(1)

Channel Partner-India:

SYSTEM CONTROLS & SWITCHGEARS

www.systemcontrols.co.in

Electromechanical &

Numerical Relays

REFERRAL GUIDE

(2)

A. Electromechanical Relays

Sr. Model of relay REFERAL PRICE ANSI Code

No

1 CCUM21, 1 ½ D Vert ,2NO S/R Reverse Power Relay 25540 32 2 CDG11,1D Vert , 2NO S/R 1 Element O/C or E/F 6150 51 or 51 N 3 CDG31,3DHorz,2NO S/R 3 Element O/C or E/F 17330 51 or 51 & 51 N

4 CDG61,3D Horz,2NO S/R 3 Element O/C & E/F with high Set 29970 51 & 50 or 51,50, 51N, 50 N 5 CDV62,3D Horz,2NO S/R O/C Relay Voltage Restrained 27470 51 V

6 VDG11,1D Vert,110 V AC Inverse O/V Relay 10440 59 7 VDG13,ID Vert,110 V AC Inverse U/V Relay 11560 27 8 VDG14,1D Vert Field Failure Neutral Displacement 12800 59N 9 CAG12, AC instantaneous )/C or E/F relay 4280 50 10 CAG14,1D Vert Restricted Earth Fault 8770 87 N, 64 R 11 CAG34,1D , Vert Generator Differential 18940 87 12 VAA11, 1/4 N Vert, 2NO+2C/O S/R , Auxilliary with S/R 2880 30 13 VAA12, 1/4 N Vert, 2NO+2C/O S/R / H/R Auxilliary with S/R+H/R 2830 30 14 VAA13, 1/4 N Vert, 2NO+2C/O H/R Auxilliary with H/R 2830 30 15 VAA21,1/2N Horz, 2NO+1N/C S/R Auxilliary with S/R 4700 30 16 VAA22,1/2 N Horz, 2NO+1C/O ,S/R / H/R Auxilliary with S/R+H/R 4690 30 17 VAA23, ½ N Vert, 2NO+1C/O, H/R Auxilliary with H/R 4490 30 18 VAA31,1/2N Horz , 2NO S/R Auxilliary with S/R 4900 30 19 VAA32,1/2N Horz , 2NO S/R / H/R Auxilliary with S/R+H/R 5260 30 20 VAA33, ½ N Horz,2NO H/R Auxilliary with H/R 4920 30 21 VAG11, 1/4N Vert Auxilliary with S/R U/V or O/V Instantaneous 3070 27 or 59 22 VAGM22,1D Vert , 110 V AC U/V or O/V variable Seting 8900 27 or 59 23 VAJC11, Single element voltage operated control relay with 8980 83

electrical reset contacts 1/2n Case

24 VAJH13,1/4N Vert Master Trip Relay 2720 86 25 VAJH23,1/2 N Vert Master Trip Relay 5320 86 26 VAJHM13, Single element high speed tripping relay with hand 3160 86

reset contacts. 1/4 N Vertical

27 VAJHM23, Two element high speed tripping relay with hand 5320 86 reset contacts. ½ N Horizontal

28 VAM12 Semaphore Indicator 2490 -29 VAM22 Semaphore Indicator 2860 -30 VAX31, ½ N Horz Trip Ckt Supervision 5650 95 TC 31 CTNM12, ½ N Horz Negative Phase Sequence 7390 46 32 SKE11,1D Vert Check Synchronising 57900 25 33 VTT11, 1/2N Horz TIMER, Time Delay For DC Relay 6340 2 34 VTT11, 1/2N Horz TIMER, Time Delay For aC Relay 8450

35 MFVUM12 Under/Over Frequency 1 Stage 50260 81 36 MFVUM22 Under/Over Frequency 2 Stage 63360 81 37 VAPM 31, Fuse Failure Relay 11680 60 38 DTH31 Transformer Differential 71490 87 39 CAEM 21, Battery Earth Fault Relay 17300 95 Battery 40 CTU12, Static definite time single pole O/C or 13050 50 or 50 N

