ULTIMATE ASSORTMENTS

(1)

All items in this flyer may contain chemicals known to the State of California to cause

ULTIMATE

ASSORTMENTS

(2)

THE KIMBALL MIDWEST

solution...

IS YOUR INVENTORY...

Poorly Organized?

Poorly Stocked?

Poorly Labeled?

Poorly Maintained?

(3)

RELIABLE

Increase Productivity

ACCURATE ORGANIZATION

Eliminate Search Time for

“Nickel And Dime” Nuisance Items

COST EFFECTIVE

Reduce Downtime and Overall MRO Costs

Customize Your Inventory Solutions

MAINTENANCE

EFFICIENCY CENTERS

four for

$549

How It Works

• All four-drawer setups start at $549 base price (which includes a free rack and stand)

• Assortments are separated into Tiers

• Tier 1 assortments are all factored into the $549 price

• For every assortment chosen from Tier 2 through Tier 8, simply tack on the adder to the $549 for your custom four-drawer setup

MEC =

More Assortments!

(4)

40-100U Phillips Black Trim Screws $139 40-100-1U Phillips Head Oval Sems Screws $109 40-100-2U Phillips Washer Head Black Screws $129

40-101U Inch Body Bolts & Nuts $129

40-102U “U” Nuts $94

40-102-1U Thread Cutting Nuts $94

40-103U Tubular Speed Nuts $74

40-103-1U Flat Speed Nuts-Stud Type $99

40-103-2U Push On Speed Nuts $109

40-103-3U Nylon Anchor Nuts Ford/GM/Imports $109 40-103-4U Panel Fasteners/Weatherstrip Clips $99

40-103-5U Door Panel Clips $94

40-103-6U Plastic Push in Fasteners $164

40-103-7U Christmas Tree Fasteners $129

40-103-8U Plastic Plugs - Recessed & Flushed $94

40-103-9U Panel Fastener $129

40-104U Fender Washers $129

40-105U Metric Body Bolts & Nuts $104

40-105-1U Metric Hex Washer Head Body Bolts $159

40-106U Plastic Blind Rivets $209

40-107U GM Headlight Adjusters $104

40-108U GM Fasteners $89

40-110U Ford Fasteners $119

40-110-1U Ford Focus/Fusion $159

40-110-2U Ford F-150 Fastener $159

40-112U GM Door Hinge Repair Parts $144

40-113-1U GM Specialty Rivets $104

40-113-2U Ford Specialty Rivets $139

40-114U Heavy Duty Fender Washers $164

40-115U Toyota Clips $109

40-115-1U Honda Clips - 1 $189

40-115-2U Honda Clips - 2 $104

40-115-4U Nissan Clips $129

40-117U Toyota Push in Fasteners $109

40-117-1U Toyota Push in Fastener $149

40-117-2U Toyota Camry Push in Fastener $159

40-117-3U Toyota Push in Fastener $189

40-117-4U Toyota Camry Misc. Fasteners $209

40-118U Honda Push in Fastener $154

40-119U Chrysler Christmas Tree $74

40-120U Chrysler Push in Fasteners $74

40-121U Ford Christmas Tree $74

40-122U Nissan Push in Fastener $189

40-123U GM Christmas Tree Fasteners $74

40-124U GM Push in Fasteners $89

40-125U License Plate Screws $114

40-126U Tuf-Lok Retainers $139

40-127U Rubber Bumpers $139

40-127-1U Import Bumper Retainer $144

40-127-2U Import Fender Fastener $199

40-127-3U Import Body Clip $164

40-347-1U Spinlock Nuts $119

BODY SHOP

(5)

ELECTRICAL: TERMINALS

40-220U Nylon Insulated Solderless Terminals $189 40-221U Nylon Insulated Solderless Terminals $229 40-222U Nylon Insulated Solderless Terminals $229 40-223U 24/20 & 22/18 GA. Nylon Terminals $139 40-224U 16/14 GA. Nylon Insulated Solderless

Terminals $154

40-225U 12/10 GA. Nylon Insulated Terminals $154 40-226U Vinyl Insulated Solderless Terminals $139 40-227U Vinyl Insulated Solderless Terminals $164 40-228U Vinyl Insulated Solderless Terminals $189

40-229U Heavy Duty Terminals $289

40-230U Non-Insulated Terminals $114

40-230-1U Color-Coded Non-Insulated Terminals $104

40-230-4U 22-18 Nytrex Terminals $144

40-230-7U Nytrex Clear Terminals $209

40-231-3U Pro-Tech II Heat Shrink Terminals $114 40-231-4U Pro-Tech II Heat Shrink Terminals $209 40-231-5U Pro-Tech Commercial Grade Heat

Shrink Terminals $99

40-231-6U Pro-Tech Commercial Grade

Heat Shrink Terminals $144

40-231-7U Pro-Tech™ Nytrex Heat Shrink Terminals $239 40-231-8U Pro-Tech™ Commercial Grade Heat Shrink

Terminals $164

40-231-9U MaxiLink Heat Shrink Terminals $104

40-232U Solderconn Terminals $179

40-233U Weatherpack Terminals $154

40-233-1U G.M. Metripack Terminals $154

40-233-2U G.M. Terminals $219

40-233-3U G.M. Terminals $154

40-233-4U Deutsch DT Terminals $329

40-233-5U Deutsch HD Terminals $289

40-233-6U MetriPack 280 Terminals $164

40-233-7U Deutsch DTM Terminals $354

40-233-8U MetriPack 150 Terminals $179

40-233-9U Deutsch DTP Terminals $189

40-234U High Temperature Terminals $99

40-234-1U Weatherpack Pigtails $164

40-234-4U Insulated Ferrules $99

40-235U Ultra-Link Terminals $219

40-236U Self-Sealing Safety & Standard

Connectors $139

40-236-1U Wire Nuts $119

40-236-2U Scotchlock Connectors $104

40-236-3U Wire Nuts and Connectors Assortments $139

40-237U Sta-Kon Nylon Terminals $324

40-237-1U 22-18 Sta-Kon Nylon Terminals $229 40-237-2U 16-14 Sta-Kon Nylon Terminals $254 40-237-3U 12-10 Sta-Kon Nylon Terminals $274

ELECTRICAL: TERMINALS & WIRE

40-238U Nylon Terminals & Cross-Link Wire -

Caddy $439

40-238-1U Nylon Terminals & PVC Wire - Caddy $364 40-239U Nylon Terminals & Cross-Link Wire -

Caddy $439

40-239-1U Nylon Terminals & PVC Wire - Caddy $364 40-239-4U Pro-Tech Nytrex Heat Shrink Terminals $599 40-239-5U Pro-Tech Nytrex Heat Shrink Terminals $499

40-239-6U Heavy Duty Pigtail $229

40-258U SXL Cross-Link Primary Wire - Rack $399

ELECTRICAL

(6)

