1541 USB2

USB: Bridging the gap between

PC application and end device

(2)

Class Objectives



When you finish this class you will:



Understand the benefits/limitations of

various USB device classes for

implementing generic data transfer



Be able to implement generic data

transfers between a Windows

®

PC and

a PIC

®

MCU running as a HID or

(3)

Agenda



Application Overview (Thermometer)



Full-Speed USB Review



Debugging USB Applications



Microchip USB Framework (MCHPFSUSB)



.NET Framework Basics



Building a HID Class Thermometer



Lab 1 – HID Class Thermometer



Building a Custom Class Thermometer

Using WinUSB



Lab 2 – Custom Class Thermometer using

(4)

Agenda (Continued)



Matching a Driver to a Device



Detecting Devices



Finding Your Device



Lab 3a – Find Your Device



Obtaining a Handle



Handling Attach/Detach Events



Lab 3b – WinUSB Thermometer using

WM_DEVICECHANGE

(5)

PIC18F

Small, Low Power, Low Cost

Up to 12 MIPS

18- to 80-Pin Packages

Up to 128 KB Flash

Up to 4 KB RAM

USB 2.0 Device Support

Migration

PIC24F

Mid-Range, Capacitive-Touch Capable

Up to 16 MIPS

64-, 80- & 100-Pin Packages

Up to 256 KB Flash

Up to 16 KB RAM

USB 2.0 Device, Embedded Host, OTG

16-bit

8-bit

Pe

rfor

mance

32-bit

PIC32

High Performance, Pin Compatible to PIC24F

80 MHz, 1.53 DMIPS/MHz

Up to 80 MIPS

64- & 100-Pin Packages

Up to 512 KB Flash

Up to 32 KB RAM

USB 2.0 Device, Embedded Host, OTG

~40 USB PIC

MCUs

The industry’s strongest

scalable product, family

and software migration

path

(6)

Class Folders

C:\Masters\1541

\Development Tools

\Lab1..Lab3

\Device

\Device Solution

\Host

\Host Solution

\Microchip

\Presentation and Handouts

\Users Guides & Data Sheets

(7)

Application Overview

(Thermometer)

(8)

Outline

Application Overview

-

Application Requirements



Demonstrate moving data between PC

Application and end device via USB



The data is Temperature



Commands (see Appendix E in lab

manual):



0 – get Version



1 – get Temperature



2 – get Potentiometer



Platform: PIC18F Starter Kit 1 (DM180021)

(9)

Board Key Components

On Board Debugger

(provides SYS CLK)

(10)

Board Key Components

(11)

Board Key Components

Capacitive Touch Buttons

and Scroll Bar

(12)

Board Key Components

(13)

Board Key Components

3 Axis Acceleration Sensor

(BMA150)

(14)

Board Key Components

(15)

Board Key Components

(16)

Board Key Components

(17)

Board Key Components

(18)

Board Key Components

(19)

PIC18F46J50 Features



Parallel Master Port (PMP)



Real-Time Clock and Calendar (RTCC)



USB FS Device Capability



Charge Time Measurement Unit (CTMU)



Master Synchronous Serial Port (MSSP)



Enhanced Capture/Compare/PWM (ECCP)



10-Bit, 13-Channel Analog-to-Digital Converter



Two Enhanced USART



Peripheral Pin Select (PPS)



Nanowatt XLP Technology

(20)

(21)

Full-Speed USB Basics



USB is a “Single Master + Multiple Slaves” polled bus



In/Out WRT host

Mouse

Speaker

Printer

USB Host Controller (Master)

and Root Hub

(22)

Logical Device



Up to 16 bidirectional pipelines



“End Points”



Data CRC-32 protected



Bad packets auto resent*

Host

Device

EP0

EP1-16

(23)

Enumeration



Enumeration process



EP0 “Control Endpoint”



Chapter 9 commands



Descriptors



Dynamic address



.inf file



Host associates driver



Vendor & Product ID

(24)

Transfer types



Control



Bus configuration



Interrupt



Low rate/bounded latency



Bulk



Guaranteed integrity



Isochronous

(25)

