16. SC-90 Conventional Surface Wellhead System
12
0
0
Full text
(2) SC-90™ Series Conventional Wellhead The SC-90 Series Conventional Wellhead System is a cost-effective wellhead. Basic System Features • Range of pressure and sizes to accommodate most casing programs • Weight-set slip hangers with weight-set seal and/or optional mechanical-set seal • Ported for plastic injection (standard) • Tubing hangers available with resilient or metalto-metal seals • Downhole control line connections and electrical feed through assemblies available upon request • Available for standard or critical service. SC-90 Conventional Flanged Wellhead BOP Stack Sizes: 20 ¾" – 3k x 13 5/ 8" – 5k x 11" – 10k Casing Program: 30" x 20" x 13 3/ 8" x 9 5/ 8". 11" - 10,000 psi API Flange. Casing Spool 11" - 10,000 psi Flange Up x 13 5/ 8" - 5,000 psi Flange Down Annulus Access Manual Valve 2 1/ 16" - 10,000 psi Companion Flange 2 1/ 16" - 10,000 psi. VR Cover Flange 2 1/ 16" - 10,000 psi Plastic Injection Port. 13 5/ 8" - 5,000 psi API Flange. DQ X-Bushing 13 5/ 8" x 9 5/ 8" Bleed Port Casing Head Spool 13 5/ 8" - 5,000 psi Up x 20 3/ 4" - 3,000 psi Down. DQ-22 Casing Hanger 13 5/ 8" x 9 5/ 8". Companion Flange 2 1/ 16" - 5,000 psi. OPEN. VR Cover Flange 2 1/ 16" - 5,000 psi. Annulus Access Manual Valve 2 1/ 16" - 5,000 psi. Plastic Injection Port. 20 3/ 4" - 3,000 psi API Flange DQ X-Bushing 20 3/ 4" x 13 3/ 8". Bleed Port. Casing Head Housing 20 3/ 4" - 3,000 psi Flange Up x 20" Slip-On Weld. DQ-22 Casing Hanger 20 3/ 4" x 13 3/ 8". Companion Flange 2 1/ 16" - 3,000 psi. VR Cover Flange 2 1/ 16" - 3,000 psi. Annulus Access Manual Valve 2 1/ 16" - 3,000 psi. Slip-On Weld Connection. Typical Wellhead for Land or Platform. Base Plate. 9 5/ 8" Casing 13 3/ 8" Casing 20" Casing 30" Casing. 1.
(3) designed for land, jack-up or platform drilling and completion applications. SC-90 Conventional Flanged Wellhead Optional Slip Lock Connector – Landing Base Combination BOP Stack Sizes: 16 ¾" – 3k x 11" – 5k x 11" – 10k Casing Program: 30" x 16" x 10 ¾" x 7". 11" - 10,000 psi API Flange. Casing Head Spool 11" - 10,000 psi Flange Up x 11" - 5,000 psi Flange Down. VR Cover Flange 2 1/ 16" - 10,000 psi. Annulus Access Manual Valve 2 1/ 16" - 10,000 psi Flange. Companion Flange 2 1/ 16" - 10,000 psi. DQ X-Bushing 11" x 7" Plastic Injection Port Bleed Port. 11" - 5,000 psi API Flange DQ-21P Casing Hanger 11" x 7". Casing Head Spool 11" - 5,000 psi Flange Up x 16 3/ 4" - 3,000 psi Flange Down. VR Cover Flange 2 1/ 16" - 5,000 psi DQ X-Bushing 16 3/ 4" x 10 3/ 4" Plastic Injection Port. Companion Flange 2 1/ 16" - 5,000 psi. OPEN. Annulus Access Manual Valve 2 1/ 16" - 5,000 psi. Bleed Port. 16 / 4" - 3,000 psi API Flange 3. Casing Head Housing 16 3/ 4" - 3,000 psi Flange Up x 20" Slip-On Down. DQ-21P Casing Hanger 16 3/ 4" x 10 3/ 4". Companion Flange 2 1/ 16" - 3,000 psi. OPEN. VR Cover Flange 2 1/ 16" - 3,000 psi Plastic Injection Ports. Annulus Access Manual Valve 2 1/ 16" - 3,000 psi Flange. Slip Lock Bleed Ports 30" Conductor 16" Casing 10 3/ 4" Casing 7" Casing. Base Plate. Typical Wellhead over Mudline Suspension with 16" Slip-Lok™ Adapter. 2.
