TABLE OF CONTENTS

MACHINE TYPE

MODEL

PAGE #

BACKHOE LOADER

3CX

5 & 6

BACKHOE LOADER

4CX

6 & 7

BACKHOE LOADER

3CX SITEMASTER

8

BACKHOE LOADER

4CN , 4C TURBO

8

BACKHOE LOADER

208S , 208S HF

9

BACKHOE LOADER

210S , 210SU

9

BACKHOE LOADER

214

10

BACKHOE LOADER

214E

11

BACKHOE LOADER

214SM-4

12

BACKHOE LOADER

215-4

12

BACKHOE LOADER

215-S

13

BACKHOE LOADER

215-S

14

BACKHOE LOADER

1400

,

1400B

14 & 15

BACKHOE LOADER

1500 ,1550B

15 & 16

BACKHOE LOADER

1700B

17

BACKHOE LOADER

SITEMASTER

18

BACKHOE LOADER

505-19 F.M , 505-22 , 505-22SWAY,

(3)

Steering

Lift

Stabilizer

Bucket

(4)
(5)

JCB 3CX BACKHOE LOADER

FOR MODELS BEFORE 1992

APPLICATION PART NUMBER DESCRIPTION

OPENING-CLOSING PISTON 991-00122 REPLACEMENT SEAL KIT LOADER TILT 991-00122 REPLACEMENT SEAL KIT LOADER LIFT 991-00123 REPLACEMENT SEAL KIT PROP PISTON 991-00122 REPLACEMENT SEAL KIT SWING PISTON 991-00018 REPLACEMENT SEAL KIT BACKHOE LIFT 991-00131 REPLACEMENT SEAL KIT BACKHOE (MIDDLE) 991-00130 REPLACEMENT SEAL KIT BACKHOE BUCKET 991-00127 REPLACEMENT SEAL KIT STICK EXTENSION 991-00122 REPLACEMENT SEAL KIT STEERING 991-00036 REPLACEMENT SEAL KIT 991-00021 REPLACEMENT SEAL KIT

JCB 3CX BACKHOE LOADER

FOR MODELS BETWEEN 1992-1997

APPLICATION PART NUMBER DESCRIPTION

OPENING-CLOSING PISTON 991-00095 REPLACEMENT SEAL KIT LOADER TILT 991-00095 REPLACEMENT SEAL KIT LOADER LIFT 991-00102 REPLACEMENT SEAL KIT PROP PISTON 991-00095 REPLACEMENT SEAL KIT SWING PISTON 991-00018 REPLACEMENT SEAL KIT BACKHOE LIFT 991-00110 REPLACEMENT SEAL KIT BACKHOE (MIDDLE) 991-00145 REPLACEMENT SEAL KIT BACKHOE BUCKET 991-00103 REPLACEMENT SEAL KIT STICK EXTENSION 991-00095 REPLACEMENT SEAL KIT STEERING 991-00052 REPLACEMENT SEAL KIT 991-00099 REPLACEMENT SEAL KIT

(6)

JCB 3CX BACKHOE LOADER

FOR MODELS SINCE 1998

APPLICATION PART NUMBER DESCRIPTION

OPENING-CLOSING PISTON 991-00095 REPLACEMENT SEAL KIT LOADER TILT 991-00095 REPLACEMENT SEAL KIT LOADER LIFT 991-00102 REPLACEMENT SEAL KIT PROP PISTON 991-00100 REPLACEMENT SEAL KIT SWING PISTON 991-00152 REPLACEMENT SEAL KIT BACKHOE LIFT 991-00110 REPLACEMENT SEAL KIT BACKHOE (MIDDLE) 991-00145 REPLACEMENT SEAL KIT BACKHOE BUCKET 991-00103 REPLACEMENT SEAL KIT STICK EXTENSION 991-00095 REPLACEMENT SEAL KIT STEERING 991-00156 REPLACEMENT SEAL KIT