Maximum Transfer Rates

Full Speed USB

-Transfer/

Endpoint Type

Polling Interval

% Reserved

BW/Frame for all

transfers of this

type

Max. # Data

Bytes/Frame/Endpoint (Max#

transactions per frame @ Max Ep

Size)*

Data

Integrity

Interrupt

Fixed, Periodic

90 64 (1 x 64)

Yes

Isochronous

Fixed, Periodic

90 1023 (1 x 1023)

No

Bulk

Variable, Uses Free

Bandwidth

0 1216 (19 x 64)

Yes

Control

Variable

10 832 (13 x 64)

Yes

(26)

USB Device Classes

Joystick

Mouse

External

Hard Drive

ICD2

COM Port

MCP2200

Thumb

Drive

Data Glove

Keyboard

Ethernet

Adapter

Human Interface Device Class

(HID)

Mass Storage Device

Class (MSD)

Communication Device

Class (CDC)

Custom Class

(Vendor Class)

Many more classes….

PICkit™ 2

(27)

Considerations When Using

Standard Classes



The Logical USB Device is predefined



Max. bandwidth is fixed



The Device data communication protocol

is defined



For CDC Class:



The PIC

®

MCU looks like a modem, or terminal

connected to a serial portsome implications:



PIC MCU may need to reply to “class-specific” requests – which

have nothing to do with your application (wastes some USB

bandwidth)



Main Benefit: Cross-platform use

(28)

USB Driver Choices

Features

HID

CDC

mchpusb.sys

(v1.0.0.6)

WinUSB

LibUSB

Driver support built

into Windows

Yes

Need .inf

No

Need .inf

No

64-bit PC Support

Yes

XP Ready

Yes

Vista/Win7 Ready

Yes

No

**

Transfer Types

Control

Yes

No

Yes

Interrupt

Yes

No

Yes

Bulk

No

Yes

(29)

Microchip USB Framework

(MCHPFSUSB)

(30)

Downloading the

Microchip Application Libraries



Download from

www.microchip.com/mal



Contains different stacks (USB, TCP/IP,

Graphics, mTouch™ Sensing Solution, etc.)



Default installation path:

C:/Microchip Solutions YYYY-MM-DD/



Contains libraries source code and several

example firmware projects based on

Microchip’s Development Tools

(31)

Default Install Directory

(32)

Default Install Directory

(33)

MCHPFSUSB Framework

Supported Platforms

-

Low Pin Count USB Development Kit (PIC18F14K50

Family)



PICDEM™ Full Speed USB (PIC18F4550 family)



PIC18F Starter Kit 1 (PIC18F46J50 family)



PIC18F46J50 FS USB Demo Board (+ HPC Explorer Board)



PIC18F87J50 FS USB Demo Board (+ HPC Explorer Board)



PIC24F Starter Kit 1 (PIC24FJ256GB110 family)



PIC24F USB PIM (+ Explorer 16 + USB PICtail™ Plus)



PIC32 USB PIM (+ Explorer 16 + USB PICtail Plus)



PIC32 USB Starter Board (PIC32MX460F512L family)



PIC32 USB Starter Board II (PIC32MX795F512L family)

(34)

Generic USB Project



General structure

./USB/Your application

main.c

usb_descriptors.c

HardwareProfile.h

usb_config.h

./Microchip

/Include

/USB

/Common

/…

Editable files

(35)

MCHPFSUSB Framework

-

Editable Files

-

usb_descriptors.c



Define your device descriptors



VID & PID



Class Specific (may not need to change)



Strings

**/* Device Descriptor */**

ROM USB_DEVICE_DESCRIPTOR device_dsc=

{ 0x12,

// Size of this descriptor (byte)

USB_DESCRIPTOR_DEVICE,

// DEVICE descriptor type

0x0200,

// USB Spec Release Number

My_Class_code,

// Class code

My_Subclass_code,

// Subclass code

My_Protocol_code,

// Protocol code

EP0_BUFF_SIZE,

// Max packet size for EP0

0x0000

,

// Vendor ID

0x0000

,

// Product ID

(36)

MCHPFSUSB Framework

-

Editable Files

-

HardwareProfile.h



Defines your board & hardware initialization routines for

your board

// #define USE_SELF_POWER_SENSE_IO

#define

tris_self_power TRISAbits.TRISA2

// Input

#if defined

(USE_SELF_POWER_SENSE_IO)

