BARCODE TICKET SOLUTION RF CARD SOLUTION MAGNETIC TICKET SOLUTION

(1)

BARCODE TICKET SOLUTION

RF CARD SOLUTION

MAGNETIC TICKET SOLUTION

(2)

RF card application

RF Card Dispenser / Encoder

SRD-2400

• Card supported : ISO 14443A, Mifare,

ISO 15693 I.CODE SLI, Ultra Light • Hopper capacity : 400 cards loaded

• Power On / Off switch

• Dispenser ID settable up to 99 • With RTC (Real Time Clock)

• Button port, LED status, Relay signal output • Interface : RS-232

• Error card bin : Up to 20 cards • Power : DC 24V, 2.5A

• Dimensions(㎜) : 132(W) × 235(D) × 430(H)

Motorized RF Card Reader / Writer

SRW-1200

• Card supported : ISO 14443A, Mifare, ISO15693, Ultralight • Interface : RS-232

• Power : DC 24V, 2.5A

• Dimensions(㎜) : 115(W) × 153(D) × 105(H)

• Card supported : ISO 14443A, Mifare, UltraLight, ISO 15693 • 16 Keys, Touch Key

• Power On / Off switch • Power : DC 24V, 3.5A

• Interface : USB [Option : Ethernet]

• Applications : RF card encoding, Visit verification, Discount encoding

• Dimensions(㎜) : 100(W)× 114(D) × 95(H)

RF Card Reader / Writer

SRF-3100

ISO15693 I.CODE SLI, UltraLight • With Buzzer & LED (2 colors)

• Windows2000, XP, Vista, Win7 supported • Power source : from USB

• Cable : 1.8M long • Interface : USB • Dimensions(㎜) : 48(W) × 90(L) × 12(H)mm  SRW-1200  SDP-3500  SRF-3100  SRD-2400

SDP-3500

STAMPER

Barcode ticket application

Fan-fold Type Ticket Issuing Unit

TIU-3100

• Thermal printing

• Cutting position adjustable

• Logo / Messages downloadable for advertisement • Error ticket capture (drop below)

• Ticket size : 54 × 86mm • Interface : RS-232

• Barcode type : EAN128, Interleaved 2 of 5 • Power : DC 24V, 3A

• Dimensions(㎜) : 140(W) × 351(D) × 111(H)

Motorized Barcode Ticket Scanner

BTS-2100

• Ticket scanned / captured (dropped back) • Interface : RS-232

• Power : DC 24V, 3.5A

• Dimensions(㎜) :111(W) × 150(D) × 167(H)

Motorized Barcode Ticket Scanner / Printer

TSP-3200

• With ticket standby mode

• Discount tickets scanned / captured • Payment / time printable

• Ticket size : 54 × 86mm • Interface : RS-232 • Power : DC 24V, 3.5A

• Dimensions(㎜) : 140(W) × 218(D) × 167(H)

SDP-3400

• Printer ID to be saved • Store, Office ID settable • Discount time / Money settable • Ticket stamping • Interface : USB [Option : Ethernet]

• Barcode type : EAN128, EAN13, Interleaved 2 of 5, Code 93, Code 128B, Code 128A, Code 39

• Ticket size: 54 × 86mm

• Power : DC 24V, 3.5A, On / Off switch • Dimensions(㎜) : 100(W) × 114(D) × 95(H)  TIU-3100  TSP-3200  BTS-2100  SDP-3400

(3)

C A R P A R K M A N A G E M E N T S Y S T E M

|

• As its reading distance is up to 6 meters, it provides Non-stop pass • As it is passive type (no battery), it may work UNLIMITTED. • It’s easy to insert and pull out card from card holder. • It provides high security.

Long Range RF Card Reader

|

SRF-3900

Long Range RF Card

|

SRF-3900

• Printer ID to be saved • Store, Office ID settable • Discount time / money settable • Ticket stamping

SPECIFICATION Ticket size 54 × 86mm

Power DC 24V, 3.5A Interface USB * Option : Ethernet On / Off switch Dimensions(㎜) 100(W) × 114(D) × 95(H)

Barcode type EAN128, EAN13, Interleaved 2 of 5, Code 93, Code 128B, _{Code 128A, Code 39} SPECIFICATION

Frequency UHF Band, 917~923.5MHz

Network

Port Serial I/O

(9.6Jbos~115.2Kbps) Type Micro patch array _(embedded) Interface RS-232, RS-485 _{* Option}_{: TCP /IP} Gain +4.5dBi Power DC 24V / 24W Polarization Circular polarization Operating temperature -30℃ ~ 70℃

