Perforated Architectural Panels

Add interest and reduce energy costs with

EPIC Architectural & Sun Screen

EPIC

®

Architectural &

Sun Screen

EPIC

Architectural & Sun Screens add interest to a

building’s façade and can also reduce heat gain, glare,

and energy costs. As a sun screen, perforated panels

on the exterior building surface, overhangs, or

walkways where heat gain is a problem can reduce the

building’s energy consumption. Variations in the

perforation pattern control the amount of light that

enters from the exterior as well as the visual

translucence of the panel from the interior.

EPIC Architectural & Sun Screens are available in six

profiles that can be specified in various gages and

depths to meet design span requirements. Contact

EPIC Metals for a consultation on your next project.

EST: _{U.S. Design Patent Number D623,773 ; D648,445 and D655,022}

EST4: U.S. Design Patent Number D623,773 and D663,045 ESV: U.S. Design Patent Number D677,405

APEXscreen™: U.S. and Canadian Patent Pending.

Canadian Design Patent Number 131,349 ; 134,371 and 134,369 Canadian Design Patent Number 131,349 and 144,931 Canadian Design Patent Number 138,173 and 141,931

Café College, San Antonio, Texas, ESE450

EST

spans 5´–17´

EST4

spans 8´–22´

ESE

spans 8´–28´

APEXscreen

™ spans 12´–24´

ESW

spans 8´–24´

ESV

spans 6´–20´ Product Profile 12˝ (305mm) coverage 41_⁄2˝ ESE450 (114mm) 6˝ ESE600 (152mm) 71_⁄2˝ ESE750 (190mm) 18˝ (457mm) coverage APEXscreen™ 143_⁄10˝ (364mm) 18˝ (457mm) coverage ESV3.0 3˝ (76mm) ESV4.5 41_⁄₂_{˝ (117mm)} ESV6.0 6˝ (152mm) 21_⁄2˝ (63mm) 6˝ (152mm) 6˝ (152mm) 6˝ (152mm) 6˝ (152mm) 24˝ (610mm) coverage 4˝ (102mm) 8˝ (203mm) 8˝ (203mm) 8˝ (203mm) 24˝ (610mm) coverage 71_⁄2˝ ESW750 (190mm) 6˝ ESW600 (152mm) 41_⁄2˝ ESW450 (114mm) 18˝ (457mm) coverage

Simulation, APEXscreen

™

URENCO Campus Commons, Eunice, New Mexico, EST

*

*Miami-Dade County Notice Of Acceptance Report #17-1221.25 for EPIC Metals sunscreen panels EST4, ESW450, ESW600 and ESW750. The listed panels meet the High Velocity Hurricane Zone (HVHZ) requirements of the 2017 Florida Building Code, 6th Edition.

(4)

7 EPIC METALS

Koehler Garage at Pearl Brewery Development

San Antonio, Texas, ESE450

CREC Medical Professions & Teacher Academy,

New Britain, Connecticut, EST2.5

(5)

PART 3: EXECUTION

3.1 GENERAL

A. The type (EST), (EST4), (ESV), (ESW), (ESE) or (APEXscreen™) screen panels shall be installed in strict accordance with the manufacturer’s instructions, approved erection drawings, and all applicable safety regulations. 3.2 BEFORE INSTALLATION

A. The supporting frame and other work relating to the type (EST), (EST4), (ESV), (ESW), (ESE) or (APEXscreen™) screen panels shall be examined to determine if this work has been properly aligned and completed. B. All components of the type (EST), (EST4), (ESV), (ESW), (ESE) or

(APEXscreen™) screen panels shall be protected from damage during storage and handling.

3.3 INSTALLATION

A. Before being permanently fastened, type (EST), (EST4), (ESV), (ESW), (ESE) or (APEXscreen™) screen panels shall be placed on the supporting frame and adjusted to final position with ends accurately aligned and adequately bearing on the supporting frame. Consistent coverage shall be maintained so that panels located in adjacent bays will be properly aligned.

B. Cutting of type (EST), (EST4), (ESV), (ESW), (ESE) or (APEXscreen™) screen panels to suit jobsite conditions shall be performed in a neat and professional manner, (no cutting torches). Only those openings indicated on the structural drawings shall be cut. Other openings shall be cut and reinforced by those requiring the openings as approved by the Structural Engineer. Exposed raw edges must be touched-up with coatings that have an equal endurance to that of the original coating.

