Preface
Welcome to this Configuration Management Guide for Rhapsody® by I-Logix Inc. The goal of this Guide is to provide you with enough information to get you started archiving your Rhapsody models into one of the supported 3rd party configuration management (CM) software applications supported by Rhapsody.
Rhapsody interfaces 3rd party software configuration mangement tools to allow users to safely document and archive changes made to their software projects. Through a process of check-in and check-out, the CM process insures that only one user can change any part of the project at a time. This allows a team of Rhapsody developers to collaborate to jointly develop a model. To facilitate this team concept, Rhapsody also makes it possible to divide a project into different parts that teams can work on in parallel.
This Configuration Mangagement Guide for Rhapsody is organized into the following two chapters:
• Chapter 1—Collaboration—This chapter describes the principles of collaboration that allow a team of developers to work on projects in parallel. It consists primarily of the semantics of archival check-in and check-out, along with aspects of unifying the parts of a Rhapsody model divided for collaborative purposes.
• Chapter 2—Implementing CM Operations—Beneath the common semantics of Rhapsody’s CM interface there are properties and settings that address the uniqueness of each CM tool. In this chapter, you edit specific implementations of CM tools that are not
The following are some additional titles in the Rhapsody documentation set: • The Rhapsody Installation Guide describes the proper procedure for
installing Rhapsody and configuring your software licenses. • The Rhapsody Release Notes describe new features and known
problems or issues associated with a specific software release. • The Getting Started documents (Guided Demo, Quick Start, and
Tutorial) help you quickly get started building and running software models with Rhapsody. See “Getting Started with Rhapsody” on page -viii.
• The Rhapsody Reference Guide provides in-depth reference information on the Rhapsody VPE.
• The RTOS Interface Guide provides information on how to adapt Rhapsody to a new real-time operating system (RTOS) environment. This document is currently a work in progress.
• Rhapsody’s extensive online help provides detailed information on most of Rhapsody’s features, including project properties and the read-write COM API.
The following are some additional sources of information on object-oriented software development for real-time embedded systems:
• Real-Time UML by Dr. Bruce Powel Douglass is part of the Addison-Wesley Object Technology Series. It demonstrates how to use the UML to effectively analyze and model real-time embedded systems using object-oriented methods. You can find it on I-Logix’ web site at http://www.ilogix.com under “What’s New.”
• Doing Hard Time; Designing and Implementing Embedded Systems with UML by Dr. Bruce Powel Douglass is another book in the Addison-Wesley Object Technology Series.
• Executable Object Modeling with Statecharts by Dr. David Harel and Eran Gery is a cover feature article from the July 1997 issue of the IEEE Computer Magazine describing the use of Statecharts for behavioral modeling within Rhapsody. You can find the article on the
Using the Online Documents
Using the Online Documents
The online books in the Rhapsody documentation set, including this Guide, are accessible as Adobe Acrobat™ PDF files from Rhapsody’s Help menu. To view these documents, you must have the Acrobat Reader™ installed. An option to install the Acrobat Reader is included as an option during Rhapsody installation. The latest version of the Reader is also available from Adobe’s web site.
To access any of the online books from within Rhapsody: 1. From the Help menu, select List of Books.
If your Acrobat Reader is properly installed, the List of Books opens in the Reader.
2. Select the book you are interested in viewing from the displayed document set.
The PDF document opens in the Reader.
Contacting I-Logix
I-Logix’ technical support hotline provides assistance with installation, application issues, and documentation. Technical support engineers also collect information about product defects and take suggestions for product enhancements. Technical support, sales, and application engineers assist prospective customers with product evaluations and provide timely responses to user issues.
Contacting I-Logix via the Hotline
Contact the hotline as follows:Telephone:
In the US: 978-682-4884 8:30 am to 5:30 pm EST In Europe: +44 (1249) 467600
Contacting I-Logix via the Web
An alternative way to contact I-Logix is via the World Wide Web. If your host machine is connected to the Internet, you can access I-Logix’ Tech Support site through Rhapsody’s Help menu:
1. From the main menu, click Help > I-Logix on the Web. 2. From the cascading menu, click Technical Support.
A Web browser opens with I-Logix’ Technical Support Form displayed. Note:You can also access I-Logix’ Technical Support site outside of
Rhapsody by starting a Web browser and directly entering the URL http://www.ilogix.com/suform_c.htm.
3. In the Technical Support Form, enter your name, company, contact information, and a description of the problem, enhancement request, or question.
To submit the form, 4. Click Send.
To clear the form and start over, 5. Click Reset.
Getting Started with Rhapsody
The online Getting Started guide helps you quickly get up and running with Rhapsody. Getting Started is accessible from the Windows Start menu. It has the following three parts:
In the US: 978-682-5995 In Europe: +44 (1249) 467610 Email: [email protected]
Getting Started with Rhapsody
• Guided Demo—Walkthrough of a model of a radio that lets you play tunes, switch stations, and set memory buttons. The radio is a prebuilt Rhapsody model.
• Quick Start—Instructions on how to quickly get started building a model, generating code, and animating an application. The Quick Sstart is a WinHelp file.
• Tutorial—Step-by-step instructions describing all the fine points of creating a simple Hello World program and then building a slightly more complicated model of a dishwasher. The Tutorial is a PDF file. You can invoke Getting Started either outside or inside of Rhapsody:
• Outside of Rhapsody—In the Windows Task bar, click Start > Programs > Rhapsody by I-Logix > Rhapsody Getting Started. • Inside of Rhapsody—From Rhapsody’s Help menu, select Getting
Started.
