the transformations that are possible!
Imagine
Vinyl Replacement Windows
The possibilities of designing your home with a perfect view are endless.
Combine that with the perfect balance between form and function with
classic beauty... and you describe Integra vinyl windows by ProVia.
From casement and double hung to slider, picture, bays, bows, and
Architectural shapes, you get the finest choice of energy-efficient
products for years into the future.
Your home reflects your personal style as you select from many color
finishes and options that make every Integra window a classic beauty.
Take time today to imagine.
We feature the ComforTech
™Warm Edge Glazing System on all
Integra
®Vinyl Replacement Windows
Lifetime
Limited
Warranty
Includes Glass Breakage & Seal
Clear Glass High Performance Low-E Argon Gas Super Spacer®
Comfortech™ DLA
R-Value of 4Insulated Glass Options:
Comfortech™ DC
Clear Glass Air Super Spacer® R-Value of 2 Clear Glass High Performance Low-E Argon Gas Super Spacer®Not available with internal grids
Comfortech™ TLA
R-Value of 6 Clear Glass High Performance Low-E Krypton Gas Super Spacer®Not available with internal grids
Comfortech™ TLK
R-Value of 9
* SHGC = Solar Heat Gain Coefficient.
** DWT - Damage Weighted Transmittance, is calculated according to a function called Tdw-ISO, developed by the International Standards Organization (ISO) and published by the International Commission on Illumination (CIE), the world’s leading technical organization on lighting and illumination. The Tdw-ISO calculation measures fading risk from solar radiation across the entire solar light spectrum, from Ultra-Violet light (280-380 nanometers) through visible light (390-780 nanometers). According to the CIE standard, which is considered more comprehensive than Ultra-Violet rating alone, our UV glass packages can minimize fading damage across the entire solar spectrum more effectively than glassdesigned primarily to block Ultra-Violet light.
- All calculations based on 7⁄8" thick, double glazed, single
strength IG units using NFRC methodology with Lawrence Berkeley National Laboratory’s Windows 5.2 software.
Cooler in Summer & Warmer in Winter:
SHGC* for DLA-UV is 66% better than clear glass and 30% better than DLA.
Increased fade Protection:
DWT** for DLA-UV is 43% better than clear glass and 23% better than DLA.
Also available with
increased UV protection!
Glass
ComforTech
™Warm Edge Glazing
System featuring Super Spacer
®offers you reduced heat loss,
warmer glass temperature and
reduced interior condensation.
The NO-Metal
Advantage:
“Thermal efficiency through no presence of conductive metals” is the Super Spacer® hallmark.Mylar 10-Layer
Vapor Barrier:
The Super Spacer® thermoset foam matrix is exceptional. Moisture is kept out, gas is kept in and conductivity is virtually nonexistent.
Lasting
Appearance:
The design of our Warm Edge Glazing System stands up to the bending and bowing that is natural in any glass unit.Meet your needs with style
Double Hung Windows Standard Features:
•
Sunshield® Vinyl • 3¼" Frame Depth• Aluminum Reinforced Sash
• Welded Frame and Sash Construction • ComforTech™ Warm Edge Glazing System • Extruded Sloped Sill
• 7⁄8" Insulating Glass • Exterior Glazing
• Ergonomically Designed Tilt Latches • 2 Ventilation Limit Latches
• Color-Matched Balance Covers • Locking Pivot Bars
• Dual Sweep Locks at 31" and Wider
• Roll-Formed Aluminum Half Screen with BetterVue™ Mesh
All Double Hung windows come with Ventilation Limit Latches that allow you to leave the window open without sacrificing security.
300 Series Double Hung
Additional Standard Features:
•
The cove sash profile offers a traditional look that adds elegance to the sash• ComforTech™ DLA High Performance Low-E Argon Glass
• Sculptured lock is a low profile design with an adjustable keeper for a perfect seal and a classic look
• Low profile tilt latches
• Compound Tension™ Balance System, the new generation of block and tackle, for ease of use
• Deluxe Double Vent Lock looks like a conventional vent latch but performs as a lock. It securely withstands impact by incorporating a tough polycarbonate, tongue-and-groove design
200 Series Double Hung
Additional Standard Features:
• Square Sash Profile
• ComforTech™ DC Clear Glass • Compound Tension™ Balance System
200 Series
Square Sash Profile Ventilation Limit Latch Contemporary Sweep Lock with Adjustable Keeper
300 Series
Balance Covers in top sash Compression Foam Seal on bottom sash Cove Sash ProfileDeluxe Vent Lock Low Profile Tilt Latch Sculptured Sweep Lock with Adjustable Keeper
Additional configurations available. See Price List for details.