PART 1: GENERAL

1.1 SUMMARY

A. Section includes: Shop fabricated metal screen panels to mount on the exterior of the building; type (EST), (EST4), (ESV), (ESW), (ESE) or (APEXscreen™) screen panels.

1.2 RELATED WORK

A. Other specification sections which directly relate to the work of this section include, but are not limited to, the following:

1. Structural Steel. 2. Supplementary Framing. 1.3 SUBMITTALS

Submit the following items with the conditions of the contract and appropriate specification sections:

A. The manufacturer’s specifications, section properties, load and span tables, dimensions, and finishes, shall be submitted.

B. Shop drawings shall be submitted showing panel placement, profiles, material thicknesses, finishes, layout, anchorage and openings as dimensioned on the Architectural drawings.

C. A full width sample shall be submitted as requested to verify compliance with the specifications and the level of quality. Color chips shall be submitted separately.

1.4 REFERENCE STANDARDS

A. Section properties shall be computed in accordance with the American

Iron and Steel Institute (AISI) Specification for Design of Cold-Formed Steel Structural Members.

B. Panel manufacturer shall have been regularly engaged in the production of metal screen panels with all of the required features for a period of at least ten years.

1.5 DELIVERY, STORAGE, AND HANDLING

A. The panels shall be protected from damage during storage, and handling. B. If storage at the jobsite is required, type (EST), (EST4), (ESV), (ESW), (ESE) or

(APEXscreen™) screen panels shall be elevated above the ground, sloped to provide drainage, and protected from the weather with a ventilated covering. Moisture must not be allowed to accumulate between or on panels; contractor shall monitor, protect, and handle accordingly. All banded bundles shall be broken open so that air can circulate between the metal surfaces.

PART 2: PRODUCTS

2.1 MANUFACTURER

A. In accordance with the requirements of this specification section, provide products manufactured by EPIC Metals Corporation, Rankin, PA. B. Type (EST) or (EST4) screen panels, and their design depth (2 ½ inch or

4 inch), shall be shown on the Architectural design drawings. Type (ESV) screen panels, and their design depth (3 inch, 4 ½ inch, or 6 inch), shall be shown on the Architectural design drawings. Type (ESE) or (ESW) screen panels, and their design depth (4 ½ inch, 6 inch, or 7 ½ inch), shall be shown on the Architectural design drawings. Type (APEXscreen™) panels design depth (14 3_{⁄10 inch), shall be shown on the Architectural} design drawings.

2.2 MATERIAL

A. The type (EST), (EST4), (ESV), (ESW), (ESE) or (APEXscreen™) screen panels shall be cold-formed from steel coils conforming to ASTM A653, Grade 40, or equal, having a minimum yield strength of 40,000 psi.

B. Before forming, the steel coils shall have received a hot-dip protective coating of zinc conforming to ASTM A924, Class G90, as defined in ASTM A653.

2.3 FABRICATION

A. Type (EST), (EST4), (ESV), (ESW), (ESE) or (APEXscreen™) screen panels shall be cold-formed by the continuous roll forming process in depth shown on Architectural design drawings. Break-formed panels are not acceptable. 1. Type (ESW) and (ESE) screen panels shall have full nested sidelaps that

from the back-side present a uniform appearance and allow drainage. 2. For type (ESW) and (ESE) screen panels, webs and center section

shall be perforated prior to forming; remaining outside corners and mounting flange of panel shall remain solid. For type (EST) and (EST4) screen panels, the surfaces between the dovetail ribs are perforated. For type (ESV) and (APEXscreen™) panels, the curved sections are perforated so as not to compromise the value of the sidelap connections.

3. Finished Paint Option- Both surfaces of the screen panels shall be factory coated with Epishield®_{and oven cured. The Epishield shall} be applied after perforating and forming are complete. Color to be selected from standard color chart; same color shall be used on both sides of panel. Painting prior to perforating, thereby leaving bare steel at edges of perforations shall not be accepted. Air dry coatings are not acceptable.

2.4 ACCESSORIES

A. Trim or accessories shall be provided as indicated on the Architectural design drawings.

B. Openings and reinforcement for openings noted specifically by the panel manufacturer on the Structural design drawings shall be provided.