(4) SC-90 Conventional Flanged Wellhead BOP Stack Sizes: 13 5/ 8" – 5k x 11" – 5k x 7 1/ 16" – 10k Casing Program: 13 3/ 8" x 9 5/ 8" x 5 ½". 7 1/ 16" - 10,000 psi API Flange. Tubing Spool 7 1/ 16" - 10,000 psi Flange Up x 11" - 5,000 psi Flange Down. VR Cover Flange 2 1/ 16" - 10,000 psi. Companion Flange 2 1/ 16" - 10,000 psi Annulus Access Manual Valve 2 1/ 16" - 10,000 psi Flange. Bleed Port. 11" - 5,000 psi API Flange DQ X-Bushing 11" - 5 1/ 2". Plastic Injection Port Casing Spool 11" - 5,000 psi Flange Up x 13 5/ 8" - 5,000 psi Flange Down. DQ-21P Casing Hanger 13 5/ 8" x 5 1/ 2". Companion Flange 2 1/ 16" - 5,000 psi. VR Cover Flange 2 1/ 16" - 5,000 psi. OPEN. Annulus Access Manual Valve 2 1/ 16" - 5,000 psi Flange. DQ X-Bushing 13 5/ 8" x 9 5/ 8" Bleed Port. Plastic Injection Port. 13 5/ 8" - 5,000 psi API Flange. Casing Head Housing 13 5/ 8" - 5,000 psi Flange Up x 13 3/ 8" Slip-On Weld Down. DQ-21P Casing Hanger 13 5/ 8" x 9 5/ 8" VR Cover Flange 2 1/ 16" - 3,000 psi. OPEN. Annulus Access Manual Valve 2 1/ 16" - 3,000 psi Flange. Slip-On Weld Connection. Test Port Base Plate. Typical Wellhead over Mudline Suspension. 5 1/ 2" Casing 9 5/ 8" Casing 13 3/ 8" Casing. 3. Companion Flange 2 1/ 16" - 3,000 psi.
(5) SC-90 Radial Bolt Stack-Up Wellhead BOP Stack Sizes: 20 3/ 4" - 3k x 13 5/ 8" - 5k x 13 5/ 8" - 10k Casing Program: 30" x 20" x 13 5/ 8" x 9 5/ 8". BOP Stack. 13 5/ 8" - 10,000 psi API Flange. BOP Adapter 13 5/ 8" - 10,000 psi Studded Top x 13 5/ 8" - 10,000 psi Radial Bolt Down. Bore Protector Casing Spool 13 5/ 8" - 10,000 psi Radial Bolt Top x 13 5/ 8" - 5,000 psi Radial Bolt Bottom. Annulus Access Manual Valve 2 1/ 16" - 10,000 psi. VR Cover Flange 2 1/ 16" - 10,000 psi Bleed Port. 13 5/ 8" - 5,000 psi DQ-22 Casing Hanger 13 5/ 8" x 9 5/ 8". Companion Flange 2 1/ 16" - 10,000 psi Radial Bolt Connector 13 5/ 8" - 5,000 psi Casing Spool 13 5/ 8" - 5,000 psi Radial Bolt Connector Up 20 3/ 4" - 3,000 psi Radial Bolt Connector Down Annulus Access Manual Valve 2 1/ 16" - 5,000 psi. VR Cover Flange 2 1/ 16" - 5,000 psi Bleed Port. 20 / 4" - 3,000 psi 3. DQ-22 Casing Hanger 20 3/ 4" x 13 3/ 8". Companion Flange 2 1/ 16" - 5,000 psi. DQ X-Bushing 20 3/ 4" x 13 3/ 8" Plastic Injection Port. Radial Bolt Connector 20 3/ 4" - 3,000 psi. Casing Head. 20 3/ 4" - 3,000 psi Radial Bolt Up. x 20" Slip Hanger Down Valve 2 1/ 16" - 3,000 psi Threaded. 2" LP Bull Plug Plastic Injection Ports. Emergency Slip Hanger 20 3/ 4" x 20". Radial Bolt Wellhead over Mudline Suspension 9 5/ 8" Casing. Adjustable Landing Ring with four 3" Outlets. 13 3/ 8" Casing 20" Casing 30" Casing. 4.
