Irregular Trellis for the Near-Capacity Unary
Error Correction Coding of Symbol
Values From an Infinite Set
12
3
Wenbo Zhang, Student Member, IEEE, Matthew F. Brejza, Tao Wang, Robert G. Maunder, Senior Member, IEEE,
and Lajos Hanzo, Fellow, IEEE
4 5
Abstract—Irregular joint source and channel coding 1
(JSCC) scheme is proposed, which we refer to as the irregu-2
lar unary error correction (IrUEC) code. This code operates on 3
the basis of a single irregular trellis, instead of employing a set 4
of separate regular trellises, as in previous irregular trellis-based 5
codes. Our irregular trellis is designed with consideration of the 6
UEC free distance, which we characterize for the first time in 7
this paper. We conceive the serial concatenation of the proposed 8
IrUEC code with an irregular unity rate code (IrURC) code and 9
propose a new EXtrinsic Information Transfer (EXIT) chart 10
matching algorithm for parametrizing these codes. This facil-11
itates the creation of a narrow EXIT tunnel at a low Eb/N0 12
value and provides near-capacity operation. Owing to this, 13
our scheme is found to offer a low symbol error ratio (SER), 14
which is within 0.4 dB of the discrete-input continuous-output 15
memoryless channel (DCMC) capacity bound in a particular 16
practical scenario, where gray-mapped quaternary phase shift 17
keying (QPSK) modulation is employed for transmission over 18
an uncorrelated narrowband Rayleigh-fading channel with an 19
effective throughput of 0.508bit s−1Hz−1. Furthermore, the 20
proposed IrUEC–IrURC scheme offers a SER performance gain 21
of 0.8 dB, compared to the best of several regular and irregular 22
separate source and channel coding (SSCC) benchmarkers, 23
which is achieved without any increase in transmission energy, 24
bandwidth, transmit duration, or decoding complexity. 25
Index Terms—Joint source–channel coding, irregular codecs, 26
channel capacity, iterative decoding. 27
I. INTRODUCTION 28
I
N MOBILE wireless scenarios, multimedia transmission is 29required to be bandwidth efficient and resilient to transmis-30
sion errors, motivating both source and channel coding [1]–[3]. 31
Classic Separate Source and Channel Coding (SSCC) may 32
be achieved by combining a near-entropy source code with a 33
near-capacity channel code. In this scenario, it is theoretically 34
Manuscript received October 31, 2014; revised April 14, 2015 and July 25, 2015; accepted October 8, 2015. This work was supported in part by the EPSRC, Swindon UK under Grant EP/J015520/1 and Grant EP/L010550/1, in part by the TSB Swindon UK under Grant TS/L009390/1, in part by the RCUK under the India-UK Advanced Technology Centre (IU-ARC), and in part by the EU under the CONCERTO project and in part by the European Research Council’s Advanced Fellow grant. The associate editor coordinating the review of this paper and approving it for publication was M. Xiao.
The authors are with School of Electronics and Computer Science, University of Southampton, Southampton SO17 1BJ, U.K. (e-mail: [email protected]. ac.uk; [email protected]; [email protected]; [email protected]. ac.uk; [email protected]).
Color versions of one or more of the figures in this paper are available online at http://ieeexplore.ieee.org.