Once Getting Started opens, you can run through the Guided Demo, the Quick Start, and/or the Tutorial in any order to learn about Rhapsody. We recommend doing the Guided Demo first, the Quick Start second, and the Tutorial third. To invoke the Guided Demo, do the following:
1. Invoke Getting Started (see above).
2. On the first page of Getting Started, click Guided Demo. To invoke the Quick Start, do the following:
1. Invoke Getting Started (see above).
2. On the first page of Getting Started, click Quick Start. To invoke the Tutorial, do the following:
1. Invoke Getting Started (see above).
Contents
Preface
Where to Find More Information
vi
Using the Online Documents
vii
Contacting I-Logix
vii
Contacting I-Logix via the Hotline vii Contacting I-Logix via the Web viii
Getting Started with Rhapsody
viii
1
Collaboration
Basic Concepts of Collaboration
1
Creating Units 2 Project 3
Configuration Item 4 Workspace 4
Configuration Management Repository 4 Add to Model 5
Unresolved References
5
Resolving Unresolved References 6
Resolution by ID vs. Resolution by Name 7 Handling Unresolved Elements 7
Browser and Diagrams 8 Code Generator 8
Read-Only Configuration Items
8
ASCII-Based Repository
9
Configuration Management Interface
9
Configuration Management Operations 9 Connect to Archive 9 Check Out 10 Check In 10 List Archive 10 Add Member 10 Lock 10 Unlock 10 Synchronize 10
Using the Configuration Items Dialog 11 Connecting to the Archive 12 Adding Members 15
Listing the Archive 15
Checking Out Configuration Items 16 Checking In Configuration Items 18 Locking Configuration Items 19 Unlocking Configuration Items 19 Synchronizing Configuration Items 20
Useful Scenarios in Configuration Management
23
Renaming a Child Package within a Parent Package 23
Propagating Child Package Name Change to the Development Team 24
Adding a New Parent Package to the Rhapsody Model 24
Propagating New Parent Package to the Development Team 25 Making a Child Package into a Parent Package in Rhapsody Model 26
Propagating New Parent Package to the Development Team 26 Using the Browser for Configuration Management 28
2
Implementing CM Operations
General Procedures
1
Naming the Project Directory 1 When to Check Out Packages 1 Rhapsody CM Pre- and Post-Actions 2
Source Integrity 7.3e
2
Setting Up Source Integrity 2 Source Integrity Semantics 4
PVCS 5.3.00
5
Setting Up PVCS 5
Configuring the Master Project 6
Configuring the Current Project 7 PVCS Semantics 8
ClearCase 3.2
8
Setting Up ClearCase 8
Case Sensitivity in ClearCase 9
Team Environment Issues in ClearCase 10
Setting up Team Member Rhapsody Projects 10 Adding New Members to the Archive 10 ClearCase Semantics 11
Configuring Rhapsody to a CM Tool
12
Arguments to Properties 12
Properties for Configuring a CM Tool 13
Collaboration
Rhapsody allows a team of developers to collaborate jointly to develop a model. To facilitate this, Rhapsody allows you to divide a project into different parts that several teams can work on in parallel. These parts are called units. Units are composite model elements that are stored in separate files. After making units of important model packages and classes you can then manage their development via a Collaboration Management (CM) tool.
Basic Concepts of Collaboration
Collaboration comprises the following features:
• An ASCII-based repository for storage and differentiation by a CM system
• The interface with CM tools,1 allowing exchange of version-controlled configuration items
• Some read-only configuration items
• Decoupling of configuration items using unresolved references This section describes the fundamental concepts of collaboration. Some of the concepts have meanings outside of the area of collaboration and are explicitly redefined here.
1. Some common CM tools that Rhapsody interfaces with are Source Integrity™ by MKS, PVCS™ by Intersolv, and (to a limited extent) ClearCase™ by Rational Software.
Creating Units
You can partition your model into units down to the class level for
collaboration with other developers. You can then check unit files in and out of a configuration management system giving you explicit control over filenames and modification rights (R/O vs. R/W).
You can make units of the following kinds of elements: • Components
• Packages • Classes
• Diagrams (except Statecharts and Activity diagrams)
An element that is a unit has a gray file bitmap overlaid over its regular icon. For example, the active component shown in the left hand margin is also a unit. To make an element a unit, do the following in the Browser:
1. Right-click the element.
2. From the element’s popup menu, select Create Unit (elements that are already units have the popup menu selection Edit Unit).
Project
3. You can select the Store in separate file checkbox only if you are editing an existing unit. If you are creating a unit, this setting is defaulted to true. 4. Edit the default filename, which is the name of the element, if desired. Do not enter an extension. Rhapsody assigns the following extensions to unit files:
5. You can select the Read Only, Read/Write, or Reference radio button to specify the unit’s modification rights only if you are editing an existing unit. When you create a unit, it is automatically created with Read/Write privileges.
Note: To copy an attribute or operation from a Read Only package to a Read/Write package, you can drag and drop it from the RO package to the RW package.
Caution: It is highly recommended that you save your model before changing any modification rights to Read Only! 6. Click OK.
When you save the model, Rhapsody creates files for all units in the project (_rpy) directory.
Project
A project is the overall set of elements—components, packages, diagrams, etc.—that describe the system that a group of developers is modeling. Elements are typically stored in a CM repository.
Model Unit Extension
Components .cmp
Packages .sbs
Classes .cls
Use Case diagrams .ucd Sequence diagrams .msc Object Model diagrams .omd
Configuration Item
A configuration item is a unit of collaboration that is exchanged among developers. CM tools manage versions of configuration items. Units chosen for archival by a CM tool are configuration items in Rhapsody. They are elements exchanged between collaborating developers of a Rhapsody model.
Workspace
Workspace refers to an area allocated to a CM tool for checking out specific revisions of configuration elements chosen for archival. In the case of Rhapsody, units are checked out to and checked in from an open Rhapsody project’s own workspace. Thus the workspace for the CM tool and Rhapsody’s workspace (where the model’s files reside) are the same.
Configuration Management Repository
The CM repository stores versions of configuration items in archives. An
archive is a CM repository grouping for common versions of a project’s configuration items. The archive may track related versions of configuration items for a specific project version. For example, it may group all
configuration items of the same version as a separate configuration item. CM tools refer to this configuration item as the project. Each project version is referred as a release, indicated as such through labeling.
Note:Rhapsody does not explicitly support the notion of releases. A release is facilitated through labels that you can attach to configuration items on check in.
Each configuration item has the following properties: • Version
• Mode: Read/Write (locked) vs. Read-Only (unlocked)
• Locked By: As defined by the CM tool (usually, the last user who had write permission)
Add to Model
Note:Configuration items keep track only of their own permissions (R/O vs. R/W) on the file system, but not of their status (locked vs. unlocked) in the CM tool.
Add to Model
The Add to Model command imports configuration items into a workspace. When you use the Add to Model command without the CM interface, there is no version control and locking. This may be useful in the initial stages of a project when you want to keep your overhead down and import design patterns from previous projects.