(6) Starting Head and Intermediate Casing Spool. Lowermost Casing Head and accessories. DQ-22 General Purpose Automatic Slip-and-Seal Assembly for moderate casing loads DQ-22 Intermediate Casing Spool pictured with standard double-P type bottom seal and studded side outlets Casing Spool and accessories. DQ-22 Lowermost Casing Head pictured with SOW bottom prep and threaded side outlets Hangers, Ring Gaskets, Boltings and Gauges. DQ-21 Mechanically Set Slip-and-Seal Assembly for use over mudline suspension equipment or for light casing loads. The standard DQ-22 Lowermost Casing Head is available with either a slip-on weld bottom with test port or with female casing threads. The upper connection is flanged, and can be offered in all standard API sizes and pressure ratings, with threaded or studded outlets. This casing head will accept the DQ-22 Automatic Slip-and-Seal Assembly for land use or the DQ-21P Mechanical-Set Seal Assembly for use over mudline suspension. Two lockdown screws in the upper flange are optional for use with the bore protector. The flanged-by-flanged DQ-22 Intermediate Casing Head Spool has the DQ-22 Bowl and can accommodate the DQ-22 or the DQ-21P Casing Hangers. The secondary seal in the bottom of the casing head spool can be the standard integral double-P type seal or a removable reducer bushing with seals.. 5.
(7) Heavy-Duty Casing/Tubing Head. Tubing Spool and accessories. DQ-29 Intermediate Casing/Tubing Spool pictured with integral double-P type seal bottom, deep bowl, top flange with lockdown screws and studded side outlets. Bore Protector Running, Retrieving and Test Tools. DQ-29 Automatic Heavy-Duty Slip-and-Seal Assembly designed for high casing loads (isolation seal optional). DQ-29 Lowermost Casing Head Deep Bowl for use with the DQ-29 Casing Hanger for high casing loads. Bore Protectors. The heavy-duty DQ-29 Lowermost Casing Head and Intermediate Casing/Tubing Spool are designed for high casing loads. The Dril-Quip DQ-29 Deep Bowl will accept all DQ series casing hangers. The standard secondary seal in the bottom of the spool is an integral double or single-P type, or an optional reducer bushing with seals. Lockdown screws in the top flange are optional for use with a bore protector, tubing hanger or casing hanger. When used as a tubing head, the DQ-29 Intermediate Spool can accommodate a DQ-1E Mandrel-Type Tubing Hanger for up to a 10-inch nominal bowl size. All Dril-Quip single completion tubing hangers are available in the 7-inch nominal bowl size.. 6.
