(1)

ARTICLES

H

YALINE MEMBRANE DISEASE, or

idio-pathic respiratory distress syndrome, is the commonest cause of death in the new-born. Although it has been the subject of

much investigation, its etiology and

patho-genetic mechanisms have remained

ob-scure. Accordingly, there are several

theo-ries about its causation and many opinions

about its optimal therapy, some of these seemingly contradictory. As a result of recent studies, both our own and those of

others, we believe that we have gained

sufficient new insight into the functional

basis of this syndrome to select therapeutic

procedures more rationally than before and

to suggest that the syndrome be renamed

the pulmonary hypoperfusion syndrome.

We believe that the syndrome reflects the calling into action of reflex vasocon-striction which tends to centralize the

circulation of the blood when the fetus or newborn infant is subjected to one or more of several stresses, such as hypoxemia, acidemia, hypothermia, and hypovolemia. This type of response has been observed

in several animal species and tends to

pre-serve blood flow to the brain, heart, and

placenta at the expense of flow to other

organs, especially the gut, the kidneys, and

the lungs and has survival value in the

presence of these stresses. Since the ductus

arteriosus is patent in the fetus and

new-born infant, however, blood flow to the

alveolar capillaries may be virtually

cx-733

EDIT0IuAL NOTE : PEDIATRICS does not usually’ publish preliminary reports,

but for that appearing below we believe an exception is justified. The

corn-l)lete report, referred to as Reference 23, is to be published in Volume 36 of

this journal.

PRELIMINARY

REPORT

THE

PULMONARY

HYPOPERFUSION

SYNDROME

J. Chu, M.D.,1 J. A. Clements, M.D.,2 E. Cotton, M.D.,3 M. H. Klaus, M.D.,4

A. Y. Sweet, M.D.,5 M. A. Thomas, M.D.,#{176}and

W. H.

Tooley, M.D.7

(Submitted January 18; accepted for publication February 17, 1965.)

‘Departments of Pediatrics, Western Reserve University School of Medicine, and Mt. Sinai Hospital,

Cleveland, Ohio.

Cardiovascular Research Institute and Department of Pediatrics, University of California Medical

Center, San Francisco; Career Investigator, American Heart Association.

Department of Pediatrics, University of Colorado Medical School, Denver, Colorado.

Departments of Pediatrics, Western Reserve University School of Medicine and Mt. Sinai Hospital,

Cleveland, Ohio. Present Address: Department of Pediatrics, Stanford University School of Medicine

Palo Alto, California.

Departments of Pediatrics, Western Reserve University School of Medicine and Metropolitan

Gen-eral Hospital, Cleveland, Ohio.

Department of Pathology, Faculty of Medicine, University of Singapore, Singapore, Malaysia.

Cardiovascular Research Institute and Department of Pediatrics, University of California Medical

Center, San Francisco, California. Markle Scholar in Academic Medicine.

Work supported in part by USPHS Grants HE-06285, HE-09504-01, HE-01-464-02, and the

Univer-sits’ of California Center for Medical Research and Training with Research Grant GM-i 1329 front the

Office of International Research, NIH.

ADDRESS (for reprints): Editor, Cardiovascular Research Institute, University of California Medical

Center, San Francisco, California 94122.

(2)

eluded by pulmonary vasoconstriction, and

ischemic damage is more likely in the lungs

than in other organs. It is for this reason

that we prefer to emphasize the occurrence of pulmonary hypoperfusion in this syn-drome.

The severity of the syndrome varies from

mild and transient postnatal respiratory

difficulty to rapidly progressing distress,

cyanosis and obtundity, and early death.

The chief clinical signs which begin

im-mediately or shortly after birth are labored, grunting respiration with inspiratory

re-tractions and cyanosis. The chest film is

consistent with a diagnosis of pulmonary

atelectasis and infiltration and usually rules

out other causes of respiratory distress.