The CM interface also uses the Add to Model. CM tools provide version control and locking, which are very useful once you start working with other developers.
Unresolved References
Every Rhapsody configuration item may include references to other
configuration items (CI cross-references). Once a configuration item is moved to another workspace, some of its references may no longer exist in the new context. These dangling references are called unresolved references. For example, as often happens when people collaborate on a project, if you replace an existing package with a newer version and the new package does not contain an item that appears in some view, that item will be unresolved. Unresolved references belong to either of the following groups:
• Diagram view elements not defined in a particular package, such as: – Packages – Classes – Role names – Attributes – Operations – Events – Types
– Actors – Use Cases
– Associations between actors and use cases • References between packages in the Browser
– Superclasses – Super-events
– Events (in Class -> Operations) – Other classes of a role
– Types
Note:You may need to refresh your file in order to obtain updated, unresolved information. Sometimes, you may need to close and reopen the model.
All unresolved view elements are indicated with the prefix “U” in the diagram or the Browser. Once the element is resolved, the unresolved indicator disappears. Since unresolved references are references to objects that are not really present, the only thing you can do with them is observe them, attempt to resolve them, or delete them (remove from view). Other operations such as modifying them or double-clicking produce error messages from Rhapsody. Note:Inconsistent roles added to the same model are removed after a
message from Rhapsody.
Note:If the other class of an association is unresolved, the other-class area of the Association dialog is dimmed.
Resolving Unresolved References
There are three ways to resolve an unresolved reference:
• If there is an unresolved element that initially you didn’t think you would need, but now you realize you need it, introduce a new configuration item containing the missing element.
Resolution by ID vs. Resolution by Name
• If the unresolved element is something you knowingly did not want to import but now want to define yourself, explicitly define the missing element using the Browser or other diagram.
• If the unresolved element arose from working with an older or newer version of a package and the object referred to was renamed, rename an existing element to match the unresolved element.
Renaming a composite meta-object such as a package or a class may resolve a whole set of unresolved references.
Note:Rhapsody cannot resolve a relation by explicit definition.
Although it is possible to define a relation using the Object Model diagram, the Browser refuses to resolve the relation as if it already exists.
Resolution by ID vs. Resolution by Name
In certain cases, Rhapsody can track an item that was renamed. For example, consider the following scenario:
1. User A defines a class C in package P.
2. User B loads package P into the workspace and draws a diagram including a reference to class C.
3. At this point, user A renames class C to C1.
4. Then user B reloads package P with the new updated package. The reference to C in the diagram is now resolved to C1 and the name is replaced with C1.
Handling Unresolved Elements
CheckerThe Checker has two ways of checking for unresolved superclasses, super-events and other classes of relation names. Currently the Checker does not check for unresolved references in diagram elements which you can inspect by observing the diagrams.
Browser and Diagrams
In the Browser and diagrams, unresolved items are marked with a (U).
Code Generator
The Code Generator checks for unresolved references within the configuration scope. If it detects unresolved elements, it aborts code generation.
Note:The only logical way to fix unresolved elements is to remove them or resolve them.
Read-Only Configuration Items
A significant part of collaboration involves change-control policy. To support this, Rhapsody uses the concept of read-only configuration items.
Configuration items are loaded into a workspace in either Read/Write (R/W) or Read-Only (R/O) mode, depending on the permission granted from the CM tool check out or some other team policy. You cannot modify configuration items that are designated as R/O.
Rhapsody designates a configuration item as R/O if the file associated with it is write protected. For example, when you check out a configuration item from a CM repository, it can be either write-protected or not. Rhapsody assigns the change protection to the configuration item based on this attribute.
The following read-only configuration items are marked “RO”: • Packages:
marked as read-only within the Browser • Diagrams:
once opened, the window banner has a “read-only” title beside the diagram name
ASCII-Based Repository
ASCII-Based Repository
Rhapsody’s ASCII-based repository facilitates an open, linear representation of Rhapsody models. All meta-objects within each configuration item are represented as hierarchical object structures, where each object is contained within some container object and the top-level container is the configuration item itself (package, diagram or configuration).
Configuration Management Interface
The CM interface automates common CM operations in most CM tools. The purpose of the CM interface is to facilitate the configuration of a Rhapsody workspace with respect to the project repository. By applying a CM operation, a developer can check configuration items into or out of an archive to facilitate collaborative work with other developers. Rhapsody does not create such a repository, but must work with an independent CM tool, such as Source Integrity.
Note:I-Logix emphatically discourages two or more developers from modifying the same unit at the same time. This may cause anomalies when you merge the units.To prevent problems, use proper locking within the CM tool.
Configuration Management Operations
The following list describes the abstract, predefined operations implemented for all CM tools supported by Rhapsody.
Connect to Archive
The Connect to Archive operation defines a property representing the archive to be used when communicating with the CM tool (whatever this means for the tool). You should connect to the archive before taking any other CM operation. Note:Once the connection between a CM archive and a project has been
made, there is no need to repeat the operation again in future work on the same project.
Check Out
The Check Out operation checks out a configuration item to the Rhapsody repository workspace, performing Add to Model and Update Configuration Items operations using the appropriate CM information (such as version, CM header).
Check In
The Check In operation checks in a configuration item from the Rhapsody repository to the archive after saving the workspace to the Rhapsody repository (including concatenating CM headers and footers). The workspace is
implicitly saved to the repository during the Check In, Add Member, and Connect to Archive operations.
List Archive
The List Archive operation lists the configuration items in the CM repository.
Add Member
Before you can check in a configuration item you must first introduce it as a new member to the CM repository.
Lock
The Lock operation locks a file so that only you can edit it.
Unlock
The Unlock operation unlocks a previously locked file so that multiple users can have access to it.
Synchronize
The Synchronize operation makes the versions of selected items the same in both the configuration management repository and your workspace.
Using the Configuration Items Dialog
Using the Configuration Items Dialog
You invoke all CM operations from the Configuration Items dialog. To access this dialog, choose File > Configuration Items from the Rhapsody main menu.
The Configuration Items dialog lists the configuration items and properties for items currently loaded in your workspace (see “Basic Concepts of
Collaboration” on page 1-1).
