PORT GAMBLE FOREST
HERITAGE PARK RIDE PARK AND STOTTLEMEYER TRAILHEAD
DEVELOPMENT
Civil Engineering Services
RFQ Number: 2020-143
December 31, 2020
Kitsap County Department of Administrative Services Purchasing Office 619 Division St.
Port Orchard, WA 98366
Subject: Kitsap County Request of Qualifications for the Development of Port Gamble Forest Heritage Park Ride Park and Stottlemeyer Trailhead Development # 2020-143
Dear Vicki:
Thank you for inviting Coffman Engineers, Inc. (Coffman) to propose our qualifications for the Port Gamble Forest Heritage Park Ride Park and Stottlemeyer Trailhead development project. We see ourselves as an extension of your team, approaching every project with the dedication and commitment to success that you do. Coffman brings many unique advantages for your project, including the following:
Parking Facilities and Trailheads: The Coffman team has a strong background in projects that include parking facilities and trailhead improvements. Our portfolio of work includes parks master planning, new parking facilities for multiple user types, restroom facilities, trailhead and pathway connections, and
wayfinding. We have engaged with state-, county- and city- run parks projects as both the prime consultant and subconsultant and their various shareholders, including Evergreen Mountain Mike Alliance, while blending in public spaces and preserving natural resources. We review all parking layouts for vehicle circulation, sight distance, pedestrian safety, mountain biking features such as tool benches, signage and ADA compliance.
Each of these opportunities has allowed us to look at not just one project site independently, but how the plan will integrate into an existing park environment. We will take this project from the inception to construction completion with efficiency and excellent customer service, while producing a quality project.
Roadway Design: Our project team has an extensive background working on projects that include formulating a vision of a proposed property and creating a flowing and thoughtful facility. Our experience includes access roads for parking facilities, maintenance routes, solar panel access, agricultural routes and staging areas, as well as urban frontage streets and improvements. Vertical and horizontal alignments are ley to cost efficient designs and stormwater management. Our team also has experience with running new water and sewer systems and commercial utilities within and alongside new roadway and access routes.
Kitsap County Experience: We have been working in Kitsap County for over 20 years on a variety of project types. Most recently, our civil team has completed several projects for Bremerton Housing Authority and Naval Base Kitsap (Bremerton, Keyport, and Bangor). Our team is familiar with the local and regional development criteria and Kitsap County stormwater strategies that are effective for this climate.
I will be your main point of contact for this selection process, as well as the project manager/principal-in- charge on the project. I have led multidiscipline teams on numerous projects with both private and public clients and look forward to leveraging my experience for this critical project. Please feel free to contact me if you have any questions or would like additional information about our team.
Sincerely,
Allison Hazen, PE
Principal, Civil Engineering
Allison Hazen, PE | Primary Point of Contact, Project Manager, and Principal- in-Charge
Our proposed project
manager, Allison Hazen, has over 20 years of experience in land development and roadway design. She has successfully served as the prime consultant on hundreds of development projects; advising owners on maximizing land development potential, implementing cost-effective solutions, and leading efforts to swiftly procure zoning entitlements and construction permits.
Through her years of experience, Allison has excelled at site layout design for a wide variety of projects including new parking lots with trailhead access, master planning, and phased construction. Her vision of your trailhead parking areas echoes her previous experiences in developing land that not only considers need for highly functioning traffic flow and pedestrian safety, but also in using conservative footprints and low impact development strategies. She also understands the site development piece of a project like yours and how roadways and site design must work in harmony, in order to create a highly operational end product.
For your project to be completed
successfully, Allison realizes that effective coordination is key. It is critical to openly communicate with you from project onset to clearly establish timelines and expectations. We will guide you through our process while making sure your needs are the focus of our attention.
We understand finding the right team that has worked on similar projects, with experience working in Kitsap County, and the ability to deliver on your unique project goals can be challenging. Our team has the knowledge and experience working in Kitsap County, as well as working together on dozens of similar projects. We are committed to providing proactive coordination, effective communications, and quality control standards to your project with a cohesive and coordinated approach through our proposed project team. For this contract, we have committed the following team members for the duration of the project:
STAFF QUALIFICATIONS
Wendy McHugh | Lead Engineer Wendy will serve as the lead engineer for this project. Wendy has significant experience in site development and utilities for similar projects. She has substantial experience with land development projects in Kitsap County and many other smaller cities in the Puget Sound region. Wendy often works on projects that require public utility and access improvements to make them successful.
Carston Mortenson | QA/QC Manager
Carston will serve as the QA/
QC manager for this project.
Carston has a background in public transit, capital improvements, and master planning.
His design experience includes a wide variety of projects from recreation and park-and-rides, to restrooms and bus stops.
Ricky Wang | The Riley Group | Geotech Engineer
Your project will also require a geotechnical engineer to collect soil borings and conduct infiltration testing. We are proposing Ricky Wang from The Riley Group to fill this role as he is a trusted teaming partner who has provided these services for several Coffman projects.
“The Coffman team exhibited excellent
communication skills and worked efficiently and seamlessly with the other consultants we have on this project and this was reflected in the quality of their work and final report.
