Complex Information System
MEGAPOLIS
Gazprom Gazoraspredelenie Vladimir
Open Joint Stock CompanyComplex information system “Megapolis” is an integration solution that covers the basic con-trol paths and consists of two basic levels:
Production
Execution
System
Dispatching
Geoinformation
System
Billing
System
Enterprise
Resource
Management
MEGAPOLIS
Complex Information System
• Billings for technical maintenance and repairing
• Billing for energy resources (gas, heat, electric power, water, and others) • Accounting and taxation, payments to personnel
• Management of personnel activity • Management of motor transport • Management of business processes • Normative and legal reference base
• Automated industrial control system (ICS) over gas, water and heat distribution in «Megapolis-TM» SCADA
• Recoding of certificates of technological objects
• Automatic meter reading and energy management software system (AMR + EMS) • Integrated geoinformation system (GIS)
• Acceptance of calls (emergency, maintenance and others)
• Monitoring of life support systems of buildings («Smart Home»)
• Monitoring of IT resources (data rooms, telephone stations, gateways, PC and others) • Monitoring of motor transport (Glonass, GPS)
• Monitoring of staff
2. Level of Enterprise Resource Management:
1. Level of Technological Processes Control:
MEGAPOLIS
Level of Technological Processes Control
Complex “Megapolis-TM” is used for the organization of dispatching of equipment status and of tech-nological processes of energy supply (gas, water, electricity, heat supply).
Complex performs functions of automated acquisition, processing and recording of measurement data on the parameters of operation of distant and local energy supply facilities, as well as remote control of technological equipment.
«Megapolis-TM» Telemechanics Complex
«Megapolis-TM» Complex Organization
• Multistage organization of dispatching with differentiation of access rights
• Support of all objects of gas industry dispatching: gas distribution stations, gas distribution points, gas distribution boxes, boiler plants, gas distribution units (commercial and household), motor transport objects, building infrastructure (data rooms).
• High reliability of Complex operation based on backup of primary sensors, controllers, communication equipment, communication channels and data acquisition servers
• Reliability and security of data transmission through encryption and VPN-tunneling • High augmentability of Complex (increasing of number of sensors and controllers) • Full compliance with regulatory requirements
Features of «Megapolis-TM» Telemechanics Complex
Data transfer level
Cellular networks GSM/3G, Wired networks, Satellite Local network / Internet
Heat supply objects Gas distribution
objects Electricity supplyobjects
Database server Data logging server GIS server
Infrastructure objects
Applications server
Water supply
objects Vehicleobjects Mobile dispatching client
MEGAPOLIS
«Megapolis-TM» Telemechanics Complex
The wide range of «Megapolis-ТМ» telemetric equipment consists of a full set of automation box mod-els for creating ICS for different objects, including:
• automation boxes with autonomous power supply (for objects without power supply) • automation boxes for outdoor installation (down to-40 °С)
• explosion proof automation boxes in Exd version (for installation in explosion risk zone)
The equipment of «Megapolis-TM» Complex consists of modern controllers, power supplies and com-munication equipment, with capability of functional extension.
All equipment of Complex, with the exception of the primary sensors, is supplied in the form of de-signed boxes with the possibility of additional equipping in accordance with the customer’s request.
Automatic box with power supply is provided with modern modular controllers with Ethernet, RS232/RS485 interfaces with wide possibilities of
expan-sion of IO channels:
• up to 64 analogue inputs
• up to 128 discreet inputs/outputs • up to 32 counter-impulse outputs • up to 64 analogue outputs
Communication equipment in installed in the Complex supports all modern
technolo-gies of package data transmission on the base of mobile communication: GSM-CSD / GPRS/
EDGE/3G, as well as VPN-tunnel technology for provision of safety virtual channel between distance ob-ject and dispatching room.
Automatic boxes with autonomous power supply are provided with power saving communication Gate-way MTM-KSH with possibility of data transmission by GSM and GPRS channel with support of sleeping mode and active session (feasibility of polling at any time).
The specific feature of mentioned above Gateway is the availability of subsystem of outer sensors power supply control and input/output modules.
The Gateway gives the possibility to perform data poll from any analogue sensors not adapted for low power consumption. Discreet channels of input-output of the gateway can be extended without limits by externalmodules on bus RS485.
