Innovative solutions for fine grained materials

002 Fluidization technology

50 years of technology evolution

Alumina CFB calciner, Worsley Alumina, Australia.

Lurgi constructed the first reactor for roasting of sulfur bearing materials in 1950, based on the principles of fluidized bed technology. The new system was quickly adopted by industry; multiple hearth furnaces and rotary kilns were increasingly replaced by fluidized bed roasters, thereby ensuring enhanced product quality and significantly reduced plant emissions. Fluidized bed combined with efficient heat recovery and offgas treatment, including the process of converting the offgas to sulfuric acid, became state-of-the-art technology for processing sulfur bearing ores. We have delivered more than 260 plants to date.

Significant process improvements have been achieved by using fluidization technology, for example in the production of alumina. The circulating fluidized bed (CFB) was developed over 40 years ago for the high temperature treatment of fine and light particles. A whole variety of other CFB applications followed, with more than 170 industrial plants worldwide. The CFB has been successfully applied for coal combustion, roasting of gold containing ores, direct reduction of iron ore fines and other uses. In the early 1990s we introduced a new variation of fluidization technology, the annular fluidized bed (AFB).

Early FB pyrite roasting plant, BASF, Germany.

For over 50 years Outotec has developed and commercialized fluidized bed technology for a variety of industrial applications.

With the aquisition of Lurgi Metallurgie in 2001, Lurgi's fluidization know-how was transferred to Outotec. The development of fluidized bed technology continues and we are working on new processes utilizing solid mixtures, such as ore and coal, with different properties for industrial application.

Fluidized bed types

The classical bubbling fluidized bed is operated at relatively low gas velocities with the particles kept in balance against their own gravity. Most of the particles do not leave the surface of the fluidized bed, typically characterized by a defined surface between gas and solids. The surface may show a behavior similar to a boiling liquid, depending on size and density of the particles. From the mixing point of view, the FB is a continuously stirred tank reactor with a defined solids residence time distribution. The mean solid velocity is close to zero with the slip velocity almost identical to the gas velocity.

Circulating fluidized bed (CFB) At higher gas velocities the slip velocity increases and the fluidized bed changes its behavior. The defined boiling surface disappears with the expansion of the fluidized solids. The fluidization gas has enough energy to entrain solids particles. The entrained particles are separated from the gas by a cyclone and recirculated via an external loop back into the fluidized bed reactor. In addition an internal recirculation of the solids in the fluidized bed reactor takes place. Both internal and external circulation results in a homogenous temperature distribution in the CFB system.

Transport or flash reactor (FR) With further increase of the gas velocity, the solids are approaching the velocity of the gas. In the flash (transport) reactor the slip velocity between gas and solids is considerably decreased compared to the circulating fluidized bed. At the same time the advantages of homogeneous temperature distribution and ideal heat and mass transfer are decreased. This type of reactor is used in selected applications where low gas and solid retention times are sufficient.

Annular fluidized bed (AFB®₎

This new type of fluidized bed improves the introduction and mixing of hot dust laden process gases. These gases enter the reactor through a large central nozzle, with additional fluidization gas introduced through an annular nozzle ring. As a result, a very intense mixing zone is achieved within the reactor above the central nozzle, comparable to the conditions achieved by an external loop of a CFB. Further advantages are excellent process control and improved mass transfer conditions.

The AFB can be combined with any other fluidized bed type.

Bubbling fluidized bed

Increasing solids density Increasing expansion Gas "Slip velocity" Solids Ve locity

Transport reactor

Circulating fluidized bed

004 Fluidization technology

Bubbling fluidized bed

01 1950 First pyrite roaster, BASF, Germany, 40 tpd 02 1956 First zinc roaster, Nikon Kogyo, Japan, 40 tpd

03 1958 Sulfate decomposition roaster, Imperial Smelting, UK, 140 tpd 04 1962 First sulfating roaster for copper ores, Chambishi, Zambia, 118 tpd 05 1965 Hydrogen based reduction plant for NiO, Inco, Canada, 150 tpd

06 1965 First single-stage dearsenifying pyrite roaster, Boliden, Sweden, 350 tpd 07 1968 First double-stage dearsenifying pyrite roaster, Bayer, Germany, 450 tpd 08 1969 First slurry feed to pyrite roaster, Gold Fields, South Africa, 2 x 125 tpd 09 1971 First partial roaster for copper ore, Noranda, Canada, 900 tpd

