Linux Iptables Avoid IP Spoofing And Bad

Addresses Attacks

by nixCraft on June 28, 2005 · 15 comments· LAST UPDATED July 9, 2008 in Debian Linux, Gentoo Linux, Iptables

Spoofing and bad address attack tries to fool the server and try to claim that packets had come from local address/network.

Following IP/netwok address are know to open this kind of attack:

Incoming source IP address is your servers IP address

Bad incoming address from following ranges:

=> 0.0.0.0/8 => 127.0.0.0/8 => 10.0.0.0/8 => 172.16.0.0/12 => 192.168.0.0/16 => 192.168.0.0/16 => 224.0.0.0/3 etc

=> Your own internal server/network ip address/ranges. Following small shell script tries to prevent this kind of attack: #!/bin/bash

INT_IF="eth1"# connected to internet

SERVER_IP="202.54.10.20"# server IP

LAN_RANGE="192.168.1.0/24"# your LAN IP range # Add your IP range/IPs here,

(2)

IPT="/sbin/iptables"# path to iptables # default action, can be DROP or REJECT

ACTION="DROP"

# Drop packet that claiming from our own server

$IPT -A INPUT -i $INT_IF -s $SERVER_IP -j $ACTION $IPT -A OUTPUT -o $INT_IF -s $SERVER_IP -j $ACTION

# Drop packet that claiming from our own internal LAN

$IPT -A INPUT -i $INT_IF -s $LAN_RANGE -j $ACTION $IPT -A OUTPUT -o $INT_IF -s $LAN_RANGE -j $ACTION

for ip in $SPOOF_IPS

do

$IPT -A INPUT -i $INT_IF -s $ip -j $ACTION $IPT -A OUTPUT -o $INT_IF -s $ip -j $ACTION

done

Save and close the file. Call above script from your own iptables script. Add following line to your /etc/sysctl.conf net.ipv4.conf.all.rp_filter = 1

This entry enables source address verification which is inbuilt into Linux kernel itself.

Tw eet Tw eet 3

0

Like 2

StumbleUpon

If you would like to be kept up to date with our posts, you can follow us on Twitter, Facebook, Google+, or even by subscribing to our RSS Feed.

Featured Articles:

30 Handy Bash Shell Aliases For Linux / Unix / Mac OS X Top 30 Nmap Command Examples For Sys/Network Admins 25 PHP Security Best Practices For Sys Admins

20 Linux System Monitoring Tools Every SysAdmin Should Know 20 Linux Server Hardening Security Tips

Linux: 20 Iptables Examples For New SysAdmins Top 20 OpenSSH Server Best Security Practices Top 20 Nginx WebServer Best Security Practices

20 Examples: Make Sure Unix / Linux Configuration Files Are Free From Syntax Errors 15 Greatest Open Source Terminal Applications Of 2012

My 10 UNIX Command Line Mistakes

Top 10 Open Source Web-Based Project Management Software Top 5 Email Client For Linux, Mac OS X, and Windows Users

(3)

The Novice Guide To Buying A Linux Laptop

{ 15 comments… read them below or add one }

1 Prerak Doshi November 23, 2006 at 7:30 am Hi,

How to configure squid as a direct connection? I would like to following option enable through squid

1. Username password security with individual site Blocking security. 2. FTP, SMTP, POP3 etc.. protocol and port configure.

3. Cache configuration

4. log maintenance of internet usage, bad site request, downloading, uploading with user name.

5. firewall configuration to block intruders.(Apart from local user nobody outside the LAN can use our port and connection to the internet

6. Antivirus : Clamav

Reply

2 nixcraft November 23, 2006 at 9:20 am Prerak

You are using Red hat Linux…..????

Reply

3 Ash December 28, 2006 at 4:38 pm - iptables -A INPUT -s -j DROP + iptables -A INPUT -s $ip -j DROP

Reply

4 nixcraft December 28, 2006 at 6:04 pm Ash,

PHP treated $ip as PHP variable. But now it is fixed. Appreciate your post.

Reply

5 budi August 6, 2007 at 11:39 pm

Address 127.0.0.0/8 is used by server mail or other server like dns or /etc/hosts. And if was blocked the server no running, how solve it?

Reply

(4)

I think that the following code:, # Original code – Start

SERVER_IP=”202.54.10.20” # Add your IP range/IPs here,

SPOOF_IPS=”0.0.0.0/8 127.0.0.0/8 10.0.0.0/8 172.16.0.0/12 192.168.0.0/16 224.0.0.0/3” iptables -A INPUT -s $SERVER_IP -j DROP

for ip in $SPOOF_IPS do

iptables -A INPUT -s $ip -j DROP done

# Original Code – End , can be re-written as :-# Suggested Code – Start PUBLICIF=eth0

SERVER_IP=202.54.10.20 # Add your IP range/IPs here,

SPOOF_IPS=”$SERVER_IP 0.0.0.0/8 127.0.0.0/8 10.0.0.0/8 172.16.0.0/16 192.168.0.0/16 224.0.0.0/3″ for ip in $SPOOF_IPS

do

iptables -A INPUT -i $PUBLICIF -s $ip -j DROP done

# Suggested code – Stop

Please correct me if I am wrong, but IMHO, if we DROP packets without mentioning the interface then legitimate connections originating from the same server on loopback (lo) will also get dropped.

Thanks.

Reply

7 Muhammad Kamran Azeem April 10, 2008 at 5:29 pm Sorry. This

line:-SPOOF_IPS=”$SERVER_IP 0.0.0.0/8 127.0.0.0/8 10.0.0.0/8 172.16.0.0/16 192.168.0.0/16 Should not contain $SERVER_IP and should instead

be:-SPOOF_IPS=”0.0.0.0/8 127.0.0.0/8 10.0.0.0/8 172.16.0.0/16 192.168.0.0/16

Reply

8 Gunjan July 9, 2008 at 6:35 am

Yes we need to be remove $SERVER_IP from SPOOF_IPS other wise server also block and we do not have any access to server

(5)

9vivek July 9, 2008 at 11:21 am Gunjan,

The script has been updated to only filter on public interface. This should fix the issue.

Reply

10 kwik August 4, 2008 at 7:20 pm

It is impossible to spoof your address if your Linux computer is behind NAT enabled router such as Cisco. This script is more useful on *Linux based router* as packet filtering is one defense against IP spoofing attacks. The Linux gateway to a network usually performs ingress filtering, which is blocking of packets from outside the network with a source address inside the network. This prevents an outside attacker spoofing the address of an internal machine. Ideally the Linux gateway would also perform egress filtering on outgoing packets, which is blocking of packets from inside the network with a source address that is not inside. This prevents an attacker within the network performing filtering from launching IP spoofing attacks against external machines.

I hope this will help someone.

Reply

11 Shoelaces November 5, 2011 at 3:35 am I had to comment out:

$IPT -A OUTPUT -o $INT_IF -s $SERVER_IP -j $ACTION this wouldn’t allow SSH connections out

Reply

12 Jouni "Rautamiekka" Järvinen August 6, 2012 at 1:07 pm

What about when the computer doesn’t have a LAN address, like those directly connected to Internet ?

Reply

13 Jouni "Rautamiekka" Järvinen August 6, 2012 at 2:20 pm

And why manually specify IPtables path when you can use §`which iptables`§ instead ?

Reply

14 shahzaib January 21, 2013 at 11:46 am Hello,

Please if you can guide me about how can i identify if someone spoofing to my ip ? Which logs should i check ?

Reply

(6)

How do you “call this script from iptables”. What does that mean? Reply Leave a Comment Name * E-mail * Website