3dB Beam 20°(E-plance) Size 235 × 225 × 55mm

Channel 16CH Weight 1Kg

Output Less than 30dBM (1Watt) Reading range 0.3~6 meter (Tag dependent) Modulation Frequency Hopping _{Spread Spectrum (FHSS)} Other Controller Relay output, Anti-passback

Memory size Approx. 11,000 cards

SPECIFICATION

Frequency UHF band, 915~923.5MHz Type _{( Beam powered)}Passive Modulation element High speed switching diode Speed 256kbbs

Operating

temperature -40℃ ~ +85℃ Card holder material ABS Memory Read only type_{Factory programmed 64 bit ID number}

Dimensions(mm) 86(W) × 55(D) × 3(H)

Antenna

|

SDP-3400

STAMPER

Barcode ticket system-

Entry

Barcode Ticket Dispenser

|

SBM-2100

• Fan-fold type ticket (54 × 86cm) • Cutting position adjustable

• Data logged & uploaded when com. is connected • Logo / Message (Advertisements) downloadable • Voice Guide

SPECIFICATION

Ticket loading 5,000 tickets / box Power AC110~220V±10% Operation temperature -20℃ ~ +50℃(heater inside) Humidity 10~90%RH

Printing Thermal printing Weight 45kg

Interface RS-232 / 485 (Networkable) and / or Stand-alone Ticket issuing mode Manual , Semi-auto, Auto mode selectable

Dimensions(㎜) 300(W) × 490(D) × 1200(H), base included

Ticket Issuer

|

TIU-3300

• Parking ticket issuing • Fan-fold barcode ticket

• For desk-top use

• With button for ticket issuing

|

TPD-3500

Ticket Producer

• Discount tickets, ID tickets producing • For desk-top use

• Fan-fold barcode ticket

SPECIFICATION

Interface RS-232 Power DC 24V, 3.5A

Dimensions(㎜) 190(W) × 370(D) × 270(H)

SPECIFICATION

Interface RS-232 Power DC 24V, 3.5A

(4)

Gate Barrier

|

SGB-5000

• Gate barrier for car access & parking control • BLDC motor / Steel body

• In case of power out, able to operate by handle bar SPECIFICATION

Bar speed Less than 1.5 sec(Open), 2.0 sec(Close) Bar material Aluminum (red, white reflective taping)

Bar type Rectangular Bar length 3 meters, 4 meters

Operation temperature -10℃ ~ +40℃ (-20℃ under heater) Humidity 10% ~ 95% (Non condensing)

Power AC110 ~ 220V ±10%, 50/60Hz Power consumption Standby 30W, Operation : 90W

Weight 40 Kg

Dimensions(㎜) 300(W) × 300(D) × 1000(H)

Option Remote control receiver & transmitter

Barcode Ticket Validator

|

SVM-2310

• Parking ticket scanned & on standby mode • Parking discount ticket scanned / captured • With voice and LCD text guides

Barcode Ticket Verifier

|

SVM-2320

• Parking discount ticket scanned / captured • With voice and LCD text guides

SVM-2310 / SVM-2320

Intercom Built-in

Interface RS-232 / 485

Ticket capture tray up to 3K tickets

Power AC 110 ~ 220V, 60MHz

Dimensions(㎜) 300(W) × 490(D)) × 1250(H)

CAR PARK MANAGEMENT SYSTEM

Barcode ticket system-

Exit Lane

|

TVM-3600

Ticket Verifier

• Barcode ticket scan / print

• With power adapter • With power On / Off switch

SPECIFICATION

Ticket size 54 × 86mm Interface RS-232

Dimensions(㎜) 190(W) × 370(D) × 270(H) Power DC 24V, 3.5A

|

BTS-1200

Barcode Ticket Scanner

SPECIFICATION Interface RS-232 Dimensions(㎜) 100(W) × 95(D) × 215(H)

|

P-301

Fee Display

SPECIFICATION Type LED Display (3 colors LED)

Interface RS-232 * Option : RS-422, RS-485 Display 2 Lines Display

Power AC 110 ~ 220V, 60Hz

Exit Entry Dispenser Program & Server Producer Fee Display Gate Barrier

(5)

C A R P A R K M A N A G E M E N T S Y S T E M

|

RF Card Producer

|

SRD-2510

• Card supported : ISO14443A, Mifare, ISO15693 ICODE SLI, Ultra Light • With power adapter • With error card tray