40-258-1U SXL Cross-Link Primary

Wire - Rack $519

40-258-2U SXL Cross-Link Primary Wire -

Narrow Spool - Rack $399

40-258-3U SXL Cross-Link Primary Wire -

Narrow Spool - Rack $519

40-259U PVC Primary Wire - Rack $274

40-259-1U PVC Primary Wire - Rack $389

40-259-2U PVC Primary Wire - Narrow Spool - Rack $274

40-259-3U PVC Primary Wire - Narrow Spool - Rack $389

ELECTRICAL: CABLE TIES AND CLAMPS

40-260U White Nylon Cable Ties $99

40-260-1U White Cable Ties - Rack $159

40-260-2U All Weather Black Cable Ties $109

40-260-8U Black Cable Ties - Rack $164

40-260-9U Black Nylon Cable Ties $99

40-261U Black Nylon Cable Ties $99

40-261-1U Color Coded Cable Ties $109

40-261-2U 4” Color Coded Cable Ties $104

40-261-6U Metal Detect Cable Ties $149

40-261-7U Metal Detect Cable Ties (Bin) - Rack $149

40-262U White Nylon Ty-Raps $149

40-262-1U Metal Detectable Ty-Raps - Rack $219

40-262-2U Metal Detectable Ty-Raps $189

40-263U Black Nylon Ty-Raps $149

40-264U Steel Cable Clamps - 3/8 Hole $104 40-264-1U Double Tube Plastisol Steel Clamps $129 40-265U Steel Cable Clamps - 1/4 Hole $104 40-265-1U Insulated Steel Clamps - 3/8 Hole $139

40-265-2U Insulated Steel Clamps - 1/4 Hole $104 40-265-3U Insulated Aluminum Clamps - 3/8 Hole $139 40-266U Aluminum Tube Clamps -1/4 Hole $109 40-266-1U Insulated Stainless Steel Clamps - 3/8

Hole $189

40-266-2U Insulated Stainless Steel Clamps - 1/4

Hole $139

40-267U Rubber Grommets $129

40-267-1U Rubber Grommets $189

40-267-2U Ratchet Action Releasable Cable Clamps $104

40-267-3U Black Nylon Clamps $89

40-267-5U Standard & Split Insulated

Bushings/Grommets $129

40-267-7U Convoluted Loom - Rack $164

ELECTRICAL: HEAT SHRINK TUBING

40-268U Black Dual Wall Heat Shrink Tubing $104 40-268-0U Red/Black Dual Wall Heat Shrink Tubing $144 40-268-1U Red Dual Wall Heat Shrink Tubing $114 40-268-2U Clear Dual Wall Heat Shrink Tubing $114 40-268-3U Color Coded Dual Wall Heat Shrink Tubing $114 40-269U Heavy Wall Heat Shrink Tubing $104

40-269-1U Fleet Heat Shrink Tubing $119

40-269-2U Black Single Wall Heat Shrink Tubing $74 40-269-3U Red Single Wall Heat Shrink Tubing $74

40-269-4U 6” Clear Heat Shrink Tubing $74

40-269-5U Red/Black Single Heat Shrink Tubing $104

ELECTRICAL: BATTERY PRODUCTS

40-270U Battery Terminals $259

40-270-1U Lead Plated Battery Terminals $209

40-270-2U Battery Terminals $364

40-270-3U Lead Plated Terminals $239

Electrical

(7)

40-270-4U Kim-Tech Twist On Battery Terminals $239

40-270-5U Kim-Tech 4Ga Twist On $179

40-270-7U Fusion Battery Terminals $314

40-270-8U Fusion Battery Terminals $479

40-271U Kim-Tech Magna Lugs $179

40-272U Kim-Tech H.D. Copper Lugs

& Connectors $199

40-273U Industrial Lugs $254

40-277U Solderconn Battery Slugs $144

ELECTRICAL: FUSES & FUSEHOLDERS

40-280U ATO Fuses $89

40-280-1U ATC Fuses $89

40-280-4U Blo-N-Glo II ATO Indicator Fuses $139

40-281U Mini ATM Fuses $94

40-281-1U Low Profile Jcase & Mini ATM Fuses $229

40-281-2U Low Profile Mini Fuses $104

40-281-3U Micro 2 Fuses $89

40-281-4U Micro Fuse $114

40-281-5U Blo-N-Glo Mini Indicator Fuses $114 40-281-8U USA & Foreign Fuse Master

(40-281-9, 40-282) $274

40-281-9U USA & Foreign Car Fuses $154 40-282U ATO, Mini ATM & Maxi Fuses $154 40-282-1U ATC, Mini ATM & Maxi Fuses $149 40-282-3U Low Profile Mini , Regular ATO & Mini ATM

Fuses $149

40-282-4U Low Profile Mini, Regular ATC & Mini ATM

Fuses $144

40-282-5U Blo-N-Glo II ATO, Mini ATM&

Maxi Indicator Fuses $209

40-282-6U PAL Autolink Fuses $159

40-282-7U JCASE Fuses $164

40-282-8U ATC, Mini ATM, Micro 2 Fuses $114

40-283-5U Pigtail Fuses $164

40-284U Glass Fuses $229

40-284-1U Fuses & Fuseholders $159

40-284-2U Fleet & HD Fuses $154

40-284-4U Low PK Midget Multi-Fuses $614

40-285U 3AG (312) Fast Acting Fuses $239

40-286U 3AG (313) Slo-Blo Time Delay Fuses $199 40-286-1U 3AB (314) Fast Acting Fuses $209 40-286-2U 3AB (326) Slo-Blo Time Delay Fuses $314

40-286-3U FLN-R Power Fuses $649

40-286-5U Low Profile ATC/ATO/ATM Circuit Breakers $299

40-286-7U ATO/ATM Circuit Breakers $259

40-286-8U ATO/Universal Circuit Breakers $274

40-286-9U Panel Mount Circuit Breaker $229

ELECTRICAL: LAMPS

40-287U 12V Miniature Lamps $119

40-287-1U 28V Miniature Lamps $254

40-288U 12V Miniature Lamps $164

40-288-1U 28V Miniature Lamps $299

40-288-2U 12V Miniature Bulb Assortment $259 40-289U Import Vehicle Miniature Lamps $179

40-290U Halogen Headlamps $274

40-291U Halogen Fog Lights $209

40-292U LED Mini Bulb $259

ELECTRICAL

(8)

FASTENERS: SOCKET HEAD PRODUCTS

40-300U Socket Head Cap Screws - USS $134 40-300-1U Socket Head Cap Screws - SAE $124 40-300-4U Socket Head Cap Screws - USS $154 40-300-7U Premium Socket Head Cap Screws - USS $204 40-300-8U Premium Socket Head Cap Screws - SAE $214

40-301U Socket Set Screws - USS $104

40-302U Socket Set Screws - SAE $109

40-303U Knurled Point Socket Set Screws - USS

& SAE $109

40-303-1U Half Dog Point Set Screws - USS $134 40-304U Button Socket Head Cap Screws - USS $144 40-304-1U Stainless Steel Button Socket Head Cap

Screw $149

40-304-5U Premium Button Socket Head Cap

Screws - USS $194

40-305U Square Head Set Screws - USS $194

40-306U Hex Socket Shoulder Screws - USS $214 40-307U Flat Socket Head Cap Screws - USS $139 40-307-5U Premium Flat Socket Head Cap

Screws - USS $249

40-308U Zinc Plated Socket Head

Cap Screws - USS $194

40-308-6U Zinc Plated Button Socket Head

40-308-7U Zinc Plated Flat Socket Head

40-309U Stainless Steel Flat Socket Head Cap

Screw $259

FASTENERS: BOLTS

40-322U Grade 2 Carriage Bolts $149

40-323-1U Rib Neck Carriage Bolts $119

40-325U Flange Bolts & Nuts $189

40-326U YZ Flange Bolts $234

FASTENERS: STAINLESS STEEL

40-331U Stainless Steel 18-8 Cap Screws, Nuts,

Flats & Locks $239

40-332U Stainless Steel 316 Cap Screws, Nuts,

Flats & Locks $254

40-333U Stainless Steel 18-8 Socket Head Cap

Screws $174

40-334U Stainless Steel 18-8 Set Screws $104 40-335U Stainless Steel 18-8 Phillips Pan Head

