvanized sheet steel

(10)

Network

SAFE AREA

HyperV (Virtualization) Windows Server RDP / VNC / NetC@P RDP / VNC / NetC@P Ethernet CAT7 < 100 m Fiber Optic bis < 2 km

Ethernet CAT7 < 100 m Fiber Optic bis < 2 km

ZONE 1 / 2 / 21 / 22 / Non-Ex

15" / 19" / 22" / 24" / 24"WU

�

RDP, VNC, and Netc@p, also

�

LAN, WLAN, and Internet

�

Remote HMI Firmware for enhanced system security

�

Remote access from any operator terminal to one /

multiple PCs

�

Cost-effective hardware,

centralized data management

SERIES 500

Thin Clients

Our Thin Clients are available in display sizes ranging from

15" up to 24"WU. All operator terminals and components

are designed as panel-mount modules, and install easily

either into existing cabinets, or in our high-quality FR, and

CFR enclosures; wall mounting is also possible.

The KVM-over-IP system has been specifically designed for

network applications that realize single, network-capable

point-to-point connections.

All Thin Clients are delivered with our special Remote

HMI Firmware for enhanced system communication and

improved usability.

(11)

Technical Data

Ex certificates ATEX, IECEx, GOST-R; NEC/UL, CEC/CSA, INMETRO, CNEX, DNV, LR

Display TFT color display: 15", 19", 22", 24", 24"WU 16.7 m colors

Resolution: 1024x768 / 1280x1024 / 1650x1080 / 1920x1080 / 1920x1200 Aspect ratio: 4:3, 5:4, 16:10, 16:9

Brightness: 250 – 1000 cd/m2_{, contrast ratio: 1000:1} 5-wire resistive touch screen optional

Service life 50,000 at +20 °C

Function keys at display

-External keyboard Yes (optional); 107 keys with trackball / joystick / mouse / touchpad (Ex ia)

Operating system / firmware Remote HMI Firmware

based on Windows Embedded Standard 2009 Closed, secure Thin Client system

Interfaces 1 x Ethernet 10/100Base-TX (Ex e), or LWL 1000BASE-SX, 1000 Mbit (Ex op is) 2 x USB (Ex ia)

1 x USB (Ex e)

1 x Audio line out (Ex e) Optional interfaces:

Material (front) Aluminum front plate, glass, glass or polyester laminated touch screen optional

Material (back) Galvanized sheet steel

(12)

APPLICATION STATION / SERVERS

VIRTUALIZATION

OPERATOR STATIONS

CONTROLLER

REMOTE I/O

THIN CLIENT WLAN

THIN CLIENT

KVM OVER IP

The process industries' demand for modern network

technologies, virtual machines, and Thin Clients keeps

growing. The main advantages of these technologies are:

cost-effectiveness, centralized data and security

manage-ment, and a high level of flexibility for remote access.

Thin Clients communicate with other clients / PCs, or

ser-vers over standard Ethernet TCP/IP, RDP, VNC, or Netc@ap,

thus enabling integrated communications across all levels

– from the field level through to the enterprise

manage-ment level (ERP).

Mobile operators working on-site in the hazardous area

can flexibly access any PC, server, or virtual machine from

the Thin Client operator terminal, thus providing

compre-hensive information, and resulting in highly effective

ope-rator control and information management. The network

technology eliminates any distance limitations.

(13)

OPERATING SYSTEM

COMPUTER HARDWARE – CPU / RAM / NIC / HDD

APPLICATIONS SOFTWARE

OPERATING SYSTEM

VIRTUALIZATION LAYER

HOST OPERATING SYSTEM

OPERATING SYSTEM

VIRTUALIZATION LAYER

HOST OPERATING SYSTEM

OPERATING SYSTEM

TYPICAL COMPUTER

SINGLE VM ON HOST

MULTIPLE VMS ON HOST

Fundamental advantages of virtual environments:

�

High level of flexibility, remote access to different kinds of machines

�

Virtual machines are completely hardware independent

�

Virtual machines can run different kinds of operating systems in parallel on one single virtualization software

