Weatherproof Tournament Table Tennis Table

(1)

M a d e i n G e r m a n y

Weatherproof Tournament Table Tennis Table

Owner’s Manual Model Number 7035-590

Printed on 100% recycled paper

.!

Absolutely W

eatherproof

Thank you for purchasing our high quality KETTLER product. If you have any questions or concerns regarding this product, please contact us: KETTLER International, Inc. E-mail [email protected] Parts & Service Department Tel: 757-427-2400 ext. 26

P.O.Box 2747 Fax: 757-563-9273

Virginia Beach, Virginia 23450 USA

Please have this owner’s manual with you when you call.

(2)

Assembly Instructions

Before assembling or using the table-tennis table, please read the following instructions carefully. They contain

impor-tant information for use and maintenance of the equipment as well as for your personal safety. Keep these instructions

in a safe place for maintenance purposes or for ordering spare parts.

All KETTLER products are designed in accordance with the latest safety regulations and undergo a constant process of quality control during manufacturing. The knowledge in this process is used to constantly improve and develop our products. In order to offer our cus-tomers the very best in product quality, we reserve the right to make technical changes at any time. Should you have any cause for com-plaint, please contact KETTLER at:

KETTLER International, Inc. P.O.Box 2747

Virginia Beach, Virginia 23450 USA Tel: 757-427-2400 ext. 26

Fax: 757-563-9273 E-mail [email protected]

Note on Safety

■The table tennis table should be used only for its intended pur-pose, i.e. for playing with suitable table tennis paddles and balls.

■All other uses are prohibited and may be dangerous. The man-ufacturer cannot be held liable for damage or injury caused by improper use of the table.

■Damaged or worn components may endanger your safety or shorten the lifespan of the table tennis table. Replace worn or damaged components immediately and remove the table from use until this has been done. Use only spare parts manufac-tured by KETTLER.

■The table tennis table complies with all safety regulations. In-correct repairs, alterations to the design (removal of original parts, addition of other components etc.) may endanger the safety of the user.

■Instruct other persons (in particularly children) using the table in its correct use, and draw their attention to any potential source of danger, especially folding or closing the table.

■When setting up or dismantling the table, stay clear of its fold-ing radius.

■When folded up, the table tennis table presents a large surface to the wind. For this reason, ensure that it is stored in a shel-tered position.

■The unit complies with the standard DIN 7898-1/10.97.

■Depending on frequency of use, check all screws, bolts etc. regularly to ensure that they are in good condition.

Handling the equipment

■Do not use the table tennis table until it has been fully and cor-rectly assembled and checked.

■Set the table up on a level surface.

■Do not cover it with plastic foil, under which condensation may form. We recommend the weatherproof KETTLER table tennis cover, art. no. 7032-800.

Limited One-Year Warranty (Residential use)

Manufacturer warrants to the original retail purchaser, this product to be free from defects in material and workmanship for a period of one (1) year from the date of purchase. Should this product become defective due to material or workmanship within the warranty period, contact our Customer Service Department for repair or replacement at our opinion. This warranty is not transferable and does not cover normal wear and tear, bowing of the table or damage caused by improper handling, installation or use of this product. This warranty is also void if product is in any way abused, damaged, or modified from its original state, or if used for other than residential use. This warranty gives you specific legal rights, and you may have other rights which vary from state to state.

If table does not seem level, it is probably because floor is not lev-el. Move table several inches (set table in playing position) in dif-ferent directions to find the best location for the table. If the floor is extremely unleveled, table may not play or operate properly. If table is high in the center, shim up under the outer legs.

■For practising without a partner, the table halves can be fold-ed up singly.

■Do not use corrosive or abrasive materials to clean the equip-ment. Ensure that such materials are not allowed to pollute the en-vironment. In most cases, a slightly dampened cloth is sufficient.

(3)

Notes on Text

Screw the connecting braces with the lateral parts.

Screw the push braces with the lateral parts.

Screw the locking levers with the middle connecting braces. Care for a correct installation of the locking levers (see designation 1 and 2).