Bowel sounds are diminished or absent, defecation and diuresis may be delayed,

and edema of hands and feet is often prom-inent. Most commonly, death ensues or

re-covery is well established within about

three days. The outstanding functional

changes are hypoxemia, hypercarbia,

res-piratory and metabolic acidosis, reduced

lung volume and compliance, and large

differences in oxygen and carbon dioxide

tensions between end-expired gas and

sys-temic arterial blood.’ Hyperkalemia often occurs.5 Pressures in the right atrium, right

ventricle, pulmonary artery, left atrium,

and aorta tend to be within or near nor-mal limits for newborn infants.6 There is

evidence, especially late in the syndrome, of large right to left shunts.3’

At autopsy, the lungs are collapsed, firm,

and dark red in color. They expand poorly

and collapse again after expansion.

Micro-scopic sections show alveolar collapse,

over-distension of alveolar ducts, and deposits

of plasma protein in the airspaces. The muscular layer of the walls of the

pulmo-nary arterioles is thick and their lumina are

small, the arterioles appearing like those

of unexpanded fetal lungs, even though the

infant may have lived 48 hours or more.

There are often petechiae in the brain and

meninges and subependymal and

intraven-tricular hemorrhages. Electron microscopic

examination reveals damage in alveolar

epithelial cells, and discontinuities in the

basement membrane. Biochemical studies

of the lung parenchyma show decreases in

neutral lipid, phospholipid, and surface

active lipoprotein fractions. There may also

be abnormalities in the fibrinolytic system of the lung tissue.#{176}’

Though the proximate cause of the

syn-drome is obscure, it is often associated with

premature delivery, antenatal maternal

hemorrhage, maternal diabetes, and with

fetal distress whether of undetermined

origin or related to these complications of pregnancy.

Pulmonary atelectasis with deposition of fibrin in airspaces has long been considered the central fact in this syndrome, a neces-sary and sufficient condition for the mor-phological diagnosis and an adequate ex-planation for the clinical and physiological manifestations. The finding that

“anti-atelectasis factor,” or surface active alveolar

lining substance is not demonstrable in the

lungs of infants that have died with ti is

syndrome reinforced this opinion and

di-rected attention more forcibly to the pri-mary role of atelectasis.h1 Accordingly,

these infants have been treated with

me-chanical inflation of the lungs, administra-tion of aerosolized surface active material

or fibrinolytic enzyme, intravenous

bicar-bonate and glucose solutions, oxygen, and other conservative forms of therapy, but without uniform success. The frequent

fail-ure of these methods to achieve clinical

control suggested that other factors might be of importance in the disease. The nature of at least one such factor, pulmonary vaso-constriction, has become clearer in the

last few years and now appears to us to

be the crucial functional abnormality which must be corrected in order to permit sur-vival.

The reasoning which led us to this

opin-ion had its origin in the demonstration2’13 of pulmonary surfactant and the suggestion

that it is secreted by glandular

ele-ments14’15 of the alveolar epithelium. Such

(3)

TABLE I

Con! rol.i

Respira!ny Di8tre..’m

Birth weight (kg),

me-dian and range

Age at death (days),

me-dian and range

Lung weight/body

weight (%)

Lung water (%)

1.5 (30)

[.80 to 3.4J

3 (30)

[0 to 30]

2.46 (30) 81.0 (24) 1.96 (30) 1.91 (28) 0.018( 8) 37.8 (28) 17.4 (26) 3.8 (28) 4.3 (25) 8.3 (23) 1.6 (19)

[.65 to 3.6]

1 (10) [4to 6]

2.16 (16) 82.0 (14) 0.92 (17) 0.84 (16) 0.0015 (11) 26.8 (15) 11.4 (19) 1.8 (15) 9.5 (17) 20.5 (18)

Minimum surface tension

of saline lung extracts

(dynes/cm)5

Numbers are mean values, unless otherwise indicated.

Numbers in parentheses give the numbers of cases on

which the mean or median is taken.