(8) Tubing Spool Adapters and Tubing Hangers. Accessories Type DQH one-way Back Pressure Valve. Lubricator and accessories. Two-way Back Pressure Valve. The DQ1A-EN Extended-Neck Tubing Hanger has a slick neck and comes with type QH back pressure valve threads. It is recommended for high-pressure applications (5,000-10,000 psi) and can also be bored to access downhole safety equipment. The DQ-1W Tubing Hanger is a slick joint wraparound hanger that provides a positive seal to full rated pressure. The DQ-1W seals off the annulus while circulating, setting the packer or installing the tree, and can be used in conjunction with the DQ-02 Tree Adapter and Coupling. The DQ-1W is available for 7-inch nominal tubing head bowl sizes.. Tubing Spool, Tree Bonnet and Valves. DL Gate Valve The DQ-02 Tubing Head Adapter and Coupling are designed for use over a DQ-1W Tubing Hanger. Self-energizing seals between the adapter and coupling isolate the critical threads from the wellbore environment. The coupling has a standard QH back pressure valve thread and may be threaded for any type of tubing connection.. 7. The DQ1A-EN Tubing Head Adapter is bored to accept and seal on the DQ-1E Type Extended-Neck Tubing Hanger utilizing double-P type seals. It can also be ported to access downhole safety equipment..
(9) Series DH, DHS, DM and DL Gate Valves Series DH, DHS, DM and DL Gate Valves The Dril-Quip series DH, DHS, DM, and DL Gate Valves are bidirectional sealing gate valves designed to offer maximum reliability for extended service in the field. All Dril-Quip gate valves are manufactured in accordance with API and ISO-9001 quality standards, and are available in four styles all qualified to API 6A PR2:. Series DH Gate Valve • Bore sizes 2 1/16" through 7 1/16", and pressure ranges 2,000 to 15,000 psi • Metal-to-metal seat seals, and nonelastomeric stem packing • Available in API 6A material classes AA to HH, and PSL levels 2 to 4 • Fire-resistant designs per API 6FA and 6FC. Series DHS Gate Valve • Bore sizes 2 1/16" through 7 1/16", and pressure ranges 2,000 to 15,000 psi • Metal-to-metal seat seals, and nonelastomeric stem packing • Unique split gate design reduces torque requirements and facilitates simultaneous testing of the upstream and downstream seats with the valve in the closed position • Available in API 6A material classes AA to HH, and PSL levels 2 to 4 • Fire-resistant designs per API 6FA and 6FC. Series DM Gate Valve • Bore sizes 2 1/16" through 7 1/16", and pressure ranges 2,000 to 10,000 psi • Metal-to-metal seat seals, and elastomer stem packing • Available in API 6A material classes AA to FF, and PSL levels 2 to 4. Series DL Gate Valve • Bore sizes 2 1/16", 2 9/16", and 3 1/8", and pressure ranges 2,000 to 5,000 psi • Resilient/elastomer seat seals, and resilient stem packing • Available in API 6A material classes AA and DD, PSL levels 1 and 2. Manually Operated Gate Valve Series. DH/DHS*. DM. DL. Pressure Ratings (psi). 2,000, 6,000, 10,000 and 15,000. 2,000, 3,000, 5,000 and 10,000. 2,000, 3,000 and 5,000. Sizes. 2 1/16" to 7 1/16". 2 1/16" to 7 1/16". 2 1/16" to 2 9/16" and 3 1/8". API Material Classification. AA to HH. AA to FF. AA to DD. Body Construction. Forged. Forged. Forged or Cast. Metal-to-Metal with Tungsten Carbide Hardfacing. Metal-to-Metal with Nitriding or Tungsten Carbide Hardfacing. Resilient Face Seal. Gate-to-Seat Seal. Pressure-Energized Metal-to-Metal with Teflon® Secondary Seals. Pressure-Energized Metal-to-Metal with Elastomeric Secondary Seals. Elastomeric. Seat-to-Body Seal. Bonnet-to-Body Seal. Pressure-Energized Metal-to-Metal. Flat Gasket Metal-to-Metal. Flat Gasket Metal-to-Metal. Stem Seal. Spring-and PressureEnergized Teflon®. Elastomeric. Resilient. *The Series DHS is the split gate version of the Series DH Gate Valve. Typical Applications • Surface BOP Stack • Choke and Kill Manifold. • Surface Completion Trees • Wellhead Systems. 8.