#define

self_power PORTAbits.RA2

#else

#define

self_power 1

#endif

//#define USE_USB_BUS_SENSE_IO

#define

tris_usb_bus_sense TRISAbits.TRISA1

// Input

#if defined

(USE_USB_BUS_SENSE_IO)

#define

USB_BUS_SENSE PORTAbits.RA1

#else

#define

USB_BUS_SENSE 1

(37)

MCHPFSUSB Framework

-

Editable Files

-

usb_config.h



Define framework options (use configuration tool)



USB Definitions



Device Class Usage



Endpoint Allocation

/ DEFINITIONS ******************************************/

#define

USB_EP0_BUFF_SIZE 8

// Valid Options: 8,

// 16, 32, or 64 bytes.

//#define USB_POLLING

#define

USB_INTERRUPT

//#define USB_SPEED_OPTION USB_LOW_SPEED //(not valid option

// for PIC24F devices)

#define

USB_SPEED_OPTION

USB_FULL_SPEED

#define

USB_SUPPORT_DEVICE

#define

USB_NUM_STRING_DESCRIPTORS 3

…

/ DEVICE CLASS USAGE ***********************************/

#define

USB_USE_CDC

…

(38)

MCHPFSUSB Framework

-

Editable Files

-

main.c



Contains

UserInit()



Main Loop



USBDeviceTasks()



Polled or Interrupt-driven



ProcessIO()



Callback function()

(39)

MCHPFSUSB Framework

Polled Program Flow

-Reset

main()

InitializeSystem()

while(1)

Your application

code

USBDeviceTasks()

ProcessIO()

USB Stack

Cooperative

Multitasking!!

No blocking

functions.

Use state

machine.

You edit UserInit()

Function

Services

CDCTxService()

MSDTasks()

Re-arm OUT Endpoint

(HID & Generic)

(40)

Reset

main()

InitializeSystem()

while(1)

Your application

code

ProcessIO()

You edit

UserInit()

USB Interrupt

Context

USBDeviceTasks()

MCHPFSUSB Framework

Interrupt Program Flow

-USBDeviceAttach()

Function

Services

Notifies the stack

when the device is

attached

CDCTxService()

MSDTasks()

Re-arm OUT Endpoint

(HID & Generic)

(41)

Cooperative Multitasking

Task B - 100us

Task A

900us

Max Loop Time

500us VS. 1000us

Task A.1 - 200us

State Machine

Task A.2 - 400us

Task A.3 - 300us

Main Loop

(42)

#include

“./USB/usb.h”

#include

“./USB/usb_function_cdc.h”

#include

“HardwareProfile.h”

void

UserInit(

void

){

…

}

void

ProcessIO(

void

){

if

((USBDeviceState < CONFIGURED_STATE)||(USBSuspendControl==1))

return

;

…

CDCTxService();

}

static void

InitializeSystem(

void

){

#if define …

#endif

UserInit();

USBDeviceInit();

}

int

main(

void

){

InitializeSystem();

while

(1){

USBDeviceTasks();

ProcessIO();

}

Code Example

Main.c

Needed (usb_config.h is called by usb.h)

Put your initzialization code here

Put your application code (state machine) here

No need to change

Conditional compiling

(No need to change)

USBDeviceTasks()

is executed into an ISR

(High Priority PIC18,

_USB1Interrupt()

(43)

Call Back Function



The USB firmware stack will call a callback

function in response to certain USB related

events



Modify that callback function to take

appropriate actions for each of these

conditions



Bottom of main.c

MAIN

PROGRAM

LIBRARY

FUNCTION

CALLBACK

FUNCTION

Application Layer

USB firmware

stack

(44)

(45)

Hardware Protocol Analyzer



The most useful tool for USB debugging



Captures signals in a cable segment and

decodes/displays the data down to each

individual byte



Typical Scenarios



View the device enumeration process



View protocol-specific communications

(HID, MSD)

(46)

Hardware Protocol Analyzer

Image © USB Complete: The

Developer’s Guide by Jan Axelson

(47)

Hardware Protocol Analyzer



Beagle 480

(

www.totalphase.com

)



Non-obtrusive real-time

monitoring



Monitors USB 2.0 LS,

FS, HS



Protocol-level decoding



Real-time filtering



Data Center Software

runs on PC, Linux &

MAC



US $1200

(48)

Using the Beagle 480

(49)

(50)

Outline

.NET Framework Basics

-

Modern PC Application Development

Requirements



What is the .NET Framework?



