Web Programming II JSP (Java Server Pages) ASP request processing. The Problem. The Problem. Enterprise Application Development using J2EE

(1)

Enterprise Application Development Using J2EE / © Shmulik London 2004 Interdisciplinary Center Herzeliza Israel

Enterprise Application

Development using J2EE

Shmulik London

Web Programming II –

JSP (Java Server Pages)

Lecture #6

Enterprise Application Development Using J2EE / © Shmulik London 2004

The Problem

ResultSet result = statement.executeQuery( "SELECT course_id, name, hours FROM courses"); response.setContentType("text/html");

PrintWriter writer = response.getWriter(); writer.println(“<html><body><table border=\"1\">"); writer.println("<tr><td>ID</td><td>Name</td></tr>”); while(result.next()) {

long id = result.getLong(1); String name = result.getString(2); writer.println("<tr><td>"+id+"</td>”+

“<tr><td>”+name+”</td></tr>”); }

writer.println(“</table></body></html>”);

The Problem

• Writing HTML in Java is

cumbersome and inefficient (both

runtime and development cycle)

• We would like Web Designers to do

design the page and programmers

to do the logic (separation of

concerns)

How we approached it

in the old days... (ASP)

<HTML><TITLE>Multiplication Table</TITLE> <H2>Multiplication Table</H2>

<TABLE border="1" cellpadding="2" cellspacing="0"> <TR height="20" bgcolor="#f0f0f0"><TD width="20"></TD> <% FOR J=1 TO 10 %>

<TD width="20"><%=J%></TD> <% NEXT

FOR I=1 TO 10 %>

<TR height="20"><TD width="20" bgcolor="#f0f0f0"><%=I%></TD> <% FOR J=1 TO 10 %> <TD width="20"><%=I*J%></TD> <% NEXT NEXT %> </TABLE> </HTML>

Note: this example is superficial – we don’t need the server for the data, we might as well do it in client side JavaScript

ASP request processing

Internet

File-system static content and templates Courses Database

IIS ISAPI Filter

ASP Page

The ASP page is parsed

and the embedded scripts

are executed to generate

dynamic content

And some continued

this way in JSP…

<HTML>

<TITLE>Multiplication Table</TITLE> <H2>Multiplication Table</H2>

<TABLE border="1" cellpadding="2" cellspacing="0"> <TR height="20" bgcolor="f0f0f0"><TD width="20"></TD> <% for (int j=1; j<=10; j++) { %>

<TD width="20"><%=j%></TD> <% } %>

<% for (int i=0; i<=10; i++) { %>

<TR height="20"><TD width="20" bgcolor="f0f0f0"><%=i%></TD> <% for (int j=1; j<=10; j++) { %> <TD width="20"><%=i*j%></TD> <% } } %> </TABLE> </HTML>

(2)

Enterprise Application Development Using J2EE / © Shmulik London 2004 <HTML>

<TITLE>Multiplication Table</TITLE> <H2>Multiplication Table</H2>

<TABLE border="1" cellpadding="2" cellspacing="0"> <TR height="20" bgcolor="f0f0f0"><TD width="20"></TD> <% for (int j=1; j<=10; j++) { %>

<TD width="20"><%=j%></TD> <% } %>

<% for (int i=0; i<=10; i++) { %>

<TR height="20"><TD width="20" bgcolor="f0f0f0"><%=i%></TD> <% for (int j=1; j<=10; j++) { %> <TD width="20"><%=i*j%></TD> <% } } %> </TABLE> </HTML>

Scripting elements make

the code messy and don’t

allow for good separation

of concerns (design / logic)

JSP offer better alternatives.

Avoid scripting elements!

But you’re too smart for that…

Scripting Elements

• Imagine large pages, containing both

scripting elements, JavaScript / DHTML,

CSS, sometimes Applets or ActiveX

controls.. server side script that

generate client side script!, pages

delegates control to each other..

• This results in a jungle that is impossible

to maintain

JSP as a Template Engine

JSP Page Request

Fetch data or compute

Use the data to fill in a JSP template

Return the result of merging the static html of the template with the dynamic data

Servlet

Example (Query Form)

<html>

<head><title>Course Search</title></head> <body>

<h1>Course Search</h1>

<form action="course-info" method="POST"> <table border="0">

<tr>

<td>Enter course code</td> <td><input name="code"

type="text" size="10"/></td>

<td><input type="submit" value="Submit"/></td> </tr>

</table> </form> </body> </html>

Example (JSP Template)

<%@ page contentType="text/html" %> <html> <body> <h1>Course Details</h1> <b>Name:</b> ${courseName} <br/> <b>Code:</b> ${courseCode} <br/>

<b>Credit points:</b> ${creditPoints} <br/> ...