10 1973 First 123 m2 _{zinc roaster, Pasminco, Australia, 800 tpd}

11 1994 Largest coarse pyrite roaster, Wengfu, China, 2 x 1,200 tpd 12 1996 Circored direct reduction plant, CAL, Trinidad, 1,500 tpd 13 1999 Largest zinc roaster, Asturiana de Zinc SA, Spain, 1,000 tpd 14 2004 Largest pyrite concentrate roaster, Tongling, China, 1,130 tpd

15 2005 Ni chloride pyrohydrolysis roaster, Goro Nickel, New Caledonia, 3 x 380 tpd Circulating fluidized bed

16 1959 First laboratory CFB plant at Metallgesellschaft, Germany, 0.5 tpd

17 1961 First pilot plant for alumina calcination, VAW Lünen, Germany, 24 tpd

18 1968 First industrial alumina calciner, VAW Lünen, Germany, 500 tpd

19 1973 First laboratory tests for iron ore reduction using CFB technology, R&D Center, Germany

20 1979 Significant capacity increase of alumina calciners, Interalumina, Venezuela, 3 x 1,400 tpd

21 1982 First coal combustion plant, VAW Lünen, Germany, 84 MW

22 1987 First gold ore roasting plant, KCGM, Australia, 575 tpd

23 1990 First alumina calciner with hydrate bypass, Worsley Alumina, Australia, 1,850 tpd

24 1991 Circodust demonstration plant, Thyssen, Germany, 120 tpd

25 1992 Largest roaster for gold ore, Newmont, USA, 2 x 3,800 tpd

26 1993 Largest CFB (11.5 x 14.7 m) based power plant, Soprolif, France, 650 MW

27 1996 Circored direct reduction plant, CAL, Trinidad, 1,500 tpd

28 2001 Oxidizing ilmenite roaster, Iscor, South Africa, 1,000 tpd

29 2002 Ore preheater, HIsmelt Corporation, Australia, 4,000 tpd

30 2003 Significant capacity increase of alumina calciners, Alunorte, Brazil, 2 x 3,300 tpd

31 2005 Reducing ilmenite roaster, Kenmare Resources plc, Mozambique, 1,200 tpd

32 2005 First preassembled module supply of alumina calciners, Alcan Gove, Australia, 2 x 3,500 tpd Flash reactor

33 1985 Flash reactor for high temperature alumina production, VAW Schwandorf, Germany, 250 tpd 34 1993 Flash reactor for ilmenite preheating, Namakwa Sands, South Africa, 625 tpd

35 1996 Circored direct reduction plant, CAL, Trinidad, 1,500 tpd Annular fluidized bed

36 1992 Waste heat boiler pilot plant, 1 tpd

37 1996 Circored direct reduction plant, CAL, Trinidad, 1,500 tpd

38 2002 Ore preheater, HIsmelt Corporation, Australia, 4,000 tpd

39 2005 Reducing ilmenite roaster, Kenmare Resources plc, Mozambique, 1,200 tpd Development in the Lurgi and Outotec companies, indicating the year of order.

References

Bubbling fluidized bed

n Zinc roasters 74

n Pyrite, copper, gold, nickel

concentrate roasters 190 Total 264

Circulating fluidized bed

n Alumina calcining plants 51

n Power plants* 82

n Gold ore roasting plants 5

n Sulphur adsorption 16

n Calcining of clay/lime 3

n Fluorine adsorption 10

n Coal based reduction (Elred) 1

n Gas based reduction (Circored) 1

n Ore preheating (Circoheat) 1

n Circodust (demonstration plant) 1

n AlF3 synthesis (demonstration) 1 Total 172

Flash reactors

n Ilmenite preheating 2

n Circored, Trinidad 1 Total 3

Annular fluidized bed

n Boiler pilot plant 1

n Circored, Trinidad 1

n Circoheat, Kwinana 1

n Ilmenite roaster, Mozambique 1 Total 4

Numbers refer to the development stages of the list of milestones.

006 More out of ore!

006 Fluidization technology

Fundamentals

Fluidization systems are ideal for the treatment of fine grained materials. For processing ultra fine materials, Outotec has developed and patented a microgranulation process. The treatment of oversized material has to be evaluated depending on its behavior during processing.

Fluidized bed phase diagram

The so-called Reh* diagram illustrates the different phase behavior of gas-solids interactions. The yellow region represents the fixed bed operating domain. The blue region indicates the domain of the bubbling fluidized bed where gravity and drag forces on the particles are in balance. The grey section represents the pneumatic transport domain. The orange triangular region represents the area of the circulating fluidized bed. As the diagram is calculated for ideal spherical homogeneous particles it provides an indication only. However, coupled with experience from industrial plants the CFB operating range can be extended to area a of the diagram. This knowledge gained from operational experience is applied to the design of new plants and processes.