The buttons in the Configuration Items dialog carry out the CM commands. You can perform those commands on multiple items at a time.
Check Out the selected items Check In the selected items Show items in Archive Add the selected items to the Archive Connect to Archive
The operations apply commands directly to the CM tool. The response of the specific tool appears in Rhapsody’s output window.
Caution:It is extremely important to pay attention to the messages in the Output window, because CM commands can sometimes fail. For example, an attempt to check out a configuration item that is already locked with the Lock box checked will fail. Because Rhapsody cannot anticipate all responses from various CM tools, it simply displays the tool’s response in the Output window so that you can respond accordingly.
Connecting to the Archive
Before you can connect to an archive, you must configure the CM tool as one of your project’s properties. See the Project Properties document for details.
To configure a CM tool:
1. Choose File > Project Properties. Lock the selected items Unlock the selected items Synchronize selected items in Archive
Connecting to the Archive
This opens the Features dialog for the project.
2. Select ConfigurationManagement for the Subject, and General for the MetaClass.
3. From the property list below, select CMTool and click the Modify button. This opens the following Property dialog for CMTool.
4. Select a CM tool from the drop-down list and click OK. You are now ready to connect to an archive.
5. From the File menu select Configuration Items...
6. From the Configuration Items dialog, select the Connect to Archive button.
This opens the Connect to Archive dialog shown below, in which you can either confirm the default archive (called a master project in Source Integrity) or select another one by either browsing or entering the full path and name of an archive.
Note:When using the Browse button, if the archive is represented as a directory rather than a file (as in PVCS and Source Integrity), then you must select a file within this directory and edit the path in the dialog. Of course, you can directly enter the entire path without using the Browse button.
Adding Members
Note:Setting the archive property may involve additional activities, depending on how your CM tool has been customized.
Rhapsody connects your project to the CM tool archive.
Note:Once a Rhapsody project is connected to a CM tool archive, it remains permanently connected once the project is saved. You do not have to reconnect it again the next time you reopen the project.
Adding Members
Before you can list the archive or begin checking in revisions of a
configuration item to the CM repository, you must first add it as a new member to the CM archive.
To add a new existing configuration item to the archive from the Configuration Items dialog, do the following:
1. In the Configuration Items dialog, select the new item. 2. Click the Add Selected Items button.
Rhapsody then adds the selected items to the CM tool archive. If the adding is successful, the Output window displays a confirmation message.
When you add an item to an archive, Rhapsody triggers an automatic save of the entire model in the repository.
Listing the Archive
The List Archive operation lists all of the configuration items in the CM archive. This operation is required if you need to check out a configuration item that does not exist in your workspace.
To view the items in the archive, do the following: 1. In the Configuration Items dialog, click List Archive.
The Archive dialog opens, listing all of the configuration items in the archive.
Once the list of archive configuration items is displayed, you can select items from the list and check them out using the Check Out button.
If you select more than one configuration item to check in or out, the items are handled in sequence, rather than all at once.
Checking Out Configuration Items
To check out configuration items from the archive:
1. In either the Configuration Items or the Archive dialog, select the items to check out.
In the Configuration Items dialog, be sure that a version number is displayed for the selected item. This indicates that the selected item has been added as a configuration item to the archive and that versions of the selected item have been checked in previously.
Checking Out Configuration Items
The Check Out dialog opens as shown below:
3. Choose from the Check Out dialog options as follows:
• Check Locked if you are acquiring a read/write copy of the items into your workspace and you want other networked users to be prevented from modifying them while you have a lock on them.
Leave the Locked box unchecked if you want to check out the items as read-only.
Note: It is customary for one user at a time to hold a lock on a given configuration item. However, some CM tools allow more than one lock on a single configuration item. This is not recommended.
• Select the With Descendant checkbox if you wish to check out the configuration items a parent item contains. For example, if you are checking out a package, selecting this checkbox will check out all archived classes, diagrams, and other elements that belong to the package.
• In the Label field, enter an optional revision setting, such as 1.1. Or you can enter a label name instead of a number.
Note:If you do not enter a revision label and you are checking out the items as locked, the CM tool automatically checks out the version with the highest revision number.
Checking In Configuration Items
To check items from your workspace back into the archive, use the Configuration Items dialog as follows:
1. Select the items you want to check in. 2. Click the Check In button.
This opens the Check In dialog.
3. Select the following options:
• Select the Locked option if you want your workspace to continue to own the current copy of the items you are checking in (the default is Unlocked).
• Select the With Descendant checkbox if you wish to check in the configuration items that the check in items contain. For example, if you are checking in a package, selecting this checkbox will check in all the classes, diagrams, and other elements that it contains into the archive.
• In the Label field, enter an optional label for the revision.
• In the Revision Description box, enter some text describing the new revision: for example, how it was modified.
Locking Configuration Items
Note: Most CM tools ignore this text the first time you check in a configuration item.
4. Click OK to confirm and check in the items.
When you check an item in to an archive, Rhapsody triggers an automatic save of the entire model in the respository.
Locking Configuration Items
You lock units so that no one else can lock them out and change them. You often do this when you are preparing to check in a new revision and need to check in some units that are not locked. Locking them first, then checking them in ensures you can check them in from your workspace:
1. Select the items in the list that you want to lock. 2. Click the Lock button.
3. When the Lock/Unlock dialog appears, you can specify whether or not to lock the descendents of the item and set the revision label. The
descendents of a package would include classes, diagrams, and other elements that are in that package.
When you click OK, the message in the Output window confirms that the units have been locked.
Unlocking Configuration Items
You unlock a previously locked configuration item when you want to give others access to it and allow them to change it.
1. Select the items in the list that you want to unlock. 2. Click the Unlock button.
3. When the Lock/Unlock dialog appears, you can specify whether or not to unlock the descendents of the item and set the revision number or label. The descendents of a package would include classes, diagrams, and other elements that are in that package.
When you click OK, the message in the Output window confirms that the units have been unlocked.
Synchronizing Configuration Items
You can synchronize items that have been changed to correct the following situations where there is a difference between the project item version and the archive item version:
• The local copy and the project archive respository have different content.
• The version numbers of the project item in the repository and the local copy are different because someone else has changed the repository copy.