Digital Object Identifier 10.1109/TCOMM.2015.2493149
possible to reconstruct the source information with an infinites- 35 imally low probability of error, provided that the transmission 36 rate does not exceed the channel’s capacity [4]. However, sep- 37 arate source-channel coding [4] is only capable of approaching 38 the capacity in the general case by imposing both infinite com- 39 plexity and infinite latency. For example, adaptive arithmetic 40 coding [5] and Lempel-Ziv coding [6] are capable of encoding 41 a sequence of symbols using a near-entropy number of bits per 42 symbol. However, these schemes require both the transmitter 43 and receiver to accurately estimate the occurrence probability 44 of every symbol value that the source produces. In practice, the 45 occurrence probability of rare symbol values can only be accu- 46 rately estimated, if a sufficiently large number of symbols has 47 been observed, hence potentially imposing an excessive latency. 48 This motivates the design of universal codes, such as the 49 Elias Gamma (EG) code [7], which facilitate the binary encod- 50 ing of symbols selected from infinite sets, without requiring 51 any knowledge of the corresponding occurrence probabilities 52 at either the transmitter or receiver. The H.264 video codec 53 [8] employs the EG code and this may be concatenated with 54 classic channel codes, such as a Convolutional Code (CC) to 55 provide a separate error correction capability. Nevertheless, this 56 SSCC typically suffers from a capacity loss, owing to the resid- 57 ual redundancy that is typically retained during EG encoding, 58 which results in an average number of EG-encoded bits per 59 symbol that exceeds the entropy of the symbols. 60 In order to exploit the residual redundancy and hence to 61 achieve near-capacity operation, the classic SSCC schemes 62 may be replaced by Joint Source and Channel Coding 63 (JSCC) arrangements [9] in many applications. As we have 64 previously demonstrated in [10, Fig. 1], the symbols that 65 are EG encoded in H.264 are approximately zeta probabil- 66 ity distributed [11], resulting in most symbols having low 67 values, but some rare symbols having values around 1000. 68 Until recently, the decoding complexity of all previous JSCCs, 69 such as Reversible Variable Length Codes (RVLCs) [12] and 70 Variable Length Error Correction (VLEC) codes [13], increased 71 rapidly with the cardinality of the symbol set, so much so that it 72 became excessive for the H.264 symbol probability distribution 73 and asymptotically tending to infinity, when the cardinality is 74
infinite. 75
Against this background, a novel JSCC scheme referred to 76 as a Unary Error Correction (UEC) code [10] was proposed 77 as the first JSCC that mitigates the capacity loss and incurs 78 0090-6778 © 2015 IEEE. Personal use is permitted, but republication/redistribution requires IEEE permission.
IEEE
Proof
Fig. 1. Schematic of the proposed IrUEC-IrURC scheme, in which an IrUEC code is serially concatenated with IrURC code and Gray-coded QPSK modulation schemes. Here,π1andπ2represent interleavers, whileπ1−1andπ2−1represent the corresponding deinterleavers.
only a moderate decoding complexity, even when the cardi-79
nality of the symbol set is infinite. In a particular practical 80
scenario, an iteratively-decoded serial concatenation of the 81
UEC code with an Irregular Unity Rate Code (IrURC) was 82
shown to offer a 1.3 dB gain compared to a SSCC bench-83
marker, without incurring an increased transmission energy, 84
duration, bandwidth or decoding complexity. Furthermore, this 85
was achieved within 1.6 dB of the Quaternary Phase Shift 86
Keying (QPSK)-modulated uncorrelated narrow band Rayleigh 87
fading Discrete-input Continuous-output Memoryless Channel 88
(DCMC) capacity bound. 89
In this paper, we will further exploit the properties of UEC 90
codes in order to facilitate reliable operation even closer to 91
the capacity bound. More specifically, we propose an Irregular 92
Unary Error Correction (IrUEC) code, which extends the regu-93
lar UEC of our previous work [10]. This IrUEC code employs 94
different UEC parametrizations for the coding of different sub-95
sets of each message frame, in analogy with previous irregular 96
codes, such as the IrURC [14], the Irregular Convolutional 97
Code (IrCC) [15] and the Irregular Variable Length Code 98
(IrVLC) [16]. However, these previous irregular codes oper-99
ate on the basis of a number of separate trellises, each of which 100