</body>

Example (Servlet)

protected void doPost(HttpServletRequest request…

String code = request.getParameter(“code”); String courseName = … fetch data using code String creditPoints = … fetch data …

request.setAttribute(“courseName”, courseName); request.setAttribute(“courseCode”, code); request.setAttribute(“creditPoints”, creditPoints); RequestDispatcher dispatcher = request.getRequestDispatcher( "/course-info.jsp"); dispatcher.forward(request, response); }

(3)

JSP request processing

Internet

JSP container

JSP Page Upon first request the JSP is

parsed and is compiled into a Servlet. The Servlet include code to dump static HTML code segments that appeared in the original JSP page

JSP compiler Controller

Servlet

Template Engines

• Many web frameworks use the idea

of a template engine

– JSP, Velocity, FreeMarker… (Java)

– Django (Python)

– Ruby on Rails (Ruby)

– Grails (Groovy)

– Lift (Scala)

– …

Beyond Placeholders

• Sometimes we need more than just

placeholders

– Lists / Tables

– Conditional segments

– Common elements – header, footer..

– …

• We use

JSP Tags

for this

– Again not embedded code!

JSP Tags

• JSP defines a set of HTML-like tags

that allow to add dynamic content

to a page

• In addition it provide a simple way

for writing your own custom tags

• You can find numerous of tag

libraries (often open source)

Example:

include

Tag

<%@ page contentType="text/html" %> <html>

<body>

<jsp:include page="header.html“/> <jsp:include page="menu.jsp“/> <h1>My special page</h1>

Here is the content of my special page . . . . . .

<jsp:include page="footer.html"/> </body>

</html>

• Includes the content of another page

(static or dynamic) in the current page

Example

Using <jsp:include> to include a result of a Servlet

Again: this example is superficial – we don’t need the server for the data, we might as well do it in client side JavaScript

(4)

Example

Using <jsp:include> to include a result

of a Servlet

MultiplicationTableServlet multiplication_table.jsp

MultiplicationTableServlet

protected void doGet( HttpServletRequest request, HttpServletResponse response) throws IOException { try {

int rows = Integer.parseInt( request.getParameter("rows")); int columns = Integer.parseInt(

request.getParameter("columns")); PrintWriter writer = response.getWriter(); printTable(writer, rows, columns); } catch (NumberFormatException e) {

System.out.println("Illegal parameter value"); }

}

MultiplicationTableServlet

private void printTable( PrintWriter writer, int rows, int columns) {

writer.println("<TABLE border=\"1\" cellpading... >"); writer.println("<TR height=\"20\" bgcolor=...</TD>"); for (int j=1; j<=columns; j++) {

writer.println("<TD width=\"20\">"+j+"</TD>"); }

for (int i=1; i<=rows; i++) { writer.println( "<TR height=\"20\"><TD width=\"20\" " + "bgcolor=\"f0f0f0\">"+i+"</TD>"); ... } }

multiplication_table.jsp

<%@ page contentType="text/html" %> <h2>Multiplication Table</h2>

<form method="GET" action="multiplication_table.jsp" > Rows <select name="rows"><option value="3">3</option>... </select>

Columns <select name="columns">... </select>

<input type="submit" value="Go"> </form> <jsp:include page="/multiplication_table_servlet" flush="true"> <jsp:param name="rows" value="<%=request.getParameter("rows")%>"/> <jsp:param name="columns" value="<%=request.getParameter("columns")%>"/> </jsp:include>

JSTL

• JSTL - JSP Standard Tag Library

• Collection of tags for functions that

are common to many web apps

– flow control, formatting, IO...

– Introduces EL expressions

Note: JSTL introduce many Tags, but not all make sense,

Tags that access the database or read files directly from the JSP

page is a bad idea! In general all the logic of fetching the data should

be done in lower layer

if Tag

<%@ page import="sokoban.web.*"%> <%@ page contentType="text/html" %> <%@ taglib prefix="c” uri="http://java.sun.com/jstl/core" %> <jsp:include page="/header.html"/>

<p>Welcome to our Sokoban server. ...