OR
• The item exists in the local area, but not in the project repository, because it is new.
Synchronize the items as follows: 1. Select the items to be synchronized. 2. Click the Sync button.
Synchronizing Configuration Items
3. A new dialog appears, displaying a list of items you might want to synchronize:
Each of the items is labeled with a mode and a status:
• RW for read-write with Status of Modified (version numbers are the same, but the content is different)
• RO for read-only with Status of Difference (local and archive version numbers are different because someone else has changed the archive copy)
• A Status of New for new items.
Click the items to synchronize. You can choose to give them all the newest revision number (shown in the list) by leaving Head Revision displaying in the combo box. Press the Refresh button to the right in the upper left corner to update the list of units.
Or you can assign those you select a distinct label by selecting By Label in the combo box and entering the label to the right. Then click the
Refresh
Checkout
Set By Label here
Enter label
here
Refresh button to the right of the Checkout button (to the upper left) to update the display.
Synchronizing gets a list of all configuration items in the repository and checks out any new/updated items to the local model. If a new
configuration item exists in the repository, it adds the item to the local model automatically. The end result is that the workspace reflects what the repository contains.
To synchronize the items you have selected, click the Checkout button (to the far upper left). For each unit that is in read-write mode, Rhapsody asks if you want to update that item, letting you confirm each unit you are synchronizing/overwriting.
Final
Useful Scenarios in Configuration Management
Now, the local archive and the configuration management repository should contain items that are the same.
Useful Scenarios in Configuration Management
What follows are details of how to implement some useful scenarios in configuration management.
Renaming a Child Package within a Parent Package
To rename a package within the parent package, you can take the following steps:
1. From the Rhapsody browser window, right click on the parent package containing the child package whose name will be changed and select Configuration Management > Check out from the popup menu. 2. Check the check boxes stating Locked. Click OK.
3. Repeat the above steps for the child you are interested in renaming. 4. In the Rhapsody Output window, verify that the parent package and its
child have been successfully checked out.
5. From the Rhapsody browser window navigation area (left window pane), highlight (by left clicking on) the child package whose name needs to be changed.
6. In the information area of the Rhapsody browser window (right window frame), type in the new name of the child package and press Enter or click the apply (*) button.
7. In the source code control system, select the child package and change its name. In some source code control systems, you may need to remove the member and add it again with the new name as if it were an entirely new member.
8. If you could simply change the name of the member in your source code control system, skip this step. If you had to add the member again as if it were a new member, you must select File > Configuration Items and when the dialog appears, select the unit and then select the Add button to add the member to the repository anew.
9. In the Rhapsody browser window navigation area (left window pane), select (left click to highlight) the parent package to be checked back in, right click and select Configuration Management > Check In. 10.From the Rhapsody browser output window, verify that the parent
package and its children (if applicable) have been successfully checked backed in.
Propagating Child Package Name Change to the Development Team
Once you have renamed the package, you must update the Rhapsody browser window so that others working on the project can see the change.
1. For another team member to see the change to the child package name, in the Rhapsody browser window, from the menu bar at the top, select File > Configuration Items.
2. Select the Show List button (with the magnifying glass on it), which opens a window that displays the current items in the configuration management repository. (Otherwise you are seeing only the configuration items in the local workspace and not what is really in the archive.) 3. Select (highlight by left clicking) the parent package containing the child
package whose name was changed from the list of configuration management items.
4. Click the button at the top of the Configuration Management window to Check Out the selected parent package.
5. Check both check boxes, Locked and With Descendents. Click OK. 6. From the Rhapsody browser output window, verify that the parent
package has been successfully checked out.
7. Other developers should now see the modified child package name in the Rhapsody browser window navigation pane.
Adding a New Parent Package to the Rhapsody Model
1. From the Rhapsody browser window navigation area (left window pane), right click on the Package folder and select Add New Package.
Propagating New Parent Package to the Development Team
2. From the Rhapsody browser window information area (right window pane), type in the name of the new parent package in the Name field and hit Enter or click the Apply (*) button on the tool bar.
3. From the Rhapsody browser window navigation area (left window pane), right click on the new package and select Configuration Management > Add to Archive.
4. Check the box stating With Descendents, type in a comment, and click OK.
5. In the Rhapsody Output window, verify that the parent package and its children (if applicable) have been successfully added to the archive. (You may also be able to verify that the object was successfully checked in by checking to see if the source code control system has incremented the version.)
Propagating New Parent Package to the Development Team
1. For another team member to see the new parent package in the source code control repository, in the Rhapsody browser window, from the menu bar at the top, select File > Configuration Items.
2. Select the Show List button (with the magnifying glass on it), which which opens up a window that displays the current items in the
configuration management repository. (Otherwise you are seeing only the configuration items in the local workspace and not what is really in the archive.)
3. Select (highlight by left clicking) the new parent package from the list of configuration management items.
4. Click the button at the top of the Configuration Management window to Check Out the selected parent package.
5. Check both check boxes stating Locked and With Descendents. Click OK. In the Rhapsody Output window, verify that the parent package and its children (if applicable) have been successfully checked out.
6. Other developers should now see the new parent package in the Rhapsody browser window navigation pane.
Making a Child Package into a Parent Package in Rhapsody Model
1. From the Rhapsody browser window, right click on the parent packagecontaining the child package to be moved and select Configuration management > Check out from the popup menu.
2. Check both check boxes stating Locked and With Descendents. Click OK.
3. In the Rhapsody Output window, verify that the parent package and its children (if applicable) have been successfully checked out.
4. From the Rhapsody browser window navigation area (left window pane), select the child package to be moved and while holding down the left mouse button, drag the child package into the Package folder so that it is at the same level as the other parent packages.
5. Save the change to the Rhapsody model by selecting File > Save from the menu at the top of the Rhapsody main window.
6. In the Rhapsody browser window navigation area (left window pane), select (left click to highlight) the new parent package which was moved, right click, and select Configuration Management > Check In to check the package back into source code control.
7. Check the box stating With Descendents, type in a comment and click OK.
8. In the Rhapsody Output window, verify that the parent package and its children (if applicable) have been successfully checked backed in. You may also be able verify that the unit was successfully checked in by being sure the version number in the source code control system has been incremented.