• With card collecting tray

SPECIFICATION

Interface RS-232

Power DC 24V, 2.5A

Hopper capacity 130 cards On / Off switch

Dimensions(㎜) 180(W) × 250(D) × 250(H)

RF Card Validator

|

SVM-2710

• With parking card standby mode

• Parking / discount cards verified / cancelled / captured • With voice and LCD text guides

RF Card Verifier

|

SVM-2720

• Without card standby mode

• Parking card verified / cancelled / captured • With voice and LCD text guides

SVM-2710 / SVM-2720

Intercom Built-in

Interface RS-232 / 485

Card capture tray up to 1K cards

Power AC 110 ~ 220V, 50/60MHz

Dimensions(㎜) 300(W)× 490(D) × 1250(H)

• Card supported : ISO 14443A, Mifare, UltraLight, ISO 15693 • 16 Keys, Touch Key

SPECIFICATION Interface USB * Option : Ethernet

Power DC 24V, 3.5A Dimensions(㎜) 100(W)×114(D)×94.72(H) On / Off switch

Applications RF card encoding, Visit verification, Discount encoding

|

SDP-3500

STAMPER

RF card system

RF Parking Card Dispenser

SRD-7400

|

SRD-7800

RF Card Dispenser

|

SRD-2500

• Card supported : ISO14443A, Mifare, ISO15693 ICODE SLI, Ultra Light • With power adapter • With error card tray

RF Card Reader / Writer

|

SRF-3110

ISO15693 I.CODE SLI, UltraLight • With Buzzer & LED ( 2 colors)

• Windows2000, XP, Vista, Win7 supported • Power source : from USB

• Cable : 1.8M long • Interface : USB

• Dimensions(㎜) : 48(W) × 90(L) × 12(H)mm

ENTRY EQUIPMENT

EXIT BOOTH EQUIPMENT

SPECIFICATION

Interface RS-232

Power DC 24V, 2.5A

Hopper capacity 130 cards On / Off switch

Dimensions(㎜) 180(W) × 250(D) × 250(H)

SRD-7400 SRD-7800

Feature

Personalized RF card compatible With card low & Empty signals

With built-in cooling fan

Gate ID : settable up to 99 _{With 2 dispensers built-in}With main controller

Loop detector & Voice guide × ◯

Hopper capacity 400 cards loaded 800 cards(400+400)

Interface RS-232

Waterproof Waterproofed, IP65

Option Built-in camera

Dimensions(㎜) 220(W)×360(D)×1484(H) 329(W)×350(D)×1482(H) SRD-7400 | SRD-7800

(6)

• Host computer & software program (Sever)

• This equipment & software program is installed in the office of supervisor

• Able to monitor all operations of parking lot

• Able to collect data / information from each PC in booth

• Able to manage information (Name ID, Duration) on regular visitors operations, data of car park and parking system

• Able to register, delete, monitor and manage regular visitors’ ID card • Able to monitor daily, weekly, monthly parking fee collected

and monitor no of car in / out

• Able to monitor all information necessary to control parking lot • DB : MS SQL 2008 R2 Standard , Enterprise

• DB : Oracle

Long Range RF Parking Card Control/Management Software Program

“ PASS Monthly”

• Monthly users management • Monthly parking fee

• Report printable

• DB : M DB, SQL • For paying park lot use

• Apartment / Community users registration / Delete • For registered vehicles control only

• No parking fee / cost concerned • DB : M DB, SQL

{

Network PMS

Long Range RF Parking Card Control/Management Software Program

“ PASS Free”

{

SOFTWARE - PROGRAM

• Parking Management Software • Regular visitor registration / deletion • Parking fee collection & clearance

• Daily, monthly, annual data search and management • Networkable

• Report

• Able to check No. of car In / Out

• Able to issue operator’s ID (Employee’s ID) • Able to control gate barriers

• Networked to open gate barrier when the receipt is printed

• Able to have “one of time, fee or % discounts” configured by software program

• Details of parking lot owner can be set • Booth operators’ (employees) revenue

collection can be printed(Car In/Out, Amount of fee collected)

• DB : M DB

• Parking lot status can be monitored

|

SRC-2100

❶ PC : Windows 7 ❷ 17” LCD Monitor ❸ With multi port embedded (RS-232) ❹ Thermal receipt printer ❺ Barcode scanner ❻ Cash drawer

❼ Fee display

SRC-2100

COMPOSITION

Pay Exit PMS

(7)
