Grating Type Din 24537

(1)

(2)

Floor gratings

Floor pressed gratings

– connecting rods are connected to bearing rods by pressing. Mesh type 33 x 33 mm. Construction

Floor pressure welded gratings SP

– rectangular or square pattern grating constructed using flat bars stood on edge, and 4,7 mm twisted transverse bars which are forged welded together under high pressure resulting in ONE PIECE construction. Mesh 34 x 38 mm.

Grates and stair treads are provided: 1._{Raw designed (black)}

2._{With deep galvanized finish according to DIN 5097} 3. _{Painted by wet dipping, the color grey pain RAL 7005}

Manufacture mesh types and supporting rods of type P (pressed) gratings accroding to DIN 24537 Name 30/30 30/15 30/10 19/30 19/60 30/60 60/60 Mesh size 33/33 33/16,6 33/12,5 19/33 19/66 33/66 66/66 Supporting profile kg/1m 2 _kg/1m2 _kg/1m2 _kg/1m2 _kg/1m2 _kg/1m2 _kg/1m2 20 x 2 14,4 18,3 20,9 21,8 19,9 12,5 7,6 25 x 2 17,0 20,9 23,5 26,3 24,3 15,1 9,1 30 x 2 19,7 23,6 26,2 30,8 28,9 17,8 10,5 35 x 2 22,4 26,3 28,8 35,3 33,4 20,4 12,0 40 x 2 25,0 28,9 31,5 39,8 38,9 23,1 13,4 45 x 2 28,1 32,0 34,6 45,1 43,1 26,2 15,1 50 x 2 30,3 34,2 36,7 48,8 46,8 28,4 16,3 60 x 2 35,6 39,5 42,1 57,8 55,9 33,7 19,2 25 x 3 24,0 27,9 30,5 38,1 36,2 22,1 12,9 30 x 3 27,6 31,5 34,0 44,2 42,3 25,7 14,8 40 x 3 35,6 39,5 42,1 57,8 55,9 33,7 19,2 70 x 3 60,5 64,3 66,9 99,9 98,0 58,5 32,8

SP grating´s possible supporting rods

High

[mm] Wide [mm]

2 3 4 5

25 YES YES NO NO

30 YES YES YES NO

35 YES YES YES NO

40 YES YES YES NO

50 YES YES NO NO

60 NO NO NO NO

Possible distance of supporting rods TS

– 34,3 and 68,6 mm SP gratings´Anti-slip choices High [mm] Wide [mm] 2 3 4 5 25 YES YES NO NO 30 YES YES NO NO 35 YES YES NO NO 40 YES YES NO NO 50 YES YES NO NO

The maximum and minimum dimension SP grating

Supporting rod: <480 mm – 3050 mm> Bearing rod: <480 mm – 1000 mm> Construction

(3)

Load of gratings with 30 x 30 mm mesh

® Bearing rod h x t [mm] * Distancec of support [mm]

Q Uniform load in kN/m2 _{f Deflection in mm from load q}

P Point load in kN in the centre of the grating 200 x 200 mm fl Deflection in mm from P