Common Language Runtime (CLR)



Framework Class Library



Namespaces & Assemblies



Common Type System



Compilation in the .NET Framework



C++/CLI: The .NET C++ Language



Visual C++ 2008 Express

(51)

Modern PC Application Development

Requirements



Simplified GUI and application

development



Platform Independence



Applications can be developed using

multiple languages



Local and distributed over the internet



New security and reliability features



Control code and/or give rights to certain

actions and deny others

(52)

What is the .NET Framework?



An abstraction layer over

an existing OS



Allows applications

compiled into a special

intermediate language

(IL) to run in a

“managed” environment



Based on ECMA/ISO/IEC

CLI standard



2 available

implementations



Microsoft .NET

Framework



Novell’s Mono Project

Windows

Linux

Common Language Runtime

Framework Class Library

Common Language Specification

Microsoft Visual

(53)

Common Language Runtime (CLR)



A virtual machine



Loads .NET

assemblies,



Verifies that the IL

code is “safe” to

execute.



Argument type

checking



Invokes a JIT

compiler to compile

the IL to native code

before execution



Garbage collection

Windows

Linux

Common Language Runtime

Framework Class Library

Common Language Specification

Microsoft Visual

(54)

Framework Class Library (FCL)



A set of thousands of

classes that provide

system services



Wrap Win32 APIs &

more



Examples



System::IO



Classes for

File/Stream IO



System::Windows::

Forms



Classes for Windows

GUI apps

Windows

Linux

Common Language Runtime

Framework Class Library

Common Language Specification

Microsoft Visual

(55)

Using Class Libraries (1/2)



.NET projects must have “references” to the

Class Library DLLs so that their code can be

linked in

or

(56)

Using Class Libraries (2/2)



To use a method from a particular class

library, you can use the “using

namespace” statement to avoid having to

type the fully qualified name

#using “System.Windows.Forms.dll”

using namespace System::Windows::Forms;

int main()

{

MessageBox::Show(“Hello, World!”);

// Fully-qualified name:

// System::Windows::Forms::MessageBox:Show(“Hello, World!”);

}

(57)

Common Language Specification (CLS)



CLS represents the

basic functionality

each .NET language

should implement if

they are to

interoperate with each

other



Class written in one

language can inherit

from a class written in

another



Common type system



Prohibit use of

pointers



Support

inter-language debugging

Windows

Linux

Common Language Runtime

Framework Class Library

Common Language Specification

Microsoft Visual

(58)

Common Type System



Some basic .NET types and their language keywords

Base Class

Visual Basic

2008

C#

C++/CLI

System::Byte

Byte

byte

unsigned char

System::SByte

SByte

sbyte

char

System::Int16

Short

short

System::Int32

Integer

int

System::Int64

Long

long

long long

System::Single

Single

float

System::Double

Double

double

System::String

String

string

String^

System::Decimal

Decimal

decimal

Decimal

(59)

Compilation in the .NET Framework

VB.NET

C#

VC++ .NET

vbc Compiler

csc Compiler

cpp Compiler

MSIL

Unmanaged

Code

Common Language Runtime JIT Compiler

CLR Services

(60)

Managed vs. Unmanaged Code



Managed



Code whose every action is subject to

approval by the CLR and types conform

to the common type system



Advantages



Type safe (type checked by the CLR)



Garbage collection



Unmanaged (“Native”)



Native machine code that runs without

(61)

C++/CLI: The .NET C++ Language



C++/CLI is an adaptation of the

standard (ANSI) C++ language by

Microsoft, targeted for the .NET

framework



New CLR data type keywords



New override specifiers



New language constructs

(62)

C++/CLI vs. C# and VB.NET



Best of Both Worlds



Reuse existing C/C++ code, .dlls

and libraries



Easiest to interop with Win32 APIs



Which we need for USB I/O



Use the extensive .NET framework

class libraries to simplify GUI

(63)

Building C++/CLI Programs for the CLR



Visual C++ is Microsoft’s C++/CLI

compiler for their CLR



This class uses Visual C++ 2008 “Express

Edition”