Larry Van Horn | Facilities Director, Island County, WA
ALLISON HAZEN, PE PIC, PROJECT MANAGER
• Primary point of contact
• Project management duties
• Civil engineering solutions
• Permit application
• Schedule driver
• Budget oversight
CARSTON MORTENSON, PE QA/QC MANAGER
WENDY McHUGH, PE LEAD ENGINEER
RICKY WANG, PHD, PE, GE
GEOTECH SUBCONSULTANT
• Civil engineering
• Soil erosion control
• Stormwater calculations
• Utility design
• Manage Quality Assurance Plan
• Develop project specific QC checklist
• Review code compliance and documentation
ORGANIZATIONAL CHART
Below is an organizational chart detailing our proposed team's structure for the project.
While our team's individual project experience is important, of greater importance is their experience working together. Our team provides you seamless project coordination applying collective knowledge from their collaboration on numerous public works projects.
MIRO BOSILKOV SR. DESIGNER MICHAELA GEHN
SR. DESIGNER
*Please see key personnel resumes in Appendix
• Plan set management
• Access road design
• Parking lot optimization
• Vehicle circulation analysis KAITY BRECHT, E.I.T.
PROJECT ENGINEER
ADDITIONAL COFFMAN CIVIL RESOURCES 19 CIVIL ENGINEERING TEAM MEMBERS IN WA STATE
• Site layout
• Grading modeling
• Engineering support
• Field testing
• Sample analysis
• Geotechnical recommendations and guidance report generations
The following is Coffman's understanding of your project and how we will approach it based on the scope of services outlined in the RFQ. We have also included how our team will manage the work during COVID-19 related restrictions and during construction activities, as well as, an outline of our
proposed schedule of activities:
Project Understanding
Our understanding is that the goal of this project is to provide complete civil engineering services for two development areas of Kitsap County’s Port Gamble Heritage Park. The park covers nearly 3500 acres with over 65 miles of trails and includes conservation areas, water access, and a variety of recreation areas.
The project locations are at the north end of the park near the town of Port Gamble and the south end of the park about halfway between Port Gamble and Poulsbo off of SR-307. Each location requires a new parking lot and supporting design features specific to the park function they will serve. Both locations will have their own functional desires, design challenges, and considerations.
For the first site location at the north end, the County envisions new facilities for the popular mountain bike ride park and multi-use trails. The new facility will consist of a highly functioning parking lot for approximately 75 vehicles, access road, and installation of prefabricated restroom facilities. The access road will include a non-motorized element to serve vehicles, pedestrians, bicyclists, and equestrians, as needed, and will be positioned within an easement granted by Rayonier. Utility planning is also a vital piece for this location. Our team will work closely with Kitsap County to determine the best method of water supply and sewage disposal for the new restroom facility.
The second project location is at the south end of the park at the Stottlemeyer Trailhead. This location will require 25 parking stalls. Signage for user wayfinding will be key at this location as it will include a link to the Sound to Olympics Trail.
Other features that will also be considered for both locations are the needs for
adhering to the park’s master plan, tree preservation, park user connections to recreational trails, low impact development, and pedestrian and vehicle safety.
We also understand that Port Gamble Heritage Park has a wide variety of groups that take interest in the park such as neighbors, recreational users, Tribes, and conversationalists. We will engage with these groups, as needed to gain consensus and coordinate project elements with their needs and goals.
Schedule
After reviewing the schedule proposed by the county, we noticed the timeframe of the design does not allow for the complete reviews of conceptual plans, 30%, 60%, and 90% progress sets, as we would typically suggest. Your input is critical to the project.
We have proposed a thorough conceptual phase to allow the County and stakeholders an opportunity to participate and influence the project from its inception. We also recommend advancing directly to the design to a 60% completeness and issue the package to your team to review while we continue with completing the design package to submit for permits (90%), so we can keep the schedule on track. The 100% issue set will include all permit review comments addressed. We assume the topographic survey will be complete and available at the project kickoff and that the geotechnical information will be available by 90% complete for permit submittal. Below we describe the steps of this process.
PROJECT APPROACH
Project Approach
To efficiently measure progress and effort, we are proposing to manage the project by separating the it into two packages: The MTB Ride Park development, bathroom, and parking area at the north end of the park; and The Stottlemeyer Trailhead Development including parking and signage. For consistency and efficiency, each package will be managed by a single project manager, Allison Hazen, and have the same lead engineer, Wendy McHugh.
This will avoid duplicated effort and capture the benefits of a comprehensive evaluation.
We have used this approach effectively on several past projects of similar size and scope.