* l)ifference in the means of controls and cases of

respiratory distress is statistically significant (p <.05).

nutrient support. Ordinarily the alveolar

tissue is perfused far in excess of its

re-(lt1ireme1t5, but, with a severely restricted

blood flow, synthesis and secretion of the surfactant might decrease. This view16 was

strengthened by the demonstration that

uni-lateral ligation of a pulmonary artery was

followed by functional, morphological, and

biochemical changes in the lung that bear

striking resemblance to those of hyaline

membrane diseasel7,18

It

was also

sug-gested that lack of surfactant and effusion into airspaces are associated phenomena

because formation of surfactant and

main-tenance of correct alveolar-capillary wall

permeability both require lipoprotein

syn-thesis and may both be deranged in either hyaline membrane disease or following

pul-monary arterial occlusion.16

The etiological link to fetal distress was

provided by experiments1’20 which had

shown that fetal animals react to hypoxia

vitli pulmonary vasoconstriction. Under

such circumstances, almost all of the

out-put of the right ventricle was delivered to the ductus arteriosus, and the alveolar re-gions of the lungs were almost unperfused.

This concept of etiology has received

sup-port from experiments in which the res-piratory distress syndrome was induced in

lambs by causing prolonged hypoxia in the

ewe while the placental circulation was

still intact.2’ It has received further

sup-port from the report of a case22 of

respira-tory distress in an infant that had extensive

atelectasis and fibrin deposition in four of

five lobes, the fifth being well expanded

and lacking fibrin deposition; the four

af-fected lobes were supplied by the

pulmo-nary artery, the fifth by a branch from the

aorta.

We have recently conducted an

inten-sive investigation of respiratory distress in

the newborn and have found additional indications that pulmonary hypoperfusion

is a prominent characteristic of the

syn-drome and that pulmonary

vasoconstric-tion may persist throughout its course.23

We have found that alveolar perfusion can

be increased by infusion of acetyl choline

Lung volume at 40 cm

water (cc per gm)*

Internal area of lungs at

40 Cm water (m2/kg

body Vt.eight)*

Pulmonary vascular

con-ductance (cc/mm/cm blood/gm lung)5

Total lipids of lung

(mg/gm wet)

Choline-containing

plios-pholipids of lung

(mg/gm wet)

highly saturated

choline-containing phospho-lipids of lung-HSCP

(mg/gm wet)5

Minimum surface tension

of HSCP (dynes/cm)5

or sodium bicarbonate. We have also found that raising oxygen tension in the inspired gas is often promptly followed by a de-crease in the arterial carbon dioxide ten-sion in these infants. Among lungs studied

(4)

PHYSIOLOGICAL

DEAD

SPACE

(ml)

10-

.

#{149}RDS

o

CONTROL

8-S #{149}

I

.

‘S

#{149} . 0

#{149} SI 0 o

SO

I.

4

0 0

So. 0

0 0

o

2-1

1

1

1

1

0

2

4

6

8

10

12

14

TIDAL

VOLUME

(ml)

Fic. 1. Physiological dead space was calculated from carbon dioxide tension in mixed-expired gas and

in blood drawn from the abdominal aorta. Measurements on infants with respiratory (listress were made

before any therapy. RDS = respiratory distress syndrome.

900 - have, that those of infants dying with

res-piratorv distress show atelectasis, hvaline

800 - A.RESPIRATORY DISTRESS

#{149}‘NORMAL membranes, poor expansion, ready collapse,

700 and deficient surface activity. These

al-terations are associated with reduced lipid

600 content and markedly increased pulmonary

vascular resistance of these lungs as

corn-500 pared to those of infants dying from other

#{149} causes. In this note we propose to deal

.400

#{149} #{149}

.

300

#{149} .

200

Fic. 2. Effective pulmonary blood flow (Qe) was

- #{163} calculated from rate of uptake of freon from a

A rebreathing bag, freon solubility in blood, and

j recorded concentration in rebreathing gas mixture.

000 2000 3000 Measurements on infants with respiratory distress

(5)

DEAD SPACE TO TIDAL VOLUME RATIO BEFORE AND

AFTER

START

OF CONTINUOUS

INFUSION

OF

ACETYLCHOLI NE

0.5

0.4

0.3 0.9

-0.6

0.2

-I I I I I I J

80 60 40 20 0 20 40 60 80

TIME

IN MINUTES

Fic. 3. Ratio of dead space to tidal volume was calculated from V,/V = 1 - (Pco2 of

mixed expired gas/Pco2 of abdominal aortic blood). Time is given in minutes before and

after acetvl choline infusion was started.

only with the main points in evidence and to offer a few general comments. Detailed

discussion of our methods, results, and

diagnostic criteria and of related work of

other investigators will be presented in

subsequent papers.