The range of «Megapolis-TM» explosion-proof equip-ment of includes automatic boxes for the following kinds of usage:
• Gas distribution points without power supply (based on the communication gateway MTM-KSH)
• Gas distribution points with power supply without heat-ing (based on the modular controller with heater)
• Surveillance cameras (base on the Beward IP-cameras) • Gas consumption meters with power supply (based on the correctors’ power supplies)
«Megapolis-TM» Automation Boxes
MEGAPOLIS
«Megapolis-TM» Telemechanics Complex
Complex solution for automation of private and administrative buildings infrastructure consists of: • Energy resources metering (gas, water, heat, electricity)
• Power supply control (from the level of power distribution inlet automatic unit to the level of end-user) • Microclimate control (heating, air conditioning)
• Security control (access protection systems, fire extinction)
• Surveillance broadcasting from IP- cameras to mobile devices through Internet • Monitoring of IT-infrastructure (servers, data centers)
Innovative solution for remote monitoring and control of automatic breakers in power distribution inlet boxes gives the possibility:
• To control the current status of automatic switchers • To differentiate the cut-off reason (manual/emergency) • To control switchers position in remote control mode • To block remote control locally
Solution for monitoring of Diesel Generation Sets (DGS) in automation systems gives the possibility to perform planned maintenance and to implement the control of all parameters of set operation:
• Parameters of main supply net • Status of reserve switching device • Parameters of engine operation • Parameters of generator operation • Statistic parameters
• Parameters of power quality
«Megapolis-TM» building power supply control boxes are designed on the basis of modern and reliable components from «Schneider Electric». Automation controllers in boxes give the possibility to perform complex monitoring and control of power distribution at different levels: inlet units, distribution units, end-users. Automation boxes are easily integrated in existing building control system using standard pro-tocols (Modbus) upon RS485/TCP bus.
Special attention in automation of buildings is paid to the infrastructure of data-centers, where the servers operation provides the information support of business. The key points of monitoring are reliability of power supply and energy effectiveness on engineering sys-tems.
«Megapolis-TM» solution for monitoring of data centers infrastructure includes control of uninterruptible power supply (UPS) units operation and control of conditioning systems operation integrated with standard protocols.
TM-E1 model is universal solution for power supply control of distant objects of automation. TM-E1 model functionality allows to determine the reason of cut-off and to reactivate the power supply of the object without site visiting.
«Megapolis-TM» Mobile client features:
• Dynamic display of technological parameters at diagrams and plans
• Displaying of static and moving objects on GIS-substrate and satellite maps • On-time alarms and notification on off limit parameters
• Registration of emergency calls for working teams (in accordance with the specified form) • Visualization and analysis of archive (historic) data at diagrams and tables
• Forming of report on alarms, values of parameters, actions of users
In order to comply the enterprise security requirements, most of the functions do not require Inter-net connection for operation. All the functions are optimized for operation though slow connection: even when a large amount of data is displayed at diagrams and tables, the system operates without significant delays in response.
Full-functional SCADA-system in Mobile Client
«Megapolis-TM» Mobile client software performs the functions of full-operated SCADA-system as a light weight Internet application. Client is opened as a Web-page in any modern browser at unlimited number of working places (stationary and mobile). Mobile client does not require any special hardware resources or installation of additional software. License allows to enable the unlimited number of objects, parameters and OPC tags.
Mobile client connection to «Megapolis-TM» server reliably op-erates through encryption protected VPN-channel even on a slow speed mobile connection. It gives the possibility to perform on-time dispatching using tablets under site conditions with provision of security and total functionality of desktop version.
Updated version of «Megapolis-TM» Mobile client is developed upon most state-of-the-art technologies and is adapted for touch control on tablets and smartphones. Adaptive client interface adjusts to screen size of device for convenient work at any monitor, tablet or smartphone (Apple iOS, Android, Windows8).
Single SCADA application for every device platform
MEGAPOLIS
Starting with version 2.3 «Megapolis-TM» Mobile client has a certain number of unique GIS-func-tions to perform topological tasks in the diagrams of pipelines:
• Searching of cut-off or insulating units (valves, stopcocks) for unspecified object (gas distribution point, building, valve)
• Search for switched off customers as a result of the cut-off / failure on the pipeline • Emergency team vehicle route tracing to the destination point
Integration with «Megalopolis» Complex in-formation system provides all inin-formation of ob-jects and customers inside the Mobile client:
• Object passports and accounting information • Technical characteristics of the installed objects • Information on current and completed
applica-tions from customers
• Information about performed works and main-tenance
Deep integration of «Megapolis-TM» dispatching system with GIS-systems and «Megapolis» information system considerably increases the quality and content of information results thus allowing to make right dispatching decisions on time.
Emergency team has technical opportunity to check the location place of the shut-off equipment relative to the team position and to control SCADA objects using «Megapolis-TM» client at tablet. Integration with emergency calls subsystem gives the possibility to receive new calls and actual information about emergency situation directly at the site.