Sheet Metal Screws $164

40-335-1U Stainless Steel 18-8 Phillips Flat Head

40-336U Stainless Steel 18-8 Phillips Oval Head

40-336-1U Stainless Steel 410 Hex Washer

Self Drilling Screws $104

40-336-2U Stainless Steel 410 Phillips Pan Head

40-337U Stainless Steel 18-8 Slotted Round Head

Machine Screws $164

40-337-1U Stainless Steel 18-8 Phillips Pan HD

Machine Screws & Nuts $199

40-337-2U Stainless Steel 18-8 Phillips Flat HD

FASTENERS: SOCKET HEAD PRODUCTS

40-300-2U Socket Head Cap Screws - USS $399 40-300-3U Socket Head Cap Screws - SAE $459

FASTENERS: BOLTS

40-324U Flange Bolts & Nuts $459

FASTENERS: STAINLESS STEEL

40-330U Stainless Steel 18-8 Nuts, Flats, Locks & Cap

Screws $599

40-331-9U Stainless Steel 316 Fasteners $794

fastener BINS

Fasteners

(9)

fastener BINS

American

QUALITY Made THAT INVITES COMPARISON

KM-USA High Head

Grade 8 Hex Head Cap Screws:

KM-USA High Head

Grade 8 Hex Head Cap Screws &

Class 10.9 Cap Screws

High Strength Medium Carbon Alloy Steel

Designed for Demanding Applications

Delivers an Extra Margin of Job Safety

RoHS Compliant Zinc Yellow Trivalent Plated

Warrantied Against Defects

Grade 8 Cap Screw

Grade 5 Cap Screw

Demo Kit DEM860-04

TRUST

CAN

YOU YOUR CAP

SCREWS?

(10)

40-338U 18-8 Stainless Steel Cotter Pins $119 40-338-1U 304 Stainless Steel Hitch Pin Clips $164 40-338-3U Stainless Steel Internal/External

Retaining Rings $159

40-338-4U Stainless Steel Internal Retaining

Rings $104

40-338-5U Stainless Steel External Retaining

Rings $104

40-338-6U 316 Stainless Steel Phillips Flat Head

40-338-7U 316 Stainless Steel Coupling Nuts $354 40-338-8U 18-8 Stainless Steel Fender Washers $129 40-339U 18-8 Stainless Steel Lock Nuts $129 40-339-3U 18-8 Stainless Steel Nuts & Washers $109 40-339-4U 316 Stainless Steel Socket Head

Cap Screws $324

40-339-5U 316 Stainless Steel Set Screws $189 40-339-6U 316 Stainless Steel Phillips Pan Head

40-339-7U 316 Stainless Steel Phillips Flat Head

40-339-8U 316 Stainless Steel Cotter Pins $239 40-339-9U 316 Stainless Steel Phillips Pan Head

FASTENERS: NUTS

40-340U Ultra-Lock Nuts $164

40-341U Grade 8 Nylon Lock Nuts $179

40-341-1U Grade 5 Nylon Lock Nuts $139

40-342U Nylon Lock Nuts $139

40-343U Jam Nuts - USS & SAE $109

40-344U SAE Slotted Hex Nuts $154 40-345U USS Slotted Hex Nuts $154

40-346-1U Coupling Nuts $144

40-347-2U Small Nuts & Washers $149

40-347-3U Keps Nuts $109

40-347-4U Weld Nuts $244

40-347-5U Weld Nuts $274

40-348U Ultra Flange Lock Nuts $179

40-349U Wing Nuts $109

FASTENERS: GRADE 5 CAP SCREWS

40-358U USS Grade 5 Cap Screws,

Nuts, Locks, Flats $144

40-358-1U Grade 5 Tap Bolts $144

40-358-2U Grade 5 HHCS W/Alloy Flat Washer USS $144 40-359U USS & SAE Grade 5 C/S, Nuts, Locks, Flats $144 40-368U SAE Grade 5 Cap Screws, Nuts,

Locks, Flats $144

40-368-2U Grade 5 HHCS W/Alloy Flat Washer SAE $144

40-369U Thermoplastic Cap Screws, Nuts, Washers $349

FASTENERS: WASHERS

40-370U Internal - External Washers $139

40-370-1 Internal External Lock Washers $199 40-371U SAE Extra Thick Hardened Flat Washers $199 40-372U USS Extra Thick Hardened Flat Washers $249

40-373U Kim-Lock Washers $234

40-373-1U Copper Washers $139

40-374U Fiber Washers $154

40-375U Copper Sealing Washers $129

40-376U Nylon Flat Washers $144

40-377U Aluminum Sealing Washers $89

FASTENERS: GRADE 8 CAP SCREWS

40-388U KM-USA Grade 8 Cap Screws USS,

40-388-1U USS Grade 8 Tap Bolts $179

40-398U KM-USA Grade 8 Cap Screws SAE,

FASTENERS: L9 CAP SCREWS

40-389-3U 1/4 - 3/8 L9 USS Cap Screws, Nuts,

Locks, Flats $224

Fasteners

(11)

FASTENERS: GRADE 8 CAP SCREWS

40-380U KM-USA Grade 8 Cap Screws Small 1/4 -

1/2 USS $589

40-380-1U KM-USA Grade 8 Cap Screws 1/4 - 3/8 USS $364 40-380-3U KM-USA Grade 8 Cap Screws 1/4 - 3/8 USS $1,894 40-381U KM-USA Grade 8 Cap Screws Large

1/4 - 5/8 USS $1,084

40-381-1U KM-USA Grade 8 Cap Screws 3/4 - 1” USS $784 40-383U KM-USA Grade 8 Cap Screws

1/4 - 5/8 USS & SAE $1,084

40-385U KM-USA Grade 8 Cap Screws Large

1/4 - 3/4 USS $1,684

40-386U KM-USA Grade 8 Cap Screws Small

1/4 - 3/4 USS $1,034

40-386-4U Grade 8 Cap Screws Plain Small

1/4 - 1/2 USS $534

40-386-6U Grade 8 Plain Cap Screws Large

1/4 - 5/8 USS $924

40-386-8U Grade 8 Plain Cap Screws Small

1/4 - 3/4 USS $924

1/4 - 1/2 SAE $584

1/4 - 5/8 SAE $1,074

40-391-1U KM-USA Grade 8 Cap Screws Large

3/4 - 1” SAE $789

1/4 - 3/4 SAE $1,684

1/4 - 3/4 SAE $1,079

FASTENERS: GRADE 5 CAP SCREWS

40-350U Grade 5 Cap Screws 1/4 - 1/2 USS $449 40-350-1U Grade 5 Cap Screws 1/4 - 3/8 USS $299 40-350-2U Grade 5 HHCS W/Alloy FW USS (1/4-1/2) $524 40-350-3U Grade 5 HHCS W/Alloy FW USS (1/4-3/8) $309 40-351U Grade 5 Cap Screws 1/4 - 5/8 USS $794 40-351-1U Grade 5 Cap Screws 3/4-1” USS $644 40-351-2U Grade 5 HHCS W/Alloy FW USS (1/4-5/8) $854 40-353U Grade 5 Cap Screws 1/4 - 5/8 USS & SAE $899 40-355U Grade 5 Cap Screws Large 1/4 - 3/4 USS $1,299 40-355-2U Grade 5 HHCS - Lrg W/Alloy FW USS (1/4-3/4) $1,349 40-355-3U 1/4 - 3/4 USS Grade 5 Cap Screws $1,349 40-356U Grade 5 Cap Screws Small 1/4 - 3/4 USS $784 40-356-2U Grade 5 HHCS - Small W/Alloy FW USS (1/4-