We elaborate more on the specific
approaches and challenges for each step in the following pages. The essential elements of methodology used for this project are:
• Kickoff Meeting
• Assessment of Existing Records
• Site Investigation/Site Visit
• Geotechnical Investigation and Report
• Review of Survey, Environmental Reports
• Review Master Planning and Programming
• Confirm Utility Systems Availability
• Produce Conceptual Plans for Each Location
• Engage with Stakeholders
• Calculate Utility Demand Projections
• Produce Phased Design (Conceptual, 60%, 90%)
• Procure Permits
• 100%Issue for Construction Drawings
• Provide Bid Assistance
• Provided Construction Assistance
Kickoff Meeting
During this first meeting, we will meet with key Kitsap County team members to:
• Discuss Kitsap County’s vision for the new parking facilities
• Clarify project expectations
• Discuss and review the park’s master plan with the Kitsap County Team including any updates
• Discuss any required zoning entitlements
• Establish project objectives and criteria for:
» Verifying development standards for this project scope
» Defining access road/path configuration and standards
» Water availability or alternate options
» Sanitary availability or alternate options
» Stormwater management criteria and low impact development
» Any commercial utilities and expectations
» Pedestrian, mountain bike and equestrian considerations
» Discuss wayfinding needs
• Engage with the County to understand the details of their permitting process
• Customize the project work plan
• Verify all existing documentation to start the evaluation process
• Plan engaging with geotechnical consultants
• Discuss cultural resource needs
• Identify potential challenges
• Verify the project schedule
• Establish next steps and timeframes
• Clarify project stakeholders and establish lines of communication between the County and our consultant team
During the kickoff meeting, we will discuss if the prefabricated restroom facility requires utilities services or if a pit latrine style is intended. If the facility needs utility connections, we understand that this general area has public water and sanitary services. We will discuss the proximity of the proposed north parking area to available public utility sources. If public utilities are not an option for this site, our team has experience working with designing Group A water systems, well designs, pit latrines and septic field designs. We can help the County determine the best option for the new restroom facilities, including cost, schedule, long-term maintenance, and life span.
15% Conceptual Design
After the kickoff meeting, we will begin the design process by preparing a conceptual design for each project location to gain feedback before we proceed to detailed design. During this phase we will:
• Release the geotechnical engineer
• Review the provided survey and incorporate into the design software
• Review any available environmental reports and tree surveys
• Review all code requirements
• Assess existing records
• Review master plan to make sure the proposed access road at the north site will allow the needed flexibility and minimize disturbance to the existing area
• Review master plan to identify any other features that may be needed and/or future development considerations
• Engage with stakeholder groups, including Evergreen Mountain Bike Alliance
• Prepare conceptual plans for each location and submit fo County project team and permit staff review.
• Avoid significant trees where possible
15% Review Meeting
Our team will meet with Kitsap County project team and County permitting agent team to discuss the conceptual plan layouts and gain any additional feedback before proceeding to the next design phase.
Kitsap County Zoning Entitlements Although not expected, if the County permitting staff has identified any need for this project to undergo any entitlements applications, Coffman will drive the process by producing the required packages and engaging with the County to obtain the required approvals. We will incorporate any County permitting staff comments from the 15% review meeting into this package to present to the County project team.
60% Design Development
With the feedback from the County groups for our 15% plans, we will proceed to 60%
Design Development. During this phase, our team will produce demolition, temporary soil erosion control (TSEC) plans and provide plan details for site improvements, wayfinding, grading, storm conveyance piping, infiltration features, and prepare detail sheets to round out the 60% plan set for both project sites. We will base the wayfinding signage on established styles and methods in the park, for consistency and ease of the user. In addition to
developing plan sets, we will also provide a preliminary stormwater report and a table of draft specifications for both locations.
Philips Creek Trailhead PROJECT APPROACH
For the north project site, we will advance the design to build the road corridor in AutoCAD Civil 3D. We will perform traffic circulation analysis for safety and fold those discoveries into the layout. We will also progress the site design to clearly define the vertical and horizontal alignments of the new access road with non-motorized considerations, provide road profiles, size and grade the roadside ditches, size any culverts and identify the grading tie-in to the existing ground surface. We will include standard sections for the access road and detail the connection to the main road and to the parking lot. Our experience with campus planning and planned unit development has taught us that this is an important consideration early in the project, to avoid rework later in the design process, saving you time and money.
For the south project site, we will review traffic safety and sight distance for
entrance to the main road and fine-tune the parking lot circulation for both vehicles and pedestrians.
During the 60% design phase, our team will layout a schematic utility layout based on input from the County and commercial utility purveyors at both locations, as needed. During this phase, we will look at alternative energy options for the parking lot, wayfinding, and restroom lighting, as we believe solar lighting may be a reasonable option.
The prefabricated restroom facilities at the north project site will need to be reviewed to determine demand loading for water and sewer. If utility services are needed, it is prudent that these needs are carefully vetted with the County to make sure the system has capacity to provide the services.
We will design a safe system that is sized properly, as well as size and detail the sanitary system, water service with loading calculations for the new restroom facilities, and detail any desired future facility utility stubs to save you time and resources for future development. Overall, we will include the layouts for any commercial utilities that are desired for this project.
Your project will require evaluation of low impact stormwater solutions, both in the work of the access road and at each parking lot. Since this area is part of the aquifer recharge area, we anticipate stormwater will be directed to infiltration areas (above or below ground). This means our proposed team will work with the County project team and County permitting staff to determine which solutions are feasible and workable into our plan.
60% Review Meeting
The 60% review meeting for your project is important because is it allows us to meet with Kitsap County to discuss the design progress and updates to the concept plans for utility services. Our team is well equipped to provide any alerts that the County’s utility systems may not meet the project’s needs by capturing those concerns in our living issues log. This allows us to provide you with organized, actionable solutions and alternative sources and methods, depending on the findings. Our team will also engage with the County permitting staff and stakeholder groups, where appropriate, to allow them an opportunity to provide input and guidance for any alternative solutions. This creates productive lines of communication and makes sure your project has appropriate influence from key stakeholders.
