A course in information architecture or web design, complemented with work in Human-Computer Interaction, will help the analyst understand how to improve the acceptability and utility of any computer-based system. End-users may be required to use a computer program but may not be satisfied with the inter-face. An understanding of interface tools, such as HTML forms, the concept of “error-correction on input”, and the like will inform your work.
Increasingly data are presented to end-users through web browsers or web-browser-like interfaces. Therefore a knowledge of HTML, CSS, XML, XML style sheets, and relational database and other file ac-cess via the Internet are the minimum skills an analyst should know.
Input
During the data gathering stage, the analyst collects samples of input and output screen designs and reports. These provide information about the data that are collected, who (or what job function) collected them, the aesthetics that end-users are familiar with, and the types of interactivity they know.
In situations where end-user participation is solicited, the analyst has many techniques for cri-tiquing and designing new input screens and reports. One technique is to hold meetings with the various user groups and to ask them to draw their ideal reports and input screens. The quality of the drawing is not important, what data and what labels the end-users provide are. Another common technique is to provide a toolkit of parts of screen designs (pieces of paper like a puzzle) and ask end-users to build various interfaces from the pieces.
Below is an image of the toolkit provided by OmniGraffle, first for web pages, second for Windows computer interfaces:
Systems Analysis Input and Output | 3
An important aspect of data input is to prevent errors before the data are stored in the system. For example, imagine a payroll system where the end-user can change his or her pay rate, accidentally entering $1.05 / hour or $1050 / hour instead of $10.50. “Error correction on input” sets the range of possible correct inputs, preventing null or 0 values when not permitted, higher or lower numbers, etc. The screen designer (the analyst himself or someone else on a design team) must know which fields can be null, repeat-ed, requirrepeat-ed, and so on. This information comes from the data dictionary.
Designing Screens
While end-user assist the analyst by drawing screens and reports on paper, the analyst (analyst, builder, designer, web-master, interface designer, whatever title) can layout screens quickly by using special tools, called “IDEs”, or Integrated Development Environments.
Here is a list of input controls for web forms. They are demonstrated in the figures above.
• Text field A single line for entering text; analyst can define the maximum length of this field on screen and the maximum number of characters that can be input in this field. This is important because the data are usually stored in an SQL ble. The data in the form cannot be larger than the field length size in the ta-ble.
• hidden field Same as above, but the end-user cannot see or alter the data contents. • test area A text area is like a text field, but has multiple lines.
• check box • radio button • radio group
• list or menu Also known as a drop-down box
• hyperlinks • image links • buttons
Dreamweaver™ is an IDE for creating web forms (http://www.adobe.com/products/ dreamweaver/). It is now part of Adobe’s (www.adobe.com) “Creative Suite 3” series.
For computer programs that collect input and provide output to end-users, analysts, programmers, and builders use other tools, depending on the programming language and operating system. Setting aside computer applications, there remain other kinds of compiled code that can run in a web browser or which communicate with a browser. Such plug-ins are familiar already among end-users who may have download-ed and installdownload-ed “skins” for Netscape and other programs that change the aesthetics of a program, or other plug-ins for displaying Adobe .pdf (portable document format) files and Macromedia Flash movies.
The analyst’s designs may be implemented by the analyst or by someone else. In the latter case, the analyst looses control over the product: if an organization has only a qualified web designer, he or she may opt to convert the design into a web form; alternatively, a computer programmer may see the implementa-tion as an applet, ActiveX control, or some other form, such as Visual Basic programs. It is the analyst’s responsibility to know what the organization or client will or can implement and specify that as part of the design.
ActiveX controls are part of Microsoft Corporation’s solution to adding greater interactivity in web design. The liability is, naturally, a preference for the Microsoft operating system. While the analyst should
Systems Analysis Input and Output | 5
know the benefits and liabilities of all the operating systems, she or he must look at Microsoft’s approach, even when the more useful solution is towards OpenSource or Unix; but be aware that Microsoft products may not run correctly on Unix, Linux or Macintosh computers.
Applets are small pieces of applications that will run on any computer. Although Microsoft has tried not to provide access to the Java Virtual Machine (JVM) or the Java Runtime Environment (JRE), end-users can download these products for free from java.sun.com. These applications are “bit-wise converters”: they convert the native code (Linux, Unix, Macintosh (which is now a flavor of Unix), and Microsoft) to a “virtual computer”. The virtual computer is a software implementation that makes it possible to run any-where, anytime. The advantage, of course, is that the analyst can specify Java and the client can implement the application or applet without fear it will not operate as specified. [Note: sometimes Java-specific recom-mendations may be implemented in C++, but this approach removes the platform-independence that so many people value.]