JCB 4CX BACKHOE LOADER

FOR MODELS BETWEEN 1992-1997

APPLICATION PART NUMBER DESCRIPTION

OPENING-CLOSING PISTON 991-00095 REPLACEMENT SEAL KIT LOADER TILT 991-00095 REPLACEMENT SEAL KIT LOADER LIFT 991-00103 REPLACEMENT SEAL KIT PROP PISTON 991-00095 REPLACEMENT SEAL KIT SWING PISTON 991-00018 REPLACEMENT SEAL KIT BACKHOE LIFT 991-00115 REPLACEMENT SEAL KIT BACKHOE (MIDDLE) 991-00145 REPLACEMENT SEAL KIT BACKHOE BUCKET 991-00103 REPLACEMENT SEAL KIT STICK EXTENSION 991-00095 REPLACEMENT SEAL KIT STEERING 991-00099 REPLACEMENT SEAL KIT

(7)

JCB 4CX BACKHOE LOADER

FOR MODELS SINCE 1998

APPLICATION PART NUMBER DESCRIPTION

OPENING-CLOSING PISTON 991-00095 REPLACEMENT SEAL KIT LOADER TILT 991-00095 REPLACEMENT SEAL KIT LOADER LIFT 991-00103 REPLACEMENT SEAL KIT PROP PISTON 991-00100 REPLACEMENT SEAL KIT SWING PISTON 991-00152 REPLACEMENT SEAL KIT BACKHOE LIFT 991-00115 REPLACEMENT SEAL KIT BACKHOE (MIDDLE) 991-00145 REPLACEMENT SEAL KIT BACKHOE BUCKET 991-00103 REPLACEMENT SEAL KIT STICK EXTENSION 991-00095 REPLACEMENT SEAL KIT STEERING 991-00157 REPLACEMENT SEAL KIT

(8)

3CX

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

STEERING-2WD M300726-M337000 30 60 991-00021 M337001-M356443 30 70 991-00036 STEERING-4WD M320000-M337000 30 60 991-00021 SWING W > M319999 110 991-00018

4CN,4C TURBO

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

STEERING-2WD M300726-M337000 30 60 991-00021 STEERING-4WD M320000-M337000 30 60 991-00021 M337001-M356443 30 70 991-00036 SWING W > M319999 110 991-00018

3CX SITEMASTER

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

STEERING-2WD M300726-M337000 30 60 991-00021 M337001-M356443 30 70 991-00036 STEERING-4WD M320000-M337000 30 60 991-00021

(9)

4CN,4C TURBO

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

STEERING-2WD M300726-M337000 30 60 991-00021 STEERING-4WD M320000-M337000 30 60 991-00021 M337001-M356443 30 70 991-00036 SWING W > M319999 110 991-00018

280S,208S HF

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

BOOM 556-60025 M751600-UP 40 70 991-00100 BUCKET 7'3" 556-60026 M751600-UP 40 70 991-00100 BUCKET 8'4" 556-60049 M751600-UP 40 70 991-00100 DIPPER 556-60027 M751600-UP 40 70 991-00100 LIFT 553-60005 M751600-UP 30 60 991-00098 SHOVEL 553-60004 M751600-UP 30 60 991-00098 STABILZER 553-60006 M751600-UP 30 60 991-00098 210S,210SU

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

BUCKET 556-60000 M762248-M769999 40 70 991-00100 EXTENSION 553-60010 M762248-M769999 30 60 991-00098 553-60022 M762248-M769999 30 60 991-00098 LIFT 556-60017 M762248-M769999 40 70 991-00100 LIFT LH 556-60023 M762248-M769999 40 70 991-00100 LIFT RH 556-60024 M762248-M769999 40 70 991-00100 SHOVEL 556-60084 M762248-M769999 40 70 991-00100 STABILIZER 556-60003 M762248-M769999 40 70 991-00100 556-60093 M762248-M769999 40 70 991-00100 SWING 556-60010 M762248-M769999 40 70 991-00100

(10)