90% Construction Documents The Coffman team will further develop the design to provide final documents for permit application. The County project team’s review comments of the 60% design will be incorporated as we bring the design to 90% complete. During this phase we will:
• Update and finalize north project site access road design
• Update and finalize stormwater, water, and sewer systems
• Produce needed utility profiles
• Finalize demolition, TESC plans, and engineering details
• Finalize the utility loading calculations
• Provide the final stormwater report with infiltration rate data confirmed
• Prepare all needed specifications
• Provide a full quality control check of the package
• Work with Kitsap County landscape restoration architect or engage with a subonsultant, if needed
90% Review Meeting
Coffman will meet with the Kitsap County team to review the 90% package, clarify design, and review modifications proposed by the County for quality assurance.
Permitting
Coffman will prepare all applications for the needed permits for all Authorities Having Jurisdiction (AHJs) and proactively lead the process with the reviewing parties.
For this process, we will submit our 90%
construction documents after addressing any final County project team comments.
We will complete all applications and revise the plans to resolve any comments from the AHJs to procure your construction permits.
The permitting process may also require contributions from a cultural resource specialist. We can easily work with any cultural resource specialist selected by Kitsap County or engage with SWCA Environmental Consultants, a trusted teaming partner.
100% Design (IFC)
The 100% set will be utilized to pick up any review comments provided by the AHJ reviewers, as well as address any outstanding concerns by the County project team. Any revisions to the plans that were a result of the AHJ reviews will be vetted with the County prior to final submission to the AHJs for approval.
Quality Assurance / Quality Control (QA/QC)
Our outlook on quality is not something that is folded into a deliverable as the project draws to a close, but rather it is incorporated intentionally throughout the project from the start. We have an extensive internal QA/QC process, which is instrumental in formalizing the quality of our work and providing you with a successful project.
Goldendale Observatory
PROJECT APPROACH
Quality is a requirement of every project we deliver. By developing a custom Quality Assurance Plan (QAP) at project inception, we can meet this objective without
creating an unnecessary cost burden to Kitsap County. Coffman has adopted a documented QAP which assigns a QA/
QC reviewer for each discipline before the project begins. This project will be supported by project specific QC Checklists, that will be updated as the project evolves.
We will engage our QA/QC lead, Carston Mortenson, from the onset of the project to take part in identifying areas for coordination and developing the project specific checklists.
To emphasize the importance of quality for this project, we will set an internal QA/
QC submittal deadline. A full review by the QA/QC personnel and the project manager is performed while leaving ample time to incorporate comments and verify those comments were addressed prior to sending the deliverable to the County or AHJ. A final review is conducted by the project manager. For this project, the key elements of the Quality Control review process are as follows:
• The designated QA/QC reviewer will review the package for code compliance and complete documentation
• The project manager, Allison Hazen, will review the package for scope, County project goals, stakeholder input, key decision inclusions and design coordination
• Final QA/QC by the reviewer after implementation of QA/QC comments
• Allison will review the package for overall completeness
We have seen an increase of product quality at all levels, as the QA/QC reviewers help develop each project’s specific QAP and QC Checklists, which are used by all team members throughout the entire project lifecycle. The standard of quality is defined by a combination of the following influences:
• Code verification
• The documented understanding between the County and Coffman
• The industry standard of care
• The value that comes from experience and creativity
• Implementing successes and lessons learned from past projects
• Ownership of deliverables Bid Assistance
Coffman will be available to provide construction bid support for this project.
We are well-versed at providing bid support, attending the pre-bid meeting(s), and assisting with contractor selection. We have a strong background in helping clients with categorizing bid packages into Base Bids and Bid Alternative. This gives our clients significant value and helps them create a competitive bid and maximize available funds or create future construction
phases, if needed. We also understand that responsiveness and thorough pre-proposal inquiries are necessary to obtain clean bids from contractors, a critical step in the success of your project.
PG Heritage Park Hair Pin Feature
For this project, we can work with your team to decide if the project would benefit from soliciting the bids with 90% Issue for Permit review documents or include the revisions based on agency comments before
preparing the bid package.
Construction Phase
Coffman also provides construction assistance with all our design projects to see the project completely through to the end. Proactive participation in the pre- construction conference is a crucial piece to establishing solid partnership between the design team and the general contractor team. We view this meeting as an important step in handing off the production role of the project and passing our knowledge base to the construction team before breaking ground. We provide RFI and submittal review services, where quick responses are the standard, allowing you to avoid delays in construction. Coffman can also be available to conduct field visits, advise County on change orders, prepare change orders, perform punch list surveys, generate as- built drawings, review operations and maintenance needs with your staff and assist with the closeout of the project.
COVID-19 Restrictions and Safety At Coffman, safety comes first, and we take local guidelines and restrictions very seriously. The proposal project team members have a long history of working with clients all over the region, country, and world. Working with both internal and external project team members remotely is a practice that we have been accustom to for over 20 years. With the onset of a global pandemic, Coffman has been able to adapt quickly and seamlessly to working remotely with little impact to the efficiency of
projects. There are a few additional nuances that we needed to incorporate with the current COVID protocols, but we have found our methods to be successful.
We have incorporated video conferencing into many of our projects for both internal meetings and collaboration with our clients and any outside consultants, so we are still able to meet “face-to-face” and review plans and documents together.