<c:if test="${!(empty sessionInfo.message)}"> <p><font color="#CC3300">

<c:out value="${sessionInfo.message}" /> </font></p>

</c:if>

(5)

foreach Tag

<%@ page contentType="text/html" %> <%@ page isELIgnored ="false" %>

<%@ taglib prefix="c" uri="http://java.sun.com/jsp/jstl/core" %> <html>

<body>

<h1>Course List</h1>

<table border="1" cellpadding="3" cellspacing="0"> <tr>

<th width="80" align="center">Symbol</th> <th width="400" align="center">Name</th> <th width="120" align="center">Instructor</th> </tr>

<c:forEach var="course" items="${courses}"> <tr> <td align="center">${course.symbol}</td> <td align="center">${course.name}</td> <td align="center">${course.instructor}</td> </tr> </c:forEach> </table> </body> </html>

Servlet Side

public void doGet(HttpServletRequest request … ) …{ ...

ResultSet results = statement.executeQuery( “SELECT * FROM courses”);

List<CourseInfo> courses = new ArrayList<CourseInfo>(); while (results.next()) {

CourseInfo course = new CourseInfo(); course.setSymbol(results.getString(“symbol”)); course.setName(results.getString(“name”)); ... } request.setAttribute(“courses”, courses); request.getRequestDispatcher(“/course-list.jsp”). forward(request, response); }

Note: there might be too many results to be sent in a single request, it is always a good idea to limit the number of results and page through them

Tag Libraries

• JSP allows you to add additional

tags through tag-libraries

• You can wrap a commonly used

presentation code in a new tag and

provide it to the web-designer

• You can find numerous tag libraries

(notably JSTL) or develop your

own

Custom Tag Example

Repeated HTML code

Again, this example is superficial – we are better off using JavaScript here as expanding the tag in the server will result-in large html sent to the client, and redundant server load

Custom JSP Tag

<%@ page contentType="text/html" %> <%@ taglib prefix="examples“

uri="http://www.idc.ac.il/j2ee/examples" %> <h2>Recommended EJB Books</h2>

<table border=0> <tr>

<td><examples:rank rank="5"/></td>

<td>Enterprise JavaBeans / Reichard Monson-Haefel</td> </tr>

<tr>

<td>Mastering Enterprise JavaBeans / Ed Roman</td> </tr>

<tr>

<td>EJB Design Patterns / Floyd Marinescu</td> </tr>

Custom JSP Tag

package examples.web.tags;

import java.io.*;

import javax.servlet.jsp.*; import javax.servlet.jsp.tagext.*; public class RankTag extends TagSupport {

private static final int MAX_RANK = 5; private int rank;

public void setRank(int rank) { this.rank = rank;

(6)

Custom JSP Tag

public int doStartTag() throws JspException {

JspWriter writer = pageContext.getOut(); try {

writer.println("<table border=0 width=50>"); writer.println("<tr height=20 width=50>"); for (int i=0; i<MAX_RANK; i++) {

writer.println(i<rank ? “<td width=10><image “+ “src=\"res/icons/star.gif\"</td>") : “<td width=10> </td>"); } } writer.println("</tr></table>"); } catch (IOException e) { e.printStackTrace(); } return EVAL_PAGE; } }

Custom JSP Tag

<?xml version="1.0" encoding="UTF-8" ?> <!DOCTYPE taglib PUBLIC "-//Sun Microsystems, ... <taglib> <tlibversion>1.1</tlibversion> <jspversion>1.1</jspversion> <shortname>examples</shortname> <uri>http://www.idc.ac.il/j2ee/examples</uri> <tag> <name>rank</name> <tagclass>examples.RankTag</tagclass> <attribute> <name>rank</name> <required>true</required> <rtexprvalue>false</rtexprvalue> </attribute> </tag> </taglib>

Web Application Framework

• Real applications consists of many

Web-pages both dynamic & static

• Pages forward/redirect request to other

pages, include other pages, and call

components to perform logic

• We need a consistent framework for

organizing all presentation and logic

components and the interaction

between them

WAFs

• Such a framework is referred to as

WAF (Web Application Framework)

• There are many Java based WAFs,

on top of JSP and/or Servlets

• We’ll describe a general design for

working with JSP & Servlets. It is

used in Struts2 and other WAFs

Model2

• Model2* applies a design pattern known

as MVC to the problem

– The client directs all requests to a single

controller Servlet

– The controller process the request, acts on the

model and forwards the request to another

Servlet/JSP for rendering

– The target Servlet/JSP render the response

according to attributes passed by the

controller via request/session attributes

Model2 (MVC)

JSP Pages (View)

Servlet (Controller)

JavaBeans / EJB / Database (Model) Forward request after setting attributes in request or session

(7)

Example (ex3)

login.jsp game.jsp MIDletResponseServlet

MapRenderingServlet

ControllerServlet

Passing parameters

public class ControllerServlet extends HttpServlet { public void doGet(HttpServletRequest request, ...) {

