ROPE HOLDING ONLINE TECHNICAL SUPPORT BY THE EXPERTS

ONLINE TECHNICAL SUPPORT

IN DEPTH ADVICE & INFORMATION ON ALL SPINLOCK PRODUCTS AT WWW.SPINLOCK.CO.UK

KEEP UP TO DATE WITH ALL THINGS SPINLOCK:

ROPE HOLDING

BY THE EXPERTS

Our 2015 Guide covers the complete Hardware and Deckware ranges in one simple book.

Spinlock continue to develop products to make your sport more enjoyable and our new range of watersports PFD’s, Wing and FOIL ensure you will be wearing the latest in flotation technology.

If you need more information, head to our new fast access website for all the technical resource you need.

Rope holding product design is continually changing as new ropes are developed and crews demand simpler and faster line handling.

When specifying rope holding gear or when looking for better performance, here are some ideas:

Check ‘Spinlock Suggests’: our interactive rope holding app and database to help select the right product/rope combination.

Clutch or Jammer? Clutches are ideal for frequently adjusted lines. Jammers are preferred for secure locking of highly loaded lines.

Be prepared to upgrade your clutch or jammer when changing to a new, thinner or low stretch line or when making upgrades to sails, spars and equipment.

The greater the diameter of the line, the better the load holding. Consider internal or external line sleeving in the clutching or jamming area to increase rope diameter.

Clean your clutches and jammers regularly. Hose out the

mechanism, flush salt, dirt and rope debris away from the gripping and bearing surfaces. Grease bearing surfaces with Spinlock lubricant after cleaning.

PROUD TO SUPPORT

IMAGES CAD FILES SPINLOCK SUGGESTS & _{DECKVEST SUGGESTS} Product Selection Apps

VIDEOS DRILL_GUIDES

ONE TO ONE TECHNICAL SUPPORT [email protected] PRODUCT WEIGHTS INSTRUCTIONS Clutch Jammer

2015

PXR POWERCLEAT

XAS POWERCLUTCH

Instant cleating and easy release under load Angle line ‘Up’ to release, ‘Down’ to engage ‘T’ series fits most cam cleat hole centres Swivel and mast mount versions available

Unbeatable for mainsheet, vang and spinnaker hoist systems

For racing yachts up to 27’ & cruising yachts up to 34’ XAS0408 for high performance for small diameter lines XAS0612 for suberb performance across the rope range Easy-access handle for effortless release

Replaceable parts, easy to upgrade and maintain Side mount available

PXR0206 LINES 2-6MM (3/32-1/4”) LOADS UP TO 140KG (308LBS) XAS0408 LINES 4-8MM (5/32-5/16”) LOADS UP TO 400KG (880LBS) PXR0810 LINES 8-10MM (5/16-3/8”) LOADS UP TO 200KG (440LBS) XAS0612 LINES 6-12MM (1/4-1/2”) LOADS UP TO 575KG (1270LBS)

KEY DATA

KEY DATA

SWIVEL BASE T-BASE VERTICAL PIVOT DOUBLE TRIPLE SIDE MOUNT

2-6MM, 8-10MM 2-6MM, 8-10MM 2-6MM 4-8MM, 6-12MM 4-8MM, 6-12MM 4-8MM, 6-12MM

XTS POWERCLUTCH

XCS POWERCLUTCH

XTS0610 for high performance small diameter lines XTS0814 for superb performance across the range Available in single, double and triple units

Offers deck upgrade options to complement existing XTS fit Side mount versions available

XCS offers large diameter rope holding in a clutch Side mounting, lock open and continuous line versions available

Black, silver and white finishes

Also available in mirror polished stainless steel

XTS0610 / XCS0610 LINES 6-10MM (1/4-3/8”) LOADS UP TO 1000KG (2200LBS) XCS0814 LINES 8-14MM (5/16-9/16”) LOADS UP TO 1200KG (2640LBS) XCS1216 LINES 12-16MM (1/2-5/8”) LOADS UP TO 1200KG (2640LBS) XTS0814 LINES 8-14MM (5/16-9/16”) LOADS UP TO 1000KG (2200LBS)

KEY DATA

KEY DATA

DOUBLE TRIPLE SIDE MOUNT DOUBLE TRIPLE SIDE MOUNT

XTR POWERCLUTCH

New Spinlock technology offers a significant rope holding improvement on the latest small diameter rope types Ultra lightweight alloy/composite construction

Handle moves freely to ergonomic position ready for release Replaceable jaw module, easy access for cleaning

Available in black, silver and white. Special order colours: blue, green, amber and yellow

XTR0812 LINES 8-12MM (5/16-1/2”) LOADS UP TO 1000KG (2200LBS)