® * 500 600 700 800 900 1000 1100 1200 1300 1400 1500 20 x 2 q 18,45 12,80 9,40 7,20 5,70 f 2,0 2,9 3,9 5,1 6,4 P 1,80 1,45 1,20 1,00 0,90 fl 1,8 2,6 3,5 4,5 5,7 25 x 2 q 28,80 20,00 14,70 11,25 8,90 7,20 5,95 5,00 f 1,6 2,3 3,1 4,1 5,1 6,3 7,7 9,1 P 2,75 2,20 1,85 1,60 1,40 1,25 1,10 1,00 fl 1,5 2,1 2,8 3,6 4,5 5,5 6,7 6,9 30 x 2 q 41,50 28,80 21,15 16,20 12,80 10,35 8,55 7,20 6,15 5,30 f 1,3 1,9 2,6 3,4 4,3 5,3 6,4 7,6 8,9 10,4 P 3,95 3,20 2,65 2,25 2,00 1,75 1,60 1,45 1,30 1,20 fl 1,2 1,7 2,3 3,0 3,8 4,6 5,5 6,6 7,7 8,8 40 x 2 q 73,75 51,20 37,60 28,80 22,75 18,45 15,25 12,80 10,90 9,40 8,20 f 1,0 1,4 1,9 2,5 3,2 4,0 4,8 5,7 6,7 7,8 8,9 P 6,90 5,55 4,60 3,95 3,45 3,10 2,75 2,50 2,30 2,15 1,98 fl 0,9 1,3 1,7 2,3 2,8 3,5 4,2 4,9 5,7 6,6 7,6 20 x 3 q 27,65 19,2 14,10 10,80 8,55 6,90 5,70 f 2,0 2,9 3,9 5,1 6,4 7,9 9,6 P 2,70 2,15 1,80 1,55 1,35 1,20 1,05 fl 1,8 2,6 3,5 4,5 5,7 6,9 8,3 25 x 3 q 43,20 30,00 22,05 16,90 13,35 10,80 8,90 7,50 6,40 5,50 f 1,6 2,3 3,1 4,1 5,1 6,4 7,7 9,1 10,7 12,4 P 4,15 3,35 2,80 2,40 2,10 1,85 1,65 1,50 1,40 1,30 fl 4,15 3,35 2,80 2,40 2,10 1,85 1,65 1,50 1,40 1,30 30 x 3 q 62,20 43,20 31,75 24,30 19,20 15,55 12,85 10,80 9,20 7,95 6,90 f 1,3 1,9 2,6 3,4 4,3 5,3 6,4 7,6 8,9 10,4 11,9 P 5,95 4,75 3,95 3,40 3,00 2,65 2,40 2,15 2,00 1,85 1,70 fl 1,2 1,7 2,3 3,0 3,8 4,6 5,5 6,6 7,7 8,8 10,1 40 x 3 q 110,0 76,80 56,45 43,20 34,15 27,65 22,85 19,20 16,35 14,10 12,30 f 1,0 1,4 1,9 2,5 3,2 4,0 4,8 5,7 6,7 7,8 8,9 P 10,40 8,30 6,90 5,95 5,20 4,60 4,15 3,75 3,45 3,20 2,95 fl 0,9 1,3 1,7 2,3 2,8 3,5 4,2 4,9 5,7 6,6 7,6

Within this restriction the grating is still capable of taking up a single tradic load of 150daN in the most unfavourable position of a loading area of 200 x 200 mm in case if a maximum deflection of 1/200 of the span.

q = loading data for uniformly distributed loads (Q v daN/m2₎

f = deflection values (f)

Stair treads

Stair treads are made according to DIN 24531 and are out of grating according to DIN 24537. On the front side of treads there is a welded anti-slip perforated stepping edge which reduces

the slip hazard and also increases the static load capacity of the tread. Treads are provided with side plates 3 mm in thikness with holes for bolts.

100 x 100 mm is 1 500 N.

Standart dimensions od stair treads

Bearing rod Width mm Mesh _{bearing rod}Mat. of the Weight n

600 240 30/30 30 x 2 4,0 kg 120 270 30/30 30 x 2 4,5 kg 150 305 30/30 30 x 2 5,0 kg 180 800 240 30/30 30 x 2 5,1 kg 120 270 30/30 30 x 2 5,7 kg 150 305 30/30 30 x 2 6,3 kg 180 1000 240 30/30 35 x 2 7,9 kg 120 270 30/30 35 x 2 8,9 kg 150 305 30/30 35 x 2 9,9 kg 180 240 30/30 40 x 2 8,7 kg 120 1200 270 30/30 40 x 2 9,7 kg 150 305 30/30 40 x 2 10,8 kg 180

(4)

Stainless steel gratings, 17241 (1.4301) grade

Anti-slip type – the pressure welding grating

The detail of Anti slip classification

P/S1 P/S2

P

xSP SP

Pressed, smooth, mesh 33 x 33,

the detail Pressed, XXP reversibleanti-slip, the detail Pressed, XP serrated on the non supporting rod, the detail

Pressed, smooth, mesh 34 x 38 Pressed, XP Anti-slip on the supporting rod

Anti-slip type – the pressure welded grating

Type of the Anti-slip grating Anti-slip classification

SP Nonserrated R10

XSP Supporting rod serrated R11

Type of the Anti-slip grating Anti-slipp class

P Non serrated R10

P/S1 Serrated supporting and connecting rod R12

P/S2 Serrated nonsupporting rod R11

Stainless steel grating is manufactured in the same way as all the other types of presswelded grating, but from steel grade 17241 AISI 304 / [1. 4301] – stainless steel