3/4) $854

40-360U Grade 5 Cap Screws 1/4 - 1/2 SAE $449 40-360-2U Grade 5 HHCS W/Alloy FW SAE (1/4-1/2) $519 40-361U Grade 5 Cap Screws 1/4 - 5/8 SAE $794 40-361-1U Grade 5 Cap Screws 3/4-1” SAE $639 40-365U Grade 5 Cap Screws Large 1/4 - 3/4 SAE $1,289 40-366U Grade 5 Cap Screws Small 1/4 - 3/4 SAE $794

FASTENERS: ARMOR COAT CAP SCREWS

40-387U Grade 8 Armor Coat™ Cap Screws 1/4 - 1/2 USS $684 40-387-2U Grade 8 Armor Coat™ Cap Screws 1/4 - 5/8 USS $1,099 40-387-5U Grade 8 Armor Coat™ Cap Screws 1/4 - 3/4 USS $1,099

40-399-3U 1/4 - 3/8 L9 SAE Cap Screws,

FASTENERS: PINS, SNAP RINGS, KEYSTOCK

40-400U Cotter Pins 1/16” - 3/16” $159

40-401U Cotter Pins 1/16” - 5/16” $139

40-401-1U Cotter Pins 3/16” - 1/2” $139

40-401-2U Cotter Pins 1/16” - 3/16” $164

40-401-3U Cotter Pins 1/16” - 5/16” $144

40-401-4U Cotter Pins 1/8” - 5/16” $139

40-401-5U Cotter Pins 3/16” - 1/2” $144

40-402U Roll Pins 1/16” - 5/16” $99

40-402-5U Roll Pins $139

40-403U Roll Pins 3/8” - 1/2” $139

40-403-1U Spiral Roll Pins $199

40-404U Spiral Roll Pins $139

40-405U Dowell Pins $109

40-406U Low Carbon Threaded Rod - Rack $274

40-407U B7 Threaded Rod - Rack $324

40-407-1U Grade 8 Threaded Rod - Rack $479

fastener BINS

(12)

40-408U Keystock - Undersize Plated - Rack $164 40-408-1U Keystock - Undersize Plain - Rack $154 40-408-2U Keystock - Oversize Plated - Rack $189 40-408-3U Keystock - Oversize Plain - Rack $164

40-409U Keystock - Undersize Plated $139

40-409-1U Keystock - Undersize Plain $119

40-409-2U Keystock - Oversize Plated $159

40-409-3U Keystock - Oversize Plain $139

40-409-4U 303 Stainless Steel Square Keystocks $189

40-410U Roller Chain Repair Links $274

40-411U Woodruff Keys $129

40-412U Machinery Bushing $179

40-413U “E” Rings $99

40-413-1U Reinforced “E” Rings $89

40-413-2U Stainless Steel “E” Rings $159 40-414U Internal - External Retaining Rings $189

40-415U Internal Retaining Rings $164

FASTENERS: PINS, SNAP RINGS, KEYSTOCK

40-416U External Retaining Rings $164

40-416-5U Wire Rope Clips $189

40-417U Set Collars $104

40-417-1U 2 Piece Steel Double Split Collars $179

FASTENERS: SCREWS

40-420U Slotted Round Head Machine

Screws & Nuts $94

40-421U Slotted Round Head Machine

Screws & Nuts $94

40-421-3U Slot Head Machine Screws, Nuts & Flats $119 40-422U Slotted Flat Head Machine Screws & Nuts $99

40-423U Hex Head Machine Screws $104

40-423-9U Phillips Round Head Machine

Screws & Nuts $89

40-424U Phillips Pan Head Machine Screws $109 40-424-1U Phillips Pan Head Machine Screws $144 40-424-2U Phillips Pan Head Machine Screws $144 40-424-3U Phillips Pan Head Machine

Screws, Nuts & Flatwashers $144

40-425U Tamperproof Machine Screws $154

40-425-1U Torx Tamperproof Machine Screws $164 40-426-1U Torx Tamperproof Sheet Metal Screws $164 40-426-2U One-Way Slotted Security Screws $189 40-427U Serrated Hex Washer Flange

Screws & Nuts $139

40-427-2U Grade 8 Serrated Hex Washer,

Flange Screws & Nut $199 40-428U Phillips Flat Head Machine Screws $94 40-428-1U Phillips Truss Head Machine Screws $109 40-429U Hex Washers Type “F” Self

Threading Screws $139

40-430U Slotted Pan Head Sheet Metal Screws $119 40-431U Slotted Pan Head Sheet Metal Screws $139 40-432U Phillips Pan Head Sheet Metal Screws $139 40-432-2U Combo Pan Head Slotted/Phillips

40-432-3U Torx Pan Head Sheet Metal Screws $144 40-432-4U Black Square Drive Sheet Metal Screws $84 40-432-5U White Square Drive Sheet Metal Screws $84 40-432-6U Phillips Pan Head Painted Head SMS $114 40-433U Phillips Oval Head Sheet

Metal Screws $139

40-433-1U Serrated Hex Washer Sheet Metal Screws $104 40-435U Phillips Oval & Pan Head Sheet

Metal Screws $139

40-436U Phillips Oval & Pan Head Sheet

Metal Screws $109

40-437U Slotted Hex & Slotted Hex

Washer Head SMS $139

40-438U Slotted Hex & Slotted Hex

Washer Head SMS $149

Fasteners

(13)

FASTENERS: L9 CAP SCREWS

40-388-9U L9 Cap Screws Large 1/4 - 1/2 USS $699 40-389U 1/4 - 1/2 L9 USS Cap Screws $859 40-389-1U L9 Cap Screws 1/4 - 5/8 USS $949 40-389-2U L9 Cap Screws 1/4 - 3/4 USS $1,524 40-398-9U L9 Cap Screws Large 1/4 - 1/2 SAE $699 40-399U 1/4 - 1/2 L9 SAE Cap Screws $949

FASTENERS: METRIC

40-450U Metric Master Assortment (M6 thru M20) $829 40-450-1U Metric Master Assortment (M6 thru M24) $1,099

40-450-9U Metric 10.9 Cap Screws (M6 thru M10) $384 40-451U 10.9 Metric Regular Pitch Cap

Screws (M6 thru M12) $449

40-451-1U Metric 10.9 Fine Thread Cap

Screws (M10 thru M16 Fine) $714

40-453U Metric Master Assortment (M4 thru M12) $529 40-453-1U M6 - M24 8.8 Master Assortment $1,289 40-454U Metric Master Assortment (M4 thru M12) $509 40-455U Metric Inventory Maximizer $479 40-462U Metric 8.8 Cap Screws (M6 thru M12) $339 40-462-1U Metric 8.8 Cap Screws (M6 thru M10) $289 40-476U Metric 18-8 SS Cap Screws (M6 thru M12) $349 40-478-1U Metric 316 SS Cap Screws $429