Table I summarizes the information

ob-tained at autopsy in 30 control cases and 19 cases of respiratory distress in which

only conventional therapy had been used.

Not all laboratory procedures were

car-ned out in all cases. The two groups arc

comparable in birth weight, lung

weight-body weight ratio, and percentage of water

in the lung tissue. They differ in all other

respects, the most striking being that

aver-age pulmonary vascular conductance in the group with respiratory distress was

one-twelfth that of controls. Additional

studies of these specimens indicated that

the vascular obstruction was in the pul-monary arterial tree. Examination of

his-tologic sections suggested that the site of obstruction was in the arterioles and that constriction of these heavily muscled ves-sels might be responsible. If this severe

constriction and alveolar hypoperfusion

had existed throughout the course of the

syndrome, we could also explain the

mic-roscopic evidence of cellular damage, the

effusion of plasma components into

air-spaces, and the decreased amounts of lipid found in all fractions that were measured, especially the highly surface active

frac-tions.

Physiological studies on 26 infants with

severe respiratory distress produced data

consistent with the notion of alveolar

hy-poperfusion. As shown in Figure 1,

(6)

100

-90

80

-E

70-

60-a.

50

-40

-I I I I I I I I I I

dioxide tensions in mixed-expired gas and in blood drawn from the abdominal aorta

was abnormally high in these infants. This elevation of dead space was not due to inadequate tidal volume. Determination of effective pulmonary blood flow revealed

low values in distressed infants, as indi-cated in Figure 2.

We reasoned that if this lack of effective pulmonary blood flow was due to arteriolar constriction, it might be ameliorated by

infusion of acetyl choline” close to the

lungs. The effects of this drug, admin-istered to 12 severely distressed infants through a catheter placed in the umbilical vein and advanced so that its

tip

was in or near the right atrium are documented in

Figures 3, 4, 5. No all of our physiological measurements were made in every case. Eleven of the 12 infants so treated re-sponded promptly and favorably. \Vithin a few minutes expiratory complaint ceased,

cyanosis was replaced by a pink flush over

the upper half of the body, and the infants

became more reactive. Bowel sounds were heard, and when the infusion was

con-tinued for several hours diuresis hecam:

evident. (Of these 12 infants, 5 died. Four

of these 5 had received acetvl choline in

small amounts and late in the course

their disease. The fifth survived 7 days and

then died

with

severe intercurrent infec

tion.) The prompt rise in effective ptmlmo-nary blood flow, decrease in dead

space-to-tidal volume ratio, and fall in arterial

car-bon dioxide tension that occurred when

acetyl choline was infused suggest to us

that this drug caused pulmonary vascular

resistance to decrease. The changes in ef-fective blood flow shown in Figure 5

pre-ceded significant rises in lung volume and

compliance. Although pulmonary

vasodila-tation might he expected to cause an

in-crease in venous admixture, arterial oygcii

saturation rose during the infusion of acetvl

choline in 10 of 11 cases in which thc

CARBON

DIOXIDE

TENSION

IN

ARTERIAL

BLOOD

ACETVLCHOLINE

100

80

60

40

20

0

20

40

60

80

00

TIME

IN MINUTES

Fic. 4. Arterial blood was drawn from the abdominal aorta and its Pco2 determined with a Severiughaus

(7)

I I I I I I I I I I

700

-600

-500

-400

-300

-200

-100

-100

ACETYLCHOLI

NE

80

60

40

20

0

20

40

60

80

100

TIME IN MINUTES

Fic. 5. See legemid to Fig. 2. lime is given in minutes before and after

acetvl choline infusion was started.

measurement was made. If flow througl i

atelectatic regions of the lungs was

in-creased b’ the drug, a greater increase in

flow must have occurred in ventilated

re-gions, or there must have been a

pr0pr-tionately greater decrease in flow through

other right to left shunts.

