Towable Options
The Valley towable options allow you to irrigate two or more fields to reduce your installed cost per hectare. Each towable machine can be towed from one field to another in less than an hour. You can choose from an on-board engine generator or public power supply to power your machine.
Skid Pivot
• Low cost option best used for infrequent towing
• Not available with 6 5/8” pivot point
2-Wheel E-Z Tow
• Ideal for part-circle fields or multi-directional towing situa-tions
• Comes standard with tongue hitch design
QuickTow Pivot Point
• Low cost option used for frequent towing
• Intended for less stressful terrain and soils
• 3-point hitch hook-up tow option
Pivot Point Options
Specifications
Span Lengths Coupler Spacing Standard Crop Clearance Overhang Options
37,6 m 43,3 m 49,1 m 54,8 m 60,6 m 66,4 m 192 cm or 288 cm 3,0 m 3,0 m 3,0 m 3,0 m 2,9 m 2,8 m 5,8 m 8,7 m 17,0 m 22,6 m 22,6 m 22,6 m
Small Field 5” Fixed Pivots
The Valley® small field pivots share the same high quality design and performance as all other Valley products. Whether you are looking to irrigate 2ha with a single-span machine or 25ha with a multi-span machine, Valley has the machine you want.
Features
• Reduced running weight
• Powered by public power or generator
• Span lengths: 37,6 m – 66,4 m (142-217 feet)
• Reliable drive train and USA made Valley gearboxes
• Choice of control panels
• Most durable structure in the industry
2 Wheel Single Span Linears
• Ideal for field sizes of 2 hectares to 25 hectares • Available with a hose drag water delivery • Operates as a standard linear or towable
The Valley Linear, whether single-span or multi-span, is an ideal solution for irrigating small rectangular fields. It can irrigate an L-shaped field by pivoting 90 degrees or it can irrigate parallel fields by towing the machine or pivoting 180 degrees around the cart and reversing direction. The Valley Linear allows you to maximize your irrigated area, by utilizing up to 98% of the field.
TOW
Can be towed from one field to another in a short amount of time
Valley Two Wheel Hose Feed
• Ideal conversion option for fields currently irrigated by flood, drip, or solid set
• Operates as a standard linear, towable or swing-around ValleyTwo Wheel Ditch Feed
• Ideal for small fields
• Can take advantage of either permanent earthen water delivery infrastructures or earthen ditches that are installed annually
• A flexible suction will keep the investment costs low by fitting nearly any functioning earthen ditch
• Operates as a standard linear, towable, or swing-around Ditch Feed Water Delivery
• On-board diesel engine with generator or cord drag option powers a pump to pressurize and provide electricity to the linear
• Rolling inlets are used in concrete canals; floating inlets are used in earthen ditches
• Skid-style suction designed specifically for earthen ditches (Two Wheel Ditch Feed only)
• Capacities of 10 lps – 285 lps (150 gpm – 4,500 gpm)
Hose Feed Water Delivery
• Electrical power supplied by on-board diesel generator or cord drag option
• Polyethylene hoses with inside diameters up to 200 mm (8"), offered in a variety of lengths connected to a pressurized mainline
Single Span Pivot Options
Valley® Single Span Pivots are ideal for small holding farmers with limited access to electricity. Valley offers the option of hydraulic or gasoline driven machines which are low maintenance and easy to use. When field conditions demand the best, but infrastructure does not allow for electric service, the Spinner or Engine Drive is the pivot of choice.
Features:
• Can run without electrical components
• Easy to maintain
• Operates as a towable or fixed pivot
• Cost savings on operation & infrastructure
• Field coverage up to 3 hectares (6 acres)
• Capable of applying crop protection products
Single Span Spinner Drive
• Hydraulically powered
• 2% maximum slope
• 2.8 bar/40 PSI minimum pressure
• Low maintenance
Single Span Engine Drive
• Powered by gasoline
• 10% maximum slope
• Low pressure requirement (1 bar/14.5 PSI)
• Variable speed to control application depth
Apple® and iPad® are registered trademarks of Apple Inc., registered in the U.S. and other countries.
Specifications
Span Lengths Coupler Spacing Standard Crop Clearance Overhang
49,1 m 51,9 m 60,6 m 66,4 m 192 cm or 288 cm 3,0 m 3,0 m 3,0 m 2,9 m 5,8 m 8,7 m 17,0 m 22,6 m
See your local authorized Valley dealer for complete details.