40-438-9U Zinc Hex Washer Head Self

Drilling Screws $239

40-439U Zinc Hex Washer Self

40-439-1U Hex Washer Self Drilling Screws -

Clima SealCoated $144

40-439-2U Hex Washer Self Drilling Screws

with Clima Seal $189

40-439-3U Kim-Clinch^™Self Drilling Screws $139 40-440U Slotted Flat Head Wood Screws $189 40-441U Phillips Flat Head Wood Screws $119 40-441-1U Brass Phillips Flat Head Wood Screws $209 40-441-9U Black Hex Washer Head

40-442U Black Hex Washer

40-442-9U Black Phillips Pan Head

40-443U Phillips Pan Self Drilling Screws $84 40-443-1U Self Drilling Square Drive

Pan Head Screws $109

40-443-2U Phillips Pan Head Painted Head Self

40-444U Phillips Flat Head Sheet

Metal Screws $139

40-445U Drywall Screws $119

40-445-1U Hi-Lo Drywall Screws $114

40-445-3U Coarse Thread Drywall Screws

(Deck Screws) $114

40-446U Lag Screws & Shields $179

40-449-1U Flat Head Power-Thread+ Screws $119

FASTENERS: METRIC

40-452U Metric 10.9 Cap Screws $229

40-452-1U Metric 10.9 Fine Thread Cap Screws $269 40-456U Metric Cap Screws & Nuts Coarse Pitch $159 40-456-1U Metric 8.8 Course Thread $174 40-456-2U Metric 8.8 Small Assortments $139 40-456-9U Metric 8.8 Fine Thread $159 40-457U Fine Thread Metric Cap Screws

& Nuts $149

40-457-1U Very Fine Thread Metric

Cap Screws & Nuts $114

40-457-2U JIS Metric Cap Screws & Nuts $149

40-457-3U Metric Hex Nuts $159

40-458U Metric Socket HD CS - Regular Pitch $154 40-458-1U Zinc Plated Metric Socket Head

Cap Screws $114

40-458-2U Premium Metric Socket Head

Cap Screw $349

40-459U Metric Socket Set Screws $109

40-460U Metric Slotted Pan HD Machine Screws $119 40-460-1U Metric Phillips Cheese Head

Machine Screws $119

40-461U Metric Phillips Machine Screws $119 40-463U Metric Button Head Socket Cap Screw $109

fastener BINS

(14)

40-464U Metric Flat Socket Head Cap Screws $109 40-464-1U Stainless Steel Metric Flat Head

Socket Screw $229

40-465U Metric Internal & External Retaining Rings $109 40-466U Metric Internal Retaining Rings $109 40-467U Metric External Retaining Rings $109

40-468U Metric Roll Pins $114

40-471U JIS Metric 10.9 Flange Bolts $129 40-471-1U DIN Metric 10.9 Flange Bolts $144 40-471-2U IFI Metric Flange Bolts $149 40-471-3U DIN Metric 10.9 Flange Bolts $154

40-472U Metric Keystock - Rack $154

40-472-0U 18-8 Metric Keystock Assortment $239 40-472-1U Metric 8.8 Threaded Rod Rack $479

40-473U Metric Keystock $139

40-474U Metric Prevailing Torque Lock Nuts $139 40-474-1U Metric Class B Nylon Insert Lock Nuts $89 40-474-2U Metric Class 10 Flange Nuts $149 40-474-9U Metric Class 10 Nylon Insert Locknuts $149

40-475U Metric Nylon Lock Nuts $104

40-475-1U Metric Fender Washers $114

40-476-1U Metric 18-8 Stainless Steel Cap Screws $154 40-476-2U Metric 18-8 Stainless Steel Nuts,

Flats & Locks $129

40-476-3U Metric 18-8 Stainless Steel Socket

Head Cap Screws $159

40-476-4U Metric 18-8 Stainless Steel Set Screws $129 40-476-5U Metric 18-8 Button Head Socket Cap Screw $274

40-477U Metric Dowel Pins $144

40-478U Metric 18-8/AZ Stainless Steel Phillips

Pan Head Machine Screws $154

40-478-2U Metric 316 Stainless Steel Nuts,

Flats & Locks $144

40-478-3U Metric 316 Stainless Steel Socket

Head Cap Screws $219

40-478-4U Metric 316 Stainless Steel Set Screws $164 40-479U M1.2 - M2.5 Metric Cotter Pins $104 40-479-1U M3.2 - M5 Metric Cotter Pins $99

40-479-2U M6.3 - M8.0 Metric Cotter Pins $139

FASTENERS: RIVETS & ANCHORS

40-480U Blind Rivets $94

40-480-1U Blind Rivets - Steel $114

40-480-2U Blind Rivets - Aluminum $114

40-480-3U Blind Rivets $144

40-480-4U Blind Rivets - Steel $159

40-480-5U Blind Rivets - Aluminum $159

40-481U Avex Rivets $89

40-482U Toggler® Anchors $144

40-482-1U Wall Anchors $114

40-483U Wall Anchors $94

40-484U Concrete Screws $189

40-484-1U Stainless Steel Concrete Screws $254

40-485U Concrete Screws $189

40-485-1U Stainless Steel Concrete Screws $259

40-486U Wedge Anchors $119

40-487U Hammer-Set Anchors $189

THREAD REPAIR, INSERTS

40-850U Large Flange Inserts $224

40-851U Large Flange Inserts $144

40-852U Thin Sheet Nutserts $234

40-853U Tric Nuts Inserts $354

40-853-1U Large Flange Inserts $374

Fasteners

(15)

STAY ORGANIZED

with our lid charts ^& labels

40-853-2U Split Body Insert $179

40-854U Thin Wall Keenserts $299

40-854-1U Stainless Steel Key Inserts $559 40-854-2U Metric Thin Wall Key Inserts $389

40-855U Heavy Duty Keenserts-UNC $259

40-855-1U Thin Wall Inserts $209

40-855-2U Thread Inserts $224

40-855-3U Metric EZ-LOK $189

40-855-4U Perma -Thread - USS $414

40-856-5U Rivet Nuts $439

40-858U EZLOK Heavy Drill & Tap $399

40-858-1U EZLOK Thin Drill & Tap $274

40-858-3U Keysert Heavy Drill & Tap $529 40-858-4U Keysert Thin Drill & Tap $434 40-858-6U Permathread Tap & Drill $299

Easier to Maintain Inventory

High quality Laminated

Barcodes – simple for scanning

Customizable

(16)

FLUID FLOW: O-RINGS

40-490U Buna-N 90 O-Rings-1/16”, 3/32”, 1/8” $139

40-491U Buna-N 90 O-Rings-1/16” $139

40-492U Buna-N 90 O-Rings-3/32” $139

40-493U Buna-N 90 O-Rings-1/8” $139

40-494U Buna-N 90 O-Rings-3/16” $164

40-495U Back-Up Buna-N 90 O-Rings -3/32” $289 40-495-1U Back-Up Buna-N 90 O-Rings-1/8” $209 40-495-2U Back-Up Buna-N 90 O-Rings-3/16” $354

40-497U Air Conditioning O-Rings $104

40-497-1U Green Air Conditioning O-Rings $144

40-498U Air Conditioning O-Rings $144

40-498-1U Sealing Washers $274

40-498-2U A/C Adapters, Caps & Valve Cores $269

40-498-3U A/C Orifice Tubes $139

40-500U O-Rings - 1/16”, 3/32”, 1/8” $109 40-501U O-Rings - 1/16”, 3/32”, 1/8” $109