Double Hung
When you need to combine timeless beauty with everyday practicality, the classic Integra double hung window is a perfect choice. Every window we make is energy efficient, versatile and easy to use.
Our durable, custom-designed vinyl double hung windows contain upper and lower sashes that both open and tilt in for easy cleaning and our frame and sash profiles are constructed from durable, maintenance-free vinyl.
All Slider Windows Include the Following
Standard Features:
• Sunshield® Vinyl
• Welded Frame and Sash Construction • 3¼" Frame Depth
• ComforTech™ Warm Edge Glazing System • Aluminum Reinforced Sash
• 7⁄8" Insulating Glass • Exterior Glazing • Brass Rollers
• Dual Sweep Locks at 31" and Taller • Ergonomically Designed Tilt Latch • Single Ventilation Limit Latch
• Roll-Formed Aluminum Screen with BetterVue™ Fiberglass Mesh
300 Series Sliders
Additional Standard Features:
• The cove sash profile offers a traditional look that adds elegance to the sash • ComforTech™ DLA High Performance
Low-E Argon Glass
• Sculptured lock is a low profile design with an adjustable keeper for a perfect seal and a classic look
• Deluxe Vent Lock looks like a conventional vent latch but performs as a lock. It securely withstands impact by incorporating a tough polycarbonate tongue-and-groove design
200 Series Sliders
Additional Standard Features:
• Square Sash Profile
• ComforTech™ DC Clear Glass
Additional configurations available. See Price List for details.
Sliders
Cove Sash
Profile Deluxe Vent Lock Low Profile Sculptured Sweep Lock
300 Series
200 Series
Contemporary Sweep Lock with Adjustable Keeper Square Sash Profile Ventilation Limit LatchIntegra sliding windows maximize the beauty of your interiors while providing stunning visual connection to the outdoors and ventilation. Our horizontal slider window will complement virtually any home style, from contemporary to traditional with effortless cleaning and maintenance, while providing superior energy efficiency.
Additional shapes available. See Price List for details.
All Architectural Shapes Include
the Following Standard Features:
• Sunshield® Vinyl
• Fully Welded Construction • 3¼" Frame Depth
• ComforTech™ DC Warm Edge Glazing System
• 7⁄8" Insulating Glass • Interior Glazing • Wide Range of Shapes
Available Options:
• Internal Grids • Woodgrain Interior • ComforTech™ DLA High
Performance Low-E Argon Glass • See Price List for a Complete
Range of Shapes and Optional Grid Patterns
Architectural Shapes
Create a unique look to your home with Integra architectural windows while adding personality & drama to any living space. Our architectural window products are available in many color combinations of interior and exterior treatments, woodgrains, window grid patterns, and window glass options to further personalize your home.
Dramatic accents add endless style
Bay and Bow windows are constructed
using your choice of picture, double hungs,
or casements. Choose the combination
that will deliver exactly what your
application requires.
Bay
&
Bow
All Bay & Bow Windows Include
the Following Standard Features:
•
Two Operable Units with Screens• Head, Jamb and Seat Boards are Constructed with 1¼" Oak Veneer Plywood
• Installation Knee Braces and Cable Support System
Available Options:
•
Prefinished Head and Seat Board available in Light Oak, Dark Oak, Cherry, White Pionite or Beige Pionite• Insulated Seat Board • Decorative Knee Braces • Roof Kits
All Picture Windows Include the
Following Standard Features:
• Sunshield® Vinyl• Fully Welded Construction • 3¼" Frame Depth
• ComforTech™ DC Warm Edge Glazing System • 7⁄8" Insulating Glass • Direct Glazed Frame • Interior Glazing
Additional configurations available. See Price List for details.
Beauty, style & elegance describe Integra’s picture windows. Enjoy a full view of the outdoors through a single, unobstructed unit or combine it with operating units along the sides for both ventilation and a wide view.
A picture window provides a
large, unobstructed view.
Our Casement windows include a “washability hinge” designed to completely offset the window frame when fully open. Cleaning the outside is easy!
All Casement & Awning Windows Include the
Following Standard Features:
• Sunshield® Vinyl
• Welded Frame and Sash Construction • 3¼" Frame Depth
• ComforTech™ DC Warm Edge Glazing System • Aluminum Reinforced Sash and Frame • 7⁄8" Insulating Glass
• Fold-Away Handle • Exterior Glazing
• Multi-Point Locking Hardware System • Washability Hinge (Casement only)
• Quick-release dual-arm operator (Awning only)
• Extruded Aluminum Screen with Better Vue™ Fiberglass Mesh
Additional configurations available. See Price List for details.