Win32 Console/GUI apps



.NET Console/GUI apps



New: Visual C++ 2010 Express Edition



Free Download

(64)

Running Visual C++ 2008 .Net Apps



Target PC must have .NET framework

version 3.5 or newer installed to run your

program



Already installed on Windows Vista/7

systems



The .NET framework typically installed

through Windows Update



Stand-alone redistributable installer also

available

(65)

Visual C++ Compilation Modes

Compiler Switch

Produces

-none-

Native mode executable. Compiles

classic C/C++ code+libraries (no

C++/CLI features)

/clr

Mixed mode assembly (contains native

and MSIL code). Compiles classic C/C++

& C++/CLI code

/clr:pure

MSIL-only assembly (no native code).

Compiles classic C/C++ & C++/CLI code.

Can use classic types compiled to MSIL

/clr:safe

MSIL-only verifiable assembly. Compiles

classic C/C++ & C++/CLI code. Can only

use .NET types.

(66)

Visual C++ Compilation Modes



Recommended: /clr:pure (default)



Features



Produces pure IL code



Minimize need to jump outside CLR during

program execution – faster.



Define & use native (LPCSTR) and managed

(String^) types



#include native headers



See Appendix F for summary and

(67)

Calling Win32 Functions from .NET



USB I/O requires calling native (Win32)

functions in setupapi.dll, user32.dll,

winusb.dll ...



Handled by a mechanism called P/Invoke

(Platform Invoke) – available to all .NET

languages



Consists of a method (DllImport) that



Finds the .dll and loads into memory



Marshals its arguments (converts from managed to

native) so the DLL can understand the call



Makes the call to the DLL function



Marshals the return value (converts from native to

managed format) so that the managed code

understands the result

(68)

P/Invoke Example

Create a managed entry point for calling

Win32 API

RegisterDeviceNotification(..)

Step 1.

Set compilation mode to \clr, \clr:pure

(69)

P/Invoke Example

Step 2.



From Visual Studio Help, search for & identify the

function signature, dll, and header file

HDEVNOTIFY WINAPI RegisterDeviceNotification(

HANDLE hRecipient,

LPVOID NotificationFilter,

DWORD Flags);

Header

Winuser.h (include Windows.h)

Library

User32.lib

DLL

User32.dll

Unicode and ANSI names

RegisterDeviceNotificationW

(Unicode) and

RegisterDeviceNotificationA

(ANSI)

(70)

P/Invoke Example

Step 3.



#include the windows header file(s) & import

the namespace containing the DllImport

method

#include <Windows.h>

using namespace

(71)

P/Invoke Example

Step 4.



Create a managed function declaration, and use

attributes to associate it to an existing native function

[DllImport(“User32.dll" , CharSet = CharSet::Unicode,

EntryPoint="RegisterDeviceNotificationW")]

extern "C" HDEVNOTIFY

WINAPI

RegisterDeviceNotificationUM(

HANDLE

hRecipient,

// Input: The window that will receive the

// notification.

LPVOID

NotificationFilter,

// Input: Pointer to a

// DEV_BROADCAST_DEVICEINTERFACE structure

DWORD Flags

// Input: Indicate whether the handle is for a

// window or service status

(72)

Summary



.NET solves problems of past Windows

development



One development paradigm for all major

languages



.NET uses managed code with services

provided by the CLR



The .NET Framework is a very large class

library available consistently across

many languages



Visual C++ enables interoperability

between classical Windows (C/C++) &

.NET (C++/CLI) application development

(73)

(74)

Outline

HID Class Thermometer

-

The HID Device Class



The HID Report Descriptor



Using the HID Function Driver APIs



MCHPHID DLL Implementation



Lab 1 – HID Class Thermometer

(75)

The HID Device Class



Human Interface Device



Designed for devices that operate in

“human time”



Low rate data



Limited latency



“Device Class Definition for Human

Interface Devices”

(76)

HID limitations



Interrupt transfers only



Up to 64 bytes per transaction (FS)



No more than one transaction per

frame



Up to 1000 frames per second

(77)

The HID Report Descriptor



HID data transferred by “reports”