KEY DATA

ZR JAMMER

XX POWERCLUTCH

Release action always safely controlled from a winch Holds three line sizes: 10, 12 and 14mm

Removable jaw module access for easy cleaning Self-sealing deck fastening

Single units only

Latest jaw technology for reliable holding of blended cover ropes

Upgrade kit XX-KIT converts previous XX0812 models One-piece jaw module: easy to remove and clean Available in black, silver or white

Lock open version available

ZR1014 LINES 10-14MM (3/8-9/16”) LOADS UP TO 1500KG (3300LBS) XX0812 LINES 8-12MM (5/16-1/2”) LOADS UP TO 1800KG (3970LBS)

KEY DATA

KEY DATA

CLUTCH MODE RELEASE MODE SIDE MOUNT LOCK OPEN LOCK OPEN DETAIL

TILLER EXTENSIONS

EA TILLER EXTENSION

Lightweight tiller extension for dinghies and small day boat cockpits

Strong, lightweight black anodised aluminium tube

360° control - Spinflex™ joint swivels freely through 360°. Overcomes the risk of fatigue failure in conventional tiller joints

Straight handled racket grip telescopic tiller extension

Compact solution for smaller cockpits. Ideal for hiking and fast tacking

Removable fast pin for easy stowage Bronze, citrus, silver or amber finish

Spinlock have been leaders in tiller extension design since the early 80’s. Designed for the hardest of conditions, they reduce strain and increase the enjoyment of helming.

Spinlock tiller extensions are the preferred solution for performance helming.

Asymmetric grip telescopic tiller extension Allows two handed helming with arms relaxed into a comfortable elbows down position

Removable fast-pin for easy stowage Amber, bronze, citrus or silver finish

EJB TILLER EXTENSION

EJ TILLER EXTENSION

| FRANK CAMMAS | GROUPAMA | M34 |

Allows the engine control to be located in best position for the helmsman

Removable handle reduces risk of lines snagging

Converts a standard Teleflex™ throttle into a flush socket unit

ATCU THROTTLE CONTROL

LENGTHS 600MM, 900MM & 1400MM EXTENDED LENGTHS 900MM, 1200MM, 1600MM & 2000MM

KEY DATA

KEY DATA

KEY DATA

ORGANISERS

Small boat organiser - 25mm sheaves Symmetric or asymmetric versions, 2 to 6 sheaves

Double stack with BE10 multiple bullseyes Curves to follow the shape of the deck

Symmetric and asymmetric versions, 2 to 6 sheaves

Use asymmetric to reduce deck footprint and save weight

Stackable when deck space is tight or for adding extra capacity later

Curves to follow shape of the deck Use TC50 organises for higher line loads

T25 ORGANISERS

T38 + T50 ORGANISERS

Line guide solution for low loads Use stand-alone or stacked on T25 organisers

Double and triple versions

Stack lines to minimise deck clutter

Low profile line guides Double screw fitting Self-sealing base

6mm*, 10mm, 12mm and 16mm

*single screw fitting

Compact stanchion lead system Reduces line friction during furling WL/1 guide for intermediate stanchions WL/2 sheave for line entry and exit stanchions

BE10 MULTIPLE BULLSEYE

BE BULLSEYE

WL FURLING LINE LEAD

T25/4Y + BE10/2 BE10/3

WL/1

BRS SPINNAKER BLOCKS

Fit a winchfeeder aft of a clutch or jammer to divert lines to an alternative winch

Low profile 25mm (1”) keeps winchfeeders safely out of traffic

Available in 50mm (2”) and 63mm (2 ½”) sheave sizes

Accessories available to link units and capture lines

Ensures fast, smooth sail hoists

Graphite bearings, anodised alloy rollers RF/MA - Mainsail feeders slots into mast track

RF/H & RF/H2 - Headsail feeder guides genoa from deck cleanly up into the foil For controlled spinnaker handling

Attaches with webbing strop to toe rail or padeye - no drilling, no deck clutter Strop allows fullest rotation for spinnaker sheet Available in 50mm (2”) and 63mm (2 ½”) sheave sizes

TWF WINCHFEEDER

RF SAILFEEDER

PD PADEYES

High strength 17-4PH stainless steel Excellent strength to weight ratio

Increased through-deck bearing surfaces to reduce loading

Significantly reduced weight Improved shock loading resistance Compact foot print and ability to ‘nest’

SUA MINI JAMMER

Significantly improves load holding in a clutch or jammer Protects lines from abrasion and UV damage

Easily brushed onto selected areas of clean dry line Ideal for strops where abrasion risk is high 250ml, 1000ml and 5000ml tins available Popular halyard jammer for smaller boats More powerful than a cam cleat; more compact than a clutch

For use with smaller winches Single, double and triple versions

ZS OPEN JAMMER

The neatest solution for superyachts where unloaded heavy line are parked taut, ready for use