�

More virtual machines can be added by creating a new VMware session

�

A virtual machine can easily be replaced while running

�

Enhanced security thanks to remote access and centralized hardware management

�

Centralized security management on server for enhanced threat and data protection

�

Reduced acquisition and maintenance costs

(14)

Basic Functions

�

Closed system design

- High degree of protection against external manipulations

- Based on Microsoft Embedded systems

- Defined access via OSD menu or system console

- Keyboard shortcuts for system access disabled (F8, Ctrl-Alt-Del…)

�

Firmware protection by FILE-BASED WRITE FILTER (FBWF)

�

Filtering of all TCP and UDP ports for incoming connections

�

Password protection for OSD entries

�

Integrated network diagnostics

�

Watchdog function for monitoring data communications

Thin Client Diagnostics

�

Ethernet link

�

Local IP address recognizable

�

Ping successful

�

IP address conflict

�

Remote workstation connection not responding

�

RDP/VNC server unavailable

The REMOTE HMI FIRMWARE has been developed by our in-house software experts with focus on secure data

communi-cations and enhanced usability. Over the years and in close cooperation with manufacturers from different industries, the

REMOTE HMI FIRMWARE has been continuously further developed to offer today's wide range of features.

The REMOTE HMI FIRMWARE represents the state of the art in comfortable and highly secure data communications in

industrial networks.

(15)

Operator Menu – OSD

�

Touch screen calibration

�

Display brightness adjustment

�

Right-click de-/activation

�

Operator input block

�

Access to address book

�

Software keyboard in 21 languages

Address Book

�

Connected / not connected

�

Multiple input switch

�

Startup/primary connection

�

Fallback connection

�

Hot key connection

�

Software Support Center

Online Help

Configuration Menu

�

Network configuration for remote HMI

�

Connection details of address book input fields

�

KVM box setting (for KVM box connection)

�

Configuration management via system console

�

Access to integrated offline help / manual

Network Settings

�

Configuration of network settings

�

DHCP / IP address

�

Integrated network scanner

�

Default configuration available

LAN Monitoring

�

ADD MAC address retrieved from scanner

�

PC name

�

Monitoring of selected PCs

Monitoring of all configured PCs

(16)

PLC Siemens Rockwell

Schneider Ex i Barcode Scanner

Ex i Mifare Reader USB Stick (backup) Windows Embedded Windows XP Windows 7 Ultimate

SAFE AREA

ZONE 1 / 2 / 21 / 22 / Non-Ex

VMwareTM Windows ServerTM MPI Ethernet Serial Profibus

Siemens WinCC flexible Rockwell Factory Talk View Schneider Vijeo Citect Ethernet CAT5 < 100 m

Fiber optic < 2 km

10"/ 15"/ 19"/ 22"/ 24"/ 24"WU

�

Ready-to-run, multi-lingual Windows operating system

�

Intel

®

Atom™ processor

�

Open for all types of HMI software, e.g.

- WinCC flexible

®

- Factory Talk View

®

- Vijeo Citect

®

SERIES 400

Panel PCs / Full Clients

The stand-alone HMI Panel PCs can independently perform

process tasks on site, as well as DCS, ERP, or MES task

within the network. The LED backlight technology ensures

best quality and readability of process images on site.

Optionally, the monitor is also available with touch screen

for intuitive operation while wearing gloves, or when using

a touch pen.

The SERIES 400 Panel PCs are ready-to-run worldwide,

with pre-installed, multi-lingual Windows Embedded

Standard 2009, or 7 Ultimate operation system (QNX,

Linux optional) – any further, and often time-consuming,

installation of drivers or operating systems is not required

– READY-TO-RUN.