Through screensharing and control features, any project team member may present, and multiple team members can mark-up a drawing together. We have also used Bluebeam Studio as a collaborative platform for sharing live pdf drawings that can be reviewed and redlined by any user at any time. Increased email and phone communication have also been effective for our team during these times where we cannot meet in person.
We meticulously follow CDC guidelines for social distancing, gathering, mask- wearing, temperature checking, and tracing procedures in addition to our usual personal protective equipment used at all site visits and construction sites. Being civil engineers, we are fortunate that our field work is almost exclusively outdoors, in line with our local COVID-19 safety guidelines.
Currently, we have active construction projects underway in Sequim, Blyn, and Black Diamond. We have been able to
efficiently partake in the construction phase using video and phone conferences, review site photos, electronic communications for RFIs, submittals and supplemental information sharing, and performing site visits to observe critical installations, assist with unforeseen conditions and conduct punch list surveys and punch list back checks. We have not experienced any delay in our team’s ability to swiftly respond to the needs of our general contractors and have kept the projects moving forward.
PROJECT APPROACH
GOLDENDALE OBSERVATORY STATE PARK, 2016 | GOLDENDALE, WA
Coffman provided civil, electrical and lighting design services for the new
observatory and visitor’s center. Civil scope included the design of razing the building and service utilities, new ADA compliant building perimeter sidewalks, new parking lot layout optimization, signage, grading and drainage, new water, fiber optics, mechanical trenching, power, electric and sanitary system layout. This project included a large septic field overhaul and Coffman was responsible for the layout of this system and its components. For grading and drainage, our team was
responsible for storm runoff collection and conveyance and the design of dispersion trenches throughout the site for low impact development. In collaboration with the interpretive exhibits’ designer, our team worked to wonderfully illuminate the exterior space with parking lot, ambient, and accent lighting, all in line with the dark- skies requirements.
GAS WORKS PARK COMFORT STATION, 2016 | SEATTLE, WA
Working with Seattle Parks and Recreation, Coffman provided civil, electrical and lighting design upgrades to Seattle's iconic Gas Work's Park. The redesign of the east entrance parking area, ADA assessments and remediation recommendations,
pathways and wayfinding, as well as a new
"comfort station" which provides restrooms and concessions to park users.
Our local teams have served clients in Kitsap County and the Olympic Peninsula for over 20 years, both with public projects and private work. We have completed several relevant parks parking lots and trailhead projects and many park and ride projects that require similar technical evaluations and design features in common with your project.
Goldendale Observatory State Park
GLENROSE MOUNTAIN BIKING TRAILHEAD PARKING LOT, 2017 |
SPOKANE COUNTY, WACoffman provided civil, structural,
electrical engineering, and land surveying, for the design of parking lot upgrades associated with the Glenrose Mountain Bike Trailhead for Spokane County. The facility has 20 parking spaces with an entry drive, bus parking, and pullout lane.
The challenging site required the design of retaining walls to integrate the new parking improvements into the existing conditions. Coffman consulting services for the site development included erosion and sediment control, earthwork, grading, stormwater management, pedestrian and vehicular circulation, site power, lighting, and provisions for future security cameras.
PRIOR EXPERIENCE
7 CEDARS CASINO HOTEL AND RV PARK & PLAY PARKING LOT, 2018- 2020 | BLYN, WA
Civil, electrical, lighting and water systems engineering and value engineering services for Phase 1 of the 95,000 sf 7 Cedars
Casino Resort master plan, which includes multi-phase resort conceptual layout, and the design and construction of a four-floor, 100-room hotel tower with new parking areas and front driveway arrival experience. The project also included a new separate 300+ vehicle parking area to accommodate overflow passenger vehicle and overnight RV parking for the casino with considerations for connections to the Olympic Discovery Trail. The civil work included site and parking lot layout, signage, demolition plans, soil erosion control, ADA design, grading, stormwater conveyance, water quality and both underground and open pond detention systems, low impact development, sanitary sewer (gravity and force main), water services, electrical service upgrades, undergrounding and relocation of power transmission lines, water and electrical services for RV parking, new site lighting, coordination of a new cross-connect water system and regional sanitary service,
incorporation of a frontage road closure and construction assistance.
MORAN STATE PARK SUMMIT VISITOR CENTER, 2019 | ORCAS ISLAND, WA
Coffman provided civil and electrical engineering and lighting design services from conceptual plans through the completion of construction. The project scope included a building expansion for new restroom facilities, parking lot improvements, ADA access improvements, improvements of site, landscape, trailhead access, wayfinding, lighting, stormwater management with low impact development strategies, and restroom utility services.PHILIPS CREEK MOUNTAIN BIKING TRAIL PARKING LOT, 2020 | SPOKANE
COUNTY, WACoffman provided civil and electrical engineering, as well as land surveying, for the design of parking lot upgrades associated with the Phillips Creek Mountain Biking Trailhead for Spokane County. The facility has 20 parking spaces with an entry drive and a bus drop off and pick-up area.
Coffman consulting services for the site development included demolition plans, erosion and sediment control, earthwork, grading, stormwater management, pedestrian and vehicular circulation, site power, lighting, and a webcam for security.