Figure 6 d

isplavs

an

addition il

plienoiii-(‘flOU which we consider of great

impor-tance in the pulmonary hvpoperfusion

syn-drome. It has been reported that acidemia

s tromi

gly

intensifies pulmonary

vasoconstric-tion due to hypoxia.2” 25 As shown in this

figure, correction of severe acidemia in au

infant maintained on constant artificial

vemi-tilation with 100% oxygen was accompanied

by a remarkable increase in the arterial

Po.

The

relation between arterial pH and

effective pulmoiiary 1)100(1 flow in 19

in-fants measured prior to specific therapy

is seen in Figure 7.

Figure 8 summarizes

the

points we

hay.

uiiade SO far and in a schematic way gives

ur concept of pathogenesis. It emphasizes the complex nature of the functional and

structural relationships and illustrates why the syndrome may be self-perpetuating and progressive. There is objective evi-deuce for each physical or functional

re-lationship in the diagram. Most striking is

that pulmonary vasoconstriction is common to five pathways of physiological feedback. To relieve it should be a primary objective of therapy. Clinical experience as well as cOnsidleratiOn of the relationships set out

in

Figure 8 indicates that both pulmonary and systemic damage accumulate during

the course of respiratory distress and that effective therapy should l)e delivered as

promptly

as possible. So far we have used

only acetyl choline, oxygen, and sodium

bicarbonate to dilate the pulmonary

ves-sels, but it may be that another cholinergic,

antiadrenergic, or ganglionoplegic drug

xvii] he more convenient and successful.

(8)

CONTROLLED

VENTILATION

P40

f

40

pH

7.4

7.3

7.2

7.1

7.0

6.9

6.8

6.7

C

l0

-ACETYLCHOLINE

40

50

#{149}RDS

300 - 0 CONTROL 0

0

0

200- 0 0

7.00 7.10 7.20 7.30

ARTERIAL pH

400

-350

-300

-250

-‘4

0

200-150

-I00

50

-20

30

AGE

IN HOURS

Fic. 6. 1,500-gram infant with severe respiratory distress. Arterial oxygen tension an(l ph fell when

acetyl choline was stopped, but rose when sodium bicarbonate xvas infused in amounts calculated to

raise pH to 7.4. f = frequency of respirator, per minute; P = peak airway pressure, cm water.

it is clear that every effort should be made

to avoid maternal hypoxia, acidemia, and systemic hypotension with decreased uter-ine blood foxy. Intervals of diminished

urn-EFFECTIVE PULMONARY

BLOOD FLOW

(mI/mm/kg)

400

100

-#{149}#{149}

#{149} #{149}#{149}

#{149}I

#{149}

bilical flow in the fetus should he minimized.

The nexvborn infant at risk should he

watched for intervals of apnea. If these are

long, additional oxygen may be indicated

and respiration may be stimulated or, if nec-essary, assisted. Since chilling may provoke acidemia2o and pulmonary vasoconstriction, we feel that prolonged cooling should be

avoided and that the infant at risk should be placed immediately in a warm environ-ment.

In view of the foregoing evidence xve believe that pulmonary hypoperfusion is the central issue in idiopathic respiratory

I I Fic. 7. See legend to Fig. 2. Measurements were

7.40 7.50 made with the infants breathing OX’s gen (>5)

(9)

PULMONARY

VASOCONSTRICTION

ALVEOLAR

-HYPOPERFUSION *

DEFICIENT ANABOLISM

IN ALVEOLAR CELLS

Jr

INCREASED ALVEOLAR

WALL PERMEABILITY

SURFACTANT-DEFICIENT

ALVEOLAR SURFACES

HYPOXEMIA AND

ACIDEMIA

ASPHYXIA AND

ANEROBIC METABOLISM

VENOUS

ADMIXTURE

REDUCED

ALVEOLAR VENTILATION

AND ATELECTASIS

+1

FIBRIN

I4

DEPOSITION

_

tJ

_____________________ EFFUSION INTO

_________

AIRSPACES

Fic. 8. Relationships of certain alveolar functions in the hpoperfusion syndrome.

distress of the

newborn.

\Ve

would em-phasize that although we have used acetyl choline as a tool for investigation and have observed that it produces beneficial effects in this syndrome, we do not believe that it will necessarily prove to he the best ther-apeutic item. We are convinced, nonethe-less, that whatever regimen proves mos

successful will have early pulmonary

vaso-dilatation as an important effect.