40-502U O-Rings - 3/32” $109

40-503U O-Rings - 1/8” $109

40-504U O-Rings - 3/16” $119

40-505U O-Rings - 1/8”, 3/16” $119

40-505-1U Quad O-Rings $104

40-506-1U O-Rings For Caterpillar Face Seal

& O-Ring Boss $144

40-507U Straight Thread O-Ring Boss Gasket $119 40-507-1U Viton Straight Thread O-Rings Boss $164 40-507-2U Viton Straight Thread O-Rings $164 40-508U Hydraulic Fittings O-Ring Seals $109

40-509U Hydraulic O-Rings - Buna 90 $154

40-509-1U For-Seal O-Rings $74

40-510U Viton O-Rings - 1/16”, 3/32”, 1/8” $199

40-511U Viton O-Rings - 1/16” $89

40-512U Viton O-Rings - 3/32” $139

40-513U Viton O-Rings - 1/8” $164

40-514U Metric Viton O-Rings $189

40-514-2U Metric Viton O-Rings - M1.0 Thru M2.0 $144 40-514-3U Metric Viton O-Rings - M2.5 Thru M3.0 $209

40-515U Metric O-Rings $94

40-515-1U Metric O-Ring Master

(40-515-2, 40-515-3, 40-515-4, 40-515-5) $399 40-515-2U Metric O-Rings - M1.0 Thru M2.0 $104 40-515-3U Metric O-Rings - M2.5 Thru M3.0 $104

40-515-4U Metric O-Rings - M3.5 $104

40-515-5U Metric O-Rings - M4.0 $104

FLUID FLOW

Fluid Flow RACKS

FLUID FLOW: HOSE CLAMP

40-517U Large Hose Clamps $154

40-517-2U Silicone Hose Clamps $189

(17)

FLUID FLOW

FLUID FLOW: HOSE CLAMPS

40-515-9U Constant Torque Hose Clamps - Rack $254

40-516U #4-36 Hose Clamps - Rack $154

40-516-1U #4-36 Heavy Duty Hose Clamps - Rack $149 40-517-1U #40-56 Heavy Duty Hose Clamps - Rack $149 40-518U #4-36 Stainless Steel Hose Clamps -

Rack $189

40-518-1U #4-36 Heavy Duty Stainless Steel Hose

Clamps - Rack $179

40-518-2U #4-32 Stainless Steel Hose Clamps $114 40-518-3U #4-32 Heavy Duty Stainless Hose Clamps $114

40-519U Silicone Hose Clamps - Rack $219

40-519-1U 2-Ear Hose Clamps $209

40-519-2U Silicone Hose Clamps - Rack $189 40-519-3U Wave Seal Constant Torque

Hose Clamps $299

40-519-4U 1-Ear Hose Clamps $209

FLUID FLOW: GREASE FITTINGS

40-520U Grease Fittings $189

40-521U Metric Grease Fittings $189

40-522U Grease Fittings - Inch & Metric $219 40-523U Stainless Steel Grease Fittings $389 40-523-1U Self-Tapping Grease Fittings $159

40-524U Tire Valves & Caps $129

40-525U Tire Repair $189

FLUID FLOW: HOSE PROTECTORS

40-526-1U Yellow Hose Protectors $129

40-527-1U Black Hose Protectors $129

40-528-1U Orange Hose Protectors $129

FLUID FLOW: AIR LINE

40-531U Industrial Interchange 1/4”, 3/8”, 1/2” $199 40-531-1U Industrial Interchange 1/4”, 1/2” $159 40-531-2U Industrial 1/4 & Repair Interchange $244

40-532U Truflate 1/4”, 3/8”, 1/2” $219

40-532-1U Truflate 1/4”, 1/2” $159

40-532-2U Tru-Flate 1/4 & Repair $254

FLUID FLOW: HOSE PRODUCTS

40-529U Hose Spacers $139 40-530U Mounted Hose Spacers $114 40-530-1 Hose & Tubing Loom $144

40-540U Tubing & Hose Connectors $139

40-541U Vacuum Caps $144

40-544U Ferrule Crimp $459

40-545U Miscellaneous Heater Nipples $274

FLUID FLOW: BRASS FITTINGS

40-550U Brass Pipe Fittings $314

40-551-5U Lead-Free Brass Pipe Fittings $314

40-552-1U Brass Pipe Fittings Complete Setup

(40-552-2U, 40-552-3U & 40 -552-4U) $1,239

40-552-2U Brass Pipe Fittings $299

40-552-6U Lead Free Brass Pipe Fittings Master

(40-552-7U, 40-552-8U & 40-552-9U) $1,724 40-552-7U Lead Free Brass Pipe Fittings $459 40-552-8U Lead Free Brass Pipe Fittings $799 40-552-9U Lead Free Brass Pipe Fittings $549

(18)

40-553U SAE 45° Flare Fittings $374

40-553-1U SAE 45° Flare Fittings $374

40-553-2U Polyline Fittings $489

40-554U Compression Tube Fittings $289

40-554-1U Lead-Free Compression Tube Fittings $364

40-555U Inverted Flare Fittings $449

FLUID FLOW: INSTANT FITTINGS

40-556U Prestolock Fittings $274

FLUID FLOW: AIR BRAKE FITTINGS

40-557U Air Brake Fittings For Nylon Tubing $439 40-557-1U Air Brake Fittings For Nylon

w/ 5/32 Prec. Grip $499

40-558U Air Brake Fittings For Nylon Tubing $519 40-558-1U Air Brake Fittings For Nylon

w/ 5/32 Prec. Grip $509

40-559U Air Brake Fittings - 5/8” & 3/4” Tubing $329 40-559-1U Air Brake Fittings For Nylon Tubing Master

(40-559-2U, 40-559-3U & 40-559-4U) $1,384 40-559-2U Air Brake Fittings For Nylon Tubing $414 40-559-3U Air Brake Fittings For Nylon Tubing $519 40-559-4U Air Brake Fittings For Nylon Tubing $479 40-559-8U Synflex Air Brake Tubing - Rack $784 40-559-9U Nylon Air Brake Tubing - Rack $674 40-559-91U DOT Airbrake Fittings Master

(40-559-92, 40-559-93, 40-559-94, 40-559-95) $1,724 40-559-92U DOT Airbrake Fittings - 1/4” $354 40-559-93U DOT Airbrake Fittings - 3/8” $419 40-559-94U DOT Airbrake Fittings - 1/2” $549 40-559-95U DOT Airbrake Fittings - 5/8” & 3/4” $549 40-559-96U DOT Airbrake Fittings - 1/8”, 5/32” & 3/16” $399 40-559-99U DOT Metric Airbrake Fittings $274

40-560U DOT Air Brake Fittings $519

40-560-01U Parker DOT Airbrake Fittings Master(40-560-02, 40-560-03, 40-560-04) $1,399 40-560-02U Parker DOT Airbrake Fittings - 1/4” $354 40-560-03U Parker DOT Airbrake Fittings - 3/8” $549 40-560-04U Parker DOT Airbrake Fittings - 1/2” $599

40-560-05U Kimposite DOT Master $799

40-560-06U Kimposite 1/4 DOT Fittings $219 40-560-07U Kimposite 3/8 DOT Fittings $284 40-560-08U Kimposite 1/2 DOT Fittings $284 40-560-1U Parker DOT Push in Fittings $519