214

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

BOOM 561-60028 M400001-M430000 60 110 991-00110 561-90011 M400001-M430000 60 110 991-00110 BUCKET 557-16000 M400001-M430000 50 90 991-00127 557-16600 M400001-M430000 50 90 991-00103 CLAM SHOVEL 556-44000 M400001-M430000 40 70 991-00100 556-60019 M400001-M430000 40 70 991-00100 DIPPER-ARM 559-60009 M400001-M430000 60 100 991-00145 559-60019 M400001-M430000 60 100 991-00145 EXTENSION 556-44500 M400001-M430000 40 70 991-00100 556-60057 M400001-M430000 40 70 991-00100 LIFT 576-60000 M400001-M430000 50 80 991-00102 SHOVEL 556-44700 M400001-M430000 40 70 991-00095 STABILIZER 556-43700 M400001-M430000 40 70 991-00100 559-60004 M400001-M430000 60 100 991-00145 559-60005 M400001-M430000 60 100 991-00145 STEERING 556-33800 M400001-M430000 30 70 991-00099 556-34000 M400001-M430000 30 70 991-00099 556-46400 M400001-M430000 30 70 991-00099 556-46500 M400001-M430000 30 70 991-00099

(11)

214E

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

BOOM 561-60028 M430001-UP 60 110 991-00110 BUCKET 557-60006 M430001-UP 50 90 991-00103 DIPPER 559-60019 M430001-UP 60 100 991-00145 EXTENSION 559-60057 M430001-UP 40 70 991-00100 LIFT 559-60000 M430001-UP 50 80 991-00102 SHOVEL 556-44700 M430001-UP 40 70 991-00100 STABILIZER LH 559-60004 M430001-UP 60 100 991-00145 STABILIZER RH 559-60005 M430001-UP 60 100 991-00145 STEERING 556-46400 M430001-UP 30 70 991-00099 556-46500 M430001-UP 30 70 991-00099

(12)

214SM-4

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

BOOM LIFT 563-60028 M460001-UP 65 120 991-00115 563-60029 M460001-UP 65 120 991-00115 BUCKET 557-60006 M460001-UP 50 90 991-00103 557-60016 M460001-UP 50 90 991-00103 557-60030 M460001-UP 60 90 991-00147 CLAM SHOVEL 556-60077 M460001-UP 40 70 991-00100 DIPPER LIFT 561-60060 M460001-UP 60 110 991-00148 561-60061 M460001-UP 60 110 991-00148 561-60071 M460001-UP 60 110 991-00148 EXTENSION 556-60057 M460001-UP 40 70 991-00100 LIFT 576-60000 M460001-UP 50 80 991-00102 SHOVEL 556-44700 M460001-UP 40 70 991-00100 STABILIZER 559-60063 M460001-UP 60 100 991-00145 559-60069 M460001-UP 60 100 991-00145 STEERING 573-20001 M460001-UP 45 75 991-00156 SWING 559-60069 M460001-UP 60 100 991-00152 215-4 CENTERMOUNT SERIES

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

BUCKET 559-60024 M460001-UP 60 100 991-00145 559-60074 M460001-UP 60 100 991-00145 CLAMSHOVEL 556-60077 M460001-UP 40 70 991-00100 EXTENSION 556-60057 M460001-UP 40 70 991-00100 LIFT 576-60000 M460001-UP 50 80 991-00102 SHOVEL 556-44700 M460001-UP 40 70 991-00100 SHOVEL C/W 556-60022 M460001-UP 40 70 991-00100 STABILIZER 559-60063 M460001-UP 60 100 991-00145 STEERING 573-10001 M460001-UP 45 75 991-00156 SWING 559-60069 M460001-UP 60 100 991-00145

(13)

215S

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

BOOM 563-60007 M400001-M430000 65 120 991-00115 BUCKET 557-16000 M400001-M430000 50 90 991-00127 557-16600 M400001-M430000 50 90 991-00103 CLAM SHOVEL 553-13800 M400001-M430000 40 70 991-00122 556-44000 M400001-M430000 40 70 991-00095 556-60019 M400001-M430000 40 70 991-00095 556-60051 M400001-M430000 40 70 991-00095 DIPPER 559-50200 M400001-M430000 60 100 991-00130 559-60013 M400001-M430000 60 100 991-00145 EXTENSION 556-31000 M400001-M430000 40 70 991-00122 556-44500 M400001-M430000 40 70 991-00095 556-45400 M400001-M430000 40 70 991-00122 LIFT 557-13100 M400001-M430000 50 90 991-00127 557-16100 M400001-M430000 50 90 991-00127 557-60000 M400001-M430000 50 90 991-00103 557-60004 M400001-M430000 50 90 991-00103 SHOVEL 556-28900 M400001-M430000 40 70 991-00122 556-44700 M400001-M430000 40 70 991-00095 556-60022 M400001-M430000 40 70 991-00095 STABILIZER 559-53600 M400001-M430000 60 100 991-00130 559-53700 M400001-M430000 60 100 991-00130 559-60004 M400001-M430000 60 100 991-00145 559-60005 M400001-M430000 60 100 991-00145 STEERING 553-09600 M400001-M430000 30 60 991-00098 553-13400 M400001-M430000 30 60 991-00098 STEERING 553-09800 M400001-M430000 30 60 991-00098 553-13800 M400001-M430000 30 60 991-00098 553-14100 M400001-M430000 30 60 991-00098