Flexibility in feed particle size

* Diagram developed by Prof. Dr.-Ing. Lothar Reh

Particle Reynolds Number

P ar tic le F ro ud e Num be r f [v ² , dP ] ReP G

Important design criteria

n Decrepitation behaviour

n Retention time

n Process temperature

n Process energy requirement

n Production rate

AFB of ilmenite roaster,

Kenmare Resources plc, Mozambique.

Application in exothermic and endothermic processes Chemical reactions occurring between the solid particles and the fluidization gas can either be endothermic or exothermic. Endothermic processes require energy input, provided either directly by the combustion of fuels or indirectly by the introduction of hot gases and/or preheated solids. All types of fluidized bed systems can be used for both endothermic and exothermic processes. A typical example of an exothermic process is the roasting of sulfide ores.

An example of an endothermic process is the calcination of alumina. Whether the process is endothermic or exothermic, tight control of temperature in a fluidized bed reactor is more easily achievable. Fluidized bed based plants may include heat recovery systems, which allow for the effective utilization of heat from offgas and solids streams to decrease operating costs and emissions.

Use of 3D design tools

Outotec uses modern 3D design systems as planning and design tools also for fluidized bed based plants. The main advantages of such systems are:

n High planning reliability

n Improved drawing quality

n Reduced modification work on site

n Shorter job execution time

Outotec's pursuit of new fluidized bed applications for customer needs is supported by experimental work in the company's in-house R&D Center. For example development of neural networks,in-situ monitoring systems and modern mathematical methods, including computational fluid dynamics modeling, are key elements of research.

Scale up experience

With Outotec's experience in many state-of-the-art fluidized bed technologies the customers do not need a large scale demonstration plant as an expensive interim step. Examples of the scale up figures:

Process, year From pilot plant size To industrial plant size Scale up factor

Alumina calcination, 1970 D=1,000 mm/24 tpd D=3,600 mm/500 tpd 1:20 Coal combustion, 1982 D=360 mm/20 kg/h D=5,000 mm/500 tpd 1:1,000 Gold ore roasting, 1990 D=200 mm/22 kg/h D=3,800 mm/2,000 tpd 1:4,000 Circored, 1999 D=200 mm/8 kg/h D=5,000 mm/1,500 tpd 1:3,500

R&D and scale up competence

Outotec has developed theoretical models of fluidized bed systems and specialist scale up know-how over many decades. A unique set of pilot plants, suitable for processing of feeds in the range of 100 g batches up to 1,000 kg/h continuously, is available to develop and improve existing technologies for customer applications. These pilot plants are designed to be flexible with respect to temperature, pressure, gas and fluidization conditions and can be configured either as single or multistage units. However, the data gained in laboratory scale fluidized bed systems are not sufficient to provide design and performance criteria of industrial plants without the experience of operating facilities.

700 mm Circofer demonstration plant, R&D Center, Germany.

Outotec's largest CFB based test facility is the Circofer demonstration plant at the R&D Center in Frankfurt. This plant is equipped with a 700 mm diameter CFB, recycle cyclone, integrated heat generator, char separator, magnetic separator, gas cleaning system, and all necessary ancillary equipment.

Applications

Outotec's portfolio related to fluidized bed technology can be classified as follows.

Reducing conditions

n Dearsenifying pyrite roasting

n Circored (gas based fine ore reduction)

n Circofer (coal based fine ore reduction)

n Circodust (processing of steel plant residues)

n Circosmelt (prereduction and smelting of ilmenite)

n Reducing ilmenite roasting

n Heat recovery by fluidized bed cooling and Circotherm

n Circoheat (preheating of ore fines)

n Circochar (coal charring)

n Circonickel (prereduction of lateritic nickel ore)

n Partial roasting of copper concentrate

Oxidizing conditions

n Alumina calcining

n Roasting of pyrite, copper and zinc concentrates

n Roasting of gold ore

n Oxidizing ilmenite roasting

n Heat recovery by fluidized bed cooling and Circotherm

n Circoheat (preheating of ore fines)

n Circoroast (improved pyrite roasting system)

Alumina calcination

calcination of alumina was designed in 1968. Calcination is the final stage of the Bayer process, in which bauxite is digested with caustic soda to first extract and then precipitate a pure aluminum hydroxide (hydrate). The hydrate from the Bayer process is then calcined to alumina in a CFB. This step was earlier carried out in rotary kilns, but today all new capa-city is installed as fluidized bed calciners.

