Model:
Description:
Voltage:
Shipping Dimensions:
Unit Weight:
Shipping Weight:
MIM452 Modular Ice Maker 120V/60Hz/1Ph, 220V/50Hz/1PhUnit Dimensions:
Ice Cube Size:
Ice Type:
130 lb / 59 kg Slab Cube
148 lb / 67 kg
FEATURE LIST
The MIM452 is an extremely reliable and efficient commercial ice maker that produces up to 460
pounds of ice per day. Stainless steel construction provides durability to a unit that is low-maintenance
and easy to clean. The unit produces crystal clear ice cubes that work great for applications in
restaurants, bars, hotels, grocery stores, and more. Stackable with optional kit. This model is NSF
and UL approved for commercial use.
Project Name:
Location:
Item:
Qty:
Model:
Model
MIM452
Modular Ice Maker
Model
MIM452
30” W x 24” D x 21” H 762mm W x 610mm D x 533mm H¾” x ¾” x 1”
19mm x 19mm x 25mm 32” W x 26” D x 22” H 813mm W x 660mm D x 559mm H(Shown on bin, model MIB400, which is not included.) Model MIB400 dimensions: 30” W x 31 1/2” D x 40” H 762mm W x 800mm D x 1016mm H
PLAN VIEW
Up to 460 lb (209 kg) daily ice production
(based on 50/70° F)
Produces crystal clear slab ice cubes
Stainless steel exterior
Advanced electronic controls
Easy to use automatic cleaning setting
Air-cooled condenser
Stackable with optional kit
Designed for commercial use
Easily mounted on ice bins
(ice bin not included)
Requires use of a drain. Water filter
recommended.
MAXX ICE
3355 Enterprise Avenue Fort Lauderdale, FL 33331 Tel: 954.202.7336 www.thelegacycompanies.com
Model
MIM452
30” W 762mm 21” H 533mm 24” D 610mm Control panel Access box Power switch Water inlet(3/8” FPT) Water outlet(1/2” FPT) Connectors Ice storage bin Drain outletBack Side
Model ShapeIce
Ice Production 24 Hours
Power Usage kWh/100 lbs. @90°Air/70°F Water Usage / 100 lbs. 45.4 kgs. of Ice 70°Air/ 50°F Water 90°Air/ 70°F Water 1 Ph Potable Water MIM452 dice 460 lbs. 368 lbs, 7.1 kwh/100 lbs. 16 Gal.
206 kgs. 164 kgs. 60.6 L
Specifications
762
530
Model:
Description:
Shipping Dimensions:
Shipping Weight:
MIB400 Ice Storage Bin
Unit Dimensions:
163 lb / 74 kg
FEATURE LIST
The MIB400 is a durable ice storage bin that holds up to 430 pounds of ice. A foamed in place
insula-tion design paired with a poly liner results in long-lasting ice. The ice bin features all stainless steel
con-struction and an easily accessible hinged door.
Project Name:
Location:
Item:
Qty:
Model:
Model
MIB400
Ice Storage Bin
Model
MIB400
PLAN VIEW
Stores up to 430lb (195 kg) of ice
Poly liner for increased insulation
Stainless steel exterior
6" Adjustable stainless steel legs
CFC Free foamed in place insulation
Easily accessible stainless steel door
Designed for commercial use
For use with all standard 30-inch modular
ice makers
Requires use of a drain
MAXX ICE
Warranty Coverage
Limited Warranty
THE LEGACY COMPANIES (TLC) warrants to each original Buyer that its products be free from defects in materials and workmanship for the period specified below. THE LEGACY COMPANIES obligation under this warranty shall be limited to repairing or replacing, at its option, any part or product found to be defective within the specified warranty period.*
Models MIM50 - MIM1000 – 2 Year Parts & Labor*** 3 Year Extended Compressor (Part Only) Warranty**
3 Year Extended Evaporator (Part Only) Warranty ****
Notes:
* Warranty subject to verification by The Legacy Companies
** Compressor, part only, will be replaced one (1) time during the extended warranty period. This extended warranty does not
apply to any electrical components, condenser, evaporators, fan motors, overload switch, starting components, temperature controls, dryer, accumulator, travel, labor charges, other supplemental charges or supplies which are covered by our standard warranty.