Report Descriptor



Detailed description of the data

coming from the device



Tells the host how to parse the data



Host sends a Get Report Descriptor

class specific request during

enumeration

(78)

Generic HID Data Descriptor

//Class specific descriptor - HID

ROM struct{BYTE report[HID_RPT01_SIZE];}hid_rpt01={

{

0x06, 0x00, 0xFF, // Usage Page = 0xFFFF (Vendor Defined)

0x09, 0x01, // Usage (Vendor Usage 1)

0xA1, 0x01, // Collection (Application)

0x19, 0x01, // Usage Minimum (0)

0x29, 0x40, // Usage Maximum (64)

0x15, 0x00, // Logical Minimum (0)

0x26, 0xFF, 0x00, // Logical Maximum (255)

0x75, 0x08, // Report Size 8 bits per report.

0x95, 0x40, // Report Count 64 bytes per report.

0x81, 0x02, // Input (Data, Var, Abs)

0x19, 0x01, // Usage Minimum (Vendor Usage = 0)

0x29, 0x40, // Usage Maximum (Vendor Usage = 64)

0x91, 0x02, // Output (Data, Var, Ads)

0xC0} // End Collection

};

(79)

usb_config.h



Need to update this field after creating

your HID descriptor table, before using

HID PC DLL functions

**/* HID */**

#define HID_INTF_ID

0x00

#define HID_EP

1  Leave at 1

#define HID_INT_OUT_EP_SIZE

3 #define HID_INT_IN_EP_SIZE

3 #define HID_NUM_OF_DSC

1

(80)

Using the HID Function Driver APIs

Inbound data

-

**HIDRxPacket(HID_EP,(BYTE*)**

&ReceivedDataBuffer,64);



Configures an endpoint to receive data



Returns a handle to the endpoint



Buffer must be within USB Dual Port RAM



HIDRxHandleBusy(USBOutHandle)



Returns 0 when buffer contains data



1 – no data Rx’d yet

(81)

HID Receive Usage

void ProcessIO(void)

{

...

if(!HIDRxHandleBusy(USBOutHandle)) {

/* Process received buffer */

//Re-arm the OUT endpoint for the next packet

USBOutHandle =

**HIDRxPacket(HID_EP,(BYTE*)**

&ReceivedDataBuffer,64);

}

(82)

Using the HID Function Driver APIs

Outbound data

-

HIDTxHandleBusy(USBInHandle



Is endpoint available?



HIDTxPacket(HID_EP,

**(BYTE*)&ToSendDataBuffer,64);**



Puts data on the endpoint for transport

(83)

HID Transmit Usage

case 0x81: //Get push button state

ToSendDataBuffer[0] = 0x81;

if(sw2 == 1)

ToSendDataBuffer[1] = 0x01;

else

ToSendDataBuffer[1] = 0x00;

if(!HIDTxHandleBusy(USBInHandle))

USBInHandle =

**HIDTxPacket(HID_EP,(BYTE*)&ToSendDataBuffer,64);**

break;

(84)

HID Class DLL



.NET Assembly “HID class.dll”



Encapsulates the Win32 HID Data transfer

APIs



Namespace HIDClass::MCHPHIDClass



Four Basic Functions:



void HIDClassInit(VID, PID, len);



bool HIDWriteReport(buffer, len);



bool HIDReadReport(buffer);

(85)

Initializing the Methods

void HIDClassInit (VID, PID,

len, timeout);



VID – Vendor ID assigned by USBIF



PID – Product ID assigned by VID

holder



Len – Buffer length (normally 64)

(86)

Polled Connection Detection

bool HIDIsConnected();



Checks to see if the VID & PID set by

HIDClassInit has been enumerated



Returns true or false



OS inquiry only. Does NOT

(87)

Writing A Report

bool HIDWriteReport (buffer,

len);



Buffer to transmit



len – Length of valid data in buffer.

Remainder of buffer padded to actual

HID buffer length



Returns True or False indicating

transfer success/failure

The device firmware must implement a “Generic” HID

report descriptor as shown earlier!

(88)

Reading a Report

bool HIDReadReport (buffer);



Buffer – Returned data



Non-blocking function



Returns true if data received within

1 second

The device firmware must implement a “Generic” HID

report descriptor as shown earlier!