EPIC

®

_{Architectural & Sun Screen}

Specifications

University of Texas College Park Parking Garage

Arlington, Texas, ESE450

C. Type (EST), (EST4), (ESV), (ESW), (ESE) or (APEXscreen™) panels shall be fastened to all supporting members with an approved fastener as specified by EPIC Metals for this particular project and as indicated on the manufacturer’s erection drawings. Care must be taken to maintain the coverage prior to fastening the screen panels. For the (ESV), (APEXscreen™) the use of registration strips at the ends and locations of anchorage are required. This is an accessory provided by Epic Metals that is field installed according to the erection drawings and prior to installing the screen panels. D. If called for by EOR, sidelaps of type (EST), (EST4), (ESV), (ESW), (ESE)

or (APEXscreen™) screen panels shall be fastened together with #12 screws at a maximum spacing of 36˝ on center or less as indicated on the manufacturer’s erection drawings.

E. Construction loads shall not be applied to type (EST), (EST4), (ESV), (ESW), (ESE) or (APEXscreen™) screen panels until after the panels are permanently fastened to supporting members, and sidelaps are attached. The construction loads shall not exceed the capacity of the panels. F. Items such as signage, light fixtures, flashing, etc. shall not be attached

to type (EST), (EST4), (ESV), (ESW), (ESE) or (APEXscreen™) screen panels without specific approval of the Architect and Structural Engineer. G. Accessories and any supplied reinforcement for small openings shall be

fastened as indicated on the manufacturer’s erection drawings. 3.4 AFTER INSTALLATION

A. Construction loads that could damage the type (EST), (EST4), (ESV), (ESW), (ESE) or (APEXscreen™) screen panels such as heavy concentrated loads and impact loads shall be avoided. Protection or planking shall be used in all high traffic areas.

B. Galvanizing and other coatings that are damaged must be field repaired using appropriate methods and shall be the responsibility of the contractor. C. Cleaning surfaces of the type (EST), (EST4), (ESV), (ESW), (ESE) or

(6)

11 EPIC METALS EPIC METALS 12

Designer’s Responsibility

The information presented in this brochure has been prepared in accordance with generally recognized engineering principles. We recommend that this information not be used or relied upon for any application without a thorough review by a licensed professional engineer, designer, or architect who will be competent to evaluate the significance and limitations of this material and who will accept responsibility for the application of this material for any specific application.

EPIC Metals Corporation makes no representation or warranty respecting any information contained in this manual, including but not limited to the accuracy, completeness, or suitability of such information for any particular purpose or use.

EPIC Metals Corporation expressly disclaims any and all warranties, expressed or implied.

By making this information available, EPIC Metals Corporation is not rendering professional services, and assumes no duty or responsibility with respect to any person making use of such information.

In addition, EPIC Metals Corporation is not liable for any claim, demand, injury, loss, expense, or liability of any kind whatsoever that in any way arises out of, or is connected with, the use of the information contained in this publication, whether or not such claim, demand, loss, expense, or liability results directly or indirectly from any action or omission of EPIC Metals Corporation. Any party using the information contained in this brochure assumes all liability arising from such use.

Since hazards may be associated with the handling, installation, or use of steel and its accessories, prudent construction practices should always be followed. We recommend that the parties involved in such handling, installation, or use review all applicable manufacturer’s material safety data sheets, applicable rules and regulations of the Occupational Safety and Health Administration and other government agencies having jurisdiction over such handling, installation, or use, and other relevant construction practice publications, including the Steel Deck Institute (SDI) Manual for Construction with Steel Deck.

Warranty

EPIC Metals Corporation warrants that materials to be furnished, insofar as they are manufactured by EPIC Metals Corporation, shall be free from structural defects. In the event of the failure of the material within one year from the date of delivery, and providing that such failure is attributed to defects found to have existed at the time of delivery, EPIC Metals Corporation’s liability hereunder shall be limited to furnishing necessary replacement material. EPIC Metals Corporation assumes no liability for damages, losses, or injuries, direct or consequential, that may arise from use or inability to use the products.

Except as herein provided, there are no expressed or implied warranties as to merchantability or fitness of the materials for any particular purpose.

Designer’s

Responsibilities

& Warranty

Cinema Park Shopping Center, Phoenix, Arizona, EST

(7)

Specifying EPIC

®

_{Architectural}

& Sun Screen Systems for your

next project can enhance the

building’s architecture while

protecting the interior from

heat gain and damaging UV

light. EPIC Sun Screens enable

the architect or engineer to

control the amount of sunlight

entering the building.