Rig or deck mounted; port and starboard versions Low profile, anodised aluminium construction

The essential solution for temporary holding of lines, peeling spinnakers, headsails and reefing

Unbeatable in an emergency

Easily attached to any strong point with a strop

Hinged body can be opened and closed like a snatch block Custom options include rig or deck mounting holes

ZL LINE PARKER

KEY DATA

ZS ROPE SENSE

KEY DATA

Compact load cell for mobile load measuring ZS Rope Sense offers the ability to quickly and easily confirm actual working loads and refine deck hardware and rope selection

Simple, soft loop attachment offers fast connection in any application

U

LTIMATE ROPE HOLDING

FOR THE HIGHEST LOADS

O

BOUNDARIES OF ROPE HOLDING

.

V

.

.

.

XXC POWERCLUTCH

XXC0812

LINES 8-12MM (5/16-1/2”) LOADS UP TO 2350KG (5180LBS)

KEY DATA

Holds lines up to a massive 2350kg working load Ceramic coated jaws

Side mounting: bolted or bonded versions Lock Open Jaw feature

UPGRADES + SPARES

ZS JAMMER

ZS Alloy

Unrivalled performance for larger diameters and high loads, with the advantage of winch controlled release

Side mountable using existing fastening holes ZS Carbon

For ultimate load holding and minimum weight Ceramic coated jaw options

ALLOY LINES 8-18MM (5/16-11/16”) LOADS UP TO 4000KG (8820LBS) CARBON LINES 10-32MM (3/8- 1 1/4”) LOADS UP TO 12000KG (26460LBS)

KEY DATA

Digitally modelled jaw surfaces

High load performance on small diameter lines High visibility handle printing

Side mount and bonded versions available

Whether you’re looking to improve performance, extend life or replace worn parts, our Upgrades and Spares shop can help clearly identify what parts are available for your Spinlock gear and how to order. Fitting a cam or jaw upgrade can significantly improve rope holding performance. New handles and labels can refresh an older deck plan.

www.spinlock.co.uk/upgrades

TSR AFT ORGANISER

We offer a comprehensive range of upgrades and spares for

Spinlock products old and new.

20mm diameter alloy sheaves

All rotating sheaves with plain bearings Central shaft designed to spread load through laminate

Tulip sheathed design reduces friction from vertical deflection

Alloy top rails

Modular design and assembly Low profile design

Simple inserting and removal of endless lines Easily serviced without demounting from deck

F

10

S

U

LTIMATE

P

ROTECTION

DECKVEST 5D

The complete lifejacket harness for all sailors

170N (38lbs) model recommended for offshore sailing Automatic inflation, easily convertible to manual only Lightweight and comfortable designed for long periods of use Deck safety harness with soft loop attachment point

Included: Sprayhood, Pylon™ light, crotch straps, safety line cutter, mesh pocket

170N & 275N VERSIONS

ISO12402-3 & ISO12401 CE APPROVED HARNESS AUTOMATIC WATER ACTIVATED AND HAMMAR HYDROSTATIC VERSIONS AVAILABLE

KEY DATA

FIT SYSTEM BACK ADJUSTMENT

DECK HARNESS PRO SENSOR

OR HAMMAR FIRING HEAD WITH CO2 _CYLINDER CROTCH STRAPS CHEST PACK ATTACHMENT POINTS QBZ ZIP LIFTING LOOP MANUAL ACTIVATION HANDLE SPRAYHOOD PYLON LIGHT ORAL INFLATION TUBE & WHISTLE

DECKVEST LITE

DECKVEST CENTO

Ultra lightweight, low profile, 170N lifejacket designed for the active water user

Stripped down to essential features and built for control Automatic inflation, easily convertible to manual only Single crotch strap with recessed clip

Upgrade attachment points for Spinlock Pylon™ light and sprayhood 170N BUOYANCY AUTOMATIC WATER ACTIVATED ISO12402-3 CE APPROVED USCG APPROVED

KEY DATA

BACK INFLATED SIDE

100N BUOYANCY HARNESS FOR USERS 20-50KG AUTOMATIC WATER ACTIVATED ISO12402-3 ISO12401 HARNESS CE APPROVED

KEY DATA

Junior lifejacket harness for users 20-50kg Automatic inflation

Soft loop harness attachment point

Compact and lightweight, sized especially for smaller users Simple adjust chest buckle and crotch straps

Upgrade attachment points for Spinlock Pylon™ light and sprayhood

DECKVEST CENTO

Perfect for personal essentials ‘Toggle fits’ to Deckvest and Deckvest LITE

Secure double fold velcro attachment fits any belt type

Internal lanyard attachment and key clip for security

PACKS

CHEST PACK

Larger capacity

Secure water bottle holder Secure double fold velcro attachment fits any belt type Internal lanyard attachment and key clip for security