(89)

Documentation



C:\Microchip Solutions\Microchip\Help\

(90)

Lab 1

(91)

Lab 1

HID Class Thermometer

-

Objective



To familiarize you with HID class transfers



Start with Generic HID example



Modify to read BMA150 temperature

sensor



Modify PC Application to read data



Display on application

(92)

HID Summary

Benefits/Drawbacks

-

Easy installation



no .inf file



driver built into OS



Throughput limited to 64 KB/sec



HID class.dll provides methods to

simplify connection to HID-class devices



Must use “generic HID” report descriptor

(93)

Building a Custom Class

(94)

Outline

Custom Class Thermometer Using WinUSB

-

Using the Custom Class Function

Driver APIs



WinUSB Overview & APIs



Obtaining & Using WinUSB



Lab 2 – Custom Class Thermometer

using WinUSB

(95)

Vendor Class

Firmware Structure

Reset

main()

InitializeSystem()

main()

You edit in

main.c/user.c

ProcessIO()

USB Interrupt

Context

You Edit

UserInit()

USBDeviceTasks()

Synchronous model



Accepts commands from host



Returns results

(96)

Custom Class Function Driver APIs

-

USBGenWrite(ep,pSrc,len);



Copies data from user’s buffer to the IN Ep buffer



Returns a USBGenericInHandle



USBGenRead(ep,pSrc,len)



Copies data from the OUT Ep buffer to the user’s

buffer



Returns a USBGenericOutHandle



USBHandleBusy(USBGenericInHandle)

(97)

Inbound data



USBGenRead(ep,pSrc,len)



“Arms” an endpoint to receive data from the host



Returns a USBGenericOutHandle to the

endpoint



USBHandleBusy(USBGenericOutHandle)



Returns TRUE if the handle is busy (i.e. still

waiting for the host)

(98)

Vendor Class Receive Usage

void ProcessIO(void)

{

...

if(!USBHandleBusy(USBGenericOutHandle))

{

switch(OUTPacket[0])

{

case 0x81: //Get push button state

...

break;

}

//Re-arm the OUT endpoint for the next packet

USBGenericOutHandle =

**USBGenRead(USBGEN_EP_NUM,(BYTE*)&OUTPacket,USBGEN_E**

P_SIZE);

}

(99)

Outbound Data



USBGenWrite(ep,pSrc,len)



Puts data on the endpoint for transport to host



Returns a USBGenericInHandle to the endpoint



USBHandleBusy(USBGenericInHandle)



Returns TRUE if the handle is busy (i.e. still sending to

the host)



Returns FALSE if the transfer is complete (i.e. the IN

endpoint buffer is available)

(100)

Vendor Class Transmit Usage

case 0x81: //Get push button state

INPacket[0] = 0x81;

if(sw2 == 1)

INPacket[1] = 0x01;

else

INPacket[1] = 0x00;

if(!USBHandleBusy(USBGenericInHandle))

USBGenericInHandle =

**USBGenWrite(USBGEN_EP_NUM,(BYTE*)&INPacket,USBGEN_**

EP_SIZE);

break;

(101)

Descriptor Table Settings

File usb_descriptors.c

**/* Device Descriptor */**

ROM USB_DEVICE_DESCRIPTOR device_dsc=

{

0x12, // Size of this descriptor in bytes

USB_DESCRIPTOR_DEVICE, // DEVICE descriptor type

0x0200, // USB Spec Release Number in BCD format

0x00, // Class Code

0x00, // Subclass code

0x00, // Protocol code

USB_EP0_BUFF_SIZE, // Max packet size for EP0, see usb_config.h

0x04D8

, // Vendor ID

0x0053

, // Product ID: Microchip WinUSB Demo

0x0100

, // Device release number in BCD format

0x01, // Manufacturer string index

0x02, // Product string index

0x03

, // Device serial number string index

0x01 // Number of possible configurations

};

(102)

Endpoint Descriptors

File usb_descriptors.c

**/* Endpoint Descriptor */**

**0x07, /sizeof(USB_EP_DSC)/**

USB_DESCRIPTOR_ENDPOINT, //Endpoint Descriptor

_EP01_OUT, //EndpointAddress

_BULK

, //Attributes

USBGEN_EP_SIZE

,0x00, //size

1, //Interval

**0x07, /sizeof(USB_EP_DSC)/**

USB_DESCRIPTOR_ENDPOINT, //Endpoint Descriptor

_EP01_IN, //EndpointAddress

_BULK

, //Attributes

USBGEN_EP_SIZE

,0x00, //size

1 //Interval

_

BULK,

_

CTRL

or _

INT

(Interrupt)