(17)

Technical Data

Ex certificates ATEX, IECEx, GOST-R; NEC/UL, CEC/CSA, KGS/KCC, INMETRO, CNEX, DNV, LR

Display TFT color display: 10.4", 15", 19", 22", 24", 24"WU 16.7 m colors

Resolution: 800x600 / 1024x768 / 1280x1024 / 1650x1080 / 1920x1080 / 1920x1200 Aspect ratio: 4:3, 5:4, 16:10, 16:9

Brightness: 250 – 1000 cd/m2_{; contrast ratio: 1000:1} 5-wire resistive touch screen optional

Backlight LED technology, service life 50,000 at +20 °C

External keyboard Yes (optional); 107 keys with trackball / joystick / mouse / touchpad (Ex ia)

CPU ATOM 1.6 GHz

Main memory 1 / 2 GB

Memory 4 / 16 GB, 128 GB MLC / SLC (solid state drive)

Extra memory (opt.) Hard drive EXICOM-SHD-xxx 100 GB

Operating system Windows XP Embedded MUI, Windows 7 MUI

Standard software WinCC flexible, IFix, RSView

(for more software solutions, please refer to our homepage)

Interfaces 1 x Ethernet 10/100Base-TX (Ex e), or LWL 1000BASE-SX, 1000 Mbit (Ex op is) 2 x USB (Ex ia)

1 x USB (Ex e)

1 x Audio line out (Ex e) Optional interfaces:

(18)

Network

Ethernet

PLC

SAFE AREA

ZONE 1 / 2 / 21 / 22

SPSPlusWIN / Engineering VNC Viewer / Remote Access Soft-SPS MPI Serial Ex i Barcode Scanner Ex i Mifare Reader SPSPlusWIN VNC Server / Remote Access Ethernet CAT5 < 100 m Fiber optic < 2 km 10" / 15"

�

Multi-lingual machine terminal with own

operating system

�

Modern Ethernet protocols: Ethernet IP / Modbus TCP /

Profinet (HMI layer)

�

Cost-effective SPSPlusWIN software

�

Remote access to network and web server

SERIES 300

Operator Interface

The SERIES 300 terminals come with a powerful CPU, a

high-bright TFT display, and optionally with SPSPlusWIN

software for fast and cost-effective project engineering.

This world-ready software provides a multi-lingual user

in-terface, language file import export function, and supports

international character sets (Unicode).

Functionality and features include recipe management,

Microsoft Excel import / export, Ethernet up- / download,

and an intelligent page navigation.

Designed as a “closed system” that runs its own real-time

operating system, the SERIES 300 is protected against

external virus/malware threats.

(19)

Technical Data

Ex certificates ATEX, IECEx, GOST-R; NEC/UL, CEC/CSA, INMETRO, CNEX, DNV, LR

Display TFT color display: 10.4", 15" 16.7 m colors

Resolution: 800x600 / 1024x768 Aspect ratio: 4:3

Brightness: 400 cd/m2 / 1000 cd/m2 8-wire resistive touch screen as standard

Function keys at display Up to 12 function keys, polyester film on aluminum plate

External keyboard Yes (optional); 105 keys (Ex ia)

CPU LX 800, 266 MHz

Main memory 256 MB

Data memory 256 MB

Extra memory

-Operating system RT Target

Languages Global, multi-lingual support

Interfaces 1 x Ethernet 10/100Base-TX (Ex e), or LWL 100BASE-SX, 100 Mbit (Ex op is) 2 x USB (Ex e)

1 x USB (Ex ib

2 x PS/2 (Ex ia) (keyboard) 1 x RS-232 / RS-422 / RS-485 (Ex e) 1 x Audio line out (Ex e)

Optional interfaces:

1 x RSi (Ex ib) data and supply for reader devices

1 x RS-232 / RS-422 / RS-485 (Ex e) Profibus with 9185/12-46-10 MPI with MPI box SSWZ-RK512-RS-422

Dimensions (W x H x D) 372 x 270 x 150 mm

Wall cutout 359.5 x 257.5 (+/- 0.5) mm

Weight 12.6 kg

Power supply 24 VDC (20.4 – 28.8 VDC); 1.2 A; 28.8 W optional: external power supply 90 – 253 VAC

Operation -20 °C up to +55 °C (optional -30 °C up to -40 °C)

(20)

SAFE AREA

ZONE 1 / 2 / 21 / 22

�

Brilliant 7" color display, 800 x 480 pixels

�

Extreme temperature range from -40 °C up to + 65 °C

�

Windows

®

Embedded Compact 7 and SPSPlusWIN

�

Optionally, open operating system for

third-party software

SERIES 200

Operator Interface

The innovative SERIES 200 Operator Interface with 7"

widescreen display reflects the latest trends in cost-

effective operation, monitoring and visualization at

machine level in hazardous areas Zone 1, 21, for

example close to stirrers or compressors.