(10) Specifications for API Studs, Nuts and Ring Gaskets Stud Bolt Length Table for 6B Flange Connections with “R” and “RX” Gaskets Flange Size Flange 2 1/16Size2M 22 11//16 3M 16 2M 22 11//16 5M 16 3M 22 91//16 2M 16 5M 9 22 9//16 3M 16 2M 9 22 9//16 5M 16 3M 1 32 9//816 2M 5M 1 33 1//88 3M 2M 1 3 1/8 5M 3M 3 /8 4 11/16 2M 5M 3 /8 4 11/16 3M 2M 4 /16 4 11/16 5M 3M 4 /16 5 11/8 2M 5M 4 /16 5 11/8 3M 2M 55 1//88 5M 1 8 3M 75 1//16 2M 18 5M 75 1//16 3M 1 16 2M 77 1//16 5M 1 3M 97 /16 2M 1 5M 97 /16 3M. 99 9 11 9 11 11 11 11 5/8 13 13 11 5/8 16 13 35//48 16 13 35//48 21 16 13//44 216 33//44 21 1/4 4 2 3/1/8 1/8. 2M 5M 3M 2M 5M 3M 2M 5M 3M 2M 3M 5M 2M 2M 3M 3M 2M 2M 3M 3M 2M 3M. Bolt Diameter Bolt 625 Diameter 875 625 875 875 75 875 1 75 11 175 875 75 1 125 875 875 1 125 1 125 875 1 25 1 125 1 1 25 1 25 1 15 11 25 5 11125 11375 125 11125 375 11375 125 11625 375 1125 625 11375 25 11875 375 1125 11375 875 11525 11625 375 11625 5 21 625 1 625 12 2 12. 1/8 1/8. Length*. Length* 5 6 55 6 65 5 5 65 5 75 5 77 5 775 65 5 75 7 75 65 65 7 75 75 65 85 75 7 25 85 8 25 7 25 1 5 7 85 25 815 5 11 7255 8 85 5 9115 25 12 85 5 9 9255 1 12 5 14 92525 91 5 1 14 7525 1 75 95 121 25 75 121 25 75 1512 25 12 25 15. LENGTH = 2(T + t + d) + S + 2(P) T LENGTH Total = flange 2(T +thickness t + d) + S + 2(P) t T Plus tolerance for flange thickness Total flange thickness d. S P. t d S. Heavy hex nut thickness Plus tolerance for flange thickness Flange face standoff (with "RX" gasket) Heavy hex nut thickness Point Maximum (1.5 x Pitch) Flange face standoff (with "RX" gasket). P. Point Maximum (1.5 x Pitch). 12 12. API Type 6BX Flanges in.. 2 si (1 . MP a) working ressure. 2 si (1 . MP a) working ressure. si (2. MP a) working ressure. si (2. MP a) working ressure. 5 si ( .5 MP a) working ressure. 5 si ( .5 MP a) working ressure. 9. Size. mm.. 52 2 1/16 Size 2 9/16 65 in. mm. 3 1/8 78 1 52 21 /16 4 /16 13 9 521/8/16 1365 1 78 1/16/8 73 178 491/16 13 228 5 1/8 13 11 279 1 178 137 5//816 346 228 16 39/4 425 21111 /4 54279 1/165/8 346 213 52 9/163/4 425 216 65 1/81/4 54 321 78 1/16 421/16 1 352 1 9 52 /8/16 1365 1/16 1/8 73 179 78 228 491/16 13 11 279 5 1/8 13 137 51//816 346 179 16 39/4 425 228 3/4 2 11 527 279 1/16 213 52 5/8 346 9/16 216 65 3/4 425 1 3 /83 78 2 /4 527 1 4 /16 13 211/16 52 5 /98 13 2 /16 65 7 1/16 178 1 3 /8 78 91 228 4 /16 13 11 279 5 1/8 13 7 1/16 178 9 228 11 279. utside Diameter in. mm.. 65 165 utside Diameter 75 19 in. mm. 8 25 21 65 165 1 75 275 13 7 5 3319 21 14 8 25 355 1615 75 42275 2 13 5133 2214 56355 42 2716 5 685 51 322 815 56 822 5 215 685 927 62 245 932 5 24815 11 58 5 295 215 13 75 35245 9 62 15 9 5 3824 1811 5 5 47295 2113 5 75 545 35 2415 6138 2718 755 7 547 3321 755 855 545 824 5 215 61 927 6275 245 75 1 5 27 33 75 855 12 25 31 85 215 14 75 375 9 62 245 15 5 395 1 5 27 19 485 12 25 31 23 585 14 75 375 15 5 395 19 485 23 585. Diameter Num er of of Bolts in. Bolts 5/8 8 Diameter Num er 3/4of 8 of Bolts in. Bolts 3/4 8 5 8 7/8 /8 8 3 1 /4 8 8 3 1 /4 12 8 7 1 1/8 /8 12 8 1 1/4 1 16 8 1 1/4 1 2 12 1 1 1/21 /8 2 12 1 5/81 1/4 24 16 7/8 1 1/4 8 2 1 1 1/2 8 2 7/8 1 5/8 8 24 1 1/8 7/8 8 8 1 1/4 1 8 8 1 1/8 7/8 12 8 1 3/81 1/8 12 8 1 3/81 1/4 16 8 1 3/81 1/8 2 12 1 5/81 3/8 2 12. 2 16 8 2 8 2 8 2 8 8 8 8 12 8 12 8 12 8 12 12 12. 2 1 3/8 7/8 1 3/8 1 1 5/8 1 1 /8 2 1 1/4 7 /8 1 1 /2 1 1 3/8 1 1 /8 1 5/8 1 1 /4 1 7/8 1 1/2 1 3/8 1 5/8 1 7/8. Length of Bolts in. mm. 114 4 1/2 Length of Bolts 5 127 in. mm. 5 1/4 133 1 4 /2 114 6 152 6 3/4 5 171 127 1 7 5 /4 178 133 8 6 2 3 152 3 8 3/46 /4 222 171 9 7 229 178 1 1/4 8 26 2 3 11 3/48 3/4 298 222 6 9 152 229 61/21 1/4 165 26 6 11 3/4 152 298 7 6 178 152 7 3/4 61/2 197 165 8 6 2 3 152 9 7 229 178 9 1/27 3/4 241 197 1 1/4 8 26 2 3 11 3/4 9 298 229 141/29 1/2 368 241 6 1 1/4 152 26 61/211 3/4 165 298 71/4 1 184 14 /2 368 8 23 6 152 1 1 254 6 /2 165 1 3/4 1 273 7 /4 184 12 35 8 23 13 3/4 349 1 254 1 3/4 273 12 35 13 3/4 349. P Ring Num er. "R" Gasket Standoff in. mm.. 23 P Ring 26 Num er 31 23 37 41 26 45 31 49 37 53 41 57 45 65 49 73 53 24 57 27 65 31 73 37 24 41 27 45 31 49 37 53 41 57 45 66 49 74 53 24 57 27 66 35 74 39 24 44 27 46 35 5 39 54 44 46 5 54. 3/16. 3/"R" 16 3/16 3/16 3/16 3/16 3/16 3/16 3/16 3/16 1/8 3/16 3/16 3/16 3/16 3/16 3/16 3/16 3/16 3/16 5/32 3/16 3/16 3/16 3/16 3/16 3/16 3/16 5/32 5/32. 48 Gasket Standoff 48 in. mm. 48 3/16 48 48 3/16 48 48 3/16 48 48 3/16 48 48 3/16 48 48 3/16 48 48 3/16 48 48 3/16 33 48 3/16 48 48 3/16 48 48 1/8 4 8 33 3/16 4 8 48 3/16 4 8 48 3/16 4 8 48 3/16 4 8 48 3/16 4 8 48 3/16 4 8 48 3/16 4 1 48 3/16 4 8 48 4 8 3/16 48 4 8 5/32 41 3/16 4 8 48 3/16 4 8 48 3/16 4 8 48 48 3/16 48 4 1 3/16 48 41 3/16 48 3/16 48 5/32 41 5/32 41.