40-560-2U Kimposite DOT Fittings $284

40-560-4U Uni-Max Inch Fittings $209

40-560-5U Uni-Max Metric Fittings $209

40-561U Super Speedfit Fittings $219

40-561-1U Push Connect Fittings $354

40-561-2U Metric Push Connect Fittings $519

40-561-3U Hydraulic Brake Fittings $479

40-561-5U Legris Fittings $234

40-561-6U Metric Legris Fittings $234

40-561-7U Legris Nickel Plated Fittings $314 40-561-8U Metric Legris Nickel Plated Fittings $354

40-563U Kimposite Fittings $164

40-563-1U Kimposite Metric Fittings $179

40-563-2U Kimposit Flow Control $399

40-563-3U Kimposit Metric Flow Control $399

40-563-6U Uni-Max Flow Control $479

FLUID FLOW: HYDRAULIC FITTINGS

40-565U For-Seal Caps, Plugs & O-Rings $209

40-565-1U For-Seal Caps & Plugs $189

FLUID FLOW

(19)

FLUID FLOW BINS

FLUID FLOW: HYDRAULIC FITTINGS

40-565-9U JIC 37° Flare Fittings $769

40-569U 1/8” - 3/4” Steel Pipe Fittings $769

FLUID FLOW: COPPER FITTINGS

40-597U Copper Sweat Fittings $959

40-598U Kim-Couple Fittings $979

FLUID FLOW: STEEL & STAINLESS PIPE

40-580U Malleable Pipe Fittings $829

40-585U Galvanized Pipe Fittings $979

40-589-1U 304 Stainless Steel Pipe Fittings $829 40-589-2U 316 Stainless Steel Pipe Fittings $1,129

FLUID FLOW: CRIMP-ON HOSE ENDS

40-574-1U “Z” Series Hose Fittings $899 40-575U 757 “E” Series A/C Fittings $859

40-575-2U 903 Synflex $869

40-576U Kim-Krimp Hose Fittings $589

40-576-1U Kim-Krimp Hose Fittings $459

40-577U Kim-Krimp Face-Seal Hose Fittings $684 40-577-1U Kim-Krimp Face-Seal Hose Fittings $899 40-577-2U Kim-Krimp Face-Seal Hose Fittings $1,049 40-578U Kim-Krimp O-Ring Hose Fittings $524 40-578-1U 1/4-3/4 Kim-Krimp ‘Z’ Series $769 40-578-2U 1/4-1/2 Faceseal K-K ‘Z’ Series $789 40-578-3U 1/4-1/2 Kim-Krimp “Z” Face-Seal Fittings $859 40-578-4U 1/4-5/8 Kim-Krimp “Z” Face-Seal Fittings $1,014 40-578-6U 1/4 - 1/2 Kim-Krimp “Z” Series Fittings $524 40-578-7U 1/4 - 1/2 Kim-Krimp “Z” Series O-Ring Fittings $829

40-579U Grip-Crimp Hose Ends $684

Competition

Kimball Midwest

3/8”

Manufactured using heavy wall extrusion process for superior performance

Designed for Hydraulic, Pneumatic, and Instrumentation applications

Larger wrenching surfaces for tightening fittings

Competition Kimball Midwest

Weighs up to 2x more than import fittings Superior wall strength – Competitive fittings

are typically 40% the wall thickness

1”

(20)

40-565-2U For-Seal Straight Thread

O-Ring Male Connector $209

40-565-3U For-Seal Elbows 45° and 90° $299 40-565-4U For-Seal Unions & O-Rings $274

40-566U JIC 37° Caps & Plugs $149

40-566-1U JIC 37° Male Connectors $149

40-566-2U JIC 37° Male Elbows $144

40-566-3U JIC 37° Female Connectors &

Male 45° Elbows $199

40-566-4U JIC 37° Small Hex Unions &

Swivel Nut 90° Elb. $139

40-566-5U JIC 37° Straight Thread

O-Ring Connector $144

40-566-6U JIC 37° Straight Thread O-Ring Elbows

(90° & 45°) & O-Rings $199 40-566-8U Flare Maxx SAE 37° (JIC) Flare Plugs $164 40-566-11U K-Lok Stainless Steel Fittings 1/4 - 1/2 $654 40-569-1U Steel Pipe - Caps, Plugs & Couplers $164 40-569-2U Steel Pipe - Bushings & Nipples $159 40-569-3U Steel Pipe 90° Elbows and Adapters $179

40-569-4U Steel Pipe Tees $229

40-569-5U Steel Swivel Adapters $209

FLUID FLOW: HOSE ENDS

40-562U Barb-Tite Hose Ends $479

40-562-1U Low Pressure Hose Ends $269

40-562-2U 316 Stainless Steel Low Pressure Hose Ends $479

40-564U 3/8” Air Brake Hose Ends $154

40-564-2U 3/8” Rubber Air Brake Fittings $329

40-567U 247 Reusable Hose Ends $519

40-568U 213 Reusable Hose Ends $559

FLUID FLOW: CRIMP-ON HOSE ENDS

40-575-9U Kim-Krimp Hose Fittings $419

40-578-5U 1/4-1/2 Kim-Krimp “Z” Hose Fittings $389

FLUID FLOW: MALLEABLE & GALVANIZED PIPE

40-581U Malleable Pipe Fittings: 1/8 - 1/2 Pipe $374 40-582U Malleable Pipe Fittings: 1/8 - 1/2 Pipe $399 40-583U Malleable Pipe Fittings: 3/4 Pipe $219 40-584U Malleable Pipe Fittings: 1” Pipe $259 40-584-1U Magnetic Pipe Plugs: 1/8 - 1” Pipe $299 40-586U Galvanized Pipe Fittings: 1/8 - 1/2 Pipe $479 40-587U Galvanized Pipe Fittings: 1/8 - 1/2 Pipe $519 40-588U Galvanized Pipe Fittings: 3/4 Pipe $314 40-589U Galvanized Pipe Fittings: 1” Pipe $314

40-589-3U 304 Stainless Steel 1/8-1/2 Pipe $479

FLUID FLOW: MISCELLANEOUS

40-589-8U LevISeal Pressure Plugs $139

40-589-9U Silicone Cap Plugs $149

40-590U Cap Plugs $94

40-590-1U Garden Hose Fittings $274

40-590-2U Large Cap Plugs $89

40-591U Threaded Plastic Plugs & Caps $104 40-591-1U Service Plugs $154 40-591-2U Flat Face O-Rings, Caps and Plugs 1/4 - 3/4 $74 40-591-3U SAE Straight Thread O-Ring Plugs $94

40-591-4U NPT Pipe Plugs $104

40-592U Hydraulic Weld-On Clamps $459

FLUID FLOW: COPPER FITTINGS

40-598-1U Kim-Couple 1/2” Fittings $389

40-598-2U Kim-Couple 3/4” & 1” Fittings $549

FLUID FLOW

(21)

AUTO FLEET: WHEEL HARDWARE

40-600U “P” Series Wheel Weights $209

40-600-1U Lead Free “P” Series Wheel Weights $364

40-601U “MC-N” Series Wheel Weights $209

40-601-1U Poly Series Wheel Weight $654

40-602U “AW-N” Series Wheel Weights $254

40-602-1U “AW” Poly Series Wheel Weight $144

40-603U “MC” Wheel Weights $239

40-603-1U “MC” Lead Free Wheel Weights $399 40-603-2U “MC” Poly Series Wheel Weight TS $189 40-603-9U “FN” Poly Series Wheel Weight TS $139