Propagating New Parent Package to the Development Team
1. For another team member to see the new parent package in the source code control repository, in the Rhapsody browser window, from the menu bar at the top, select File > Configuration Items.
2. Select the button with the magnifying glass on it (Show List) to open a window that displays the current items in the configuration management repository. (Otherwise, you are seeing only the configuration items in
Propagating New Parent Package to the Development Team
3. Select (highlight by left clicking) the new parent package from the list of configuration management items.
4. Click the button at the top of the Configuration Management window to check out the selected parent package.
5. Check both check boxes stating Locked and With Descendents. Click OK.
6. In the Rhapsody Output window, verify that the parent package and its children (if applicable) have been successfully checked out.
7. You should now see the new parent package in the Rhapsody browser window navigation pane.
Using the Browser for Configuration Management
Rhapsody provides you with a convenient subset of the commands from the Configuration Items dialog and makes them directly available for units displayed in the Browser.
To perform CM activities in the Browser, do the following:
1. Expand the Browser to reveal a unit you want check in, check out, or add to archive.
2. Right-click the unit.
3. From the resulting popup menu, select Configuration Management.... 4. From the next resulting popup menu, select one of the following CM
actions:
• Add to archive • Check in • Check out
Selecting Check In or Check Out produces dialogs the same as those encountered using the Configuration Items dialog. The Add to archive option takes no dialog. After each operation, the appropriate CM transcript appears in the Output Window, just as before.
Implementing CM
Operations
Rhapsody’s CM tool support defines certain abstract operations supported in most CM tools. However, because each CM tool implements the operations differently, Rhapsody adopts the semantics of the particular tool to avoid enforcing any one approach.
The following sections describe the common semantics of the five CM operations implemented in Rhapsody for all CM tools, and any differences that may apply to the way they are implemented by specific tools.
You can edit specific implementations and are not permanently set in Rhapsody. You may well need to modify some settings to meet your specific requirements.
General Procedures
The items below are important CM considerations you need to make regardless of your CM software
Naming the Project Directory
As a general guideline, be sure to name the project and the directory that it’s in with the same name.
When to Check Out Packages
Depending on what changes are made to an element of a package, the package information may also change accordingly. In the following situations, it is
necessary for users to check out the containing package as well as the element itself.
• Changing the package that the element belongs to
• Moving the element from one configuration item to another within the package
• Changing the name of the element
Rhapsody CM Pre- and Post-Actions
Rhapsody assumes a miminal configuration for all CM operations, and takes certain actions either before (pre-actions) or after (post-actions) beginning CM support.
Note:Rhapsody performs all post-actions whether or not the CM operation succeeded.
Source Integrity 7.3e
Setting Up Source Integrity
To set up Source Integrity to use as your CM tool, follow these steps: 1. Create a directory to serve as your archive directory.
2. Create an archive facade as follows: • Open Source Integrity.
Operation Pre-Action Post-Action
Connect to Archive Saves the project None
List Archive None None
Add Member Saves the project Rereads the CM information stored in the configuation item’s file. This causes load metering to begin and to process rapidly.
Check Out None Loads the configuration item from its file
Setting Up Source Integrity
• Choose File > Create Project.
• For the Project Name field browse to the new archive directory or directly enter the full path and project name.
Note: The project name must have the extension .pj. The default project name is project.pj.
3. Click the Finish button.
This creates the project file project.pj in the archive directory and opens an empty project window with title
[...<path>\project.pj] title shown below:.
Note: Clicking the Next button instead of Finish allows you to create new file archives (page 2 of 3) and a sandbox (page 3 of 3). These are, however, not necessary since file archives can be created later and I-Logix does not recommend that you start a sandbox for your projects.
4. Set the configuration for this project with the following steps:
• Select Configuration > Personal ... from the Source Integrity main menu.
• In the Configuration dialog, select the Checkout tab.
• In the Check Out Defaults group, as the Working File Format select DOS Format (CR/LF).
• Select Expand Keywords (in Working File). • Select the Archive tab.
• Select OK to for the Personal Configuration
Source Integrity Semantics
The following table shows the semantics of the five CM operations as specifically implemented for Source Integrity.
Operation Semantics
Check In Items are checked in, even if their current contents are identical to those already in the archive.
Check Out Configuration item files overwrite writable (locked or newly created) configuration items of the same name.
Show Items in Archive
The items listed are the head revisions, usually the most recently checked-in revision of each configuration item. Add Member Copies the file to the archive directory and adds is as a Source
Integrity project member, without creating an archive. The first check-in creates the archive.
Connect to Archive
The project file project.pj created in Steps 1-5 represents the archive. No Source Integrity operation is performed during its creation. Particularly, no sandbox is created. I-Logix recommends that you do not create a sandbox file, and especially not in the _rpy directory.
PVCS 5.3.00
PVCS 5.3.00
Setting Up PVCS
To set up PVCS to use as your CM tool, follow these steps: 1. Create a directory to serve as your archive directory. 2. Configure the project to specify:
• A flag to save read-only work files (NODELETEWORK) • The archive path (VCSDIR)
• Keyword expansion in files with the extensions .cmp, .cls, .msc, .omd, .ucd, and .sbs (EXPANDKEYWORDS).
In PVCS, there are two ways to do this. You can either include these settings in the Master Project configuration file (continue with Step 3 on page 6) or, if you cannot modify the Master Project, you can include them in the current project configuration file (continue with the alternative Step 3 on page 7). The PVCS program directory contains two configuration files: master.cfg and template.cfg. The first lists the configuration setting for the Master Project, the second the default values for those settings. Use the template as the basis for a new project configuration file.
Each project also has its own configuration file, which should contain only those settings that differ from the Master Project. The project configuration file is stored in the project directory and bears the name of the project. For example, the configuration file for a project named myproject would be stored as
...\myproject\myproject.cfg
Configuring the Master Project
If you can modify the Master Project, do so using the PVCS GUI as follows: 3. In the Folders list, select the Master Project and choose Project >
Configure Project.
4. Select the category Workfiles and check the radio button Keep Read-only Workfile.
5. Select the category Keyword Expansion.
6. In the File Extension list, scroll down to the last row, which should be blank, and enter the extension .cmp in the first column.
Configuring the Current Project
The letter Y should appear by default to indicate that expansion of keywords ending in the letters .cfg is enabled. If the letter N appears instead, click inside the cell to change it to a Y.