(11) API Type 6BX Flanges Sizes in.. Ouside Diameter mm.. in.. Number of Bolts. Diameter of Bolts, in.. in.. mm.. 1 040. 20. 1 3/4. 13 3/4. 350. 167. 14 1/4. mm.. Length of Bolts. API Ring Number. 2,000 psi (13.8 MPa) working pressure. 26 3/4 30. 762. 44 19. 1 125. 32. 1 5/8. 360. 303. 3,000 psi (20.7 MPa) working pressure. 26 3/4. 680. 43 38. 1 100. 24. 2. 17. 430. 168. 30. 762. 46 68. 1 185. 32. 1 7/8. 17 3/4. 440. 303. 5,000 psi (34.5 MPa) working pressure. 13 5/8. 346. 26 50. 675. 16. 1 5/8. 12 1/2. 315. 160. 14 1/2. 365. 162. 440. 163. 10,000 psi (69.0 MPa) working pressure. 425. 30 38. 770. 16. 1 7/8. 18 3/4. 476. 35 62. 905. 20. 2. 17 1/2. 21 1/4. 540. 39 00. 990. 24. 2. 18 3/4. 470. 165. 1 13/16. 46. 7 38. 190. 8. 3/4. 5. 130. 151. 5 1/4. 2 1/16. 52. 7 88. 200. 8. 3/4. 130. 152. 2 9/16. 65. 9 12. 230. 8. 7/8. 6. 150. 153. 3 1/16. 78. 10 62. 270. 8. 1. 6 3/4. 170. 154. 4 1/16. 103. 12 44. 315. 8. 1 1/8. 8. 200. 155. 12. 1 1/8. 8 3/4. 220. 169. 11 1/4. 285. 156. 13. 330. 157. 130. 14 06. 360. 7 1/16. 179. 18 88. 479. 12. 1 1/2. 9. 228. 21 75. 555. 16. 1 1/2. 11. 279. 25 75. 655. 16. 1 3/4. 15. 380. 158. 13 5/8. 346. 30 25. 770. 20. 1 7/8. 17 1/4. 440. 159. 16 3/4. 425. 34 31. 870. 24. 1 7/8. 17 1/2. 440. 162. 18 3/4. 476. 40 94. 1 040. 24. 2 1/4. 22 1/4. 570. 164. 24. 2 1/2. 24 1/2. 620. 166. 5 1/2. 540. 45 00. 1 13/16. 46. 8 19. 210. 8. 7/8. 140. 151. 2 1/16. 52. 8 75. 220. 8. 7/8. 6. 150. 152. 2 9/16. 65. 10 00. 250. 8. 1. 6 3/4. 170. 153. 3 1/16. 78. 11 31. 290. 8. 1 1/8. 7 1/2. 190. 154. 4 1/16. 103. 14 91. 360. 8. 1 3/8. 9 1/4. 235. 155. 7 1/16. 179. 19 88. 505. 16. 1 1/2. 12 3/4. 325. 156. 9. 228. 25 50. 650. 16. 1 7/8. 15 3/4. 400. 157. 11. 279. 32 00. 815. 20. 2. 19 1/4. 490. 158. 13 5/8. 346. 34 88. 885. 20. 2 1/4. 21 1/4. 540. 159. 18 3/4. 476. 45 75. 1 160. 20. 3. 26 3/4. 680. 164. 1 13/16. 46. 10 12. 255. 8. 1. 7 1/2. 190. 151. 2 1/16. 52. 11 31. 285. 8. 1 1/8. 8 1/4. 210. 152. 2 9/16. 325. 8. 1 1/4. 9 1/4. 235. 153. 21 1/4. 20,000 psi (138.0 MPa) working pressure. 41 00. 16 3/4. 5 1/8. 15,000 psi (103.5 MPa) working pressure. 680. 1 145. 65. 12 81. 3 1/16. 78. 14 06. 355. 8. 1 3/8. 10. 255. 154. 4 1/16. 103. 17 56. 445. 8. 1 3/4. 12 1/4. 310. 155. 7 1/16. 179. 25 81. 655. 16. 2. 17 1/2. 445. 156. 9. 228. 31 69. 805. 16. 2 1/2. 22 3/8. 570. 157. 11. 279. 34 75. 880. 16. 2 3/4. 23 3/4. 605. 158. 13 5/8. 346. 45 75. 1 160. 20. 3. 30. 760. 159. 2,000 psi 138 bars, 3,000 psi 207 bars, 5,000 psi 345 bars, 10,000 psi 690 bars, 15,000 psi 1,035 bars, 20,000 psi 1,. 380 bars. 10.
