COMPILER-ASSISTED MULTIPLE INSTRUCTION ROLLBACK RECOVERY USING A READ BUFFER
Neal Jon Alewine, Ph.D.
Department of Electrical and Computer Engineering
University of Illinois at Urbana-Champaign, 1993 W. Kent Fuchs, Advisor
Multiple instruction rollback (MIR) isa technique to provide rapid recovery from
transientprocessorfailuresand has been implemented inhardware by researchersand also
in mainframe computers. Hardware-based MIR designseliminate rollback data hazards
by providing data redundancy implemented in hardware. Compiler-based MIR designs
have also been developed which remove rollback data hazards directlywith data flow
manipulations, thus eliminatingthe need formost data redundancy hardware.
This thesisfocuses on compiler-assistedtechniques to achievemultiple
instructionroll-back recovery. We observe that data some hazards resultingfrom instructionrollbackcan
be resolved more efficientlyby providing hardware redundancy while others are resolved
more efficientlywith compiler transformations. A compiler-assistedmultiple instruction
rollback scheme is developed which combines hardware-implemented data redundancy
with compiler-drivenhazard removal transformations. Experimental performance
evalu-ationswere conducted which indicateimproved eillciencyover previous hardware-based
and compiler-based schemes. Various enhancements to the compiler transformations
are described and evaluated. The final topic of this thesis deals with the application
of compiler-assisted MIR techniques to aid in exception repair and branch repair in a speculative execution architecture.