E/F Relay-1D VERT

41 CTU32, Three pole static 3 O/C or 2 O/C & 1 E/F relay , 1D VERT 18000 50 or 50 & 50 N 42 CTU 62, Three pole definite time static O/C relay instantaneous 18960 50 or 50 & 50 N

with highset.-1D VERT

43 CTU15, Single pole sensitive definite time static E/F relay 30790 50 44 CTUM15, Single pole definite time static sensitive E/F relay 11600 50N

PRICES APPLICABLE FOR DC Relay only

**** **** **** **** **** **** **** **** **** #### ****

(3)

Application Model ANSI Code Price Input Output Case Size/Cut Out Dimensions P141 50/51/67,50N/51N/67N, 67N, 67W, 170000 8 7 40 TE YN, 64, 51V, 46, 49, 37P/37N, 27, 59, 59N, 47, 81U, 81O, 81R, BC, 50BF, VTS, CTS, 49SR, 50/51P 67P ,87R ,86 ,32 P142 50/51/67, 50N/51N/67N, 67N, 67W, 180000 8 7 40 TE YN ,64, 51V, 46, 49, 37P/37N, 27, 59, 59N, 47, 81U, 81O, 81R, BC 50BF, VTS, CTS, 49SR, 79, 50/51P, 67P, 87R, 86, 32 P143 50/51/67, 50N/51N/67N, 67N, 67W, 196000 16 14 60 TE YN, 64, 51V, 46, 49, 37P/37N, 27, 59, 59N, 47, 81U, 81O, 81R, BC, 50BF, VTS, CTS, 49SR, 79, 25, 50/51P, 67P, 87R, 86, 32 P144 50/51/67, 50N/51N/67N, 67N, 67W, 210000 8 7 60 TE YN, 64, 51V, 46, 49, 37P/37N, 27, 59, 59N, 47, 81U, 81O, 81R, BC, 50BF, VTS, CTS, 49SR, 79, 50/51P, 67P, 87R, 86, 32 P145 50/51/67, 50N/51N/67N, 67N, 67W, 239500 16 16 60 TE YN, 64, 51V, 46, 49, 37P/37N, 27, 59, 59N, 47, 81U, 81O, 81R, BC, 50BF, VTS, CTS, 49SR, 79, 25, 50/51P, 67P, 87R, 86, 32 FEEDER

B. Numerical Relays

MiCOM

ALSTOM

P14x

Feeder Protection

(4)

Application Model ANSI Code Price Input Output Case Size/Cut Out Dimensions P241 50/51, 50N/51N, 50N/51N/67N, 136500 8 7 40 TE 32N/64N, 50BF, 66, 37, 46, 32R, without 47, 49, 27/59, 59N, 81U, 48/51LR, RTD, 51S, 14, 26 185500 with RTD P242 50/51, 50N/51N, 50N/51N/67N, 220000 16 16 60 TE 32N/64N, 50BF, 66, 37, 46, 32R, 47, 49, 27/59, 59N, 81U, 48/51LR, 51S, 14, 26 P243 50/51, 50N/51N, 50N/51N/67N, 279500 16 16 80 TE 32N/64N, 50BF, 66, 37, 46, 32R, 47 49, 87, 27/59, 59N, 81U, 48/51LR, 51S, 14, 26 MOTOR

MiCOM ALSTOM P24x

Motor Protection

P241 in 40 TE P241 in 80 TE

(5)

MiCOM ALSTOM P34x

MiCOM ALSTOM P34x

Application Model ANSI Code Price Input Output Case Size/Cut Out Dimensions P341 81R, ? Vè, 50/51/67, 50N/51N/67N, 310000 8 7 40 TE 67N/67W, 64, 59N, 27/59, 81U/81O 32R/32L/32O, 49, 46, 47, 50BF P342 50/51/67, 50N/51N, 67N/67W, 64, 359500 8 7 40 TE 51V, 21, 59N, 27/59, 81U/81O,