has a different but uniform structure and is used for the cod-101
ing of a different subset of the message frame. By contrast, our 102
new IrUEC code operates on the basis of a single irregular 103
trellis having a novel design. This trellis has a non-uniform 104
structure that applies different UEC parametrizations for dif-105
ferent subsets of the frame on a bit-by-bit basis. This allows 106
the irregularity of the proposed IrUEC code to be controlled 107
on a fine-grained bit-by-bit basis, rather than on a symbol-by-108
symbol basis, hence facilitating nearer-to-capacity operation. 109
More specifically, our results demonstrate that controlling the 110
IrUEC irregularity on a bit-by-bit basis offers gains of up to 111
0.2 dB over the symbol-by-symbol approach, without impos-112
ing any increase in transmission energy, bandwidth, latency or 113
decoding complexity. 114
This bit-by-bit IrUEC approach is facilitated by some partic-115
ular properties of UEC codes, which grant some commonality 116
to all UEC parametrizations. By exploiting this fine-grained 117 control of the IrUEC irregularity, the IrUEC EXtrinsic 118 Information Transfer (EXIT) function may be shaped to cre- 119 ate a narrow, but marginally open EXIT chart tunnel. This 120 implies that near-capacity operation is facilitated, according to 121 the theoretical properties of EXIT charts [17]. 122 The rest of this paper is organized as follows. Section II 123 describes a transmitter that serially concatenates the proposed 124 IrUEC encoder with a IrURC encoder, while Section III 125 describes the corresponding iterative receiver. The IrUEC 126 encoder and decoder operate on the basis of our novel irregular 127 trellis structure, which allows bit-level control of the irregular 128 coding fractions. The free distance of UEC codes is quantified 129 for the first time in Section IV, which proposes a novel low- 130 complexity heuristic method conceived for this purpose. This is 131 used for selecting a family of UEC trellis structures having a 132 wide variety of EXIT function shapes. The resultant UEC trel- 133 lis family maximises the design freedom for the IrUEC EXIT 134 function and therefore has a general applicability for IrUEC 135 codes used in diverse applications. Furthermore, for any partic- 136 ular application of an IrUEC code, we propose a double-sided 137 EXIT chart matching algorithm for selecting the specific frac- 138 tion of the frame that should be encoded using each IrUEC 139 and IrURC trellis structure. This allows the EXIT functions of 140 IrUEC and IrURC codes to be accurately shaped for closely 141 matching each other, hence creating a narrow but marginally 142 open EXIT chart tunnel. In Section V, the proposed IrUEC- 143 IrURC scheme is compared to an irregular JSCC benchmarker, 144 which is referred to as the EG-IrCC-IrURC scheme. The first 145 version of this benchmarker employs the recursive systematic 146 CCs that were originally recommended as IrCC component 147 codes in [15]. However, we demonstrate that the systematic 148 nature of these IrCC component codes results in a capacity loss. 149 This motivates the employment of the second version of our 150 EG-IrCC-IrURC benchmarker, which employs the recursive 151 non-systematic CCs of [10] as the IrCC component codes. The 152 simulation results of Section V show that in a particular prac- 153 tical scenario, the proposed IrUEC-IrURC scheme provides a 154
IEEE
Proof
0.8 dB gain over the best SSCC benchmarker, while operating155
within 0.4 dB of the capacity bound. This is achieved with-156
out any increase in transmission energy, bandwidth, latency or 157
decoding complexity. Finally, Section VI concludes the paper. 158
II. IRUEC-IRURC ENCODER 159
In this section, we introduce the transmitter of the proposed 160
IrUEC-IrURC scheme of Fig. 1. The IrURC encoder employs 161
T number of component Unity Rate Code (URC) encoders 162
{URCt}T
t=1, each having a distinct independent trellis structure. 163
By contrast, the IrUEC employs a unary encoder and a novel 164
Irregular Trellis (IrTrellis) encoder with a single irregular trel-165
lis. However, in analogy with the IrURC code, we note that this 166
irregular trellis comprises a merging of S component UEC trel-167
lis structures{UECs}sS=1, where UECs is the s-th component 168
UEC trellis structure that is defined by the corresponding code-169
word set Cs, as illustrated in [10, Fig. 3(a)]. In Section II-A 170