(14)

215S

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

STEERING 553-09700 M400001-M430000 30 60 991-00098 553-13600 M400001-M430000 30 60 991-00098 STEERING 553-09900 M400001-M430000 30 60 991-00098 553-13800 M400001-M430000 30 60 991-00098 553-14300 M400001-M430000 30 60 991-00098 SWING 559-52800 M400001-M430000 60 100 991-00130 559-52900 M400001-M430000 60 100 991-00130 559-53400 M400001-M430000 60 100 991-00130 559-53500 M400001-M430000 60 100 991-00130 1400,1400B

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

CLAMSHOVEL 556-45400 TO M435696 40 70 991-00122 556-31900 M337001-M399999 40 70 991-00122 DIPPER 557-12900 M337001-M399999 50 90 991-00127 557-16600 M337001-M399999 50 90 991-00127 559-44000 M337001-M399999 60 100 991-00130 559-50000 M337001-M399999 60 100 991-00130 EXTENSION 556-23800 M337001-M399999 40 70 991-00122 556-31000 M337001-M399999 40 70 991-00122 SHOVEL 556-23900 M337001-M399999 40 70 991-00122 STABILIZER 556-23600 M337001-M399999 40 70 991-00122

(15)

1400,1400B

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

STABILIZER LH 559-36300 M337001-M399999 60 100 991-00130 559-53500 M337001-M399999 60 100 991-00130 559-60004 M337001-M399999 60 100 991-00130 STABILIZER RH 559-36400 M337001-M399999 60 100 991-00130 559-53700 M337001-M399999 60 100 991-00130 559-60005 M337001-M399999 60 100 991-00130 STEERING 556-23700 M337001-M399999 30 70 991-00036 556-28700 M337001-M399999 30 70 991-00036 556-46400 M337001-M399999 30 70 991-00036 556-46500 M337001-M399999 30 70 991-00036 SWING LH 559-53400 M337001-M399999 60 100 991-00130 SWING RH 559-53500 M337001-M399999 60 100 991-00130 1500,1550B

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

BUCKET 557-12900 M337001-M399999 50 90 991-00127 557-16000 M337001-M399999 50 90 991-00127 557-16600 M337001-M399999 50 90 991-00127 CLAMSHOVEL 556-23700 M337001-M399999 40 70 991-00122 556-31900 M337001-M399999 40 70 991-00122 556-44000 M337001-M399999 40 70 991-00122

(16)

1500,1550B

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

DIPPER 559-43200 M337001-M399999 60 100 991-00130 559-50200 M337001-M399999 60 100 991-00130 EXTENSION 556-23800 M337001-M399999 40 70 991-00122 556-31000 M337001-M399999 40 70 991-00122 556-44500 M337001-M399999 40 70 991-00122 SHOVEL 556-23900 M337001-M399999 40 70 991-00122 STABILIZER 559-36400 M337001-M399999 60 100 991-00130 559-53700 M337001-M399999 60 100 991-00130 559-60005 M337001-M399999 60 100 991-00130 STEERING 556-27600 M337001-M399999 30 70 991-00036 556-28700 M337001-M399999 30 70 991-00036 556-33800 M337001-M399999 30 70 991-00099 556-33800 M337001-M399999 30 70 991-00036 556-34000 M337001-M399999 30 70 991-00036 556-34000 M337001-M399999 30 70 991-00099 556-46400 M337001-M399999 30 70 991-00099 556-46500 M337001-M399999 30 70 991-00099 SWING 559-53400 M337001-M399999 60 100 991-00130

(17)