USBGEN_EP_SIZE

defined in usb_config.h

#define USBGEN_EP_SIZE 64

(103)

(104)

WinUSB



Before Windows

®

Vista

®

, all USB

device drivers had to operate in

kernel mode



WinUSB architecture :



Kernel-mode driver (winusb.sys)



User-mode dynamic link library

(105)

WinUSB Architecture



No need to write

your own driver



FULL speed



Works with XP and

Vista/7



One .inf file

Application

USB Stack

User mode

Kernel mode

USB Device

(PIC18F14K50)

Device

WinUSB.SYS

Microsoft

Existing

Component

Vendor

Component

Microsoft

New

Component

WinUSB

DLL

(106)

WinUSB features



WinUSB supports:



Device I/O control requests



Bulk, control, and interrupt transfers



Selective suspend



Remote wake

(107)

Key WinUSB APIs



winusb.dll exposes user mode

**client routines*:**



WinUsb_Initialize



WinUsb_WritePipe



WinUsb_ReadPipe



WinUSB_Free

*See

http://msdn.microsoft.com/en-us/library/ff540046(v=VS.85).aspx#winusb

(108)

WinUsb_Initialize



Creates a WinUSB handle for the

device specified by a file handle

BOOL __stdcall WinUsb_Initialize(

__in HANDLE DeviceHandle,

__out PWINUSB_INTERFACE_HANDLE InterfaceHandle

);

DeviceHandle

[in]

The handle to the device that CreateFile returned.

InterfaceHandle

[out]

The WinUSB handle for the device. All other WinUSB

routines require this handle as input.

(109)

WinUsb_WritePipe



Writes data to a pipe

BOOL __stdcall WinUsb_WritePipe(

__in WINUSB_INTERFACE_HANDLE InterfaceHandle,

__in UCHAR PipeID,

__in PUCHAR Buffer,

__in ULONG BufferLength,

__out_opt PULONG LengthTransferred,

__in_opt LPOVERLAPPED Overlapped

);

InterfaceHandle

[in]

WinUSB handle, for the device, which is returned by WinUsb_Initialize.

PipeID

[in]

An 8-bit value that consists of a 7-bit address and a direction bit.

Buffer

[in]

A caller-allocated buffer that contains the data to write.

BufferLength

[in]

The number of bytes to write. This number must be less than or equal to the size, in bytes, of Buffer.

LengthTransferred

[out, optional]

A pointer to a ULONG variable that receives the actual number of bytes that were written to the pipe.

Overlapped

[in, optional]

An optional pointer to an OVERLAPPED structure, which is used for asynchronous operations. If this parameter is

specified, WinUsb_WritePipe immediately returns, and the event is signaled when the operation is complete.

(110)

WinUsb_ReadPipe



Reads data from the specified pipe

BOOL __stdcall WinUsb_ReadPipe(

__in WINUSB_INTERFACE_HANDLE InterfaceHandle,

__in UCHAR PipeID,

__out PUCHAR Buffer,

__in ULONG BufferLength,

__out_opt PULONG LengthTransferred,

__in_opt LPOVERLAPPED Overlapped

);

InterfaceHandle

[in]

WinUSB handle, for the device, which is returned by WinUsb_Initialize.

PipeID

[in]

An 8-bit value that consists of a 7-bit address and a direction bit.

Buffer

[in]

A caller-allocated buffer that receives the data that is read.

BufferLength

[in]

The maximum number of bytes to read. This number must be less than or equal to the size, in bytes, of Buffer.

LengthTransferred

[out, optional]

A pointer to a ULONG variable that receives the actual number of bytes that were copied into Buffer.

Overlapped

[in, optional]

An optional pointer to an OVERLAPPED structure, which is used for asynchronous operations. If this parameter is

specified, WinUsb_ReadPipe returns immediately rather than waiting synchronously for the operation to complete

before returning. An event is signaled when the operation is complete.