...

request.setAttribute(“price”, new Float(price)); ... forward <%@ page contentType="text/html" %> ... Price: ${price} ... Controller Servlet Rendering JSP page

Using JavaBeans

• JSP allows to separate presentation

from logic by using JavaBeans

– You ‘embed’ a JavaBean in your page

– Set its properties, typically according

to request parameters values

– The bean calculates the value of

other properties accordingly

– Retrieve the value of the calculated

property and include it in the page

Using JavaBeans

Developer

Works with

Java & HTML

Web-Designer

Works with

designer tools

JSP Page

JavaBeans Component

(logic)

Mortgage Calculator Example

MortgageCalcBean

/**

* A JavaBean component for calculating a mortgage * monthly payment

*/

public class MortgageCalcBean implements Serializable { // The requested amount of the loan

private double loanAmount; // The annual interest private double interest;

// The requested period of the load in years. private int years;

(8)

MortgageCalcBean

public double getLoanAmount() { return loanAmount; }

public void setLoanAmount(double loanAmount) { this.loanAmount = loanAmount;

}

public double getInterest() { return interest; }

public void setInterest(double interest) { this.interest = interest;

}

Setter/Getter methods, define the

properties of the bean

MortgageCalcBean

public double getMonthlyPayment() {

double monthlyPayment = calculateMonthlyPayment(); return monthlyPayment;

}

private double calculateMonthlyPayment() { double monthlyInterest = interest * 0.01 / 12; int months = years * 12;

double debt = Math.pow(1+monthlyInterest, months); double monthlyPayment = loanAmount*debt*monthlyInterest/(debt-1); monthlyPayment = Math.floor(monthlyPayment*100)/100.0; return monthlyPayment; } }

Read only property to return the result

mortgage_calculator.jsp

<%@ page contentType="text/html" %>

<h1 align="center">Simple Mortgage Calculator</h1> <p>

Below is a simple calculator for calculating the monthly payment of the mortgage. Please enter the required loan amount, the interest you expect to get for the loan and the period of the loan in years; then press the 'calculate' button.

</p>

... tabs, tables to enhance the look of the page

mortgage_calculator.jsp

<jsp:useBean id="calc" class="MortgageCalcBean"/> <jsp:setProperty name="calc"

property="loanAmount" param="loanAmount"/> <jsp:setProperty name="calc" property="interest" ... <jsp:setProperty name="calc" ...

<form method="POST" action="mortgage_calc.jsp" > Amount: <input type="text" name="loanAmount"

value="<%=calc.getLoanAmount()%>"><br> Interest: <input type="text" name="interest"

value="<%=calc.getInterest()%>"><br> Years: <input type="text" name="years"

value="<%=calc.getYears()%>"><br> <input type="submit" value="Calculate"> </form>

Monthly Payment $

<jsp:getProperty name="calc" property="monthlyPayment"/>

Packaging

• A web-application consists of many

elements

– Static HTML pages and resources

(images, clips, ...)

– JSP pages and tag-libraries

– Servlets, Java classes, JARs

– Configuration files (descriptors)

Packaging

• J2EE defines a standard form for

packaging web-applications

– The packaging unit is called a web-module

– It has standard folder structure and

contains standard descriptor files

– The module is packaged as a WAR file (Web

Achieve) – essentially a zip of the folder

– It can either be packaged standalone or as

part of a J2EE application together with

other web modules and ejb modules

(9)

Packaging

Example

resources

libraries

required

by JSTL

web-pages

JSP & static

Servlet and

supporting classes

tag library

definition

for JSTL

web application

descriptor

JBoss specific

web application

descriptor

web.xml

<web-app> <servlet> <servlet-name>CourseListServlet</servlet-name> <servlet-class>CourseListServlet</servlet-class> </servlet> <servlet-mapping> <servlet-name>CourseListServlet</servlet-name> <url-pattern>/course_list</url-pattern> </servlet-mapping> ... <env-entry> <env-entry-name>jdbc/IDCDB</env-entry-name> <env-entry-value> !org.gjt.mm.mysql.Driver!jdbc:mysql://localhost:... </env-entry-value> <env-entry-type>java.lang.String</env-entry-type> </env-entry> </web-app>

application.xml

<?xml version="1.0" encoding="ISO-8859-1"?>

<!DOCTYPE application PUBLIC '-//Sun Microsystems, ... <application> <display-name>Examples</display-name> <module> <web> <web-uri>examples.war</web-uri> <context-root>/examples</context-root> </web> </module> </application>