VETERANS PARK NORTHERN STATE RECREATION AREA, 2017 | SEDRO-
WOOLLEY, WACivil engineering services for the design of drainage system repairs to the existing parking area at Veterans Park within the Northern State Recreation Area. The parking area was redesigned improve vehicle maneuvering and safety and to eliminate a flooding problem. Coffman devised a solution to redirect the stormwater back into an underutilized drainage ditch and also to disperse areas across the existing lawn areas using low impact development techniques. A conceptual design for future expansion of the parking area and addition of sports facilities were also provided to further develop the park’s master plan of this area. The project also included consulting services for parking lot materials to fit within the park’s project budget. This included a phased construction plan to install a gravel parking area that can be converted to a paved parking area in the future once funds become available.
JAMESTOWN S'KLALLAM TRIBE, HEALING CAMPUS LONG-TERM MASTER PLANNING - OUTPATIENT CLINIC, 2019-PRESENT | SEQUIM, WA
Coffman provided civil engineering services for the Jamestown S’Klallam Tribe’s Healing Campus. The project began with long- term master planning by the architect with Coffman civil support to plan 40+ acres of land. The first design phase of this project, currently under construction, is a 17,000 square foot medication assisted treatment facility, parking facility, drainage areas and a meditation pathway.The design team collaborated with
numerous stakeholders to develop a design concept that would support patients on their healing journey. This design concept is expressed through the use of natural and local materials and through the integration of tribal art, the signage, and the landscape design.
The master planning phase included producing conceptual site layouts with input from the Tribe, public road layouts, public utilities, vehicle maneuvering analysis, planning sessions with the client group and city staff, negotiating project requirements with the city staff, attending public meetings and zoning entitlement assistance. The first phase of the full design scope was the medical clinic building, reflection pathway, parking lot and site utilities, two new public streets with sidewalks and street trees, public gravity sanitary main, public watermain, electrical and telecom transmission line undergrounding, stormwater management (pipes, ditches and bioretention systems), relocation and hard-piping of the existing open-channel irrigation ditch, landscape, site lighting and construction assistance.
7 Cedars Hotel and Casino
Jamestown S'Klallum Tribe Clinic Building
STA INDIAN TRAIL LAYOVER RESTROOM, 2015 | SPOKANE, WA
Coffman provided survey, civil, andelectrical engineering services as the prime consultant for Spokane Transit Authority (STA). The project involved the addition of a concrete pad and prefabricated restroom to STA’s existing layover and turn around at the north end of Indian Trail Road. The project also included extension of power, domestic water, and sanitary sewer services to the restroom. The project consisted of a topographic survey and preparation of plans, specifications, cost estimate, bidding assistance, and construction administration. This project was bid and constructed in 2015.
APPENDIX
Years of Experience: 20
Education BS Civil/Environmental
Engineering; Michigan State University; 2000
Professional Licenses Washington; Civil; #45458
Professional/
Community Activities American Council of Engineering Companies
Land Development Coalition Executive
Committee Design Build Institute of
America Member Seattle Lean-In A/E/C
Chapter Co-Chair
Professional Experience
Allison has more than 20 years of experience in civil engineering, focused on project management, land development, existing facility conditions assessments, site investigations, site layouts, zoning entitlements, ADA compliance, grading, stormwater analysis and system design, utility designs, roadway design, permit procurements, and construction assistance. With proficiency throughout these project phases, her land development experience includes park and trailhead projects, municipal projects, government facilities, entertainment facilities, mixed-use, small- and large-box commercial, national and international retail programs, shopping centers, industrial projects, off-site frontage improvements, utility upgrades, and ADA- centric projects.
Project Experience
Moran State Park - Summit Visitor Center | Orcas Island, WA Senior project manager for the design of the Phase 1 work for Summit Visitor’s Center positioned at the top of Moran State Park.
The scope included a building expansion to house the new restroom facilities, parking area upgrades, exterior ADA upgrades, trailhead connections and signage, storm conveyance and infiltration pit drain, new water and sanitary sewer services, and RV concessions services considerations. Allison was responsible for the updated parking lot layout and grading to create ADA compliant parking stalls and aisleway, as well as an ADA compliant sidewalk to the new restrooms.
She also performed quality control for vehicle maneuverability analysis, the design for the storm, water and sanitary utilities and the project as a whole.
Goldendale Observatory State Park | Goldendale, WA
Civil engineering QC reviewer for the Goldendale Observatory State Park Visitors Center renovation and expansion. The observatory and site had not been upgraded in 46 years. Coffman provide pre-design and schematic design of several concepts. For the full design, the civil scope included site layout for the building and parking lot expansion, ADA access improvements, soil erosion control, new water services including a meter, booster pump and service leads, new power and telecom utilities, storm collection and stormwater management dispersion design, sanitary conveyance, septic drain field layout, septic components layout and connections, equipment pads, grading, and stormwater management of the drain field. Allison's role was to lead design strategy and review the plans for completeness, design compliance and multidiscipline coordination.
Project Experience Continued
Gas Works Park Pre-Design Study and ADA Self-Storage | Seattle, WA
Civil engineer for predesign study for ADA access improvements, upgraded site lighting, and new comfort station. Allison was responsible for the ADA self-evaluation of parking area, pathways, restrooms and concession approaches, picnic table area, the playground barn access, and shelters.