8. Tab to the Newline Char column, and enter the letter combination \r\n. At this point, the File Extensions table has added another blank line.
9. Tab to the first column of the next line and repeat Steps 6. through 8., adding the file extensions .cls, .ucd, .omd, .msc, and .sbs to the list.
10.Select the category Project Options.
11.Under Configuration File, check the Make Selection Secure check box. 12.Click OK.
13.Using a text editor, explicity include the master.cfg file in the project configuration file (see articles #1259 and #1569 in Intersolv’s PVCS knowledge base on their web site).
Configuring the Current Project
If you cannot modify the Master Project, create a project configuration file as follows.
Note:These steps are continued from Step 2 on page 5.
3. Using a text editor, create a file that contains the following lines:
NODELETEWORK
VCSDIR = <archive directory created in Step 1> EXPANDKEYWORDS .cmp EXPANDKEYWORDS .cls EXPANDKEYWORDS .msc EXPANDKEYWORDS .omd EXPANDKEYWORDS .ucd EXPANDKEYWORDS .sbs
4. Save the file in the project directory using the naming convention <Drive>:\<path>\<projectdir>\<projectname>.cfg 5. Create a new project and specify this file as your project configuration file
6. In the Project Name field, enter the name of your new project.
7. In the Project Configuration File field, enter the full path and name of the .cfg file you created in Steps 3. and 4.
8. In the Project Working Directory field, enter the name of the project directory entered in Step 4.
9. Click OK.
PVCS Semantics
The following table shows the semantics of the five CM operations as specifically implemented for PVCS.
ClearCase 3.2
Setting Up ClearCase
To set up ClearCase to use as your CM tool, follow these steps: 1. Create a directory to serve as the VOB mounting point.
2. Create the VOB (mkvob) and mount it (mount). Alternatively, you can use the VOB Creation Wizard.
Operation Semantics
Connect to Archive The configuration file created in Step 2 represents the archive. PVCS does not participate in this operation. List Archive List only those configuration items with the highest version
numbers.
Add Member Create the archive file with initial information (do not check in).
Check In Check in configuration items, even if the current items are identical to those already in the archive.
Check Out Do not overwrite any writable (locked or newly created) configuration items of the same names in the user’s workspace.
Case Sensitivity in ClearCase
Note:I-Logix has tested these commands only under Windows NT. To apply shell commands (such as mkvob) in Windows NT, precede them with the word cleartool. For example,
> cleartool mkvob
3. Create a view (mkview) and activate it (startview). Alternatively, you can use the View Creation Wizard.
4. Add to version control (mkelem) any directory that is a parent to Rhapsody’s workspace repository (the _rpy directory). This includes the directory that you can optionally create as part of Rhapsody’s new project.
Note:Check out (reserve) this directory before connecting to the archive, which you should do once only and not for every single user (workspace). In ClearCase, adding a member performs a Check In as well.
Case Sensitivity in ClearCase
When you save a model in a ClearCase directory (under source control), it is assigned an all-lower-case name. If it is then connected to an archive,
Rhapsody creates the directory with an upper case name. This leaves you with the file <project>.rpy in lower case and the directory <project>_rpy in upper case letters which doesn't work in ClearCase.
To fix the problem,
1. Change the MVFS settings in the Control Panel > ClearCase applet to be “case preserving.”
2. Reboot the machine to allow the changes to take effect.
If this is not set and a project name has upper-case characters, then, in some cases, ClearCase will not be able to find the correct _rpy files.
Team Environment Issues in ClearCase
Setting up Team Member Rhapsody ProjectsWhen setting up the Rhapsody model for team members to share model elements, do not use the Add to Model feature of Rhapsody. Instead use the following procedure:
1. Create a new model in the same directory as the original model but in the view of the second user.
Be sure to follow the general guideline of naming the project and the directory that it’s in with the same name.
2. Save it with the original model's name.
3. Set the ConfigurationManagement::General::CMTool property to be “ClearCase”.
4. Open the Configuration Items dialog and press the List Archive button. 5. In the List Archive dialog, select top level packages (packages whose
owner isn't another package) and call Check Out (with descendants) operation.
6. Do the same (Check Out with descendants) for components and top level diagrams (the diagrams their owner isn't a package).
7. Delete from the model the "Default" package and the
"DefaultComponent" component that were created along with the new model.
8. Save the model.
Adding New Members to the Archive
When users add new elements to their models, team members may see them in the Show Items window (Archive Members window) as eligible for checkout since adding a member with ClearCase also checks it in. To avoid conflicts, the user creating the new element should immediately check the element out after adding it to the archive.
ClearCase Semantics
ClearCase Semantics
The following table shows the semantics of the five CM operations as specifically implemented for ClearCase.
Operation Semantics
Connect to Archive Renames Rhapsody’s workspace repository and creates a new version-controlled directory for it.
List Archive Lists the files that appear in the current view and are under version control.
Add Member Adds the configuration item file to version control.
Check In Checks in configuration items, even if the current items are identical to those already in the archive. ClearCase does not have Check In with Lock capabilities, so selecting the Lock field has no effect.
Check Out Do not overwrite any writable (locked or newly created) configuration items of the same names in the user’s workspace.
Configuring Rhapsody to a CM Tool
Rhapsody provides all necessary information to the CM tool in one of the following ways:
• Based on the GUI or explicit definition of default values
• By using flags that automatically provide default answers or force “silent” operations
Rhapsody does not respond to questions from the CM tool. However, you can use the properties and attributes in the following two tables to configure a CM tool different from Source Integrity, PVCS, and ClearCase into Rhapsody.
Arguments to Properties
The arguments in this table are used in conjunction with the properties in the next table to configure Rhapsody for a non-standard CM tool:
Argument Description
$archive Archive pathname as specified in the Connect to Archive dialog. Used in the
ConnectToCMRepository command.
$archivedirectory Directory part of $archive. If the archive is a directory, these two are the same.
$label Revision label of a configuration item, optionally provided in Check In/Out dialog.
$mode Flag indicating the locking mode. If locked, $mode expands to the contents of the ReadWrite property; otherwise, to the contents of the ReadOnly property.