81AB, 32R/32L/32O, 40, 46T, 46OC, 47, 49, 24, 50BF, 49G, 49T, 64R, 81R, 37P/37N, 25

P343 87, 50/51/67, 50N/51N, 67N/67W 439000 16 14 60 TE, 64, 51V, 21, 59N, 27/59, 81U/81O,

81AB, 32R/32L/32O, 40, 46T, 46OC, 47, 49, 24, 78, 27TN/59TN, 50/27, 50BF, 49G, 49T, 64R, 81R, 37P/37N, 25

P344 87, 50/51/67, 50N/51N, 67N/67W, 469000 24 24 80 TE 64, 51V, 21, 59N, 27/59, 81U/81O,

81AB, 32R/32L/32O, 40, 46T, 46OC, 47, 49, 24, 78, 27TN/59TN, 50/27, 50BF, 49G, 49T, 64R, 81R, 37P/37N, 25

P345 87, 50/51/67, 50N/51N, 67N/67W, 519000 24 24 80 TE 64, 51V, 21, 59N, 27/59, 81U/81O,

81AB, 32R/32L/32O, 40, 46T, 46OC, 47, 49, 24, 78, 27TN/59TN, 50/27, 50BF, 64S, 49G, 49T, 64R, 81R, 37P/37N, 25

P346 87, 50/51/67, 50N/51N, 67N/67W, 399000 16 14 60 TE 64, 51V, 21, 59N, 27/59, 81U/81O,

81AB, 32R/32L/32O, 40, 46T, 46OC, 47, 49, 24, 50BF, 49G, 49T, 64R, 81R, 37P/37N, 25

INTERCON-NECTION & GENERATOR

Interconnection & Generator Protection

(6)

Application Model ANSI Code Price Input Output Case Size/Cut Out Dimensions P441 21P, 21G, 50/51/67, 50N/51N/67N, 299500 8 14 40 TE 67N, 32N, 67/46, 68, 50/27, 85, 49, 79, 25, 27, 59, 46BC, 50ST, 50BF, VTS, CVTS, CTS, 51FF, 21/21N, 78, 50/51P, 67P, 46, 59N P442 21P, 21G, 50/51/67, 50N/51N/67N, 359500 16 21 60 TE 67N, 32N, 67/46, 68, 50/27, 85, 49, 79, 25, 27, 59, 37, 81U/O, 46BC, 50ST, 50BF, VTS, CVTS, CTS, 51FF, 21/21N, 78, 50/51P, 67P, 46, 59N P443 21P/21G, 85, 50/27, 68, 78, ? I/? V, 558600 16 24 80 TE 67N, 50/51/67, 50N/51N/67N, 67/46, 46BC, 49, 27, 59, 59N, 50BF, CTS/VTS, 79, 25, FL, 21/21N, 78, 50/51P, 67P, 46, 59N, 81R P444 21P, 21G, 50/51/67, 50N/51N/67N, 499000 24 32 80 TE 67N, 32N, 67/46, 68, 50/27, 85, 49, 79, 25, 27, 59, 37, 81U/O, 46BC, 50ST, 50BF, VTS, CVTS, CTS, 51FF, 21/21N, 78, 50/51P, 67P, 46, 59N P445 21P/21G, 85, 50/27, 68, 67N, 598500 8 8 40 TE 50/51/67, 50N/51N/67N, 67/46, 46BC, 49, 27, 59, 59N, 50BF, CTS/VTS, 79, 25, FL, 21/21N, 78, 50/51P, 67P, 46, 59N, 81R DISTANCE

MiCOM ALSTOM P44x

(7)