REFERENCES

1. Reardon, II. S.: Treatment of acute respiratory

distress in newborn infants of diabetic and

“1re-1imhetic” mothers. j. Dis. Child., 94: 558, 1957.

2. Karlberg, P., Cook, C. D., O’Brien, D. Cherry,

H. B., and Smith, C. A.: Studies of

respira-tory physiology in the newborn infant:

Ob-servations during and after respirator

dis-tress. Acta Paediat., 43:397, 1954.

3. Strang, L. B., and MacLeish, M. H.:

Ventila-ton failure and right-to-left shunt in

new-born infants with respiratory distress. PEDI-ATBICS, 28:17, 1961.

4. Nelson, N. M., Prod’hom, L. S., Cherry, R. B.,

Lipsitz, P. J., and Smith, C. A.: Pulmonary

function in the newborn infant. II. Perfusion.

Estimation by analysis of the

arterial-alveo-lar carbon dioxide difference. PEDIATRICS,

30:975, 1962.

5. Usher, R.: Reduction of murtalitv from

respi-ratorv distress syndrome of prematurity with

earls’ administration of intravenous glucose

and sodium bicarbonate. PEDI TRICS, 32:

936, 1963.

6. Rudolph, A. M., Drorbaugh, J. E., Auld,

P. A. M., Rudolph, A. j., Nadas, A. S.,

Smith, C. A., and Hubbell, J. P.: Studies

on the circulation in the neonatal period.

The circulation in the respiratory distress

syndrome. PEDIAmIcs, 27:551, 1961.

7. Stahlman, M.: Treatment of cardiovasculir

disorders of the newborn. Pediat. Clin. N.

Amer., 11:363, 1964.

8. Campiche, M., Prod’hom, S., and Cautier, A.:

Etude an microscope electronique du

pou-mon des pr#{233}matur#{233}smorts en destresse

respi-ratoire. Ann. Pediat., 196:81, 1961.

9. Lieberman, J.: Clinical syndromes associated

with deficient lung fibrinolvtic activity. I.

New concept of hyaline membrane disease.

New Engl. J. Med., 260:619, 1959.

10. Ambrus, C. M., Weinstraub, D. II., Dunphy,

D., Dowd, J. E., Pickren, J. W., Niswander,

K. R., and Ambrus, J. L.: Studies on

(10)

system in pathogenesis and therapy.

PEDI-ATRICS, 32:10, 1963.

11. Avery, M. E. and Mead,

J.:

Surface

proper-ties in relation to atelectasis and hyaline

membrane disease. J. Dis. Child., 97:517,

1959.

12. Pattle, R. E.: Properties, function, and origin

of the alveolar lining layer. Proc. Roy. Soc.

B., 148:217, 1958.

13. Clements, J. A.: Surface tension of lung

ex-tracts. Proc. Soc. Exp. Biol. Med., 95:180,

1957.

14. Macklin, C. C.: Pulmonary alveolar mucoid

film and the pneumonocytes. Lancet, 266:

1099, 1954.

15. Clements,

J.

A., Brown, E. S., Johnson, R. P.:

Pulmonary surface tension and the mucus

lining of the lungs: Some theoretical

con-siderations. J. Appl. Physiol., 12:262, 1958.

16. Clements, J. A.: Pulmonary edema and

perme-ability of alveolar membranes. Arch. Environ.

Health, 2:280, 1961.

17. Tooley, W., Gardner, R., Thung, N., and

Finley, T.: Factors affecting the surface

tension of lung extracts. Fed. Proc., 20:428,

1961.

18. Finley, T., Tooley, W., Swenson, E., Gardner,

R., and Clements, J.: Pulmonary surface

ten-sion in experimental atelectasis. Amer. Rev.

Resp. Dis., 89:372, 1964.

19. Dawes, C. and Mott, J.: The vascular tone

of the foetal lung. J. Physiol., 164:465, 1962.