Now position one table half. Secure the table half against sliding and/or overturning for the subsequent installation steps! First, have a second person screw the angles at-tached to the table with the lateral parts.

At each side, screw the push brace with the supporting leg. Repeat process with the other table half.

Instructions for Use

Lowering the table halves: Press down both locking levers. Then lower the table slowly (do not let the table move down fast).

Collapsing the table halves: Pay attention to the fact that the tables always stand in final position and that the lock-ing levers have been arrested such that the tables cannot be lowered unintentionally.

A

B

C

D

E

H

1

H

2

Instructions for Assembly

■Carefully read these assembly instructions before beginning with the work itself. The individual steps are additionally ex-plained in the sequence by means of symbols, in some cases a text mark indicates that a written explanation is available. Strictly follow the individual mounting steps to ensure a safe use and operation of the unit.

■To ensure that the table-tennis table is properly assembled and can be safely used, observe the instructions for assembly ex-actly.

(4)

Checklist (contents of packaging)

Actual size chart

2x 2x 2x 4x

2x

4x 2x

4x 4x

4x 2x 1x

4x

4x 8x

4x 2x

4x

2x

4x 2x 4x

4x

M6x90

4x

M6x75

4x

M6x65

4x

M6x45

4x

M6x35

8x

ø12

24x

ø12

20x

M6

20x

M6

4x

You also need the following tools (Not included):

(5)

1

(6)

3 A

4x M6x35

4 B

4x M6x75

B

A

B

A

(7)

6 D

5 C

4x

(8)

H

1

A

B

C

7

8

4x M6x65

(9)

H

2

9

10 Handling

4x M6x35

(10)

11 Handling

12 Handling

19mm Wood 22mm Aluminium

A Adjustment knob; pull knob off net post and select desired thickness (22mm for aluminium top)

B Slide the netposts between the table halves.

C Slide the tension pin through net D Place pin in designated slots

E Tie tension string to plastic tension tab.

F Place tension string in slots over tension pin and net post. Adjust net tension by adjusting plastic tension tab.

A

B

C

D

E

F

(11)

Spare parts drawing

2

17

7

1

6

10

13

9

17

20

11

15

14

16

18

4

5

12

3

22

21

23

(12)

Spare parts list

Item Description Pieces Part No.

for 7035-590 (green)

Ordering spare parts

When ordering spare parts, always state the full product number, spare-part number, the quantity required and the control number stamped on the back.

Example order:Product No. 7035-590 / spare-part no. 10100046 / 2 pieces / inspection no...

Important:spare part prices do not include fastening material; if fastening material (bolts, nuts, washers etc.) is required, this should be clearly stated on the order by adding the words „with fastening material“.

For parts, please contact us at:

KETTLER International, Inc. P.O.Box 2747

Virginia Beach, VA 23450-2747 USA E-mail [email protected] Tel: 757-427-2400 ext. 26 Fax: 757-563-9273

In case of complaint, please state this control number.

1 Top-Half/Aluminium (PLEASE STATE ART.NO. 7035-590 WHEN ORDERING TABLE HALF!) 2 94130003

2 PVC-Clamp round 4 10128024

3 PVC-Clamp square 4 70130660

4 Front leg assembly 2 94110810

5 Foot Cap 4 70130540

6 Side shroud 2 94110800

7 Leg connector bar 4 94110812

8 PVC Spacer (Not shown) 4 10107032

9 Center transport frame-half 2 94110803

10 Square cap 4 10100046

11 Frame cross bar 2 94110804

12 Wheel assembly 4 94110413

13 PVC bushing-wheel 8 10116013

14 Safety lock #1 2 70130960

15 Safety lock #2 2 70130965

16 Lock spring 4 25505854

17 Spacer 4 97201442

18 Protector – half sleeve 4 70101550

19 Hardware bag (Not shown) 1 94180110

20 Square cap – open 4 10100065

21 Stabilizer bar 2 94110811

22 Bushing 4 70131040

23 net (complete) 1 94180083