Application Model ANSI Code Price Input Output Case Size/Cut Out Dimensions P642 87T, 64, 49, 24, 50/51, 50N/51N, 279500 8 8 40 TE 46, 50BF, CTS, TCS, 87G/64, 50/51P P643 87T, 64, 49, 24, 50/51, 50N/51N, 379000 16 16 60 TE 46, 67/67N, 50BF, 27/59/59N, 81U/81O, VTS, CTS, TCS, 87G/64, 50/51P, 67P P645 87T, 64, 49, 24, 50/51, 50N/51N, 459000 16 16 60 TE 46, 67/67N, 50BF, 27/59/59N, 81U/81O, VTS, CTS, TCS, 87G/64, 50/51P, 67P MX3DPT3A 87T ,50BF 154000 TRANSFORMER

MiCOM ALSTOM P64x

(8)

MX RANGE

Application Description Model ANSI Code Price

Number

Multifunction numerical 3 Phase current and earth MX3AJ30A 49-49-50-51-51-fault relay for HV,MV,LV cables and machinery. MX3AJ30F 37-50N-51N-51N

Numerical protection and control for MV and MX3AJM30A 49-49-49-50-46-LV motors 51R-37-51N-66

Multifunction numerical 3 Phase and earth fault MX3AM30A 50-51-51-50N-over current relay for HV,MV,LV applications 51N-51N

Multifunction numerical sensitive directional earth MX3AMD0A 67N-67N-67N-59N fault relay for HV,MV,LV applications

Multifunction numerical 3 Phase directional MX3AMD3A 67-67-67 overcurrent relay for HV,MV,LV applications

Multifunction numerical 2 Phase directional MX3AMD20A 67-67-67-67N- On request overcurrent ans sensitive directional earth fault 67N-67N-59N

relay for HV,MV,LV applications

Multifunction numerical 3 Phase overcurrent and MX3AMD30A 51-51-50-67N-67N sensitive directional earth fault relay for HV,MV,LV -67N-59N applications

Numerical 3 phase biased differential protection MX3DPT3A 87T for two windings transformer application

Numerical high impedance differential for MX3DVZ3A 87S(51N-51N-27 -59 50BF)

Numerical module for automatic synchronizing MX3EG1A 90F-90U-25 of generators

Numerical 3 Phase biased differential protection MX3DPG3A 87G for generator and motor application

(9)

MX RANGE

Application Description Model ANSI Code Price

Number

Numerical measurement module MX3IM1A

-Numerical integrated generator protection MX3IPG1A 49-49-51-51-50 (51V)-51N-51N- 50N-21-21-46-46- 27-59-40-40/78-32R-32-32-37 Numerical integrated generator protection MX3IPG2A 64R-27dc-59dc (Rotor and auxillary protection)

Multifunction numerical voltage relay for MX3VIC30A 27-27-59-59-47 HV,MV,LV applications MX3VIC30F (U2>)-81<-81<-81<

-81<-81>24(U/f>)-59N-59N Multifunction numerical voltage relay for MX3VIR30A 27-27-59-59-81< HV,MV,LV applications -81<-81>-81>

-59N-59N On request Numeric integrated protection and control MX31PD1A 51-51-50-67N-67N

for MV distribution MX3IPD1B -67N-59N-79 Numerical integrated protection and control for MX3IPD2A 51-50-67N-97N-27 MV distribution -27-59-59-59N-32P

-32P-32Q-32Q-55 -55-79

Numeric automatic recloser for HV and MX3R1A 79 MV application

Numerical input/output (I/O)module MX3MUX1A MX3MUX1B

Power voltage and frequency numerical MX3P3A 32-32-32(P)-32-32(Q)-37-37(Q) -32(P mean_-32 (Q mean)-55<-27 -27-59-59-59N-81< -81<-81>-81>

(10)

A Single window solution for every electrical installation

Channel Partner UNIVERSAL TRANSFORMER A Brand of Schneider Electric PIERLITE

Making Energy Matters TRINITY

30 / 30, GF East Patel Nagar, New Delhi - 110 008 Phone: 45631920 (100 lines), Fax: 45631903 E - m a i l : s y s t e m . c o n t r o l s @ g m a i l . c o m Customer Care: 9717003397, custcare.scs@gmail.com

SYSTEM CONTROLS & SWITCHGEARS