Use

Stainless steel gratings are very popular for highly corrosive enviroments and long-lasting architectural apllications. The Pasove rating produced by pickling is resistant to water, water vzpour, citric acid, atmospheric humidity as well as teak organic and inorganic acids. These properties make them ideal especially for food industry (according to EU hygiencial requirements), beverage productions, pharmaceutical and cosmetics industry. The uniform and attractive surface is stainless steel grating particularly suitable for aesthetic architecture. We provide onesided (bearing rods direction) or reversible/bothsided (supporting rods direction), types or even in Anti-slip form.

The Stainless steel grates finish

– untreated, natural – pickled

Supporting

rod Bearing rod Mesh Finish Manufactured

20 x 2

8 x 1,5

30 x 30 Natural Stainless steel grate

25 x 2 30 x10 Stained Stringer XSL

30 x 2 20 x 20 Polished Grate with cut

35 x 2 22 x 22 40 x 2 22 x 30 20 x 3 10 x 2 22 x 44 25 x 3 22 x 88 30 x 3 30 x 60 35 x 3 60 x 30 40 x 3 30 x 60 50 x 3 60 x 10

(5)

Fastening materials and fixings

The position of gratings is in supporting rods

direction and should be if possible equal of the hight of supporting rods, min 25 mm. Gratings must

be secured against rising or sliding off the bearing structure. Each grating should be fixed at least in four points or welded.

K-1/P-T

Stadard clip to be fasten to material f.e. I – profile.

K-1/P-S

The top part of fastening – the clip.

K-2/P – 30T

Clip to be fasten to material, without drilling to.

K-2/P – 30S

Nailing fastening member without the drilling to construction needed. With the top part – the clip to mesh 30 x 30 mm.

K-3/P

Double clip to connect 2 gratings.

K-2/P – 20S

Nailing fastening member without the drilling to construction needed. With the top part – the clip to mesh 20 x 20 mm.

K-6/P - 10S

Fastening for a small dimensions of meshes 30 x 10 mm.

K-6/P - 15S

Fastening for a small dimensions of meshes 30 x 15 mm.

K-4/P

Clip for the small dimensions meshes f.e.: 33 x 16,5 mm.

K-5/P

(6)

Steel grating shelves

Shelf grating with L-shaped

angle section surround Shelf grating, bearing bar with raised edge surround Shelf grating with 4 „against movement“ elements KASALI, s.r.o. offers 3 types of shelf grating

according to construction type. The type of the grating shelves is designed according to desired load and customer´s requirements. Further specific

adjustments can be carried. Orientation and mesh size and design of the rods, we produce, depending on the required load.

Gratings tolerances according to

ČSN 73 2611

The following production tolerance is for all type of grates only in these conditions:

– Supporting bar´s size maximum 60 x 5 mm

– The axial pitches of bearing and connecting bars from 11 mm to 68 mm

– The area of the grating will not be more than 2 m2_{, no grating´s dimension will not be more}

than 2000 mm

Defection of the bearing rod from vertical plane

g_max = 0,1 x h

Verical position of connecting rod

connecting rod 6 mm: i_max = 1,5 mm connecting rod 8 mm: i_max = 2 mm

Horizontal position of connecting rod

k_max = 0,5 mm High framing p_max = 1 mm

Low framing

m_max = 1 mm Slanted cut of bearing rod n_max = 0,1 x H

Mesh gratings

Standart mesh 50 x 50 mm. Finish: raw, hot dip galvanized and grey colour as per RAL 7005 (hot dipped).

Deflection concave or convex

deflection lenght to 600 mm: q_max = 3 mm

lenght over 600 mm: q_max = 1 / 200 of loading lenght

Difference of measured diagonals

a - b = max. 0,012 x L

Tolerance of holes and shapes

c, e, f = max. + 0 mm, - 4 mm g = max. +/- 1,5 mm

d = max. +/- 4 mm (measured over 10 rods) h = max. + 8 mm, - 0 mm h = max. + 8 mm, - 0 mm