She also was responsible for ADA access remediation recommendations, working closely with the project architect and the Seattle Parks and Recreation Department.
Bremerton Housing Authority On-Call | Bremerton, WA
Project manager and lead civil engineer for the Bremerton Housing Authority properties and offices.
Recent projects include a sanitary lift station and forcemain upgrade, new playground areas, low impact development consulting, corrections to areas experiencing drainage issues, trash enclosures and treatment, and a new sanitary sewer project. The projects all required permitting through the City of Bremerton and Kitsap County standards.
Jamestown S'Klallam Tribe Outpatient Clinic | Sequim, WA
Project Manager and civil engineering quality control reviewer for the Tribe's new 18-acre, multi- phase Healing Campus. The project consisted of both master planning phase and full design phases.
The master planning included producing conceptual site layouts, public road layouts, public utilities, vehicle maneuvering analysis, planning sessions with the client group and city staff, negotiating project requirements with the city staff, attending public meetings and zoning entitlement assistance. The first phase of the full design scope was a 17,000 sf medical building, parking lot and site utilities, two new public streets (horizontal and vertical alignments, cross-sections), public gravity sanitary main, public watermain, electrical and telecom transmission line undergrounding, and stormwater management (pipes, ditches and bioretention systems), permitting, bid assistance and construction assistance.
ALLISON HAZEN, PE
Principal, Civil Engineering, Project Manager
Jefferson Healthcare Emergency Department Expansion | Port Townsend, WA
Senior civil engineer, ADA compliance specialist and QA/
QC engineer for a 50,000 sf, three-story hospital addition, including an emergency department expansion and other specialty services. The project involved parking lot layout concepts with extreme grading conditions along the ambulance travel path, retaining walls, ADA features both on-site and public right-of-way, utility rerouting, stormwater analysis and design, and construction assistance.
Additional Project Experience
f 7 Cedars Casino Hotel and RV Park & Play Parking Lot | Blyn, WA
f Central Washington University ADA Transition Plan | Ellensburg, WA
f Island County Master Plan | Coupeville, WA f Gas Works Park Comfort Station | Seattle, WA
f NAVFAC X029 Command Records Storage | Bremerton, WA Jefferson Healthcare RESUMES
Years of Experience: 22
Education B.S. Civil Engineering;
University of Washington
Professional Licenses Washington; Civil; 2004;
#40502
Professional/
Community Activities American Society of Civil
Engineers American Council of Engineering Companies
Engineers Without Borders
American Public Works Association Northwest EcoBuilding
Guild Secretary
Professional Experience
Wendy’s 20+ years of experience is focused primarily on site development and utilities including site grading, stormwater management, erosion control, water, and sewer design. She has substantial experience with land development projects in King County, Jefferson County, Clallam County, San Juan County, Snohomish County, and many other cities and towns throughout Washington. Wendy has worked on various types of civil projects both large- and small- scale including parks, commercial, public buildings, residential and industrial.
These projects have often included the parking optimization, vehicle maneuvering analysis, access improvements and utilities work required to make these projects successful.
Project Experience
Moran State Park Summit Visitor Center | Orcas Island, WA
Civil engineer for the replacement of the learning center and restroom facility at the top of Mount Constitution at the north end of Moran State Park. This new building was built in phases beginning with the three stall restroom facilities, a water treatment system room to house the onsite treatment facility, and a mechanical room. The classroom and office spaces were built in phase 2. Water, sewer, power and communication services were installed for this facility from the services at the base of the mountain. The existing parking area was upgraded for ADA compliance and storm water was collected from the new building and parking area and dispersed with a rock pad before draining down the slope.
Goldendale Observatory State Park Visitors Center | Goldendale, WA Civil engineer for the design of the expansion and renovation of the observatory learning center and parking area at Goldendale State Park. Water, power, and communication services were installed for this facility from the services at the base of the mountain. Stormwater was dispersed using gravel trenches. A new onsite septic system was installed on the slope below the facility, routed between the existing rocks and trees which needed to be protected on this historic site.
Conceptual layouts for the parking area redesign were produced to accommodate multiple visitors as well as school buses for field trips to the observatory. Educational trails were constructed around the new facility to provide ADA access to the exterior viewing platforms.
Additional Project Experience
f 7 Cedars Casino Hotel and RV Park & Play Parking Lot | Blyn, WA f Jamestown S'klallam Tribe Outpatient Clinic | Sequim, WA f Skagit County Parks and Recreation
f Veteran's Park Northern State Recreation Area | Sedro-Woolley, WA
Years of Experience: 20
Education B.S. Civil Engineering;
North Dakota State University; 2000
Professional Licenses Washington; Civil P.E.;
2006; #42312 Idaho; Civil PE.; 2007;
#12543
Professional/
Community Activities American Society of Civil
Engineers West Plains Chamber of
Commerce
Professional Experience
Carston is a design and construction engineer with a background in transit, highway construction, residential subdivisions, and commercial sites. Carston is an experienced project manager and works on
projects from conceptual design through construction administration and close-out. His transit design experience includes a wide variety of projects, including parking lots and connections, passenger facilities, master plan studies, bus stop improvements, and park and ride improvements. Carston is experienced in leading multidiscipline projects, including many Transit Authority on-call projects and the recently constructed Kootenai County Riverstone Transit Center.