and Section II-B, the two components of the IrUEC encoder 171
in Fig. 1, namely the unary encoder and the novel IrTrellis 172
encoder are detailed. The IrURC encoder and the modulator are 173
introduced in Section II-C. 174
A. Unary Encoder 175
The IrUEC encoder is designed for conveying a vector 176
x= [xi]ai=1 comprising a number of symbols, as shown in 177
Fig. 1. The value of each symbol xi ∈ N1 may be modeled 178
by an Independent and Identically Distributed (IID) Random 179
Variable (RV) Xi, which adopts the value x with a prob-180
ability of Pr(Xi = x) = P(x), where N1= {1, 2, 3, . . . , ∞} 181
is the infinite-cardinality set comprising all positive integers. 182
Throughout this paper we assume that the symbol values obey a 183
zeta probability distribution [11], since this models the symbols 184
produced by multimedia encoders, as described in Section I. 185
The zeta probability distribution is defined as 186 P(x) = x −s ζ(s), (1) whereζ(s) =x∈N 1x
−s is the Riemann zeta function, s> 1 187
parametrizes the zeta distribution and p1= Pr(Xi = 1) = 188
1/ζ(s) is the probability of occurrence for the most frequently 189
occurring symbol value, namely x = 1. Without loss of gener-190
ality, Table I exemplifies the first ten symbol probabilities P(xi) 191
for a zeta distribution having the parameter p1= 0.797, which 192
corresponds to s= 2.77 and was found in [10] to allow a fair 193
comparison between unary- and EG-based schemes. Note that 194
other p1 values of 0.694, 0.8 and 0.9 have been investigated 195
in [18], [19]. In the situation where the symbols obey the zeta 196
probability distribution of (1), the symbol entropy is given by 197 HX= x∈N1 H [P(x)] = ln(ζ(s)) ln(2) − sζ(s) ln(2)ζ(s), (2) where H [ p]= p log2(1/p) and ζ(s) = −
x∈N1ln(x)x
−s is 198
the derivative of the Riemann zeta function. 199
As shown in Fig. 1, the IrUEC encoder represents the source 200
vector x using a unary encoder. More specifically, each symbol 201
TABLE I
THEFIRSTTENSYMBOLPROBABILITIES FOR AZETADISTRIBUTION HAVING THEPARAMETERp1= 0.797,ASWELL AS THECORRESPONDINGUNARY ANDEG CODEWORDS
xi in the vector x is represented by a corresponding codeword 202 yi that comprises xi bits, namely(xi− 1) binary ones followed 203
by a zero, as exemplified in Table I. When the symbols adopt 204 the zeta distribution of (1), the average unary codeword length l 205 is only finite for s> 2 and hence for p1> 0.608 [10], in which 206
case we have 207
l=
x∈N1
P(x) · x =ζ(s − 1)
ζ(s) . (3)
Note that for p1≤ 0.608, our Elias Gamma Error Correction 208 (EGEC) code of [19] may be employed in order to achieve a 209 finite average codeword length, albeit at the cost of an increased 210 complexity. In our future work, we will consider a novel 211 Irregular EGEC code, which has a finite codeword length for 212 p1≤ 0.608. Without loss of generality, in the example scenario 213 of p1= 0.797, an average codeword length of l = 1.54 results. 214 The output of the unary encoder is generated by concatenating 215 the selected codewords{yi}ai=1, in order to form the b-bit vec- 216
tor y= [yj]bj=1. For example, the source vector x= [4, 1, 2] of 217 a= 3 symbols yields the b = 7-bit vector y = [1110010]. Note 218 that the average length of the bit vector y is given by(a · l). 219
B. IrTrellis Encoder 220
Following unary encoding, the IrTrellis encoder of Fig. 1 221 employs a single new irregular trellis to encode the bit vec- 222 tor y, rather than using a selection of separate trellis structures, 223 as is necessary for the IrCC [15], IrVLC [16] and IrURC [14] 224 coding schemes. Our novel irregular trellis structure is facil- 225 itated by the properties of the generalised trellis structure of 226 [10, Fig. 3(a)], which was the basis of our previous work on 227 regular UEC codes. This trellis structure is parametrized by 228 an even number of states r and by the UEC codeword setC, 229 which comprises r/2 binary codewords of a particular length 230 n. Each bit yj of the unary-encoded bit sequence y= [yj]bj=1 231
corresponds to a transition in the UEC trellis from the previous 232 state mj−1∈ {1, 2, . . . , r} to the next state mj ∈ {1, 2, . . . , r}. 233
Each next state mj is selected from two legitimate alternatives, 234
depending both on the previous state mj−1and on the bit value 235 yj, according to [18, (3)]. More specifically, regardless of how 236 the UEC trellis is parametrized, a unary-coded bit of yj = 1 237
causes a transition towards state mj = r − 1 or r of the gener- 238
