Aquavision – the ultimate in luxury
As a leading manufacturer of waterproof, wall-integrated televisions, Aquavision is the first choice of particularly demanding customers.
We have been creating excellent design using high quality materials and innovative functions for exquisite TV solutions since 1997.
Classic-Series
Designs
Glass fronts available in • Black
• MirrorVision®and MirrorVision®+
• Polar White
• IP 65 Splash Protection
• Flush-to-the-wall installation
• Stainless steel frames
Available in a variety of sizes
TV diagonals Outer dimensions (HxW) Installation dimensions (HxWxD)
22“ 412 x 575 mm 402 x 566 x 50 mm 22“ Ultra 412 x 575 mm 402 x 566 x 26 mm 27“ 492 x 722 mm 483 x 718 x 50 mm 27“ Ultra 492 x 722 mm 483 x 718 x 26 mm 32“ 571 x 854 mm 562 x 845 x 60 mm 40“ 692 x 1049 mm 683 x 1043 x 60 mm
The unique and original Aquavision design, with polished stainless steel frames housing the screen, which allows for fully flush in-wall appearance. The stainless steel panels frame the glass and provide the TV with a classy look. An optional Slim Line Backbox is available for dusty or damp environments.
A variety of configurations
Genesis
DVB-T, DVB-C, Analogue cable, IR, 2x HDMI, USB
Nexus
DVB-T, DVB-C, DVB-S2, RS232, IR, CI+, 3x HDMI, USB
Pinnacle
DVB-T/T2, DVB-C, Analogue cable, RS232, IR, CI+, Smart TV, 3x HDMI, 2x USB
ConnecTV
such as Genesis, additional HDBaseT without mains supply
ConnecTV activ
such as Genesis plus HDBaseT with mains supply for the display (PoH) up to 27“ size
Ultra
such as Genesis, only 26 mm depth
Touch
Touchscreen with 5m USB cable, available for all glass designs (from 32“: no touchscreen control for TV functions)
Frameless-Series
Designs
Glass fronts available in • Black
• MirrorVision®and MirrorVision®+
• Polar White
A variety of configurations
Genesis
DVB-T, DVB-C, Analogue cable, IR, 2x HDMI, USB
Nexus
DVB-T, DVB-C, DVB-S2, RS232, IR, CI+, 3x HDMI, USB
Pinnacle
DVB-T/T2, DVB-C, Analogue cable, RS232, IR, CI+, Smart TV, 3x HDMI, 2x USB
ConnecTV
such as Genesis, additional HDBaseT without mains supply
ConnecTV activ
such as Genesis plus HDBaseT with mains supply for the display (PoH) up to 27“ size
Ultra
such as Genesis, only 26 mm depth
Touch
Touchscreen with 5m USB cable, available for all glass designs (from 32“: no touchscreen control for TV functions)
A variety of sizes
TV diagonals Outer dimensions (HxW) Installation dimensions (HxWxD)
16“ 350 x 495 mm 322 x 448 x 50 mm 22“ 391 x 554 mm 352 x 520 x 50 mm 22“ Ultra 391 x 554 mm 352 x 520 x 26 mm 27“ 472 x 702 mm 437 x 656 x 50 mm 27“ Ultra 472 x 702 mm 437 x 656 x 26 mm 32“ 550 x 833 mm 517 x 790 x 60 mm 40“ 670 x 1028 mm 638 x 985 x 60 mm 65“ 970 x 1590 mm 935 x 1540 x 60 mm
A sleek glass design that looks great in any room and with any wall surface. The Frameless Series is fitted in the wall with a slim Backbox and the glass surface is mounted onto the wall.
only Genesis only MirrorVision
• IP 65 Splash Protection
• Wall installation – only the glass surface
protrudes from the wall.
Silhouette
Designs
Glass fronts available in • Black
• MirrorVision®and MirrorVision®+
• Polar White
A variety of configurations
Genesis
DVB-T, DVB-C, Analogue cable, IR, 2x HDMI, USB
ConnecTV
such as Genesis, additional HDBaseT without mains supply
ConnecTV activ
such as Genesis plus HDBaseT with mains supply for the display (PoH)
Ultra
such as Genesis, only 26 mm depth
• IP 65 Splash Protection
• Wall Surface Installation – Only 50mm depth
A variety of sizes
TV diagonals Outer dimensions (HxW)
22“ 415 x 578 x 50 mm
22“ Ultra 415 x 578 x 26 mm
27“ 495 x 725 x 50 mm
27“ Ultra 495 x 725 x 26 mm
The innovative solution for mounting an Aquavision TV onto the surface of the wall. Elegant lines and an ultra-thin profile inconspicuously hide the assembly frame. All cables are hidden within the frame, creating a unique look of being suspended in the air with no visible means of fixing or cables.
KitchenVision
Specially developed for kitchen viewing solutions. They consist of two products; a 600 mm wide and 355 mm high assembly frame (the same size as a coffee machine or a microwave) and a 600 x 720 mm door solution that is only 24 mm deep. Both products incorporate a 22” screen. Available in MirrorVision and white glass.
• IP 65 Splash Protection
• 24 mm installation depth.
• Door solution in standard kitchen units
Bespoke
Customised mirrored designs created to your own individual specification. Bespoke can incorporate any size and model of Aquavision screen and can be mounted in any position. Thanks to MirrorVision+® Technology, the mirrored surface looks just like a standard mirror, and not like a TV, when inactive. When switched on, it appears as a clear TV image with a virtually no reflection. Perfect for bathrooms, living rooms, bedrooms or for anywhere both a mirror and TV are required.
• Individual Mirror Solutions
• 22“ – 65“ Displays
• Mirrors up to 2.400 x 1.500 mm
A variety of configurations
Genesis
DVB-T, DVB-C, Analogue cable, IR, 2x HDMI, USB
ConnecTV
such as Genesis, additional HDBaseT without mains supply
ConnecTV activ
such as Genesis plus HDBaseT with mains supply for the display (PoH)
A variety of sizes
TV diagonals Outer dimensions (HxW)
22“ 600 x 715 x 24 mm
distributed by www.vivateq.de 10/2014