1700B

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

BUCKET 557-12900 M337001-M399999 50 90 991-00127 557-16000 M337001-M399999 50 90 991-00127 557-16600 M337001-M399999 50 90 991-00127 559-36100 M337001-M399999 60 100 991-00130 CLAMSHOVEL 556-23700 TO M345696 40 70 991-00122 556-44000 M337001-M399999 40 70 991-00122 EXTENSION 556-23800 M337001-M399999 40 70 991-00122 556-31000 M337001-M399999 40 70 991-00122 556-44500 M337001-M399999 40 70 991-00122 STABILIZER LH 559-36300 M337001-M399999 60 100 991-00130 559-53600 M337001-M399999 60 100 991-00130 559-60004 M337001-M399999 60 100 991-00130 STABILZER RH 559-36400 M337001-M399999 60 100 991-00130 559-53700 M337001-M399999 60 100 991-00130 559-60005 M337001-M399999 60 100 991-00130 STEERING 556-27600 M337001-M399999 30 70 991-00036 556-28700 M337001-M399999 30 70 991-00036 556-46400 M337001-M399999 30 70 991-00099 556-46500 M337001-M399999 30 70 991-00099 SWING LH 559-53400 M337001-M399999 60 100 991-00130 SWING RH 559-53500 M337001-M399999 60 100 991-00130

(18)

SITEMASTER

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

BUCKET 557-12900 M337001-M399999 50 90 991-00127 557-16000 M337001-M399999 50 90 991-00127 557-16600 M337001-M399999 50 90 991-00127 CLAMSHOVEL 556-23700 M337001-M399999 40 70 991-00122 556-31900 M337001-M399999 40 70 991-00122 556-44000 M337001-M399999 40 70 991-00122 DIPPER 556-44000 M337001-M399999 60 100 991-00130 559-50000 M337001-M399999 60 100 991-00130 EXTENSION 556-23800 M337001-M399999 40 70 991-00122 556-31000 M337001-M399999 40 70 991-00122 556-44500 M337001-M399999 40 70 991-00122 SHOVEL 556-23900 M337001-M399999 40 70 991-00122 STABILIZER 559-36400 M337001-M399999 60 100 991-00130 STEERING 556-27600 M337001-M399999 30 70 991-00036 556-28700 M337001-M399999 30 70 991-00036 556-33800 M337001-M399999 30 70 991-00036 556-34000 M337001-M399999 30 70 991-00036 556-46400 M337001-M399999 30 70 991-00099 556-46500 M337001-M399999 30 70 991-00099 SWING 559-53400 M337001-M399999 60 100 991-00130

(19)

505-19 F.M

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

CLAMSHOVEL 556-60019 M561011-M579360 40 70 991-00095 LIFT 561-60017 M561011-M579359 60 110 991-00110 LIFT-Float 561-60039 M561011-M579359 60 110 991-00110 TILT 553-02000 M561011-M579360 30 60 991-00021 553-04300 M561011-M579360 30 60 991-00021 TOW HITCH 556-42200 M568560 30 70 991-00099 556-46700 M561011-M579360 30 70 991-00099 505-22,505-22 SWAY

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

CLAM SHOVEL 556-60019 M561011-M579360 40 70 991-00095 LIFT 556-60015 M561011-M579360 60 110 991-00110 TILT 553-02000 M561011-M579360 30 60 991-00021 553-04300 M561011-M579360 30 60 991-00021 TOW HITCH 556-42200 M568560 30 70 991-00099 556-46700 M561011-M579360 30 70 991-00099 506B

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

DISPLACEMENT 563-60012 M570000 65 120 991-00115 TILT 563-60011 M570000 65 120 991-00115

525B-4HL

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

TILT-Side 553-04300 M272000-M276567 30 60 991-00021

530B-4HL

APPLICATION CYLINDER # SERIAL # ROD Ø BORE Ø SEAL KIT #

(20)

All part numbers contained in this catalog are for reference purposes only.We do not imply that these items are the product of any original equipment manufacturer.This application İnformation is the property of Hidrolik Sistemler Sız.El.San.Tic.Ltd.Şti. , which is not associated with any of the original equipment manufacturers listed in this catalog.The trademark JCB® İs a registered trademark owned by the original equipment manufacturer who is the source of all products bearing that trademark.