20. Cook, C. D., Drinker, P., Jacobson, H.,

Levi-son, H., and Strang, L.: Control of

pul-monary blood flow in foetal and newly born

lamb. J. Physiol., 169:10, 1963.

21. Orzalesi, M., Cook, C. D., Craig, J. HolLter,

D., Jacobson, H., Kikkawa, Y., Motoyama,

E., and Reynolds, E.: The effect of

con-trolled prenatal asphyxia on the pulmonary

function and lung surfactant of newborn

lambs. Physiologist 6:248, 1963.

22. Bozic, C.: Pulmonary hyaline membranes and

vascular anomalies of the lung. Description

of a case. PEDIATRICS, 32:1094, 1963.

23. Chu, J., Clements, J., Cotton, E., Klaus, M.,

Sweet A., Thomas, M., Tooley, W., an(l

Wright, R.: Manuscript in preparation.

24. Liljestrand, C.: Chemical control of the

dis-tribution of the pulmonary blood flow. Acta

Physiol. Scand., 44:216, 1958.

25. Enson, Y., Giuntini, C., Lexvis, M., Morris, T.,

Ferrer, M., and Harvey, R.: The influence

of hydrogen ion concentration and hypoxia

on the pulmonarv circulation. J. Clin.

In-vest., 43:1146, 1964.

26. Candy, C. M., Adamsons, K., Cunningham, N.,

Silverman, W. A., and James, L. S.:

Ther-mal environment and acid-base homeostasis

in human infants during the first few hours

(11)

1965;35;733

Pediatrics

Tooley

J. Chu, J. A. Clements, E. Cotton, M. H. Klaus, A. Y. Sweet, M. A. Thomas and W. H.

PRELIMINARY REPORT: THE PULMONARY HYPOPERFUSION SYNDROME

Services

Updated Information &

http://pediatrics.aappublications.org/content/35/5/733

including high resolution figures, can be found at:

Permissions & Licensing

http://www.aappublications.org/site/misc/Permissions.xhtml

entirety can be found online at:

Information about reproducing this article in parts (figures, tables) or in its

Reprints

http://www.aappublications.org/site/misc/reprints.xhtml

(12)

1965;35;733

Pediatrics

Tooley

J. Chu, J. A. Clements, E. Cotton, M. H. Klaus, A. Y. Sweet, M. A. Thomas and W. H.

http://pediatrics.aappublications.org/content/35/5/733

the World Wide Web at:

The online version of this article, along with updated information and services, is located on

American Academy of Pediatrics. All rights reserved. Print ISSN: 1073-0397.

References

Related documents

Principal component analysis (PCA) shows a scatter plot of variables of four target cell types, as analyzed using the Partex Genomic Suite software. In this plot, each sphere

work with NWIRP. The views are those of the author, not of the organization.. has not been a positive one. More individuals have been deported under the current administration

But the question remains: why would the Framers include eligibility qualifications in only two of the three branches of America’s fledgling government? After all, many of the

They presented a method for identifying services based on affinity clustering, Elementary business process and business Entity Affinity analysis Technique (EEAT). Compared to

řƆţũƈƅŔ ƑƅƏƗŔ ¿ƈŮś ƅŔ ƒŧŕŰśƁƛŔƏƈƊƅŔŚƛŧŸƈƓžĻŔŧũųƈĻŕŷŕſśũŔŚŧƎŮƓśƅŔŚŔƏƊŬ ŘũśſƅŔžƉƔśũśžƇŲśƏ ƑƅƏƗŔ Ɖƈ ƑƅŔ ƉƈřƔƊŕŝƅŔŘũśſƅŔƏ ƑƅŔ Ə ŕƎśœŪŠśƉƄƈƔ ƅ ƉƔśũśſ ŖŧřŽƃŒ ƏƃƍƕŒ

This testing kit consist of components such as current transformer to step down current, voltage transformer to step down voltage, zero crossing detector to measure

We did not fractionate the AML samples for the following reasons: (a) the bone marrow blast percentage for all samples, including M3 abnormal promyelocytes, was high (medi-

Thus, the study of assimilating organs in five species of the genus Сlimасорtеrа revealed Kranz (the leaf, bract and bracteole) and non-Kranz (cotyledon and perianth)