Integrated GIS in a mobile client
«Megapolis-TM. Virtual dispatching» application completes the mobile client with the possibility to control dispatching systems by voice and gestures. Application is based
on the innovative technologies of voice and gestures recognition from Microsoft and is adopted to oral Russian and English speech recognition. Gesture control allows the operator to control the system in front of the screen, without being attached to a desktop. Voice command control increases considerably the speed and convenience of initial data input for the situation analysis (customer address in emergency call, searching of SCADA object by its name or address).
Pronunciation of voice commands is clear at the level of intuition and does not need time for keyboard input.
As a result of voice command integration dispatching effectiveness, comfort of work and personnel study abilities increased considerably.
Voice and Gestures control for Dispatching Systems
MEGAPOLIS
MEGAPOLIS
Level of Technological Processes Control
«Megapolis» complex information system (CIS) provides storage of registration and passport data for all kinds of objects:
• Data about technical specifications, design and civil construction • Information about owners and maintenance organizations
• Passport data (technical characteristics) for objects
• Operation passports of pipelines, gas distribution points, gas distribution boxes, electrochemical protection units, shut-off accessories and equipment
• Information about maintenance of technological objects
• Objects connection with fixed assets, obtaining initial, current, residual value and accrued depre-ciation
• Object connection with geoinformation system (GIS)
• Forming of technological diagrams (schemes), route maps in coincidence with standard documen-tation requirements
MEGAPOLIS
Level of Technological Processes Control
«Megapolis» Complex information system integrates the functionality of geoinformation systems: • Connection of certificated objects with objects at GIS-maps and diagrams (schemes)
• Forming of technological diagrams and route maps in coincidence with standards requirements • Solving of topological tasks: simulation of switching off and on of locking (shut-off) equipment,
localization of failure areas and objects at GIS- schemes with report forming
Integration with Geoinformation Systems
Subsystem of Vehicle Supervision provides the recoding and registration of business operations of the transport service:
• Registration of enterprise vehicles, repairs and maintenance
• Registration of fuel consumption • Registration of accidents
• Registration of working hours of drivers • Data integration from Sattelite monitoring
systems
• Integration with «Megapolis-TM» Teleme-chanics Complex
MEGAPOLIS
Level of Enterprise Resource Management
Subsystem of billing for energy resources performs the following:
• Registration of billing for energy resources supplied by the enterprise (natural and liquefied gas, power supply, heat supply)
• Registration of in-building equipment, nets, regulation and distribution units, electrochemical pro-tection units and others
• Keeping of all necessary documentation in accordance with technical regulations standards require-ment
• Automatic generation of standard reports with possibility of sampling according to different criteria • Integration of data from hardware metering systems (telemetry)
Billing for Energy Resources
Document workflow for registration of technical maintenance and repairing of equipment is imple-mented in Complex. It includes the following functions:
• creation of annexes to the contracts with legal entities with work performance list
• reference of works to the objects of counterparties , making of acts about performed works • conducting of mutual settlements with counterparties with full integration with accounting • registration and monitoring of equipment installed at counterparties
• forming of reports in accordance with underlying accounting records
All underlying accounting documents have bar codes for automation of search and analysis during accessioning, returning the documents from counterparties and, handing over of documents between departments and services of the enterprise.
MEGAPOLIS
Level of Enterprise Resource Management
The subsystem is intended to work with customers for recording and registration of emergency calls. The subsystem includes registration of personal accounts of customers, contracts, correspondence, his-tory of equipment changes, metering data.
Subsystem also implements planning of maintenance, performance of charge service, registration of customers payments, including those using a barcode scanner.
Flexible configuration of tariffs, which depend on category, brand, country of origin and equipment lifetime, as well as on unlimited number of optional parameters, is also implemented in the subsystem.
Receiving of Emergency Calls
Subsystem allows to automate the activity of the following departments: emergency-dispatching ser-vice, in-house nets serSubsystem allows to automate the activity of the following departments: emergency-dispatching ser-vice, underground metal protection service and customers service department.
Complex Information System
MEGAPOLIS
Diplomas and awards of «Megapolis» Complex information system
Diplomas and awards of «Megapolis-TM» telemetry complex
Certificates and a «Megapolis-TM» Telemechanics Complex
RosGazExpo-2011 diploma “Best solution for municipal energetics”
RosGazExpo-2008 diploma
“Automation facilities” “Best innovative solution in energetics”RosGazExpo-2011 diploma
RosGazExpo-2014 diploma “Best reginal project in gas distribution”
RosGazExpo-2014 diploma “Huge contribu-tion to city infrastructure development and
energetic safety rising” RosGazExpo-2012 diploma