(12) WORLDWIDE SALES & SERVICE DRIL-QUIP WESTERN HEMISPHERE. DRIL-QUIP EASTERN HEMISPHERE. DRIL-QUIP ASIA PACIFIC. DRIL-QUIP, INC. World Headquarters. DRIL-QUIP (Europe), Ltd.. DRIL-QUIP Asia Pacific Pte. Ltd.. DRIL-QUIP do Brasil, LTDA.. DRIL-QUIP London. DRIL-QUIP China. Macaé, Brazil Tel (55) 22 2791 8950 Fax (55) 22 2791 8989. High Wycombe, Bucks, England Tel (44) 1494 601086 Fax (44) 1494 601094. DRIL-QUIP New Orleans. DRIL-QUIP Norway. DRIL-QUIP Egypt. DRIL-QUIP The Netherlands. Alexandria, Egypt Tel (20) 3 450 0507 Fax (20) 3 450 0508. 6401 North Eldridge Pkwy. Houston, Texas 77041 Tel (713) 939 7711 Fax (713) 939 8063. New Orleans, Louisiana Tel (504) 522 5566 Fax (504) 522 4426. Stoneywood Park, Dyce Aberdeen, Scotland, UK AB21 7DZ Tel (44) 1224 727000 Fax (44) 1224 727070. Stavanger, Norway Tel (47) 51 443700 Fax (47) 51 443701 Beverwijk, The Netherlands Tel (31) 251 22 9250 Fax (31) 251 22 0044. DRIL-QUIP Denmark Esbjerg, Denmark Tel (45) 7518 0944 Fax (45) 7518 0640. www.dril-quip.com 072214T. © 2014 Dril-Quip, inc. Printed in the USA. No. 80 Tuas West Drive Singapore, 638417 Tel (65) 6861 0600 Fax (65) 6861 5700. Shekou, P. R. China Tel (86) 75 5268 97137 Fax (86) 75 5268 97134. Zahraa El-Maadi, Cairo, Egypt Tel (20) 22 753 8809 Fax (20) 22 753 8907. DRIL-QUIP Nigeria, Ltd. Port Harcourt, Nigeria Tel (234) 84 463866 Fax (234) 84 463649 DRIL-QUIP (Ghana) Ltd. Takoradi, Ghana Tel: (233) 312 5384. DRIL-QUIP Oilfield Services (Tianjin) Co., Ltd. Tanggu, Tianjin, P. R. China Tel (86) 22 2580 7466 Fax (86) 22 2580 7130. DRIL-QUIP Malaysia. Kuala Lumpur, Malaysia Tel (60) 3 2168 4308 Fax (60) 3 2168 4201. D.Q. Holdings Pty., Ltd. Perth, Australia Tel (61) 8 9322 8600 Fax (61) 8 9322 8500. DRIL-QUIP Qatar. Doha, Qatar Tel (974) 44389715 Fax (974) 44417041. DRIL-QUIP Indonesia Jakarta, Indonesia Tel (62) 21 720 0612 Fax (62) 21 720 1513.