Project Experience
f Glenrose Trailhead Parking Lot | Spokane County, WA f Philip Creek Trailhead Parking Lot | Spokane County, WA f Indian Trail Layover Restroom | Spokane, WA
f Spokane Community College Transit Center | Spokane, WA f Spokane Falls Community College Transit Center | Spokane, WA f Riverstone Transit Center | Coeur d’Alene, ID
f Moran Prairie Park and Ride | Spokane Valley, WA f Jefferson Park and Ride Repairs | Spokane, WA f South Hill Park and Ride Ingress | Spokane, WA
f Mirabeau & Five Mile Park & Rides Real Time Signage | Spokane Valley, and Spokane, WA
f Spokane Transit Authority Bus Stop Standards | Spokane, WA f SFCC P-13 Parking Lot | Spokane, WA
f Plaza High Performance Transit Platforms | Spokane, WA f STA Boone NW Bus Garage | Spokane, WA
f Bella Terra Gardens Residential Subdivision | Spokane, WA f Wall Street Reconstruction | Spokane, WA
f West Geiger Boulevard Improvements | Spokane County, WA f Franklin & Star/Robinson Road Improvements | Nampa, ID f Southgate KXLY Master Plan / Binding Site Plan | Spokane, WA f Whitworth University Athletics Leadership Team Center | Spokane
County, WA
f STA Administrative and Maintenance Facility Master Plan | Spokane, WA
f Windsor Elementary Update | Spokane County, WA f Sunset Elementary Update | Airway Heights, WA f Prairie View Park | Spokane County, WA
CARSTON MORTENSON, PE
QA/QC ManagerRESUMES
Years of Experience: 24
Education PhD, Geological Engineering; University of
Arizona; 1994 MS, Geotechnical Engineering; China University of Geosciences
(Beijing); 1988 BE, Mining Engineering;
University of Science and Technology Beijing; 1985
Professional Licenses Professional Engineer (PE)
Civil Engineering: OR;
WA; CT; MA; MD; PA; DC;
VA; ID; MT; CA; UT Registered Engineering
Geologist (LEG), WA Licensed Geotechnical
Engineer (GE), CA; OR
Professional Experience
Dr. Wang has over 24 years of experience providing geotechnical and geologic engineering services throughout the Pacific Northwest (Washington, Oregon, and Idaho) for both public and private sector clients. His diverse professional background includes working for the Oregon State Department of Transportation (ODOT) as a geotechnical engineer and project manager. During his career with ODOT, Dr. Wang provided expertise for landslide and rockfall mitigation, as well as geotechnical engineering support for the development of major highways throughout Oregon State. His experience gives him a deep level of understanding of public sector project organization and management. He recognizes the challenges these agencies face in dealing with restrictive budget constraints and tight schedule demands.
In addition, Dr. Wang has overseen and successfully completed several large scale private development projects. These projects include mixed-use, mid-rise, and high-rise building projects, as well as warehouse and big box building construction. His vast expertise in dealing with these types of developments includes shallow and deep foundation design, temporary and permanent shoring systems, seismic and liquefaction analysis, soil nail wall design and dewatering.
Because of his multi-faceted background, Mr. Wang has provided geotechnical engineering expertise to a highly mixed group of clients. His recent client base includes working with the Cities of Issaquah and Tacoma, and local Indian Tribes for whom he has provided geotechnical engineering services for infiltration projects, building design, sewer line expansions, water reservoir and bridge construction projects. For private sector clients such as the Vulcan, Inc., and The Schuster Group, Mr. Wang has supported green building design projects including The Mosler Lofts located in downtown Seattle.
RESUMES
MIRO BOSILKOV | SENIOR DESIGNER
Miro has over 20 years of experience in the field of civil engineering and surveying. He specializes in BIM and CAD solutions, using his background in engineering to produce clear and visually pleasing graphics for construction documents as well as public presentations. He has been involved in various conceptual site layouts, vehicle turning analysis, and large master planning development projects.
Project Experience: 7 Cedars Casino, Goldendale Observatory State Park, Jamestown S'Klallam Tibe Outpatient Clinic, and Moran State Park
MICHAELA GEHN | SENIOR DESIGNER
Michaela is an Autodesk Civil 3D Certified Professional with over 25 years of experience in the AEC industry. Her specialties include 3D design of grading and utilities, taking projects from their initial concept, through final design, to producing precise 3D models that translate seamlessly to construction documents. Michaela has experience with parks and is focused on improving designs and finding opportunities for cost savings during the CAD design process, increasing construction efficiency and delivering the highest quality product possible.
Project Experience: Skagit County Parks & Rec,
Jamestown S'Klallam Tibe Outpatient Clinic, Goldendale Observatory State Park, 7 Cedars, and Moran State Park
KAITY BRECHT, E.I.T. | CIVIL ENGINEERING
Kaity has nearly two years of experience working on a variety of civil engineering projects focusing on site layout, parking lot turn analysis, water systems, sanitary sewer, storm design (conveyance and detention),
grading, ADA compliance and construction assistance.
Knowledgeable in AutoCAD, Civil3D, WWHM and Microsoft Office, Kaity has experience working on small and large scale projects including campus projects, commercial developments and utility projects throughout the state.
Project Experience: 7 Cedars Casino and Jamestown S'Klallam Outpatient Clinic