CFB calcination process

The CFB calciner uses a two-stage venturi preheating system to recover the waste gas heat by preheating and de-watering the hydrate. Final calcination to alumina (Al2O3) is accomplished in the CFB reactor in which the energy is provided by direct combustion of fuel (oil or gas). The energy of the hot alumina is recovered to the incoming air in a multistage cooling system including cyclones and a fluidized bed alumina cooler.

Some energy of the hot alumina is also used for direct calcination of incoming hydrate in a so-called ”hydrate by-pass”. This efficient heat recovery system leads to an overall fuel energy consumption of less than 3 GJ/t of alumina for the calcination process. CFB calciners operate in a range from 900 to 1,000 °C depending on product quality demands.

Due to the homogeneous temperature in the CFB reactor, product qualities regarding specific surface area, loss on ignition and alpha content in the alumina can fulfill the demands of today’s aluminium smelters. We have installed more than 50 CFB calciner units worldwide, which represents approximately one third of the world's production of smelter grade alumina.

Alumina calcination in the CFB.

Outotec's preassembled module (PAM) technology reduces capital cost and meets the challenges of plant construction in remote areas. The first PAM delivery of two large calciners took place in 2006 to the Northern Territory in Australia. The calcining units were preassembled in South East Asia and transported by ship to Alcan's Gove operation.

3,500 tpd preassembled calciner module being delivered to Alcan Gove, Australia.

Hydrate Fuel Secondary air Primary air Cooling water Preheating stage I Preheating stage II CFB reactor Calcining stage

Cooling stage I Cooling stage II

Cooling water Alumina Fluidized bed cooler

Hydrate bypass Electrostatic precipitator Waste gas

010 Fluidization technology

Roasting of sulfide ores

Gold ore roasting in the CFB.

Pyrite roasting in the FB

The optimum reactor for roasting of extremely fine flotation concentrates of copper, pyrite and zinc is a highly stable FB. These reactors, characterized by relatively low fluidization velocities, are well suited to treat such fine materials with grain sizes down to approximately 20 microns. The established concept of a roasting plant consists of a FB roaster, waste heat boiler, gas cleaning and calcine handling systems. Dry feed throughput rates of over 350,000 tpa per unit are achievable. The generated SO_{2 gas} is recovered in a dedicated sulfuric acid plant.

Pyrite roasting plant, ETI Holding, Turkey.

Gold ore roasting in the CFB The CFB roaster is the appropriate reactor for special roasting processes or higher throughput rates of over one million tpa. An example is the gold refractory ore roasting process, where sulfur and carbon removal are essential to obtain acceptable gold recoveries in the subsequent calcine leaching steps.

The roasting of sulfide ores and concentrates is an important process step in the production of metals and chemicals. Sulfides of iron, zinc, copper and other metals are oxidized with air at temperatures between 600 and 1,000 °C into metal oxides and gaseous sulfur dioxide. After cleaning and cooling, the sulfur dioxide contained in the roasting gas is further processed to sulfuric acid. Both FB and CFB types of fluidized bed reactors are commonly used depending on the material properties and specific process requirements.

Gold ore Pyrite CFB ore preheater Fuel 0₂ make up Fuel Fuel Sulfur CFB reactor Waste heat boiler Hot electrostatic precipitator Gas cleaning + sulfuric acid plant

Fluidized bed cooler Quench tank Calcine slurry Tailgas acid plant

Iron ore preheating and direct reduction

The drivers for the development of the Circored process in the early 1990s were the growing demand for direct reduced iron (DRI) coupled with the advantages of using iron ore fines directly in the steelmaking value chain, avoiding the agglomeration step. The Circored process, using hydrogen as the only reductant, applies a two-stage CFB/FB reactor configuration for reduction. In addition, a single CFB is utilized for ore preheating and an AFB based flash heater is used to achieve the DRI briquetting temperature. The first commercial Circored plant, with an annual capacity of 500,000 t of hot briquetted iron (HBI), commenced operations in 1999 in Trinidad.

Circored direct reduction in the CFB/FB.

Circoheat™

The first commercial Circoheat plant, operating at HIsmelt's Kwinana facility in Western Australia is capable of preheating approximately 1,300,000 tpa of iron ore fines to 850 °C using offgas from the HIsmelt smelt reduction vessel (SRV). In the Circoheat process, wet iron ore fines are fed to a suspension preheater system where they are preheated to approximately 500 °C prior to introduction into a CFB reactor. Hot combustible SRV offgas at a temperature of 1,000 °C is introduced into the CFB reactor via an AFB system. The offgas is partially combusted with air to generate the necessary energy for preheating the iron ore. Since the SRV gas is not completely combusted, a reduction of the iron ore to the magnetite/wuestite stage is achieved. The preheated material is subsequently pressurized in a lock hopper system and injected at high temperature into the SRV via a new pneumatic hot ore conveying system.