SIDE PACK

Perfect for daily essentials Secure double fold velcro attachment fits any belt type Internal lanyard attachment and key clip for security

FOIL

HIGH AGILITY FLOTATION

WING

IDEAL FOR DINGHIES, KEELBOATS, RIB’S AND WATERSPORTS 50N 4 SIZES: S, M, L, XL ISO 12402 CE APPROVED

KEY DATA

Front and Side ZIP versions

Low profile with low snag body fit system Tapered high cut for action and mobility Internal ‘GRIP’ print

Stretch mesh outer pocket with internal security pocket Articulated back panelling (FOIL)

Light and compact - for use with every lifejacket harness Compact, elasticated webbing, dry coated to repel water Easy, one handed action

Overload indicator CE Approved ISO12401

Razor edged security knife for cutting loaded safety lines in an emergency

Pouch will fit any lifejacket belt

Integrated with all Deckvest 5D lifejacket harnesses

Unbeatable impact protection for sailing

High density foam-moulded protection and support Breathable neoprene panelling for extra compactness Extra tough abrasion covers

COW HITCH / CONNECT

CLIP / CONNECT

SAFETY LINES

SAFETY LINE CUTTER

KNEE PADS

Single clip, loop

Double clip

Single clip, loop, stretch

Double clip, stretch

Double clip, loop, stretch

Triple clip, stretch

The only compact lifejacket light with complete 360° visibility

Water activated with manual on/off switch Battery test indicator

Fitted as standard to all Deckvest 5D lifejacket harnesses Retro fits on other inflatable lifejackets

Latest generation of the only mast harness designed for the marine environment

The safer, fully certified alternative to a bosun’s chair Ergonomic waist belt and super wide leg straps for extra comfort and lumbar support

Tripping Spike pocket Tool attachment points

Machined in hard anodised alloy CE Approved 0120 Type C – EN12277

Improved design with new shackle key for sizes 5 -14mm Sized for snap shackles up to Tylaska T-20

Machined in alloy, hard anodised Half the weight of traditional spikes

Revolutionary deck harness design Ultra light, comfortable and easy to fit Soft loop attachment point

CE Approved ISO12401

MAST PRO HARNESS

TRIPPING SPIKE

DECK PRO HARNESS

UPGRADES + SPARES

Retrofit Sprayhood for Deckvest LITE and Cento to reduce spray inhalation secondary drowning risk

Deckvest Pro Sensor – 33g or 60g CO2 cylinder and firing head Deckvest LITE – 33g CO2 cylinder and firing head CENTO Junior Lifejacket – 20g CO2 cylinder and firing head

Halkey Roberts Re-Arming kit for Deckvest LITE - USCG version only

With ‘CRC’ Corrosion Resistant Coating prevents CO2 Bottle corrosion – unique to Spinlock

CO2 cylinders and firing heads are available in all models as required

For Deckvest Pro Sensor and Deckvest LITE - Kit for converting UML automatic firing systems to manual only For Deckvest Hammar – 33g or 60g CO2 cylinder, firing head and manual handle

Replacement thigh and crotch straps are available for all Deckvest Models

SPRAYHOOD

DECKVEST LITE & CENTO

RE-ARMING KITS

CO

CYLINDER & FIRING HEAD

MANUAL CONVERSION KIT

HAMMAR RE-ARMING KITS

A compressed paper element / bobin dissolves to release a sprung needle which pierces the CO2 cylinder. Sea, spray or

rain running down through the unit should not cause activation. Only water flowing upwards will activate firing.

Will not inflate until the cap is approximately 10cm underwater.

It is designed for use in more extreme conditions and extended offshore sailing.

UML/HALKEY ROBERTS – WATER ACTIVATED

HAMMAR MA1 – PRESSURE ACTIVATED

DECKVEST LIFEJACKETS SIZE GUIDES

Spinlock Deckvest lifejackets use a range of inflation systems. The Deckvest LITE lifejacket uses the water activted UML paper coil system*. The Deckvest 5D is available with either UML Pro Sensor or Hammar hydrostatic inflation system. *USCG LITE – Halkey Roberts

LIFEJACKET INFLATION SYSTEMS

DECKVEST SIZE GUIDE

CHEST MEASUREMENT

DECKVEST 5D

LITE

CENTO

KNEE PADS SIZE GUIDE

30cm 11.8” 20cm S/M L/XL 7.9” 40cm 15.75” 50cm 19.7”

WING & FOIL SIZE GUIDE

CHEST MEASUREMENT XS S M L XL CO VER IMA

GE: JESÚS RENEDO – BLA

CK PEARL, SOTO 40, COP

A DEL REY

DESIGN: SIMON UD

AL DESIGN L