A popular approach to accessing data stored as files or in relational databases (such as MySQL) is to use interpreted languages, such as PHP or Perl. These languages are specially designed to process text (and after all, web files are just text).
In between the power of compiled languages and interpreted languages are Java Server Pages (JSP) and Active Server Pages (ASP). JSP, like Java, will operate on any computer. ASP and ASPX are Microsoft-specific implementations and require additional Microsoft products to create the files. Other implementa-tions include Cold Fusion, Ruby on Rails, and some emerging technologies.
Reports
Increasingly the analyst may design reports to be viewed through web browsers or at least on a com-puter screen. Let’s stick with web browsers for the moment. HTML permits the specifying of an internal or external file that holds commands that overwrite HTML’s interpretation of HTML tags. These are called cascading style sheets (.css). CSS can be created to control how data are presented on screen, but also how the data are expressed off-screen, that is, in print.
In addition, CSS let the analyst address how data will be viewed by other media types. If, for
example, the client-base includes blind people, the analyst could specify how the data should be reported in braille. There’s no reason, too, why the analyst couldn’t suggest alternative devices, such as televisions!
Here is an example of specifying different media in a web page (using the paragraph <p> tag), fol-lowed by a list of different media types.
<html> <head>
<title>Report</title></head> <style>
@media screen {
p.test {font-family:verdana, sans-serif;font-size:14 px} }
@media print {
p.test { font-family: times, serif; font-size: 10px } }
@ media screen, print { p.test { font-weight: bold } }
</style> </head> <body>
… rest of the document </body>
</html>
Above we used “screen” and “print.” Here is the list of complete media types you could use:
Media type Description
all Used for all media type devices
aural Used for speech and sound synthesizers
braille Used for braille tactile feedback devices embossed Used for paged braille printers
handheld Used for small or handheld devices
print Used for printers
projection Used for projected presentations, slides
screen Used for computer screens
tty Used for fixed-pitch character grid (teletypes, terminals)
tv Used for televisions
Aural Style Sheets Properties
Aural presentations are intended to be used by the blind, helping others to read, home entertain-ment, in the car, and where print is not possible. The below is an example of changing the <h1>, <h2>, <h3> tags in a web page:
h1, h2, h3 { voice-family: male; richness: 80; cue-before: url(“beep.au”) }
In this case a file will be read (beep.au) and played before any text tagged with <h1>, <h2>, or <h3> is read by a male voice. For more, read about CSS2 Aural Reference recommendations.
Print Style Sheet Properties
Anyone who has printed a document from a web browser has been surprised how the screen display differs from the printed version. The CSS2 print properties offers a great deal of control over how lines of text print. Variables are in italics (e.g., number could refer to any numeric value, e.g., 2, or 4, or 10, etc.).
Property Description Values
orphansMinimum number of lines that must be left at the number, e.g. 2
bottom of a page
marks Sorts of marks that should be rendered outside the none
page box crop
Systems Analysis Input and Output | 7
page Sets a page type to use when display an element auto
identifier
page-break-after [and] page-break-before auto
always avoid left right
size Orientation and size of a page auto
portrait landscape
windows The minimum number of lines for a paragraph number
that must be left at the top of a page
In addition to the .css commands, output may be directed automatically to a .pdf file, using XSL-FO (Extensible Markup Language-Formatting Objects).
Report formats
However the data are reported, most analyses require some kind of status or overview report. In this example, parts of these types of reports are identified:
[Report header / page header -->] Sales by Stock Number
June 30, 2008
[Column headers -->] Stock Description Invoice Quantity
Code number
[Detail lines -->] 2-1102 21” monitor 07-99939 1
2-1334 27” cinema dis. 08-10029 3
29-12 19” monitor 08-10040 1
99281-2 32” display 08-9-110 0
[Summary line -->] Subtotal 4
[Detail lines suppressed -->] 2-1334 27” cinema dis. 08-10030 1
08-70031 1
08-70032 1
08-92211 1
Subtotal 4
[Report summary] Report total 8
Finally, reports should be identified by any identifier, name, date, version number, page number, and creator.
What reports to make?
The analyst should consider clustering input and output interactions by function: input
process output
recipient
Specify what restrictions there are on the reports. This is called the “view of the data.” The con-cept is reviewed in any database and XML reporting texts and courses. In short, not all end-users ought to see all data. For example, from the same personnel and salary databases, two different end-users will see (at least) two different types of reports. One end-user may see only a list of staff identification numbers and paycheck numbers to make sure every staff member has a paycheck prepared. A manager, on the other hand, may see a summary report that lists all names, identification numbers, salaries, as well as the paycheck number.