*** Two (2) Year Parts & Labor Warranty requires proof of an approved water filtration system at the time of installation and proper maintenance of this
system according to manufacturer’s recommendations. If Filtration System is not installed, the Warranty will be 1 Year Parts & Labor.
**** Three (3) Year Extended Evaporator Warranty requires proof of an approved water filtration system at the time of installation and proper
maintenance of this system according to manufacturer’s recommendations. Evaporator warranty may be void if the ice maker was cleaned with any product other than “Nickel-safe ice machine cleaner”.
Warranty Claims
Warranty claims can be made by calling 1-877-368-2797 during normal business hours between 8:30am and 5:30pm Eastern, Monday thru Friday excluding Weekends and Holidays. Emergency warranty service claims can be made after hours, weekends and holidays by dialing 1-877-368-2797 and following the automated prompts. All claims must include: make, model number, serial number, proof of purchase (dated receipt), date of installation, authorized equipment dealer and all pertinent information supporting the claim prior to the issuance of a warranty claim number. At the time of a warranty claim, should on-site service be necessary, a service company will be dispatched to the location to facilitate repairs covering labor (during normal business
hours, premium or overtime service is not included) and appropriate travel. If during the warranty event the on-site technician
Product Returns
Product returned without an RMA or to Distributors and/or Dealers under the auspices of warranty, freight damage or other, prior to the review and authorization Management with the expectation of receiving a credit and/or payment for the same, is strictly prohibited and will become the sole responsibility of the party authorizing the transaction.
Warranty Exclusions
NO CONSEQUENTIAL DAMAGES: The manufacturer is not responsible for economic loss or special, indirect or consequential
including without limitation; loss or damage arising from food or product spoilage claims, whether or not on account of product failure.
WARRANTY IS NOT TRANSFERABLE: This warranty is not transferable or assignable and applies only to the original verified
purchaser.
NO IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR PARTICULAR SERVICE: There are no other warranties
statutory, expressed, or implied, except that which is specifically found on the website. These warranties are exclusive and in lieu of all other warranties including implied and merchantability or fitness of a particular purpose.
IMPROPER ELECTRICAL CONNECTIONS: The manufacturer is not responsible for the repair or replacement of failed or damaged
components resulting from electrical power failure, the use of extension cords, low voltage, or voltage drops to the unit.
IMPROPER USAGE: The manufacturer assumes no liability for parts or labor coverage for component failure or other damages
resulting from improper usage or installation or failure to clean and/or maintain the product as set forth in the Owner’s Manual provided with each unit.
CONSUMABLES: This warranty does not include and is not limited to items such as: water filter replacement cartridges, bin
drain line and electrical plug.
ADJUSTMENTS & CALIBRATIONS: Adjustments including calibrations, leveling, tightening of fasteners, or utility connections
normally associated with the original installation are the responsibility of the dealer or installer and not the responsibility of the manufacturer.
CONSEQUENTIAL DAMAGES: This warranty does not cover any defect due to, or resulting from, ordinary wear and tear,
handling, abuse, misuse, improper ventilation, or harsh chemical action, nor shall it extend to any product from which the serial number has been removed or altered, or modifications made by unauthorized service personnel or damage by flood, fire or other acts of God.
OUTSIDE NORTH AMERICA: This warranty does not apply to, and the manufacturer is not responsible for any warranty claims
made on products sold or used outside North America and or any territories of the United States of America.
Warranty Grace Period
Warranty coverage begins on the date of purchase from the manufacturer. The manufacturer offers an additional six (6) months grace period for warranty coverage to allow for storage and warehousing until such product can be sold. This additional grace period does not extend the end user’s warranty coverage. Exceptions to this policy will require authorization from the Manufacturer.