With its sophisticated product design, the ET-208 is

extremely rugged, sea-water resistant, and provides IP66

ingress protection from the front. It is suitable for a wide

range of applications across different industries, at

ambient temperatures ranging between -40 °C and +65 °C.

The ET-208 can be configured with our cost-effective

project engineering software SPSPlusWIN, and Windows

®

Embedded Compact 7 operating system. Optionally, for

integration of third-party software, the SERIES 200 is

also available with an open operating system. For further

operating system solutions, please contact us to discuss

the details.

(21)

Technical Data

Ex certificates ATEX, IECEx (pending)

Display TFT color display: 7" 16.7 m colors Resolution: 800x480 Aspect ratio: 15:9 Brightness: 500 cd/m2 Capacitive touch screen

Service life: 50,000 h at +25 °C

Function keys at display Optionally via matrix keyboard, freely configurable up to 4 x 8 keys

External keyboard

-CPU Cortex A8, 800 MHz

Main memory 512 MB RAM

Data memory 1 GB Flash + 512 MB SSD

Extra memory up to 64 GB (optional)

Operating system Windows® _{Embedded Compact 7}

Languages Global, multi-lingual support

Interfaces 1 x Ethernet 10/100Base-TX (Ex e), or LWL 100Base-FX, 100 Mbit (Ex op is) 2 x USB (Ex ib)

1 x USB (Ex e)

1 x RS-422 / RS-485 (Ex e) Optional interfaces:

1 x Barcode / RFID via ReaderBox RS-422 1 x WLAN 802.11b/g, 11 / 54 Mbps MPI with MPI box SSW7-RK512-RS-422

Dimensions (W x H x D) 372 x 270 x 150 mm

Wall cutout 359.5 x 257.5 (+/- 0.5) mm

Weight 12.6 kg

Power supply 24 VDC (Ex e)

85 – 265 VAC, 48 – 62 Hz (Ex e)

Operation -40 °C up to +65 °C Storage -40 °C up to +70 °C

Heat dissipation Cooling through front plate

Rel. air humidity 90 % at +40 °C, non-condensing

(22)

Standard

Enclosures

FR

Enclosure

CFR

Enclosure

For any type of application

For clean rooms,

aseptic/food processing

Mounting Options

Enclosures and Accessories

Customized

Mounting Options

(23)

(24)

RDP / Net@P

WLAN + ACCESS POINT

Ex i Barcode Scanner

Operating System

Ex i Mifare Card Reader

Backup/Recovery Stick

Remote Administration

Software

Ex i Keyboard

available as panel-mount module, or stand-alone keyboard in

"office style"

Matrix Keyboard

R. STAHL

Remote HMI Firmware

Touch Pen

ideal to perform precise touch operation in hazardous areas

SPSPlusWIN

Project Engineering Software

Accessories

Additional

accessories available

on request

Hardware

(examples taken from the accessories' list)

(25)

(26)

Our HMIs are designed for extremely reliable

and long life operation. If you have any technical

questions or issues, our global Support Team is

ready to help.

[email protected]

(27)

Engineered in Germany

Quality "German engineering" ensures extremely

reliable HMIs for use in the process industries –

for 24/7 operation, all year round.

HMI Experts

If you have any questions, please contact

our "process industry" HMI experts.

[email protected]

+49 (0) 221 59 808 - 53

(28)

R. STAHL HMI Systems GmbH Im Gewerbegebiet Pesch 14 D-50767 Cologne Phone: +49 (0) 221 59 808 -200 Fax: +49 (0) 221 59 808 -260 E-mail: [email protected] www.stahl-hmi.de www.exicom.de