$unit Unit of collaboration. If more than one unit is provided, the CM command is repeated in a for-each loop. For example, if several items are provided as arguments to the CheckIn command, it is repeated for each item in a loop.
Properties for Configuring a CM Tool
Properties for Configuring a CM Tool
Rhapsody provides a full set of properties for specifying its interface with the Source Integrity, PVCS and ClearCase CM tools. These properties are specified in the file factory.prp which must not be edited by users. Using the file site.prp file, however, you can enter new customizable properties into Rhapsody.
Prior to any alterations, the contents of the site.prp file are as follows:
To provide a full set of properties for a different CM tool, do the following: 1. From the factory.prp file, copy the “Subject
ConfigurationManagement” section to include the two Metaclass sections under it, “Metaclass General” and “Metaclass SourceIntegrity”
2. Paste the copied lines to the very beginning of the site.prp file. 3. To the property CMTool, add the name of the new tool at the end of the
quoted string which lists the already supported CM tools. In the example below, the name “NewCMTool” is used.
4. Replace the “SourceIntegrity” in the “Metaclass SourceIntegrity” line with the name of the new tool. In the example below, this line becomes “Metaclass NewCMTool.”
The first property, ToolCommandTimeOut, is a timeout value in
milliseconds that applies to all CM tools. For a large configuration item and slow CM tool, you should increase this value. If the timeout is disabled (timeout = 0), Rhapsody waits as long as a CM tool requires to complete an operation. If it cannot complete the operation (e.g., because it is waiting for user input), Rhapsody pends.
Note:Rhapsody does not provide a way for you to interact with the CM tool. This means that you cannot respond to prompts or provide interactive information to the CM tool.
The following table provides a list of the CM properties and a description. Some properties require the use of “regular expressions” for theri values. For
Properties for Configuring a CM Tool
an understanding of regular expressions, see the book Mastering Regular Expressions by Friedl (O'Reilly; ISBN: 1-56592-257-3).
Property Arguments Semantics
ToolCommandTimeOut None Specifies the maximum time that
Rhapsody waits for a CM tool to complete an operation. If the timeout expires before the operation is complete, Rhapsody aborts the operation.
ConnectToCMRepository $archive $projectName
Specifies the comand that connects the workspace to a CM respository
Archive None Path to the CM archive. The
ConnectToCMRepository command sets this property.
ConnectionSuccess None String returned from the
ConnectToCMRepository command indicating that the operation was successful. CheckIn $projectname $CheckInLabelPart $mode $archivedirectory $unit Check-In command. CheckOut $projectname $CheckOutLabelPart $mode $archivedirectory $unit
Check-Out command for units currently in the workspace. CheckOutFromArchive $projectname $CheckOutLabelPart $mode $archivedirectory $unit
Check-Out command for units from the archive (not in the workspace). In most cases, this property is similar to the
CheckOut property.
parReadOnly None Command specifying the Unlocked switch for the Check-In and Check-Out operations.
ReadWrite None Command specifying the locked version of the configuration item.
CheckOutItsVersion None Regular expression identifying the version from the command output line.
CheckOutItsLockedBy None String identifying the lock status of the configuration item in the command output line.
ListArchive $projectname Command that lists the contents of the CM repository.
ListArchiveItsWorking None Regular expression identifying File the configuration item in the listing line.
ListArchiveItsVersion None Regular expression identifying the current revision in the listing line.
ListArchiveItsMode None Regular expression identifying the mode of the configuration item in the listing line.
ListArchiveItsOwner None Regular expression identifying the owner of the configuration item in the listing file.
AddMember $unit
$archivedirectory $archive
Command to add a new comfiguration item to the CM archive.
HeaderFile None Pathname to a file containing the CM header template.
CMHeaderItsVersion None Regular expression specifying how the version is extracted from the header.
CMHeaderItsOwner None Regular expression specifying how the owner is extracted from the header.
MultiRecordDelimiter None Delimiter for multi-record output lines generated by the list archive command.
CheckInLabelPart $label Specifies the label portion of the
CheckIn command. Argument of the
CheckIn property. If the $label is empty, then it expands to an empty string. This facilitates a conditional value of the property.
CheckOutLabelPart $label Similar to CheckInLabelPartbut used by the CheckOut command property.
Index
A
add
new member 15
Add Member operation 10 Add Selected Items button 15 Add to archive
Browser 28
Add to Model command 5 archive 4 ASCII-based repository 9
B
Browser Add to archive 28 Check in 28 Check out 28 buttonAdd Selected Items 15 Check In 18
Check Out 16 Checkout 22
Listing the Archive 15 Lock 19 Show List 24, 25 Sync 20 Synchronize 20 Unlock 19
C
Check in Browser 28 Check In button 18 Check In operation 10, 18 Check Out 10 button 16 operation 16 Check out Browser 28 checkbox Locked 17, 18 With Descendant 17, 18Checking for unresolved elements 7 checking out packages 2
Checkout button 22 child packages
making into parent 26 renaming 23
ClearCase
adding members 9 adding new members 10 case sensitivity 9 create a view 9
operation semantics 11 setting up 8
team environments 10 VOB mounting point 8 CM 1
add new member 15 operations in Browser 28 post-action operations 2 pre-action operations 2 CM interface 9 CM operations 9 CM operations in Browser 28 CM repository 3, 4
configure 12 Project Properties 12 CM tools 1 common semantics 1 Code Generator unresolved elements 8 configuration item 4 locked by 4 mode 4 permissions 5 version 4 configuration items read/write 8 read-only 8
Configuration Items dialog 11 buttons 11 configure CM tool 12 configure project Source Integrity 3 Configuring a CM Tool properties 13
Configuring CM tool to Rhapsody 12 Connect to Archive
browsing 14 button 14 connection 15
Connect to Archive operation 9
D
dialog Configuration Items 11E
element as unit 2 elements 3executable object modeling vi
factory.prp file 13 field Label 17, 18
H
Harel, Dr. David viI
interface CM 9K
keywords PVCS 5L
Label field 17, 18 labels 4List Archive operation 10 Listing the Archive
button 15
Listing the Archive operation 15 Lock button 19
Lock operation 10 Locked checkbox 17, 18
M
messages in the Output window 12
N
naming the Rhapsody project 1
O
operation
Add Member 10 Check In
