ABAP Custom Code Security
A collaboration of:
SAP Global IT & SAP Product Management for Security, IDM & SSO
SAP Global IT - ABAP custom code security
1.
Introduction / Motivation
2.
Custom Code Scanning Project
Code-Security for ABAP-based applications
Tasks and Responsibilities
Phase 1:
Identify Security Issues
Phase 2:
Fixing Security Issues
Global IT Responsibility
Task:
review custom specific ABAP code
Solution:
Tool based approach with a
specialized ABAP security scanner
(Virtual Forge CodeProfiler)
SAP´s Responsibility
Task:
review codebase of approx. 280
million lines of code
Solution:
Tool based approach with an ABAP
security scanner
Task:
Implementation of published
Security Notes
Remediate potential security gaps
in ABAP custom code
Regularly search and implement
relevant security notes
Task:
Process issues in SAP standard code
Solution:
SAP Security Notes
: currently
approx.. 2400 notes released (up to
10/2012)
Introduction of
SAP Security Patch
day
New Secure Programming Guidelines
Entry points for security questions concerning custom
developed ABAP-applications
Are business critical
applications and
processes sufficiently
protected within
custom application?
Are compliance
guidelines adhered
within the custom
applications?
Are data protection
rules and guidelines
violated through
security flaws?
Get a general
overview of the
code quality
concerning the
security aspects
Are there
Backdoors or
malicious coding in
the customer
specific
developments?
Custom
Source
Code
Security
Key
Message
Ensuring Security and Compliancy of custom developed code is key
To ensure custom developed ABAP code a highly atomized solution is required
The solution must also support the developers requirements in his daily work in a
convenient way
SAP Global IT - ABAP custom code security
1.
Introduction / Motivation
2.
Custom Code Scanning Project
ABAP Custom Code Project
– Functionality / Characteristics of static code profiling approach -
Proceeding:
Key
Message
Virtual Forge CodeProfiler (VF CP)* uses static ABAP patterns to scan ABAP source code for potential
weaknesses and issues.
Allows prioritizing countermeasures by categorizing all findings regarding impact and probability
High number of constantly updated test cases for security checks
In conducted scans at Global IT the VF CP* showed a low number of false-positives
Core SAP Business
Systems
VF CodeProfiler*
TC 33 Missing AUTHORITY-CHECK in Reports
[#46] TID=80,
FID=5A66D9C5271AE8E7360B61F5F167B49D5
D890A40
Package: Z_BW_CORE, Program:
YBW_BW_CALL_STATISTICS
Extract via RFC
Analyze and Document
Output
CodeProfiler Test case Examples
Test Group
Potential Impact
Missing Authority Checks
ABAP can execute business transactions without privileges. Therefore, whenever
ABAP programs call functionality that requires certain privileges to run, an authority
check should be made programmatically. Otherwise users might get access to
restricted functionality
Dangerous ABAP
commands
These test patterns check if there are any commands used in an ABAP program that
could pose a security threat. Examples are access to files and low-level system
commands
Backdoors
There are several ways to include backdoors in ABAP programs. They allow
malicious developers to secretly access extra-functionality by feeding certain triggers
to the program
Hard-coded user credentials
These test patterns check if there are any hard-coded user credentials in the code
Generic Operations
Sometimes developers write code in a way that it can be used for a number of
different use cases. This flexibility often results in vulnerabilities when malicious
users discover unforeseen use cases nobody expected
Command execution
In some instances, ABAP code can be generated and executed at runtime. These
test patterns check, if such risky practices are used and if they are exploitable
SQL Injection
This coding defect allows malicious users to manipulate OSQL
statements. This can result in information disclosure and
manipulation of arbitrary data in the SAP database
Custom Code Security at SAP Global IT
Get secure – Stay secure
Implementation of Virtual Forge
CodeProfiler* and conduction of regular
code scans
Creation of agreed procedures and
guidance how to fix potential security gaps
Analysis and remediation of security
related issues identified by the Virtual
Forge CodeProfiler* for the four core SAP
Global IT Business Systems
Analysis and remediation of security
related issues identified by the Virtual
Forge CodeProfiler* for all SAP Global IT
Business Systems
Get Secure
SAP Global IT Secure Development
Framework – rules and standards for the
development of ABAP code
Secure ABAP development training for
developers at Global IT teaching how to
develop secure ABAP code
Full integration of security checks into the
ABAP development workbench with high
usability for developers and quality experts
using the ABAP Test Cockpit (ATC)
Perform security checks during transport
release (Q-Gate) to avoid new security
related issues in production
Stay Secure
SAP Global IT - ABAP Source Code Security Approach
Analysis and
Prioritization
of Issues
Monitoring
of
Remediation
Custom
Source
Code
Security
Holistic Custom Source
Code Scans
Remediation of
Source Code Issues
Secure
Programming Training
Secure Programming
Guide
Remediation
Scanning
Automat.
Periodization
Automat.
Monitoring
Project Level
Daily Operational Level
SAP Global IT - ABAP Custom Code Security
1.
Introduction / Motivation
2.
Custom Code Scanning Project
Motivation for ABAP Test Cockpit
Different Tools, Different UIs, Different Results
Different checks, messages, priorities
Different code checks before release of
transports
No common base for QM and developer
perspective
No central point to overview the quality of
What is it?
ATC is an ABAP check framework which allows running static checks and unit
tests for ABAP programs
ATC is designed to help meeting the production standard “Functional
Correctness” in the ABAP world
ATC is fully integrated into development environment and transport tools,
along with instant navigation, documentation and fix recommendation
What are the benefits?
ATC is the single point of entry for all static code check tools
ATC comprises a 4-eye principle exception process to handle false/ positive
findings effectively
ATC is fully integrated in the ABAP development workbench with a high
usability for developers and quality experts
ATC is not only a check tool but supports essential QA techniques like
Q-Gates or regression testing in a consolidation system
Code Scanning Tools at Global IT
Syntax Check (
Check
, SE 80)
Extended Program Check (
SLIN
)
•
checks the syntax and internal semantics of a
program.
SAP Code Inspector (
SCI
)
•
Performs extended checks e.g. searching for
obsolete ABAP statements
•
Additional checks for example adherence to
naming conventions or performance
optimization
Virtual Forge CodeProfiler (
CP
)*
•
Test Domains: Security & Compliance
•
Allows prioritizing countermeasures by
categorizing all findings
•
Establishes a baseline security level for all
ABAP-based business applications
•
Integration into ABAP Test Cockpit and
Transport Management System
•
High number of test domains and test cases
A
B
A
P
T
es
t Cockpit
(A
TC)
Thank You!
A collaboration of:
•
SAP Global IT
•
SAP Product Management for Security, Identity
ABAP Test Cockpit
Configuration of five-system landscape
DEV
PSS
QAS
FQA
PRD
Scanning of tasks / transports
perform full system scan
Developers run static / unit /
scenario tests on their objects
Periodic check runs to validate
code of a development team
Q-experts run mass checks and
distribute the results
i
Use ONE quality
standard for Q-Gates
ABAP Test Cockpit
Availability
The ABAP Test Cockpit (ATC) is a tool for doing static and dynamic quality checks
of ABAP code and associated repository objects
The ATC is now available with EhP2 for SAP NetWeaver 7.0 with support package
stack 12. Additionally, the ATC is planned for SAP NetWeaver AS ABAP 7.03
support package stack 5.
The ATC is introduced with the following releases:
•
SAP NetWeaver 7.0 EHP2 Support Package 12
•
SAP NetWeaver 7.31 Support Package 5 (planned)
•
SAP NetWeaver 7.32 initial release