Casement
&
Awning
When your room needs something different
Casement and Awning windows can give you the look you want with the ventilation options you need.
The Integra awning window is hinged at the top to let fresh air in and keep rain out. Our sturdy awning window products make adjusting to changing seasons simple and elegant.
Unique Multi-point locking system for a tighter seal and added security
Garden
All Garden Windows Include the
Following Standard Features:
•
Fully Welded Construction• Completely Assembled with 1¼" Oak Veneer Seat Board
• ComforTech™ DC Warm Edge Glazing System
• Top Sloped Insulating Glass is Tempered • Snap-in Corner Slope Closure Profile
Seals Tight
• Twin Sealing, Fully Screened Operating Casements with Exterior Glazing • Easy Access Dual-Point Locking Operator • Fold-Away Handle
Available Options:
• ComforTech™ DLA High Performance Low-E Argon Glass
• Seat Board also available in Birch Veneer, White or Beige Pionite (Pionite resists water damage)
• Insulated Seat Board
• Custom Jamb Depths Available • Tempered Glass Shelves
To see all our styles and color palettes, ask for our Inspirations Art Glass brochure.
A ProVia Door Exclusive
Designs:
The process begins with conceptual design. Our eight beautiful Inspirations Art Glass styles originated from the imagination of our in-house designers.
Resin Bead:
The design pattern is created on our computer software, and sent to a CNC machine which applies a resin bead to the surface of the glass in one of our four stylish colors.
Color Fill:
The color fill truly brings the glass to life. Five distinct color palettes are offered empowering you to perfectly reflect the personality of you and your home. Our craftsmen hand-apply this color fill to your glass.
Our Guarantee:
The resin bead and color fill are backed by our Lifetime Limited Warranty, and will not fade, blister or peel away from the glass.
A colorful way to personalize
your windows
Inspirations™ Art Glass allows you to do just what the name
suggests, let your doors and windows reflect the inspiration of your
imagination with your choice of design and color.
Available on:
Standard
Features
• Lifetime Limited Warranty
• Sunshield® Vinyl - a look that lasts a lifetime • Night Ventilating Latches limit sash travel • Interlocking pivot bar system
• Double hung sashes tilt in, slider sashes lift out • Casement sashes open a full 90°
• A well designed balance system • Sleek, narrow frame lines • Barrier-fin type weatherstripping
• 7⁄8" insulating glass with ComforTech™ warm edge technology
• Dual sweep locks on double hungs over 31" wide • Aluminum reinforced sashes
• Dual durometer glazing • Sloping sill
• Aluminum screen frame
• Fiberglass BetterVue™ screen mesh
Euro White
Beige
Light Oak
Dark Oak
Cherry
Windows are available in White, Beige or Woodgrain interior with White or Beige exterior.
All Integra window products are
professionally crafted and provide
excellent quality & performance.
Integra windows offer homeowners a
wide range of options and are backed
by an outstanding warranty.
Colonial Prairie Cottage
Available on all window styles. (Diamond Grids not shown.) See price list for more information.
Grid Patterns
• 2½" Modern • 2½" Colonial • 3½" Colonial
Add the finishing touch with oak or
poplar casing
Casing
Woodgrain Option Available in
the Following Models:
•
Double Hung - 301 Model • Slider - 302, 303, 304 Model • Casement• Picture - 309 Model
Adds style and warmth to any window
Consider a woodgrain finish in Light Oak, Dark Oak or Cherry. You get the benefits of vinyl windows with the elegant look of wood.
• Garden (Light Oak/White only) • Bay - 300 Series
• Bow - 300 Series • Architectural Shapes
Woodgrain windows come standard with coppertone hardware
Woodgrain Option
Polished B
rass
Pencil G
rids
Painted
Brass
Woodgrain
Grid Options
Additional Options:
• ComforTech™ DLA-UV, TLA-UV and TLK-UV Warm Edge Glazing Systems (see “glass” page)
• Heavy-duty Fiberglass Screen Mesh • Double Strength Glass
• Tempered Glass • Interior Stop • Insulation Options:
- Double Hung - Insulated Frame & Vertical Sash Rail
- Slider - Insulated Frame & Vertical Sash Rails
- Picture - Insulated Frame
- Insulation N/A For Casements & Awnings
• Perimeter Insulation Wrap • Aluminum Screen Mesh • Full Screen
• Factory Mulling
• Factory Installed Nail Fins • Obscure (Bathroom) Glass • Gluechip Glass
Options
Extras that add value & style
Everyone’s needs are unique. That’s why we offer ways to customize our windows to be perfect for each applicationVinyl Replacement Windows