Ore preheater, HIsmelt Corporation, Australia.

Offgas scrubber To thickener Suspension preheater Iron ore CFB preheater Air Preheating system Feed system Bucket elevator Recycle cyclone Reduction system CFB stage I FB stage II Natural gas Fuel Air Process gas heater

Fuel Air Hydrogen make up Flash heater DRI discharge Cyclone Product handling system Hot briquetting option HBI Hot charging option EAF Steel Bleed as fuel To thickener Process gas scrubber Multi-clone Process gas compressor Process gas heat exchanger Fuel

012 Fluidization technology

Latest developments

Circored plant, CAL, Trinidad.

Circofer CFB prereduction step for HIsmelt.

Based on the wealth of experience gained in the field of fluidization technology, Outotec is continuously working on improving existing processes and developing new processes and applications to meet the demands of an industry pursuing sustainable solutions.

Coal

Dol

omit

e

Char Stand pipe

Ore dryer Hot air Coal crushing Pneumatic coal feeding

Multiclone Process gas scrubber

Stage I Preheating Stage II Reduction CFB reactor Heat gene-rator Process gas heater Air Bleed gas Process gas compressor Char separator Hot injection Recycle char Prereduced iron and char Hlsmelt SRV metalHot with 4% C Slag Coal Offgas Steam Hot air Smelting Thickener CO2 CO2 absorber

One possible application of Circofer is as a single stage prereduction step for the HIsmelt® _{process, replacing} the Circoheat ore preheater. This leads to a significant increase in the throughput of the HIsmelt SRV.

Iron or

e

O2 Circofer®

The Circofer process has been developed to reduce iron ore fines utilizing coal as reductant. Similar to the Circored process, Circofer uses a two-stage CFB/FB reactor configuration to obtain a highly metallized product. A heat generator is integrated into the CFB prereduction circuit to provide the energy necessary for the endothermic reduction reaction by partially combusting the introduced coal with oxygen. The process operates at reduction temperatures of approximately 950 °C in a closed gas circuit without the production of export gas.

Circosmelt®

The combination of ilmenite prereduction in a single stage Circofer CFB unit with an electric smelting furnace allows for the production of a high quality TiO2 slag and pig iron, resulting in significant energy savings.

Circochar®

The CFB based Circochar process, a spin-off from the circofer development, produces metallurgical char and a valuable fuel gas from fine grained high volatile coals. The gas quality can be adjusted to meet the requirements for power generation by adding steam or oxygen to the process.

014 Fluidization technology

Goal Char Ilmenit

e

Pneumatic

transport Heat

gene-rator

CFB Stage I Preheating Stage II

Multiclone Venturi scrubber

Hot magnetic separation Process gas compressor Process gas heater O₂ Dust Gas lift Recyle char Prereduced Ilmenite CO₂ absorber Steam Offgas Titania slag Air Pig iron Smelting furnace CO₂ Thickener

Circosmelt: Ilmenite preheating, prereduction and smelting.

Circoroast®

The next generation of sulfide ore roasting processes will have an environmental and maintenance friendly reactor design. The compact combination of roaster reactor, recycle cyclone, waste heat boiler and fluidized bed cooler provides maximum efficiency in heat recovery and reduced investment and operating costs.

Clay calcination

Calcined clay can be mixed in a ratio of up to 40% with Portland cement to supplement production whilst maintaining quality. The calcination temperature for the clay is significantly lower than the production of equivalent Portland cement leading to considerable energy savings. Using the CFB calcination process, organic and inorganic compounds are removed to achieve a homogenous high quality intermediate product for further downstream processing.

Where applications require intensive mixing between solids and hot dust laden gases, a special reactor design is needed. Circotherm is ideally suited for the quenching of hot offgases with solids, as well as condensing vapors contained in offgas streams that are difficult to handle. The core system comprises an AFB with integrated heat reco-very systems and a solids recoreco-very cyclone.

Circonickel

Outotec has developed a process where the calcination and reduction of lateritic nickel ores to the wuestite/metallic state is performed in a combination of a CFB and a FB system. Coal and natural gas can be used as reductants. Through improved process control of the prereduction, considerable energy savings in smelting of lateric nickel ores to ferro-nickel can be achieved. The new process avoids the production of excessive fine dust as currently generated in existing production plants. Furthermore, dust deposits of existing plants can be processed recovering its nickel content.
