Backup of data residing on Open-E Data Storage Software with Backup Exec

(1)

(2)

1. Hardware configuration

2. Settings of backup agent on DSS V6

3. Configure the „Backup-to-disk Folder”

4. Logging on the accounts in „Backup Exec”

5. Creating a backup job

T

O SET UP BACKUP

,

PERFORM THE FOLLOWING STEPS

:

(3)

LAN End User Workstation Backup End User Workstation

Backup & Restore with regular backup software (Backup Exec of Symantec)

Backup of data residing on DSS with Backup Exec

1. Hardware configuration

(4)

Backup of data residing on DSS with Backup Exec

2. Settings of backup agent on DSS V6

After logging on the DSS V6 please go to

„CONFIGURATION” -> ”NAS

settings”. In Backup agent settings function, in field

„Backup agent”, please select „backupexec” and enter the Password. In order to confirm click apply button.

(5)

Backup of data residing on DSS with Backup Exec

3. Configure the „Backup-to-disk Folder”

Backup Exec Server

Under „Device” tree, select „Backup-to-Disk-Folder”

In this filed hit right click then click on „Backup-to-Disk

(6)

In „Backup-to-Disk Wizard” select „Create a new

backup-to-disk folder” and click

„Next” to confirm.

Backup of data residing on DSS with Backup Exec

3. Configure the „Backup-to-disk Folder”

(7)

Next select „Backup-to-disk

folder” and click Next to

confirm.

Backup of data residing on DSS with Backup Exec

3. Configure the „Backup-to-disk Folder”

(8)

Next enter a name for the backup-to-folder. In this example „Backup-to-Disk

Folder 1” and click Next to

confirm.

Backup of data residing on DSS with Backup Exec

3. Configure the „Backup-to-disk Folder”

(9)

In this step enter a name for the backup-to-folder and click Next to confirm. In this example data will be backedup on folder

„C:\Backup”.

Backup of data residing on DSS with Backup Exec

3. Configure the „Backup-to-disk Folder”

(10)

If you want to Allocate the maximum size for „Backup-to-disk file”, check Yes or leave it as No and click Next to confirm.

Backup of data residing on DSS with Backup Exec

3. Configure the „Backup-to-disk Folder”

(11)

In case you didn't choose option "Allocate the maximum size „backup-to-disk file“ you have to define the size in GB manually and click Next to confirm.

Backup of data residing on DSS with Backup Exec

3. Configure the „Backup-to-disk Folder”

(12)

In this step Enter the maximum number of concurrent jobs and click Next to confirm.

Backup of data residing on DSS with Backup Exec

3. Configure the „Backup-to-disk Folder”

(13)

In this window Backup Exec program will display a summary of settings for "backup-to-disk folder". If these settings are correct, click Next to confirm.

To make changes, click Back.

Backup of data residing on DSS with Backup Exec

3. Configure the „Backup-to-disk Folder”

(14)

Your changes will be applied after you click Finish.

Backup of data residing on DSS with Backup Exec

3. Configure the „Backup-to-disk Folder”

(15)

In menu Network select „Logon Accounts…”

Backup of data residing on DSS with Backup Exec

4. Logging on the accounts in „Backup Exec”

(16)

In new windows you can modify the logon account credential used by Backup Exec to access network resources. In case of adding new accounts please

Backup of data residing on DSS with Backup Exec

4. Logging on the accounts in „Backup Exec”

(17)

Backup of data residing on DSS with Backup Exec

4. Logging on the accounts in „Backup Exec”

In „Add Logon Credentials” window enter „User name”, in this case „ralus”, and the password then click OK

(18)

Backup of data residing on DSS with Backup Exec

4. Logging on the accounts in „Backup Exec”

New Account "ralus" was created. Click "OK" to finish

(19)

Backup of data residing on DSS with Backup Exec

5. Creating a backup job

Backup Exec Server

(20)

Backup of data residing on DSS with Backup Exec

5. Creating a backup job

Backup Exec Server

Please right click on "User defined Selection" field and then choose "Manage

(21)

Backup of data residing on DSS with Backup Exec

5. Creating a backup job

Backup Exec Server

(22)

Backup of data residing on DSS with Backup Exec

5. Creating a backup job

Please right click on

„192.168.0.220” field and then choose „Connect As..."

(23)

Backup of data residing on DSS with Backup Exec

5. Creating a backup job

Please select "ralus" account from the list and click OK to confirm.

(24)

Backup of data residing on DSS with Backup Exec

5. Creating a backup job

Next press F5 key to refresh.

(25)

Backup of data residing on DSS with Backup Exec

5. Creating a backup job

Backup Exec Server

(26)

Backup of data residing on DSS with Backup Exec

5. Creating a backup job

Backup Exec Server

(27)

Backup of data residing on DSS with Backup Exec

5. Creating a backup job

Backup Exec Server

After expanding branches of tree folders, on the right part of the window will appear folders of Data Storage Software (DSS). After connection has been established, at the server level you will be presented with a list of folders to be backed up. Please note that only the

shares folder is a valid backup

source or destination - it contains all your shares. Please check the box with

(28)

Backup of data residing on DSS with Backup Exec

5. Creating a backup job

Backup Exec Server

(29)

Backup of data residing on DSS with Backup Exec

5. Creating a backup job

Backup Exec Server

(30)

Backup of data residing on DSS with Backup Exec

5. Creating a backup job

Backup Exec Server

In this field you can enter a name for backup job. You can change backup job name or leave it as “default“ assigned name. In order to confirm click

(31)

Backup of data residing on DSS with Backup Exec

5. Creating a backup job

Backup Exec Server

In this field you can select a device backup your data. In this example select

(32)

Backup of data residing on DSS with Backup Exec

5. Creating a backup job

Backup Exec Server

In this place you can choose whether to append to or overwrite available media. In this example select default options.

Please configure next

selections accordingly to your backup requirements. Please refer to Backup Exec User Manual for more details. In order confirm please click

(33)

Backup of data residing on DSS with Backup Exec

5. Creating a backup job

Backup Exec Server

You can choose a method to use backed up files. In this example select default option. In order to confirm please click

(34)

Backup of data residing on DSS with Backup Exec

Backup Exec Server

You have completed the Backup Wizard and

successfully created a backup job. If you want to run the job now please click Finish.

(35)

Backup of data residing on DSS with Backup Exec

Backup Exec Server

After clicking Finish button on the right part of the window, there will appear info about backup status. Status is „In

use”.

(36)

Backup of data residing on DSS with Backup Exec

Backup Exec Server

Next, select „Job Monitor”.

The configuration and

testing backup of the data

residing on DSS with

In „Job list” you have info about active jobs.

(37)