40-604U “FN” Wheel Weights $419

40-604-1U “FN” Lead Free Wheel Weights $364

40-604-2U “TN” Wheel Weights $439

40-604-3U “TN” Lead Free Wheel Weights $389 40-604-4U “TN” Poly Series Wheel Weight TS $209

40-605U Universal Studs $239

40-607U Wheel Nuts $259

AUTO FLEET: PINS & CLIPS

40-620U Clevis Pins $139

40-621U Universal Clevis Pins $139

40-622U Hairpin Retainers $94

40-623U Hitch Pin Clips $119

40-623-1U Bow-Tie Cotter Pins $109

40-623-2U Rue-Ring Cotter Pins and Cotter Pins $114

40-623-4U Double Loop Hitch Pin $189

40-624U Clevis Assemblies $189

40-624-5U Lynch Pins $139

40-624-6U Square PTO Pin Assortments $109

AUTO FLEET: SPRINGS

40-625U Extension Springs $259

40-626U Compression Springs $144

40-627U Springs Master (40-627-1U, 40-627-2U,

40-627-3U & 40-627-4U) $859

40-627-1U Compression Springs $259

40-627-2U Extension Springs $189

40-627-3U Extension Springs $189

40-627-4U Long Extension Springs $254

40-627-5U .20 - .30 Precision

Wire Compression Springs $199

40-627-6U .36 - .48 Precision Wire Compression

Springs $199

40-627-7U 1/8 - 1/4” Precision Wire

Extension Springs $219

40-627-8U 5/16 - 1/2” Precision

Wire Extension Springs $239

40-627-9U Spring Assortment Master

(40-627-5, 40-627-6, 40-627-7, 40-627-8) $834

40-628U Import Door Rod End Clips $254

AUTO FLEET: PLUGS

40-640U Cup Extension Plugs $189

40-641U Concave Expansion Plugs $189

40-642U Nylon Locking Hole Plugs $129

40-643U Drain Plugs $129

40-643-1U Drain Plugs $119

40-643-2U Accufit™ Oil Drain Plugs $274

40-643-3U Accufit™ Oil Drain Plugs Gaskets $274

40-644U Drain Plug Gaskets $94

40-644-1U Drain Plug Gaskets $104

Auto Fleet

(22)

SHOP SUPPLIES: CUTTING TOOLS

40-820U Super Primalloy Taper, Plug

& Bottom Taps $799

40-821U Super Primalloy Taper Taps $324

40-822U Super Primalloy Plug Taps $324

40-823U Super Primalloy Bottom Taps $324

40-824U Super Primalloy Machine Screw Taps $159

40-825U Super Primalloy Spiral Taps $324

40-826U Super Primalloy Taper Pipe Taps $354 40-827U Super Primalloy Metric Plug Taps $354 40-829U Super Primalloy 1/2” Shank Drills $614

40-829-5U Roto-Kut™ 3/4 Depth of Cut $909

40-829-7U Roto-Kut™ 1” Depth of Cut $1,699 40-830U Eliminator Hacksaw &

Reciprocating Saw Blades $199

40-830-1U Reciprocating Saw Blades $159 40-830-2U Compact Reciprocating Air Saw and

Cobalt-Maxx™ Air Saw Blades $479

40-831U Reciprocating Saw Blades $189

40-832U Black Vortex Files - 10” $154

40-832-1U Black Vortex Files - 8” $139

SHOP SUPPLIES: MISCELLANEOUS

40-833-1U Paint Marker Assortment $114

40-835U ProCell Batteries $274

40-835-1U Rayovac Batteries $179

40-835-2U Procell Batteries $314

40-835-3U Ray-O-Vac Batteries $199

40-837U Steel Welding Rod $129 40-837-1U All Metal Welding Rod $109

40-839U Welding Supply $364

40-839-1U Welding Supply XL $364

40-840U Welding Heat Shop $209

40-857U Insert Bits and Power Bits $109

SHOP SUPPLIES: ABRASIVES

40-868U Crud Busters $104

40-869U 2” Surface Conditioning Flap Wheels $179

40-870U Flap Wheel Abrasives $154

40-870-1U Crimson Fire Flap Wheels $189

40-870-2U Flap Bands $159

40-870-3U Finishing Abrasives $199

40-871U Zirconia Cut-Off Wheels $109

40-871-1U Super-Maxx Cut-Off Wheels $139

40-872U Bristle Discs $254

40-872-0U Abrasive Brushes $139

40-872-1U Mini Pneumatic Cut-Off Tool $269

40-872-2U USA Master Pneumatic $959

40-872-3U USA 2” Grinder & Disc $374

40-872-4U USA Die Grinder & Disc $329

40-872-5U USA Right Angle Die Grinder $419

40-873U 2” Kim-Flex Discs $189

40-873-1U Mini Air Tool $329

40-873-2U Mini Air 4 Piece $439

40-873-3U Mini Air 6 Piece $674

40-873-4U Master Pneumatic Grinder $519

40-873-5U Mini Angle Grinder with Abrasives $254 40-873-6U Mini Die Grinder with Abrasives $259 40-873-7U Mini Right Angle Grinder with Abrasives $299 40-873-8U Mini Die Grinder Gun with Abrasives $289

40-873-9U 2” Abrasive Discs $139

Shop supplies

(23)

40-874U 2” Coral-Kut Discs $104

40-874-1U 3” Coral-Kut Discs $119

40-874-6U Kim-Kut SST Quick-Change Discs $179 40-875U Kim-Brite Surface Conditioning Discs $129 40-875-1U 2” & 3” Surface Preparation Discs $144

40-875-2U Surface Preparation Master $189

40-875-4U Mini Pneumatic Surface Prep. Gun

w/2” Abrasives $239

40-875-5U Mini Pneumatic Surface Prep. Gun

w/2” & 3” Abrasives $299

40-876U Cartridge Rolls $99

40-876-2U Orange “Blaze” Grinding Discs $209 40-876-3U Crimson-Fire^™ Grinding Discs $139 40-876-4U Dark-Fire 2” & 3” Discs $164

40-877U Mini Flap Wheels $144

40-878U Kim-Brite XL $129

40-879U Belt Sander $364

40-881U 1” Abrasive Waterproof Cloth Rolls - Rack $259

40-882U 1-1/2” Abrasive Waterproof

Cloth Rolls - Rack $324

40-883U 2” Abrasive Waterproof Cloth

Rolls - Rack $399

40-884U 1-1/2” Waterproof Screen

Cloth Rolls - Rack $289

40-885U Rotary Tool Accessories $154

40-886U Impact Gun & Socket $1,209

40-886-1U Impact Gun $909

40-887U Wire Brush $299

40-888U Sanding Pads $209

SHOP SUPPLIES: MISC. ABRASIVES

40-875-3U Kim-Brite Surface Conditioning Discs

- Rack $284

40-878-1U Kim-Brite XL Discs - Rack $304

40-878-2U Crimson Fire Discs - Rack $229

40-878-3U Orange Blaze Discs - Rack $389

40-878-4U Kim-Kut Zirconia Discs - Rack $224

40-878-5U Dark-Fire Discs $269

sHOP sUPPLIES

ABOUT abrasives storage equipment ASK YOUR REP

Gravity Feed Dispenser

715

Metal Peg Board

611 702

Wire & Abrasive Rack

NOTE: Abrasive Discs/Rolls are not included

4” Cut-Off

699 698

3” Cut-Off

703

4-1/2 Cut-Off

(24)

www.kimballmidwest.com 1-800-233-1294

Columbus, Ohio
